Please read this manual carefully before using this product.
Control Panel
Air Outlet
Air Inlet
24V 1.75A
AR-400
3
300m /h
35W
221x221x372mm
3.2kg
2
24-40m
23-50dB(A)
Rated Voltage
Product Usage
Filtration
Rated Power
CADR
Noise
Effective Area
Product Size
Weight
Removes pollutants such as particulate matter, gaseous
pollutants and microorganisms in the air.
Pre-filter + HEPA filter + Activated Carbon Filter
AIRROBO Air Purifier
Product Name
Model Number
Filter
Replacement
Reminder
Sleep Mode
Fan Speed
Power
Timer
User Manual
TRUE HEPA AIR PURIFIER
Tech Specs How to Use How to clean or maintain
Product Introduction
◆ How to install the filter
Take the filter out from the plastic bag, insert the filter into the
bottom of AR400, twist clockwise, and tighten the filter.
How to remove the filter◆
Twist counterclockwise, rotate and pull out the filter from the
bottom of AR400.
Power: Plug the power plug into a wall socket or power extension. The
Power indicator will flash red to indicate that it has entered into the standby
state. Touch the Power button to turn on AR400. The AR400 will start working
in Fan Speed 2 at default.
Fan Speed: Once the AR400 is turned on, touch the Fan Speed button to
switch among Fan Speed 1, 2, 3 and Sleep mode.
Timer: Once the AR400 is turned on, touch the Timer button to set the
AR400 to stop working in 1-8 hours. During setting, the number of hours will
be shown on the control panel by flashing 3 times. After flashing, the timer
is successfully set. To cancel the Timer, please press and hold the Timer
button for longer than 2 seconds while the number of hours is flashing.
Filter Replacement Reminder: Please replace the filter when the indicator
of Filter Replacement Reminder is flashing. After replacing the filter, press
and hold the Filter Replacement Reminder button to reset it. (The reminder
is set to be activated after 1500 hours of usage)
Sleep Mode: Under the Sleep Mode, other indicators on the control panel
will be off, while indicator of Sleep Mode will be dimmed. To exit the Sleep
Mode, please touch the Fan Speed button.
3-in-1 Filter (Pre-filter+HEPA filter+Activated Carbon Filter) needs to be replaced
every 6-8 months under normal use.
After every 1500 hours of working, the indicator of Filter Replacement
Reminder will flash slowly to remind user to replace the filter. After
replacing the filter, press and hold the Filter Replacement Reminder
button for 3 seconds to reset it.
• Place the AR400 in a ventilated place for maximized performance. Do not expose it under
strong sunlight.
• The pre-filter should be cleaned every 2-4 weeks to increase the efficiency and extend
the life of your filter. Clean the pre-filter by using a soft brush or vacuum hose to remove
hair, dust, and large particles.
• Do not wash the filter with water or other liquids.
Tips
※
• Always unplug the power plug before cleaning and maintenance.
• Do not operate with the filter removed (the unfiltered dust may cause equipment
failure).
• If unused for an extended period, unplug the power cord and store the appliance
properly. (it will also consume power in the standby state).
• Depending on the environment and purpose of use (for example, for households with
a large number of smokers or areas with severe air pollution), the filter replacement
cycle may be shortened. If the filtration effect is reduced, please replace the filter in
time.
• When replacing the filter, please turn off the appliance first.
Reminder: Make sure to remove the plastic bag on the filter.
AR400
（3-in-1 Filter)
AIRROBO
www.air-robo.com
Please keep the manual properly for future reference.
