Thank you for purchasing this Armor All
®
wet/dry shampoo vacuum cleaner. Feel condent that
with our Armor All
®
wet/dry shampoo vac you are obtaining a high-quality product engineered
for optimal performance. This vacuum is capable of picking up liquids and dry materials.
FOR YOUR SAFETY: CAREFULLY READ AND UN DERSTAND ALL IN STRU CTI ONS.
TABLE OF CONTENTS
SECTION Page
3
3
6
7
7
8
11
13
14
16
19
20
21
22
22
23
25
26
IMPORTANT INFORMATION
GALLONS
"Tank Size" refers to the actual tank volume and does not reect capacity available during operation.
PEAK HP
"Peak Horsepower" is a term used in the wet-dry vac industry for consumer comparison purposes. It
does not denote the operational horsepower output of a wet-dry vac, but rather the horsepower output
of a motor, including the motor’s inertial contribution, achieved in laboratory testing. In actual use,
motors do not operate at the peak horsepower shown.
3
WARRANTY
We take pride in producing a high-quality, durable product. This vac carries a limited two (2) year
warranty against defects in workmanship and materials from date of purchase under normal household
use. Please keep your receipt as proof of purchase. This warranty gives you specic legal rights, and
you may have other rights, which vary from state to state.
For customer service please call 1-866-384-8432.
Not Covered by Warranty:
• Any part that has become inoperative due to misuse, negligence, direct/indirect abuse, accidents,
improper maintenance, repairs or alterations;
• Consumables such as lters and accessories;
• Normal wear and tear of parts and attachments, such as hose, nozzles, or casters;
• Normal deterioration of the exterior nish due to use or exposure;
• Any product where serial number/data label is tampered with or removed;
• Any product purchased from an unauthorized retailer.
READ AND UNDERSTAND ALL INSTRUCTIONS
BEFORE USING THIS VACUUM.
Read and understand this operator’s manual and all labels on the vacuum cleaner before operating.
Safety is a combination of common sense, staying alert and knowing how your vacuum works. Use
this vacuum only as described in this manual. To reduce the risk of personal injury or damage to your
vacuum, use only manufacturer recommended accessories.
When using a vacuum, basic precautions should always be followed including the following.
Failure to follow the warnings and instructions may result in explosion, fire and/or serious
injury.
• Do not run vacuum unattended.
• Do not use to pick up ammable or combustible liquids, such as gasoline, or use
in areas where they may be present.
•
Do not vacuum, or use this vacuum near ammable liquids, gases, or explosive
vapors like gasoline or other fuels, lighter uids, cleaners, oil-based paints, natural
gas, hydrogen, or explosive dust like coal dust, magnesium dust, grain dust, or
gun powder. Sparks inside the motor can ignite ammable vapors or dust.
I MPORTANT SAFETY I NSTRUCTI ONS
SAVE THI S M ANUAL FOR FUTURE REFEREN CE.
WARNING:
TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR INJURY:
4
• To reduce the risk of health hazards from vapors or dust, do not vacuum toxic
materials.
• Do not use or store near hazardous materials.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches,
or hot ashes.
• Do not expose to rain. Store indoors.
• If vacuum is not working as it should, has been dropped, damaged, left
outdoors, or dropped into water, return it to a service center.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not use with damaged cord or plug.
• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull
cord around sharp edges or corners.
• Keep cord away from heated surfaces.
• Do not run the vacuum over cord.
• Do not handle plug or vacuum with wet hands.
• Do not use without dust bag and/or lters in place.
• Do not allow to be used as a toy. Close attention is necessary when used by or
near children.
• To reduce the risk of injury from accidental starting, unplug power cord before
changing or cleaning lter.
• Do not leave vacuum when plugged in. Unplug from outlet when not in use and
before servicing.
• Turn off all controls before unplugging.
• Unplug before connecting or disconnecting hose, or any other accessories.
• Do not put any object into openings. Do not use with any opening blocked; keep
free of dust, lint, hair, and anything that may reduce air ow.
• Keep hair, loose clothing, ngers, and all parts of body away from openings and
moving parts.
• Use extra care when cleaning on stairs.
• Use only as described in this manual. Use only manufacturer’s recommended
attachments.
• Use only manufacturer's recommended cleaning solution with this vacuum. See
the Carpet/Upholstery Cleaning Operation section of this manual.
• This vacuum is provided with double insulation. Use only identical replacement
parts. See DOUBLE INSULATION INSTRUCTIONS.
CAUTION:
TO REDUCE THE RISK OF INJURY FROM
MOVING PARTS - UNPLUG BEFORE SERVICING.
5
FCC COMPLIANCE
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that
may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
SAVE THESE INSTRUCTIONS
For Household Use Only
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK -
UNPLUG BEFORE CLEANING OR SERVICING.
CAUT ION:
ANY CHANGES OR MODIFICATIONS NOT
EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR
COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE
THE EQUIPMENT.
6
DOUBLE I NSULATI ON I NSTRUCTI ONS
This Wet/Dry Vacuum is double insulated, eliminating the need for a separate grounding system.
Use only identical replacements parts. Read the instructions for Servicing Double-Insulated Wet/Dry
Vacuums before servicing. Use this vacuum as described in this manual.
Observe the following warnings that appear on the motor housing of your vacuum.
DOUBLE INSULATED - GROUNDING NOT REQUIRED - WHEN SERVICING USE ONLY
IDENTICAL REPLACEMENT PARTS.
WARNING: SERVICING OF DOUBLE-INSULATED WET/DRY VACUUMS
WITH A DOUBLE-INSULATED WET/DRY VACUUM, TWO SYSTEMS
OF INSULATION ARE PROVIDED INSTEAD OF GROUNDING. NO
GROUNDING MEANS IS PROVIDED ON A DOUBLE-INSULATED
APPLIANCE, NOR SHOULD A MEANS FOR GROUNDING BE ADDED.
SERVICING A DOUBLE INSULATED WET/DRY VACUUM REQUIRES
EXTREME CARE AND KNOWLEDGE OF THE SYSTEM, AND
SHOULD BE DONE ONLY BY QUALIFIED SERVICE PERSONNEL.
REPLACEMENT PARTS FOR A DOUBLE-INSULATED WET/DRY
VACUUM MUST BE IDENTICAL TO THE PARTS THEY REPLACE. YOUR
DOUBLE-INSULATED WET/DRY VAC IS MARKED WITH THE WORDS
‘DOUBLE INSULATED’ AND THE SYMBOL (SQUARE WITHIN A
SQUARE) MAY ALSO BE MARKED ON THE APPLIANCE.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK - DO NOT
EXPOSE TO RAIN. STORE INDOORS.
WARNING: FOR YOUR OWN SAFETY, READ AND UNDERSTAND THE
OPERATOR’S MANUAL. DO NOT RUN UNATTENDED. DO NOT PICK UP
HOT ASHES, COALS, TOXIC, FLAMMABLE OR OTHER HAZARDOUS
MATERIALS. DO NOT USE AROUND EXPLOSIVE LIQUIDS OR VAPORS.
CAUTION:
DO NOT VACUUM DRYWALL DUST, FIREPLACE SOOT, OR ASH
WITH STANDARD WET/DRY FILTER. THIS TYPE OF DUST IS VERY FINE
WHICH MAY NOT BE CAPTURED BY THE FILTER AND CAUSE DAMAGE
TO MOTOR. WHEN VACUUMING FINE DUST USE A FINE DUST FILTER.
7
EXTENSI ON CORDS
SYMBOLS
When using an extension cord with your Wet/Dry Shampoo Vacuum refer to the following table to
determine the required A.W.G. wire size. Before using the cleaner make sure the power cord and
extension cord are in good working condition. Make repairs or replacements before using the vacuum
cleaner. Only use extension cords that are rated for outdoor use.
Length of Extension Cord
120V 25ft (7.62m) 50ft (15.24m) 100ft (30.48m) 150ft (45.72m)
Ampere rating
A.W.G. Wire Size
More than Not more than
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not recommended
The following signal words and meanings are intended to explain the levels of risk associated with
this product.
SYMBOL SIGNAL MEANING
DANGER
Indicates an imminently hazardous situation, which, if not avoided,
will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
NOTICE
(Without Safety Alert Symbol) Indicates a situation that may result
in property damage.
8
UNPACKI NG & CHECKI NG CARTON
CONTENTS
A B
E
I
L
M
O P Q
K
N
J
G
H
F
C
D
R
S T
Remove all contents from the box. Remove the
powerhead and take out any contents inside the
collection tank. Check each item against the carton
contents list.
Carton Contents List:
Key
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
Description .............................................
Vacuum Assembly ...................................
Handle .....................................................
Washable Cartridge Filter ........................
Filter Retainer ..........................................
Foam Wet Filter .............…….........……...
Dust Collection Bag ..............…………….
Floor Brush/Squeegee Nozzle .................
Carpet Shampoo Nozzle ............………...
Handheld Shampoo Nozzle ...........…......
Crevice Tool .............................................
Round Dust Brush ...................................
Extension Wand .......................................
Exhaust Filter ...........................................
Hose and Remote-Control Handle (with
delivery tube attached) ............................
Rear Caster .............................................
Caster Foot Assembly ..............................
Hose Storage Rack ..................................
4 Screws (Bag) ........................................
Carpet Cleaning Solution .........................
Operator’s Manual ...................................
Qty
1
1
1
1
1
1
1
1
1
1
1
2
1
1
2
2
2
1
1
1
NOTE: The hose and accessories for this vacuum are 35 mm diameter.
9
Detergent
Mode
Vacuum
Mode
Powerhead
Hose Storage Rack
Power Cord Storage
Exhaust Filter Door
Collection Tank
Vacuum Port
Cleaning
Solution Outlet
Vacuum Mode Button
On/Off Switch
Handle
Detergent Mode Button
Accessory Storage
Front Caster
Foot
Cleaning Solution Tube
Cap of Cleaning
Solution Tank
Cleaning Solution
Tube Inlet
Latch
Cleaning Solution
Tank
Rear Caster
Front Caster
Drain Port
10
ACCESSORIES
A choice of accessories and attachments are supplied with this product. Refer to below descriptions for
their functions.
Illustration Description Function
Handheld Shampoo
Nozzle
For cleaning sofas, chairs, stairs, and car interiors.
Carpet Shampoo
Nozzle
Used without brush holder for cleaning carpets.
Used with brush holder for cleaning hard oors.
Crevice Tool For cleaning edges, gaps, and tight spaces.
Extension Wand
Used to connect accessories to the remote-control
handle and extend the cleaning reach.
Floor Brush/Squeegee
Nozzle
For cleaning dry and liquid messes on hard surfaces
and low-pile carpets.
Round Dust Brush
For cleaning fragile or easily scratched items, such as
certain furniture or drapes.
11
A Phillips head screw driver is required.
GENERAL ASSEMBLY I NSTRUCTI ONS
3
1
2
7
8
5
9
6
4
10
11 12
13
14
15
16
19
17
18
①
Detergent
Mode
Vacuum
Mode
Detergent
Mode
Vacuum
Mode
WARNING:
DO NOT PLUG THE POWER CORD INTO A POWER OUTLET. MAKE
SURE THE PLUG IS DISCONNECTED BEFORE ASSEMBLING THE WET/DRY SHAMPOO
VACUUM. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT EXPOSE TO RAIN.
UNPACKING YOUR WET/DRY SHAMPOO VACUUM & GENERAL ASSEMBLY
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. Undo the latches (Fig. 2).
3. Lift the powerhead off the collection tank (Fig. 3).
4. Remove the contents from inside the collection tank; make sure you have all contents as listed on
page 8.
5. Turn the collection tank upside down and insert the two front caster feet into the slots on the
collection tank and tighten with supplied screws. Verify that the casters are mounted correctly. Do
not over-tighten the screws (Fig. 4).
6. Insert the two rear casters into the slots and apply pressure until they click into place (Fig. 5).
7. Insert the handle into the slots located on the top of the powerhead and secure it with the screws
provided. Do not over-tighten the screws (Fig. 6).
12
8. Your vacuum comes ready for dry vacuum cleaning. If the cartridge lter is not installed, refer to
page 20 for installation instructions (Fig. 7 & 8).
9. Optional: For improved dust ltration, t the dust collection bag ange onto the inlet port, taking
care not to damage the bag (Fig. 9).
NOTE: The dust collection bag is for dry pick-up only.
10. For wet vacuum cleaning, remove the cartridge lter, and install the supplied foam wet lter. See
page 21 for the foam wet lter installation instructions (Fig. 10).
11. Position the hose storage rack as illustrated. Squeeze the open sides of the hose storage rack
inward. Insert the hose storage rack into the channel on the front side of the powerhead just
above the top edge of the tank. Verify that the rack is secured in place as shown in (Fig. 11 & 12).
Then squeeze in the other hose storage rack and insert it into the corresponding channel making
sure it is secured.
12. Place the powerhead back on the collection tank aligning the top section with the latches, and
snap into place (Fig. 13).
13. Ensure the end of the cleaning solution tube is securely tted into the cleaning solution tank
(Fig. 14).
14. A cleaning solution delivery tube runs along the hose with a threaded connector at the end. Insert
the locking end of the hose into the vacuum port of the collection tank and turn clockwise to lock
into place. Connect the threaded connector on the end of the delivery tube onto the cleaning
solution outlet coupling on the front of the powerhead (Fig. 15).
15. Choose the desired accessory and/or the extension wand and connect it onto the remote-control
handle (Fig. 16). The air ow regulation (
①
) on the remote-control handle allows you to manually
change the amount of vacuum suction (Fig. 17).
NOTE: If the suction power is too high when cleaning, adjust the air ow regulation to decrease the
suction power (Fig. 17).
POLARIZED PLUG
To reduce the risk of electrical shock, this appliance has a polarized plug (one blade wider than the
other). This plug will t in a polarized outlet only one way. If the plug does not t fully in the outlet,
reverse the plug. If it still does not t, contact a qualied electrician to install the proper outlet. Do not
change the plug in any way. Double insulation eliminates the need for the three-wire grounded
power cord and grounded power supply system.
PROGRAMMING THE REMOTE-CONTROL HANDLE
NOTE: The programming of the remote-control handle has been preset and is ready to be used in
both vacuum and detergent mode. Reset the remote-control handle using the steps below if unable to
operate in vacuum mode.
1. Ensure the vacuum is plugged into the power outlet.
2. Switch the on/off switch to the “I” ON position.
3. Locate the detergent mode button on the powerhead indicated by the following symbol .
4.
Press and hold the detergent mode button until the indicator light illuminates continuously (Fig. 18).
5. While the light is on, press and hold the detergent mode button on the remote-control handle until
the indicator light on the powerhead starts to ash. The remote-control handle is now programmed
to vacuum, and you should be able to operate in both detergent and vacuum modes (Fig. 19).
6. If the indicator light does not ash, repeat steps 1 to 5.
13
DRY VACUUM OPERATI ON
3
4
1
2
5
6
7
8 9 10
11
DRY VACUUMING
WARNING:
BE SURE TO READ, UNDERSTAND, AND APPLY INFORMATION
ENTITLED “IMPORTANT SAFETY INSTRUCTIONS”. DO NOT VACUUM IN AREAS WITH
FLAMMABLE GASES, VAPORS, OR EXPLOSIVE DUST IN THE AIR. FLAMMABLE
GASES OR VAPORS INCLUDE BUT ARE NOT LIMITED TO: LIGHTER FLUID, SOLVENT
TYPE CLEANERS, OIL-BASED PAINTS, GASOLINE, ALCOHOL, OR AEROSOL SPRAYS.
EXPLOSIVE DUST INCLUDE BUT ARE NOT LIMITED TO: COAL, MAGNESIUM, GRAIN,
OR GUN POWDER. TO REDUCE THE RISK OF HEALTH HAZARDS FROM VAPORS OR
DUST, DO NOT VACUUM TOXIC MATERIALS.
WARNING:
DO NOT PLUG THE POWER CORD INTO A POWER OUTLET. MAKE
SURE THE PLUG IS DISCONNECTED BEFORE CHANGING THE FILTERS.
CAUTION:
DO NOT VACUUM DRYWALL DUST, FIREPLACE SOOT, OR ASH
WITH STANDARD WET/DRY FILTER. THIS IS A VERY FINE DUST WHICH WILL NOT
BE CAPTURED BY THE FILTER AND MAY CAUSE DAMAGE TO THE MOTOR. WHEN
VACUUMING FINE DUST USE A FINE DUST FILTER.
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. Your wet/dry shampoo vacuum comes with the cartridge lter pre-installed. In order to prepare
your vacuum for dry vacuuming, make sure the cartridge lter completely covers the lter cage
against the powerhead. For installation instructions, see page 20 (Fig. 2 & 3).
3. Place the lter retainer on the top of the cartridge lter and tighten down by turning the retainer
handle clockwise (Fig. 4).
14
4. Optional: For improved dust ltration, t the dust collection bag ange onto the inlet port, taking
care not to damage the bag (Fig. 5).
5. Place the powerhead back on the collection tank and secure it in place using the latches (Fig. 6).
OPERATING INSTRUCTIONS: DRY VACUUMING
6. Insert the locking end of the hose into the vacuum port on the collection tank and turn clockwise to
lock into place (Fig. 7).
7. Choose the desired accessory and connect onto the remote-control handle or the extension wand
(Fig. 8). The air ow regulation on the remote-control handle allows you to manually change the
amount of vacuum suction.
8. Verify that the switch is in the ‘O’ OFF position before plugging the power cord into the power
outlet. Plug the power cord into the outlet (Fig. 9 & 10).
9. Turn the motor on by ipping the switch to the ‘I’ ON position and the machine is ready for use.
Press the vacuum mode button, indicated by the following symbol , on either the remote-
control handle or the powerhead and operate the vacuum (Fig. 11).
10. Once you have completed vacuuming, switch off the vacuum by pressing the vacuum mode
button on either the remote-control handle or the powerhead. Switch to the “O” OFF position and
unplug the power cord from the power outlet.
O = OFF I = ON = VACUUM MODE
DO NOT USE THE CARTRIDGE FILTER FOR LIQUID VACUUMING.
DO NOT USE THE DUST BAG FOR LIQUID VACUUMING.
LI QUI D VACUUM OPERATI ON
4
1
5
6
7
8
3
2
15
1. Verify that the power cord is disconnected from the outlet. Make sure that the collection tank is
clean and free of dust and dirt (Fig. 1).
2. Remove the cartridge lter, then carefully install the foam wet lter over the lter cage and place
the powerhead back on the collection tank. For foam wet lter installation instructions, see page 21
(Fig. 2).
OPERATING INSTRUCTIONS: WET VACUUMING
3. Insert the locking end of the hose into the vacuum port on the collection tank and lock into place
(Fig. 3).
4. Choose the desired accessory and connect onto the remote-control handle or the extension wand
(Fig. 4). The air ow regulation on the remote-control handle allows you to manually change the
amount of vacuum suction.
5. Verify that the switch is in the ‘O’ OFF position before plugging the power cord into the power outlet.
Plug the power cord into the outlet (Fig. 5 & 6).
6. Turn the motor on by ipping the switch to the ‘I’ ON position and the machine is ready for use.
Press the vacuum mode button, indicated by the following symbol , on either the remote-
control handle or the powerhead and operate the vacuum (Fig. 7).
7. Once you have completed vacuuming, switch off the vacuum by pressing the vacuum mode button
on either the remote-control handle or the powerhead. Switch to the “O” OFF position and unplug
the power cord from the power outlet.
8. After use, empty the collection tank by unscrewing the drain cap. Drain liquids into a suitable
receptacle or drain (Fig. 8). Once the collection tank is cleaned and dried, ret the drain cap to the
collection tank.
IMPORTANT! When vacuuming large quantities of liquids, do not immerse the nozzle completely in
the liquid; leave a gap at the tip of the nozzle opening to allow air inow. The machine is tted with a
oat valve that stops the suction action when the collection tank reaches its maximum capacity. You
will notice an increase in motor speed. When this happens, turn off the machine, disconnect from
power supply, and drain the liquid. To continue vacuuming, replace the drain cap. After wet vacuuming,
turn the machine off and remove plug from power supply. Empty the collection tank, clean, and dry the
inside and outside before storage.
REMEMBER! The foam wet lter must be removed after wet vacuuming and the cartridge lter must
be installed before dry vacuuming again.
LIQUID VACUUMING
WARNING:
BE SURE TO READ, UNDERSTAND, AND APPLY INFORMATION
ENTITLED “IMPORTANT SAFETY INSTRUCTIONS”. DO NOT VACUUM IN AREAS WITH
FLAMMABLE GASES, VAPORS, OR EXPLOSIVE DUST IN THE AIR. FLAMMABLE
GASES OR VAPORS INCLUDE BUT ARE NOT LIMITED TO: LIGHTER FLUID, SOLVENT
TYPE CLEANERS, OIL-BASED PAINTS, GASOLINE, ALCOHOL, OR AEROSOL SPRAYS.
EXPLOSIVE DUST INCLUDE BUT ARE NOT LIMITED TO: COAL, MAGNESIUM, GRAIN,
OR GUN POWDER. TO REDUCE THE RISK OF HEALTH HAZARDS FROM VAPORS OR
DUST, DO NOT VACUUM TOXIC MATERIALS.
WARNING:
DO NOT PLUG THE POWER CORD INTO A POWER OUTLET. MAKE
SURE THE PLUG IS DISCONNECTED BEFORE CHANGING THE FILTERS.
CAUTION:
DO NOT SUBMERGE THE REMOTE-CONTROL HANDLE IN LIQUIDS.
16
CARPET/ UPHOLSTERY CLEANI NG
OPERATI ON
3
4
1
2
5
6
7
8
9
17
②
③
15 16
10
14
I
II
19
I
II
18
12
11
13
6
Gallo n
Detergent
Mode
Vacuum
Mode
WARNING:
DO NOT RUN THE VACUUM IN DETERGENT MODE WITHOUT
SOLUTION IN THE CLEANING SOLUTION TANK.
WARNING:
USE ONLY MANUFACTURER RECOMMENDED CLEANING
SOLUTION WITH THIS VACUUM CLEANER.
WARNING:
DO NOT REPLACE FURNITURE UNTIL THE CARPET IS
COMPLETELY DRY!
17
NOTE: ALWAYS DRY VACUUM THE AREA BEING CLEANED BEFORE USING THE SHAMPOO
MODE.
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. To prepare your vacuum cleaner for carpet/upholstery cleaning, remove the cartridge lter.
3. Carefully install the supplied foam wet lter over the lter cage, making sure the lter cage is
completely covered. For foam wet lter installation instructions, see page 21 (Fig. 2).
4. Remove the cleaning solution tank from the vacuum base. Open the cap of cleaning solution tank
and pour the cleaning solution mixture into the tank. To make the cleaning solution mixture, mix 1.5
oz. of cleaning solution per 0.5 gallon of water (Fig. 3).
NOTE: A 17 oz. (500ml) bottle of cleaning solution is provided with this vacuum cleaner. Ensure the
cleaning solution and water are mixed at the correct ratio. Water must be at room temperature.
NOTE: Once depleted, the cleaning solution can be replaced by a high-quality liquid carpet cleaning
solution that can be purchased from a local retailer. Always use the cleaning solution as directed by
the manufacturer.
5. Snap the cap of cleaning solution tank back into place. Then insert the cleaning solution tank back
into the vacuum base. Insert the end of the cleaning solution tube into the cleaning solution tank
(Fig. 4).
6. Insert the locking end of the hose into the vacuum port on the collection tank and turn clockwise to
lock into place. Connect the threaded connector on the end of the cleaning solution delivery tube
onto the cleaning solution outlet coupling (Fig. 5).
7. Insert the remote-control handle and its cleaning solution outlet coupling (
②
) into the larger end
of the extension wand and its cleaning solution inlet connector (
③
) ensuring a "click" is heard.
The air ow regulation on the remote-control handle allows you to manually change the amount of
vacuum suction (Fig. 6 & 7).
8. Attach the carpet shampoo nozzle to the extension wand and make sure it clicks into place
(Fig. 8 & 9).
For best performance, it is recommended to remove the brush holder during carpet cleaning. Follow
steps in Fig. 10. to remove the brush holder.
To re-install the brush holder, make sure to rst align the arrows on the brush holder and the nozzle as
shown. Then move the brush holder to the left as indicated by the arrow until you hear a "click" (Fig. 11).
9. To clean sofas, chairs, stairs, and car interiors, connect the handheld shampoo nozzle onto the
remote-control handle (Fig. 14).
NOTE: When cleaning the headliner of your car, adjust the air ow regulation to decrease the suction
power if the suction power is high.
CAUTION:
NEVER PRY OR ROTATE THE SPRAY OUTLETS OF THE CARPET
SHAMPOO NOZZLE AND HANDHELD SHAMPOO NOZZLE WITH A SCREWDRIVER OR
ANY OTHER TOOL (FIG. 12 & 13).
CAUTION:
THE CLEANING SOLUTION CONTAINS A CHEMICAL SOLUTION.
AVOID PROLONGED CONTACT AS SOME INDIVIDUALS MAY EXPERIENCE SKIN AND
EYE IRRITATION. FOR SKIN AND EYE IRRITATION, WASH AFFECTED AREA WITH
WATER FOR 5-10 MINUTES. IF IRRITATION PERSISTS, SEEK MEDICAL ATTENTION
IMMEDIATELY. INDIVIDUALS WITH SENSITIVE SKIN SHOULD WEAR RUBBER GLOVES.
WASH HANDS THOROUGHLY AFTER USE. DO NOT INGEST. KEEP OUT OF REACH OF
CHILDREN. USER ASSUMES ALL RISK.
CAUTION:
BEFORE YOU USE THIS PRODUCT TO SHAMPOO CLEAN AN AREA,
TEST YOUR WET/DRY SHAMPOO VACUUM AND THE CLEANING SOLUTION ON A SMALL
HIDDEN AREA FOR COLORFASTNESS. IF THE COLOR IS AFFECTED, DO NOT USE.
18
If there is dirt or debris accumulated in the handheld shampoo nozzle, press the release button and
remove the cover from the nozzle for cleaning (Fig. 15).
10. Plug the power cord into a power outlet (Fig. 16).
11. Turn on the motor by ipping the switch to the “I” ON position and the machine is ready for use.
Press the detergent mode button, indicated by the following symbol , on either the remote-
control handle or the powerhead for cleaning solution application only. Select both the detergent
mode and vacuum mode for simultaneous shampoo and wet vacuum operation (Fig. 17).
12. Once you have completed cleaning, switch off the vacuum by pressing detergent mode button on
either the remote-control handle or the powerhead. Flip the switch to the “O” OFF position, unplug
the power cord from the power outlet and drain the liquid (Fig. 18).
O = OFF I = ON = DETERGENT MODE
DO NOT USE THE CARTRIDGE FILTER FOR LIQUID VACUUMING.
DO NOT USE THE DUST BAG FOR LIQUID VACUUMING.
NOTE: VACUUM THE CARPET/UPHOLSTERY THOROUGHLY BEFORE USING THE SHAMPOO
MODE.
• For carpet cleaning it is recommended to remove all furniture from the room to be cleaned or move
it away from the cleaning area. Clean the whole carpet systematically in squares, using strokes of
approximately 5ft. (1.5m) each. This avoids walking over the cleaned carpet until it is completely dry.
• Start furthest away from the entrance of the room, extend the hose, and work backwards.
• Pull the carpet shampoo nozzle back towards you in approximately 5ft. strokes. Rell the cleaning
solution tank if the solution runs out.
•
Select the vacuum mode, indicated by the following symbol , to suck up the dirty solution. More
cleaning solution can be applied to heavily soiled areas. The dirty liquid is visible as it is sucked up
through the carpet shampoo nozzle. Stop vacuuming when the liquid being extracted is no longer dirty.
• Do not walk over or place furniture on the cleaned area until it is completely dry.
• The handheld shampoo nozzle is ideal for cleaning sofas, chairs, stairs and car interiors.
• The carpet shampoo nozzle is ideal for cleaning carpets.
DISASSEMBLING THE WET/DRY SHAMPOO VAC
NOTE: SOME LIQUID MAY REMAIN IN THE TUBES AFTER USING THE PRODUCT FOR LIQUID
OR SHAMPOO CLEANING. DISASSEMBLE THE VACUUM OUTDOORS OR OVER A SINK AS
THERE MAY BE SOME LEAKAGE.
To disassemble the shampoo vacuum, follow the steps below.
1. Remove the cleaning solution tube from the powerhead by pressing down on the orange latch.
Disconnect the hose from the vacuum.
2. Disconnect the accessories and/or extension wand from the remote-control handle by pressing
down on the release button (Fig. 19).
WARNING:
THE MOTOR NOISE CHANGES TO A HIGHER PITCH WHEN THE
COLLECTION TANK IS FULL OR BLOCKED. STOP THE VACUUM IMMEDIATELY AND
EMPTY THE COLLECTION TANK.
19
EMPTYING THE COLLECTION TANK
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. Press down the orange latch on the cleaning solution delivery tube and unplug the delivery tube
from the vacuum. Then disconnect the hose from the vacuum (Fig. 2).
3. Disconnect the cleaning solution tube from the cleaning solution tank (Fig. 3).
4. Undo the latches and remove the powerhead from the collection tank (Fig. 4). Place the powerhead
on a soft, clean surface upside down.
5. Clear all dirt or debris from the collection tank and hose into a proper waste container (Fig. 5).
6. Clean or replace the lters.
7. Check the hose, attachments, and power cord to ensure that they have not been damaged.
8. Place the powerhead back onto the collection tank and secure latches.
IMPORTANT! Clean or change the lter regularly for best performance. ALWAYS USE THE
CARTRIDGE FILTER FOR DRY VACUUMING. If the machine is used without the cartridge lter, the
motor will burn out and the warranty will be voided. Always keep spare lters on hand.
NOTICE! The lters included are made of high-quality materials designed to stop small dust particles.
The cartridge lter should be used for dry pick-up only. A dry cartridge lter is necessary to pick up
dust. If the cartridge lter is wet, it will clog quickly and be very difcult to clean. Handle the lter
carefully when removing it for cleaning and replacing it. Check the lters for tears or small holes. A
small hole can let dust pass through and out of the lter. Do not use a lter with holes or tears; replace
it immediately.
STORAGE
Before storing your vacuum, the collection tank should be emptied and cleaned. The accessories
should be cleaned and stored so they can be readily available when needed. Store the wet/dry
vacuum indoors.
REPAIRS
Repairs for this wet/dry shampoo vacuum should be performed only by qualied service personnel
using only identical replacement parts.
WARNING:
ALWAYS DISCONNECT THE PLUG FROM THE POWER OUTLET
BEFORE REMOVING THE POWERHEAD FROM COLLECTION TANK.
MAI NTENANCE
4
1
5
3
2
20
INSTALLING CARTRIDGE FILTER
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. Remove the powerhead and place in an upside-down position.
3. Install the cartridge lter over the lter cage making sure the cage is completely covered (Fig. 2 & 3).
4. Place the lter retainer on the top of the cartridge lter over the raised lip and tighten down by
turning the retainer clockwise; do not over-tighten (Fig. 4 & 5).
5. Place the powerhead back onto the collection tank.
REMOVING & CLEANING CARTRIDGE FILTER
1. Unlock and remove the lter retainer by turning the retainer handle counter-clockwise (Fig. 6).
2. With the removed powerhead in an upside-down position, carefully remove the cartridge lter from
the lter cage (Fig. 7).
3. Clean the cartridge lter by gently brushing or rinsing off the debris (Fig. 8). Cleaning should not be
done indoors in living areas. For optimal performance a new lter is recommended.
4. Install cleaned or new lter as described in steps 2-4 of Installing Cartridge Filter.
I NSTALLI NG & CLEANI NG
CARTRI DGE FI LTER
4
1
5
6
3
2
8
7
21
INSTALLING FOAM WET FILTER
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. Remove the powerhead and place in an upside-down position. Follow instructions to remove the
cartridge lter on page 20.
3. Carefully slide the foam wet lter down over the lter cage making sure the cage is completely
covered (Fig. 2 & 3).
4. Place the powerhead onto the collection tank.
CLEANING FOAM WET FILTER
1. With the removed powerhead in an upside-down position, carefully remove the foam wet lter
(Fig. 4).
2. Use a mild soap and water solution to wash the foam wet lter and rinse with clean water (Fig. 5).
3. Allow the wet lter to air dry completely before storing or installing onto the lter cage.
I NSTALLI NG & CLEANI NG
FOAM WET FI LTER
4
1
5
3
2
22
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
wards to the release. Pull the door out
(Fig. 2).
y tapping or brushing off dirt. For
door into place (Fig. 4).
NOTE:
Only replace the battery with a 27A 12V Alkaline battery.
1. Verify that the power cord is disconnected from the outlet (Fig. 1).
2. Pry off the battery cover and remove it from the battery compartment (Fig. 2).
3. Remove the battery from the battery compartment. Insert the new battery with the terminals in the
direction as shown (Fig. 3).
4. Position the battery cover in the angle of inclination as shown. Then insert it into the slot on the
battery compartment and press down the battery cover to click into place (Fig. 4 & 5).
CLEANING & REPLACING
EXHAUST FILTER
CHANGING THE BATTERY
3
4
1
2
3
4
1
2
5
＋
＋
＋
＋
I
II
23
PROBLEM POSSIBLE CAUSE SOLUTION
The wet/dry shampoo
vacuum will not operate.
Faulty power cord, switch, or
motor.
Unplug and check the power cord.
If damaged, have it repaired by a
professional or call customer service.
No power supply.
Check the power supply, cord,
breakers, and fuses.
On/Off switch is in the wrong
position. Or the correct mode
button is not selected.
Press the ON ‘I’ button on the
powerhead and select desired
cleaning mode. Follow instructions on
page 13-18.
Collection tank full. Empty the collection tank.
The dust comes out from
the motor cover.
The cartridge lter is missing or
damaged.
Attach or replace the cartridge lter.
Incorrect use of foam lter when
dry vacuuming.
Replace the foam wet lter with the
cartridge lter.
The exhaust lter is missing or
damaged.
Attach or replace the exhaust lter.
Low suction power and
high operating noise /
vibrations.
Nozzle, hose, or tank inlet is
blocked.
Check and remove blockage from the
nozzle, hose, and tank inlet.
Cartridge lter is clogged by ne
dust.
Take off the lter and clean it or install
a new cartridge lter.
Float valve has closed.
Empty the collection tank of any liquid
waste and ensure the oat valve
located underneath the lter is able to
move freely.
TROUBLESHOOTI NG
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK, UNPLUG BEFORE TROUBLESHOOTING.
24
PROBLEM POSSIBLE CAUSE SOLUTION
Cleaning solution does
not spray out.
Detergent mode is not selected. Press the detergent mode button.
Cleaning solution tank is empty. Rell the cleaning solution tank.
Incorrectly tted tubes.
Check ttings and connections.
Ensure there are no kinks in tubes.
The water pump inside the
powerhead overheats.
Let the vacuum cool down to reach a
normal temperature, then re-start the
vacuum.
Foam is leaking from the
outlet on the powerhead.
Incorrect cleaning solution or
incorrect mix ratio is used.
Use manufacturer’s cleaning solution
or high-quality low-foaming liquid
carpet cleaning solution. Ensure the
cleaning solution is mixed with water
at the correct ratio.
The remote control will
not operate.
The battery has no charge.
Replace the old battery with a new
one.
The remote control is not
programmed.
Reset the remote control using the
instructions on page 12.
The remote control is damaged. Contact customer service.
25
EXPLODED VI EW
26
PARTS LI ST
Part Part Number Description Quantity
1 551746101 Handle Assembly
1
2 551657102 Hose Storage Rack
2
3 Powerhead Assembly
1
4 551005103 Float
1
5 551437105 Filter Cage
1
6 551746103 Exhaust Filter Door
1
7 551121122 Exhaust Filter Assembly
1
8 551746104 Latch Assembly
2
9 Collection Tank
1
10 551661104 Vacuum Port Assembly
1
11 551002110 Drain Cap Assembly
1
12 551617105 Vacuum Base
1
13 551661106 Rear Caster
2
14 551661105 Caster Foot Assembly
2
15 551657106 Cleaning Solution Tank
1
16 551437107 Filter Retainer
1
17 551324115 Cartridge Filter
1
18 551023139 Round Dust Brush
1
19 551746106 Hose and Remote-Control Handle
1
20 551324122 Floor Brush/Squeegee Nozzle
1
21 551746107 Extension Wand
2
22 551746108 Carpet Shampoo Nozzle
1
22.1 551746109 Carpet Shampoo Nozzle Spray Head
1
23 551746110 HandHeld Shampoo Nozzle
1
23.1 551746111 Handheld Shampoo Nozzle Spray Head
1
24 551051116 Crevice Tool
1
25 Carpet Cleaning Solution
1
26 551008132 Foam Wet Filter
1
27 551188114 Dust Collection Bag
1
