CAM-508L
Box Contents:
u Camera
u Wiring Harness
u Power Adapter
u Manual
Dimensions:
7.00”
7.62”
1.13”
0.31”
0.28”
0.20”
.047”
1.13”
1.13”
7.00”
7.62”
1.13”
0.31”
0.28”
0.20”
.047”
1.13”
1.13”
Wiring Diagram
7.00”
7.62”
1.13”
0.31”
0.28”
0.20”
.047”
1.13”
1.13”
Parking Lines (Green) On - Cut (Default)
GND (Black)
VIDEO
Switched +12V (Red)
+12V
GND
1 2
43
Video
22in
30in
O - Joined
234in
email - [email protected]
phone - 866-931-8021
15500 Lightwave Drive, Suite 202
Clearwater, Florida 33760
EchoMaster is a Power Brand of AAMP Global
EchoMaster.com
EchoMaster cameras are designed to improve
safety during driving by providing high quality
images of surrounding areas and obstacles in
the vicinity of the vehicle. They will also improve
vehicle maneuvering capability by displaying blind
spots not normally visible to the driver.
Please ensure you read and understand all
aspects of this manual before tting or using your
EchoMaster camera. Choose a suitable mounting
place dependent on the application. Ensure that
there are no wiring harnesses or hoses / pipes
located behind the panel before drilling.
