Technical Support
If you need technical support with your BOSS AUDIO product or have
quesons about its use, please contact us:
800.999.1236
www.BossAudio.com
6
Due to ongoing product development, specicaons are subject to change without noce.
BE8D_1216
1
Congratulaons on your purchase of the BOSS AUDIO Subwoofer.
BOSS AUDIO takes great pride in producing products that look great,
sound great, and stand up to the daily rigors applied by audio enthusi-
asts around the world.
BE8D 8” Subwoofer
Dual 4 Ω Voice Coils
600 W Peak Power Handling
Rubber Surround
2
5
Enclosures
The BE8D will work in both sealed and ported enclosures.
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality.
The dimensions have already accounted for the volume displacement
of the subwoofer, and using 3/4” (19mm) MDF.
All dimensions are external.
Enclosure Dimensions
Sealed Dimensions:
Height (H) : 10” (254 mm)
Depth (D) : 8” (203 mm)
Width (W) : 10” (254 mm)
Cutout Diameter: 7-1/4” (184 mm)
Ported Dimensions:
Height (H) : 11” (279 mm)
Depth (D) : 11” (279 mm)
Width (W) : 15” (381 mm)
Port Diameter : 3” (89 mm)
Port Length : 8” (203 mm)
Tuning Freq : 50 Hz
8 Ω 2 Ω
Wiring your Subwoofer
4
Mulple Subwoofers
4 Ω
1 Ω
3
Product Specicaons
Impedance Dual 4 Ω
Resonant Frequency 65 Hz
Qts 0.31
Qms 1.67
Qes 0.38
Vas 0.33 ³ (9.3 liters)
Xmax 7 mm
Sensivity (1 W/ 1 m) 90 dB
Peak Power Handling 600 W
Mounng Depth 3-3/4” (95 mm)
Cutout Diameter 7-1/4” (184 mm)
8 Ω 2 Ω
Wiring your Subwoofer
4
Mulple Subwoofers
4 Ω
1 Ω
3
Product Specicaons
Impedance Dual 4 Ω
Resonant Frequency 65 Hz
Qts 0.31
Qms 1.67
Qes 0.38
Vas 0.33 ³ (9.3 liters)
Xmax 7 mm
Sensivity (1 W/ 1 m) 90 dB
Peak Power Handling 600 W
Mounng Depth 3-3/4” (95 mm)
Cutout Diameter 7-1/4” (184 mm)
BE8D 8” Subwoofer
Dual 4 Ω Voice Coils
600 W Peak Power Handling
Rubber Surround
2
5
Enclosures
The BE8D will work in both sealed and ported enclosures.
Below you will nd the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality.
The dimensions have already accounted for the volume displacement
of the subwoofer, and using 3/4” (19mm) MDF.
All dimensions are external.
Enclosure Dimensions
Sealed Dimensions:
Height (H) : 10” (254 mm)
Depth (D) : 8” (203 mm)
Width (W) : 10” (254 mm)
Cutout Diameter: 7-1/4” (184 mm)
Ported Dimensions:
Height (H) : 11” (279 mm)
Depth (D) : 11” (279 mm)
Width (W) : 15” (381 mm)
Port Diameter : 3” (89 mm)
Port Length : 8” (203 mm)
Tuning Freq : 50 Hz
Technical Support
If you need technical support with your BOSS AUDIO product or have
quesons about its use, please contact us:
800.999.1236
www.BossAudio.com
6
Due to ongoing product development, specicaons are subject to change without noce.
BE8D_1216
1
Congratulaons on your purchase of the BOSS AUDIO Subwoofer.
BOSS AUDIO takes great pride in producing products that look great,
sound great, and stand up to the daily rigors applied by audio enthusi-
asts around the world.
