User Manual
Full Frame License Plate
Reverse Camera
CAM-LF2
Introduction
Key Features
u 1/4” CMOS Sensor
u Operates at 0 LUX
u 8 IR LEDs
u IP67 Rated
u 140 Degree Viewing Angle
u Selectable Image (mirrored/non-mirrored)
Box Contents
Wiring Diagram & Pin Out
Specications
Dimensions
CAM-LF2B-N / CAM-LF2C-N
Sensor ¼” CMOS
LEDs 8
Illumination 0 LUX
Viewing Angle 140 degrees
Mirror Image YES
Normal Image YES
Water/Debris-Proof IP67
Audio NO
Power Supply 12V DC
Current <110mA
Working Temperature -20ºC - +50ºC
Dimensions (mm) D (27) x W (310) x H (160)
System NTSC
TV Lines 380
Resolution (HxV) 640 X 480
u Camera
u Manual
u Wiring Harness
u Mounting Hardware
Thank you for purchasing your EchoMaster
automotive camera.
The following part numbers are supported:
u CAM-LF2B-N u CAM-LF2C-N
EchoMaster cameras are designed to improve safety during
driving by providing high quality images of surrounding areas
and obstacles in the vicinity of the vehicle. They will also
improve vehicle maneuvering capability by displaying blind
spots not normally visible to the driver.
Please ensure you read and understand all aspects of this
manual before tting or using your EchoMaster Camera.
Choose a suitable mounting place dependent on the
application. Ensure that there are no wiring harnesses or
hoses/pipes located behind this panel before drilling.
Extension (sold separately)
VIDEO
GND (Black)
+12V (Red)
+12V
GND
1 2
43
Video Audio
