0621
MRGB10W
USER’S MANUAL
10" (254 mm) MARINE DUAL 2Ω SUBWOOFER
FEATURING MULTICOLOR ILLUMINATION AND PATTERN OPTION
BOSS Audio Systems
3451 Lunar Court • Oxnard, CA 93030
www.bossaudio.com
805-751-4853 Customer Service
Tech Support: www.bossaudio.com/support
Congratulations on your purchase of the Boss Audio Phantom Subwoofer.
Boss Audio takes great pride in producing products that sound great and
stand up to the daily rigors applied by audio enthusiasts around the world.
If you need technical support with your Boss Audio product or have
questions about its use, please contact us:
805.751.4853
www.bossaudio.com
Technical Support
5
Since the woofer has a pole-vent, it needs a minimum clearance from the rear wall
enclosure of 0.75" (19 mm).
maximum output while retaining great sound quality.
The dimensions have already accounted for the volume displacement of the subwoofer,
and using 0.75" (19 mm) MDF. All dimensions are external.
Enclosures
Enclosure Dimensions
Sealed Dimensions:
Length (L) : 17" (432 mm)
Width (W) : 9" (229 mm)
Height (H) : 12" (305 mm)
Cut-out Diameter: 9.125" (232 mm)
Internal Volume: 1ft3
Ported Dimensions:
Length (L) : 24" (610 mm)
Width (W) : 12" (305 mm)
Height (H) : 12" (305 mm)
Port Diameter: 4" (102 mm)
Port Length : 13" (330 mm)
Internal Volume: 1.9ft3
The MRGB10W is designed to work in a medium sized or ported
enclosure.
H
L
W
Power ON/OFF Light Mode
Lighting Changing
Speed Up
Light Bright Up
Light Bright Down
Light Changing
Speed Down
Light Color Change
6
Wireless Remote Control
Functions
Dual 2Ω Voice Coils
800W Peak Power Handling
MRGB10W - 10" SUBWOOFER
Polypropylene Cone with Rubber Surround
4
Multiple Subwoofers
Parallel Series
1 Ω 4 Ω
-
Wiring Options
+ +
--
+ +
--
+
-
+
+
-
+
-
+
Series
2 Ω
Parallel
0.5 Ω
-
+
-
+
-
+
-
+
5
Since the woofer has a pole-vent, it needs a minimum clearance from the rear wall
enclosure of 0.75" (19 mm).
maximum output while retaining great sound quality.
The dimensions have already accounted for the volume displacement of the subwoofer,
and using 0.75" (19 mm) MDF. All dimensions are external.
Enclosures
Enclosure Dimensions
Sealed Dimensions:
Length (L) : 17" (432 mm)
Width (W) : 9" (229 mm)
Height (H) : 12" (305 mm)
Cut-out Diameter: 9.39" (238.5 mm) Cut-out Diameter: 9.39" (238.5 mm)
Internal Volume: 1ft3
Ported Dimensions:
Length (L) : 24" (610 mm)
Width (W) : 12" (305 mm)
Height (H) : 12" (305 mm)
Port Diameter: 4" (102 mm)
Port Length : 13" (330 mm)
Internal Volume: 1.9ft3
The MRGB10W is designed to work in a sealed or ported enclosure.
H
L
W
Congratulations on your purchase of the Boss Audio Phantom Subwoofer.
Boss Audio takes great pride in producing products that, sound great and
stand up to the daily rigors applied by audio enthusiasts around the world.
If you need technical support with your Boss Audio product or have
questions about it's use, please contact us:
805.751.4853
www.bossaudio.com
1
Technical Support
2
Dual 2Ω Voice Coil
800W Peak Power Handling
MRGB10W - 10" SUBWOOFER
Polypropylene Cone with Rubber Surround
6
Wireless Remote Control
Functions
Turn the LED light
Power Button
Switch to dynamic lighting
and select a mode change
speed (10 options)
Speed Buttons
Switch to static lighting
and select a light mode
(20 options)
Observe correct polarity while inserting the battery. Replace only with the same
type or equivalent type.
excessive heat.
Remove the battery from the remote control if not used for a long time.
The remote control contains a coin/button type battery, which can be swallowed.
Keep the battery out of reach of children at all times! If swallowed, the battery can
cause serious injury or death.
Color Buttons
Important notes on battery
Switch to dynamic lighting
and select a light mode
(22 options)
Mode Buttons
Select a brightness level
for static lighting
(5 options)
Brightness Buttons
Show 17 dynamic lighting
modes in loop. Each mode
repeats three times.
Demo Button
OPEN
CR2025 battery
replacement
7
0821
Impedance Dual 2Ω
Resonant Frequency 40 Hz
Qts 0.68
Qms 7.15
Qes 0.77
Vas 0.96 f
3
(27.1 L)
Xmax (OneWay) 10 mm
Sensitvity (1 W/ 1 m) 85 dB
Peak Power Handling 800 W
Mounting Depth 4.57" (116 mm)
Cut-out Diameter 9.39" (238.5 mm)
021
MRGB10W
USER’S MANUAL
10" (254 mm) MARINE 4Ω SUBWOOFER
FEATURING MULTICOLOR ILLUMINATION AND PATTERN OPTION
BOSS Audio Systems
3451 Lunar Court • Oxnard, CA 93030
www.bossaudio.com
805-751-4853 Customer Service
Tech Support: www.bossaudio.com/support
