Hikvision DS-K3B802BX Ultra Swing Barriers User Manual

Swing Barrier

User Manual

Legal Informaon

About this Document

●

This Document includes instrucons for using and managing the Product. Pictures, charts,

images and all other

informaon hereinaer are for descripon and explanaon only.

●

The

informaon contained in the Document is subject to change, without noce, due to

rmware updates or other reasons. Please nd the latest version of the Document at the

Hikvision website ( hps://www.hikvision.com ). Unless otherwise agreed, Hangzhou Hikvision

Digital Technology Co., Ltd. or its aliates (hereinaer referred to as "Hikvision") makes no

warranes, express or implied.

●

Please use the Document with the guidance and assistance of professionals trained in

supporng the Product.

About this Product

●

This product can only enjoy the aer-sales service support in the country or region where the

purchase is made.

●

If the product you choose is a video product, please scan the following QR code to obtain the

"Iniaves on the Use of Video Products", and read it carefully.

Acknowledgment of Intellectual Property Rights

●

Hikvision owns the copyrights and/or patents related to the technology embodied in the

Products described in this Document, which may include licenses obtained from third pares.

●

Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part

of this Document may be excerpted, copied, translated, or modied in whole or in part by any

means without

wrien permission.

●

and other Hikvision's trademarks and logos are the properes of Hikvision in

various

jurisdicons.

●

Other trademarks and logos menoned are the properes of their respecve owners.

LEGAL DISCLAIMER

●

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS DOCUMENT AND THE

PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS

IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR

Swing Barrier User Manual

IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR

FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.

IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,

INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF

BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR

LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING

NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE

PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR

LOSS.

●

YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY

RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,

PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,

VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE

TIMELY TECHNICAL SUPPORT IF REQUIRED.

●

YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE

SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.

ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT

INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF

PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY

RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE

DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR

PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT

RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF

HUMAN RIGHTS ABUSES.

●

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE

LATTER PREVAILS.

Data

Protecon

●

To protect data, the development of Hikvision Products incorporates privacy by design

principles. For example, for Products with facial

recognion features, biometrics data is stored in

your Products with encrypon method; for ngerprint Products, only ngerprint template will be

saved, which is impossible to reconstruct a

ngerprint image.

●

As a data controller/processor, you may process personal data, including collecon, storage, use,

processing, disclosure,

deleon, etc. You are advised to pay aenon to and comply with

applicable laws and regulaons related to the protecon of personal data, including without

limitaon, conducng security controls to safeguard personal data, such as, implemenng

reasonable administrave and physical security controls, conduct periodic reviews and the

assessments of the

eecveness of your security controls.

Swing Barrier User Manual

Regulatory Informaon

FCC Informaon

Please take aenon that changes or modicaon not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

FCC compliance: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable

protecon against harmful interference in a residenal installaon. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance

with the

instrucons, may cause harmful interference to radio communicaons. However, there is

no guarantee that interference will not occur in a parcular installaon. If this equipment does

cause harmful interference to radio or television

recepon, which can be determined by turning

the equipment o and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the

separaon between the equipment and receiver.

—Connect the equipment into an outlet on a circuit

dierent from that to which the receiver is

connected.

—Consult the dealer or an experienced radio/TV technician for help

This equipment should be installed and operated with a minimum distance 20cm between the

radiator and your body.

FCC

Condions

This device complies with part 15 of the FCC Rules. Operaon is subject to the following two

condions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired

operaon.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE"

and comply therefore with the applicable harmonized European standards listed

Swing Barrier User Manual

iii

under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve

2011/65/EU

2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed

of as unsorted municipal waste in the European Union. For proper recycling, return

this product to your local supplier upon the purchase of equivalent new equipment,

or dispose of it at designated

collecon points. For more informaon see:

www.recyclethis.info

2006/66/EC (baery direcve): This product contains a baery that cannot be

disposed of as unsorted municipal waste in the European Union. See the product

documentaon for specic baery informaon. The baery is marked with this

symbol, which may include

leering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the

baery to your supplier or to a designated

collecon point. For more informaon see:www.recyclethis.info

Swing Barrier User Manual

Safety Instrucon

These instrucons are intended to ensure that user can use the product correctly to avoid danger

or property loss.

The

precauon measure is divided into Dangers and Cauons:

Dangers: Neglecng any of the warnings may cause serious injury or death.

Cauons: Neglecng any of the cauons may cause injury or equipment damage.

Dangers: Follow these safeguards to prevent

serious injury or death.

Cauons: Follow these precauons to prevent

potenal injury or material damage.

Danger:

●

In the use of the product, you must be in strict compliance with the electrical safety regulaons

of the naon and region.

●

The equipment must be connected to an earthed mains socket-outlet.

●

Shock hazard! Disconnect all power sources before maintenance.

●

Do not touch the bare metal contacts of the inlets

aer the circuit breaker is turned o.

Electricity sll exists.

●

indicates hazardous live and the external wiring connected to the terminals requires

installaon by an instructed person.

●

Keep body parts away from fan blades. Disconnect the power source during servicing.

●

Keep body parts away from motors. Disconnect the power source during servicing.

●

To prevent possible hearing damage, do not listen at high volume levels for long periods.

●

All the electronic

operaon should be strictly compliance with the electrical safety regulaons,

re

prevenon regulaons and other related regulaons in your local region.

●

Do not connect several devices to one power adapter as adapter overload may cause over-heat

re hazard.

●

Please make sure that the power has been disconnected before you wire, install or dismantle the

device.

If the top caps should be open and the device should be powered on for maintenance, make

sure:

1. Power

o the fan to prevent the operator from geng injured accidentally.

2. Do not touch bare high-voltage components.

3. Make sure the switch’s wiring sequence is correct

aer maintenance.

●

Please make sure that the power has been disconnected before you wire, install or dismantle the

device.

●

When the product is installed on wall or ceiling, the device shall be

rmly xed.

●

If smoke, odors or noise rise from the device, turn

o the power at once and unplug the power

cable, and then please contact the service center.

Swing Barrier User Manual

●

Do not ingest baery, Chemical Burn Hazard.

This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it

can cause severe internal burns in just 2 hours and can lead to death.

Keep new and used

baeries away from children. If the baery compartment does not close

securely, stop using the product and keep it away from children. If you think

baeries might have

been swallowed or placed inside any part of the body, seek immediate medical

aenon.

●

If the product does not work properly, please contact your dealer or the nearest service center.

Never aempt to disassemble the device yourself. (We shall not assume any responsibility for

problems caused by unauthorized repair or maintenance.)

Cauons:

●

The equipment shall not be exposed to dripping or splashing and that no objects lled with

liquids, such as vases, shall be placed on the equipment.

●

Ensure correct wiring of the terminals for connecon to an AC mains supply.

●

The equipment has been designed, when required,

modied for connecon to an IT power

distribuon system.

●

+ idenes the posive terminal(s) of equipment which is used with, or generates direct current.

+ idenes the negave terminal(s) of equipment which is used with, or generates direct

current.

●

No naked

ame sources, such as lighted candles, should be placed on the equipment.

●

This equipment is suitable for mounng on concrete or other non-combusble surface only.

●

Install the equipment according to the instrucons in this manual.

●

To prevent injury, this equipment must be securely

aached to the oor/wall in accordance with

the installaon instrucons.

●

Stainless steel may be corroded in some circumstances. You need to clean and care the device by

using the stainless steel cleaner. It is suggested to clean the device every month.

●

Do not drop the device or subject it to physical shock, and do not expose it to high

electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places

subject to shock (ignorance can cause equipment damage).

●

Do not place the device in extremely hot (refer to the

specicaon of the device for the detailed

operang temperature), cold, dusty or damp locaons, and do not expose it to high

electromagnec radiaon.

●

The device cover for indoor use shall be kept from rain and moisture.

●

Exposing the equipment to direct sun light, low

venlaon or heat source such as heater or

radiator is forbidden (ignorance can cause re danger).

●

Do not aim the device at the sun or extra bright places. A blooming or smear may occur

otherwise (which is not a

malfuncon however), and aecng the endurance of sensor at the

same

me.

●

Please use the provided glove when open up the device cover, avoid direct contact with the

device cover, because the acidic sweat of the ngers may erode the surface coang of the device

cover.

●

Please use a

so and dry cloth when clean inside and outside surfaces of the device cover, do

not use alkaline detergents.

Swing Barrier User Manual

●

Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you

need to return the device to the factory with the original wrapper. Transportaon without the

original wrapper may result in damage on the device and lead to addional costs.

●

Improper use or replacement of the

baery may result in hazard of explosion. Replace with the

same or equivalent type only. Dispose of used

baeries according to the instrucons provided by

the

baery manufacturer.

●

Biometric

recognion products are not completely applicable to an-spoong environments. If

you require a higher security level, use mulple authencaon modes.

●

Do not stay in the lane when the device is reboong.

●

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED

BATTERIES ACCORDING TO THE INSTRUCTIONS.

●

SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY.

●

The

instrucons shall require connecon of the equipment protecve earthing conductor to the

installaon protecve earthing conductor.

Swing Barrier User Manual

vii

Available Models

Product Name Model Descripon

Swing Barrier DS-K3B802BX-L Le Pedestal

DS-K3B802BX-M Middle Pedestal

DS-K3B802BX-R Right Pedestal

Swing Barrier User Manual

viii

Contents

Chapter 1 Overview .................................................................................................................... 1

1.1 Introducon ........................................................................................................................... 1

1.2 Main Features ........................................................................................................................ 1

Chapter 2 System Wiring ............................................................................................................ 3

Chapter 3 Installaon ................................................................................................................. 5

3.1 Disassemble before Installaon ............................................................................................. 5

3.2 Install Pedestals ..................................................................................................................... 9

Chapter 4 General Wiring ......................................................................................................... 10

4.1 Components

Introducon .................................................................................................... 10

4.2 Wiring Electric Supply .......................................................................................................... 13

4.3 Wire Interconnecng Cable ................................................................................................. 15

4.4 Wire Network Switch ........................................................................................................... 15

4.5 Terminal

Descripon ............................................................................................................ 16

4.5.1 Main Lane Control Board Terminal Descripon .......................................................... 17

4.5.2 Sub Lane Control Board Terminal

Descripon ............................................................ 17

4.5.3 Access Control Board Terminal Descripon ................................................................ 18

4.5.4 Main Extended Interface Board Terminal Descripon ................................................ 20

4.5.5 Sub Extended Interface Board Terminal

Descripon .................................................. 22

4.5.6 Card Reader Board Terminal Descripon .................................................................... 23

4.5.7 Lane Status Indicator Board ........................................................................................ 23

4.5.8 Wiring Diagram ........................................................................................................... 25

4.5.9 RS-485 Wiring ............................................................................................................. 26

4.5.10 Face

Recognion Module Wiring .............................................................................. 27

Chapter 5 Device

Sengs ......................................................................................................... 29

5.1 Set Study Mode .................................................................................................................... 29

5.2 Pair Keyfob ........................................................................................................................... 31

Swing Barrier User Manual

5.3 Inialize Device .................................................................................................................... 33

Chapter 6 Acvaon ................................................................................................................. 34

6.1

Acvate via SADP ................................................................................................................. 34

6.2 Acvate Device via Client Soware ...................................................................................... 35

6.3 Acvate via Web Browser .................................................................................................... 36

Chapter 7 Operaon via Web Browser ...................................................................................... 37

7.1 Login .................................................................................................................................... 37

7.2 Web Wizard .......................................................................................................................... 37

7.2.1 Time Sengs ............................................................................................................... 37

7.2.2 Administrator Sengs ................................................................................................ 38

7.3 Overview .............................................................................................................................. 38

7.4 Person Management ............................................................................................................ 39

7.5 Search Event ........................................................................................................................ 41

7.6 Conguraon ....................................................................................................................... 43

7.6.1 View Device Informaon ............................................................................................. 43

7.6.2 Set Time ...................................................................................................................... 43

7.6.3 Set DST ........................................................................................................................ 44

7.6.4 Change Administrator's Password ............................................................................... 44

7.6.5 Online Users ................................................................................................................ 44

7.6.6 View Device Arming/Disarming

Informaon .............................................................. 45

7.6.7 Network Sengs ......................................................................................................... 45

7.6.8 Set Audio Parameters .................................................................................................. 47

7.6.9 Event Linkage .............................................................................................................. 47

7.6.10 Access Control

Sengs ............................................................................................. 48

7.6.11 Turnsle .................................................................................................................... 53

7.6.12 Card

Sengs ............................................................................................................. 57

7.6.13 Set Privacy Parameters .............................................................................................. 58

7.6.14 Set Smart Parameters ............................................................................................... 58

Swing Barrier User Manual

7.6.15 Prompt Schedule ....................................................................................................... 59

7.6.16 Upgrade and Maintenance ....................................................................................... 61

7.6.17 Device Debugging ..................................................................................................... 62

7.6.18 Component Status .................................................................................................... 63

7.6.19 Log Query .................................................................................................................. 64

7.6.20

Cercate Management ........................................................................................... 64

Chapter 8 Client Soware Conguraon ................................................................................... 66

8.1 Conguraon Flow of Client Soware ................................................................................. 66

8.2 Device Management ............................................................................................................ 66

8.2.1 Add Device .................................................................................................................. 67

8.2.2 Reset Device Password ................................................................................................ 69

8.2.3 Manage Added Devices .............................................................................................. 70

8.3 Group Management ............................................................................................................. 71

8.3.1 Add Group ................................................................................................................... 71

8.3.2 Import Resources to Group ......................................................................................... 72

8.4 Person Management ............................................................................................................ 72

8.4.1 Add

Organizaon ........................................................................................................ 72

8.4.2 Congure Basic Informaon ....................................................................................... 73

8.4.3 Issue a Card by Local Mode ......................................................................................... 73

8.4.4 Upload a Face Photo from Local PC ............................................................................ 75

8.4.5 Take a Photo via Client ................................................................................................ 76

8.4.6 Collect Face via Access Control Device ....................................................................... 77

8.4.7 Collect Fingerprint via Client ....................................................................................... 78

8.4.8 Collect Fingerprint via Access Control Device ............................................................. 79

8.4.9

Congure Access Control Informaon ........................................................................ 80

8.4.10 Customize Person

Informaon .................................................................................. 81

8.4.11 Congure Resident Informaon ................................................................................ 82

8.4.12

Congure Addional Informaon ............................................................................. 82

Swing Barrier User Manual

8.4.13 Import and Export Person Idenfy Informaon ........................................................ 83

8.4.14 Import Person Informaon ....................................................................................... 83

8.4.15 Import Person Pictures ............................................................................................. 84

8.4.16 Export Person

Informaon ........................................................................................ 84

8.4.17 Export Person Pictures .............................................................................................. 85

8.4.18 Get Person Informaon from Access Control Device ................................................ 85

8.4.19 Move Persons to Another Organizaon .................................................................... 86

8.4.20 Issue Cards to Persons in Batch ................................................................................. 86

8.4.21 Report Card Loss ....................................................................................................... 87

8.4.22 Set Card Issuing Parameters ...................................................................................... 87

8.5 Congure Schedule and Template ....................................................................................... 88

8.5.1 Add Holiday ................................................................................................................. 88

8.5.2 Add Template .............................................................................................................. 89

8.6 Set Access Group to Assign Access Authorizaon to Persons .............................................. 90

8.7 Congure Advanced Funcons ............................................................................................ 93

8.7.1 Congure Device Parameters ...................................................................................... 93

8.7.2

Congure Remaining Open/Closed ............................................................................. 99

8.7.3 Congure Mul-Factor Authencaon ..................................................................... 100

8.7.4 Congure Custom Wiegand Rule .............................................................................. 103

8.7.5

Congure Card Reader Authencaon Mode and Schedule .................................... 104

8.7.6 Congure First Person In ........................................................................................... 106

8.7.7 Congure An-Passback ........................................................................................... 107

8.7.8

Congure Device Parameters .................................................................................... 108

8.8 Congure Linkage Acons for Access Control .................................................................... 109

8.8.1 Congure Client Acons for Access Event ................................................................. 109

8.8.2

Congure Device Acons for Access Event ............................................................... 110

8.8.3 Congure Device Acons for Card Swiping ............................................................... 111

8.9 Door Control ...................................................................................................................... 112

Swing Barrier User Manual

xii

8.9.1 Control Door Status ................................................................................................... 113

8.9.2 Check Real-Time Access Records .............................................................................. 114

Appendix A. Tips for Scanning Fingerprint ............................................................................... 116

Appendix B. DIP Switch ........................................................................................................... 118

B.1 DIP Switch

Descripon ....................................................................................................... 118

B.2 DIP Switch Corresponded Funcons .................................................................................. 118

Appendix C. Error Code Descripon ........................................................................................ 119

Appendix D. Communicaon Matrix and Device Command .................................................... 121

Swing Barrier User Manual

xiii

Chapter 1 Overview

1.1 Introducon

The swing barrier with two barriers and 24 pair of IR lights is designed to detect unauthorized

entrance or exit. By adopng the swing barrier integrated with the access control system, person

should

authencate to pass through the lane via swiping IC or ID card, scanning QR code, etc. It is

widely used in aracons, stadiums, construcon sites, residences, etc.

1.2 Main Features

●

32-bit high-speed processor

●

TCP/IP network

communicaon

The communicaon data is specially encrypted to relieve the concern of privacy leak.

●

Permissions

validaon and an-tailgang

●

Remaining open/closed mode selectable

Swing Barrier User Manual

●

Bidireconal (Entering/Exing) lane

The barrier opening and closing speed can be congured according to the visitor ow.

●

The barrier will be locked or stop working when people are nipped

●

An-forced-accessing

The barrier will be locked automacally without open-barrier signal.

●

Self-detecon, Self-diagnoscs, and automac alarm

●

Audible and visual alarm will be triggered when

detecng intrusion, tailgang, reverse passing,

and climbing over barrier

●

IP conict detecon

●

Remote control and management

●

Online/oine operaon

●

LED indicates the entrance/exit and light bar indicates passing status

●

Barrier remains open when powered down

●

Fire alarm passing

When the

re alarm is triggered, the barrier will be open automacally for emergency

evacuaon

●

Valid passing duraon sengs

System will cancel the passing permission if a person does not pass through the lane within the

valid passing duraon

●

Opens/Closes barrier according to the schedule template

Swing Barrier User Manual

Chapter 2 System Wiring

The preparaon before installaon and wiring.

Steps

Draw a central line on the

installaon surface of the le or right pedestal.

Draw other parallel lines for installing the other pedestals.

Note

The distance between the nearest two line is L+190 mm. L represents the lane width.

Slong on the installaon surface and dig installaon holes according to the hole posion

diagram.

Figure 2-1 Hole Posion Diagram

Bury cables. Each lane buries 1 low voltage cable and 1 high voltage cable. For details, see the

system wiring diagram above.

Swing Barrier User Manual

Note

●

High voltage: AC power input

●

Low voltage: interconnecng cables

●

The supplied interconnecng cables are 5.5 m in length.

●

The suggested inner diameter of the low voltage conduit is larger than 30 mm.

●

If you want to bury both of the AC power cord and the low voltage cable at the entrance, the

two cables should be in separated conduits to avoid interference.

●

If more peripherals are required to connect, you should increase the conduit diameter or bury

another conduit for the external cables.

●

The external AC power cord should be double-insulated.

●

The network cable must be CAT5e or the network cable has

beer performance. And the

suggested network cable length should be less than 100 m.

Swing Barrier User Manual

Chapter 3 Installaon

3.1 Disassemble before Installaon

Before installaon, you should disassemble the pedestal and remove some screws.

Before You Start

●

Keep the disassembled components and screws.

●

You should prepare the following tools to disassemble the pedestal: 1. Pedestal Key (supplied); 2.

Allen Wrench (2.5 mm); 3. Allen Wrench (3 mm); 4. Allen Wrench (4 mm).

Steps

Use the pedestal key to open the front and back components.

Figure 3-1 Lock Posion

Swing Barrier User Manual

Use the Allen wretch (4 mm) to loosen the 2 screws (M5 × 25) at the top of the device and

remove the components carefully.

Figure 3-2 Front/Back Component Screw

Use the Allen wretch (4 mm) to loosen the 2 screws (M5 × 12) at the front or back of the

pedestal base and remove the side base cover slowly.

Swing Barrier User Manual

Figure 3-3 Loosen Side Base Screw

Use the Allen wretch (2.5 mm) to loosen the 4 screws (M4 × 8) and remove the motor boom

cover.

Swing Barrier User Manual

Figure 3-4 Motor Boom Cover

Swing Barrier User Manual

3.2 Install Pedestals

Before You Start

Prepare for the installaon tools, check the device and the accessories, and clear the installaon

base.

Steps

Note

●

The device should be installed on the concrete surface or other at non-ammable surfaces.

●

Make sure the device is powered o during installaon and other operaons.

●

The installaon tools are put inside the package of the pedestal.

●

The dimension is as follows.

Figure 3-5 Dimension

Prepare for the installaon tools, check the components, and prepare for the installaon base.

Drill holes on the ground according to the installaon holes on the pedestals and insert the

expansion sleeves.

According to the entrance and exit marks on the pedestals, move the pedestals to the

corresponded

posions.

Note

Make sure the installaon holes on the pedestals and the base are aligned with each other.

Secure each pedestal with 8 expansion bolts.

Note

Do not immerse the pedestal in the water. In special circumstances, the immersed height should

be no more than 150 mm.

Aer installaon, assemble the components and screws back to the pedestal.

Swing Barrier User Manual

Chapter 4 General Wiring

4.1 Components Introducon

By default, basic components of the turnsle are connected well. The pedestals can communicate

by wiring the interconnecng cables. And the turnsle supports wiring the AC electric supply for

the whole system's power supply.

Note

The voltage uctuaon of the electric supply is between 100 VAC and 220 VAC, 50 to 60 Hz.

The picture displayed below describes each component's posion on the turnsle.

Note

The diagram is for reference only.

Swing Barrier User Manual

Figure 4-1 Components Diagram

The picture displayed below describes the serial port on the entrance and exit direcon.

Swing Barrier User Manual

Figure 4-2 Serial Port

The picture displayed below describes the IR sending/receiving module and their corresponding

number on the pedestal.

Swing Barrier User Manual

Figure 4-3 IR Sending/Receiving Module Posion

Note

Standing at the entrance posion in the lane, the IR modules on your le are the IR sending

modules, the ones on your right are the IR receiving modules.

4.2 Wiring Electric Supply

Wire electric supply with the switch in the pedestal. Terminal L and terminal N are on the switch,

while terminal PE should connect to a ground wire (yellow and green wire).

Swing Barrier User Manual

Note

●

The cable bare part should be no more than 8 mm. It is suggested that you can immerse the

bare part into the liquid n. If possible, wear an insulaon cap at the end of the bare cable.

Make sure there’s no bare copper or cable aer the wiring.

●

The Terminal L and the Terminal N cannot be wired reversely. Do not wire the input and output

terminal reversely.

●

To avoid people injury and device damage, when tesng, the ground resistance of the

equipotenal points should not be larger than 2 Ω。

●

Use the device in

conjuncon with an UPS.

Swing Barrier User Manual

4.3 Wire Interconnecng Cable

You should use interconnecng cables to connect the main lane board and the sub lane board for

components communicaon.

The picture displayed below describes the cable hole's posion on the pedestals.

Figure 4-4 Cable Hole of Interconnecng Cable

For interconnecng cable wiring, refer to Wiring Diagram .

4.4 Wire Network Switch

Connect the network cable and the network switch.

Steps

Note

The device do not support the PoE network switch. Connecng with the PoE network switch may

damage the control board.

Open the side cover of the pedestal.

Swing Barrier User Manual

Figure 4-5 Network Switch Posion

Lead out 12 V power supply from the main switch and connect it to the network switch's power

interface.

Connect the network cable with the network switch.

4.5 Terminal

Descripon

The lane controller contains main lane controller and sub lane controller, which controls the IR

beams, motor, and other components' work.

Swing Barrier User Manual

4.5.1 Main Lane Control Board Terminal Descripon

The main lane control board contains power supply interface, supercapacitor interface, brake

interface, motor drive interface, light board interface, motor encoder interface, door open

posion

detecon interface, debug port, lane communicaon interface, interconnecng interface, and DIP

switch (reserved).

The picture displayed below is the main lane control board diagram.

Figure 4-6 Main Lane Control Board

4.5.2 Sub Lane Control Board Terminal

Descripon

The sub lane control board contains power supply interface, supercapacitor interface, brake

interface, motor drive interface, light board interface, motor encoder interface, door open

posion

detecon interface, debug port, lane communicaon interface, and interconnecng interface.

The picture displayed below is the sub lane control board diagram.

Figure 4-7 Sub Lane Control Board

Swing Barrier User Manual

4.5.3 Access Control Board Terminal Descripon

Access control board is mainly used for authority idencaon in places with high security levels

such as public security or judicial place, external device accessing, and

communicaon with the

upper plaorm and lane controller.

Figure 4-8 Access Control Board

Swing Barrier User Manual

Note

●

RS-485A corresponds to UART 5 on web and is for QR code scanner connecon at entrance by

default; RS-485C corresponds to UART 7 on web and is for card reader connecon at entrance by

default.

●

The SOC and MCU serial port are for maintenance and debugging use only.

●

Press the Reset buon for 5 s and the device will start to restore to factory sengs.

●

The DIP switch is for study mode seng and keyfob paring. For detailed informaon about the

DIP switch, see DIP Switch Descripon.

The wiring diagram of extended interface of access control board is shown as follows.

Swing Barrier User Manual

Figure 4-9 Wring Diagram of BUS3 Interface

Note

RS-232A corresponds to UART 1 on web.

4.5.4 Main Extended Interface Board Terminal Descripon

The main extended interface board contains the Wiegand/exit buon interface and

communicaon interface.

Swing Barrier User Manual

Figure 4-10 Main Oponal Board Terminal

Swing Barrier User Manual

4.5.5 Sub Extended Interface Board Terminal Descripon

Figure 4-11 Sub Extended Interface Board

Note

●

RS-485B corresponds to UART 6 on web and is for QR code scanner connecon at exit by default.

●

RS-485D corresponds to UART 4 on web and is for card reader connecon at exit by default.

●

RS-232B corresponds to UART 2 on web.

●

RS-232C corresponds to UART 3 on web.

Swing Barrier User Manual

4.5.6 Card Reader Board Terminal Descripon

The card reader board can be connected to the access control board via RS-485 interface.

Figure 4-12 Card Reader Board

4.5.7 Lane Status Indicator Board

Appearance

Lane status indicator board is shown as follows.

Figure 4-13 Lane Status Indicator Board

DIP Switch

Entrance

Swing Barrier User Manual

Set both DIP switches on the lane status indicator board at entrance to "ON" side:

Figure 4-14 DIP Switch for Entrance

Entrance

Set both DIP switches on the lane status indicator board at exit to "1" side:

Figure 4-15 DIP Switch for Exit

Wiring

Lane status indicator board wiring diagram is shown as follows.

Swing Barrier User Manual

Figure 4-16 Lane Status Indicator Board Wiring

4.5.8 Wiring Diagram

The wiring diagram of components and peripherals.

Figure 4-17 General Wiring

Swing Barrier User Manual

Note

●

The supplied 2 interconnecng cables need connecng on-site:

1. Communicaon cable for connecon between main lane control board and sub lane control

board. The cable is 5.5 m in length and put inside the package of the right/middle pedestal.

2. CAT5e

Communicaon cable. The cable is 5.5 m in length and put inside the package of the

right/middle pedestal.

●

The ① and ② refer to the two sides of a same board.

●

Barrier opens at the entrance/exit: connect to BTN1/BTN2 and GND.

4.5.9 RS-485 Wiring

Swing Barrier User Manual

Note

●

There are four RS-485 interfaces, which are for connecng ID card reader, IC card reader, QR

code scanner, ngerprint and card reader, card recycler, text screen, ngerprint reader, and face

recognion terminal. Take the wiring of RS-485 card reader as an example.

●

For details about text screen, see

Conguring Screen Parameters in User Manual of iVMS-4200

AC Client

Soware.

4.5.10 Face Recognion Module Wiring

Connect the face recognion module to the turnsle.

The wiring diagram is shown as follows:

Figure 4-18 Face Recognion Module Wiring (Entrance)

Swing Barrier User Manual

Figure 4-19 Face Recognion Module Wiring (Exit)

Swing Barrier User Manual

Chapter 5 Device Sengs

Aer installaon and wiring completed, you should set the barriers closed posion (study mode)

before entering the working mode.

You can also set the test mode, normal mode, passing mode and memory mode, pair the keyfob,

inialize the hardware by seng the DIP switch on the access control board.

●

Study Mode: The barrier will learn the closed posion.

●

Normal Mode: The device will work properly.

●

Test Mode: Test mode is the same as the normal mode except that the device cannot report the

alarm, the event, or the people

counng informaon to the center.

●

Memory Mode: By default, the memory mode is enabled. When

mulple cards are presented

and

authencated, it allows mulple persons passing through the lane. When it counts the

passing people number is equal to the card presented mes, or no person passing through the

lane

aer the last person passing, the barriers will be closed.

5.1 Set Study Mode

Enter the study mode through DIP switching to set the closed posion of the device barrier.

Steps

Set the No.1 of the 2-digit DIP switch on the access control board to ON by referring the

following

gure to enter the study mode.

Swing Barrier User Manual

Figure 5-1 DIP Switch Locaon

Figure 5-2 Study Mode

Adjust the closed posion of the barrier.

Power on the device.

The device will remember the current

posion (closed posion) automacally.

Power o the device.

Set the No.1 switches of the 2-digit DIP Switch on the main user extended interface board by

referring to the following

gure.

Swing Barrier User Manual

Figure 5-3 Normal Mode

Power on the device again.

Note

For details about the DIP switch value and meaning, see DIP Switch Descripon.

The barrier will open automacally and turns back to the closed posion. At this circumstance,

the device enters the normal mode.

5.2 Pair Keyfob

Pair the remote control to the device through DIP switch to open/close the barrier remotely.

Before You Start

Ask our technique supports or sales and purchase the keyfob.

Steps

Power o the turnsle.

Set the No.2 switch of the DIP Switch on the access control board to the ON side.

Swing Barrier User Manual

Figure 5-4 DIP Switch Locaon

Figure 5-5 Enable Keyfob Paring Mode

Power on the turnsle and it will enter the keyfob pairing mode.

Hold the Close

buon for more than 10 seconds.

The keyfob's indicator of the will ash twice if the pairing is completed.

Set the No.2 switch to the OFF side, and reboot the

turnsle to take eect.

Note

●

Only one turnsle can pair the keyfob. If mulple turnsles are in the pairing mode, the

keyfob will select only one of them to pair.

●

For details about DIP switch value and meaning, see DIP Switch Descripon .

Swing Barrier User Manual

Oponal: Go to System → User → Keyfob User on the remote control page of the client

soware to delete the keyfob.

5.3 Inialize Device

Steps

Hold the inializaon buon on the access control board for 5 s.

Figure 5-6 Inializaon Buon Posion

The device will start restoring to factory sengs.

When the process is nished, the device will beep for 3 s.

Cauon

The inializaon of the device will restore all the parameters to the default seng and all the

device events are deleted.

Note

Make sure no persons are in the lane when powering on the device.

Swing Barrier User Manual

Chapter 6 Acvaon

You should acvate the device before the rst login. Aer powering on the device, the system will

switch to Device

Acvaon page.

Acvaon via the device, SADP tool and the client soware are supported.

The default values of the device are as follows:

●

The default IP address: 192.0.0.64

●

The default port No.: 8000

●

The default user name: admin

6.1

Acvate via SADP

SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.

Before You Start

●

Get the SADP soware from the supplied disk or the ocial website hp://

www.hikvision.com/en/ , and install the SADP according to the prompts.

●

The device and the PC that runs the SADP tool should be within the same subnet.

The following steps show how to acvate a device and modify its IP address. For batch acvaon

and IP addresses modicaon, refer to User Manual of SADP for details.

Steps

Run the SADP soware and search the online devices.

Find and select your device in online device list.

Input new password (admin password) and

conrm the password.

Cauon

STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of

your own choosing (using a minimum of 8 characters, including upper case leers, lower case

leers, numbers, and special characters) in order to increase the security of your product. And

we recommend you reset your password regularly, especially in the high security system,

reseng the password monthly or weekly can beer protect your product.

Click

Acvate to start acvaon.

Swing Barrier User Manual

Status of the device becomes Acve aer successful acvaon.

Modify IP address of the device.

1) Select the device.

2) Change the device IP address to the same subnet as your computer by either modifying the IP

address manually or checking Enable DHCP.

3) Input the admin password and click Modify to

acvate your IP address modicaon.

6.2

Acvate Device via Client Soware

For some devices, you are required to create the password to acvate them before they can be

added to the

soware and work properly.

Steps

Note

This funcon should be supported by the device.

Enter the Device Management page.

Click on the right of Device Management and select Device.

Click Online Device to show the online device area.

The searched online devices are displayed in the list.

Check the device status (shown on Security Level column) and select an

inacve device.

Click

Acvate to open the Acvaon dialog.

Create a password in the password eld, and conrm the password.

Swing Barrier User Manual

Cauon

The password strength of the device can be automacally checked. We highly recommend you

change the password of your own choosing (using a minimum of 8 characters, including at least

three kinds of following categories: upper case leers, lower case leers, numbers, and special

characters) in order to increase the security of your product. And we recommend you change

your password regularly, especially in the high security system, changing the password monthly

or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

Click OK to acvate the device.

6.3

Acvate via Web Browser

You can acvate the device via the web browser.

Steps

Enter the device default IP address (192.0.0.64) in the address bar of the web browser, and press

Enter.

Note

Make sure the device IP address and the computer's should be in the same IP segment.

Create a new password (admin password) and conrm the password.

Cauon

STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of

your own choosing (using a minimum of 8 characters, including upper case leers, lower case

leers, numbers, and special characters) in order to increase the security of your product. And

we recommend you reset your password regularly, especially in the high security system,

reseng the password monthly or weekly can beer protect your product.

Click Acvate.

Edit the device IP address. You can edit the IP address via the SADP tool, the device, and the

client

soware.

Swing Barrier User Manual

Chapter 7 Operaon via Web Browser

7.1 Login

You can login via the web browser or the remote conguraon of the client soware.

Note

Make sure the device is acvated.

Enter the device IP address in the address bar of the web browser and press Enter to enter the

Enter the device user name and the password. Click Login.

Conguraon of Client Soware

Download and open the client soware. Aer adding the device, click to enter the Conguraon

page.

7.2 Web Wizard

7.2.1 Time Sengs

Click in the top right of the web page to enter the wizard page.

Time Zone

Select the device located

me zone from the drop-down list.

Time Sync.

NTP

You should set the NTP server's IP address, port No., and interval.

Manual

By default, the device me should be synchronized manually. You can set the device me

manually or check Sync. with Computer Time to synchronize the device me with the

computer's me.

Server Address/NTP Port/Interval

You can set the server address, NTP port, and interval.

DST

You can view the DST start me, end me and bias me.

Click Next to save the sengs and go to the next parameter. Or click Skip to skip me sengs.

Swing Barrier User Manual

7.2.2 Administrator Sengs

Steps

Click

in the top right of the web page to enter the wizard page. Aer me sengs, you can

click Next to enter the Administrator Sengs page.

Enter the employee ID and name of the administrator.

Add card.

1) Click+ to add card.

Note

Up to 5 cards can be supported.

2) enter the Card No. and select the property of the card.

Click Complete to complete the sengs.

7.3 Overview

You can view the device component status, real-me event, person informaon, network status,

basic informaon, and device capacity. You can also control the barrier remotely.

Figure 7-1 Overview

Funcon Descripons:

Device Component Status

You can check if the device is working properly. Click View More to view the detailed

component status.

Remote Control

Swing Barrier User Manual

/ / /

The door is opened/closed/remaining open/remaining closed.

Real-Time Event

You can view the event Employee ID, Name, Card No., Event Type, Time, and Operaon. You can

also click View More to enter the event search page.

Person Informaon

You can view the quanty informaon of person, card and ngerprint.

Network Status

You can view the network connecon status.

Basic Informaon

You can view the model, serial No. and rmware version.

Device Capacity

You can view the person, card, ngerprint and event capacity.

7.4 Person Management

Click Add to add the person's informaon, including the basic informaon, cercate,

authencaon and sengs.

Swing Barrier User Manual

Figure 7-2 Add Person

Add Basic

Informaon

Click Person Management → Add to enter the Add Person page.

Add the person's basic informaon, including the employee ID, the person's name, person

type,etc.

If you select Visitor as the person type, you can set the visit

mes.

Click Save to save the sengs.

Set Permission Time

Click Person Management → Add to enter the Add Person page.

Enable Long-Term

Eecve User, or set Validity Period and the person can only has the permission

within the congured me period according to your actual needs.

Click Save to save the

sengs.

Add Card

Click Person Management → Add to enter the Add Person page.

Click Add Card, enter the Card No. and select the Property, and click OK to add the card.

Swing Barrier User Manual

Note

Up to 50 cards can be added.

Click Save to save the sengs.

Authencaon Sengs

Click Person Management → Add to enter the Add Person page.

Set Authencaon Type as Same as Device or Custom.

Click Save to save the sengs.

Import/Export Person Data

Export Person Data

You can export added person data for back-up or imporng to other devices.

Click Export Person Data, set an encrypon password and conrm it. Click OK.

Note

●

The person data will be downloaded to your PC.

●

The password you set will be required for imporng the data le.

Imporng Person Data

Click Imporng Person Data and select the le. Click Import.

Enter the encrypon password to import and synchronize the person data to devices.

7.5 Search Event

Click Event Search to enter the Search page.

Swing Barrier User Manual

Figure 7-3 Search Event

Select the event type and enter the search condions, including the employee ID, name, card No.,

start

me, and end me, and click Search.

The results will be displayed on the right panel.

Swing Barrier User Manual

7.6 Conguraon

7.6.1 View Device Informaon

Click Conguraon → System → System Sengs → Basic Informaon to enter the conguraon

page.

You can view the device name, language, model, serial No., version, IO input, IO output, and local

RS-485 number.

You can change Device Name and click Save.

You can view the device capacity, including person, card,

ngerprint and event.

7.6.2 Set Time

Set the device's me.

Click Conguraon → System → System Sengs → Time Sengs .

Figure 7-4 Time Sengs

Click Save to save the sengs aer the conguraon.

Time Zone

Select the device located me zone from the drop-down list.

Time Sync.

Swing Barrier User Manual

NTP

You should set the NTP server's IP address, port No., and interval.

Manual

By default, the device me should be synchronized manually. You can set the device me

manually or check Sync. with Computer Time to synchronize the device me with the

computer's me.

Server Address Type/Server Address/NTP Port/Interval

You can set the server address type, server address, NTP port, and interval.

7.6.3 Set DST

Steps

Click

Conguraon → System → System Sengs → Time Sengs .

Enable DST.

Set the DST start me, end me and bias me.

Click Save to save the sengs.

7.6.4 Change Administrator's Password

Steps

Click

Conguraon → System → User Management .

Click .

Enter the old password and create a new password.

Conrm the new password.

Click Save.

Cauon

The password strength of the device can be automacally checked. We highly recommend you

change the password of your own choosing (using a minimum of 8 characters, including at least

three kinds of following categories: upper case leers, lower case leers, numbers, and special

characters) in order to increase the security of your product. And we recommend you change

your password regularly, especially in the high security system, changing the password monthly

or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

7.6.5 Online Users

The informaon of users logging into the device is shown.

Swing Barrier User Manual

Go to Conguraon → User Management → Online Users to view the list of online users.

7.6.6 View Device Arming/Disarming Informaon

View device arming type and arming IP address.

Go to

Conguraon → User Management → Arming/Disarming Informaon .

You can view the device arming/disarming informaon. Click Refresh to refresh the page.

7.6.7 Network Sengs

Set TCP/IP and port.

Set Basic Network Parameters

Click Conguraon → Network → Network Sengs → TCP/IP .

Figure 7-5 TCP/IP Sengs Page

Set the parameters and click Save to save the sengs.

NIC Type

Select a NIC type from the drop-down list. By default, it is Self-Adapve.

DHCP

If you disable DHCP, you should manually set the IPv4 address, IPv4 subnet mask, IPv4 default

gateway, preferred DNS server, and alternate DNS server.

Swing Barrier User Manual

If you enable DHCP, the system will automacally allocate the IPv4 address, IPv4 subnet mask,

the IPv4 default gateway preferred DNS server and alternate DNS server.

DNS Server

Set the preferred DNS server and the Alternate DNS server according to your actual need.

Set Port Parameters

Set the HTTP, HTTPS, and HTTP Listening parameters.

Click Conguraon → Network → Network Service → HTTP(S) .

Figure 7-6 Network Service

HTTP

It refers to the port through which the browser accesses the device. For example, when the

HTTP Port is

modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.

HTTPS

Swing Barrier User Manual

Set the HTTPS for accessing the browser. Cercate is required when accessing.

HTTP Listening

The device can send alarm informaon to the event alarm IP address or domain name via HTTP

protocol/HTTPS protocol. Edit the event alarm IP address or domain name, URL, port, and

protocol.

Note

The event alarm IP address or domain name should support the HTTP protocol/HTTPS protocol

to receive the alarm informaon.

7.6.8 Set Audio Parameters

Set the image quality, resoluon, and the device volume.

Set Audio Parameters

Click Conguraon → Video/Audio → Audio .

Figure 7-7 Set Audio Parameters

Drag the block to adjust the output volume.

Click Save to save the sengs aer the conguraon.

You can also enable Voice Prompt.

Note

The funcons vary according to dierent models. Refers to the actual device for details.

7.6.9 Event Linkage

Set linked acons for events.

Steps

Click Conguraon → Event → Event Detecon → Linkage Sengs to enter the page.

Set event source.

If you choose Linkage Type as Event Linkage, you need to select event types from the drop-

down list.

Swing Barrier User Manual

If you choose Linkage Type as Card Linkage, you need to enter the card No. and select the

card reader.

If you choose Linkage Type as Employee ID Linkage, you need to enter the employee ID and

select the card reader.

Set linked acon.

Linked Buzzer

Enable Linked Buzzer and select Start Buzzing or Stop Buzzing for the target event.

Linked Door

Enable Linked Door, check Entrance or Exit, and set the door status for the target event.

Linked Alarm Output

Enable Linked Alarm Output, check Alarm Output 1 or Alarm Output 2, and set the alarm

output status for the target event.

Linked Audio Prompt

Enable Linked Audio Prompt and select the play mode.

●

If you choose TTS, you need to set language and enter the prompt content.

●

If you choose Audio File, you need to select an available audio le from the drop-down list

or click General Linkage

Sengs to add a new audio le.

7.6.10 Access Control

Sengs

Set Authencaon Parameters

Click Conguraon → Access Control → Authencaon Sengs .

Note

The funcons vary according to dierent models. Refers to the actual device for details.

Swing Barrier User Manual

Figure 7-8 Set Authencaon Parameters

Click Save to save the sengs aer the conguraon.

Terminal

Choose Entrance or Exit for sengs.

Terminal Type/Terminal Model

Get terminal descripon. They are read-only.

Enable Authencaon Device

Enable the authencaon funcon.

Authencaon

Select an authencaon mode according to your actual needs from the drop-down list.

Authencaon Interval

You can set the authencaon interval of the same person when authencang. The same

person can only authencate once in the congured interval. A second authencaon will be

failed.

Alarm of Max. Failed

Aempts

Enable to report alarm when the card reading aempts reach the set value.

Max. Authencaon Failed Aempts

Enable to report alarm when the card reading aempts reach the set value.

Swing Barrier User Manual

Communicaon with Controller Every

When the access control device cannot connect with the card reader for longer than the set

me, the card reader will turn oine automacally.

Note

The authencaon interval value ranges from 2 s to 255 s.

Set Door Parameters

Click Conguraon → Access Control → Door Parameters .

Figure 7-9 Door Parameters Sengs Page

Click Save to save the sengs aer the conguraon.

Door No.

Select Entrance or Exit for sengs.

Door Name

You can create a name for the door.

Open

Duraon

Set the door unlocking duraon. If the door is not opened for the set me, the door will be

locked.

Note

The open duraon ranges from 5 s to 60 s.

Exit Buon Type

You can set the exit buon as Remain Open or Remain Closed according to your actual needs.

By default, it is Remain Open.

Swing Barrier User Manual

Door Remain Open Duraon with First Person

Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows

mulple persons access the door or other authencaon acons.

Note

The duraon ranges from 1 s to 1440 s.

Serial Port Sengs

Set serial port parameters.

Steps

Click Conguraon → Access Control → Serial Port Conguraon .

Figure 7-10 Serial Port Sengs

Select a serial port No., and the corresponding serial port type will display automacally.

Set Baud Rate, Data Bit, Stop Bit and Parity.

Set the Peripheral Type as Card Reader, QR Code Scanner, Fingerprint Module or Disable.

Note

When you select QR Code Scanner, Fingerprint Module or Disable, you can set the peripheral

posion.

You can view the connected device model and peripheral soware version.

Click Save.

Swing Barrier User Manual

Set Wiegand Parameters

You can set the Wiegand transmission direcon.

Steps

Note

Some device models do not support this funcon. Refer to the actual products when conguraon.

Click Conguraon → Access Control → Wiegand Sengs .

Select Entrance or Exit.

Enable Wiegand

funcon.

The wiegand transmission direcon is set Input by default.

Note

Input: the device can connect a Wiegand card reader.

Click Save to save the sengs.

Note

If you change the peripheral, and aer you save the device parameters, the device will reboot

automacally.

Set Terminal Parameters

Set the working mode and remote vericaon.

Steps

Click Conguraon → Access Control → Terminal Parameters to enter the page.

Figure 7-11 Terminal Parameters

Set the device working mode.

Permission Free Mode

Swing Barrier User Manual

The device will not verify the person's permission, but only the person's validity period. If the

person is in the validity period, the barrier will open.

You can enable Verify Credenal Locally. Aer enabling the funcon, the device will only

verify the person's permission without the schedule template, etc.

Access Control Mode

The device works normally and will verify the person's permission to open the barrier.

Set remote

vericaon.

1) Enable Remote Vericaon.

Note

The device will upload the person's authencaon informaon to the plaorm. The plaorm

will judge to open the barrier or not.

2) Oponal: Enable Verify Credenal Locally.

Note

Aer enabling the funcon, the device will only verify the person's permission without the

schedule template, etc.

Click Save to complete terminal parameter sengs.

7.6.11

Turnsle

Basic Parameters

Set turnsle basic parameters.

Steps

Click Conguraon → Turnsle → Basic Sengs to enter the page.

View the Device Type, Device Model and Working Status.

Set Barrier Material, Lane Width, Barrier Height, Barrier Opening Speed and Barrier Closing

Speed.

Set the passing mode.

If you choose General Passing, you can select the barrier status for the entrance and exit from

the drop-down list.

Note

If you set barrier-free mode, the barrier remains open and will close when authencaon

fails.

If you choose Weekly Schedule, you can set a weekly schedule for entrance and exit barriers.

Click Save.

Swing Barrier User Manual

keyfob

Set keyfob patameters.

Steps

Click Conguraon → Turnsle → Keyfob to enter the page.

Figure 7-12 keyfob

Set Working Mode as One-to-One or One-to-Many.

Add keyfob.

1) Click Add and the keyfob adding window will pop up.

2) Enter the Name and Serial No..

3) Check to enable Remain Open Permission at your actual needs.

4) Click OK to add the keyfob.

Oponal: Select a keyfob and click Delete to delete the keyfob.

Click Save.

IR Detector

Set IR detector.

Steps

Click Conguraon → Turnsle → IR Detector to enter the page.

Swing Barrier User Manual

Figure 7-13 IR Detector

Set the entrance and exit inducve mode as Single Triggered or Triggered Simultaneously.

Set custom IR detector mode.

Enable IR Emergency Mode

If some IR beams do not work properly, you can shield those IR beams to restore the lane. But

this

acon may hit person and cause injury.

Enable Custom

An-pinch for Door Closing

An-pinch for door closing refers that the barrier will not close if the device has detected

person in the lane. Only

aer the person walks out of the lane, the barrier will close. If you

enable the funcon, you can shield parts of the IR beams for closing barrier in advance. But

this

acon may hit person and cause injury.

Click Save.

People

Counng

Set people counng .

Steps

Click Conguraon → Turnsle → People Counng to enter the page.

Swing Barrier User Manual

Figure 7-14 People Counng

Check to enable People Counng.

Enable Device Oine People Counng at your actual needs.

Select People Counng Type as Invalid, Passing Detecon or Authencaon Number.

Oponal: Click clear to clear all the people counng informaon.

Set Light Color

Set the color for the barrier light.

Steps

Click Conguraon → Turnsle → Light Sengs to enter the page.

Set barrier light color.

1) Check to enable Light on When on Standby at your actual needs.

2) Set the barrier light color.

Click Save.

Other

Sengs

Set other parameters.

Steps

Click Conguraon → Turnsle → Other Sengs to enter the page.

Set Alarm Output

Duraon.

Note

The alarm output duraon ranges from 0 s to 3599 s.

Set Temperature Unit.

Swing Barrier User Manual

Check to enable Do Not Open Barrier When Lane is Not Clear.

Drag the block or enter the value to adjust the light board brightness.

Set the alarm buzzer beeping duraon, barrier closing delay me, intrusion duraon, overstaying

duraon and IR obstructed duraon.

Check to enable Memory Mode at your actual needs.

Note

Mulple cards presenng for mulple person passing is allowable when enabling the memory

mode. When the passing person's number exceeds the card presenng number, or aer the

latest person passing with no other person passing within the door open duraon, the door will

automacally.

Choose the control mode.

So Mode

The barrier will be closed aer the person has passed through the barrier when confronng

tailing, forced accessing, etc.

Guard Mode

The barrier will be closed immediately when confronng tailgang, forced accessing, etc.

Set the re input type.

10.

Click Save.

7.6.12 Card

Sengs

Set Card Security

Click Conguraon → Card Sengs → Card Type to enter the sengs page.

Set the parameters and click Save.

Enable NFC Card

In order to prevent the mobile phone from

geng the data of the access control, you can

disable NFC card to increase the security level of the data.

Enable M1 Card

Enable M1 card and

authencang by presenng M1 card is available.

M1 Card Encrypon

Sector

M1 card encrypon can improve the security level of authencaon.

Enable the funcon and set the encrypon sector. By default, Sector 13 is encrypted. It is

recommended to encrypt sector 13.

Enable EM Card

Enable EM card and authencang by presenng EM card is available.

Swing Barrier User Manual

Note

If the peripheral card reader supports presenng EM card, the funcon is also supported to

enable/disable the EM card funcon.

Enable DESFire Card

The device can read the data from DESFire card when enabling the DESFire card funcon.

DESFire Card Read Content

Aer enable the DESFire card content reading funcon, the device can read the DESFire card

content.

Enable FeliCa Card

The device can read the data from FeliCa card when enabling the FeliCa card

funcon.

Set Card

Authencaon Parameters

Set the card reading content when authencate via card on the device.

Go to

Conguraon → Card Sengs → Card NO. Authencaon Sengs .

Select a card authencaon mode and enable reversed card No. at your actual needs. Click Save.

7.6.13 Set Privacy Parameters

Set the event storage type.

Go to Conguraon → Security → Privacy Sengs

The event storage type is overwring by default. The earliest 5% events will be deleted when the

system detects the stored events has been over 95% of the full space.

7.6.14 Set Smart Parameters

Note

Some device models do not support the ngerprint related funcons.

Select the card reader at entrance or exit, and click to enable Fingerprint Recognion.

Select Fingerprint Security Level from the drop-down list.

Security Level

You can select the

ngerprint security level.

The security level related false acceptance rate is shown as below:

Swing Barrier User Manual

Fingerprint Security Level False Acceptance Rate (FAR)

3 1/1000 FAR

5 1/100000 FAR

6 1/1000000 FAR

12 3/100000 FAR

13 3/1000000 FAR

7.6.15 Prompt Schedule

Customize the output audio content when authencaon succeeded and failed.

Steps

Click Conguraon → Preference → Prompt Schedule .

Swing Barrier User Manual

Figure 7-15 Customize Audio Content

Select me schedule.

Enable the

funcon.

Set the appellaon.

Set the me period when authencaon succeeded.

1) Click Add Time

Duraon.

2) Set the me duraon.

Swing Barrier User Manual

Note

If authencaon is succeeded in the congured me duraon, the device will broadcast the

congured content.

3) Set the audio content.

TTS

If you choose TTS, you need to set the language and enter the prompt content of

authencaon success.

Audio File

If you choose audio le, you need to select an available audio le from the drop-down list

or click Audio File Management to add a new

le.

Note

The audio le's format should be wav, and the size should be within 200 KB.

4) Oponal: Repeat substep 1 to 3.

Oponal: Click to delete the congured me duraon.

Set the me duraon when authencaon failed.

1) Click Add.

2) Set the

me duraon.

Note

If authencaon is failed in the congured me duraon, the device will broadcast the

congured content.

3) Set the audio content.

TTS

If you choose TTS, you need to set the language and enter the prompt content of

authencaon failure.

Audio File

If you choose audio le, you need to select an available audio le from the drop-down list

or click Audio File Management to add a new

le.

Note

The audio le's format should be wav, and the size should be within 200 KB.

4) Oponal: Repeat substep 1 to 3.

5) Oponal: Click to delete the congured me duraon.

Click Save to save the sengs.

7.6.16 Upgrade and Maintenance

Reboot device, restore device parameters, and upgrade device version.

Swing Barrier User Manual

Reboot Device

Click Maintenance and Security → Maintenance → Restart .

Click Restart to reboot the device.

Upgrade

Click Maintenance and Security → Maintenance → Upgrade .

Select an upgrade type from the drop-down list. Click

and select the upgrade le from your

local PC. Click Upgrade to start upgrading.

Note

Do not power o during the upgrading.

Restore Parameters

Click Maintenance and Security → Maintenance → Backup and Reset .

Restore All

All parameters will be restored to the factory

sengs. You should acvate the device before

usage.

Restore

The device will restore to the default sengs, except for the network parameters and the user

informaon.

Import and Export Parameters

Click Maintenance and Security → Maintenance → Backup and Reset .

Export

Click Export to export the device parameters.

Note

You can import the exported device parameters to another device.

Import

Click and select the le to import. Click Import to start import conguraon le.

7.6.17 Device Debugging

You can set device debugging parameters.

Steps

Click Maintenance and Security → Maintenance → Device Debugging .

You can set the following parameters.

Enable SSH

Swing Barrier User Manual

To raise network security, disable SSH service. The conguraon is only used to debug the

device for the professionals.

Print Log

You can select a component from drop-down list and click Export to export log.

Capture Network Packet

You can set the Capture Packet Duraon, Capture Packet Size, and click Start Capture to

capture.

7.6.18 Component Status

Main Lane Status

Device Component

You can view the status of the access control board, lane control board, main extended interface

board, lane status indicator board and IR adapter board.

Peripheral Device

You can view the status of the RS-485 card reader and tamper input.

Temperature

You can view the pedestal temperature.

Movement

You can view the working status of motor encoder.

Sub Lane Status

Device Component

You can view the status of the lane control board, lane status indicator board and IR adapter

board.

Peripheral

You can view the status of the RS-485 card reader, RS-232 card receiver and tamper input.

Movement

You can view the working status of motor encoder.

Others

Passing Mode

You can view the passing mode of entrance and exit.

IR Detector Status

You can view the status of each pair of the IR beam sensors.

Input and Output Status

Swing Barrier User Manual

You can view the status of the event input/output, alarm input/output and re alarm.

Other Status

You can view the status of the barrier and the keyfob receiving module.

7.6.19 Log Query

You can search and view the device logs.

Go to Maintenance and Security → Maintenance → Log .

Set the major and minor type of the log type. Set the start me and end me for searching, and

click Search.

The results will be displayed below, which including the No.,

me, the major type the minor type,

the channel No., the local/remote user informaon, the remote host IP, etc.

7.6.20

Cercate Management

It helps to manage the server/client cercates and CA cercate.

Note

The funcon is only supported by certain device models.

Create and Install Self-signed Cercate

Steps

Go to Maintenance and Security → Security → Cercate Management .

In the

Cercate Files area, select a Cercate Type from the drop-down list.

Click Create.

Input cercate informaon.

Click OK to save and install the cercate.

The created cercate is displayed in the Cercate Details area.

The

cercate will be saved automacally.

Download the cercate and save it to an asking le in the local computer.

Send the asking

le to a cercaon authority for signature.

Import the signed cercate.

1) Select a cercate type in the Import Passwords area, and select a cercate from the local,

and click Install.

2) Select a cercate type in the Import Communicaon Cercate area, and select a cercate

from the local, and click Install.

Swing Barrier User Manual

Install Other Authorized Cercate

If you already has an authorized cercate (not created by the device), you can import it to the

device directly.

Steps

Go to Maintenance and Security → Security →

Cercate Management .

In the Import Passwords and Import Communicaon Cercate areas, select cercate type

and upload

cercate.

Click Install.

Install CA

Cercate

Before You Start

Prepare a CA cercate in advance.

Steps

Go to Maintenance and Security → Security → Cercate Management .

Create an ID in the Import CA Cercate area.

Note

The input cercate ID cannot be the same as the exisng ones.

Upload a cercate le from the local.

Click Install.

Swing Barrier User Manual

Chapter 8 Client Soware Conguraon

8.1 Conguraon Flow of Client Soware

Follow the ow diagram below to congure on the client soware.

Figure 8-1 Flow Diagram of Conguraon on Client Soware

8.2 Device Management

The client supports managing access control devices and video intercom devices.

Swing Barrier User Manual

Example

You can control entrance & exit and manage aendance aer adding access control devices to the

client; you can perform video intercom with the indoor staons and door staons.

8.2.1 Add Device

The client provides three device adding modes including by IP/domain, IP segment, and ISUP

protocol. The client also supports imporng mulple devices in a batch when there are large

amount of devices to be added.

Add Device by IP Address or Domain Name

If you know the IP address or domain name of the device to add, you can add devices to the client

by specifying the IP address (or domain name), user name, password, etc.

Steps

Enter Device Management module.

Click Device tab on the top of the right panel.

The added devices are displayed on the right panel.

Click Add to open the Add window, and then select IP/Domain as the adding mode.

Enter the required

informaon.

Name

Create a descripve name for the device. For example, you can use a nickname that can show

the locaon or feature of the device.

Address

The IP address or domain name of the device.

Port

The devices to add share the same port number. The default value is 80.

User Name

Enter the device user name. By default, the user name is admin.

Password

Enter the device password.

Cauon

The password strength of the device can be automacally checked. We highly recommend

you change the password of your own choosing (using a minimum of 8 characters, including

at least three kinds of following categories: upper case leers, lower case leers, numbers,

and special characters) in order to increase the security of your product. And we recommend

Swing Barrier User Manual

you change your password regularly, especially in the high security system, changing the

password monthly or weekly can beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

Oponal: Check Transmission Encrypon (TLS) to enable transmission encrypon using TLS

(Transport Layer Security) protocol for security purpose.

Note

●

This funcon should be supported by the device.

●

If you have enabled Cercate Vericaon, you should click Open Cercate Directory to

open the default folder, and copy the cercate le exported from the device to this default

directory to strengthen the security.

●

You can log into the device to get the cercate le by web browser.

Check Synchronize Time to synchronize the device me with the PC running the client aer

adding the device to the client.

Oponal: Check Import to Group to create a group by the device name, and import all the

channels of the device to this group.

Example

For access control device, its access points, alarm inputs/outputs, and encoding channels (if

exist) will be imported to this group.

Finish adding the device.

Click Add to add the device and back to the device list page.

Click Add and New to save the

sengs and connue to add other device.

Import Devices in a Batch

You can add mulple devices to the client in a batch by entering the device parameters in a pre-

dened CSV le.

Steps

Enter the Device Management module.

Click Device tab on the top of the right panel.

Click Add to open the Add window, and then select Batch Import as the adding mode.

Click Export Template and then save the

pre-dened template (CSV le) on your PC.

Open the exported template le and enter the required informaon of the devices to be added

on the corresponding column.

Note

For detailed descripon of the required elds, refer to the introducons in the template.

Adding Mode

Enter 0 or 1 or 2.

Swing Barrier User Manual

Address

Edit the address of the device.

Port

Enter the device port number. The default port number is 8000.

User Name

Enter the device user name. By default, the user name is admin.

Password

Enter the device password.

Cauon

The password strength of the device can be automacally checked. We highly recommend

you change the password of your own choosing (using a minimum of 8 characters, including

at least three kinds of following categories: upper case leers, lower case leers, numbers,

and special characters) in order to increase the security of your product. And we recommend

you change your password regularly, especially in the high security system, changing the

password monthly or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

Import to Group

Enter 1 to create a group by the device name. All the channels of the device will be imported

to the corresponding group by default. Enter 0 to disable this

funcon.

Click and select the template le.

Click Add to import the devices.

8.2.2 Reset Device Password

If you forgot the password of the detected online devices, you can reset the device password via

the client.

Steps

Enter Device Management page.

Click Online Device to show the online device area.

All the online devices sharing the same subnet will be displayed in the list.

Select the device from the list and click

on the Operaon column.

Reset the device password.

Click Generate to pop up the QR Code window and click Download to save the QR code to

your PC. You can also take a photo of the QR code to save it to your phone. Send the picture

to our technical support.

Swing Barrier User Manual

Note

For the following operaons for reseng the password, contact our technical support.

Cauon

The password strength of the device can be automacally checked. We highly recommend you

change the password of your own choosing (using a minimum of 8 characters, including at least

three kinds of following categories: upper case leers, lower case leers, numbers, and special

characters) in order to increase the security of your product. And we recommend you change

your password regularly, especially in the high security system, changing the password monthly

or weekly can

beer protect your product.

Proper conguraon of all passwords and other security sengs is the responsibility of the

installer and/or end-user.

8.2.3 Manage Added Devices

Aer adding devices to device list, you can manage the added devices including eding device

parameters, remote conguraon, viewing device status, etc.

Table 8-1 Manage Added Devices

Edit Device Click to edit device informaon including device name, address, user

name, password, etc.

Delete Device Check one or more devices, and click Delete to delete the selected

devices.

Remote Conguraon On the device list page, click in the Operaon column to perform

remote conguraon for a device. The is in the rightmost column of

the Device page. For details, refer to the user manual of device.

View Device Status Click to view device status, including door No., door status, etc.

Note

For dierent devices, you will view dierent informaon about device

status.

View Online User Click to view the details of online user who access the device,

including user name, user type, IP address and login me.

Refresh Device

Informaon

Click to refresh and get the latest device informaon.

Upgrade Device View device status in the Firmware Upgrade column, check one or more

upgradable devices, and click Upgrade Device Firmware to upgrade the

selected devices. For details, refer to .

Swing Barrier User Manual

Get Events from Device Check one device, and click Get Events from Device to synchronize

events. For details, refer to .

Export Device Click Export Device, set the saving path and select device type to export

the device details (such as device type, IP address, and port No.) to your

local PC.

Note

The super user can enable Password Protecon and enter the

password, then the exported le of device informaon will be

encrypted.

8.3 Group Management

The client provides groups to manage the added resources in dierent groups. You can group the

resources into dierent groups according to the resources' locaons.

Example

For example, on the 1st oor, there mounted 16 doors, 64 alarm inputs, and 16 alarm outputs. You

can organize these resources into one group (named 1st Floor) for convenient management. You

can control door status, and do some other

operaons of the devices aer managing the resources

by groups.

8.3.1 Add Group

You can add group to organize the added device for convenient management.

Steps

Enter the Device Management module.

Click Device Management → Group to enter the group management page.

Create a group.

Click Add Group and enter a group name as you want.

Click Create Group by Device Name and select an added device to create a new group by the

name of the selected device.

Note

The resources (such as alarm inputs/outputs, access points, etc.) of this device will be

imported to the group by default.

Swing Barrier User Manual

8.3.2 Import Resources to Group

You can import the device resources (such as alarm inputs/outputs, access points, etc.) to the

added group in a batch.

Before You Start

Add a group for managing devices. Refer to

Add Group .

Steps

Enter the Device Management module.

Click Device Management → Group to enter the group management page.

Select a group from the group list and select the resource type as Access Point, Alarm Input,

Alarm Output, etc.

Click Import.

Select the thumbnails/names of the resources in the thumbnail/list view.

Note

You can click or to switch the resource display mode to thumbnail view or to list view.

Click Import to import the selected resources to the group.

8.4 Person Management

You can add person informaon to the system for further operaons such as access control, video

intercom, me and aendance, etc. You can manage the added persons such as issuing cards to

them in a batch,

imporng and exporng person informaon in a batch, etc.

8.4.1 Add

Organizaon

You can add an organizaon and import person informaon to the organizaon for eecve

management of the persons. You can also add a surbodinate organizaon for the added one.

Steps

Enter Person module.

Select a parent organizaon in the le column and click Add in the upper-le corner to add an

organizaon.

Create a name for the added organizaon.

Note

Up to 10 levels of organizaons can be added.

Oponal: Perform the following operaon(s).

Edit

Organizaon Hover the mouse on an added organizaon and click to edit its name.

Swing Barrier User Manual

Delete

Organizaon

Hover the mouse on an added organizaon and click to delete it.

Note

●

The lower-level organizaons will be deleted as well if you delete an

organizaon.

●

Make sure there is no person added under the organizaon, or the

organizaon cannot be deleted.

Show Persons in

Sub Organizaon

Check Show Persons in Sub Organizaon and select an organizaon to

show persons in its sub organizaons.

8.4.2 Congure Basic Informaon

You can add person to the client one by one and congure the person's basic informaon such as

name, email, phone number, etc.

Steps

Enter Person module.

Select an

organizaon in the organizaon list to add the person.

Click Add to open the adding person window.

The Person ID will be generated

automacally.

Enter the basic informaon including person name, telephone number, email address, validity

period, etc.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons.

8.4.3 Issue a Card by Local Mode

If a card enrollment staon is available, you can issue a card by local mode. To read the card

number, you should connect the card enrollment

staon to the PC running the client by USB

interface or COM, and place the card on the card enrollment staon.

Steps

Enter Person module.

Select an

organizaon in the organizaon list to add the person and click Add to enter Add

Person panel.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

In the Credenal → Card area, click +.

Swing Barrier User Manual

Click Sengs to enter the Sengs page.

Select Local as the card issuing mode.

Figure 8-2 Issue a Card by Local Mode

Set other related parameters.

Card Enrollment

Staon

Select the model of the connected card enrollment staon.

Note

Currently, the supported card enrollment staon models include DS-K1F100-D8, DS-K1F100-

M, DS-K1F100-D8E, and DS-K1F180-D8E.

Card Type

Swing Barrier User Manual

This eld is only available when the model is DS-K1F100-D8E or DS-K1F180-D8E. Select the

card type as EM card or M1 card according to the actual card type.

Buzzing

Enable or disable the buzzing when the card number is read successfully.

Card No. Type

Select the type of the card number according to actual needs.

M1 Card Encrypon

This eld is only available when the model is DS-K1F100-D8, DS-K1F100-D8E, or DS-K1F180-

D8E. If the card is M1 card, then you can enable the M1 Card Encrypon funcon and select

the sector of the card to encrypt.

Click OK to

conrm the operaon.

Place the card on the card enrollment staon, and click Read to get the card number.

The card number will display in the Card No.

eld automacally.

Click Add.

The card will be issued to the person.

8.4.4 Upload a Face Photo from Local PC

When adding person, you can upload a face photo stored in local PC to the client as the person's

prole.

Steps

Enter Person module.

Select an

organizaon in the organizaon list to add the person and click Add.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

Click Add Face in the Basic Informaon panel.

Select Upload.

Select a picture from the PC running the client.

Note

The picture should be in JPG or JPEG format and smaller than 200 KB.

Oponal: Enable Verify by Device to check whether the facial recognion device managed in

the client can recognize the face in the photo.

Note

This funcon is hidden or shown according to the device capacity.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Swing Barrier User Manual

Click Add and New to add the person and connue to add other persons .

8.4.5 Take a Photo via Client

When adding a person, you can take a photo of the her/him via the client and set this photo as the

person's

prole.

Before You Start

Make sure PC running the client has a camera or you have connected other USB camera to the PC.

Steps

Enter Person module.

Select an

organizaon in the organizaon list to add the person and click Add to enter Add

Person window.

Note

Enter the person's basic informaon rst. For details, refer to Congure Basic Informaon .

Click Add Face in the Basic Informaon area.

Select Take Photo to enter Take Photo window.

Oponal: Enable Verify by Device to check whether the captured face photo can meet the

uploading requirements.

Take a photo.

1) Face to the camera and make sure your face is in the middle of the

collecng window.

2) Click

to capture a face photo.

3) Oponal: Click to capture again.

4) Click OK to save the captured photo.

Swing Barrier User Manual

Figure 8-3 Take a Photo via Client

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons.

8.4.6 Collect Face via Access Control Device

When adding person, you can collect the person's face via access control device added to the client

which supports facial recognion funcon.

Steps

Enter Person module.

Swing Barrier User Manual

Select an organizaon in the organizaon list to add the person and click Add.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

Click Add Face in the Basic Informaon panel.

Select Remote

Collecon.

Select an added access control device or the enrollment staon from the drop-down list.

Note

If you select the enrollment staon, you should click Login to set related parameters of the

device including IP address, port No., user name, and password. Also, you can check Face An-

Spoong and select the liveness level as Low, Medium, or High.

Face An-Spoong

If you check this funcon, then the device can detect whether the face to be collected is an

authenc one.

Collect face.

1) Face to the camera of the selected access control device and make sure your face is in the

middle of the

collecng window.

2) Click

to capture a photo.

3) Click OK to save the captured photo.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons .

8.4.7 Collect Fingerprint via Client

Collecng ngerprints locally means you can collect the ngerprint via the ngerprint recorder

connected directly to the PC running the client. The

ngerprints recorded can be used as

credenals of the persons to access the authorized doors.

Before You Start

Connect the ngerprint recorder to the PC running the client.

Steps

Enter Person module.

Select an

organizaon in the organizaon list to add the person and click Add.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

In the Credenal → Fingerprint panel, click +.

In the pop-up window, select the collecon mode as Local.

Swing Barrier User Manual

Select the model of the connected ngerprint recorder.

Note

If the ngerprint recorder is DS-K1F800-F, you can click Sengs to select the COM the

ngerprint recorder connects to.

Collect the ngerprint.

1) Click Start.

2) Place and li your ngerprint on the ngerprint recorder to collect the ngerprint.

3) Click Add to save the recorded ngerprint.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons.

Note

Once the ngerprint is added, the ngerprint type cannot be changed.

8.4.8 Collect Fingerprint via Access Control Device

When adding person, you can collect ngerprint informaon via the access control device's

ngerprint module. The ngerprints recorded can be used as credenals of the persons to access

the authorized doors.

Before You Start

Make sure ngerprint collecon is supported by the access control device.

Steps

Enter Person module.

Select an

organizaon in the organizaon list to add the person and click Add.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

In the Credenal → Fingerprint panel, click +.

In the pop-up window, select the

collecon mode as Remote.

Select an access control device which supports ngerprint recognion funcon from the drop-

down list.

Collect the

ngerprint.

1) Click Start.

2) Place and li your ngerprint on the ngerprint scanner of the selected access control device

to collect the ngerprint.

3) Click Add to save the recorded ngerprint.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Swing Barrier User Manual

Click Add and New to add the person and connue to add other persons .

Note

Once the ngerprint is added, the ngerprint type cannot be changed.

8.4.9 Congure Access Control Informaon

When adding a person, you can set her/his access control informaon, such as binding an access

control group with the person, conguring PIN code, seng the person as a visitor, a blocklist

person, or a super user, etc.

Steps

Enter Person module.

Select an

organizaon in the organizaon list to add the person and click Add.

In the Access Control area, click

to select access group(s) for the person.

Note

For details, refer to Set Access Group to Assign Access Authorizaon to Persons .

Figure 8-4 Congure Access Control Informaon

Set a unique PIN code for the person which can be used for access authencaon.

Manually enter a PIN code containing 4 to 8 digits.

Note

Persons' PIN codes cannot be repeated.

Click Generate to randomly generate an unrepeated PIN code of 6 digits.

Note

If there are repeated PIN codes, a prompt will pop up on the client. The admin can generate a

new PIN code to replace the repeated PIN code and nofy related persons.

Check the person's operaon permissions.

Swing Barrier User Manual

Super User

If the person is set as a super user, he/she will have authorizaon to access all the doors/

oors and will be exempted from remaining closed restricons, all an-passback rules, and

rst person authorizaon.

Extended Door Open Time

Use this funcon for persons with reduced mobility. When accessing the door, the person will

have more

me than others to pass through doors.

For details about seng the door's open duraon, refer to Congure Parameters for Door .

Add to Blocklist

Add the person to the blocklist and when the person tries to access doors/oors, an event

will be triggered and sent to the client to nofy the security personnel.

Mark as Visitor

If the person is a visitor, you should set the her/his valid mes for visit.

Note

The valid mes for visit is between 1 and 100. You can also check No Limit, then there are no

limited mes for the visitor to access doors/oors.

Device Operator

For person with device operator role, he/she is authorized to operate on the access control

devices.

Note

The Super User, Extended Door Open Time, Add to Blocklist, and Mark as Visitor funcons

cannot be enabled concurrently. For example, if one person is set as super user, you cannot

enable extended door open me for her/him, add her/him to the blocklist, or set her/him as

visitor.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons.

8.4.10 Customize Person

Informaon

You can customize the person properes which are not pre-dened in the client according to actual

needs, e.g., place of birth.

Aer customizing, when add a person, you can enter the custom

informaon to make the person informaon complete.

Steps

Enter Person module.

Set the

elds of custom informaon.

1) Click Custom Property.

2) Click Add to add a new property.

Swing Barrier User Manual

3) Enter the property name.

4) Click OK.

Set the custom informaon when adding a person.

1) Select an

organizaon in the organizaon list to add the person and click Add.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

2) In the Custom Informaon panel, enter the person informaon.

3) Click Add to add the person and close the Add Person window, or click Add and New to add

the person and

connue to add other persons.

8.4.11

Congure Resident Informaon

If the person is resident, for video intercom purpose, you need to set the room number for

her/him and bind an indoor

staon. Aer bound, you can call this person by calling the indoor

staon and perform video intercom with her/him.

Steps

Enter Person module.

Select an

organizaon in the organizaon list to add the person and click Add.

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

In the Resident Informaon panel, select the indoor staon to bind it to the person.

Note

If you select Analog Indoor Staon, the Door Staon eld will display and you are required to

select the door staon to communicate with the analog indoor staon.

Enter the oor No. and room No. of the person.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons.

8.4.12

Congure Addional Informaon

When adding person, you can congure the addional informaon for the person, such as person's

identy type, identy No., country, etc., according to actual needs.

Steps

Enter Person module.

Select an organizaon in the organizaon list to add the person and click Add.

Swing Barrier User Manual

Note

Enter the person's basic informaon rst. For details about conguring person's basic

informaon, refer to Congure Basic Informaon .

In the Addional Informaon panel, enter the addional informaon of the person, including

person's ID type, ID No., job

tle, etc., according to actual needs.

Conrm to add the person.

Click Add to add the person and close the Add Person window.

Click Add and New to add the person and

connue to add other persons .

8.4.13 Import and Export Person Idenfy Informaon

You can import the informaon and pictures of mulple persons to the client soware in a batch.

Meanwhile, you can also export the person informaon and pictures and save them in your PC.

8.4.14 Import Person

Informaon

You can enter the informaon of mulple persons in a predened template (CSV/Excel le) to

import the informaon to the client in a batch.

Steps

Enter the Person module.

Select an added

organizaon in the list, or click Add in the upper-le corner to add an

organizaon and then select it.

Click Import to open the Import panel.

Select Person

Informaon as the imporng mode.

Click Download Template for

Imporng Person to download the template.

Enter the person informaon in the downloaded template.

Note

●

If the person has mulple cards, separate the card No. with semicolon.

●

Items with asterisk are required.

●

By default, the Hire Date is the current date.

Click to select the CSV/Excel le with person informaon from local PC.

Click Import to start imporng.

Note

●

If a person No. already exists in the client's database, delete the exisng informaon before

imporng.

●

You can import informaon of no more than 2,000 persons.

Swing Barrier User Manual

8.4.15 Import Person Pictures

Aer imporng face pictures for the added persons to the client, the persons in the pictures can be

idened by an added face recognion terminal. You can either import person pictures one by

one, or import mulple pictures at a me according to your need.

Before You Start

Be sure to have imported person informaon to the client beforehand.

Steps

Enter the Person module.

Select an added

organizaon in the list, or click Add in the upper-le corner to add an

organizaon and then select it.

Click Import to open the Import panel and check Face.

Oponal: Enable Verify by Device to check whether face recognion device managed in the

client can recognize the face in the photo.

Click to select a face picture le.

Note

●

The (folder of) face pictures should be in ZIP format.

●

Each picture le should be in JPG format and should be no larger than 200 KB.

●

Each picture le should be named as "Person ID_Name". The Person ID should be the same

with that of the imported person

informaon.

Click Import to start imporng.

The imporng progress and result will be displayed.

8.4.16 Export Person

Informaon

You can export the added persons' informaon to local PC as a CSV/Excel le.

Before You Start

Make sure you have added persons to an organizaon.

Steps

Enter the Person module.

Oponal: Select an organizaon in the list.

Note

All persons' informaon will be exported if you do not select any organizaon.

Click Export to open the Export panel.

Check Person Informaon as the content to export.

Check desired items to export.

Click Export to save the exported

le in CSV/Excel le on your PC.

Swing Barrier User Manual

8.4.17 Export Person Pictures

You can export face picture le of the added persons and save in your PC.

Before You Start

Make sure you have added persons and their face pictures to an organizaon.

Steps

Enter the Person module.

Oponal: Select an organizaon in the list.

Note

All persons' face pictures will be exported if you do not select any organizaon.

Click Export to open the Export panel and check Face as the content to export.

Click Export to start exporng.

Note

●

The exported le is in ZIP format.

●

The exported face picture is named as "Person ID_Name_0" ("0" is for a full-frontal face).

8.4.18 Get Person Informaon from Access Control Device

If the added access control device has been congured with person informaon (including person

details, ngerprint, and issued card informaon), you can get the person informaon from the

device and import them to the client for further

operaons.

Steps

Note

●

If the person name stored in the device is empty, the person name will be lled with the issued

card No. aer imporng to the client.

●

If the card number or person ID (employee ID) stored on the device already exists in the client

database, the person with this card number or person ID will not be imported to the client.

Enter Person module.

Select an organizaon to import the persons.

Click Get from Device.

Select an added access control device or the enrollment

staon from the drop-down list.

Note

If you select the enrollment staon, you should click Login, and set IP address, port No., user

name and password of the device.

Click Import to start imporng the person informaon to the client.

Swing Barrier User Manual

Note

Up to 2,000 persons and 5,000 cards can be imported.

The person informaon, including person details, person's ngerprint informaon (if

congured), and the linked cards (if congured), will be imported to the selected organizaon.

8.4.19 Move Persons to Another Organizaon

You can move the added persons to another organizaon if you need.

Before You Start

●

Make sure you have added at least two

organizaons.

●

Make sure you have imported person informaon.

Steps

Enter Person module.

Select an

organizaon in the le panel.

The persons under the organizaon will be displayed in the right panel.

Select the person to move.

Click Change Organizaon.

Select the

organizaon to move persons to.

Click OK.

8.4.20 Issue Cards to Persons in Batch

The client provides a convenient way to issue cards to mulple persons in a batch.

Steps

Enter Person module.

Click Batch Issue Cards.

All the added persons with no card issued will be displayed in the right panel.

Oponal: Enter key words (name or person ID) in the input box to lter the person(s) that need

issuing cards.

Oponal: Click Sengs to set the card issuing parameters. For details, refer to Issue a Card by

Local Mode.

Click

Inialize to inialize the card enrollment staon or card reader to make it ready for issuing

cards.

Click the Card No. column and enter the card number.

Place the card on the card enrollment

staon.

Swipe the card on the card reader.

Manually enter the card number and press the Enter key.

The person(s) in the list will be issued with card(s).

Swing Barrier User Manual

8.4.21 Report Card Loss

If the person lost his/her card, you can report the card loss so that the card's related access

authorizaon will be inacve.

Steps

Enter Person module.

Select the person you want to report card loss for and click Edit to open the Edit Person window.

In the

Credenal → Card panel, click on the added card to set this card as lost card.

Aer reporng card loss, the access authorizaon of this card will be invalid and inacve. Other

person who gets this card cannot access the doors by swiping this lost card.

Oponal: If the lost card is found, you can click to cancel the loss.

Aer cancelling card loss, the access authorizaon of the person will be valid and acve.

If the lost card is added in one access group and the access group is applied to the device

already,

aer reporng card loss or cancelling card loss, a window will pop up to nofy you to

apply the changes to the device. Aer applying to device, these changes can take eect on the

device.

8.4.22 Set Card Issuing Parameters

The client provides two modes for reading a card's number: via card enrollment staon or via the

card reader of the access control device. If a card enrollment

staon is available, connect it to the

PC running the client by USB interface or COM, and place the card on the card enrollment to read

the card number. If not, you can also swipe the card on the card reader of the added access control

device to get the card number. As a result, before issuing a card to one person, you need to set the

card issuing parameters including the issuing mode and related parameters.

When adding a card to one person, click

Sengs to open the Card Issuing Sengs window.

Local Mode: Issue Card by Card Enrollment

Staon

Connect a card enrollment staon to the PC running the client. You can place the card on the card

enrollment staon to get the card number.

Card Enrollment

Staon

Select the model of the connected card enrollment staon

Note

Currently, the supported card enrollment staon models include DS-K1F100-D8, DS-K1F100-M,

DS-K1F100-D8E, and DS-K1F180-D8E.

Card Type

This eld is only available when the model is DS-K1F100-D8E or DS-K1F180-D8E.

Select the card type as EM card or IC card according to the actual card type.

Swing Barrier User Manual

Serial Port

It is only available when the model is DS-K1F100-M.

Select the COM the card enrollment

staon connects to.

Buzzing

Enable or disable the buzzing when the card number is read successfully.

Card No. Type

Select the type of the card number according to actual needs.

M1 Card

Encrypon

This eld is only available when the model is DS-K1F100-D8, DS-K1F100-D8E, or DS-K1F180-D8E.

If the card is M1 card, and if you need to enable the M1 Card Encrypon funcon, you should

enable this funcon and select the sector of the card to encrypt.

Remote Mode: Issue Card by Card Reader

Select an access control device added in the client and swipe the card on its card reader to read

the card number.

8.5

Congure Schedule and Template

You can congure the template including holiday and week schedule. Aer seng the template,

you can adopt the

congured template to access groups when seng the access groups, so that

the access group will take eect in the me duraons of the template.

Note

For access group sengs, refer to Set Access Group to Assign Access Authorizaon to Persons .

8.5.1 Add Holiday

You can create holidays and set the days in the holidays, including start date, end date, and holiday

duraon in one day.

Steps

Note

You can add up to 64 holidays in the soware system.

Click Access Control → Schedule → Holiday to enter the Holiday page.

Click Add on the

le panel.

Create a name for the holiday.

Oponal: Enter the descripons or some nocaons of this holiday in the Remark box.

Add a holiday period to the holiday list and congure the holiday duraon.

Swing Barrier User Manual

Note

Up to 16 holiday periods can be added to one holiday.

1) Click Add in the Holiday List eld.

2) Drag the cursor to draw the me duraon, which means in that duraon of me, the

congured access group is acvated.

Note

Up to 8 me duraons can be set to one holiday period.

3) Oponal: Perform the following operaons to edit the me duraons.

●

Move the cursor to the me duraon and drag the me duraon on the meline bar to the

desired posion when the cursor turns to .

●

Click the

me duraon and directly edit the start/end me in the appeared dialog.

●

Move the cursor to the start or the end of me duraon and drag to lengthen or shorten

the me duraon when the cursor turns to .

Oponal: Select the me duraon(s) that need to be deleted, and then click in the

Operaon column to delete the selected me duraon(s).

5) Oponal: Click in the Operaon column to clear all the me duraon(s) in the me bar.

Oponal: Click in the Operaon column to delete this added holiday period from the

holiday list.

Click Save.

8.5.2 Add Template

Template includes week schedule and holiday. You can set week schedule and assign the me

duraon

of access authorizaon for dierent person or group. You can also select the added

holiday(s) for the template.

Steps

Note

You can add up to 255 templates in the soware system.

Click Access Control → Schedule → Template to enter the Template page.

Note

There are two default templates: All-Day Authorized and All-Day Denied, and they cannot be

edited or deleted.

All-Day Authorized

The access authorizaon is valid in each day of the week and it has no holiday.

All-Day Denied

Swing Barrier User Manual

The access authorizaon is invalid in each day of the week and it has no holiday.

Click Add on the le panel to create a new template.

Create a name for the template.

Enter the

descripons or some nocaon of this template in the Remark box.

Edit the week schedule to apply it to the template.

1) Click Week Schedule tab on the lower panel.

2) Select a day of the week and draw

me duraon(s) on the meline bar.

Note

Up to 8 me duraon(s) can be set for each day in the week schedule.

3) Oponal: Perform the following operaons to edit the me duraons.

●

Move the cursor to the

me duraon and drag the me duraon on the meline bar to the

desired

posion when the cursor turns to .

●

Click the

me duraon and directly edit the start/end me in the appeared dialog.

●

Move the cursor to the start or the end of me duraon and drag to lengthen or shorten

the me duraon when the cursor turns to .

4) Repeat the two steps above to draw more me duraons on the other days of the week.

Add a holiday to apply it to the template.

Note

Up to 4 holidays can be added to one template.

1) Click Holiday tab.

2) Select a holiday in the le list and it will be added to the selected list on the right panel.

Oponal: Click Add to add a new holiday.

Note

For details about adding a holiday, refer to Add Holiday .

4) Oponal: Select a selected holiday in the right list and click to remove the selected one, or

click Clear to clear all the selected holiday(s) in the right list.

Click Save to save the

sengs and nish adding the template.

8.6 Set Access Group to Assign Access

Authorizaon to Persons

Aer adding the person and conguring the person's credenals, you can create the access groups

to dene which person(s) can get access to which door(s) and then apply the access group to the

access control device to take

eect.

Swing Barrier User Manual

Before You Start

●

Add person to the client.

●

Add access control device to the client and group access points. For details, refer to Group

Management .

●

Add template.

Steps

When the access group sengs are changed, you need to apply the access groups to the devices

again to take eect. The access group changes include changes of template, access group sengs,

person's access group sengs, and related person details (including card number, ngerprint, face

picture, linkage between card number and ngerprint, linkage between card number and

ngerprint, card password, card eecve period, etc).

Click Access Control →

Authorizaon → Access Group to enter the Access Group interface.

Click Add to open the Add window.

In the Name text

eld, create a name for the access group as you want.

Select a template for the access group.

Note

You should congure the template before access group sengs. Refer to Congure Schedule

and Template for details.

In the le list of the Select Person eld, select person(s) to assign access authority.

In the

le list of the Select Access Point eld, select door(s), door staon(s) or oor(s) for the

selected persons to access.

Click Save.

You can view the selected person(s) and the selected access point(s) on the right side of the

interface.

Swing Barrier User Manual

Figure 8-5 Display the Selected Person(s) and Access Point(s)

Aer adding the access groups, you need to apply them to the access control device to take

eect.

1) Select the access group(s) to apply to the access control device.

2) Click Apply All to Devices start applying all the selected access group(s) to the access control

device or door

staon.

3) Click Apply All to Devices or Apply Changes to Devices.

Apply All to Devices

This

operaon will clear all the existed access groups of the selected devices and then

apply the new access group to the device.

Apply Changes to Devices

This operaon will not clear the existed access groups of the selected devices and only

apply the changed part of the selected access group(s) to the device(s).

4) View the applying status in the Status column or click Applying Status to view all the applied

access group(s).

Note

You can check Display Failure Only to lter the applying results.

The selected persons in the applied access groups will have the authorizaon to enter/exit the

selected doors/door

staons with their linked card(s) or ngerprints.

Oponal: Click to edit the access group if necessary.

Swing Barrier User Manual

Note

If you change the persons' access informaon or other related informaon, you will view the

prompt Access Group to Be Applied on the right corner of the client.

You can click the prompt to apply the changed data to the device. You can select either Apply

Now or Apply Later.

Figure 8-6 Data Synchronizaon

8.7

Congure Advanced Funcons

You can congure the advanced funcons of access control to meet some special requirements in

dierent scene.

Note

●

For the card related funcons(the type of access control card), only the card(s) with access group

applied will be listed when adding cards.

●

The advanced funcons should be supported by the device.

●

Hover the cursor on the Advanced

Funcon, and then Click to customize the advanced

funcon(s) to be displayed.

8.7.1 Congure Device Parameters

Aer adding the access control device, you can congure the parameters of access control device,

access control points.

Congure

Parameters for Access Control Device

Aer adding the access control device, you can congure its parameters.

Swing Barrier User Manual

Steps

Click Access Control → Advanced Funcon → Device Parameter .

Note

If you can nd Device Parameter in the Advanced Funcon list, Hover the cursor on the

Advanced Funcon, and then Click to select the Device Parameter to be displayed.

Select an access device to show its parameters on the right page.

Turn the switch to ON to enable the corresponding funcons.

Note

The displayed parameters may vary for dierent access control devices.

RS-485 Communicaon Redundancy

You should enable this funcon if you wire the RS-485 card reader to the access control

device redundantly.

Enable NFC

If enable the funcon, the device can recognize the NFC card. You can present NFC card on

the device.

Enable M1 Card

If enable the

funcon, the device can recognize the M1 card. You can present M1 card on the

device.

Enable EM Card

If enable the funcon, the device can recognize the EM card. You can present EM card on the

device.

Enable CPU Card

Reserved. If enable the

funcon, the device can recognize the CPU card. You can present CPU

card on the device.

Enable ID Card

Reserved. If enable the funcon, the device can recognize the ID card. You can present ID

card on the device.

Click OK.

Oponal: Click Copy to, and then select the access control device(s) to copy the parameters in

the page to the selected device(s).

Congure

Parameters for Door

Aer adding the access control device, you can congure its access point door parameters.

Steps

Click Access Control → Advanced Funcon → Device Parameter .

Swing Barrier User Manual

Select an access control device on the le panel, and then click to show the doors or oors of

the selected device.

Select a door or oor to show its parameters on the right page.

Edit the door or

oor parameters.

Note

The displayed parameters may vary for dierent access control devices.

Name

Edit the card reader name as desired.

Exit Buon Type

You can set the exit buon as remaining closed or remaining open. Usually, it is remaining

open.

Open Duraon

Aer swiping the normal card and relay acon, the me for locking the door starts working.

Door Le Open Timeout Alarm

The alarm can be triggered if the door has not been closed in a congured me period. If it is

set as 0, no alarm will be triggered.

Super Password

The

specic person can open the door by inpung the super password.

Some of the following parameters are not listed in the Basic Informaon page, click Advanced to

edit the parameters.

Duress Code

The door can open by

inpung the duress code when there is duress. At the same me, the

client can report the duress event.

Dismiss Code

Create a dismiss code which can be used to stop the buzzer of the card reader (by entering

the dismiss code on the keypad).

Note

●

The duress code, super code, and dismiss code should be dierent.

●

The duress code, super password, and the dismiss code should be dierent from the

authencaon password.

●

The length of duress code, super password, and the dismiss code is according the device,

usually it should contains 4 to 8 digits.

Click OK.

Oponal: Click Copy to , and then select the door(s) to copy the parameters in the page to the

selected doors(s).

Swing Barrier User Manual

Note

The door's status duraon sengs will be copied to the selected door(s) as well.

Congure Parameters for Card Reader

Aer adding the access control device, you can congure its card reader parameters.

Steps

Click Access Control → Advanced Funcon → Device Parameter .

In the device list on the

le, click to expand the door, select a card reader and you can edit the

card reader's parameters on the right.

Edit the card reader basic parameters in the Basic

Informaon page.

Note

The displayed parameters may vary for dierent access control devices. There are part of

parameters listed as follows. Refer to the user manual of the device for more details.

Name

Edit the card reader name as desired.

Minimum Card Swiping Interval

If the interval between card swiping of the same card is less than the set value, the card

swiping is invalid. You can set it as 0 to 255.

Alarm of Max. Failed

Aempts

Enable to report alarm when the card reading aempts reach the set value.

Card Reader Type/Card Reader Descripon

Get card reader type and descripon. They are read-only.

Oponal: Some of the following parameters are not listed in the Basic Informaon page, click

Advanced to edit the parameters.

Enable Card Reader

If enabling the

funcon, user can present card on the card reader. If disabling the funcon,

the card reader for entrance cannot be used.

OK LED Polarity/Error LED Polarity/Buzzer Polarity

Set OK LED Polarity/Error LED Polarity/Buzzer LED Polarity of main board according to the

card reader parameters. Generally, adopts the default sengs.

Buzzing Time

Set the card reader buzzing me. The available me ranges from 0 to 5,999s. 0 represents

connuous buzzing.

Max. Interval When Entering PWD

Swing Barrier User Manual

When you inpung the password on the card reader, if the interval between pressing two

digits is larger than the set value, the digits you pressed before will be cleared automacally.

Tampering Detecon

Enable the an-tamper detecon for the card reader.

Communicate with Controller Every

When the access control device cannot connect with the card reader for longer than the set

me, the card reader will turn oine automacally.

Fingerprint Recognion Level

Select the ngerprint recognion level in the drop-down list.

Click OK.

Oponal: Click Copy to, and then select the card reader(s) to copy the parameters in the page to

the selected card reader(s).

Congure

Parameters for Alarm Output

Aer adding the access control device, if the device links to alarm outputs, you can congure the

parameters.

Before You Start

Add access control device to the client, and make sure the device supports alarm output.

Steps

Click Access Control → Advanced Funcon → Device Parameter to enter access control

parameter

conguraon page.

In the device list on the le, click to expand the door, select an alarm input and you can edit

the alarm input's parameters on the right.

Set the alarm output parameters.

Name

Edit the card reader name as desired.

Alarm Output

Acve Time

How long the alarm output will last aer triggered.

Click OK.

Oponal: Set the switch on the upper right corner to ON to trigger the alarm output.

Congure

Parameters for Lane Controller

Aer adding the lane controller to the client, you can congure its parameters for passing through

the lane.

Swing Barrier User Manual

Steps

Click Access Control → Advanced Funcon → Device Parameter to enter Parameter Sengs

page.

In the device list on the

le, select a lane controller and you can edit the lane controller's

parameters on the right.

Edit the parameters.

Passing Mode

Select the controller which will control the barrier status of the device.

●

If you select According to DIP

Sengs, the device will follow the controller's DIP sengs to

control the barrier. The sengs on the soware will be invalid.

●

If you select According to Door's Schedule Sengs, the device will follow the schedule

congured in the client soware to control the barrier. The DIP sengs of the controller

will be invalid.

Enable Free Passing

Authencaon

Aer enabling free passing authencaon, an alarm will be triggered when the passing

personnel has no permission to pass through.

Opening/Closing Barrier Speed

Set the barrier's opening and closing speed. You can select from 1 to 10. The greater the

value, the faster the speed.

Note

The recommended value is 6.

Alarm Voice Prompt Duraon

Set how long the audio will last, which is played when an alarm is triggered.

Note

0 refers to the alarm audio will be played unl the alarm is ended.

Temperature Unit

Select the temperature unit that displayed in the device status.

Lightboard Brightness

Set the lightboard brightness.

Barrier Material

Select the material of the barrier gate. You can select the barrier material from the drop-

down list.

Note

The barrier material will aect the device working. Select a correct barrier material or the

barrier may not open.

Swing Barrier User Manual

Lane Length

The width of the lane. You can set the lane width.

Note

The lane width will aect the device working. Set a correct lane width or the barrier may not

open.

Do Not Open Barrier When Lane is Not Clear

If there is someone or something in the lane, the gate will not open even if the credenal is

authencated.

This funcon is designed to avoid more than one person passing through the gate with only

one

authencaon.

Click OK.

8.7.2

Congure Remaining Open/Closed

You can set the status of the door as open or closed. For example, you can set the door remaining

closed in the holiday, and set the door remaining open in the specied period of the work day.

Before You Start

Add the access control devices to the system.

Steps

Click Access Control → Advanced

Funcon → Remain Open/Closed to enter the Remain Open/

Closed page.

Select the door that need to be

congured on the le panel.

To set the door status during the work day, click the Week Schedule and perform the following

operaons.

1) Click Remain Open or Remain Closed.

2) Drag the cursor to draw the me duraon, which means in that duraon of me, the

congured access group is acvated.

Note

Up to 8 me duraons can be set to each day in the week schedule.

3) Oponal: Perform the following operaons to edit the me duraons.

●

Move the cursor to the me duraon and drag the me duraon on the meline bar to the

desired

posion when the cursor turns to .

●

Click the me duraon and directly edit the start/end me in the appeared dialog.

●

Move the cursor to the start or the end of

me duraon and drag to lengthen or shorten

the me duraon when the cursor turns to .

4) Click Save.

Operaons

Swing Barrier User Manual

Copy to Whole

Week

Select one duraon on the me bar, click Copy to Whole Week to copy all

the duraon sengs on this me bar to other week days.

Delete Selected Select one duraon on the me bar, click Delete Selected to delete this

duraon.

Clear Click Clear to clear all the duraon sengs in the week schedule.

To set the door status during the holiday, click the Holiday and perform the following operaons.

1) Click Remain Open or Remain Closed.

2) Click Add.

3) Enter the start date and end date.

4) Drag the cursor to draw the

me duraon, which means in that duraon of me, the

congured access group is acvated.

Note

Up to 8 me duraons can be set to one holiday period.

5) Perform the following operaons to edit the me duraons.

●

Move the cursor to the

me duraon and drag the me duraon on the meline bar to the

desired posion when the cursor turns to .

●

Click the

me duraon and directly edit the start/end me in the appeared dialog.

●

Move the cursor to the start or the end of me duraon and drag to lengthen or shorten

the

me duraon when the cursor turns to .

6) Oponal: Select the me duraon(s) that need to be deleted, and then click in the

Operaon column to delete the selected me duraon(s).

7) Oponal: Click in the Operaon column to clear all the me duraon(s) in the me bar.

8) Oponal: Click in the Operaon column to delete this added holiday period from the

holiday list.

9) Click Save.

Oponal: Click Copy to to copy the door status sengs of this door to other door(s).

8.7.3

Congure Mul-Factor Authencaon

You can manage the persons by group and set the authencaon for mulple persons of one

access control point (door).

Before You Start

Set access group and apply the access group to the access control device. For details, refer to

Set

Access Group to Assign Access Authorizaon to Persons .

Perform this task when you want to set

authencaons for mulple cards of one access control

point (door).

Steps

Click Access Control → Advanced Funcon → Mul-Factor Auth .

Select an access control device in device list on the

le panel.

Swing Barrier User Manual

100

Add a person/card group for the access control device.

1) Click Add on the right panel.

2) Create a name for the group as desired.

3) Specify the start

me and end me of the eecve period for the person/card group.

4) Select members(s) and card(s) in the Available list, and the selected member(s) and card(s)

will be added to the Selected list.

Note

Make sure you have issue card to the person.

Make sure you have set access group and apply the access group to the access control device

successfully.

5) Click Save.

6) Oponal: Select the person/card group(s), and then click Delete to delete it(them).

7) Oponal: Select the person/card group(s), and then click Apply to re-apply access group that

failed to be applied previously to the access control device.

Select an access control point (door) of selected device on the

le panel.

Enter the maximum interval when entering password.

Add an authencaon group for the selected access control point.

1) Click Add on the

Authencaon Groups panel.

2) Select a congured template as the authencaon template from the drop-down list.

Note

For seng the template, refer to Congure Schedule and Template .

3) Select the authencaon type as Local Authencaon, Local Authencaon and Remotely

Open Door, or Local

Authencaon and Super Password from the drop-down list.

Local Authencaon

Authencaon by the access control device.

Local Authencaon and Remotely Open Door

Authencaon by the access control device and by the client. When the person swipes the

card on the device, a window will pop up. You can unlock the door via the client.

Swing Barrier User Manual

101

Figure 8-7 Remotely Open Door

Note

You can check Oine Authencaon to enable the super password authencaon when

the access control device is disconnected with the client.

Local Authencaon and Super Password

Authencaon by the access control device and by the super password.

4) Select the added person/card group in the

le list below and it will be added to the Selected

list on the right as the authencaon group.

5) Click the added authencaon group in the right list to set authencaon mes in the Auth

Times column.

Note

●

The authencaon mes should be larger than 0 and smaller than the added personnel

quanty in the personnel group.

●

The maximum value of authencaon mes is 16.

6) Click Save.

Note

●

For each access control point (door), up to four authencaon groups can be added.

●

For the authencaon group of which authencaon type is Local Authencaon, up to 8

person/card groups can be added to the authencaon group.

●

For the

authencaon group of which authencaon type is Local Authencaon and Super

Password or Local

Authencaon and Remotely Open Door, up to 7 person/card groups can

be added to the

authencaon group.

Click Save.

Swing Barrier User Manual

102

8.7.4 Congure Custom Wiegand Rule

Based on the knowledge of uploading rule for the third party Wiegand, you can set mulple

customized Wiegand rules to communicate between the device and the third party card readers.

Before You Start

Wire the third party card readers to the device.

Steps

Note

●

By default, the device disables the custom wiegand funcon. If the device enables the custom

Wiegand funcon, all wiegand interfaces in the device will use the customized wiegand protocol.

●

Up to 5 custom Wiegands can be set.

●

For details about the custom Wiegand, see Custom Wiegand Rule

Descripons.

Click Access Control → Advanced Funcon → Custom Wiegand to enter the Custom Wiegand

page.

Select a custom Wiegand on the

le.

Create a Wiegand name.

Note

Up to 32 characters are allowed in the custom Wiegand name.

Click Select Device to select the access control device for seng the custom wiegand.

Set the parity mode according to the property of the third party card reader.

Note

●

Up to 80 bits are allowed in the total length.

●

The odd parity start bit, the odd parity length, the even parity start bit and the even parity

length range from 1 to 80 bit.

●

The start bit of the card ID, the manufacturer code, the site code, and the OEM should range

from 1 to 80 bit.

Set output transformaon rule.

1) Click Set Rule to open the Set Output

Transformaon Rules window.

Swing Barrier User Manual

103

Figure 8-8 Set Output Transformaon Rule

2) Select rules on the le list.

The selected rules will be added to the right list.

Oponal: Drag the rules to change the rule order.

4) Click OK.

5) In the Custom Wiegand tab, set the rule's start bit, length, and the decimal digit.

Click Save.

8.7.5

Congure Card Reader Authencaon Mode and Schedule

You can set the passing rules for the card reader of the access control device according to your

actual needs.

Steps

Click Access Control → Advanced Funcon → Authencaon to enter the authencaon mode

conguraon page.

Select a card reader on the le to congure.

Set card reader authencaon mode.

1) Click

Conguraon.

Swing Barrier User Manual

104

Figure 8-9 Select Card Reader Authencaon Mode

Note

PIN refers to the PIN code set to open the door. Refer to Congure Access Control

Informaon .

2) Check the modes in the Available Mode list and they will be added to the selected modes list.

3) Click OK.

Aer selecng the modes, the selected modes will display as icons with dierent color.

Click the icon to select a card reader authencaon mode, and drag the cursor to draw a color

bar on the schedule, which means in that period of

me, the card reader authencaon is valid.

Repeat the above step to set other me periods.

Swing Barrier User Manual

105

Figure 8-10 Set Authencaon Modes for Card Readers

Oponal: Select a congured day and click Copy to Week to copy the same sengs to the whole

week.

Oponal: Click Copy to to copy the sengs to other card readers.

Click Save.

8.7.6

Congure First Person In

You can set mulple rst persons for one access control point. Aer the rst person is authorized,

it allows mulple persons access the door or other authencaon acons.

Before You Start

●

Add access control device to the client, and make sure the device supports the rst person in

funcon.

●

Add person and assign access authorizaon to designed person. For details, refer to Person

Management and Set Access Group to Assign Access Authorizaon to Persons .

Steps

Click Access Control → Advanced

Funcon → First Person In to enter the First Person In page.

Select an access control device in the list on the le panel.

Select the current mode as Enable Remaining Open aer First Person, Disable Remaining Open

aer First Person, or Authorizaon by First Person from the drop-down list for each access

control point of the selected device.

Enable Remaining Open

aer First Person

Swing Barrier User Manual

106

The door remains open for the congured me duraon aer the rst person is authorized

unl the remain open duraon ends. If you select this mode, you should set the remain open

duraon.

Note

The remain open duraon should be between 0 and 1440 minutes. By default, the remain

open duraon is 10 minutes.

Disable Remaining Open aer First Person

Disable the funcon of rst person in, namely normal authencaon.

Authorizaon by First Person

All authencaons (except for the authencaons of super card, super password, duress

card, and duress code) are allowed only

aer the rst person authorizaon.

Note

You can authencate by the rst person again to disable the rst person mode.

Click Add on the First Person List panel.

Select person(s) in the

le list and the person(s) will be add to the selected persons as the rst

person(s) of the doors.

The added rst person(s) will list in the First Person List

Oponal: Select a rst person from the list and click Delete to remove the person from the rst

person list.

Click Save.

8.7.7

Congure An-Passback

The an-passback feature is designed to minimizes the misuse or fraudulent use of access

credenals such as passing back card to an unauthorized person, or tailed access. The an-

passback funcon establishes a specic sequence in which access credenals must be used in

order to grant access. You can set the sequence according to the actual path via the client and if

the person uses the

credenal in wrong sequence, you can also reset the an-password records.

Before You Start

Add access control device to the client, and enable the an-passing back funcon of the access

control device.

Steps

Note

Either the an-passing back or mul-door interlocking funcon can be congured for an access

control device at the same me. For the conguraon of mul-door interlocking, refer to .

Click Access Control → Advanced Funcon → An-Passback to enter the An-Passpack Sengs

page.

Swing Barrier User Manual

107

Select an access control device on the le panel.

Select a card reader as the beginning of the path in the First Card Reader eld.

Click of the selected rst card reader in the Card Reader Aerward column to open the select

card reader dialog.

Select the aerward card readers for the rst card reader.

Note

Up to four aerward card readers can be added as aerward card readers for one card reader.

Click OK in the dialog to save the selecons.

Click Save in the An-Passback Sengs page to save the sengs and take eect.

Example

Set Card Swiping Path: If you select Reader In_01 as the beginning, and select Reader In_02,

Reader Out_04 as the linked card readers. Then you can only get through the access control

point by swiping the card in the order as Reader In_01, Reader In_02 and Reader Out_04.

Click Reset

An-Passback and select the person(s) to delete the related an-passback records

about the person(s) on the device.

Note

This funcon should be supported by the device.

8.7.8 Congure Device Parameters

Aer adding the access control device, you can set its parameters such as network parameters.

Set RS-485 Parameters

You can set the access control device's RS-485 parameters including the baud rate, data bit, the

stop bit, parity type, ow control type, communicaon mode, work mode, and connecon mode.

Steps

Note

The RS-485 Sengs should be supported by the device.

Enter the Access Control module.

On the

navigaon bar on the le, enter Advanced Funcon → More Parameters .

Select an access control device in the device list and click RS-485 to enter the RS-485 Sengs

page.

Select the serial port number from the drop-down list to set the RS-485 parameters.

Set the serial number, external device, authencaon center, baud rate, data bit, stop bit, parity

type,

ow control type, communicaon mode, and working mode in the drop-down list.

Click Save.

Swing Barrier User Manual

108

●

The congured parameters will be applied to the device automacally.

●

When you change the working mode or connecon mode, the device will reboot

automacally.

Enable M1 Card Encrypon

M1 card encrypon can improve the security level of authencaon.

Steps

Note

The funcon should be supported by the access control device and the card reader.

Enter the Access Control module.

On the navigaon bar on the le, enter Advanced Funcon → More Parameters .

Select an access control device in the device list and click M1 Card

Encrypon to enter the M1

Card Encrypon page.

Set the switch to on to enable the M1 card

encrypon funcon.

Set the sector ID.

The sector ID ranges from 1 to 100.

Click Save to save the

sengs.

8.8

Congure Linkage Acons for Access Control

You can congure dierent linkage acons for the event detected by the access control device.

Aer that, linkage acons will be triggered once the event happens. This mechanism is used for

nofying the security personnel the event, or triggering automac access control in real me.

Two types of linkage acons are supported:

●

Client Acons: When the event is detected, it will trigger the acons on the client, such as the

client making an audible warning..

●

Device

Acons: When the event is detected, it will trigger the acons of a specic device, such

as buzzing of a card reader and, opening/closing of a door, ..

8.8.1

Congure Client Acons for Access Event

Even if you are far away from an access point, you can sll know what happens and how urgent the

event is via the client by

conguring client acons for the access event. Client acons here refer to

the acons automacally executed by the client itself, such as making an audible warning and

sending an email. Once an event is triggered, the client will

nofy the security personnel, so that

he/she can handle the event in me.

Swing Barrier User Manual

109

Before You Start

Add access control device to the client.

Steps

Click Event

Conguraon → Access Control Event .

The added access control devices will display in the device list.

Select a resource (including device, alarm input, door, and card reader) from the device list.

The event types which the selected resource supports appear.

Select the event(s) and click Edit Priority to

dene the priority for the event(s), which can be

used to

lter events in the Event Center.

Set the linkage acons of the event.

1) Select the event(s) and click Edit Linkage to set the client acons when the event(s) are

triggered.

Audible Warning

The client

soware gives an audible warning when the event is triggered. You can select

alarm sound for the audible warning.

Note

For details about seng the alarm sound, refer to Set Alarm Sound in the user manual of

the client soware.

Send Email

Send an email nocaon about the event to one or more receivers.

For details about

seng email parameters, refer to Set Email Parameters in the user

manual of the client soware.

2) Click OK.

Enable the event so that when the event is detected, event will be sent to the client and the

linkage acons will be triggered.

Oponal: Click Copy to to copy the event sengs to other access control device, alarm input,

door, or card reader.

8.8.2

Congure Device Acons for Access Event

You can set the access control device's linkage acons for the access control device's triggered

event. When the event is triggered, it can trigger the alarm output, host buzzer, and other

acons

on the same device.

Steps

Note

It should be supported by the device.

Click Access Control → Linkage Conguraon .

Swing Barrier User Manual

110

Select the access control device from the list on the le.

Click Add buon to add a new linkage.

Select the event source as Event Linkage.

select the event type and detailed event to set the linkage.

In the Linkage Target area, set the property target to enable this acon.

Buzzer on Controller

The audible warning of access control device will be triggered.

Click Save.

Oponal: Aer adding the device linkage, you can do one or more of the following:

Edit Linkage

Sengs

Select the congured linkage sengs in the device list and you can edit its

event source parameters, including event source and linkage target.

Delete Linkage

Sengs

Select the congured linkage sengs in the device list and click Delete to

delete it.

8.8.3 Congure Device Acons for Card Swiping

You enable access control device's linkage acons (such as disarming a zone and triggering audio

prompt) for the swiping of a

specic card, In this way, you can monitor the card holder's behaviors

and whereabouts.

Steps

Note

It should be supported by the device.

Click Access Control → Linkage Conguraon .

Select the access control device from the list on the

le.

Click Add to add a new linkage.

Select Card Linkage as the event source.

Enter the card number or select the card from the drop-down list.

Select the card reader where the card swipes.

In the Linkage Target area, set the property target to enable this

acon.

Buzzer on Controller

The audible warning of access control device will be triggered.

Buzzer on Reader

The audible warning of card reader will be triggered.

Capture

An event-related picture will be captured when the selected event happens.

Recording

Swing Barrier User Manual

111

An event-related picture will be captured when the selected event happens.

Note

The device should support recording.

Alarm Output

The alarm output will be triggered for nocaon.

Alarm Input

Arm or disarm the alarm input.

Note

The device should support alarm input funcon.

Access Point

The door status of open, close, remain open, or remain closed will be triggered.

Audio Play

The audio prompt will be triggered. And the select audio index related audio content will be

played according to the congured play mode.

Click Save.

When the card

(congured in Step 5) swipes on the card reader (congured in Step 6), it can

trigger the linked acons (congured in step 7).

Oponal: Aer adding the device linkage, you can do one or more of the followings:

Delete Linkage

Sengs

Select the congured linkage sengs in the device list and click Delete to

delete it.

Edit Linkage

Sengs

Select the congured linkage sengs in the device list and you can edit its

event source parameters, including event source and linkage target.

8.9 Door Control

In Monitoring module, you can view the real-me status of the doors managed by the added

access control device. You can also control the doors such as open/close the door, or remain the

door open/closed via the client remotely. The

real-me access event are displayed in this module.

You can view the access details and person details.

Note

For the user with door control permission, the user can enter the Monitoring module and control

the door. Or the icons used for control will not show. For seng the user permission, refer to

Person Management .

Swing Barrier User Manual

112

8.9.1 Control Door Status

You can control the status for the door(s), including unlock door, locking door, remaining the door

unlock, remaining the door locked, remain all unlocked, etc.

Before You Start

●

Add person and assign access authorizaon to designed person, and person will have the access

authorizaon to the access points (doors). For details, refer to Person Management and Set

Access Group to Assign Access Authorizaon to Persons .

●

Make sure the

operaon user has the permission of the access points (doors).

Steps

Click Monitoring to enter the status monitoring page.

Select an access point group on the upper-right corner.

Note

For managing the access point group, refer to Group Management .

The doors in the selected access control group will display.

Click a door icon to select a door, or press Ctrl and select mulple doors.

Note

For Remain All Unlocked and Remain All Locked, ignore this step.

Click the following buons to control the door.

Unlock

When the door is locked, unlock it and it will be open for once.

Aer the open duraon, the

door will be closed and locked again automacally.

Lock

When the door is unlocked, lock it and it will be closed. The person who has the access

authorizaon can access the door with credenals.

Remain Unlocked

The door will be unlocked (no maer closed or open). All the persons can access the door

with no credenals required.

Remain Locked

The door will be closed and locked. No person can access the door even if he/she has the

authorized

credenals, except the super users.

Remain All Unlocked

All doors in the group will be unlocked (no maer closed or open). All the persons can access

the doors with no credenals required.

Remain All Locked

Swing Barrier User Manual

113

All doors in the group will be closed and locked. No person can access the doors even if

he/she has the authorized credenals, except the super users.

Capture

Capture a picture manually.

Note

The Capture buon is available when the device supports capture funcon. The picture is

saved in the PC running the client. For seng the saving path, refer to Set File Saving Path in

the user manual of the client soware.

Result

The icon of the doors will change in real-me according to the operaon if the operaon is

succeeded.

8.9.2 Check Real-Time Access Records

The real-me access records can be displayed in the client, including card swiping records, face

recognion records, skin-surface temperature informaon, etc. Also, you can view the person

informaon and view the picture captured during access.

Before You Start

You have added person(s) and access control device(s) to the client. For details, refer to Person

Management and Add Device .

Steps

Click Monitoring to enter monitoring module.

Real-me access records are displayed on the boom of the page. You can view record details,

including card No., person name, event

me, door locaon, temperature, authencaon type

etc.

Figure 8-11

Real-me Access Records

Swing Barrier User Manual

114

Note

You can right click the column name of access event table to show or hide the column according

to actual needs.

Oponal: Select an access point group from the drop-down list in the upper-right corner to

show the real

me access records of the selected group.

Oponal: Check the event type and event status.

The detected events of checked type and status will be displayed in the list below.

Oponal: Check Show Latest Event to view the latest access record.

The record list will be listed reverse chronologically.

Oponal: Check Enable Abnormal Temperature Prompt to enable abnormal skin-surface

temperature prompt.

Note

When enabled, if there is abnormal temperature informaon, an Abnormal Temperature

window pops up when you enter Monitoring module, displaying person's picture, skin-surface

temperature, card No., person name, etc.

Oponal: Click an event to view person pictures (including captured picture and prole).

Note

In Linked Capture Picture eld, you can double click the captured picture to view an enlarged

picture.

Oponal: Click to view details (including person's detailed informaon and the captured

picture).

Note

In the pop-up window, you can click to view details in full screen.

Swing Barrier User Manual

115

Appendix A. Tips for Scanning Fingerprint

Recommended Finger

Forenger, middle nger or the third nger.

Correct Scanning

The gure displayed below is the correct way to scan your nger:

You should press your nger on the scanner horizontally. The center of your scanned nger should

align with the scanner center.

Incorrect Scanning

The gures of scanning ngerprint displayed below are incorrect:

Swing Barrier User Manual

116

Environment

The scanner should avoid direct sun light, high temperature, humid condions and rain.

When it is dry, the scanner may not recognize your

ngerprint successfully. You can blow your

nger and scan again.

Others

If your ngerprint is shallow, or it is hard to scan your ngerprint, we recommend you to use other

authencaon methods.

If you have injuries on the scanned nger, the scanner may not recognize. You can change another

nger and try again.

Swing Barrier User Manual

117

Appendix B. DIP Switch

B.1 DIP Switch Descripon

The DIP switch is on the access control board. No.1 and No 2 is from the low bit to the high bit.

Figure B-1 DIP Switch

When the switch is towards ON, it means the switch is enabled, otherwise, the switch is o.

B.2 DIP Switch Corresponded

Funcons

Note

Aer seng the DIP switch, you should reboot the device, or the funcon cannot take eect.

The 2-bit DIP switch corresponded funcons on the access control board are as follows:

Bit

Device Mode Funcon Decimal Value DIP Switch

Address Diagram

1 Work Mode Normal Mode 0

Study Mode 1

2 Keyfob Paring

Mode

Disable Keyfob

Paring Mode

Enable Keyfob

Paring Mode

Swing Barrier User Manual

118

Appendix C. Error Code Descripon

The swing barrier will display the error code on the seven-segment display if error occurred. Refer

to the table below to

nd the descripon of each number.

Error Reason Code Error Reason Code

The First IR Beam Triggered 01 The Eighteenth IR Beam

Triggered

The Second IR Beam Triggered 02 The Nineteenth IR Beam

Triggered

The Third IR Beam Triggered 03 The Tweneth IR Beam

Triggered

The Fourth IR Beam Triggered 04 The Twenty-First IR Beam

Triggered

The Fih IR Beam Triggered 05 The Twenty-Second IR Beam

Triggered

The Sixth IR Beam Triggered 06 The Twenty-Third IR Beam

Triggered

The Seventh IR Beam Triggered 07 The Twenty-Fourth IR Beam

Triggered

The Eighth IR Beam Triggered 08 Authencaon Indicator Board

(Entrance) Oine

The Ninth IR Beam Triggered 09 Authencaon Indicator Board

(Exit) Oine

The Tenth IR Beam Triggered 10 IR Adapter Board Oine 51

The Eleventh IR Beam Triggered 11 Interconnecng Excepon 53

The Twelh IR Beam Triggered 12 Not Studying 54

The Thirteenth IR Beam

Triggered

13 Obstrucon 55

The Fourteenth IR Beam

Triggered

14 Exceeding Studying Range 56

The Fieenth IR Beam

Triggered

15 Encoder Excepon 57

Swing Barrier User Manual

119

Error Reason Code Error Reason Code

The Sixteenth IR Beam

Triggered

16 Motor Excepon 58

The Seventeenth IR Beam

Triggered

17 Extended Interface Board

Oine (If the board is not

installed, the error code of "59"

will appear but the device

funcons normally)

Swing Barrier User Manual

120

Appendix D. Communicaon Matrix and Device

Command

Communicaon Matrix

Scan the following QR code to get the device communicaon matrix.

Note that the matrix contains all

communicaon ports of Hikvision access control and video

intercom devices.

Figure D-1 QR Code of Communicaon Matrix

Device Command

Scan the following QR code to get the device common serial port commands.

Note that the command list contains all commonly used serial ports commands for all Hikvision

access control and video intercom devices.

Figure D-2 Device Command

Swing Barrier User Manual

121

UD31575B-A

Hikvision DS-K3B802BX Ultra Swing Barriers

Product's Documents

User Manual

Specifications

Hikvision DS-K3B802BX Questions and Answers
