CTEK MXT 14
14A
PROFESSIONAL BATTERY CARE
FOR 24V BATTERIES
CTEK MXT 14
The MXT 14 is a professional 24V charger. It is developed for com-
mercial vehicles where the batteries are put under considerable
strain and is ideal for busses, trucks and CV workshops. The MXT 14
is equipped with all necessary features and functions to solve a
broad range of battery related problems. It off ers features such as
battery diagnosis that shows if a battery can receive and retain a
charge, a special reconditioning function that restores stratifi ed and
deeply discharged batteries, unique maintenance charging, and a
temperature sensor for optimised charging regardless of the weather
conditions. It also has a power supply mode which allows the bat-
tery to be disconnected from the vehicle without losing important
confi gurations.
The MXT 14 is a fully automatic 8-step charger that delivers 14A
to 24V batteries from 28–300Ah and is suitable for maintenance
charging up to 500Ah. The charger is IP44 classifi ed (outdoor use),
designed to protect vehicle electronics and non-sparking, reverse
polarity protected and short-circuit proof. It is delivered with a 2-year
warranty.
TECHNICAL DATA
CHARGING VOLTAGE 28.8 / 31.6 / 27.2V
CHARGING CURRENT Max 14A
TYPE OF CHARGER 8 step, fully automatic charging cycle
TYPE OF BATTERY 24V lead-acid batteries
BATTERY CAPACITY 28–300Ah, up to 500Ah for maintenance
INSULATION IP44 (outdoor use)
AUTO
Fully automatic for optimal charging
For all lead-acid batteries
FULLY CHARGED BATTERY
MAINTENANCE CHARGING
Temperature sensor
Recondition of deeply discharged batteries
Use the charger as a power supply
MODE
SUPPLYNORMAL RECOND
RECOND
SUPPLY
24V/14A
MXT 14
www.ctek.com
CTEK MXT 14
CTEK MXT 14
14A
1
2
14A/28.8V
3
1
2
3
1.5A/31.6V
14A/27.2V
CTEK CLAMPS
20015643E, 56-797 EN
• Temperature compensated and fully automatic charging and mainte-
nance in 8 steps maximizes battery life and performance
• Power Supply that simplifi es battery replacement without losing vehicle
memory
• Patented maintenance charge for a unique combination of maximized
life and performance
• Recondition of deep discharged batteries
• Patented desulphation that extends the battery life
• No sparks, short-circuit proof and reverse-polarity protected for
untroubled usage
• Automatic detection of end-of-life batteries that eliminates surprises
READY TO USE
MODE
SUPPLYNORMAL RECOND
RECOND
SUPPLY
24V/14A
MXT 14
SUPPLY
The table shows the estimated time for empty battery to 80% charge.
BATTERY SIZE (Ah) TIME TO 80% CHARGED
30 2h
100 6h
200 12h
350 17h
GUARANTEED QUALITY WITH CTEK
CTEK customer support is available to answer any questions related to
charging and CTEK chargers. Safety, simplicity and fl exibility character-
izes all products and solutions developed and sold by CTEK. CTEK sup-
ply chargers to more than 60 countries throughout the world. CTEK is also
a reliable OEM supplier to many of the world’s most prestigious car and
motorcycle manufacturers.
Contact customer support: inf[email protected]
PROGRAMS
DESULPHATION
SOFT START
BULK
ABSORPTION, READY TO USE
ANALYSE
FLOAT, FULLY CHARGED
PULSE, MAINTENANCE CHARGING
SUPPLY
RECOND
CTEK CHARGING
CONNECT THE CHARGER TO
THE BATTERY
CONNECT THE CHARGER TO
THE WALL SOCKET
PRESS THE MODE-BUTTON TO SELECT
CHARGING PROGRAM
CTEK CLAMPS
TEMPERATURE SENSOR
CONNECT AND CHARGE
