9L Dual Air Fryer
Model No. SDA2616
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9L Dual Air Fryer
Model No. SDA2616
User Manual
Contents
Page No.
2 Contents
3 Reading and Storing the User Manual
3 Important Safety Instructions for Proper Use
6 Additional Safety Information
7 Explanation of Symbols
7 Introduction
8 Description of Parts
8 Description of Control Panel
9 Before the First Time You Use Your Air Fryer
9 Control Panel Functions
11 Cooking Preset Functions
11 Instructions for Use
12 Cooking with Your Air Fryer
13 Hints and Tips
13 Cleaning and Maintenance
14 Cooking Timings, Temperature and Quantity
15 Troubleshooting Guide
16 Technical Specification
16 Plug Wiring Information
16 Recycling Information
17 Recipes for You to Try
19 Customer Support
Back Page Warranty Information
3
9L Dual Air Fryer
Model No. SDA2616
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this
manual carefully paying particular attention to the
safety instructions. Failure to do so may result in
personal injury or damage to the product.
Carefully save this instruction manual for future reference.
Ensure the user manual is included when passing the product on
to any third parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
Whilst using electrical appliances, basic safety precautions
should always be followed.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to
property or persons.
The manufacturer or vendor cannot be held liable for damages
or injury incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Air Fryer.
• Before plugging your unit into the mains, visually check
that it is intact and has not suffered any transit damage.
• Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
• DO NOT use this product with a programmer, timer,
separate remote-control system or any other such device.
• DO NOT immerse this appliance in water or any other
liquids.
• Cooking appliances should be positioned in a stable
situation with the handles (if any) positioned to avoid
spillage of liquids.
• DO NOT touch hot surfaces. Accessible surfaces
are liable to get hot during use. Always use the
handles provided.
• Oven gloves should be used whilst using this appliance.
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9L Dual Air Fryer
Model No. SDA2616
User Manual
• Close supervision is required when using this appliance
near children.
• Never leave this appliance within reach of children.
• This appliance shall not be used by children from 0 to 8
years.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the appliance.
• Keep the appliance and its cord out of reach of children
less than 8 years.
• Cleaning and user maintenance shall not be made by
children.
• DO NOT leave the appliance unattended during use.
• DO NOT leave the appliance unattended whilst connected
to the mains supply.
• Always use this appliance on a solid, level, non-flammable
surface.
• DO NOT use this appliance outdoors.
• It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
• Regular, periodic checks should be carried out on the
supply cord to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
• If the supply cord is damaged it is to be replaced by a
qualified person in order to avoid a hazard.
• DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
5
9L Dual Air Fryer
Model No. SDA2616
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
damaged in any way.
• DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
• Allow the unit to cool before storage.
• Never place the appliance near to flammable material or
high-pressure containers.
• This appliance is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
the supplier.
• DO NOT use this appliance for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
• Ensure appliance is situated in an open area, do not allow
it to come in contact with cupboards, curtains, wall
coverings, clothing or other flammable materials.
• Unplug after each use. Grasp the plug, not the cord.
• DO NOT cover this appliance.
• Never place this appliance on an electric, gas, or any other
type of hob.
WARNING! Do not attempt to move the air fryer whilst
it is hot or contains hot food or liquids. Turn the
appliance off and disconnect from the mains and let it
cool sufficiently before moving it.
WARNING! Hot steam may be released when opening
and closing the appliance during use. Risk of scalding!
WARNING! Always carry the appliance with both
hands. Always use oven gloves. Burn hazard!
THIS APPLIANCE MUST BE EARTHED
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9L Dual Air Fryer
Model No. SDA2616
User Manual
Additional Safety Information
• PLEASE NOTE: Before use, ensure that the Air Fryer is used in
an open, well ventilated area well away from other
appliances and other obstructions.
• Do not use the Air Fryer in front of, near or below
combustible materials such as plastics, curtains or cupboards,
etc.
• Do not place the appliance against a wall or against other
appliances. Leave at least 10cm minimum free space on the
back and sides and 10cm minimum free space above the
appliance.
• Do not place anything on top of the appliance.
The diagram above shows the rear of the air
fryer and the air vent outlets arrowed.
Keep these areas free and clear from
obstructions as directed above.
7
9L Dual Air Fryer
Model No. SDA2616
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.
WARNING!
This symbol provides useful additional information on the use of
this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This symbol indicates that the surface gets hot and care must be
taken.
Introduction
This household Double Drawer Air Fryer cooks using very little or no cooking oil
for healthier cooking.
If a little oil is required for extra browning for example, use a moderate amount
of spray type cooking oil.
WARNING! DO NOT fill your Air Fryer with cooking oil as this will cause a
fire and scalding hazard.
DO NOT fill your Air Fryer with water as this will cause a scalding hazard.
DO NOT use metal cooking tools with this Air Fryer as damage may occur to the
non-stick coating. Only use wooden or plastic (nylon) tools with your Air Fryer.
This designates a hazard with moderate risk, which may result
in severe injury if not adhered to.
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9L Dual Air Fryer
Model No. SDA2616
User Manual
Description of Parts
Description of Control Panel (1)
2
3
1
1. Control Panel
2. Right Drawer
3. Drawer Handle (R)
4. Drawer Handle (L)
5. Left Drawer
6. Air Vent (on the rear)
7. Trivet (x2)
4
5
6
7
17
10. Power On/Off
11. Heat Indicator (L)
12. Left LED Display
13. Right LED Display
14. Heat Indicator (R)
15. Start/Pause
16. Cooking Pre-set Menu
10
16
17. Temperature Setting (-)
18. Temperature Setting (+)
19. Left Drawer Control
20. Sync Finish
21. Right Drawer Control
22. Time Setting (-)
23. Time Setting (+)
11
12
13
14
15
18
19
20
21
22
23
9
9L Dual Air Fryer
Model No. SDA2616
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Before First Use of Your Air Fryer
• Remove all packing materials and discard responsibly.
• Ensure all parts are present see Description of Parts above.
• Ensure that you clean your Air Fryer before first and every use with a damp cloth
and dry thoroughly.
• Wash the two Drawers (2 & 5) and the two Trivets (7) in warm soapy water.
• DO NOT remove the silicone feet from the Trivets (7) as these are fitted to hold
the Trivet in place and prevent damage to the drawers.
• Whilst using your Air Fryer for the first time you may notice a little smoke and
odour; this is normal and simply the protective grease used during manufacture
and will soon pass.
Control Panel Functions
Power On/Off Button (10)
• The Power On/Off (10) button will illuminate once the fryer is plugged in.
• Press the Power On/Off (10) button to switch the unit on, the Left & Right
Drawer Control (19 & 21) buttons will illuminate.
• The air fryer will switch to standby mode if no selection is made within 1 minute
and only the Power On/Off (10) button will remain illuminated.
• Press the Power On/Off (10) button again to switch the unit off.
• At the end of cooking, both the Left & Right LED Displays (12 & 13) will show
“End”, the fan will continue to run for a short while to cool the fryer after use.
Left & Right LED Displays (12 & 13)
• The Left & Right LED Displays (12 & 13) will show the set temperature and both
the set and remaining cooking time.
Start/Pause Button (15)
• Press the Start/Pause button (15) to start or pause cooking.
Temperature Setting Buttons (17 & 18)
• Press the Temperature Setting buttons (17 & 18) to adjust the cooking
temperature to override pre-set functions where required.
• The temperature will increase or decrease in 5°C increments.
• Press and hold to fast cycle from minimum 80°C to maximum 200°C for all pre-
set functions except Dehydrate (30°C -100°C).
Drawer Control Buttons (19 & 21)
• Press the Left Drawer Control (19) to select the Left Drawer (5). The button will
flash when pressed.
• Press the Right Drawer Control (21) to select the Right Drawer (2). The button
will flash when pressed.
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9L Dual Air Fryer
Model No. SDA2616
User Manual
Cooking Pre-Sets (16)
• Select one of the 8 pre-set cooking programs from the Cooking Pre-Set
Functions below. The selected program will flash when pressed, the time and
temperature will be automatically set.
• Press the Start/Pause button (15) to start cooking immediately.
• The pre-set cooking programs can be overridden by pressing the Temperature
Setting buttons (17 & 18) or Time Setting buttons (22 & 23) to set the desired
temperature and time accordingly.
The Air Fryer is pre-programmed with 8 pre-set cooking times and temperatures
as follows:
Pre-set
Default
Temp
Default Time
Temperature
Range
Time Range
Rollover Reminder
Fries
200⁰C
28 minutes
80⁰C-200⁰C
1-60 mins
Remind at 10 &
20 mins
Wings
200⁰C
20 minutes
80⁰C-200⁰C
1-60 mins
Remind at 10 mins
Seafood
200⁰C
18 minutes
80⁰C-200⁰C
1-60 mins
Remind at 9 mins
Bacon
180⁰C
6 minutes
80⁰C-200⁰C
1-60 mins
N/A
Roast
200⁰C
25 minutes
80⁰C-200⁰C
1-60 mins
Remind at 10 &
20 mins
Bake
180⁰C
12 minutes
80⁰C-200⁰C
1-60 mins
N/A
Vegetables
160⁰C
20 minutes
80⁰C-200⁰C
1-60 mins
N/A
Dehydrate
65⁰C
8 Hours
30⁰C-100⁰C
1-12 Hours
N/A
Cooking time will vary according to size, weight and personal preference. Always
check the internal temperature of chicken and meats before eating.
There is a Rollover reminder during
cooking, it will beep and “trn” will show
on the corresponding LED Display.
Time Setting Button (22 & 23)
• Press the Time Setting buttons (22 & 23) to adjust the cooking time to override
pre-set functions where required.
• The time will increase or decrease in 1 minute increments.
• Press and hold to fast cycle from minimum of 1 minute to maximum 60 minutes
for all pre-set functions except Dehydrate (1H-12H).
11
9L Dual Air Fryer
Model No. SDA2616
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Sync Finish (20)
• Press the Sync Finish button (20) so that both drawers complete cooking at the
same time.
• Set both drawers to the desired cooking time and temperature, then press the
Sync Finish button (20).
• The drawer with the shorter cooking time will show “---" on the corresponding
LED Display as the air fryer synchronizes the final cooking times.
• The air fryer will start cooking with the drawer set to the longer cooking time,
the second drawer with the shorter cooking time, will start afterwards to ensure
that both drawers cooking times conclude at the same time.
Example If the cooking time for the Right Drawer (2) is 20 minutes and the
cooking time for the Left Drawer (5) is 14 minutes, the Left Drawer (5) would
begin cooking 6 minutes after the Right Drawer (2) so that the two drawers finish
at the same time.
Instructions for Use
Place the air fryer on a solid, level, heat resistant
surface clear of all obstructions as described above.
Insert the mains plug into an outlet socket.
WARNING! Take care whilst handling the Air Fryer Drawer, use of Oven
Gloves are recommended.
1. Before use, remove the Right Drawer (2) and Left Drawer (5).
2. Ensure that both Trivets (7) are placed in the bottom of the air fryer drawers
with the silicone feet fitted as shown below.
3. Slide the drawers back into the Air Fryer ensuring that if they are pushed fully
home.
The Air Fryer will not function and
show “OUt” on the corresponding LED
Display if the drawers are not pushed
fully into the Air Fryer.
The Trivets (7) must be fitted to the base of each Air Fryer Drawer as they lift
the food clear of the base and provide air circulation around the food for
efficient cooking.
12
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9L Dual Air Fryer
Model No. SDA2616
User Manual
Cooking with Your Air Fryer
1. Carefully remove the Air Fryer Drawer from the Air Fryer. The Air Fryer can be
used with one or both drawers. Ensure that the Trivets (7) are placed in the
bottom of both drawers.
DO NOT remove the silicon feet from the Trivet as they hold the trivet in place
and prevent damage to the drawers.
2. Place the food to be cooked into the Air Fryer Drawer ensuring that there is
adequate room left for the air to circulate, do not fill to the brim. Insert the
drawer back into the air fryer ensuring that the drawer is pushed fully home.
The Air Fryer will not operate if the Air Fryer Drawer is removed or not pushed
all the way in.
3. Press the Power On/Off (10) button to
switch the unit on then the Left & Right
Drawer Control (19 & 21) buttons will
illuminate as shown right.
4. Press the Left or Right Drawer Control
button (19 or 21) to select the required
drawer, the corresponding drawer
control will flash, then the Cooking Pre-
Set Menu (16), Temperature Setting (17
& 18), Sync Finish (20) and Time Setting
buttons (22 & 23) will illuminate.
5. Select the desired Cooking Pre-Set from one of the 8 available using the
Cooking Pre-Set Menu (16) button. The pre-set cooking programs can be
overridden by pressing the Temperature Setting (17 & 18) and Time Setting
buttons (22 & 23) to set the desired temperature and time accordingly.
6. Alternatively, press the Temperature Setting (17 & 18) and Time Setting
buttons (22 & 23) to set the temperature and time manually according to the
chosen recipe.
7. Repeat the above step 4 or 5 to use the other drawer. If the cooking times are
different between drawers, press the Sync Finish (20) button so that the two
drawers will finish cooking at the same time.
8. Press the Start/Pause (15) button to start cooking.
13
9L Dual Air Fryer
Model No. SDA2616
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9. At the end of the cooking, the Left &
Right LED Displays (12 & 13) will show
“End” and the fan will continue to run for
a short while to cool the fryer. After that
it will beep 3 times indicating that the
drawers can now be removed.
10. Remove the Air Fryer Drawer(s) and serve. (Place the drawer on a heat proof
surface if it is put down during serving).
WARNING! Take care whilst handling the Air Fryer Drawers, use of Oven
Gloves are recommended.
DO NOT use metal cooking tools with this Air Fryer as damage may occur to the
non-stick coating. Only use wooden or plastic (nylon) tools with your Air Fryer.
Hints and Tips
• This household Litre Air Fryer cooks using very little or no cooking oil for
healthier cooking.
• If a little oil is required for extra browning for example, use a moderate amount
of spray type cooking oil.
• DO NOT fill your Air Fryer with cooking oil as this will cause a fire and scalding
hazard.
• The Air Fryer will quickly cook your food using rapid cycling airflow of hot air.
• DO NOT use metal cooking tools or harsh abrasive chemicals with this Air Fryer
as damage may occur to the non-stick coating. Only use wooden or plastic
(nylon) tools with your Air Fryer.
Cleaning and Maintenance
• Always unplug the Air Fryer from the mains supply and allow to cool before
cleaning.
• DO NOT clean any part of the Air Fryer in a dishwasher – NOT dishwasher safe.
• DO NOT submerge any part of the main body, the mains cable or mains plug in
water or any other liquids.
• Wipe excess oil from the Air Fryer Drawers and Trivets with kitchen roll or
similar.
• Wipe the main body of the Air Fryer clean using a soft, damp cloth.
• The Air Fryer Drawers and Trivets can be washed in warm soapy water, rinse and
dry thoroughly before reusing.
• Remove the silicone feet from the Trivets (7) before washing so they do not get
lost. Replace the silicone feet after drying the Trivets (7).
14
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9L Dual Air Fryer
Model No. SDA2616
User Manual
• DO NOT remove the silicone feet from the Trivets (7) as these are fitted to hold
the Trivet in place and prevent damage to the Fryer Drawers.
• Never clean any part of the Air Fryer with harsh or abrasive cleaners.
• After cleaning, allow the product to thoroughly dry before re-use.
Cooking Timings, Temperatures and Quantity
Food Product
Min-Max
Amount (g)
Time
(min)
Temperature
(C)
Shake/
Turn
Additional
Information
Chips & Potatoes
Thin Frozen
Chips
200-400
15-20
200
Shake
Thick Frozen
Chips
200-400
20
200
Shake
Home-made
Chips (8x8mm)
200-350
18-25
180
Shake
Add ½ tbsp. of oil
Home-made
Potato Wedges
200-350
18-22
180
Shake
Add ½ tbsp. of oil
Home-made
Potato Cubes
200-400
12-18
180
Shake
Add ½ tbsp. of oil
Rosti
200
15-18
180
Turn
Potato Gratin
500
18-22
180
Meat & Poultry
Steak
100-300
8-14
180
Turn
Pork Chops
100-300
10-14
180
Turn
Hamburger
100-300
7-14
180
Turn
Sausage Roll
100-300
13-15
180
Turn
Chicken
Drumsticks
100-400
18-22
180
Turn
Chicken Breast
100-400
10-15
180
Turn
Frozen Chicken
Nuggets
100-300
6-10
200
Shake
Use oven ready
Snacks
Spring Rolls
100-300
8-10
200
Shake
Use oven ready
Stuffed
Vegetables
100-300
10
160
Frozen
Breadcrumbed
Cheese Snacks
100-300
8-10
180
Turn
Use oven ready
Fish
Frozen Fish
Fingers
100-300
6-10
200
Turn
Use oven ready
15
9L Dual Air Fryer
Model No. SDA2616
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Troubleshooting Guide
Problem
Possible Cause
Possible Fix
Food is overcooked or
burnt
Cooking temperature is
set too high.
Check cooking
temperature and decrease
accordingly.
Cooking time is too long.
Check cooking time and
decrease accordingly.
Food is not evenly
cooked
Certain foods require
turning or shaking part.
way through cooking
See ‘Cooking with Your Air
Fryer’ above.
Food is undercooked
Cooking temperature is
set too low.
Check cooking
temperature and increase
accordingly.
Cooking time is too
short.
Check cooking time and
increase accordingly.
The Air Fryer Drawer has
been overfilled.
Ensure that the Air Fryer
Drawer is not filled to the
brim and leave a 3-4cm
area free for the air to
circulate.
The Trivets (7) have not
been fitted to the base
of the Air Fryer Drawers
reducing air flow.
Ensure the Trivets are
inserted into the base of
the Air Fryer Drawers and
the silicone feet are fitted.
Unit does not power up
LED Display is not
illuminated.
Press the Power On/Off
(10) button on the Control
Panel (1).
No power to the Air
Fryer.
Check that the mains plug
is inserted into the socket
and the socket is switched
on (if applicable).
The Air Fryer Drawer not
inserted or not pushed
fully home.
Ensure the Drawer is
inserted and pushed fully
home.
Burning smell from unit
Food trapped under
Trivets.
Ensure Air Fryer Drawers
and Trivets are clean.
Previous food remains
on Air Fryer Drawers or
Trivets.
16
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9L Dual Air Fryer
Model No. SDA2616
User Manual
Technical Specification
Model No.
SDA2616
Rated Voltage
220-240V~ 50/60Hz
Rated Power
1800-2000W
Protection Class
I (This Appliance must be Earthed)
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing. If in doubt, consult a qualified electrician.
If you need to remove the plug – DISCONNECT FROM THE MAINS – and then cut
it off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
17
9L Dual Air Fryer
Model No. SDA2616
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Place the potato strips into the Fryer Drawer, insert the drawer back into the Air fryer and set the timer
for 15-20 minutes - depending on the number of fries or until the fries are golden brown.
For best results, turn the fries by shaking the Fryer Drawer in the middle of cooking.
Recipes for You to Try……
1. Asian Spicy Fries
Potato x4 / 600g
Oi 2 teaspoons
Salt 1 teaspoon
Pepper powder 1 teaspoon
Shallot powder 1 teaspoon
Red chili powder ½ teaspoon
● Peel potatoes and cut into strips;
● Soak potato strips in salt water for at least
20mins, and then dry with kitchen paper.
● Mix shallot, salt and pepper, garlic powder/
garlic oil, red chili powder, stir in the potato
strips.
● Set temperature to 180 degrees and time
to 5 minutes to preheat the air fryer.
2. Golden Chicken Wings
Chicken wings 500g
Garlic x2
Ginger powder 2 teaspoon
Cumin powder 1 teaspoon
Black pepper powder 1 teaspoon
Sweet chili sauce 100 mg
● Set temperature to 200 degrees and timer
to 5 minutes to preheat the air fryer.
● Stir garlic, ginger powder, cumin powder,
spicy black pepper and a little salt together,
and then coat the chicken wings.
● Allow the chicken wings to stand for 20
minutes.
• Place the chicken wings into the fryer drawer evenly, set the time for 15-20 minutes and the
temperature for 200 degrees.
18
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9L Dual Air Fryer
Model No. SDA2616
User Manual
3. Fried chicken nuggets
Fresh chicken nuggets 500g
Eggs x3
Flour 1 cup
Olive oil 1 spoon
White pepper powder 1 teaspoon
● Set the temperature to 200 degrees and
the time to 5 minutes to preheat the air
fryer.
● Pat the chicken for 5 minutes with a knife
blade.
● Stir eggs, flour, olive oil, white pepper
and a little salt together, and then coat the
chicken nuggets.
● Allow the nuggets to stand for 20
minutes.
• Place the chicken nuggets into the fryer drawer evenly, set the time for 15-20 minutes and the
temperature for 200 degrees.
4. Fried squid
Squid (Frozen) 500g
Oil 2 tablespoon
Salt 1 teaspoon
Cumin powder 1 teaspoon
Chicken powder 1 teaspoon
Pepper powder 1 teaspoon
● Set the temperature to 200 degrees and
the timer to 5 minutes to preheat the air
fryer.
● Stir seasoning together, and then coat
the squid and allow to stand for 20
minutes.
• Place the squid into the fryer drawer, set the temperature for 200 degrees and the time for 12-15
minutes or until golden brown.
19
9L Dual Air Fryer
Model No. SDA2616
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Rinse the Prawns.
• Apply a thin layer of salad oil to the prawns, place the prawns into the fryer drawer, select the ‘Shrimp’
Preset and the temperature for 200 degrees and the cooking time for 5-8 minutes or until a golden
crunchy layer has formed.
• Shake the Fryer Draw ⅔ through cooking to ensure even cooking.
5. Spicy Shrimp
Unfrozen prawns x10
Salad Oil 2 tsp
Garlic finely chopped x1
Black pepper 1 tsp
Chili powder 1 tsp
Sweet chili sauce 100mg
20
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9L Dual Air Fryer
Model No. SDA2616
User Manual
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
