8W USB SOLDERING IRON
MODEL NO: SDL12
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this
equipment.
9 Familiarise yourself with the application, limitations and potential hazards of the device.
9 Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9 Locate device in a suitable working area, keep area clean and tidy and free from unrelated materials.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
9 Keep the device clean for best and safest performance.
9 Ensuretherearenoammableorcombustiblematerialsneartheworkarea.
9 Wear approved safety eye protection (standard spectacles are not adequate).
9 Wear heat resistant gloves and appropriate protective clothing.
9 Ensure the workpiece is adequately held before operating the device.
9 Always use the stand provided when not using the hot tool so that the tip cannot make contact with the work surface.
9 Always use device in a well ventilated atmosphere or alternatively wear respiratory protection.
9 Ensure that when the device is put down during use that the tip is not near to or in contact with any material that may burn or melt.
9 After use always keep the plastic welder in its original package in a safe place away from children.
8 DO NOT touch the tip during its warm up phase.
8 DO NOT use in wet or damp conditions.
8 DO NOToperatethedevicewhenyouaretiredorundertheinuenceofalcohol,drugsorintoxicatingmedication.
8 DO NOTleavethedevicehotandunattended.(Ifyouareleavingtheworkareaevenforashortperiodoftimeswitchitoandallow
to cool.)
8 DO NOT use the device for any purpose other than that for which it has been designed.
8 DO NOT allow untrained persons to operate the device.
8 DO NOT touch the workpiece as it will be very hot. Allow to cool.
8 DO NOT operate the device if damaged.
2. INTRODUCTION
Heatsuptoworkingtemperatureinjust15seconds.Compactandlightweightdesignmakesthisdeviceextremelyportable.Idealdevicefor
weldingcircuitboardsandhobbyistsoldering.Maximumtemperatureof400°C.
3. SPECIFICATION
Model No:................................................................... SDL12
Power Rating: ...................................................................8W
4. OPERATION
4.1. Once the usb is plugged in the tool will become hot.
8 DO NOT leave the tool unattended while it is hot.
4.2. Use the stand provided when placing the device on a work surface, being aware that it is not touching anything.
5. MAINTENANCE
9 Keep the tip of the tool clean while you work. Have a damp sponge handy to occasionally wipe your tip to keep it clean.
Properly cleaned tips are bright and shiny.
8 Neverlethesurfaceofthetip.
SDL12Issue116/07/2020
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Hot surfaces Indoor use only Wear eye
protection
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
