User Manual
7 Inch Utral-thin TFT LCD Monitor HD 800x480
After-sale service mail box: support@toguard.cc
Please feel free to contact us if there any problem with your purchase
Packing Content:
1 x 7 inch Monitor
1 x Bracket (with Double-sided Adhesive）
1 x Video Cable
1 x USB Cable ( ONLY for power supply use, NO data transfer function )
1 x VGA Cable ( Mini USB to VGA )
1 x Power Adapter
1 x Remote Control
1 x User Manual
Use r Manua l
7 Inch U tral- thin TF T LCD Mon itor HD 1 024x6 00
After-sale service mail box: [email protected]
Please feel free to contact us if there any problem with your purchase
D701
PO WER
VO L-
ME NU
VO L+ MO DE
ULTR A - T HIN
7
TF T LCD C OL OR MO NI TOR
Re m ote
co n trol
To u ch
bu t ton
1. Remote Controller Key Function:
Power switch
AV1/AV2
select
Display M ODE
shift
Volume adjust
MENU adjust
MENU
2. Monitor Key Function:
TOUCH
BUTTONS
(1) VGA resolution ratio, please refer to the description of the matching label on the
back of the machine.
(2) HDMI support two versions as 1.1 and 1.2,and support 720P&1080P video display.
(3) The machine will automatically turn off the screen as without signal for 1 minute,
the screen will turn on again if you connect signals or turn on the machine then.
(4) If you don’t want close the key pressing voice, please enter manual to close it.
(5) Please Peel OFF the screen protect film if there have scratches.
3. Interface Diagram:
AV
HDMI
VGA
Trumpet
DC 12V
USB 5V/2A
Warm Tips:
1. Working voltage please refer to the description of the label on the back of the
machine.
2. Note that do not reverse the red and black lines.
3. When backing the car, the monitor will automatically power on, and show AV2
picture.
4.Please change to the right signal input mode when screen show “No Signal”.
