Technical Support
If you need technical support with your BOSS AUDIO product or have
quesons about its use, please contact us:
800.999.1236
www.BossAudio.com
6
Due to ongoing product development, specicaons are subject to change without noce.
BE10D_1216
1
Congratulaons on your purchase of the BOSS AUDIO Subwoofer.
BOSS AUDIO takes great pride in producing products that look great,
sound great, and stand up to the daily rigors applied by audio enthusi-
asts around the world.
BE10D 10” Subwoofer
Dual 4 Ω Voice Coils
800 W Peak Power Handling
Rubber Surround
2
5
Enclosures
The BE10D will work in both sealed and ported enclosures.
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality.
The dimensions have already accounted for the volume displacement
of the subwoofer, and using 3/4” (19mm) MDF.
All dimensions are external.
Enclosure Dimensions
Sealed Dimensions:
Height (H) : 12” (305 mm)
Depth (D) : 10” (254 mm)
Width (W) : 15” (381 mm)
Cutout Diameter: 9-1/4” (235 mm)
Ported Dimensions:
Height (H) : 12” (305 mm)
Depth (D) : 10” (254 mm)
Width (W) : 18” (457 mm)
Port Diameter : 3.5” (89 mm)
Port Length : 10” (254 mm)
Tuning Freq : 45 Hz
8 Ω 2 Ω
Wiring your Subwoofer
4
Mulple Subwoofers
4 Ω
1 Ω
3
Product Specicaons
Impedance Dual 4 Ω
Resonant Frequency 44 Hz
Qts 0.48
Qms 2.37
Qes 0.60
Vas 1.01 ³ (28.7 liters)
Xmax 9 mm
Sensivity (1 W/ 1 m) 88 dB
Peak Power Handling 800 W
Mounng Depth 4-5/8” (118 mm)
Cutout Diameter 9-1/4” (235 mm)
8 Ω 2 Ω
Wiring your Subwoofer
4
Mulple Subwoofers
4 Ω
1 Ω
3
Product Specicaons
Impedance Dual 4 Ω
Resonant Frequency 44 Hz
Qts 0.48
Qms 2.37
Qes 0.60
Vas 1.01 ³ (28.7 liters)
Xmax 9 mm
Sensivity (1 W/ 1 m) 88 dB
Peak Power Handling 800 W
Mounng Depth 4-5/8” (118 mm)
Cutout Diameter 9-1/4” (235 mm)
BE10D 10” Subwoofer
Dual 4 Ω Voice Coils
800 W Peak Power Handling
Rubber Surround
2
5
Enclosures
The BE10D will work in both sealed and ported enclosures.
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality.
The dimensions have already accounted for the volume displacement
of the subwoofer, and using 3/4” (19mm) MDF.
All dimensions are external.
Enclosure Dimensions
Sealed Dimensions:
Height (H) : 12” (305 mm)
Depth (D) : 10” (254 mm)
Width (W) : 15” (381 mm)
Cutout Diameter: 9-1/4” (235 mm)
Ported Dimensions:
Height (H) : 12” (305 mm)
Depth (D) : 10” (254 mm)
Width (W) : 18” (457 mm)
Port Diameter : 3.5” (89 mm)
Port Length : 10” (254 mm)
Tuning Freq : 45 Hz
