Hikvision DS-K3B411BX Value Swing Barriers

Product's Documents

Below are documents related to this product, you can read online or download:
User Manual Specification Installation Instruction
DS-K3B411BX photo

User Manual

This is the main product document for model DS-K3B411BX.

The file format is pdf, 123 pages, you can download this manual here .

background
DS-K3B411B(L)X Series Swing Barrier
User Manual
background
Legal Informaon
About this Document
This Document includes instrucons for using and managing the Product. Pictures, charts,
images and all other
informaon hereinaer are for descripon and explanaon only.
The
informaon contained in the Document is subject to change, without noce, due to
rmware updates or other reasons. Please nd the latest version of the Document at the
Hikvision website ( hps://www.hikvision.com ). Unless otherwise agreed, Hangzhou Hikvision
Digital Technology Co., Ltd. or its aliates (hereinaer referred to as "Hikvision") makes no
warranes, express or implied.
Please use the Document with the guidance and assistance of professionals trained in
supporng the Product.
About this Product
This product can only enjoy the aer-sales service support in the country or region where the
purchase is made.
If the product you choose is a video product, please scan the following QR code to obtain the
"Iniaves on the Use of Video Products", and read it carefully.
Acknowledgment of Intellectual Property Rights
Hikvision owns the copyrights and/or patents related to the technology embodied in the
Products described in this Document, which may include licenses obtained from third pares.
Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part
of this Document may be excerpted, copied, translated, or modied in whole or in part by any
means without
wrien permission.
and other Hikvision's trademarks and logos are the properes of Hikvision in
various
jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
LEGAL DISCLAIMER
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS DOCUMENT AND THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR
DS-K3B411B(L)X Series Swing Barrier User Manual
i
background
IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.
IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE
LATTER PREVAILS.
Data
Protecon
To protect data, the development of Hikvision Products incorporates privacy by design
principles. For example, for Products with facial
recognion features, biometrics data is stored in
your Products with encrypon method; for ngerprint Products, only ngerprint template will be
saved, which is impossible to reconstruct a
ngerprint image.
As a data controller/processor, you may process personal data, including collecon, storage, use,
processing, disclosure,
deleon, etc. You are advised to pay aenon to and comply with
applicable laws and regulaons related to the protecon of personal data, including without
limitaon, conducng security controls to safeguard personal data, such as, implemenng
reasonable administrave and physical security controls, conduct periodic reviews and the
assessments of the
eecveness of your security controls.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
DS-K3B411B(L)X Series Swing Barrier User Manual
ii
background
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the users authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable
protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the
instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television
recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the
separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
FCC
Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired
operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
DS-K3B411B(L)X Series Swing Barrier User Manual
iii
background
under the EMC Direcve 2014/30/EU, LVD Direcve 2014/35/EU, the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated
collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include
leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the
baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
DS-K3B411B(L)X Series Swing Barrier User Manual
iv
background
Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The
precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
The equipment must be connected to an earthed mains socket-outlet.
Shock hazard! Disconnect all power sources before maintenance.
Do not touch the bare metal contacts of the inlets
aer the circuit breaker is turned o.
Electricity sll exists.
indicates hazardous live and the external wiring connected to the terminals requires
installaon by an instructed person.
Keep body parts away from fan blades. Disconnect the power source during servicing.
Keep body parts away from motors. Disconnect the power source during servicing.
To prevent possible hearing damage, do not listen at high volume levels for long periods.
All the electronic
operaon should be strictly compliance with the electrical safety regulaons,
re
prevenon regulaons and other related regulaons in your local region.
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or
re hazard.
Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
If the top caps should be open and the device should be powered on for maintenance, make
sure:
1. Power
o the fan to prevent the operator from geng injured accidentally.
2. Do not touch bare high-voltage components.
3. Make sure the switch’s wiring sequence is correct
aer maintenance.
Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
When the product is installed on wall or ceiling, the device shall be
rmly xed.
If smoke, odors or noise rise from the device, turn
o the power at once and unplug the power
cable, and then please contact the service center.
DS-K3B411B(L)X Series Swing Barrier User Manual
v
background
Do not ingest baery, Chemical Burn Hazard.
This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used
baeries away from children. If the baery compartment does not close
securely, stop using the product and keep it away from children. If you think
baeries might have
been swallowed or placed inside any part of the body, seek immediate medical
aenon.
If the product does not work properly, please contact your dealer or the nearest service center.
Never aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
Cauons:
The equipment shall not be exposed to dripping or splashing and that no objects lled with
liquids, such as vases, shall be placed on the equipment.
Ensure correct wiring of the terminals for connecon to an AC mains supply.
The equipment has been designed, when required,
modied for connecon to an IT power
distribuon system.
+ idenes the posive terminal(s) of equipment which is used with, or generates direct current.
+ idenes the negave terminal(s) of equipment which is used with, or generates direct
current.
No naked
ame sources, such as lighted candles, should be placed on the equipment.
This equipment is suitable for mounng on concrete or other non-combusble surface only.
Install the equipment according to the instrucons in this manual.
To prevent injury, this equipment must be securely
aached to the oor/wall in accordance with
the installaon instrucons.
Stainless steel may be corroded in some circumstances. You need to clean and care the device by
using the stainless steel cleaner. It is suggested to clean the device every month.
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
Do not place the device in extremely hot (refer to the
specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
The device cover for indoor use shall be kept from rain and moisture.
Exposing the equipment to direct sun light, low
venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a
malfuncon however), and aecng the endurance of sensor at the
same
me.
Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
Please use a
so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
DS-K3B411B(L)X Series Swing Barrier User Manual
vi
background
Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to addional costs.
Improper use or replacement of the
baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used
baeries according to the instrucons provided by
the
baery manufacturer.
Biometric
recognion products are not completely applicable to an-spoong environments. If
you require a higher security level, use mulple authencaon modes.
Do not stay in the lane when the device is reboong.
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY.
The
instrucons shall require connecon of the equipment protecve earthing conductor to the
installaon protecve earthing conductor.
DS-K3B411B(L)X Series Swing Barrier User Manual
vii
background
Available Models
Product Name Model Type Descripon
Swing Barrier DS-K3B411BX-L Le Pedestal with Supplied
Access Control Board
DS-K3B411BLX-L Le Pedestal without Access
Control Board
DS-K3B411BX-M Middle Pedestal with Supplied
Access Control Board
DS-K3B411BLX-M Middle Pedestal without
Access Control Board
DS-K3B411BX-R Right Pedestal with Supplied
Access Control Board
DS-K3B411BLX-R Right Pedestal without Access
Control Board
DS-K3B411B(L)X Series Swing Barrier User Manual
viii
background
Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Introducon ........................................................................................................................... 1
1.2 Main Features ........................................................................................................................ 1
Chapter 2 System Wiring ............................................................................................................ 3
Chapter 3 Installaon ................................................................................................................. 5
3.1 Disassemble Pedestals ........................................................................................................... 5
3.2 Install Pedestals ..................................................................................................................... 5
Chapter 4 General Wiring ........................................................................................................... 9
4.1 Components
Introducon ...................................................................................................... 9
4.2 Wiring Electric Supply .......................................................................................................... 10
4.3 Terminal Descripon ............................................................................................................ 11
4.3.1 Main Lane Control Board Terminal
Descripon .......................................................... 11
4.3.2 Sub Lane Control Board Terminal Descripon ............................................................ 12
4.3.3 Access Control Board Terminal Descripon (Oponal) ............................................... 13
4.3.4 Main Extended Interface Board Terminal
Descripon ................................................ 15
4.3.5 Sub Extended Interface Board Terminal Descripon .................................................. 17
4.3.6 Card Reader Board Terminal Descripon .................................................................... 17
4.3.7 General Wiring ............................................................................................................ 18
4.3.8 RS-485 Wiring ............................................................................................................. 19
4.3.9 RS-232 Wiring ............................................................................................................. 20
4.3.10 Alarm Input Wiring ................................................................................................... 20
4.3.11 Exit
Buon Wiring ..................................................................................................... 20
4.3.12 Light Strip Wiring ...................................................................................................... 21
Chapter 5 Device
Sengs ......................................................................................................... 24
5.1 Conguraon via Buon ...................................................................................................... 25
5.2 Study Mode Sengs ............................................................................................................ 28
DS-K3B411B(L)X Series Swing Barrier User Manual
ix
background
5.2.1 Set Study Mode via Buon ......................................................................................... 29
5.2.2 Set Study Mode ........................................................................................................... 29
5.3 Keyfob Pairing ...................................................................................................................... 31
5.3.1 Pair Keyfob via
Buon ................................................................................................. 31
5.3.2 Pair Keyfob .................................................................................................................. 32
5.4 Inialize Device .................................................................................................................... 33
Chapter 6 Acvaon ................................................................................................................. 35
6.1 Acvate via SADP ................................................................................................................. 35
6.2 Acvate Device via Client Soware ...................................................................................... 36
6.3 Acvate via Web Browser .................................................................................................... 37
Chapter 7 Operaon via Web Browser ...................................................................................... 38
7.1 Login .................................................................................................................................... 38
7.2 Overview .............................................................................................................................. 38
7.3 Person Management ............................................................................................................ 39
7.4 Search Event ........................................................................................................................ 41
7.5 Conguraon ....................................................................................................................... 43
7.5.1 View Device
Informaon ............................................................................................. 43
7.5.2 Set Time ...................................................................................................................... 43
7.5.3 Set DST ........................................................................................................................ 44
7.5.4 Change Administrator's Password ............................................................................... 44
7.5.5 Online Users ................................................................................................................ 44
7.5.6 View Device Arming/Disarming
Informaon .............................................................. 45
7.5.7 Network
Sengs ......................................................................................................... 45
7.5.8 Event Linkage .............................................................................................................. 47
7.5.9 Access Control Sengs ............................................................................................... 49
7.5.10
Turnsle .................................................................................................................... 54
7.5.11 Card Sengs ............................................................................................................. 58
7.5.12 Set Privacy Parameters .............................................................................................. 59
DS-K3B411B(L)X Series Swing Barrier User Manual
x
background
7.5.13 Upgrade and Maintenance ....................................................................................... 59
7.5.14 Device Debugging ..................................................................................................... 60
7.5.15 Component Status .................................................................................................... 61
7.5.16 Log Query .................................................................................................................. 62
7.5.17
Cercate Management ........................................................................................... 62
Chapter 8 Client Soware Conguraon ................................................................................... 64
8.1 Conguraon Flow of Client Soware ................................................................................. 64
8.2 Device Management ............................................................................................................ 64
8.2.1 Add Device .................................................................................................................. 65
8.2.2 Reset Device Password ................................................................................................ 72
8.3 Group Management ............................................................................................................. 72
8.3.1 Add Group ................................................................................................................... 73
8.3.2 Import Resources to Group ......................................................................................... 73
8.3.3 Edit Resource Parameters ........................................................................................... 73
8.3.4 Remove Resources from Group .................................................................................. 74
8.4 Person Management ............................................................................................................ 74
8.4.1 Add
Organizaon ........................................................................................................ 74
8.4.2 Import and Export Person Idenfy Informaon .......................................................... 75
8.4.3 Get Person Informaon from Access Control Device .................................................. 77
8.4.4 Issue Cards to Persons in Batch ................................................................................... 78
8.4.5 Report Card Loss ......................................................................................................... 78
8.4.6 Set Card Issuing Parameters ........................................................................................ 79
8.5
Congure Schedule and Template ....................................................................................... 80
8.5.1 Add Holiday ................................................................................................................. 80
8.5.2 Add Template .............................................................................................................. 81
8.6 Set Access Group to Assign Access
Authorizaon to Persons .............................................. 82
8.7 Congure Advanced Funcons ............................................................................................ 84
8.7.1
Congure Device Parameters ...................................................................................... 84
DS-K3B411B(L)X Series Swing Barrier User Manual
xi
background
8.7.2 Congure Device Parameters ...................................................................................... 90
8.8 Door Control ........................................................................................................................ 91
8.8.1 Control Door Status ..................................................................................................... 91
8.8.2 Check Real-Time Access Records ................................................................................ 92
Appendix A. DIP Switch ............................................................................................................ 93
A.1 DIP Switch
Descripon ......................................................................................................... 93
A.2 DIP Switch Corresponded Funcons .................................................................................... 93
Appendix B. Buon Conguraon Descripon .......................................................................... 94
Appendix C. Event and Alarm Type ......................................................................................... 106
Appendix D. Table of Audio Index Related Content ................................................................. 107
Appendix E. Error Code Descripon ........................................................................................ 108
Appendix F. Communicaon Matrix and Device Command ..................................................... 109
DS-K3B411B(L)X Series Swing Barrier User Manual
xii
background
Chapter 1 Overview
1.1 Introducon
Figure 1-1 Appearance
The swing barrier is designed to detect unauthorized entrance or exit. By adopng the swing
barrier integratedly with the access control system, personnel should authencate to pass through
the lane via swiping IC or ID card, scanning QR code, etc. It is widely used in aracons, stadiums,
construcon sites, residences, etc.
1.2 Main Features
32-bit high-speed processor
TCP/IP network communicaon and network speed adapve
The communicaon data is specially encrypted to relieve the concern of privacy leak
Permissions validaon and an-tailgang
Supports control mode,
inducve mode, free passing mode, remain open mode and remain
closed mode in both entrance and exit direcon.
Bidireconal (Entering/Exing) lane
The barrier opening and closing speed can be congured according to the visitor ow
The barrier will be locked or stop working when people are nipped
An-forced-accessing
DS-K3B411B(L)X Series Swing Barrier User Manual
1
background
The barrier will react according to so mode or guarding mode when confronng forced-
accessing.
Self-detecon, Self-diagnoscs, and automac alarm
Audible and visual alarm will be triggered when
detecng intrusion, tailgang, reverse passing,
and climbing over barrier
IP
conict detecon
Remote control and management
Online/oine operaon
LED indicates the entrance/exit and passing status
Barrier is in open status when powered down; If the device is installed with supercapacitor, the
barrier remains open when powered down
Fire alarm passing
When the
re alarm is triggered, the barrier will be open automacally for emergency
evacuaon
Valid passing
duraon sengs
System will cancel the passing permission if a person does not pass through the lane within the
valid passing duraon
Opens/Closes barrier according to the schedule template (when equipped with access control
board)
Remote barrier opening via keyfob and broadcasng via loudspeaker (custom broadcasng
context is supported when installed with access control board).
DS-K3B411B(L)X Series Swing Barrier User Manual
2
background
Chapter 2 System Wiring
The preparaon before installaon and general wiring.
Steps
1.
Draw a central line on the
installaon surface of the le or right pedestal.
2.
Draw other parallel lines for installing the other pedestals.
Note
The distance between the nearest two line is L + 200 mm. L represents the lane width.
3.
Slot on the installaon surface and dig installaon holes. Put 4 expansion bolts of M12*120 for
each pedestal.
Figure 2-1 Hole Posion and System Wiring
4.
Bury cables. Each lane buries 1 high voltage cable and 1 low voltage cable. For details, see the
system wiring diagram of step 3.
Note
High voltage: AC power input
DS-K3B411B(L)X Series Swing Barrier User Manual
3
background
Low voltage: interconnecng cable (communicaon cable and 24 V power cable) and network
communicaon cable
The supplied 24 V power cable length is 4 m and the communicaon cable length is 3.75 m.
The suggested inner diameter of the low voltage conduit is larger than 30 mm.
If you want to bury both of the AC power cord and the low voltage cable, the two cables
should be in separated conduits to avoid interference.
If more peripherals are required to connect, you should increase the conduit diameter or bury
another conduit for the external cables.
The external AC power cord should be double-insulated.
The network cable must be CAT5e or the network cable has
beer performance.
DS-K3B411B(L)X Series Swing Barrier User Manual
4
background
Chapter 3 Installaon
3.1 Disassemble Pedestals
Before installaon, you should use the key to open the pedestals.
View the pictures below to nd the lock holes.
Figure 3-1 Lock Holes
3.2 Install Pedestals
Before You Start
Prepare for the installaon tools, check the device and the accessories, and clear the installaon
base.
DS-K3B411B(L)X Series Swing Barrier User Manual
5
background
Steps
Note
The device should be installed on the concrete surface or other non-ammable surfaces.
In order to prevent stainless steel from rusng due to dirt during the construcon process, it is
recommended to tear o the protecve lm aer the device is installed. There may be residual
glue at the
lm cung posion, and it is recommended to wipe the lm with WD-40 protecve
liquid aer tearing the lm.
No face recognion terminal installed: If the installaon area is too close to the wall, make sure
the distance between the pedestal and the wall should be more than 20 mm, or the surface may
be scratched.
Figure 3-2 Installaon Distance (Without Face Recognion Terminal)
Face recognion terminal installed: If the installaon area is too close to the wall, make sure the
distance between the pedestal and the wall should be more than 60 mm, or the surface may be
scratched.
DS-K3B411B(L)X Series Swing Barrier User Manual
6
background
Figure 3-3 Installaon Distance (With Face Recognion Terminal)
The dimension is as follows.
Figure 3-4 Dimension
1.
Prepare for the installaon tools, check the components, and prepare for the installaon base.
2.
Drill holes on the ground according to the
installaon holes on the pedestals and insert the
expansion sleeves.
3.
Seal the
boom of the turnsle to avoid water from entering.
4.
According to the entrance and exit marks on the pedestals, move the pedestals to the
corresponded
posions.
Note
Make sure the installaon holes on the pedestals and the base are aligned with each other.
5.
Secure the pedestals with expansion bolts.
DS-K3B411B(L)X Series Swing Barrier User Manual
7
background
Note
Do not immerse the pedestal in the water. In special circumstances, the immersed height should
be no more than 150 mm.
DS-K3B411B(L)X Series Swing Barrier User Manual
8
background
Chapter 4 General Wiring
4.1 Components Introducon
By default, basic components of the turnsle are connected well. The pedestals can communicate
by wiring the interconnecng cables. And the turnsle supports wiring the AC electric supply for
the whole system's power supply.
Note
The voltage uctuaon of the electric supply is between 100 VAC and 240 VAC, 50 to 60 Hz.
The picture displayed below describes each component's posion on the turnsle.
Note
The diagram is for reference only.
Figure 4-1 Components
Note
The reinstalled supercapacitor needs to be powered on for at least 3 minutes before it can work
normally.
DS-K3B411B(L)X Series Swing Barrier User Manual
9
background
The picture displayed below describes the IR sending/receiving module and their corresponding
posion on the pedestal.
Figure 4-2 IR Module Layout
Note
If the turnsle contains two lanes, standing at the entrance posion, the IR boards on the le
pedestal are the IR sending boards. The IR boards on the right pedestal are the IR receiving boards.
The IR boards on the le side of the middle pedestal are the IR receiving boards, while the IR
boards on the right side of the middle pedestal are the IR sending boards.
4.2 Wiring Electric Supply
Wire electric supply with the switch in the pedestal. Terminal L and terminal N are on the switch,
while terminal PE should connect to a ground wire (yellow and green wire).
Before wiring, open the
protecve cover outside the switch.
DS-K3B411B(L)X Series Swing Barrier User Manual
10
background
Note
The cable bare part should be no more than 8 mm. It is suggested that you can immerse the
bare part into the liquid n. If possible, wear an insulaon cap at the end of the bare cable.
Make sure there's no bare copper or cable aer the wiring.
The Terminal L and the Terminal N cannot be wired reversely. Do not wire the input and output
terminal reversely.
To avoid people injury and device damage, when tesng, the ground resistance of the
equipotenal points should not be larger than 2 Ω.
4.3 Terminal Descripon
The lane controller contains main lane controller and sub lane controller, which controls the IR
beams, motor, and other components' work.
4.3.1 Main Lane Control Board Terminal
Descripon
The main lane control board contains interconnecng interface, USB ash drive interface
(reserved), access control board interface, re input interface, exit buon interface, 12 VDC output
interface, 24 VDC input interface, fan interface,
communicaon interface, encoder interface, power
supply interface for motor, supercapacitor interface, IR adaptor interface and light bar interface.
DS-K3B411B(L)X Series Swing Barrier User Manual
11
background
The picture displayed below is the main lane control board diagram.
Figure 4-3 Main Lane Control Board Terminals
4.3.2 Sub Lane Control Board Terminal
Descripon
The sub lane control board contains interconnecng interface, USB ash drive interface (reserved),
access control board interface, exit
buon interface, 12 VDC power output interface, 24 VDC
power input interface, fan interface, communicaon interface, encoder interface, power supply
interface for motor, supercapacitor interface, IR adaptor interface and light bar interface.
The picture displayed below is the sub lane control board diagram.
DS-K3B411B(L)X Series Swing Barrier User Manual
12
background
Figure 4-4 Sub Lane Control Board Terminals
4.3.3 Access Control Board Terminal
Descripon (Oponal)
Access control board is mainly used for authority idencaon in places with high security levels
such as public security or judicial place, external device accessing, and communicaon with the
upper plaorm and lane controller.
DS-K3B411B(L)X Series Swing Barrier User Manual
13
background
Note
RS-485A corresponds to UART 5 on web and is for QR code scanner connecon at entrance by
default; RS-485C corresponds to UART 7 on web and is for card reader connecon at entrance by
default.
The SOC and MCU serial port are for maintenance and debugging use only.
Press the Reset buon for 5 s and the device will start to restore to factory sengs.
The DIP switch is for study mode seng and keyfob paring. For detailed informaon about the
DIP switch, see DIP Switch Descripon .
The wiring diagram of extended interface of access control board is shown as follows.
DS-K3B411B(L)X Series Swing Barrier User Manual
14
background
Figure 4-5 Wring Diagram of BUS3 Interface
Note
RS-232A corresponds to UART 1 on web.
4.3.4 Main Extended Interface Board Terminal Descripon
The main extended interface board contains the sub-1G antenna interface, barrier light interface,
loudspeaker interface, debugging port, Wiegand/exit
buon interface, 5 VDC output and
communicaon interface.
DS-K3B411B(L)X Series Swing Barrier User Manual
15
background
Figure 4-6 Main Extended Interface Board Terminal
Note
When the device is installed with access control board, the loudspeaker shall be connected to the
access control board. If not, the loudspeaker shall be connected to the main extended interface
board.
DS-K3B411B(L)X Series Swing Barrier User Manual
16
background
4.3.5 Sub Extended Interface Board Terminal Descripon
Figure 4-7 Sub Extended Interface Board
Note
RS-485B corresponds to UART 6 on web and is for QR code scanner connecon at exit by default.
RS-485D corresponds to UART 4 on web and is for card reader connecon at exit by default.
RS-232B corresponds to UART 2 on web.
RS-232C is reserved.
4.3.6 Card Reader Board Terminal Descripon
The card reader board can be connected to the access control board via RS-485 interface.
DS-K3B411B(L)X Series Swing Barrier User Manual
17
background
Figure 4-8 Card Reader Board
4.3.7 General Wiring
The general wiring of lane control board, access control board and extended interface board.
Figure 4-9 General Wiring
DS-K3B411B(L)X Series Swing Barrier User Manual
18
background
Note
The power cable from power supply to the main lane control board has been connected. You will
need to prepare the 14AWG power cable to connect the AC power input to power supply.
The supplied 2 interconnecng cables need connecng on-site:
1. 24 V power cable of 14 AWG. The cable is 4 m in length and put inside the right/middle
pedestal at the exit.
2. CAT5e
Communicaon cable. The cable is 3.75 m in length and put inside the package of the
right/middle pedestal.
The ① and ② or ③ and ④ refer to the two sides of a same board.
Barrier opens at the entrance/exit: connect to BTN1/BTN2 and GND.
4.3.8 RS-485 Wiring
The RS-485 interfaces on the access control board and sub extended interface board are suggested
to connect with the face
recognion module or the card reader. Here takes connecng with a card
reader as an example.
Note
There are 2 RS-485 interfaces on the access control board for entrance. Refer to Access Control
Board Terminal Descripon (Oponal) for details.
There are 2 RS-485 interfaces on the sub extended interface board for exit. Refer to Sub
Extended Interface Board Terminal Descripon for details.
If
connecng the RS-485 with a card reader, by default, the DIP switch of the card reader should
be set as follows:
For entrance, set the No.1 of the 4-digit DIP switch to ON side.
For exit, set the No.3 of the 4-digit DIP switch to ON side.
If there are other RS-485 devices
connecng, the ID of the RS-485 cannot be conicted.
The connected 12 V power interface for the face
recognion terminal cannot be connected with
other 12 V devices.
Figure 4-10 Wiring RS-485
DS-K3B411B(L)X Series Swing Barrier User Manual
19
background
4.3.9 RS-232 Wiring
Note
There is 1 RS-232 interface on the extended interface of access control board, see Access Control
Board Terminal Descripon (Oponal) . The RS-232A corresponds to UART 1 on web.
There is 1 RS-232 interface on the sub extended interface board, see Sub Extended Interface
Board Terminal Descripon . The RS-232B corresponds to UART 2 on web.
The RS-232C interface is reserved.
Figure 4-11 RS-232 Wiring
4.3.10 Alarm Input Wiring
On the main lane control board, you can wire the re alarm input interface.
Figure 4-12 Remaining Open
4.3.11 Exit Buon Wiring
The main and sub lane control board each has 1 buon interface, which can be connected to exit
buon or face recognion device.
DS-K3B411B(L)X Series Swing Barrier User Manual
20
background
Figure 4-13 Exit Buon Wiring
Note
The face recognion devices are powered via 12 VDC power output interface of the main and
sub lane control board.
Barrier open at the entrance: connect to BTN1 and GND.
Barrier open at the exit: connect to BTN2 and GND.
4.3.12 Light Strip Wiring
Change the barrier light color via wiring.
The wiring diagram is shown as follows:
DS-K3B411B(L)X Series Swing Barrier User Manual
21
background
Figure 4-14 Barrier Light Strip Wiring (Main Lane)
DS-K3B411B(L)X Series Swing Barrier User Manual
22
background
Figure 4-15 Barrier Light Strip Wiring (Sub Lane)
Note
Connect the brown wire to the 12VOUT interface of lane control board.
Connect the wire with color corresponding to the barrier light. If you want to change barrier light
color to green, for example, you need to connect the green wire to GND interface and connect
brown wire to 12VOUT interface.
The barrier light color is blue by default.
DS-K3B411B(L)X Series Swing Barrier User Manual
23
background
Chapter 5 Device Sengs
You can congure the device via buon on the main lane control board or the DIP switch on the
access control board.
Funcon Main Lane Control Board &
Loudspeaker (Connected to
Main Extended Interface
Board)
Main Lane Control Board &
Access Control Board &
Loudspeaker (Connected to
Access Control Board)
Working Mode
Normal/Study Mode Congure via buon (refer to
Set Study Mode via Buon )
Congure via DIP switch (refer
to Set Study Mode )
keyfob Pairing Congure via buon (refer to
Pair Keyfob via Buon )
Congure via DIP switch (refer
to Pair Keyfob )
Passing Mode Congure via buon Congure via buon/web
Memory Mode Congure via buon Congure via buon/web
Control Mode Congure via buon Congure via buon/web
Parameter Sengs
Keyfob Control Congure via buon Congure via buon/web
Barrier Opening Speed Congure via buon Congure via buon/web
Barrier Closing Speed Congure via buon Congure via buon/web
Card Reading on the Alarm
Area
Congure via buon Congure via buon/web
Barrier Opening Duraon
(Entrance)
Congure via buon Congure via buon/web
Barrier Opening Duraon (Exit) Congure via buon Congure via buon/web
IR Sensing Duraon Congure via buon Congure via buon/web
Intrusion Duraon Congure via buon Congure via buon/web
Overstay Duraon Congure via buon Congure via buon/web
Delay Time for Barrier Closing Congure via buon Congure via buon/web
Volume Adjustment Congure via buon Congure via buon
Barrier Material Congure via buon Congure via buon/web
DS-K3B411B(L)X Series Swing Barrier User Manual
24
background
Funcon Main Lane Control Board &
Loudspeaker (Connected to
Main Extended Interface
Board)
Main Lane Control Board &
Access Control Board &
Loudspeaker (Connected to
Access Control Board)
Barrier Length Congure via buon Congure via buon/web
Fan Congure via buon Congure via buon
Light Brightness Congure via buon Congure via buon/web
Restore to Default Congure via buon Congure via buon/web
Voice Prompt
Climbing over Barrier Enable or disable via buon Enable or disable via buon
Reverse Passing Enable or disable via buon Enable or disable via buon
Exceeding Passing Duraon Enable or disable via buon Enable or disable via buon
Intrusion Alarm Enable or disable via buon Enable or disable via buon
Tailing Alarm Enable or disable via buon Enable or disable via buon
Overstaying Alarm Enable or disable via buon Enable or disable via buon
Motor Inspecon Enable or disable via buon Enable or disable via buon
Self-check Voice Prompt Enable or disable via buon Enable or disable via buon
Study Mode Voice Prompt Enable or disable via buon Enable or disable via buon
Note
Refer to Buon Conguraon Descripon for detailed informaon.
If the device is not equipped with access control board, the loudspeaker shall be connected to
the main extended interface board.
If the device is equipped with access control board, the loudspeaker shall be connected to the
access control board. You can set custom broadcasng context via web. For details, see .
5.1 Conguraon via Buon
DS-K3B411B(L)X Series Swing Barrier User Manual
25
background
Buon Descripon
Figure 5-1 Buon
Exit Buon
Press to open the barrier from the entrance posion.
Double press to open the barrier from the exit posion.
Parameter Conguraon Buon
LEFT: Press to add 10 to conguraon data.
RIGHT: Press to add 1 conguraon data.
CANCEL: Return to the Level-1 menu, or exit Level-1 menu.
OK:
Conrm the sengs, or enter conguraon mode, or enter the Level-2 menu.
Note
Conguraon No. is displayed by two digital tubes.
Level-1 Menu: If the decimal point on the right is on, it indicates the Level-1 menu. The
number represents the conguraon No.
Level-2 Menu: If the decimal point in the middle is on, it indicates the level-2 menu. The
number represents the conguraon No.
Buon Conguraon Procedure
Steps:
DS-K3B411B(L)X Series Swing Barrier User Manual
26
background
1. Hold OK buon for 3 s unl one beep occurs. The device enter the conguraon mode. Level 1
menu lights up. The display screen displays the conguraon No. 1.
2. In the Level-1 menu, press LEFT (plus 10) and RIGHT (plus 1) to set the conguraon No. Press
OK to save
sengs and the enter the level-2 menu. Press CANCEL to exit the current menu, or
conduct no
operaon for 5 s to cancel conguraon and exit the current menu.
3.
Aer enter the level 2 menu, press LEFT (plus 10) and RIGHT (plus 1) to set the parameters at
your needs. Press OK to save the sengs or press CANCEL to exit the current menu, or conduct
no operaon for 5 s to cancel conguraon and exit the current menu.
Note
-
The conguraon No. will display in a cycle.
-
Each conguraon No. refers to a funcon. For details about the conguraon No. and its
related funcon, see Buon Conguraon Descripon .
Example
Take the procedure of seng barrier opening duraon (entrance) to 8 s as example.
DS-K3B411B(L)X Series Swing Barrier User Manual
27
background
Figure 5-2 Procedure
Hold OK for 3 s unl you hear one beep. The device enters the conguraon mode and the level 1
decimal point lights up. The display screen will display the No. 1.
Press RIGHT 8
mes and then press OK to enter the level-2 menu and the barrier opening duraon
(entrance) is 5 s by default.
Press RIGHT 3 mes to set the barrier opening duraon (entrance) as 8 s. Press OK to save the
sengs.
5.2 Study Mode
Sengs
Set the closed posion of the device barrier.
DS-K3B411B(L)X Series Swing Barrier User Manual
28
background
5.2.1 Set Study Mode via Buon
Enter the study mode through buon conguraon to set the closed posion of the device barrier.
Steps
Note
If the device is equipped with access control board, you can set study mode via DIP switch on
the access control board only.
For details about buon's operaon, see Conguraon via Buon .
For details about the
conguraon No. and its related funcon, see Buon Conguraon
Descripon .
1.
Enter the study mode.
1) Enter the
conguraon mode.
2) Set the conguraon No. in Level-1 to 1. The device will enter the study mode.
3) Set the
conguraon No. in the Level-2 menu to 2. The device will enter the study mode.
2.
Power o the device and swing the barrier unl it is vercal to the pedestal.
3.
Power on the device.
The device will remember the current posion automacally.
4.
Reboot the device when you hear Study accomplished. Please reboot.
5.2.2 Set Study Mode
Enter the study mode through DIP switching to set the closed posion of the device barrier.
Steps
1.
Set the No.1 of the 2-digit DIP switch on the access control board to ON by referring the
following
gure to enter the study mode.
DS-K3B411B(L)X Series Swing Barrier User Manual
29
background
Figure 5-3 DIP Switch Locaon
Figure 5-4 Study Mode
2.
Adjust the closed posion of the barrier.
3.
Power on the device.
The device will remember the current
posion (closed posion) automacally.
4.
Power o the device.
5.
Set the No.1 switches of the 2-digit DIP Switch on the main user extended interface board by
referring to the following
gure.
DS-K3B411B(L)X Series Swing Barrier User Manual
30
background
Figure 5-5 Normal Mode
6.
Power on the device again.
Note
For details about the DIP switch value and meaning, see DIP Switch Descripon.
The barrier will open automacally and turns back to the closed posion. At this circumstance,
the device enters the normal mode.
5.3 Keyfob Pairing
Pair keyfob via buon or DIP switch.
5.3.1 Pair Keyfob via
Buon
Pair the keyfob to the device via buon to open/close the barrier remotely.
Before You Start
Ask our technique supports or sales and purchase the keyfob.
Steps
Note
If the device is equipped with access control board, you can pair keyfob via DIP switch on the
access control board only.
For details about buon's operaon, see Conguraon via Buon .
For details about the
conguraon No. and its related funcon, see Buon Conguraon
Descripon .
For details about the keyfob operaon instrucons, see the keyfob's user manual.
1.
Enter the keyfob pairing mode.
1) Enter the conguraon mode.
2) Set the
conguraon No. in Level-1 to 2. The device will enter the keyfob pairing mode.
3) Set the conguraon No. in the Level-2 menu to 2. The device will enter the keyfob pairing
mode.
2.
Hold the Close
buon for more than 10 seconds.
The keyfob's indicator will
ash if the pairing is completed.
DS-K3B411B(L)X Series Swing Barrier User Manual
31
background
3.
Exit the keyfob pairing mode.
1) Enter the conguraon mode.
2) Set the conguraon No. in Level-1 to 2. The device will enter the keyfob pairing mode.
3) Set the
conguraon No. in the Level-2 menu to 1. The device will exit the keyfob pairing
mode.
4.
Reboot the device to take eect.
5.3.2 Pair Keyfob
Pair the remote control to the device through DIP switch to open/close the barrier remotely.
Before You Start
Ask our technique supports or sales and purchase the keyfob.
Steps
1.
Power
o the turnsle.
2.
Set the No.2 switch of the DIP Switch on the access control board to the ON side.
Figure 5-6 DIP Switch Locaon
DS-K3B411B(L)X Series Swing Barrier User Manual
32
background
Figure 5-7 Enable Keyfob Paring Mode
3.
Power on the turnsle and it will enter the keyfob pairing mode.
4.
Hold the Close
buon for more than 10 seconds.
The keyfob's indicator of the will ash twice if the pairing is completed.
5.
Set the No.2 switch to the OFF side, and reboot the turnsle to take eect.
Note
Only one turnsle can pair the keyfob. If mulple turnsles are in the pairing mode, the
keyfob will select only one of them to pair.
For details about DIP switch value and meaning, see DIP Switch Descripon .
6.
Oponal: Go to System → User → Keyfob User on the remote control page of the client
soware to delete the keyfob.
5.4
Inialize Device
Steps
1.
Hold the inializaon buon on the access control board for 5 s.
Figure 5-8 Inializaon Buon Posion
2.
The device will start restoring to factory sengs.
3.
When the process is nished, the device will beep for 3 s.
Cauon
The inializaon of the device will restore all the parameters to the default seng and all the
device events are deleted.
DS-K3B411B(L)X Series Swing Barrier User Manual
33
background
Note
Make sure no persons are in the lane when powering on the device.
DS-K3B411B(L)X Series Swing Barrier User Manual
34
background
Chapter 6 Acvaon
You should acvate the device before the rst login. Aer powering on the device, the system will
switch to Device
Acvaon page.
Acvaon via the device, SADP tool and the client soware are supported.
The default values of the device are as follows:
The default IP address: 192.0.0.64
The default port No.: 8000
The default user name: admin
6.1
Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
Before You Start
Get the SADP soware from the supplied disk or the ocial website hp://
www.hikvision.com/en/ , and install the SADP according to the prompts.
The device and the PC that runs the SADP tool should be within the same subnet.
The following steps show how to acvate a device and modify its IP address. For batch acvaon
and IP addresses modicaon, refer to User Manual of SADP for details.
Steps
1.
Run the SADP soware and search the online devices.
2.
Find and select your device in online device list.
3.
Input new password (admin password) and
conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4.
Click
Acvate to start acvaon.
DS-K3B411B(L)X Series Swing Barrier User Manual
35
background
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same subnet as your computer by either modifying the IP
address manually or checking Enable DHCP.
3) Input the admin password and click Modify to
acvate your IP address modicaon.
6.2
Acvate Device via Client Soware
For some devices, you are required to create the password to acvate them before they can be
added to the
soware and work properly.
Steps
Note
This funcon should be supported by the device.
1.
Enter the Device Management page.
2.
Click on the right of Device Management and select Device.
3.
Click Online Device to show the online device area.
The searched online devices are displayed in the list.
4.
Check the device status (shown on Security Level column) and select an
inacve device.
5.
Click
Acvate to open the Acvaon dialog.
6.
Create a password in the password eld, and conrm the password.
DS-K3B411B(L)X Series Swing Barrier User Manual
36
background
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
7.
Click OK to acvate the device.
6.3
Acvate via Web Browser
You can acvate the device via the web browser.
Steps
1.
Enter the device default IP address (192.0.0.64) in the address bar of the web browser, and press
Enter.
Note
Make sure the device IP address and the computer's should be in the same IP segment.
2.
Create a new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
3.
Click Acvate.
4.
Edit the device IP address. You can edit the IP address via the SADP tool, the device, and the
client
soware.
DS-K3B411B(L)X Series Swing Barrier User Manual
37
background
Chapter 7 Operaon via Web Browser
7.1 Login
You can login via the web browser or the remote conguraon of the client soware.
Note
Make sure the device is acvated. For detailed informaon about acvaon, see Acvaon .
Login via Web Browser
Enter the device IP address in the address bar of the web browser and press Enter to enter the
login page.
Enter the device user name and the password. Click Login.
Login via Remote
Conguraon of Client Soware
Download and open the client soware. Aer adding the device, click to enter the Conguraon
page.
7.2 Overview
You can view the device component status, real-me event, person informaon, network status,
basic
informaon, and device capacity. You can also control the barrier remotely.
Figure 7-1 Overview
Funcon Descripons:
Device Component Status
DS-K3B411B(L)X Series Swing Barrier User Manual
38
background
You can check if the device is working properly. Click View More to view the detailed
component status.
Remote Control
/ / /
The door is opened/closed/remaining open/remaining closed.
Real-Time Event
You can view the event Employee ID, Name, Card No., Event Type, Time, and
Operaon. You can
also click View More to enter the search condions, including the event type, employee ID, the
name, the card No., the start me, and the end me, and click Search. The results will be
displayed on the right panel.
Person
Informaon
You can view the added and not added informaon of person and card.
Network Status
You can view the network connecon status.
Basic Informaon
You can view the model, serial No. and rmware version.
Device Capacity
You can view the person, card and event capacity.
7.3 Person Management
Click Add to add the person's informaon, including the basic informaon, cercate,
authencaon and sengs.
DS-K3B411B(L)X Series Swing Barrier User Manual
39
background
Figure 7-2 Add Person
Add Basic
Informaon
Click Person Management → Add to enter the Add Person page.
Add the person's basic
informaon, including the employee ID, the person's name, and person
type.
If you select Visitor as the person type, you can set the visit
mes.
Click Save to save the sengs.
Set Permission Time
Click Person Management → Add to enter the Add Person page.
DS-K3B411B(L)X Series Swing Barrier User Manual
40
background
Enable Long-Term Eecve User, or set Validity Period and the person can only has the permission
within the congured me period according to your actual needs.
Click Save to save the sengs.
Add Card
Click Person Management → Add to enter the Add Person page.
Click Add Card, enter the Card No. and select the Property, and click OK to add the card.
Note
Up to 50 cards can be added.
Click Save to save the sengs.
Authencaon
Sengs
Click Person Management → Add to enter the Add Person page.
Set
Authencaon Type as Same as Device or Custom.
Click Save to save the sengs.
Import/Export Person Data
Export Person Data
You can export added person data for back-up or imporng to other devices.
Click Export Person Data, set an
encrypon password and conrm it. Click OK.
Note
The person data will be downloaded to your PC.
The password you set will be required for imporng the data le.
Imporng Person Data
Click Imporng Person Data and select the le. Click Import.
Enter the encrypon password to import and synchronize the person data to devices.
7.4 Search Event
Click Event Search to enter the Search page.
DS-K3B411B(L)X Series Swing Barrier User Manual
41
background
Figure 7-3 Search Event
Enter the search condions, including the event type, the employee ID, the name, the card No., the
start
me, and the end me, and click Search.
The event types contain access control event and ID card event. If you choose to search for ID card
event, you will not need to enter the employee ID, the name, or the card No.
The results will be displayed on the right panel.
DS-K3B411B(L)X Series Swing Barrier User Manual
42
background
7.5 Conguraon
7.5.1 View Device Informaon
Click Conguraon → System → System Sengs → Basic Informaon to enter the conguraon
page.
You can view the device name, language, model, serial No., version, IO input, IO output, and local
RS-485 number.
You can change Device Name and click Save.
You can view the device capacity, including person, card and event.
7.5.2 Set Time
Set the device's me.
Click Conguraon → System → System Sengs → Time Sengs .
Figure 7-4 Time Sengs
Click Save to save the sengs aer the conguraon.
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
DS-K3B411B(L)X Series Swing Barrier User Manual
43
background
NTP
You should set the NTP server's IP address, port No., and interval.
Manual
By default, the device me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's me.
Server Address Type/Server Address/NTP Port/Interval
You can set the server address type, server address, NTP port, and interval.
7.5.3 Set DST
Steps
1.
Click
Conguraon → System → System Sengs → Time Sengs .
2.
Enable DST.
3.
Set the DST start me, end me and bias me.
4.
Click Save to save the sengs.
7.5.4 Change Administrator's Password
Steps
1.
Click
Conguraon → User Management .
2.
Click .
3.
Enter the old password and create a new password.
4.
Conrm the new password.
5.
Click OK.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
7.5.5 Online Users
The informaon of users logging into the device is shown.
DS-K3B411B(L)X Series Swing Barrier User Manual
44
background
Go to Conguraon → User Management → Online Users to view the list of online users.
7.5.6 View Device Arming/Disarming Informaon
View device arming type and arming IP address.
Go to
Conguraon → User Management → Arming/Disarming Informaon .
You can view the device arming/disarming informaon. Click Refresh to refresh the page.
7.5.7 Network Sengs
Set TCP/IP and port.
Set Basic Network Parameters
Click Conguraon → Network → Network Sengs → TCP/IP .
Figure 7-5 TCP/IP Sengs Page
Set the parameters and click Save to save the sengs.
NIC Type
Select a NIC type from the drop-down list. By default, it is Self-Adapve.
DHCP
If you disable DHCP, you should manually set the IPv4 address, IPv4 subnet mask, IPv4 default
gateway, preferred DNS server, and alternate DNS server.
DS-K3B411B(L)X Series Swing Barrier User Manual
45
background
If you enable DHCP, the system will automacally allocate the IPv4 address, IPv4 subnet mask,
the IPv4 default gateway preferred DNS server and alternate DNS server.
DNS Server
Set the preferred DNS server and the Alternate DNS server according to your actual need.
Set Port Parameters
Set the HTTP, HTTPS, and HTTP Listening parameters.
Click Conguraon → Network → Network Service → HTTP(S) .
Figure 7-6 Network Service
HTTP
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is
modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.
HTTPS
DS-K3B411B(L)X Series Swing Barrier User Manual
46
background
Set the HTTPS for accessing the browser. Cercate is required when accessing.
HTTP Listening
The device can send alarm informaon to the event alarm IP address or domain name via HTTP
protocol/HTTPS protocol. Edit the event alarm IP address or domain name, URL, port, and
protocol.
Note
The event alarm IP address or domain name should support the HTTP protocol/HTTPS protocol
to receive the alarm informaon.
.
7.5.8 Event Linkage
Set linked acons for events.
Steps
1.
Click Conguraon → Event → Basic Event → Event Linkage to enter the page.
DS-K3B411B(L)X Series Swing Barrier User Manual
47
background
Figure 7-7 Event Linkage
2.
Set event source.
-
If you choose Linkage Type as Event Linkage, you need to select event types from the drop-
down list.
-
If you choose Linkage Type as Card Linkage, you need to enter the card No. and select the
card reader.
DS-K3B411B(L)X Series Swing Barrier User Manual
48
background
-
If you choose Linkage Type as Employee ID Linkage, you need to enter the employee ID and
select the card reader.
3.
Set linked acon.
Linked Buzzer
Enable Linked Buzzer and select Start Buzzing or Stop Buzzing for the target event.
Linked Door
Enable Linked Door, check Door 1 or Door 2, and set the door status for the target event.
Linked Alarm Output
Enable Linked Alarm Output, check Alarm Output 1 or Alarm Output 2, and set the alarm
output status for the target event.
7.5.9 Access Control
Sengs
Set Authencaon Parameters
Click Conguraon → Access Control Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
Figure 7-8 Set Authencaon Parameters
Click Save to save the sengs aer the conguraon.
DS-K3B411B(L)X Series Swing Barrier User Manual
49
background
Terminal
Choose Entrance or Exit for sengs.
Terminal Type/Terminal Model
Get terminal descripon. They are read-only.
Enable
Authencaon Device
Enable the authencaon funcon.
Authencaon
Select an authencaon mode according to your actual needs from the drop-down list.
Authencaon Interval
You can set the authencaon interval of the same person when authencang. The same
person can only
authencate once in the congured interval. A second authencaon will be
failed.
Alarm of Max. Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Max. Authencaon Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Communicaon with Controller Every
When the access control device cannot connect with the card reader for longer than the set
me, the card reader will turn oine automacally.
Note
The authencaon interval value ranges from 2 s to 255 s.
Set Door Parameters
Click Conguraon → Access Control → Door Parameters .
DS-K3B411B(L)X Series Swing Barrier User Manual
50
background
Figure 7-9 Door Parameters Sengs Page
Click Save to save the sengs aer the conguraon.
Door No.
Select Entrance or Exit for
sengs.
Door Name
You can create a name for the door.
Open Duraon
Set the door unlocking duraon. If the door is not opened for the set me, the door will be
locked.
Note
The open duraon ranges from 5 s to 60 s.
Exit Buon Type
You can set the exit buon as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Open.
Door Remain Open
Duraon with First Person
Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows
mulple persons access the door or other authencaon acons.
Note
The duraon ranges from 1 s to 1440 s.
Serial Port Sengs
Set serial port parameters.
DS-K3B411B(L)X Series Swing Barrier User Manual
51
background
Steps
1.
Click Conguraon → Access Control → Serial Port Conguraon .
Figure 7-10 Serial Port Sengs
2.
Select a serial port No., and the corresponding serial port type will display automacally.
3.
Set Baud Rate, Data Bit, Stop Bit and Parity.
4.
Set the Peripheral Type as Card Reader, QR Code Scanner, Fingerprint Module or Disable.
Note
When you select QR Code Scanner, Fingerprint Module or Disable, you can set the peripheral
posion.
5.
You can view the connected device model and peripheral soware version.
6.
Click Save.
Set Wiegand Parameters
You can set the Wiegand transmission
direcon.
Steps
Note
Some device models do not support this funcon. Refer to the actual products when conguraon.
1.
Click Conguraon → Access Control → Wiegand Sengs .
DS-K3B411B(L)X Series Swing Barrier User Manual
52
background
2.
Select Entrance or Exit.
3.
Enable Wiegand funcon.
4.
The wiegand transmission direcon is set Input by default.
Note
Input: the device can connect a Wiegand card reader.
5.
Click Save to save the
sengs.
Note
If you change the peripheral, and aer you save the device parameters, the device will reboot
automacally.
Set Terminal Parameters
Set the working mode and remote vericaon.
Steps
1.
Click Conguraon → Access Control → Terminal Parameters to enter the page.
Figure 7-11 Terminal Parameters
2.
Set the device working mode.
Permission Free Mode
The device will not verify the person's permission, but only the person's validity period. If the
person is in the validity period, the barrier will open.
You can enable Verify
Credenal Locally. Aer enabling the funcon, the device will only
verify the person's permission without the schedule template, etc.
Access Control Mode
The device works normally and will verify the person's permission to open the barrier.
3.
Set remote
vericaon.
1) Enable Remote Vericaon.
DS-K3B411B(L)X Series Swing Barrier User Manual
53
background
Note
The device will upload the person's authencaon informaon to the plaorm. The plaorm
will judge to open the barrier or not.
2) Oponal: Enable Verify Credenal Locally.
Note
Aer enabling the funcon, the device will only verify the person's permission without the
schedule template, etc.
4.
Click Save to complete terminal parameter sengs.
7.5.10 Turnsle
Basic Parameters
Set turnsle basic parameters.
Steps
1.
Click Conguraon Turnsle → Basic Sengs to enter the page.
DS-K3B411B(L)X Series Swing Barrier User Manual
54
background
Figure 7-12 Basic Parameters
2.
View the Device Type, Device Model and Working Status.
3.
Set Barrier Material, Lane Width, Barrier Opening Speed and Barrier Closing Speed.
4.
Set the passing mode.
-
If you choose General Passing, you can select the barrier status for the entrance and exit from
the drop-down list.
Note
If you set barrier-free mode, the barrier remains open and will close when authencaon
fails.
-
If you choose Weekly Schedule, you can set a weekly schedule for entrance and exit barriers.
5.
Click Save.
keyfob
Set keyfob patameters.
Steps
1.
Click
Conguraon Turnsle → Keyfob to enter the page.
DS-K3B411B(L)X Series Swing Barrier User Manual
55
background
Figure 7-13 keyfob
2.
Set Working Mode as One-to-One or One-to-Many.
3.
Add keyfob.
1) Click Add and the keyfob adding window will pop up.
2) Enter the Name and Serial No..
3) Check to enable Remain Open Permission at your actual needs.
4) Click OK to add the keyfob.
4.
Oponal: Select a keyfob and click Delete to delete the keyfob.
5.
Click Save.
IR Detector
Set IR detector.
Steps
1.
Click
Conguraon Turnsle → IR Detector to enter the page.
Figure 7-14 IR Detector
DS-K3B411B(L)X Series Swing Barrier User Manual
56
background
2.
Set the entrance and exit inducve mode as Single Triggered or Triggered Simultaneously.
3.
Set custom IR detector mode.
Enable IR Emergency Mode
If some IR beams do not work properly, you can shield those IR beams to restore the lane. But
this acon may hit person and cause injury.
Enable Custom
An-pinch for Door Closing
An-pinch for door closing refers that the barrier will not close if the device has detected
person in the lane. Only aer the person walks out of the lane, the barrier will close. If you
enable the
funcon, you can shield parts of the IR beams for closing barrier in advance. But
this acon may hit person and cause injury.
4.
Click Save.
People
Counng
Set people counng .
Steps
1.
Click Conguraon Turnsle → People Counng to enter the page.
Figure 7-15 People Counng
2.
Check to enable People Counng.
3.
Enable Device
Oine People Counng at your actual needs.
4.
Select People Counng Type as Invalid, Passing Detecon or Authencaon Number.
5.
Oponal: Click clear to clear all the people counng informaon.
Other
Sengs
Set other parameters.
DS-K3B411B(L)X Series Swing Barrier User Manual
57
background
Steps
1.
Click Conguraon Turnsle → Other Sengs to enter the page.
2.
Set Alarm Output Duraon.
Note
The alarm output duraon ranges from 0 s to 3599 s.
3.
Set Temperature Unit.
4.
Check to enable Do Not Open Barrier When Lane is Not Clear.
5.
Drag the block or enter the value to adjust the light board brightness.
6.
Set the alarm buzzer beeping duraon, door closing delay me, intrusion duraon, overstaying
duraon and IR obstructed duraon.
7.
Check to enable Memory Mode at your actual needs.
Note
Mulple cards presenng for mulple person passing is allowable when enabling the memory
mode. When the passing person's number exceeds the card presenng number, or aer the
latest person passing with no other person passing within the door open duraon, the door will
close
automacally.
8.
Choose the control mode.
So Mode
The barrier will be closed aer the person has passed through the barrier when there are
tailing, forced accessing, etc.
Guard Mode
The barrier will be closed immediately when there are tailgang, forced accessing, etc.
9.
Set the
re input type.
10.
Click to enable Motor Self-Test and choose the main lane or sub lane to start motor self-
tesng.
11.
Click Save.
7.5.11 Card
Sengs
Set Card Security
Click Conguraon → Card Sengs → Card Type to enter the sengs page.
Set the parameters and click Save.
Enable NFC Card
In order to prevent the mobile phone from
geng the data of the access control, you can
disable NFC card to increase the security level of the data.
Enable M1 Card
DS-K3B411B(L)X Series Swing Barrier User Manual
58
background
Enable M1 card and authencang by presenng M1 card is available.
M1 Card Encrypon
Sector
M1 card encrypon can improve the security level of authencaon.
Enable the funcon and set the encrypon sector. By default, Sector 13 is encrypted. It is
recommended to encrypt sector 13.
Enable EM Card
Enable EM card and
authencang by presenng EM card is available.
Note
If the peripheral card reader supports presenng EM card, the funcon is also supported to
enable/disable the EM card funcon.
Enable DESFire Card
The device can read the data from DESFire card when enabling the DESFire card funcon.
DESFire Card Read Content
Aer enable the DESFire card content reading funcon, the device can read the DESFire card
content.
Enable FeliCa Card
The device can read the data from FeliCa card when enabling the FeliCa card funcon.
Set Card
Authencaon Parameters
Set the card reading content when authencate via card on the device.
Go to Conguraon → Card Sengs → Card NO. Authencaon Sengs .
Select a card
authencaon mode and enable reversed card No. at your actual needs. Click Save.
7.5.12 Set Privacy Parameters
Set the event storage type.
Go to
Conguraon → Security → Privacy Sengs
The event storage type is overwring by default. The earliest 5% events will be deleted when the
system detects the stored events has been over 95% of the full space.
7.5.13 Upgrade and Maintenance
Reboot device, restore device parameters, and upgrade device version.
DS-K3B411B(L)X Series Swing Barrier User Manual
59
background
Reboot Device
Click Maintenance and Security → Maintenance → Restart .
Click Restart to reboot the device.
Upgrade
Click Maintenance and Security → Maintenance → Upgrade .
Select an upgrade type from the drop-down list. Click
and select the upgrade le from your
local PC. Click Upgrade to start upgrading.
Note
Do not power o during the upgrading.
Restore Parameters
Click Maintenance and Security → Maintenance → Backup and Reset .
Restore All
All parameters will be restored to the factory
sengs. You should acvate the device before
usage.
Restore
The device will restore to the default sengs, except for the network parameters and the user
informaon.
Import and Export Parameters
Click Maintenance and Security → Maintenance → Backup and Reset .
Export
Click Export to export the device parameters.
Note
You can import the exported device parameters to another device.
Import
Click and select the le to import. Click Import to start import conguraon le.
7.5.14 Device Debugging
You can set device debugging parameters.
Steps
1.
Click Maintenance and Security → Maintenance → Device Debugging .
2.
You can set the following parameters.
Enable SSH
DS-K3B411B(L)X Series Swing Barrier User Manual
60
background
To raise network security, disable SSH service. The conguraon is only used to debug the
device for the professionals.
Print Log
You can select a component from drop-down list and click Export to export log.
Capture Network Packet
You can set the Capture Packet Duraon, Capture Packet Size, and click Start Capture to
capture.
7.5.15 Component Status
You can view the main lane and sub lane status.
Main Lane Status
Device Component
You can view the status of the access control board, lane control board, user extended interface
board, and passing mode indicator board.
Peripheral
You can view the status of the RS-485 card reader and tamper input.
Temperature
You can view the pedestal temperature.
Movement
You can view the working status of motor encoder.
Sub Lane Status
Device Component
You can view the status of the lane control board, passing mode indicator board and upper IR
adaptor.
Peripheral
You can view the status of the RS-485 card reader, RS-232 card receiver and tamper input.
Movement
You can view the working status of motor encoder.
Others
Passing Mode
You can view the entrance and exit mode.
IR Detector Status
You can view the status of each pair of the IR beam sensors.
DS-K3B411B(L)X Series Swing Barrier User Manual
61
background
Input and Output Status
You can view the status of the event input/output, alarm input/output and re alarm.
Other Status
You can view the status of the barrier and the keyfob receiving module.
7.5.16 Log Query
You can search and view the device logs.
Go to Maintenance and Security → Maintenance → Log .
Set the major and minor type of the log type. Set the start
me and end me for searching, and
click Search.
The results will be displayed below, which including the No., me, the major type the minor type,
the channel No., the local/remote user
informaon, the remote host IP, etc.
7.5.17
Cercate Management
It helps to manage the server/client cercates and CA cercate.
Note
The funcon is only supported by certain device models.
Create and Install Self-signed Cercate
Steps
1.
Go to Maintenance and Security → Security
Cercate Management .
2.
In the Cercate Files area, select a Cercate Type from the drop-down list.
3.
Click Create.
4.
Input
cercate informaon.
5.
Click OK to save and install the cercate.
The created cercate is displayed in the Cercate Details area.
The cercate will be saved automacally.
6.
Download the cercate and save it to an asking le in the local computer.
7.
Send the asking le to a cercaon authority for signature.
8.
Import the signed
cercate.
1) Select a cercate type in the Import Passwords area, and select a cercate from the local,
and click Install.
2) Select a
cercate type in the Import Communicaon Cercate area, and select a cercate
from the local, and click Install.
DS-K3B411B(L)X Series Swing Barrier User Manual
62
background
Install Other Authorized Cercate
If you already has an authorized cercate (not created by the device), you can import it to the
device directly.
Steps
1.
Go to Maintenance and Security → Security
Cercate Management .
2.
In the Import Passwords and Import Communicaon Cercate areas, select cercate type
and upload
cercate.
3.
Click Install.
Install CA
Cercate
Before You Start
Prepare a CA cercate in advance.
Steps
1.
Go to Maintenance and Security → Security Cercate Management .
2.
Create an ID in the Import CA Cercate area.
Note
The input cercate ID cannot be the same as the exisng ones.
3.
Upload a cercate le from the local.
4.
Click Install.
DS-K3B411B(L)X Series Swing Barrier User Manual
63
background
Chapter 8 Client Soware Conguraon
8.1 Conguraon Flow of Client Soware
Follow the ow diagram below to congure on the client soware.
Figure 8-1 Flow Diagram of Conguraon on Client Soware
8.2 Device Management
The client supports managing access control devices and video intercom devices.
DS-K3B411B(L)X Series Swing Barrier User Manual
64
background
Example
You can control entrance & exit and manage aendance aer adding access control devices to the
client; you can perform video intercom with the indoor staons and door staons.
8.2.1 Add Device
The client provides three device adding modes including by IP/domain, IP segment, and ISUP
protocol. The client also supports imporng mulple devices in a batch when there are large
amount of devices to be added.
Add Online Device
The acve online devices in the same local subnet with the client soware will be displayed on the
Online Device area. You can click Refresh Every 60s to refresh the informaon of the online
devices.
Add Single Online Device
You can add single online device to the client soware.
Steps
1.
Enter the Device Management module.
2.
Oponal: Click on the right of Device Management and select Device.
3.
Click Online Device to show the online device area.
The searched online devices are displayed in the list.
4.
Select an online device from the Online Device area.
Note
For the inacve device, you need to create the password for it before you can add the device
properly. For detailed steps, refer to Acvaon .
5.
Click Add to open the device adding window.
6.
Enter the required informaon.
Name
Enter a descripve name for the device.
Address
The IP address of the device is obtained automacally in this adding mode.
Port
The port number is obtained automacally.
User Name
By default, the user name is admin.
DS-K3B411B(L)X Series Swing Barrier User Manual
65
background
Password
Enter the device password.
Cauon
The password strength of the device can be automacally checked. We highly recommend
you change the password of your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers, lower case leers, numbers,
and special characters) in order to increase the security of your product. And we recommend
you change your password regularly, especially in the high security system, changing the
password monthly or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
7.
Oponal: Check Synchronize Time to synchronize the device me with the PC running the client
aer adding the device to the client.
8.
Oponal: Check Import to Group to create a group by the device name.
Note
You can import all the channels of the device to the corresponding group by default.
9.
Click OK to add the device.
Add
Mulple Online Devices
You can add mulple online devices to the client soware.
Steps
1.
Enter the Device Management module.
2.
Click
on the right of Device Management and select Device.
3.
Click Online Device to show the online device area.
The searched online devices are displayed in the list.
4.
Select
mulple devices.
Note
For the inacve device, you need to create the password for it before you can add the device
properly. For detailed steps, refer to Acvaon .
5.
Click Add to open the device adding window.
6.
Enter the required informaon.
User Name
By default, the user name is admin.
Password
Enter the device password.
DS-K3B411B(L)X Series Swing Barrier User Manual
66
background
Cauon
The password strength of the device can be automacally checked. We highly recommend
you change the password of your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers, lower case leers, numbers,
and special characters) in order to increase the security of your product. And we recommend
you change your password regularly, especially in the high security system, changing the
password monthly or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
7.
Oponal: Check Synchronize Time to synchronize the device me with the PC running the client
aer adding the devices to the client.
8.
Oponal: Check Import to Group to create a group by the device name.
Note
You can import all the channels of the device to the corresponding group by default.
9.
Click OK to add the devices.
Add Device by IP Address or Domain Name
When you know the IP address or domain name of the device to add, you can add devices to the
client by specifying the IP address (or domain name), user name, password, etc.
Steps
1.
Enter Device Management module.
2.
Click Device tab on the top of the right panel.
The added devices are displayed on the right panel.
3.
Click Add to open the Add window, and then select IP/Domain as the adding mode.
4.
Enter the required
informaon.
Name
Create a descripve name for the device. For example, you can use a nickname that can show
the
locaon or feature of the device.
Address
The IP address or domain name of the device.
Port
The devices to add share the same port number. The default value is 8000.
User Name
Enter the device user name. By default, the user name is admin.
Password
Enter the device password.
DS-K3B411B(L)X Series Swing Barrier User Manual
67
background
Cauon
The password strength of the device can be automacally checked. We highly recommend
you change the password of your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers, lower case leers, numbers,
and special characters) in order to increase the security of your product. And we recommend
you change your password regularly, especially in the high security system, changing the
password monthly or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
5.
Oponal: Add the oine devices.
1) Check Add
Oine Device.
2) Enter the required informaon, including the device channel number and alarm input
number.
Note
When the oine device comes online, the soware will connect it automacally.
6.
Check Synchronize Time to synchronize the device me with the PC running the client aer
adding the device to the client.
7.
Oponal: Check Import to Group to create a group by the device name.
8.
Finish adding the device.
-
Click Add to add the device and back to the device list page.
-
Click Add and
Connue to save the sengs and connue to add other device.
9.
Oponal: Perform the following operaon(s).
Remote
Conguraon
Click on Operaon column to set remote conguraon of the
corresponding device.
Note
For detail operaon steps for the remote conguraon, see the user
manual of the device.
Device Status Click on Operaon column to view device status, including cameras,
recording status, signal status, hardware status, etc.
Edit Device
Informaon
Click on Operaon column to edit the device informaon, such as IP
address, user name, and password.
Check Online User Click on Operaon column to check the online users who access the
device, such as user name, user type, user's IP address, and login me.
Refresh Click on Operaon column to get the latest device informaon.
Delete Device Select one or mulple devices and click Delete to delete the selected
device(s) from the client.
DS-K3B411B(L)X Series Swing Barrier User Manual
68
background
Add Devices by IP Segment
If the devices share the same port No., user name and password, and their IP addresses are
sharing an IP segment. You can specify the start IP address and the end IP address, port No., user
name, password, etc of the devices to add them to the client.
Steps
1.
Enter the Device Management module.
2.
Click Device tab on the top of the right panel.
The added devices are displayed on the right panel.
3.
Click Add to open the Add window.
4.
Select IP Segment as the adding mode.
5.
Enter the required
informaon.
Start IP
Enter a start IP address.
End IP
Enter an end IP address in the same network segment with the start IP.
Port
Enter the device port No. The default value is 8000.
User Name
By default, the user name is admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally checked. We highly recommend
you change the password of your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers, lower case leers, numbers,
and special characters) in order to increase the security of your product. And we recommend
you change your password regularly, especially in the high security system, changing the
password monthly or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
6.
Oponal: Add the oine devices.
1) Check Add Oine Device.
2) Enter the required informaon, including the device channel number and alarm input
number.
Note
When the oine device comes online, the soware will connect it automacally.
DS-K3B411B(L)X Series Swing Barrier User Manual
69
background
7.
Check Synchronize Time to synchronize the device me with the PC running the client aer
adding the device to the client.
8.
Oponal: Check Import to Group to create a group by the device name.
9.
Finish adding the device.
-
Click Add to add the device and back to the device list page.
-
Click Add and Connue to save the sengs and connue to add other device.
10.
Oponal: Perform the following operaon(s).
Remote
Conguraon
Click on Operaon column to set remote conguraon of the
corresponding device.
Note
For detail operaon steps for the remote conguraon, see the user
manual of the device.
Device Status Click on Operaon column to view device status, including
cameras, recording status, signal status, hardware status, etc.
Edit Device
Informaon
Click on Operaon column to edit the device informaon, such as
IP address, user name, and password.
Check Online User Click on Operaon column to check the online users who access
the device, such as user name, user type, user's IP address, and
login me.
Refresh Click on Operaon column to get the latest device informaon.
Delete Device Select one or mulple devices and click Delete to delete the
selected device(s) from the client.
Import Devices in a Batch
You can add mulple devices to the client in a batch by entering the device parameters in a pre-
dened CSV le.
Steps
1.
Enter the Device Management module.
2.
Click Device tab on the top of the right panel.
3.
Click Add to open the Add window, and then select Batch Import as the adding mode.
4.
Click Export Template and then save the
pre-dened template (CSV le) on your PC.
5.
Open the exported template le and enter the required informaon of the devices to be added
on the corresponding column.
Note
For detailed descripon of the required elds, refer to the introducons in the template.
DS-K3B411B(L)X Series Swing Barrier User Manual
70
background
Adding Mode
Enter 0 or 1 or 2.
Address
Edit the address of the device.
Port
Enter the device port number. The default port number is 8000.
User Name
Enter the device user name. By default, the user name is admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally checked. We highly recommend
you change the password of your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers, lower case leers, numbers,
and special characters) in order to increase the security of your product. And we recommend
you change your password regularly, especially in the high security system, changing the
password monthly or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
Import to Group
Enter 1 to create a group by the device name. All the channels of the device will be imported
to the corresponding group by default. Enter 0 to disable this
funcon.
6.
Click and select the template le.
7.
Click Add to import the devices.
8.
Oponal: Perform the following operaon(s).
Remote
Conguraon
Click on Operaon column to set remote conguraon of the
corresponding device.
Note
For detail operaon steps for the remote conguraon, see the user
manual of the device.
Device Status Click on Operaon column to view device status, including cameras,
recording status, signal status, hardware status, etc.
Edit Device
Informaon
Click on Operaon column to edit the device informaon, such as IP
address, user name, and password.
Check Online User Click on Operaon column to check the online users who access the
device, such as user name, user type, user's IP address, and login me.
DS-K3B411B(L)X Series Swing Barrier User Manual
71
background
Refresh Click on Operaon column to get the latest device informaon.
Delete Device Select one or mulple devices and click Delete to delete the selected
device(s) from the client.
8.2.2 Reset Device Password
If you forgot the password of the detected online devices, you can reset the device password via
the client.
Steps
1.
Enter Device Management page.
2.
Click Online Device to show the online device area.
All the online devices sharing the same subnet will be displayed in the list.
3.
Select the device from the list and click
on the Operaon column.
4.
Reset the device password.
-
Click Generate to pop up the QR Code window and click Download to save the QR code to
your PC. You can also take a photo of the QR code to save it to your phone. Send the picture
to our technical support.
Note
For the following operaons for reseng the password, contact our technical support.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
8.3 Group Management
The client provides groups to manage the added resources in dierent groups. You can group the
resources into
dierent groups according to the resources' locaons.
Example
For example, on the 1st
oor, there mounted 16 doors, 64 alarm inputs, and 16 alarm outputs. You
can organize these resources into one group (named 1st Floor) for convenient management. You
can control door status, and do some other operaons of the devices aer managing the resources
by groups.
DS-K3B411B(L)X Series Swing Barrier User Manual
72
background
8.3.1 Add Group
You can add group to organize the added device for convenient management.
Steps
1.
Enter the Device Management module.
2.
Click Device Management → Group to enter the group management page.
3.
Create a group.
-
Click Add Group and enter a group name as you want.
-
Click Create Group by Device Name and select an added device to create a new group by the
name of the selected device.
Note
The resources (such as alarm inputs/outputs, access points, etc.) of this device will be
imported to the group by default.
8.3.2 Import Resources to Group
You can import the device resources (such as alarm inputs/outputs, access points, etc.) to the
added group in a batch.
Before You Start
Add a group for managing devices. Refer to
Add Group .
Steps
1.
Enter the Device Management module.
2.
Click Device Management → Group to enter the group management page.
3.
Select a group from the group list and select the resource type as Access Point, Alarm Input,
Alarm Output, etc.
4.
Click Import.
5.
Select the thumbnails/names of the resources in the thumbnail/list view.
Note
You can click or to switch the resource display mode to thumbnail view or to list view.
6.
Click Import to import the selected resources to the group.
8.3.3 Edit Resource Parameters
Aer
imporng the resources to the group, you can edit the resource parameters. For access point,
you can edit the access point name. For alarm input, you can edit the alarm input name. Here we
take access point as an example.
DS-K3B411B(L)X Series Swing Barrier User Manual
73
background
Before You Start
Import the resources to group.
Steps
1.
Enter the Device Management module.
2.
Click Device Management → Group to enter the group management page.
All the added groups are displayed on the
le.
3.
Select a group on the group list and click Access Point.
The access points imported to the group will display.
4.
Click
in the Operaon column to open the Edit Resource window.
5.
Edit the resource name.
6.
Click OK to save the new sengs.
8.3.4 Remove Resources from Group
You can remove the added resources from the group.
Steps
1.
Enter the Device Management module.
2.
Click Device Management → Group to enter the group management page.
All the added groups are displayed on the
le.
3.
Click a group to show the resources added to this group.
4.
Select the resource(s) and click Delete to remove the resource(s) from the group.
8.4 Person Management
You can add person informaon to the system for further operaons such as access control, video
intercom, me and aendance, etc. You can manage the added persons such as issuing cards to
them in a batch,
imporng and exporng person informaon in a batch, etc.
8.4.1 Add
Organizaon
You can add an organizaon and import person informaon to the organizaon for eecve
management of the persons. You can also add a surbodinate organizaon for the added one.
Steps
1.
Enter Person module.
2.
Select a parent organizaon in the le column and click Add in the upper-le corner to add an
organizaon.
3.
Create a name for the added organizaon.
DS-K3B411B(L)X Series Swing Barrier User Manual
74
background
Note
Up to 10 levels of organizaons can be added.
4.
Oponal: Perform the following operaon(s).
Edit Organizaon Hover the mouse on an added organizaon and click to edit its name.
Delete
Organizaon
Hover the mouse on an added organizaon and click to delete it.
Note
The lower-level organizaons will be deleted as well if you delete an
organizaon.
Make sure there is no person added under the organizaon, or the
organizaon cannot be deleted.
Show Persons in
Sub Organizaon
Check Show Persons in Sub Organizaon and select an organizaon to
show persons in its sub organizaons.
8.4.2 Import and Export Person Idenfy Informaon
You can import the informaon and pictures of mulple persons to the client soware in a batch.
Meanwhile, you can also export the person informaon and pictures and save them in your PC.
Import Person
Informaon
You can enter the informaon of mulple persons in a predened template (a CSV le) to import
the
informaon to the client in a batch.
Steps
1.
Enter the Person module.
2.
Select an added organizaon in the list, or click Add in the upper-le corner to add an
organizaon and then select it.
3.
Click Import to open the Import panel.
4.
Select Person Informaon as the imporng mode.
5.
Click Download Template for
Imporng Person to download the template.
6.
Enter the person informaon in the downloaded template.
Note
If the person has mulple cards, separate the card No. with semicolon.
Items with asterisk are required.
By default, the Hire Date is the current date.
7.
Click to select the CSV le with person informaon.
8.
Click Import to start imporng.
DS-K3B411B(L)X Series Swing Barrier User Manual
75
background
Note
If a person No. already exists in the client's database, delete the exisng informaon before
imporng.
You can import informaon of no more than 10,000 persons.
Import Person Pictures
Aer imporng face pictures for the added persons to the client, the persons in the pictures can be
idened by an added face recognion terminal. You can either import person pictures one by
one, or import mulple pictures at a me according to your need.
Before You Start
Be sure to have imported person
informaon to the client beforehand.
Steps
1.
Enter the Person module.
2.
Select an added organizaon in the list, or click Add in the upper-le corner to add an
organizaon and then select it.
3.
Click Import to open the Import panel and check Face.
4.
Oponal: Enable Verify by Device to check whether face recognion device managed in the
client can recognize the face in the photo.
5.
Click
to select a face picture le.
Note
The (folder of) face pictures should be in ZIP format.
Each picture le should be in JPG format and should be no larger than 200 KB.
Each picture le should be named as "Person ID_Name". The Person ID should be the same
with that of the imported person
informaon.
6.
Click Import to start imporng.
The imporng progress and result will be displayed.
Export Person
Informaon
You can export the added persons' informaon to local PC as a CSV le.
Before You Start
Make sure you have added persons to an organizaon.
Steps
1.
Enter the Person module.
2.
Oponal: Select an organizaon in the list.
DS-K3B411B(L)X Series Swing Barrier User Manual
76
background
Note
All persons' informaon will be exported if you do not select any organizaon.
3.
Click Export to open the Export panel and check Person Informaon as the content to export.
4.
Check desired items to export.
5.
Click Export to save the exported CSV le in your PC.
Export Person Pictures
You can export face picture le of the added persons and save in your PC.
Before You Start
Make sure you have added persons and their face pictures to an organizaon.
Steps
1.
Enter the Person module.
2.
Oponal: Select an organizaon in the list.
Note
All persons' face pictures will be exported if you do not select any organizaon.
3.
Click Export to open the Export panel and check Face as the content to export.
4.
Click Export to start
exporng.
Note
The exported le is in ZIP format.
The exported face picture is named as "Person ID_Name_0" ("0" is for a full-frontal face).
8.4.3 Get Person Informaon from Access Control Device
If the added access control device has been congured with person informaon (including person
details,
ngerprint, and issued card informaon), you can get the person informaon from the
device and import them to the client for further operaons.
Steps
Note
If the person name stored in the device is empty, the person name will be lled with the issued
card No. aer imporng to the client.
If the card number or person ID (employee ID) stored on the device already exists in the client
database, the person with this card number or person ID will not be imported to the client.
1.
Enter Person module.
2.
Select an
organizaon to import the persons.
3.
Click Get from Device.
DS-K3B411B(L)X Series Swing Barrier User Manual
77
background
4.
Select the access control device from the drop-down list.
5.
Click Get to start imporng the person informaon to the client.
The person informaon, including person details, person's ngerprint informaon (if
congured), and the linked cards (if congured), will be imported to the selected organizaon.
8.4.4 Issue Cards to Persons in Batch
The client provides a convenient way to issue cards to mulple persons in a batch.
Steps
1.
Enter Person module.
2.
Click Batch Issue Cards.
All the added persons with no card issued will be displayed in the right panel.
3.
Oponal: Enter key words (name or person ID) in the input box to lter the person(s) that need
issuing cards.
4.
Oponal: Click Sengs to set the card issuing parameters. For details, refer to .
5.
Click
Inialize to inialize the card enrollment staon or card reader to make it ready for issuing
cards.
6.
Click the Card No. column and enter the card number.
-
Place the card on the card enrollment staon.
-
Swipe the card on the card reader.
-
Manually enter the card number and press the Enter key.
The person(s) in the list will be issued with card(s).
8.4.5 Report Card Loss
If the person lost his/her card, you can report the card loss so that the card's related access
authorizaon will be inacve.
Steps
1.
Enter Person module.
2.
Select the person you want to report card loss for and click Edit to open the Edit Person window.
3.
In the
Credenal → Card panel, click on the added card to set this card as lost card.
Aer reporng card loss, the access authorizaon of this card will be invalid and inacve. Other
person who gets this card cannot access the doors by swiping this lost card.
4.
Oponal: If the lost card is found, you can click to cancel the loss.
Aer cancelling card loss, the access authorizaon of the person will be valid and acve.
5.
If the lost card is added in one access group and the access group is applied to the device
already,
aer reporng card loss or cancelling card loss, a window will pop up to nofy you to
apply the changes to the device. Aer applying to device, these changes can take eect on the
device.
DS-K3B411B(L)X Series Swing Barrier User Manual
78
background
8.4.6 Set Card Issuing Parameters
The client provides two modes for reading a card's number: via card enrollment staon or via the
card reader of the access control device. If a card enrollment
staon is available, connect it to the
PC running the client by USB interface or COM, and place the card on the card enrollment to read
the card number. If not, you can also swipe the card on the card reader of the added access control
device to get the card number. As a result, before issuing a card to one person, you need to set the
card issuing parameters including the issuing mode and related parameters.
When adding a card to one person, click
Sengs to open the Card Issuing Sengs window.
Local Mode: Issue Card by Card Enrollment Staon
Connect a card enrollment staon to the PC running the client. You can place the card on the card
enrollment
staon to get the card number.
Card Enrollment Staon
Select the model of the connected card enrollment staon
Note
Currently, the supported card enrollment staon models include DS-K1F100-D8, DS-K1F100-M,
DS-K1F100-D8E, and DS-K1F180-D8E.
Card Type
This eld is only available when the model is DS-K1F100-D8E or DS-K1F180-D8E.
Select the card type as EM card or IC card according to the actual card type.
Serial Port
It is only available when the model is DS-K1F100-M.
Select the COM the card enrollment
staon connects to.
Buzzing
Enable or disable the buzzing when the card number is read successfully.
Card No. Type
Select the type of the card number according to actual needs.
M1 Card Encrypon
This eld is only available when the model is DS-K1F100-D8, DS-K1F100-D8E, or DS-K1F180-D8E.
If the card is M1 card, and if you need to enable the M1 Card Encrypon funcon, you should
enable this funcon and select the sector of the card to encrypt.
Remote Mode: Issue Card by Card Reader
Select an access control device added in the client and swipe the card on its card reader to read
the card number.
DS-K3B411B(L)X Series Swing Barrier User Manual
79
background
8.5 Congure Schedule and Template
You can congure the template including holiday and week schedule. Aer seng the template,
you can adopt the congured template to access groups when seng the access groups, so that
the access group will take eect in the me duraons of the template.
Note
For access group sengs, refer to Set Access Group to Assign Access Authorizaon to Persons .
8.5.1 Add Holiday
You can create holidays and set the days in the holidays, including start date, end date, and holiday
duraon in one day.
Steps
Note
You can add up to 64 holidays in the soware system.
1.
Click Access Control → Schedule → Holiday to enter the Holiday page.
2.
Click Add on the le panel.
3.
Create a name for the holiday.
4.
Oponal: Enter the descripons or some nocaons of this holiday in the Remark box.
5.
Add a holiday period to the holiday list and congure the holiday duraon.
Note
Up to 16 holiday periods can be added to one holiday.
1) Click Add in the Holiday List eld.
2) Drag the cursor to draw the me duraon, which means in that duraon of me, the
congured access group is acvated.
Note
Up to 8 me duraons can be set to one holiday period.
3) Oponal: Perform the following operaons to edit the me duraons.
Move the cursor to the me duraon and drag the me duraon on the meline bar to the
desired
posion when the cursor turns to .
Click the me duraon and directly edit the start/end me in the appeared dialog.
Move the cursor to the start or the end of
me duraon and drag to lengthen or shorten
the me duraon when the cursor turns to .
4) Oponal: Select the me duraon(s) that need to be deleted, and then click in the
Operaon column to delete the selected me duraon(s).
5) Oponal: Click in the Operaon column to clear all the me duraon(s) in the me bar.
DS-K3B411B(L)X Series Swing Barrier User Manual
80
background
6) Oponal: Click in the Operaon column to delete this added holiday period from the
holiday list.
6.
Click Save.
8.5.2 Add Template
Template includes week schedule and holiday. You can set week schedule and assign the me
duraon of access authorizaon for dierent person or group. You can also select the added
holiday(s) for the template.
Steps
Note
You can add up to 255 templates in the soware system.
1.
Click Access Control → Schedule → Template to enter the Template page.
Note
There are two default templates: All-Day Authorized and All-Day Denied, and they cannot be
edited or deleted.
All-Day Authorized
The access authorizaon is valid in each day of the week and it has no holiday.
All-Day Denied
The access authorizaon is invalid in each day of the week and it has no holiday.
2.
Click Add on the le panel to create a new template.
3.
Create a name for the template.
4.
Enter the
descripons or some nocaon of this template in the Remark box.
5.
Edit the week schedule to apply it to the template.
1) Click Week Schedule tab on the lower panel.
2) Select a day of the week and draw
me duraon(s) on the meline bar.
Note
Up to 8 me duraon(s) can be set for each day in the week schedule.
3) Oponal: Perform the following operaons to edit the me duraons.
Move the cursor to the
me duraon and drag the me duraon on the meline bar to the
desired posion when the cursor turns to .
Click the me duraon and directly edit the start/end me in the appeared dialog.
Move the cursor to the start or the end of
me duraon and drag to lengthen or shorten
the me duraon when the cursor turns to .
4) Repeat the two steps above to draw more
me duraons on the other days of the week.
6.
Add a holiday to apply it to the template.
DS-K3B411B(L)X Series Swing Barrier User Manual
81
background
Note
Up to 4 holidays can be added to one template.
1) Click Holiday tab.
2) Select a holiday in the le list and it will be added to the selected list on the right panel.
3) Oponal: Click Add to add a new holiday.
Note
For details about adding a holiday, refer to Add Holiday .
4) Oponal: Select a selected holiday in the right list and click to remove the selected one, or
click Clear to clear all the selected holiday(s) in the right list.
7.
Click Save to save the
sengs and nish adding the template.
8.6 Set Access Group to Assign Access
Authorizaon to Persons
Aer adding the person and conguring the person's credenals, you can create the access groups
to dene which person(s) can get access to which door(s) and then apply the access group to the
access control device to take
eect.
Before You Start
Add person to the client.
Add access control device to the client and group access points. For details, refer to Group
Management .
Add template.
Steps
When the access group sengs are changed, you need to apply the access groups to the devices
again to take
eect. The access group changes include changes of template, access group sengs,
person's access group sengs, and related person details (including card number, ngerprint, face
picture, linkage between card number and
ngerprint, linkage between card number and
ngerprint, card password, card eecve period, etc).
1.
Click Access Control
Authorizaon → Access Group to enter the Access Group interface.
2.
Click Add to open the Add window.
3.
In the Name text
eld, create a name for the access group as you want.
4.
Select a template for the access group.
Note
You should congure the template before access group sengs. Refer to Congure Schedule
and Template for details.
5.
In the le list of the Select Person eld, select person(s) to assign access authority.
6.
In the
le list of the Select Access Point eld, select door(s), door staon(s) or oor(s) for the
selected persons to access.
DS-K3B411B(L)X Series Swing Barrier User Manual
82
background
7.
Click Save.
You can view the selected person(s) and the selected access point(s) on the right side of the
interface.
Figure 8-2 Display the Selected Person(s) and Access Point(s)
8.
Aer adding the access groups, you need to apply them to the access control device to take
eect.
1) Select the access group(s) to apply to the access control device.
2) Click Apply All to Devices start applying all the selected access group(s) to the access control
device or door
staon.
3) Click Apply All to Devices or Apply Changes to Devices.
Apply All to Devices
This
operaon will clear all the existed access groups of the selected devices and then
apply the new access group to the device.
Apply Changes to Devices
This operaon will not clear the existed access groups of the selected devices and only
apply the changed part of the selected access group(s) to the device(s).
4) View the applying status in the Status column or click Applying Status to view all the applied
access group(s).
Note
You can check Display Failure Only to lter the applying results.
DS-K3B411B(L)X Series Swing Barrier User Manual
83
background
The selected persons in the applied access groups will have the authorizaon to enter/exit the
selected doors/door staons with their linked card(s) or ngerprints.
9.
Oponal: Click to edit the access group if necessary.
Note
If you change the persons' access informaon or other related informaon, you will view the
prompt Access Group to Be Applied on the right corner of the client.
You can click the prompt to apply the changed data to the device. You can select either Apply
Now or Apply Later.
Figure 8-3 Data Synchronizaon
8.7
Congure Advanced Funcons
You can congure the advanced funcons of access control to meet some special requirements in
dierent scene.
Note
For the card related funcons(the type of access control card), only the card(s) with access group
applied will be listed when adding cards.
The advanced funcons should be supported by the device.
Hover the cursor on the Advanced
Funcon, and then Click to customize the advanced
funcon(s) to be displayed.
8.7.1 Congure Device Parameters
Aer adding the access control device, you can congure the parameters of access control device
(access controller), access control points (door or
oor), alarm inputs, alarm outputs, card readers
and lane controller.
DS-K3B411B(L)X Series Swing Barrier User Manual
84
background
Congure Parameters for Access Control Device
Aer adding the access control device, you can congure its parameters.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter .
Note
If you can nd Device Parameter in the Advanced Funcon list, Hover the cursor on the
Advanced Funcon, and then Click to select the Device Parameter to be displayed.
2.
Select an access device to show its parameters on the right page.
3.
Turn the switch to ON to enable the corresponding
funcons.
Note
The displayed parameters may vary for dierent access control devices.
RS-485 Communicaon Redundancy
You should enable this funcon if you wire the RS-485 card reader to the access control
device redundantly.
Enable NFC
If enable the funcon, the device can recognize the NFC card. You can present NFC card on
the device.
Enable M1 Card
If enable the
funcon, the device can recognize the M1 card. You can present M1 card on the
device.
Enable EM Card
If enable the funcon, the device can recognize the EM card. You can present EM card on the
device.
Enable CPU Card
Reserved. If enable the
funcon, the device can recognize the CPU card. You can present CPU
card on the device.
Enable ID Card
Reserved. If enable the funcon, the device can recognize the ID card. You can present ID
card on the device.
4.
Click OK.
5.
Oponal: Click Copy to, and then select the access control device(s) to copy the parameters in
the page to the selected device(s).
DS-K3B411B(L)X Series Swing Barrier User Manual
85
background
Congure Parameters for Door
Aer adding the access control device, you can congure its access point door parameters.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter .
2.
Select an access control device on the
le panel, and then click to show the doors or oors of
the selected device.
3.
Select a door or
oor to show its parameters on the right page.
4.
Edit the door or oor parameters.
Note
s
The displayed parameters may vary for dierent access control devices.
Name
Edit the card reader name as desired.
Exit Buon Type
You can set the exit buon as remaining closed or remaining open. Usually, it is remaining
open.
Open Duraon
Aer swiping the normal card and relay acon, the me for locking the door starts working.
Door Le Open Timeout Alarm
The alarm can be triggered if the door has not been closed in a congured me period. If it is
set as 0, no alarm will be triggered.
Super Password
The
specic person can open the door by inpung the super password.
5.
Some of the following parameters are not listed in the Basic Informaon page, click Advanced to
edit the parameters.
Duress Code
The door can open by
inpung the duress code when there is duress. At the same me, the
client can report the duress event.
Dismiss Code
Create a dismiss code which can be used to stop the buzzer of the card reader (by entering
the dismiss code on the keypad).
DS-K3B411B(L)X Series Swing Barrier User Manual
86
background
Note
The duress code, super code, and dismiss code should be dierent.
The duress code, super password, and the dismiss code should be dierent from the
authencaon password.
The length of duress code, super password, and the dismiss code is according the device,
usually it should contains 4 to 8 digits.
6.
Click OK.
7.
Oponal: Click Copy to , and then select the door(s) to copy the parameters in the page to the
selected doors(s).
Note
The door's status duraon sengs will be copied to the selected door(s) as well.
Congure Parameters for Card Reader
Aer adding the access control device, you can congure its card reader parameters.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter .
2.
In the device list on the le, click to expand the door, select a card reader and you can edit the
card reader's parameters on the right.
3.
Edit the card reader basic parameters in the Basic
Informaon page.
Note
The displayed parameters may vary for dierent access control devices. There are part of
parameters listed as follows. Refer to the user manual of the device for more details.
Name
Edit the card reader name as desired.
Minimum Card Swiping Interval
If the interval between card swiping of the same card is less than the set value, the card
swiping is invalid. You can set it as 0 to 255.
Alarm of Max. Failed
Aempts
Enable to report alarm when the card reading aempts reach the set value.
Card Reader Type/Card Reader Descripon
Get card reader type and descripon. They are read-only.
4.
Oponal: Some of the following parameters are not listed in the Basic Informaon page, click
Advanced to edit the parameters.
Enable Card Reader
DS-K3B411B(L)X Series Swing Barrier User Manual
87
background
If enabling the funcon, user can present card on the card reader. If disabling the funcon,
the card reader for entrance cannot be used.
OK LED Polarity/Error LED Polarity/Buzzer Polarity
Set OK LED Polarity/Error LED Polarity/Buzzer LED Polarity of main board according to the
card reader parameters. Generally, adopts the default sengs.
Buzzing Time
Set the card reader buzzing me. The available me ranges from 0 to 5,999s. 0 represents
connuous buzzing.
Max. Interval When Entering PWD
When you inpung the password on the card reader, if the interval between pressing two
digits is larger than the set value, the digits you pressed before will be cleared automacally.
Tampering Detecon
Enable the an-tamper detecon for the card reader.
Communicate with Controller Every
When the access control device cannot connect with the card reader for longer than the set
me, the card reader will turn oine automacally.
Fingerprint Recognion Level
Select the ngerprint recognion level in the drop-down list.
5.
Click OK.
6.
Oponal: Click Copy to, and then select the card reader(s) to copy the parameters in the page to
the selected card reader(s).
Congure
Parameters for Alarm Output
Aer adding the access control device, if the device links to alarm outputs, you can congure the
parameters.
Before You Start
Add access control device to the client, and make sure the device supports alarm output.
Steps
1.
Click Access Control → Advanced
Funcon → Device Parameter to enter access control
parameter conguraon page.
2.
In the device list on the
le, click to expand the door, select an alarm input and you can edit
the alarm input's parameters on the right.
3.
Set the alarm output parameters.
Name
Edit the card reader name as desired.
Alarm Output
Acve Time
How long the alarm output will last aer triggered.
DS-K3B411B(L)X Series Swing Barrier User Manual
88
background
4.
Click OK.
5.
Oponal: Set the switch on the upper right corner to ON to trigger the alarm output.
Congure Parameters for Lane Controller
Aer adding the lane controller to the client, you can congure its parameters for passing through
the lane.
Steps
1.
Click Access Control → Advanced
Funcon → Device Parameter to enter Parameter Sengs
page.
2.
In the device list on the le, select a lane controller and you can edit the lane controller's
parameters on the right.
3.
Edit the parameters.
Passing Mode
Select the controller which will control the barrier status of the device.
Note
You can select either According to Device's Passing Mode or According to Door's Schedule
Sengs.
If you select According to Device's Passing Mode, the device will follow the lane
controller's passing mode, which can be
congured in remote control sengs page, to
control the barrier.
If you select According to Door's Schedule
Sengs, the device will follow the sengs of
the soware to control the barrier.
Free Passing Authencaon
If you enable this funcon, when both entrance and exit's barrier mode is Remain Open, the
pedestrians should
authencate each me passing through the lane. Or an alarm will be
triggered.
Opening/Closing Door Speed
Set the barrier's opening and closing speed. You can select from 1 to 10. The greater the
value, the faster the speed.
Note
The recommended value is 6.
Audible Prompt Duraon
Set how long the audio will last, which is played when an alarm is triggered .
Note
0 refers to the alarm audio will be played unl the alarm is ended.
DS-K3B411B(L)X Series Swing Barrier User Manual
89
background
Temperature Unit
Select the temperature unit that displayed in the device status.
4.
Click OK.
8.7.2 Congure Device Parameters
Aer adding the access control device, you can set its parameters such as network parameters.
Set RS-485 Parameters
You can set the access control device's RS-485 parameters including the baud rate, data bit, the
stop bit, parity type, ow control type, communicaon mode, work mode, and connecon mode.
Steps
Note
The RS-485 Sengs should be supported by the device.
1.
Enter the Access Control module.
2.
On the navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and click RS-485 to enter the RS-485
Sengs
page.
4.
Select the serial port number from the drop-down list to set the RS-485 parameters.
5.
Set the serial number, external device,
authencaon center, baud rate, data bit, stop bit, parity
type,
ow control type, communicaon mode, and working mode in the drop-down list.
6.
Click Save.
The
congured parameters will be applied to the device automacally.
When you change the working mode or connecon mode, the device will reboot
automacally.
Enable M1 Card
Encrypon
M1 card encrypon can improve the security level of authencaon.
Steps
Note
The funcon should be supported by the access control device and the card reader.
1.
Enter the Access Control module.
2.
On the
navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and click M1 Card Encrypon Vericaon to
enter the M1 Card Encrypon Vericaon page.
DS-K3B411B(L)X Series Swing Barrier User Manual
90
background
4.
Set the switch to on to enable the M1 card encrypon funcon.
5.
Set the sector ID.
Note
The sector ID ranges from 1 to 100.
By default, Sector 13 is encrypted. It is recommended to encrypt sector 13.
6.
Click Save to save the sengs.
8.8 Door Control
In Monitoring module, you can view the real-me status of the doors managed by the added
access control device. You can also control the doors such as open/close the door, or remain the
door open/closed via the client remotely. The
real-me access event are displayed in this module.
You can view the access details and person details.
Note
For the user with door control permission, the user can enter the Monitoring module and control
the door. Or the icons used for control will not show. For seng the user permission, refer to
Person Management .
8.8.1 Control Door Status
You can control the status for a single door, including opening door, closing door, remaining the
door open, and remaining the door closed.
Steps
1.
Click Monitoring to enter the status monitoring page.
2.
Select an access point group on the upper-right corner.
Note
For managing the access point group, refer to Group Management in the user manual of the
client soware.
The doors in the selected access control group will display.
3.
Click a door icon to select a door, or press Ctrl and select
mulple doors.
4.
Click the following buons to control the door.
Open Door
When the door is locked, unlock it and it will be open for once.
Aer the open duraon, the
door will be closed and locked again automacally.
Close Door
DS-K3B411B(L)X Series Swing Barrier User Manual
91
background
When the door is unlocked, lock it and it will be closed. The person who has the access
authorizaon can access the door with credenals.
Remain Open
The door will be unlocked (no maer closed or open). All the persons can access the door
with no credenals required.
Remain Closed
The door will be closed and locked. No person can access the door even if he/she has the
authorized
credenals, except the super users.
Capture
Capture a picture manually.
Note
The Capture buon is available when the device supports capture funcon. The picture is
saved in the PC running the client. For seng the saving path, refer to Set File Saving Path in
the user manual of the client soware.
Result
The icon of the doors will change in real-me according to the operaon if the operaon is
succeeded.
8.8.2 Check Real-Time Access Records
The access records will display in real me, including card swiping records, face recognions
records, ngerprint comparison records, etc. You can view the person informaon and view the
picture captured during access.
Steps
1.
Click Monitoring and select a group from the drop-down list on the upper-right corner.
The access records triggered at the doors in the selected group will display in real
me. You can
view the details of the records, including card No., person name, organizaon, event me, etc.
2.
Oponal: Check the event type and event status so that these events will show in the list if the
events are detected. The events of unchecked type or status will not be displayed in the list.
3.
Oponal: Check Show Latest Event and the latest access record will be selected and displayed at
the top of the record list.
4.
Oponal: Click the event to view the accessed person details, including person pictures
(captured picture and
prole), person No., person name, organizaon, phone, contact address,
etc.
Note
You can double click the captured picture to enlarge it to view the details.
5.
Oponal: Right click on the column name of the access event table to show or hide the column
according to actual needs.
DS-K3B411B(L)X Series Swing Barrier User Manual
92
background
Appendix A. DIP Switch
A.1 DIP Switch Descripon
The DIP switch is on the access control board. No.1 and No 2 is from the low bit to the high bit.
Figure A-1 DIP Switch
When the switch is towards ON, it means the switch is enabled, otherwise, the switch is o.
A.2 DIP Switch Corresponded
Funcons
Note
Aer seng the DIP switch, you should reboot the device, or the funcon cannot take eect.
The 2-bit DIP switch corresponded funcons on the access control board are as follows:
Bit
Device Mode Funcon Decimal Value DIP Switch
Address Diagram
1 Work Mode Normal Mode 0
Study Mode 1
2 Keyfob Paring
Mode
Disable Keyfob
Paring Mode
0
Enable Keyfob
Paring Mode
1
DS-K3B411B(L)X Series Swing Barrier User Manual
93
background
Appendix B. Buon Conguraon Descripon
Refer to the table below for device conguraon via buon on the main lane control board.
Level-1 Conguraon
No.
Descripon Level-1 Conguraon
No. and Funcons
Notes
1 Study Mode 1-Exit Study Mode/
Normal Mode
2-Study Mode
Note
By default, 1 will be
displayed on the
display screen.
If the device is
equipped with access
control board, you can
only set via DIP switch.
2 keyfob Pairing Mode 1-Normal Mode
2-Pairing Mode
Note
By default, 1 will be
displayed on the
display screen.
If the device is
equipped with access
control board, you can
only set via DIP switch.
3 Passing Mode 1-Both sides under
control
Note
By default, 1 will be
displayed on the
display screen.
2-Entrance under
control; exit prohibited
3-Entrance under
control; exit on
inducve mode
4-Both sides on
inducve mode
DS-K3B411B(L)X Series Swing Barrier User Manual
94
background
Level-1 Conguraon
No.
Descripon Level-1 Conguraon
No. and Funcons
Notes
5-Entrance on
inducve mode; exit
under control
6-Entrance on
inducve mode; exit
prohibited
7-Both sides prohibited
8-Entrance prohibited;
exit under control
9-Entrance prohibited;
exit on
inducve mode
10-Entrance under
control; exit remaining
open
11-Entrance under
control; exit on free
mode
12-Entrance on
inducve mode; exit
remaining open
13-Entrance on
inducve mode; exit
on free mode
14-Entrance
prohibited; exit
remaining open
15-Entrance
prohibited; exit on free
mode
16-Entrance remaining
open; exit under
control
17-Entrance remaining
open; exit on
inducve
mode
DS-K3B411B(L)X Series Swing Barrier User Manual
95
background
Level-1 Conguraon
No.
Descripon Level-1 Conguraon
No. and Funcons
Notes
18-Entrance remaining
open; exit remaining
open
19-Entrance remaining
open; exit on free
mode
20-Entrance remaining
open; exit prohibited
21-Entrance on free
mode; exit under
control
22-Entrance on free
mode; exit on
inducve mode
23-Entrance on free
mode; exit remaining
open
24-Entrance on free
mode; exit on free
mode
25-Entrance on free
mode; exit prohibited
4
Memory Mode 1-Disable
2-Enable
Note
By default, 2 will be
displayed on the
display screen.
5 keyfob Remote Control 1-one to one
2-one to mulple
Note
By default, 1 will be
displayed on the
display screen.
DS-K3B411B(L)X Series Swing Barrier User Manual
96
background
Level-1 Conguraon
No.
Descripon Level-1 Conguraon
No. and Funcons
Notes
6 Barrier Opening Speed 1-1, 2-2, …10-10
Note
By default, 5 will be
displayed on the
display screen.
7 Barrier Closing Speed 1-1, 2-2, …10-10
Note
By default, 5 will be
displayed on the
display screen.
8 Card Reading on the
Alarm Area
1-Do not open
2-Open
Note
By default, 2 will be
displayed on the
display screen.
9 Barrier Opening
Duraon (Entrance)
5-5s6-6s7-7s, ..., 60-
60s
Note
By default, 5 will be
displayed on the
display screen.
10 Barrier Opening
Duraon (Exit)
5-5s6-6s7-7s, ..., 60-
60s
Note
By default, 5 will be
displayed on the
display screen.
11 IR Sensing Duraon 0-0s1-1s2-2s,..., 25-
25s
DS-K3B411B(L)X Series Swing Barrier User Manual
97
background
Level-1 Conguraon
No.
Descripon Level-1 Conguraon
No. and Funcons
Notes
Note
By default, 0 will be
displayed on the
display screen.
12 Intrusion Duraon 0-0s1-1s2-2s,..., 20-
20s
Note
By default, 0 will be
displayed on the
display screen.
13 Overstay Duraon 0-0s1-1s2-2s,..., 20-
20s
Note
By default, 0 will be
displayed on the
display screen.
14 Delay Time for Barrier
Closing
0-0s1-1s2-2s3-
3s4-4s5-5s
Note
By default, 0 will be
displayed on the
display screen.
15 Control Mode 1-Buon Conguraon
2-DIP Switch on Access
Control Board
Note
By default, 1 will be
displayed on the
display screen.
18 Lane Number 1-Dual Lanes Unable to change
DS-K3B411B(L)X Series Swing Barrier User Manual
98
background
Level-1 Conguraon
No.
Descripon Level-1 Conguraon
No. and Funcons
Notes
2-Single Lane
Note
By default, 1 will be
displayed on the
display screen.
19 Motor Rotaon 1-Clockwise
2-Anclockwise
Note
By default, 1 will be
displayed on the
display screen.
Unable to change
21 Volume 1-02-13-24-3
5-4
Note
By default, 2 will be
displayed on the
display screen.
The device will be
muted when set to "1".
22 Authencated Passing 1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
Unable to change via
buon
23 Invalid Card No. 1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
Unable to change via
buon
DS-K3B411B(L)X Series Swing Barrier User Manual
99
background
Level-1 Conguraon
No.
Descripon Level-1 Conguraon
No. and Funcons
Notes
24 Fingerprint Unmatched 1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
Unable to change via
buon
25 Climbing over Barrier 1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
26 Reverse Passing 1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
27 Exceeding Passing
Duraon
1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
28 Intrusion Alarm 1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
DS-K3B411B(L)X Series Swing Barrier User Manual
100
background
Level-1 Conguraon
No.
Descripon Level-1 Conguraon
No. and Funcons
Notes
29 Forced Passing 1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
Unable to change via
buon
30 Tailgang Alarm 1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
31 Unauthorized Passing 1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
Unable to change via
buon
32 Exceeding
Authencaon
Duraon
1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
Unable to change via
buon
33 Failed Authencaon 1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
Unable to change via
buon
DS-K3B411B(L)X Series Swing Barrier User Manual
101
background
Level-1 Conguraon
No.
Descripon Level-1 Conguraon
No. and Funcons
Notes
34 Expired Credenal 1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
Unable to change via
buon
35 Overstaying Alarm 1-Disable
2-Enable
Note
By default, 1 will be
displayed on the
display screen.
36 Barrier Material 1-Acrylic
2-Stainless Steel
3-Glass
37 Barrier Length 1-550
2-600
3-650
4-700
5-750
6-800
7-850
8-900
9-950
10-1000
11-1100
12-1200
13-1300
14-1400
DS-K3B411B(L)X Series Swing Barrier User Manual
102
background
Level-1 Conguraon
No.
Descripon Level-1 Conguraon
No. and Funcons
Notes
Note
By default, 8 will be
displayed on the
display screen.
38 Motor Inspecon 1-Disable
2-Enable on Main Lane
3-Enable on Sub Lane
Note
By default, 1 will be
displayed on the
display screen.
39 Brightness of Light 0-01-12-2, … , 10-
10
Note
By default, 3 will be
displayed on the
display screen.
The higher the value is,
the brighter the light
will be.
40 Self-check Voice
Prompt
1-Disable
2-Enable
Note
By default, 2 will be
displayed on the
display screen.
41 Study Mode Voice
Prompt
1-Disable
2-Enable
Note
By default, 2 will be
displayed on the
display screen.
DS-K3B411B(L)X Series Swing Barrier User Manual
103
background
Level-1 Conguraon
No.
Descripon Level-1 Conguraon
No. and Funcons
Notes
42 IR Detector Quanty 4-46-68-8,
Note
By default, 4 will be
displayed on the
display screen.
Unable to change via
buon
43 Applicaon Mode 1-Wind-proof
2-Indoor
By default, 1 will be
displayed on the
display screen.
44 Barrier Recover
Duraon
1-Normal Speed
2-Fast Recover
By default, 1 will be
displayed on the
display screen.
45 Brake 1-Disable
2-Barrier Posion
Excepon
3-Intrusion
By default, 2 will be
displayed on the
display screen.
46 Brake Angle 1-5°
2-10°
3-15°
By default, 1 will be
displayed on the
display screen.
47 IR Sensing 1-Single Triggered
2-Triggered
Simultaneously
DS-K3B411B(L)X Series Swing Barrier User Manual
104
background
Level-1 Conguraon
No.
Descripon Level-1 Conguraon
No. and Funcons
Notes
By default, 1 will be
displayed on the
display screen.
48 Fan 1-Disabled
2-Enabled
By default, 2 will be
displayed on the
display screen.
49 Barrier Height 1-700
2-1200
3-1400
4-1600
5-1800
By default, 5 will be
displayed on the
display screen.
Unable to change via
buon
99 Restore to Default 1- Default
2- Start
Note
By default, 1 will be
displayed on the
display screen.
DS-K3B411B(L)X Series Swing Barrier User Manual
105
background
Appendix C. Event and Alarm Type
Event Alarm Type
Tailgang Visual and Audible
Reverse Passing Visual and Audible
Force Accessing None
Climb over Barrier Visual and Audible
Overstay Visual and Audible
Passing Timeout None
Intrusion Visual and Audible
Barrier Obstructed None
DS-K3B411B(L)X Series Swing Barrier User Manual
106
background
Appendix D. Table of Audio Index Related Content
Note
If the device is not equipped with access control board, the loudspeaker shall be connected to
the main extended interface board.
If the device is equipped with access control board, the loudspeaker shall be connected to the
access control board. You can set custom
broadcasng context via web.
Content
Climbing over the barrier.
Reverse passing.
Passing meout.
Intrusion.
Tailgang.
Overstay.
DS-K3B411B(L)X Series Swing Barrier User Manual
107
background
Appendix E. Error Code Descripon
The swing barrier will display the error code on the seven-segment display if error occurred. Refer
to the table below to
nd the descripon of each number.
Error Reason Code Error Reason Code
The First IR Beam Triggered 01 IR Adapter Board Oine 51
The Second IR Beam Triggered 02 Interconnecng Excepon 53
The Third IR Beam Triggered 03 Not Studying 54
The Fourth IR Beam Triggered 04 Obstrucon 55
The Fih IR Beam Triggered 05 Exceeding Studying Range 56
The Sixth IR Beam Triggered 06 Encoder Excepon 57
Authencaon Indicator Board
(Entrance) Oine
49 Motor Excepon 58
Authencaon Indicator Board
(Exit) Oine
50 Extended Interface Board
Oine (If the board is not
installed, the error code of "49"
will appear but the device
funcons normally)
59
DS-K3B411B(L)X Series Swing Barrier User Manual
108
background
Appendix F. Communicaon Matrix and Device
Command
Communicaon Matrix
Scan the following QR code to get the device communicaon matrix.
Note that the matrix contains all
communicaon ports of Hikvision access control and video
intercom devices.
Figure F-1 QR Code of Communicaon Matrix
Device Command
Scan the following QR code to get the device common serial port commands.
Note that the command list contains all commonly used serial ports commands for all Hikvision
access control and video intercom devices.
Figure F-2 Device Command
DS-K3B411B(L)X Series Swing Barrier User Manual
109
background
UD31743B-A

Specifications

Hikvision DS-K3B411BX Questions and Answers
