BAUMR-AG BMHGTL00A HG3 20V SYNC Cordless Power Heat Gun User Manual

THE BATTERY MAY HAVE SOME CHARGE ON ARRIVAL, IT IS IMPORTANT

HOWEVER THAT THE BATTERY IS CHARGED PRIOR TO USE.

User Manual

[Revision 4.0 November 2023]

READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY

VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance,

assembly, inclusions, specifications, description, and packaging.

HG3 Heat Gun - SYNC Series

Safety

Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or

equipment or property damage if not understood or followed. Safety messages have the following symbols:

You WILL be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be INJURED if you do

not follow instructions or equipment

damage may occur.

It is vital that you read and understand this

user manual before using the product,

including safety warnings, and any assembly

and operating instructions. Keep the manual

for future reference.

Safety precautions and recommendations

detailed here must be fully understood and

followed to reduce the risk of injury, fire,

explosion, electrical hazard, and/or property

damage.

Safety information presented here is generic

in nature – some advice may not be

applicable to every product. The term

"equipment" refers to the product, be it

electrical mains powered, battery powered or

combustion engine powered.

• Before Use - If you are not familiar with the

safe operation/handling of the equipment or

are in any way unsure of any aspect of

suitability or correct use for your

application, you should complete training

conducted by a person or organization

qualified in safe use and operation of this

equipment, including fuel/electrical handling

and safety.

• Do NOT operate the equipment in

flammable or explosive environments, such

as in the presence of flammable liquids,

gases, or dust. The equipment may create

sparks or heat that may ignite flammable

substances.

• Keep clear of moving parts.

• Equipment may be a potential source of

electric shock or injury if misused.

• Do NOT operate the equipment if it is

damaged, malfunctioning or is in an

excessively worn state.

• Do NOT allow others to use the equipment

unless they have read this manual and are

adequately trained.

• Keep packaging away from children - risk

of suffocation! Operators must use the

equipment correctly. When using the

equipment, consider conditions and pay

due care to persons and property.

General Work Area Safety

• Work areas should be clean and well it.

• Do not operate the equipment if

bystanders, animals etc are within

operating range of the equipment or the

general work area.

• If devices are provided for connecting dust

extraction / collection facilities, ensure

these are connected and used properly.

Dust collection can reduce dust-related

hazards.

General Personal Safety

• Wear appropriate protective equipment

when operating, servicing, or when in the

operating area of the equipment to help

protect from eye and ear injury, poisoning,

burns, cutting and crush injuries. Protective

equipment such as safety goggles,

respirators, non-slip safety footwear, hard

hat, hearing protection etc should be used

for appropriate equipment / conditions.

Other people nearby should also wear

appropriate personal protective equipment.

Do not wear loose clothing or jewellery,

which can be caught in moving parts. Keep

hair and clothing away from the equipment.

• Stay alert and use common sense when

operating the equipment. Do not over-

reach. Always maintain secure footing and

balance.

• Do not use the equipment if tired or under

the influence of drugs, alcohol, or

medication.

• This equipment is not intended for use by

persons with reduced physical, sensory, or

mental capabilities.

General Fuel Safety

• Petrol/fuel/gasoline is extremely flammable

– keep clear of naked flames or other

ignition sources.

• Do not spill fuel. If you spill fuel, wipe it off

the equipment immediately – if fuel gets on

your clothing, change clothing.

• Do NOT smoke near fuel or when

refuelling.

• Always shut off the engine before

refuelling.

• Do NOT refuel a hot engine.

• Open the fuel cap carefully to allow any

pressure build-up in the tank to release

slowly.

• Always refuel in well ventilated areas.

• Always check for fuel leakage. If fuel

leakage is found, do not start, or run the

engine until all leaks are fixed.

General Carbon-Monoxide Safety

• Using a combustion engine indoors CAN

KILL IN MINUTES. Engine exhaust

contains carbon-monoxide – a poison you

cannot smell or see.

• Use combustion engines OUTSIDE only,

and far away from windows, doors, and

vents.

General Equipment Use and Care

• The equipment is designed for domestic

use only.

• Handle the equipment safely and carefully.

• Before use, inspect the equipment for

misalignment or binding of moving parts,

loose components, damage, or any other

condition that may affect its operation. If

damaged, have the equipment repaired by

an authorised service centre or technician

before use.

• Prevent unintentional starting of the

equipment - ensure equipment and power

switches are in the OFF position before

connecting or moving equipment. Do not

carry equipment with hands or fingers

touching any controls. Remove any tools or

other items that are not a part of the

equipment from it before starting or

switching on.

• Do not force the equipment. Use the

correct equipment for your application.

Equipment will perform better and be safer

when used within its design and usage

parameters.

• Use the equipment and accessories etc. in

accordance with these instructions,

considering working conditions and the

work to be performed. Using the equipment

for operations different from those intended

could result in hazardous situations.

• Always keep equipment components

(engines, hoses, handles, controls, frames,

housings, guards etc) and accessories

(cutting tools, nozzles, bits etc) properly

maintained. Keep the equipment clean and,

where applicable, properly lubricated.

• Store the equipment out of reach of

children or untrained persons. To avoid

burns or fire hazards, let the equipment

cool completely before transporting or

storing. Never place or store the equipment

near flammable materials, combustible

gases, or liquids etc.

• The equipment is not weather-proof, and

should not be stored in direct sunlight, at

high ambient temperatures or locations that

are damp or humid.

• Do not clean equipment with solvents,

flammable liquids, or harsh abrasives.

• For specific equipment safety use and care,

see Equipment Safety.

HG3 Heat Gun - SYNC Series

General Electrical Safety

• Inspect electrical equipment, extension

cords, power bars, and electrical fittings for

damage or wear before each use. Repair or

replace damaged equipment immediately.

• Ensure all power sources conform to

equipment voltage requirements and are

disconnected before connecting or

disconnecting equipment.

• When wiring electrically powered

equipment, follow all electrical and safety

codes.

• Always use a Residual Current Device

(RCD) (GFCI) / Earth Leakage Circuit

Breaker / Safety Switch when operating this

item (electrical items only).

• High voltage / high current power lines may

be present. Use extreme caution to avoid

contact or interference with power lines.

Electrical shock can be fatal.

General Electrical Safety

• Electrically grounded equipment must have

an approved cord and plug and be

connected to a grounded electrical outlet.

• Do NOT bypass the ON/OFF switch and

operate equipment by connecting and

disconnecting the electrical cord.

• Do NOT use equipment that has exposed

wiring, damaged switches, covers or

guards.

• Do NOT use electrical equipment in wet

conditions or in damp locations.

• Do NOT use electrical cords to lift, move or

carry equipment.

• Do NOT coil or knot electrical cords, and

ensure electrical cords are not trip hazards.

General Service Information

• The equipment must be serviced or

repaired at authorised service centres by

qualified personnel only.

• Replacement parts must be original

equipment manufacturer (OEM) to ensure

equipment safety is maintained.

• Do NOT attempt any maintenance or repair

work not described in this manual.

• After use, the equipment and components

may still be hot – allow the equipment to

cool and disconnect spark plugs and/or

electrical power sources and/or batteries

from it before adjusting, changing

accessories, or performing repair or

maintenance.

• Do NOT adjust while the equipment is

running.

• Perform service-related activities in suitable

conditions, such as a workshop.

• Replace worn, damaged or missing

warning/safety labels immediately.

General Power Tool Safety Warning

WARNING! READ ALL SAFETY WARNINGS, INSTRUCTIONS, ILLUSTRATIONS, AND SPECIFICATIONS PROVIDED WITH THIS POWER

TOOL. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/OR SERIOUS INJURY.

SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE. THE TERM "POWER TOOL" IN THE WARNINGS REFERS TO

YOUR MAINS-OPERATED (CORDED) POWER TOOL OR BATTERY-OPERATED (CORDLESS) POWER TOOL.

Work Area Safety

• Keep work area clean and well lit. Cluttered or dark areas invite accidents.

• Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Power tools create sparks

which may ignite the dust or fumes.

• Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical Safety

• Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric

shock if your body is earthed or grounded.

• Indoor Use. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.

Personal Safety

• Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under

the influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in serious personal injury.

• Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask, non-skid safety shoes, hard hat or

hearing protection used for appropriate conditions will reduce personal injuries.

• Prevent unintentional starting. Ensure the switch is in the OFF position before connecting to power source and/or battery pack, picking up or

carrying the tool. Carrying power tools with your finger on the switch or energizing power tools that have the switch on invites accidents.

• Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.

• Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair

can be caught in moving parts.

• If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust

collection can reduce dust-related hazards.

• Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can

cause severe injury within a fraction of a second.

Power Tool Use and Care

• Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for

which it was designed.

• Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must

be repaired.

• Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power tool before making any adjustments,

changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.

• Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the

power tool. Power tools are dangerous in the hands of untrained users.

• Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may

affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power

tools.

HG3 Heat Gun - SYNC Series

• Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work

to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.

• Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe

handling and control of the tool in unexpected situations.

Battery Tool Use and Care

• Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire

when used with another battery pack.

• Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.

• When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws, or other small metal objects,

that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.

• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts

eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.

• Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in

fire, explosion, or risk of injury.

• Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 265°F (130°C) may cause explosion.

• Follow all charging instructions and do not charge the battery pack or tool outside the temperature range specified in the instructions. Charging

improperly or at temperatures outside the specified range may damage the battery and increase the risk of fire.

Service

• Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power

tool is maintained.

• Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers.

Specific Safety Rules for Heat Guns

• READ THESE INSTRUCTIONS!

• Know your work environment. Hidden areas such as behind walls, ceilings, floors, soffit boards and other panels may contain flammable

materials that may ignite when using the heat gun in these locations. Ignition of these materials may not be readily apparent and could result in

property damage and personal injury. Check these areas before applying heat. If in doubt, use an alternate method. Pausing or lingering in one

spot may ignite the panel or the material behind it. Keep heat gun moving to avoid excessive temperatures.

• Do not direct the heat gun air airflow at clothing, hair or other body parts. Do not use as a hair dryer. Heat guns can produce 1100°F (593°C) or

more of flameless heat at the nozzle. Contact with the air stream could result in personal injury.

• Do not use near flammable liquids or in explosive atmospheres, such as in the presence of fumes, gases or dust. The flameless heat from the

heat gun may ignite the dust or fumes. Remove materials or debris that may become ignited from work area.

• Shield materials around the heated area to prevent property damage or fire.

• Keep a fire extinguisher nearby. Heat guns may ignite flammable materials left in the work area.

• WARNING! HOT SURFACES. ALWAYS HOLD THE HEAT GUN BY THE PLASTIC ENCLOSURE. DO NOT TOUCH NOZZLE, ACCESSORY

TIPS OR STORE HEAT GUN UNTIL THE NOZZLE HAS COOLED TO ROOM TEMPERATURE. THE METAL NOZZLE REQUIRES

APPROXIMATELY 20 MINUTES TO COOL BEFORE IT CAN BE TOUCHED. CONTACT WITH THE NOZZLE OR ACCESSORY TIP COULD

RESULT IN PERSONAL INJURY. PLACE THE HEAT GUN IN A CLEAR AREA AWAY FROM COMBUSTIBLE MATERIALS WHILE

COOLING TO PREVENT FLAMMABLE MATERIALS FROM IGNITING.

• Do not cut off airflow by placing nozzle too close to workpiece. Keep intake vents clean and clear of obstructions. Restricting airflow may cause

the heat gun to overheat.

• Place the heat gun on a stable, level surface when not hand held.

• Do not leave the heat gun unattended while running or cooling down. Inattention invites accidents.

• Store indoors in a dry location. Do not expose to rain or moisture.

• Do not direct airflow directly on glass. The glass may crack and could result in property damage or personal injury.

• WARNING! SOME DUST CREATED BY POWER SANDING, SAWING, GRINDING, DRILLING, AND OTHER CONSTRUCTION ACTIVITIES

CONTAINS CHEMICALS KNOWN TO CAUSE CANCER, BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. SOME EXAMPLES OF

THESE CHEMICALS ARE:

• lead from lead-based paint

• crystalline silica from bricks and cement and other masonry products.

• arsenic and chromium from chemically treated lumber.

• Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemicals: work in a

well-ventilated area, and work with approved safety equipment, such as those dust masks that are specially designed to filter out microscopic

particles.

Important Safety Instructions for Removing Paint

• WARNING! USE EXTREME CARE WHEN STRIPPING PAINT. PEELINGS, RESIDUE AND VAPOURS OF PAINT MAY CONTAIN LEAD,

WHICH IS POISONOUS. PRE-1977 PAINT MAY CONTAIN LEAD AND PAINT MADE BEFORE 1950 IS LIKELY TO CONTAIN LEAD. HAND

TO MOUTH CONTACT WITH PAINT PEELINGS OR RESIDUE FROM PRE-1977 PAINT MAY RESULT IN LEAD INGESTION. EXPOSURE

TO EVEN LOW LEVELS OF LEAD CAN CAUSE IRREVERSIBLE BRAIN AND NERVOUS SYSTEM DAMAGE. YOUNG AND UNBORN

CHILDREN ARE ESPECIALLY VULNERABLE TO LEAD POISONING. DO NOT REMOVE LEADBASED PAINT WITH A HEAT GUN.

BEFORE BEGINNING YOUR WORK, DETERMINE WHETHER THE PAINT YOU ARE REMOVING CONTAINS LEAD. A LOCAL HEALTH

DEPARTMENT OR A PROFESSIONAL WHO USES A PAINT ANALYSER CAN CHECK THE PAINT FOR LEAD CONTENT. LEADBASED

PAINT SHOULD BE REMOVED ONLY BYAPROFESSIONAL. PERSONS REMOVING PAINT SHOULD FOLLOW THESE GUIDELINES:

HG3 Heat Gun - SYNC Series

• Work in a well-ventilated area. If possible, move the workpiece outdoors. If working indoors, open windows and place an exhaust fan in a window.

Be sure the fan is moving air from inside to outside. Proper ventilation will reduce the risk of inhaling chemicals found in the fumes or dust created

by using a heat gun.

• Remove or cover any carpets, rugs, furniture, clothing, cooking utensils and air ducts to prevent property damage from the paint peelings.

• Place drop cloths in the work area to catch paint scrapings. Wear protective clothing such as hats, extra work shirts and overalls. Paint scrapings

may contain chemicals that are hazardous.

• Work in one room at a time. Remove furnishings or cover them and place in the centre of the room. Seal doorways with drop cloths to seal work

area from the rest of the building.

• Children, pregnant or potentially pregnant women, and nursing mothers should not be near work area until all work is completed, and work area

is cleaned thoroughly.

• Wear a dust respirator mask or a dual filter (dust and fume) respirator mask which has been approved by the Occupational Safety and Health

Administration (OSHA), or the National Institute of Safety and Health (NIOSH). These masks and replaceable filters are readily available at major

hardware stores. Be sure the mask fits. Beards and facial hair may keep masks from sealing properly. Change filters often. DISPOSABLE

PAPER MASKS ARE NOTADEQUATE.

• Use caution when operating the heat gun. Keep the heat gun moving to prevent excessive temperatures. Excessive heat can cause paint and

other materials to burn and cause fumes, which may be inhaled by the operator.

• Keep work environment clean. Keep food and drink away from work area. Wash hands, arms and face and rinse mouth before eating and

drinking. Do not smoke, or chew gum or tobacco in the work area. Paint scrapings and dust created from removing paint may contain chemicals

that are hazardous.

• Clean up all paint scraping and dust. DO NOT SWEEP, DRY DUST OR VACUUM. Wet mop floors. Use a wet cloth to clean all walls, sills, and

other surfaces where paint and dust have accumulated. Use a high phosphate detergent, trisodium phosphate (TSP), or a trisodium phosphate

substitute to clean and mop the work area.

• Dispose of paint scrapings properly. Following each work session, place paint scrapings in a double plastic bag, close it with tape or twist ties and

dispose.

• Remove protective clothing and work shoes in the work area to avoid transferring dust to other parts of the building. Wash work clothes

separately. Wipe shoes off with a wet rag that is then washed with the work clothes. Wash hair and body thoroughly with soap and water.

HG3 Heat Gun - SYNC Series

Safety Symbols

The product may have safety warning labels attached to it, explained below. Understand the symbols on your

product and their meanings. If any stickers become unreadable, unattached etc., replace them.

Flammable Material Hazard

Flammable liquids, gases, or

substances etc may present.

Avoid ignition sources and open

flames. Danger of fire.

Read User Manual

Read and fully understand

product safety warnings,

operation, procedures etc before

using the product.

Use Hand Protection

Wear appropriate hand protection

and take due care as the product

or use of the product may present

hand hazards.

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Electrocution / Electrical Shock

Hazard

High voltage or high current

electricity may be present or

required by the product. Take

due care when handling electrical

products, cables, plugs and

leads. Electrical shock can be

fatal.

Toxic Fumes / Dust Hazard

Using the product or by-products

from use may produce fumes,

smoke or particles that could be

harmful if inhaled. Wear

appropriate breathing protection

and have adequate ventilation.

Explosive Material Hazard

Combustible liquids, gases, or

substances etc may be present.

Avoid ignition sources and open

flames. Danger of explosion.

Cutting / Amputation Hazard

The product may have blades,

edges or mechanical devices that

can cause severe cut injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Crush Hazard

The product may have blades,

edges or mechanical devices that

can cause severe crush injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Single Operator Only

The product must be operated by

a single person only. More than

one person operating the product

may introduce additional hazards.

Use Face Protection

Wear appropriate full-face

protection and take due care as

the product or use of the product

may present face and eye

hazards.

Use Foot Protection

Wear appropriate foot protection

and take due care as the product

or use of the product may present

foot hazards.

Use Eye / Ear / Head Protection

Wear appropriate eye and / or

ear and / or head protection and

take due care as the product or

use of the product may present

eye, hearing, and head hazards.

Running Hazard

Do not run on or near the product

as doing so may present a fall

hazard.

Diving Hazard

Do not dive into the product as

doing so may present a neck /

head injury hazard.

Adult Supervision Required

Always supervise children and

other users of a product to

prevent drowning or injury.

Skin Penetration / Puncture

Hazard

The product may produce

pressure, emit liquids or objects

that can cause severe injury to

fingers, limbs, blood etc. Take

due care when handling and

using the product.

Hot Surface Hazard

Be aware that the product may

produce high temperatures and

hot surfaces that can cause burn

injuries.

Flying Debris Hazard

Be aware that the product or use

of the product may present

hazards produced by flying

debris. Wear appropriate clothing

and protective devices.

Moving Parts Hazard

Be aware that the product

contains or uses mechanical

devices that move or rotate.

Always wait for moving parts to

stop fully before handling the

product, adjusting, maintenance

etc.

HG3 Heat Gun - SYNC Series

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Pull Hazard

Be aware that the product

contains or uses mechanical

devices that can pull in objects

and can cause severe injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Slope / Fall Injury Hazard

Be aware that using the product

on sloping surfaces or in slippery

conditions may present additional

dangers from falls and contact

with blades, moving parts, hot

surfaces etc.

"Slam Dunk" Warning

Do NOT attempt "slam dunk"

manoeuvres as this may result in

severe injury due to falling,

product breakage or collapse etc.

Electrocution / Electrical Shock

Hazard - Outdoor

High voltage or high current

electricity may be present or

required by the product. Do NOT

use in rain, damp, or wet

conditions. Electrical shock can

be fatal.

Electrocution / Electrical Shock

Hazard - Disconnect

High voltage or high current

electricity may be present or

required by the product. Always

disconnect the product from the

electrical supply before handling

the product, adjusting,

maintenance etc.

Power Line Electrocution

Hazard

High voltage / high current power

lines may be present. Use

extreme caution to avoid contact

or interference with power lines.

Electrical shock can be fatal.

"Kick-Back" Hazard

High level of "kick-back" hazard

that can cause the machine to

suddenly rotate towards operator.

Kick-back injury can be fatal.

Winch Operator Position

Hazard

Do NOT stand between winch

and load. Do NOT use winch to

move people.

Winch Lift Hazard

Do NOT LIFT load vertically. Use

machine to PULL only.

Cable Hazard

Ensure that load bearing cable is

not kinked or knotted.

Winch Cable Hazard

Ensure that there is a minimum

number of cable coils on

winching mechanism.

Winch Hook Hazard

Carry hook to load – do NOT

throw or run.

Flash / Blinding Hazard

Wear appropriate eye protection

for welding. Direct exposure to

weld arcs may cause permanent

eye injury.

Laser Hazard

Laser may be in use – do NOT

look directly at laser or allow

others to.

HG3 Heat Gun - SYNC Series

Table of Contents

Safety ............................................................................................................................................................. 2

Safety Symbols ........................................................................................................................................................... 6

Parts Identification ....................................................................................................................................... 9

Main Parts ................................................................................................................................................................... 9

Accessories ................................................................................................................................................................ 9

Assembly ..................................................................................................................................................... 10

Removing/Inserting the Battery ................................................................................................................................ 10

Installing/Removing Nozzles .................................................................................................................................... 10

Operation ..................................................................................................................................................... 11

General Operation .................................................................................................................................................... 11

LED Light .................................................................................................................................................................. 11

Applications .............................................................................................................................................................. 11

Types of Nozzles ................................................................................................................................................ 11

Removing Paint .................................................................................................................................................. 11

Heat Shrinking .................................................................................................................................................... 12

Lithium Battery Care and Maintenance .................................................................................................... 13

Top 3 Battery Care Requirements ............................................................................................................................ 13

Maintenance ................................................................................................................................................ 15

Maintaining the Power Tool ...................................................................................................................................... 15

Cleaning .................................................................................................................................................................... 15

Environmental Protection ......................................................................................................................................... 15

Specifications ............................................................................................................................................. 16

HG3 Heat Gun - SYNC Series

Parts Identification

Main Parts

No. Name

1 Heat nozzle

2 Guard sleeve

3 Main body

4 ON/OFF switch/Airflow adjustment

5

LED

Accessories

5

4

3

2

1

A

B

C

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

HG3 Heat Gun - SYNC Series

Assembly

WARNING! Recharge only with the charger specified for the battery. For specific charging

instructions, read the operator’s manual supplied with your charger and battery.

Removing/Inserting the Battery

To remove the battery, push in the release buttons and pull the battery pack away from the tool.

WARNING! Always remove battery pack before changing or removing accessories. To insert the

battery, slide the pack into the body of the tool. Make sure it latches securely into place.

WARNING! Only use accessories specifically recommended for this tool. Others may be hazardous. To

reduce the risk of injury, do not remove or attach accessory tips until tool has cooled to room

temperature.

Installing/Removing Nozzles

1. To install, slide the nozzle onto the heat gun nose and twist it into place.

2. Adjust distance from work and length of application as necessary.

3. To remove, allow tool to cool to room temperature, then twist and pull the nozzle away from tool.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

HG3 Heat Gun - SYNC Series

Operation

WARNING! This product may heat surfaces around it. Heat may be projected in any direction.

Keep away from any surface that could be affected by heat.

General Operation

1. The tool is switched ON and OFF at the two-stage switch on the front of the grip handle. Please keep the

three-stage switch pressed to activate heat setting 2.

2. As soon as you stop keeping this setting pressed, the switch changes directly to setting 1.

3. The distance from the object you are working on depends on material and intended method of working.

Always try out the airflow and temperature on a test piece first.

4. Using the attachable accessory nozzles, the flow of hot air can be controlled with maximum precision. A

small quantity of smoke may occur the first time the tool is used.

5. Switch the tool OFF by selecting the "0" switch setting. Take care when changing hot nozzles!

6. When using the hot air tool in the self-resting position, make sure it is standing on a stable, non-slip and

clean surface.

LED Light

The LED light is lit when the tool is switched on. In addition to illuminating the area you are working on, it also

serves as a "tool ON" indicator light.

Applications

WARNING! To reduce the risk of injury, do not remove or attach accessory tips until tool has

cooled to room temperature.

Types of Nozzles

•

Hook Nozzle - Surrounding heat for thin pipe welding, soft soldering copper pipes, tube shaping and

shrinking of shrink tubes.

•

Air Reduction Nozzle - Intensified, spot directed heat for corners, plexiglass bending and soldering.

•

Deflector Nozzle - Deflected heat protects glass window panes when removing paint and putty.

•

Air Spreader Nozzle - Directs heat over large areas for drying, removing paint, floor coverings, and vinyl

tops.

Removing Paint

WARNING! Read safety instructions for removing paint before proceeding with paint removal.

1. Place nozzle approximately 1" away from work surface.

2. Pass nozzle back and forth over a small area of workpiece.

3. When paint starts to blister, then remove heat.

4. Remove paint using a sharp-edged putty knife.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

HG3 Heat Gun - SYNC Series

Heat Shrinking

1. Attach an air reduction or hook nozzle to the heat gun.

2. To heat shrink tubing, apply heat to the workpiece using a side-to-side motion until tubing has shrunk.

Remove heat immediately.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

HG3 Heat Gun - SYNC Series

Lithium Battery Care and Maintenance

Top 3 Battery Care Requirements

1. Charge battery before first use. The battery may arrive with some charge, regardless of this the

battery must be charged on the initial charge and for each subsequent charge.

2. Charge battery immediately when it is depleted. Do not store a depleted battery. This will

permanently impact the life of the battery. If the battery is going to be stored for a period of time, fully

charge the battery before storing.

3. Disconnect battery when not in use. To prolong the life of a battery, disconnect it from the unit

when not in use. Disconnect chargers from the battery once charged.

To ensure the battery maintains optimum performance, follow the guidelines outlined below.

•

For best results, charge batteries in temperatures between 10°C and 30°C

•

When battery is charged, disconnect the charger from the power supply and remove the battery from the

charger.

•

If a battery is stored or otherwise unused for an extended period, and the battery has no charge remaining

when you check it, consider it to be damaged. Do not attempt to recharge it or to use it. Replace it with a

new battery.

•

Use only with the battery charger specified by the manufacturer.

•

Ensure that the battery charger electrical cord is not subjected to damage or stress. Do not operate the

battery charger if it has a damaged electrical cord or plug.

•

Do not use the charger in wet areas or expose it to rain or water.

•

The typical estimated life of a Lithium-Ion battery is about two to three years or 300 to 500 charge cycles,

whichever occurs first. One charge cycle is a period of use from fully charged, to fully discharged, and fully

recharged again

•

Explosion hazard – protect the battery against heat, for example, direct sunlight and fire. Do not store

batteries in vehicles or locations subject to heat.

•

Batteries can explode in the presence of an ignition source, such as a pilot light. To reduce the risk of

serious personal injury, never use any cordless product in the presence of open ﬂame. Exploding batteries

can propel debris and chemicals.

•

Do not open the battery – danger of short-circuiting and/or explosion.

•

Do not attempt to destroy or disassemble the battery pack or remove any of its components.

•

Do not touch the battery terminals with metal objects and/or body parts as short-circuit and/or personal injury

may result.

•

Explosion hazard – do not open and/or short-circuit the battery.

•

Poison hazard – battery leakage (liquid ejection). Under extreme conditions, liquid may be ejected from the

battery – avoid contact. If contact accidentally occurs, immediately seek medical attention, and flush with

water. If liquid contacts eyes, immediately seek medical attention, flush with clean water for at least 10

minutes. Liquid ejected from the battery may cause irritation or burns.

•

Dispose of non-serviceable batteries in an environmentally responsible manner and according to local

regulations.

Failure to adhere to the requirements above may result in the battery becoming inoperative or battery life being

reduced. In extreme cases or abuse, battery overheating or fire may result.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

HG3 Heat Gun - SYNC Series

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

HG3 Heat Gun - SYNC Series

Maintenance

WARNING! To reduce the risk of injury, always unplug the charger and remove the battery pack

from the charger or tool before performing any maintenance.

Maintaining the Power Tool

•

Keep your tool, battery pack and charger in good repair by adopting a regular maintenance program. Inspect

your tool for issues such as undue noise, misalignment or binding of moving parts, breakage of parts, or any

other condition that may affect the tool operation.

•

If the tool does not start or operate at full power with a fully charged battery pack, clean the contacts on the

battery pack.

WARNING! To reduce the risk of personal injury and damage, never immerse your tool, battery

pack or charger in liquid or allow a liquid to flow inside them.

Cleaning

•

Clean dust and debris from vents.

•

Keep handles clean, dry, and free of oil or grease.

•

Use only mild soap and a damp cloth to clean, since certain cleaning agents and solvents are harmful to

plastics and other insulated parts. Some of these include gasoline, turpentine, lacquer thinner, paint thinner,

chlorinated cleaning solvents, ammonia and household detergents containing ammonia.

•

Never use flammable or combustible solvents around tools.

Environmental Protection

•

Do not throw devices, rechargeable batteries/batteries into household waste, fire or water at the end of their

useful life.

•

Rechargeable batteries/batteries should be collected, recycled, or disposed of in an environmentally friendly

manner.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

HG3 Heat Gun - SYNC Series

Specifications

Battery 20V SYNC series (Li-ion)

Max. Temperature

550℃

Power 250W

Max Air Flow 100 LPM

Switch positions 0 (Off), 1 (Fan Only), 2 (Heat Setting)

Fast Charger Yes

Input voltage 240V AC

Power Plug 10A Australian Standard

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Some experts believe that the incorrect or prolonged use of almost any

product may cause serious injury or death. To help reduce your risk of

serious injury or death, refer to the information below. For more information,

see www.datastreamserver.com/safety



Consult all documentation, packaging,

and product labelling before use. Note

that some products feature

documentation available online. It is

recommended to print and retain the

documentation.



Before each use, check the product for

loose/broken/damaged/missing parts,

wear, or leaks (if applicable). Never use a

product with

loose/broken/damaged/missing parts,

wear, or leaks.



Products must be inspected and serviced

(if applicable) by a qualified technician

every 6 months. This is based on

average residential use by persons of

average size and strength, and on a

property of average metropolitan size.

Use beyond these recommendations may

require more frequent

inspections/servicing.



Ensure that all users of the product have

completed a suitable industry recognised

training course before being allowed

access to the product.



The product has been supplied by a general merchandise

retailer that may not be familiar with your specific

application or description of application. Be sure to attain

third-party approval from a qualified specialist for your

application before use, regardless of any assurances from

the retailer or its representatives.



This product is not intended for use where fail-safe

operation is required. As with any product (for example,

automobile, computer, toaster), there is the possibility of

technical issues that may require the repair or

replacement of parts, or the product itself. If the possibility

of such failure and the associated time it may take to

rectify could in any way inconvenience the user, business,

or employee, or financially affect the user, business, or

employee, then the product is not suitable for your

requirements. This product is not intended for use where

incorrect operation or a failure of any kind, including but

not limited to, a condition requiring product return,

replacement, parts replacement, or service by a

technician may cause financial loss, loss of employee

time or an inconvenience requiring compensation.



If this product has been purchased in error when

considering the information presented here, contact the

retailer directly for details of their returns policy, if

required.

ideas, diagrams, or images may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying, scanning, or recording, or any information storage and retrieval system,

without express permission or consent from the publisher.

BAUMR-AG BMHGTL00A HG3 20V SYNC Cordless Power Heat Gun

Product's Documents

Product manual

Specifications

BAUMR-AG BMHGTL00A Questions and Answers
