Security Rader
Quick Start Guide
1
Appearance
2
Wiring
1. Install the device according to the instructions in Quick Start Guide.
2. To prevent injury, this device must be securely attached to the installation surface in
accordance with the installation instructions.
3. CAUTION: If the bracket is designed for a specific device model of our company, use the bracket
with the corresponding device only. Use with other devices may result in instability and cause
injury.
Installation Notes
1. Use 4 screws to secure the bracket on the device.
2. Loosen the screws on each side on the bracket.
3. Adjust the device's pitch angle and secure the screws back.
Bracket Installation
Screw: SC-PSFM4×10-SUS-GB9074.8
Notes:
1. If using latitude and longitude/GPS to calibrate, you should measure the latitude and longitude and orientation angle of the radar at the time of installation.
2. When measuring the direction of the radar, the deviation angle of the radar direction should be measured with 0° due north as the reference.
3
Installation
Grounding
372 mm
316 mm
84 mm
Alarm Input
Relay Output
Power Input
(36 VDC, with power adaptor)
Relay Output
RS-232 Debugging Port (for debugging use only)
RS-485
Network
Note: After installation and wiring, all interfaces need to be wrapped with waterproof tape.
