Dji MINI SE User Manual

2024.01

v1.0

User Manual

Searching for Keywords

Search for keywords such as “battery” and “install” to find a topic. If you are using Adobe

Acrobat Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to

begin a search.

Navigating to a Topic

View a complete list of topics in the table of contents. Click on a topic to navigate to that

section.

Printing this Document

This document supports high resolution printing.

Using this Manual

Legend

Warning Important Hints and Tips Reference

Read Before the First Flight

Read the following documents before using the DJI

Mini SE:

1. In the Box

2. User Manual

3. Quick Start Guide

4. Disclaimer and Safety Guidelines

It is recommend to watch all tutorial videos on the ocial DJI website and read the disclaimer and safety

guidelines before using for the rst time. Prepare for your rst ight by reviewing the quick start guide

and refer to this user manual for more information.

* For increased safety, ﬂight is restricted to a height of 98.4 ft (30 m) and range of 164 ft (50 m) when not

connected or logged into the app during ﬂight. This applies to DJI Fly and all apps compatible with DJI

aircraft.

The operating temperature of this product is 0° to 40° C. It does not meet the standard operating

temperature for military grade application (-55° to 125° C), which is required to endure greater

environmental variability. Operate the product appropriately and only for applications that it meets the

operating temperature range requirements of that grade.

DJI Fly App

Fly Spots

Altitude Zone (120m)

Connect Aircraft

Proﬁle

Skypixel

Album

Academy

Download the DJI Fly App

Make sure to use DJI Fly during ight. Scan the QR code on the right to download the

latest version.

The Android version of DJI Fly is compatible with Android v6.0 and later. The iOS version

of DJI Fly is compatible with iOS v10.0.2 and later.

Video Tutorials

Go to the address below or go to Academy in DJI Fly to watch the DJI Mini SE tutorial

videos, which demonstrate how to use the DJI Mini SE safely:

https://www.dji.com/mini-se/video

Contents

Using this Manual

Legend

Read Before the First Flight

Download the DJI Fly App

Video Tutorials

Download DJI Assistant 2 for Mavic

Product Prole

Introduction

Feature Highlights

Preparing the Aircraft

Preparing the Remote Controller

Aircraft Diagram

Remote Controller Diagram

Activation

Aircraft

Flight Modes

Aircraft Status Indicator

Return to Home

Vision System and Infrared Sensing System

Intelligent Flight Mode

Flight Recorder

Propellers

Intelligent Flight Battery

Gimbal and Camera

Remote Controller

Remote Controller Prole

Using the Remote Controller

Optimal Transmission Zone

Linking the Remote Controller

DJI Fly App

Home

Camera View

Flight

Flight Environment Requirements

Flight Limits and GEO Zones

Pre-Flight Checklist

Auto Takeoff/Landing

Starting/Stopping the Motors

Flight Test

Appendix

Specications

Calibrating the Compass

Firmware Update

After-sales information

Product Prole

This section introduces DJI Mini SE and

lists the components of the aircraft and

remote controller.

Product Prole

Introduction

Featuring a Downward Vision System and Infrared Sensing System, DJI Mini SE can hover and fly

indoors as well as outdoors and Return to Home automatically. With a fully stabilized 3-axis gimbal and

1/2.3” sensor camera, DJI Mini SE shoots 2.7K video and 12 MP photos.

Feature Highlights

DJI Mini SE boasts a foldable design and an ultralight weight of less than 249 g. The Intelligent Flight

Mode QuickShots provide four sub modes, which can automatically shoot and generate dierent styles

of video.

Using the advanced DJI flight controller, DJI Mini SE is able to provide a safe and reliable flight

experience. The aircraft is able to automatically return to its Home Point when the remote controller

signal is lost or the battery level is low, as well as being able to hover indoors at low altitudes.

DJI's enhanced Wi-Fi technology is built into the remote controller, supporting both 2.4 GHz and 5.8 GHz

frequencies and a transmission range of up to 2.49 mi (4 km), making it possible to stream 720p video to

your mobile device.

DJI Mini SE has a maximum ight speed of 29 mph (46.8 kph) and a maximum ight time of 30 minutes,

while the maximum runtime of the remote controller is 4.5 hours.

Preparing the Aircraft

All aircraft arms are folded before the aircraft is packaged. Follow the steps below to unfold the aircraft

arms.

1. Remove the gimbal cover from the camera.

2. Unfold the front arms.

3. Unfold the rear arms and then unfold all the propellers.

Maximum ight time was tested in an environment with no wind while ying at a consistent 10.5 mph

(17 kph) and the maximum ight speed was tested at sea level altitude with no wind. These values

are for reference only.

The remote controller reaches its maximum transmission distance (FCC) in a wide-open area with

no electromagnetic interference at an altitude of approx. 400 ft (120 m). The maximum transmission

distance refers to the maximum distance that the aircraft can still send and receive transmissions. It

does not refer to the maximum distance the aircraft can y in a single ight. The maximum runtime

was tested in a laboratory environment and without charging the mobile device. This value is for

reference only.

5.8 GHz is not supported in some regions. This frequency band will automatically be disabled in

these regions. Observe local laws and regulations.

DJI Mini SE User Manual

It is recommended to install a gimbal protector to protect the gimbal when the aircraft is not in use.

Unfold the front arms before unfolding the rear arms.

Make sure the gimbal cover is removed and all arms are unfolded before powering on the

aircraft. Otherwise, it may affect the aircraft self-diagnostics.

Preparing the Remote Controller

1. Unfold the mobile device clamps and the antennas.

2. Remove the control sticks from their storage slots on the remote controller and screw them into

place.

3. Choose an appropriate remote controller cable based on the type of mobile device. A Lightning

connector cable, Micro USB cable, and USB-C cable are included in the packaging. Connect the

end of the cable with the DJI logo to the remote controller and the other end of the cable to your

mobile device. Secure your mobile device by pushing both clamps inward.

If a USB connection prompt appears when using an Android mobile device, select the option to

charge only. Otherwise, it may result in connection failure.

4. All Intelligent Flight Batteries are in hibernation mode before shipment to ensure safety. Use the USB

charger to charge and activate Intelligent Flight Batteries for the rst time. It is recommended to use

a USB charger with a power of 18W or higher for fast-charging.

DJI Mini SE User Manual

Aircraft Diagram

Remote Controller Diagram

1. Gimbal and Camera

2. Power Button

3. Battery Level LEDs

4. Downward Vision System

5. Infrared Sensing System

6. Motors

7. Propellers

8. Antennas

9. Battery Compartment Cover

10. Charging Port (USB-C)

11. microSD Card Slot

12. Aircraft Status Indicator

1. Antennas

Relay aircraft control and video wireless

signals.

2. Power Button

Press once to check the current battery level.

Press once, then again, and hold to turn the

remote controller on or off.

3. Control Sticks

Use the control sticks to control the aircraft

movements. Set the flight control mode in DJI

Fly. The control sticks are removable and easy to

store.

4. Battery Level LEDs

Displays the current battery level of the remote

controller.

5. Flight Pause and Return to Home (RTH)

Button

Press once to make the aircraft brake. If the

DJI Mini SE User Manual

Activation

DJI Mini SE requires activation before using for the rst time. After powering on the aircraft and remote

controller, follow the on-screen instructions to activate DJI Mini SE using DJI Fly. An internet connection

is required for activation.

aircraft is performing a QuickShot, Intelligent

RTH, or auto landing, press once to make the

aircraft exit the procedure and hover in place.

Press and hold the button to initiate RTH. The

aircraft returns to the last recorded Home Point.

Press again to cancel RTH.

6. Remote Controller Cable

Connect to a mobile device for video linking via

the remote controller cable. Select the cable

according to the mobile device.

7. Video-Downlink/Power Port (Micro USB)

Connect to a mobile device for video linking via

the remote controller cable. Connect to the USB

charger to charge the remote controller battery.

8. Control Sticks Storage Slots

For storing the control sticks.

9. Mobile Device Clamps

Used to securely mount your mobile device to

the remote controller.

10. Gimb

al Dial

Controls the camera's tilt.

1. Re

cord Button

In video mode, press once to start recording.

Press again to stop recording. In photo mode,

press once to switch to video mode.

12. S

hutter Button

In photo mode, press once to take a photo

according to the mode selected in DJI Fly. In

video mode, press once to switch to photo

mode.

Aircraft

DJI Mini SE contains a ight controller,

video downlink system, vision system,

propulsion system, and an Intelligent

Flight Battery.

Aircraft

DJI Mini SE contains a ight controller, video downlink system, vision system, propulsion system, and an

Intelligent Flight Battery.

Flight Modes

DJI Mini SE has three ight modes: Position, Sport, and CineSmooth. Users can switch between modes

in DJI Fly.

Position Mode: Positon mode works best when the GPS signal is strong. The aircraft utilizes GPS and

the Vision System to locate itself and stabilize. Intelligent Flight Mode is enabled in this mode. When the

Downward Vision System is enabled and lighting conditions are sucient, the maximum ight altitude

angle is 20° and the maximum ight speed is 8 m/s.

The aircraft automatically changes to Attitude (ATTI) mode when the Vision System is unavailable or

disabled and when the GPS signal is weak or the compass experiences interference. When the Vision

System is unavailable, the aircraft cannot position itself or brake automatically, which increases the risk

of potential ight hazards. In ATTI mode, the aircraft may be more easily aected by its surroundings.

Environmental factors such as wind can result in horizontal shifting, which may present hazards,

especially when ying in conned spaces.

Sport Mode: In Sport mode, the aircraft uses GPS and Vision System for positioning. In Sport mode,

aircraft responses are optimized for agility and speed making it more responsive to control stick

movements. The maximum ight speed is 13 m/s, maximum ascent speed is 4 m/s, and maximum

descent speed is 3 m/s.

CineSmooth Mode: CineSmooth mode is based on Position mode and the flight speed is limited,

making the aircraft more stable during shooting. The maximum ight speed is 4 m/s, maximum ascent speed

is 1.5 m/s, and maximum descent speed is 1 m/s.

The aircraft’s maximum speed and braking distance signicantly increase in Sport mode. A minimum

braking distance of 30 m is required in windless conditions.

Descent speed significantly increases in Sport mode. A minimum braking distance of 10 m is

required in windless conditions.

The aircraft’s responsiveness signicantly increases in Sport mode, which means a small control stick

movement on the remote controller translates into the aircraft moving a large distance. Be vigilant

and maintain adequate maneuvering space during ight.

DJI Mini SE User Manual

Aircraft Status Indicator

The aircraft status indicator is located at the rear of the aircraft. It communicates the status of the

aircraft’s ight control system. Refer to the table below for more information about the aircraft status

indicator.

Return to Home

The Return to Home (RTH) function brings the aircraft back to the last recorded Home Point. There are

three types of RTH: Smart RTH, Low Battery RTH, and Failsafe RTH. This section describes these three

types of RTH in detail. RTH will also be triggered if the video link is disconnected.

Aircraft Status Indicator

Aircraft Status Indicator States

Normal States Color Blinking/Solid Description of Aircraft State

Alternating red,

green, and yellow

Blinking

Powering on and performing self-diagonistic

tests

Yellow Blinks four times Warming up

Green Blinking slowly P-mode with GPS

Green

Periodically blinks

twice

P-mode with Downward Vision System

Yellow Blinking slowly

No GPS, or Downward Vision System (ATTI

mode)

Green Blinking quickly Braking

Warning States

Yellow Blinking quickly Remote controller signal lost

Red Blinking slowly Low battery

Red Blinking quickly Critically low battery

Red Blinking IMU error

Red Solid Critical error

Alternating red

and yellow

Blinking quickly Compass calibration required

DJI Mini SE User Manual

GPS

Description

Home

Point

The default Home Point is the rst location where the aircraft received a strong or

moderately strong GPS signal (where the icon shows white). It is recommended

to wait until the Home Point is successfully recorded before ying. After the Home

Point is recorded, the aircraft status indicator blinks green and a prompt appears

in DJI Fly. If it is necessary to update the Home Point during the ight (such as

if the user changes position), the Home Point can be manually updated under

Safety in System Settings on DJI Fly..

Smart RTH

If the GPS signal is suciently strong, Smart RTH can be used to bring the aircraft back to the Home

Point. Smart RTH is initiated either by tapping

in DJI Fly or by pressing and holding the RTH button

on the remote controller. Exit Smart RTH by tapping

in DJI Fly or by pressing the RTH button on the

remote controller.

Low Battery RTH

Low Battery RTH is triggered when the Intelligent Flight Battery is depleted to the point that the safe

return of the aircraft may be aected. Return home or land the aircraft immediately when prompted.

DJI Fly displays a warning when the battery level is low. The aircraft will automatically return to the Home

Point if no action is taken after a 10 second countdown.

The user can cancel RTH by pressing the RTH button on the remote controller. If RTH is cancelled

following a low battery level warning, the Intelligent Flight Battery may not have enough power for the

aircraft to land safely, which may lead to the aircraft crashing or being lost.

The aircraft will land automatically if the current battery level can only support the aircraft long enough

to descend from its current altitude. The user cannot cancel the auto landing but can use the remote

controller to alter the aircraft’s direction during the landing process.

Failsafe RTH

If the Home Point was successfully recorded and the compass is functioning normally, Failsafe RTH

automatically activates after the remote controller signal is lost for more than 11 seconds.

Other RTH Scenarios

If the video link signal is lost during ight while the remote controller is still able to control the movements

of the aircraft, there will be a prompt to initiate RTH. RTH can be cancelled.

RTH Procedure

1. The Home Point is recorded.

2. RTH is triggered.

3. If the altitude is lower than 20 m, the aircraft ascends to the RTH altitude or 20 m, and then adjusts

its orientation. If the altitude is higher than 20 m, the aircraft adjusts its orientation immediately.

a. If the aircraft is further than 20 m from the Home Point when the RTH procedure begins, it ascends

to the preset RTH altitude and ies to the Home Point at a speed of 8 m/s. If the current altitude is

higher than the RTH altitude, the aircraft ies to the Home Point at the current altitude.

DJI Mini SE User Manual

1 Record Home Point 2 Conrming Home Point

4 Signal Lost for Extended Time

RTH (adjustable altitude)

Height over HP ≥ Failsafe Altitude

Elevate to Failsafe Altitude

Height over HP < Failsafe Altitude

Failsafe Altitude

6 Landing

3 Remote Controller Signal Lost

The aircraft cannot return to the Home Point if the GPS signal is weak or unavailable. If the GPS

signal become weak or unavailable after RTH is triggered, the aircraft will hover in place for a

while, and then start landing.

It is important to set a suitable RTH altitude before each ﬂight. Launch DJI Fly, and then set the

RTH altitude. In Smart RTH and Low Battery RTH, the aircraft automatically ascends to the RTH

altitude. If the aircraft is at an altitude of 65 ft (20 m) or higher and has not yet reached the RTH

altitude, the throttle stick can be moved to stop the aircraft from ascending. The aircraft will ﬂy

directly to the Home Point at its current altitude.

During RTH, the aircraft’s speed, altitude, and the orientation can be controlled using the remote

controller if the remote controller signal is normal, but the direction of ight cannot be controlled.

GEO zones will affect RTH. If the aircraft ﬂies into a GEO zone during RTH it will hover in place.

The aircraft may not be able to return to a Home Point when the wind speed is too high. Fly with

caution.

b. If the aircraft is less than 20 m from the Home Point when the RTH procedure begins, it lands

immediately.

5. After reaching the Home Point, the aircraft lands and the motors stop.

FailSafe RTH Illustration

Landing Protection

Landing Protection will activate during Smart RTH.

1. During Landing Protection, the aircraft will automatically detect and gently land on suitable ground.

2. If Landing Protection determines that the ground is not suitable for landing, DJI Mini SE will hover

and wait for pilot conrmation.

3. If Landing Protection is not operational, DJI Fly will display a landing prompt when DJI Mini SE

descends below 0.5 meters. Pull down on the throttle stick or use the auto landing slider to land.

DJI Mini SE User Manual

Vision System and Infrared Sensing System

DJI Mini SE is equipped with a Downward Vision System and Infrared Sensing System. The Downward

Vision System consists of one camera and the Infrared Sensing System consists of two 3D infrared

modules. The Downward Vision System and Infrared Sensing System help the aircraft maintain its

current position, hover in place more precisely, and to y indoors or in other environments where GPS is

unavailable.

Infrared Sensing System

Detection Fields

The Downward Vision System works best when the aircraft is at an altitude of 0.5 to 10 m, and its

operating range is 0.5 to 30 m.

Using the Vision System

When GPS is unavailable, the Downward Vision System is enabled if the surface has a discernable

surface and sucient light. The Downward Vision System works best when the aircraft is at an altitude

of 0.5 to 10 m. If the aircraft’s altitude is above 10 m, the Vision System may be aected, so extra

caution is required.

71°

56°

Downward Vision System

DJI Mini SE User Manual

Follow the steps below to use the Downward Vision System

1. Make sure the aircraft is on a at surface. Power on the aircraft.

2. The aircraft hovers in place after takeoff. The aircraft status indicator blinks green twice, which

indicates the Downward Vision System is working.

The max hover altitude of the aircraft is 5 m if there is no GPS. The Vision System works best when

the aircraft is at an altitude from 0.5 to 10 m. If the altitude of the aircraft is above 10 m, the Vision

System may be aected, so extra caution is required.

The Vision System may not function properly when the aircraft is ying over water or snow-covered

areas.

Note that the Vision System may not function properly when the aircraft is ying too fast. Fly with

caution when ying at over 10 m/s at 2 m (6.6 ft) or over 5 m/s at 1 m (3.3 ft).

The Vision System cannot work properly over surfaces that do not have clear pattern variations. The

Vision System cannot work properly in any of the following situations. Operate the aircraft cautiously.

a. Flying over monochrome surfaces (e.g., pure black, pure white, pure green).

b. Flying over highly reective surfaces.

c. Flying over water or transparent surfaces.

d. Flying over moving surfaces or objects.

e. Flying in an area where the lighting changes frequently or drastically.

f. Flying over extremely dark (< 10 lux) or bright (> 40,000 lux) surfaces.

g. Flying over surfaces that strongly reect or absorb infrared waves (e.g., mirrors).

h. Flying over surfaces without clear patterns or texture.

i. Flying over surfaces with repeating identical patterns or textures (e.g., tiles with the same design).

j. Flying over obstacles with small surface areas (e.g., tree branches).

Keep the sensors clean at all times. DO NOT tamper with the sensors. DO NOT use the aircraft in

environment with dust and humidity. DO NOT obstruct the Infrared Sensing System.

DO NOT y on days that are rainy, smoggy, or if there is limited visibility.

Check the following every time before takeo:

a. Make sure there are no stickers or any other obstructions over the Infrared Sensing and Vision

System.

b. If there is any dirt, dust, or water on the Infrared Sensing and Vision System, clean it with a soft

cloth. Do not use any cleanser that contains alcohol.

c. Contact DJI Support if there is any damage to the glass of the Infrared Sensing and Vision System.

Intelligent Flight Mode

DJI Mini SE supports QuickShots Intelligent Flight Mode. QuickShots shooting modes include Dronie,

Rocket, Circle, and Helix. DJI Mini SE records a video according to the selected shooting mode and

automatically generates videos approximately 15-second long. The video can be viewed, edited, or

shared to social media from playback.

Dronie: The aircraft ﬂies backward and ascends, with the camera locked on the subject.

Rocket: The aircraft ascends with the camera pointing downward.

Circle: The aircraft circles around the subject.

DJI Mini SE User Manual

Using QuickShots

1. Make sure that the Intelligent Flight Battery is suciently charged. Take o and hover at least 6.6 ft

(2 m) above the ground.

2 m

2. In DJI Fly, tap to select QuickShots and follow the prompts. Make sure that the user understands

how to use the shooting mode and that there are no obstacles in the surrounding area.

3. Select your target subject in the camera view by tapping the circle on the subject or dragging a box

around the subject. Choose a shooting mode and tap “Start” to begin recording. The aircraft ies

back to its original position once shooting is nished.

4. Tap

to access the video. The video can be edited and shared on social media after downloading

to your phone.

Exiting QuickShots

Press the Flight Pause/RTH button once or tap the in DJI Fly to exit QuickShots. The aircraft will

hover in place.

Helix: The aircraft ascends and spirals around the subject.

Start

Radius

50m

45m

40m

35m

30m

25m

20m

Helix

Cricle

Rocket

Dronie

Quickshot

Vedio


In Flight

RCRC

1.6m/s

7.9m/s

625m

+1.0+1.0

EVEV

1:30:26

1080p 30

DJI Mini SE User Manual

Attaching the Propellers

Attach the propellers with marks to the motors of the arm with marks and the unmarked propellers

to the motors of the arm without marks. Use the screwdriver to mount the propellers. Make sure the

propellers are secure.

MarksUnmarked

Flight Recorder

Flight data including flight telemetry, aircraft status information, and other parameters are

automatically saved to the internal data recorder of the aircraft. The data can be accessed using

DJI Assistant 2 (Consumer Drones Series).

Propellers

There are two types of DJI Mini SE propellers, which are designed to spin in dierent directions. Marks

are used to indicate which propellers should be attached to which motors. The two blades attached to

one motor are the same.

Propellers

With marks Without marks

Illustration

Mounting

Position

Attach to the motors of the arms with

marks

Attach to the motors of the arms

without marks

Use QuickShots at locations that are clear of buildings and other obstacles. Make sure that there

are no humans, animals, or other obstacles in the ﬂight path.

Pay attention to objects around the aircraft and use the remote controller to avoid accidents with

the aircraft.

DO NOT use QuickShots in any of the following situations:

a. When the subject is blocked for an extended period or outside the line of sight.

b. When the subject is more than 50 m away from the aircraft.

c. When the subject is similar in color or pattern with the surroundings.

d. When the subject is in the air.

e. When the subject moves fast.

f. The lighting is extremely low (< 300 lux) or high (> 10,000 lux).

DO NOT use QuickShots in places that are close to buildings or where the GPS signal is weak.

Otherwise, the ﬂight path may be unstable.

Make sure to follow local privacy laws and regulations when using QuickShots.

DJI Mini SE User Manual

Detaching the Propellers

Use the screwdriver to detach the propellers from the motors.

Propeller blades are sharp. Handle with care.

The screwdriver is only used to mount the propellers. DO NOT use the screwdriver to disassemble

the aircraft.

If a propeller is broken, remove the two propellers and screws on the corresponding motor and

discard them. Use two propellers from the same package. DO NOT mix with propellers from other

packages.

Only use ocial DJI propellers. DO NOT mix propeller types.

Purchase the propellers separately if necessary.

Make sure that the propellers are installed securely before each ight. Check if the screws on the

propellers are tightened every 30 hours of ight time (approx. 60 ights).

Make sure all propellers are in good condition before each ight. DO NOT use aged, chipped, or

broken propellers.

To avoid injury, stand clear of and do not touch propellers or motors when they are spinning.

DO NOT squeeze or bend the propellers during transportation or storage.

Make sure the motors are mounted securely and rotating smoothly. Land the aircraft immediately if a

motor is stuck and unable to rotate freely.

DO NOT attempt to modify the structure of the motors.

DO NOT touch or let your hands or body come in contact with the motors after ight as they may be hot.

DO NOT block any of the ventilation holes on the motors or the body of the aircraft.

Make sure the ESCs sound normal when powered on.

Intelligent Flight Battery

The DJI Mini SE Intelligent Flight Battery is a 7.7 V, 2250 mAh battery with smart charging and

discharging functionality.

Battery Features

1. Balanced Charging: during charging, the voltages of the battery cells are automatically balanced.

2. Auto-Discharging Function: to prevent swelling, the battery automatically discharges to approx. 96%

of the battery level when it is idle for one day, and automatically discharges to approx. 72% of the

battery level when it is idle for nine days. It is normal to feel moderate heat being emitted from the

battery during the discharging process.

3. Overcharge Protection: the battery stops charging automatically once fully charged.

4. Temperature Detection: To prevent damage, the battery only charges when the temperature is

between 5° and 40° C (41° and 104° F). Charging stops automatically if the temperature of the

battery exceeds 50° C (122° F) during the charging process.

5. Overcurrent Protection: the battery stops charging if an excess current is detected.

6. Over-discharge Protection: discharging stops automatically to prevent excess discharge when the

battery is not in ight use. Over-discharge protection is not enabled when the battery is in ight use.

7. Short Circuit Protection: the power supply is automatically cut if a short circuit is detected.

DJI Mini SE User Manual

Using the Battery

Insert the battery in the battery compartment and secure the battery clamp. A clicking sound indicates

the battery is fully engaged. Make sure that the battery is fully inserted and the battery cover is secure in

place.

Checking Battery Level

Press the power button once to check the battery level.

Battery Level LEDs

: LED is on.

: LED is ashing.

: LED is o.

LED1 LED2 LED3 LED4

Battery Level

battery level

＞

88%

75%

＜

battery level

≤

88%

Refer to the DJI Mini SE Disclaimer and Safety Guidelines before use. Users take full

responsibility for all operations and usage.

DO NOT detach the battery when the aircraft is powering on.

Make sure that the battery is mounted ﬁrmly.

LED1

LED2

LED3

LED4

Battery Level LEDs

Power Button

Fully engagedNot engaged

Press the battery clamp and detach the battery from the battery compartment to remove it.

8. Battery Cell Damage Protection: DJI Fly displays a warning prompt when a damaged battery cell is

detected.

9. Hibernation Mode: if the battery cell voltage is lower than 3.0 V or the battery level is less than 10%,

the battery enters Hibernation mode to prevent over-discharge. Charge the battery to wake it from

hibernation.

10. Communication: information about the voltage, capacity, and current of the battery is transmitted to

the aircraft.

DJI Mini SE User Manual

Charging the Battery

Fully charge the Intelligent Flight Battery before using for the rst time.

1. Connect the USB charger to an AC power supply (100-240V, 50/60 Hz). Use a power adapter if

necessary.

2. Attach the aircraft to the USB charger.

3. The battery level LEDs display the current battery level during charging.

4. The Intelligent Flight Battery is fully charged when all the battery level LEDs are on. Detach the USB

charger when the battery is fully charged.

In cold environments, insert the battery into the battery compartment and turn on the aircraft to

warm up before taking off.

Powering On/O

Press the power button once, then press again, and hold for two seconds to turn the battery on or o.

The battery level LEDs display the battery level when the aircraft is powered on.

Press the power button once and the four battery level LEDs will blink for three seconds. If LED 3 and 4

blink simultaneously without pressing the power button, this indicates the battery is abnormal.

Low Temperature Notice

1. Battery capacity is signicantly reduced when ying in low-temperature environments of 32° to 41° F (0°

to 5° C). It is recommended to hover the aircraft in place temporarily to heat the battery. Make sure

to fully charge the battery before takeo.

2. To ensure the optimal performance of the battery, keep the battery temperature above 68° F (20° C).

3. The reduced battery capacity in low-temperature environments reduces the wind speed resistance

performance of the aircraft. Fly with caution.

4. Fly with extra caution at high sea levels.

63%

＜

battery level

≤

75%

50%

＜

battery level

≤

63%

38%

＜

battery level

≤

50%

25%

＜

battery level

≤

38%

13%

＜

battery level

≤

25%

＜

battery level

≤

13%

DJI Mini SE User Manual

Battery Protection Mechanisms

The battery LED indicator can display battery protection indications triggered by abnormal charging

conditions.

LED1 LED2 LED3 LED4

Battery Level

＜

battery level

≤

50%

＜

battery level

≤

75%

＜

battery level

＜

100%

Fully charged

Battery Level LEDs During Charging

The table below shows battery level during charging.

The battery cannot be charged if the aircraft is powered on and the aircraft cannot be powered

on during charging.

DO NOT charge an Intelligent Flight Battery immediately after ﬂight as the temperature may be

too high. Wait until it cools down to room temperature before charging again.

The charger stops charging the battery if the battery cell temperature is not within the operating

range of 41° to 104° F (5° to 40° C). The ideal charging temperature is 71.6° to 82.4° F (22° to 28° C).

The Battery Charging Hub (not included) can charge up to three batteries. Visit the ofﬁcial DJI

Online Store to learn more.

Fully charge the battery at least once every three months to maintain battery health.

It is recommended to use a QC2.0 USB charger to charge. DJI does not take any responsibility

for damage caused by using a charger that does not that meet the speciﬁed requirements.

When using the DJI 18W USB charger, the charging time is approximately 1 hour and 22 minutes.

It is recommended to discharge the Intelligent Flight Batteries to 30% or lower. This can be done

by ﬂying the aircraft outdoors until there is less than 30% charge left.

The blinking frequency of the battery level LEDs will be different when using different USB

charger. If the charging speed is fast, the battery level LEDs will blink quickly. If the charging

speed is extremely slow, the battery level LEDs will blink slowly (once every two seconds). It is

recommended to change the Micro USB cable or USB charger.

If there is no battery in the aircraft, LED 3 and 4 will blink three times alternatively.

The four LEDs blink simultaneously to indicate the battery is damaged.

Battery Protection Mechanisms

LED1 LED2 LED3 LED4 Blinking Pattern Battery Protection Item

LED2 blinks twice per second Overcurrent detected

LED2 blinks three times per

second

Short circuit detected

LED3 blinks twice per second Overcharge detected

LED3 blinks three times per

second

Over-voltage charger detected

DJI Mini SE User Manual

If the charging temperature protection is enabled, the battery will resume charging once the temperature

has returned to within the allowable range. If one of the other battery protection mechanisms activate, in

order to resume charging it is necessary to press the button to power o the battery, unplug the battery

from the charger, and then plug it in again. If the charging temperature is abnormal, wait for the charging

temperature to return to normal, and the battery will automatically resume charging without the need to

unplug and plug in the charger again.

Gimbal and Camera

Gimbal Prole

DJI Mini SE's 3-axis gimbal provides stabilization for the camera, allowing you to capture clear and

stable images and video. Use the gimbal dial on the remote controller to control the camera’s tilt.

Alternatively, enter the camera view in DJI Fly. Press the screen until a circle appears and drag the circle

up and down to control the camera’s tilt.

The gimbal has a tilt range of -90˚ to +20˚ by enabling “Allow Upward Gimbal Rotation” in DJI Fly. The

default control range is -90˚ to 0˚.

-90°

0°

20°

Gimbal Operation Modes

Two gimbal operation modes are available. Switch between the dierent operation modes in DJI Fly.

Follow Mode: The angle between the gimbal’s orientation and aircraft front remains constant at all times.

FPV Mode: The gimbal synchronizes with the movement of the aircraft to provide a rst-person ying

experience.

LED4 blinks twice per second Charging temperature is too low

LED4 blinks three times per

second

Charging temperature is too

high

Make sure there are no stickers or objects on the gimbal before taking o. When the aircraft is powered

on, DO NOT tap or knock the gimbal. Take o from open and at ground in order to protect the gimbal

Precision elements in the gimbal may be damaged in a collision or impact, which may cause the

gimbal to function abnormally.

Avoid getting dust or sand on the gimbal, especially in the gimbal motors.

A gimbal motor error may occur in the following situations:

a. The aircraft is on uneven ground or the gimbal is obstructed.

b. The gimbal experiences excessive external force, such as a collision.

DJI Mini SE User Manual

Camera Prole

DJI Mini SE uses a 1/2.3" CMOS sensor camera, which can shoot up to 2.7K video and 12 MP photos,

and supports shooting modes such as Single Shot and Interval.

The aperture of the camera is f/2.8 and can focus from 1 m to innity.

Storing Photos and Videos

DJI Mini SE supports the use of a microSD card to store your photos and videos. A UHS-I Speed Grade

3 rating microSD card is required due to the fast read and write speeds necessary for high-resolution

video data. Refer to the Specifications section for more information about recommended microSD

cards.

Make sure the temperature and humidity are suitable for the camera during usage and storage.

Use a lens cleanser to clean the lens to avoid damage.

DO NOT block any ventilation holes on the camera as the heat generated may damage the

device and hurt the user.

Do not remove the microSD card from the aircraft while it is turned on. Otherwise, the microSD

card may be damaged.

To ensure the stability of the camera system, single video recordings are limited to 30 minutes.

Check camera settings before use to ensure they are conﬁgured as desired.

Before shooting important photos or videos, shoot a few images to test the camera is operating

correctly.

Photos or videos cannot be transmitted or copied from the camera if the aircraft powered off.

Make sure to power off the aircraft correctly. Otherwise, your camera parameters will not be

saved and any recorded videos may be damaged. DJI is not responsible for any failure of an

image or video to be recorded or having been recorded in a way that is not machine-readable.

DO NOT apply external force to the gimbal after the gimbal is powered on. DO NOT add any

extra payload to the gimbal as this may cause the gimbal to function abnormally or even lead to

permanent motor damage.

Make sure to remove the gimbal cover before powering on the aircraft. Also, make sure to mount

the gimbal cover when the aircraft is not in use.

Flying in heavy fog or clouds may make the gimbal wet, leading to temporary failure. The gimbal

recovers full functionality once it is dry.

Remote Controller

This section describes the features

of the remote controller and includes

instructions for controlling the aircraft

and the camera.

Remote Controller

Remote Controller Profile

Built into the remote controll is DJI's enhanced Wi-Fi technology, offering 2.4 GHz and 5.8 GHz*

transmission frequencies, a maximum transmission distance of 2.49 mi (4 km), and 720p video downlink

from the aircraft to DJI Fly on your mobile device. The detachable control sticks make the remote

controller easier to store. Refer to the remote controller diagram in the Product Prole section for more

information.

The built-in battery has a capacity of 2600 mAh and a maximum run time of 4.5 hours when using an

iOS device and 1 hour and 40 minutes when using an Android device. The remote controller charges

the Android device with a charging ability of 500 mA@5V. The remote controller automatically charges

Android devices.

* The MR1SD25 model remote controller can support both 2.4 GHz and 5.8 GHz. The MR1SS5 model remote

controller only supports 5.8 GHz.

Compliance Version: The remote controller is compliant with local regulations.

Control Stick Mode: The control stick mode determines the function of each control stick

movement. Three pre-programmed modes (Mode 1, Mode 2, and Mode 3) are available and

custom modes can be conﬁgured in DJI Fly. The default mode is Mode 2.

Using the Remote Controller

Powering On/Off

Press the power button once to check the current battery level.

Press once, then again and hold to turn the remote controller on or o. If the battery level is too low,

recharge before use.

Controlling the Camera

1. Record Button: Press to start/stop recording

(Video) or switch to video mode (Photo).

2. Shutter Button: Press to take photo (Photo)

or switch to photo mode (Video).

Charging the Battery

Use a Micro USB cable to connect the USB charger to the Micro USB port of the remote controller.

Record Button Shutter Button

DJI Mini SE User Manual

Controlling the Aircraft

Three pre-programmed modes (Mode 1, Mode 2, and Mode 3) are available and custom modes can be

dened in the DJI Fly app. The default mode is Mode 2.

Right StickLeft Stick

Turn RightTurn Left

Down

RightLeft

Down

Turn RightTurn Left

RightLeft

Forward

Backward

Left Stick Right Stick

Forward

Backward

Right Stick

Down

Forward

Backward

Left Stick

Turn RightTurn Left

RightLeft

Mode 1

Mode 2

Mode 3

DJI Mini SE User Manual

Remote Controller

(Mode 2)

Aircraft

(

Indicates Nose Direction)

Remarks

Moving the left stick up or down changes the

aircraft’s altitude. Push the stick up to ascend

and down to descend. The more the stick is

pushed away from the center position, the

faster the aircraft will change altitude. Push the

stick gently to prevent sudden and unexpected

changes in altitude.

Moving the left stick to the left or right controls

the orientation of the aircraft. Push the stick

left to rotate the aircraft counter-clockwise

and right to rotate the aircraft clockwise. The

more the stick is pushed away from the center

position, the faster the aircraft will rotate.

Moving the right stick up and down changes

the aircraft’s pitch. Push the stick up to fly

forward and down to y backward. The more

the stick is pushed away from the center

position, the faster the aircraft will move.

Moving the right stick to the left or right

changes the aircraft’s roll. Push the stick left to

y left and right to y right. The more the stick

is pushed away from the center position, the

faster the aircraft will move.

Flight Pause/RTH Button

Press once to make the aircraft brake and hover in place. If the aircraft is performing a QuickShot, RTH,

or auto landing, press once to exit the procedure and hover in place.

Press and hold the RTH button to start RTH. Press this button again to cancel RTH and regain control

of the aircraft. Refer to the Return to Home section for more information about RTH.

The gure below explains how to use each control stick, using Mode 2 as an example.

DJI Mini SE User Manual

Optimal Transmission Zone

The signal between the aircraft and the remote controller is most reliable when the antennas are

positioned in relation to the aircraft as depicted below.

strong weak

Linking the Remote Controller

The remote controller is linked to the aircraft before delivery. Linking is only required when using a new

remote controller for the rst time. Follow these steps to link a new remote controller:

1. Power on the remote controller and the aircraft.

2. Launch DJI Fly. In camera view, In camera view, tap

and select Control and Connect to Aircraft,

or press and hold the power button of the remote controller for more than four seconds. The remote

controller beeps continuously indicating it is ready to link.

3. Press and hold the power button of the aircraft for more than four seconds. The aircraft beeps once

indicating it is ready to link. The aircraft beeps twice indicating linking is successfully.

Make sure the remote controller is within 0.5 m of the aircraft during linking.

The remote controller will automatically unlink from an aircraft if a new remote controller is linked to

the same aircraft.

Fully charge the remote controller before each ight.

If the remote controller is powered on and not in use for ve minutes, an alert will sound. After six

minutes, the aircraft automatically powers o. Move the control sticks or press any button to cancel

the alert.

Adjust the mobile device clamp to ensure the mobile device is secure.

Make sure the antennas of the remote controller are unfolded and adjusted to the proper position to

achieve optimal transmission quality.

Repair or replace the remote controller if damaged. A damaged remote controller antenna greatly

decreases performance.

Fully charge the battery at least once every three months to maintain battery health.

DJI Fly App

This section introduces the main

functions of the DJI Fly app.

DJI Fly App

Home

Launch DJI Fly and enter the home screen.

Fly Spots

View or share nearby suitable ight and shooting locations, learn more about GEO zones, and preview

aerial photos of dierent locations taken by other users.

Academy

Tap the icon in the top right corner to enter Academy. Product tutorials, ight tips, ight safety, and

manual documents can be viewed here.

Album

Allows you to view the DJI Fly and your phone’s album. QuickShots videos can be viewed after

downloading to your phone. Create contains Templates and Pro. Templates provides auto edit feature

for imported footage. Pro allows you to edit the footage manually.

SkyPixel

Enter SkyPixel to view videos and photos shared by users.

Prole

View account information, flight records, DJI forum, online store, Find My Drone feature, and other

settings.

Academy

Fly Spots

GO FLY

Skypixel

Album

Altitude Zone (120m)

Proﬁle

DJI Mini SE User Manual

Camera View

1. Flight Mode

P Mode

: displays the current ight mode. Tap to switch between modes.

2. System Status Bar

In Flight

: indicates the aircraft flight status and displays various warning messages. Tap to view more

information when a warning prompt appears.

3. Battery Information

24'26"

: displays the current battery level and remaining ight time. Tap to view more information about

the battery.

4. Video Downlink Signal Strength

: displays the video downlink signal strength between the aircraft and remote controller.

5. GPS Status

: displays the current GPS signal strength.

6. System Settings

: There are Safety, Control, Camera, Transmission and About.

Safety

Flight Protection: Max Altitude, Max Distance, Auto RTH Altitude settings, and Update Home Point.

Sensors: View the IMU and compass status and start to calibrate if necessary.

Advanced Settings including Emergency Propeller Stop and Payload mode. “Emergency Only” indicates that

the motors can only be stopped mid-ight in an emergency situation such as if there is a collision, a motor

has stalled, the aircraft is rolling in the air, or the aircraft is out of control and ascending or descending very

quickly. “Anytime” indicates that the motors can be stopped mid-ight anytime once the user performs a

combination stick command (CSC). Stopping the motors mid-ight will cause the aircraft to crash.

If accessories such as the propeller guard are mounted to the aircraft, it is recommended to enable Payload

mode for enhanced safety. After takeo, Payload mode is enabled automatically if a payload is detected.

The ight performance will be reduced accordingly when ying with any payload. Note that the Max Service

+1.0+1.0

EVEV

RCRC

P Mode

In Flight

1:30:26

1.6m/s

7.9m/s

625m

1080p 30

1 2 3 4 5 6

111213

DJI Mini SE User Manual

Ceiling above Sea Level is 1500 m and the max ight speed is limited when Payload mode is enabled.

The Find My Drone feature helps to nd the location of the aircraft on the ground.

Control

Aircraft Settings: Select Flight mode and Units settings.

Gimbal Settings: Switch gimbal mode and calibrate gimbal. Advanced gimbal settings include Pitch Speed,

Pitch Smoothness, and Allow Upward Gimbal Rotation.

Remote Controller Settings: Stick mode settings and remote controller calibration.

Beginner Flight Tutorial: View the ight tutorial.

Connect to Aircraft: When the aircraft is not linked to the remote controller, tap to start linking.

Camera

Set the photo size and select the microSD card settings.

Advanced Settings such as Histogram, Gridlines, Overexposure Warning, and Anti-Flicker.

Tap Reset Camera Settings to restore all camera settings to default.

Transmission

Frequency and Channel mode settings.

About

View device information, rmware information, app version, battery version, and more.

7. Shooting Mode

Photo: Choose between Single Shot and Interval.

Video: Video resolution can be set to 2.7K 24/25/30 fps and 1080P 24/25/30/48/50/60 fps.

QuickShots: Choose from Dronie, Circle, Helix, and Rocket.

8. Shutter/Record Button

Tap to start shooting photos or recording video.

9. Playback

: Tap to enter playback and preview photos and videos as soon as they are captured.

10. Camera Mode Switch

: choose between Auto and Manual mode when in photo mode. In Manual mode, shutter and ISO can

be set. In Auto mode, AE lock and EV can be set.

11. microSD Card Information

1080p 30

: displays the remaining number of photos or video recording time of the current microSD card. Tap

to view the available capacity of the microSD card.

12. Flight Telemetry

D 12m, H 6m, 1.6m/s, 1m/s: displays the distance between the aircraft and the Home Point, height from

the Home Point, aircraft horizontal speed, and aircraft vertical speed.

13. Attitude Indicator

Displays information such as the orientation and tilt angle of the aircraft, position of the remote controller,

and position of the Home Point.

Collapse

Switch to minimap

Aircraft tilt angle

Home Point

Remote controller position

Aircraft orientation

Switch to Attitude

Indicator

DJI Mini SE User Manual

Make sure to fully charge your mobile device before launching DJI Fly.

Mobile cellular data is required when using DJI Fly. Contact your wireless carrier for data

charges.

If you are using a mobile phone as your display device, DO NOT accept phone calls or use

texting features during ﬂight.

Read all safety tips, warning messages, and disclaimers carefully. Be familiar with the related

regulations in your area. You are solely responsible for being aware of all relevant regulations

and ﬂying in a way that is compliant.

a. Read and understand the warning messages before using the Auto-take off and Auto-landing

features.

b. Read and understand the warning messages and disclaimer before setting the altitude

beyond the default limit.

c. Read and understand the warning messages and disclaimer before switching between ﬂight

modes.

d. Read and understand the warning messages and disclaimer prompts near or in GEO zones.

e. Read and understand the warning messages before using the Intelligent Flight Mode.

Land your aircraft immediately at a safe location if a prompt to land appears in the app.

Review all warning messages on the checklist displayed in the app before each ﬂight.

Use the in-app tutorial to practice your ﬂight skills if you have never operated the aircraft or if you

do not have sufﬁcient experience to operate the aircraft with conﬁdence.

Cache the map data of the area where you intend to ﬂy the aircraft by connecting to the internet

before each ﬂight.

The app is designed to assist your operation. Use your discretion and DO NOT rely on the app

to control your aircraft. Your use of the app is subject to DJI Fly Terms of Use and DJI's Privacy

Policy. Read them carefully in the app before ﬂying.

14. Auto Takeo/Landing/RTH

: tap the icon. When the prompt appears, press and hold the button to initiate auto takeo or

landing.

Tap

to initiate Smart RTH and have the aircraft return to the last recorded Home Point.

15. Back

: tap to return to the home screen.

Press the screen until a circle appears and drag the circle up and down to control the tilt of the gimbal.

Flight

This section describes safe ight

practices and ight restrictions.

Flight

Once pre-ight preparation is complete, it is recommended to hone your ight skills and practice ying

safely. Make sure that all ights are carried out in an open area. The ying height is limited to 500 m. DO

NOT exceed this height. Strictly abide by local laws and regulations when ying. Make sure to read the

DJI Mini SE Disclaimer and Safety Guidelines to understand the safety notices before ying.

Flight Environment Requirements

1. Do not use the aircraft in severe weather conditions including wind speeds exceeding 10 m/s, snow,

rain, and fog.

2. Only fly in open areas. Tall structures and large metal structures may affect the accuracy of the

onboard compass and GPS system. It is recommended to keep the aircraft at least 5 m away from

structures.

3. Avoid obstacles, crowds, high voltage power lines, trees, and bodies of water. It is recommended to

keep the aircraft at least 3 m above water.

4. Minimize interference by avoiding areas with high levels of electromagnetism such as locations near

power lines, base stations, electrical substations, and broadcasting towers.

5. Aircraft and battery performance is subject to environmental factors such as air density and

temperature. DO NOT y the aircraft 3,000 m (9,842 ft) or higher above sea level. Otherwise, the

battery and aircraft performance may be reduced.

6. Aircraft cannot use GPS within the polar regions. Use the Downward Vision System when ying in

such locations.

7. Fly with caution when taking o from moving surfaces such as a moving boat or vehicle.

Flight Limits and GEO Zones

Unmanned aerial vehicle (UAV) operators should abide by the regulations from self-regulatory

organizations such as the International Civil Aviation Organization, the Federal Aviation Administration,

and local aviation authorities. For safety reasons, flight limits are enabled by default to help users

operate this aircraft safely and legally. Users can set ight limits on height and distance.

Altitude limits, distance limits, and GEO zones function concurrently to manage ight safety when GPS

is available. Only altitude can be limited when GPS is unavailable.

Flight Altitude and Distance Limits

The ight altitude and distance limits can be changed in DJI Fly. Based on these settings, the aircraft will

y in a restricted cylinder, as shown below:

Max Flight Altitude

Max Radius

Home Point

Height of aircraft

when turned on

DJI Mini SE User Manual

Flight Limits DJI Fly App

Aircraft Status

Indicator

Max

Altitude

Aircraft's altitude cannot exceed the

specied value

Warning: Height limit

reached

Blinks green and

red alternatively

Max

Radius

Flight distance must be within the

max radius

Warning: Distance limit

reached

When GPS is weak

Flight Limits DJI Fly App

Aircraft Status

Indicators

Max

Altitude

Height is restricted to 16 ft (5 m)

when the GPS signal is weak and

Infrared Sensing System is operating.

Height is restricted to 98 ft (30 m)

when the GPS signal is weak and

Infrared Sensing System is not

operating.

Warning: height limit

reached

Blinks red and

green alternately

Max

Radius

The restrictions on the radius are disabled and warning prompts cannot be received in

the app.

There will be no altitude limit if the GPS signal becomes weak during ight as long as the GPS signal

was stronger than weak (white or yellow signal bars) when the aircraft was powered on.

If the aircraft is in a GEO zone and there is a weak or no GPS signal, the aircraft status indicator will

glow red for ve seconds every twelve seconds.

If the aircraft reaches an altitude or radius limit, you can still control the aircraft, but you cannot y it

any further. If the aircraft ies out of the max radius, it will automatically y back within range when

the GPS signal is strong.

For safety reasons, do not y close to airports, highways, railway stations, railway lines, city centers,

or other sensitive areas. Fly the aircraft only within your line of sight.

GEO Zones

All GEO zones are listed on the DJI ocial website at http://www.dji.com/ysafe. GEO zones are divided

into different categories and include locations such as airports, flying fields where manned aircraft

operate at low altitudes, borders between countries, and sensitive locations such as power plants.

There will be prompts in DJI Fly app alerting users of any nearby GEO zones.

Pre-Flight Checklist

1. Make sure the remote controller, mobile device, and Intelligent Flight Battery are fully charged.

2. Make sure the Intelligent Flight Battery and the propellers are mounted securely.

3. Make sure the aircraft arms are unfolded.

When GPS is available

DJI Mini SE User Manual

Auto Takeoff/Landing

Auto Takeoff

1. Launch DJI Fly and enter the camera view.

2. Complete all steps in the pre-ight checklist.

3. Tap

. If conditions are safe for takeo, press and hold the button to conrm.

4. The aircraft will take o and hover 3.9 ft (1.2 m) above the ground.

The aircraft status indicator shows whether the aircraft is using GPS and/or the Downward Vision

System for ﬂight control. It is recommended to wait until the GPS signal is strong before using

auto takeoff.

DO NOT takeo from an moving surface, such as a moving boat or vehicle.

Auto Landing

Use auto landing when the aircraft status indicator blinks green.

1. Tap

. If conditions are safe to land, press and hold the button to conﬁrm.

2. Auto landing can be cancelled by tapping

3. If the Vision System is working normally, Landing Protection will be enabled.

4. Motors stops after landing.

Choose the proper place for landing.

Starting/Stopping the Motors

Starting the Motors

A Combination Stick Command (CSC) is used to start the motors. Push both sticks to the bottom

inner or outer corners to start the motors. Once the motors have started spinning, release both sticks

simultaneously.

Stopping the Motors

There are two methods to stop the motors.

1. Method 1: When the aircraft has landed, push and hold the left stick down. The motors will stop after

three seconds.

4. Make sure the gimbal and camera are functioning normally.

5. Make sure nothing is obstructing the motors and that they are functioning normally.

6. Make sure DJI Fly is successfully connected to the aircraft.

7. Make sure the camera lens and Vision System sensors are clean.

8. Use only genuine DJI parts or parts certified by DJI. Unauthorized parts or parts from non-DJI

certied manufacturers may cause system malfunctions and compromise safety.

DJI Mini SE User Manual

Flight Test

Takeoff/Landing Procedures

1. Place the aircraft in an open, at area with the aircraft status indicator facing towards you.

2. Turn on the aircraft and the remote controller.

3. Launch DJI Fly and enter the camera view.

4. Wait until the aircraft status indicator blinks green indicating that the Home Point has been recorded

and it is now safe to y.

5. Gently push the throttle stick to take o or use auto-takeo.

6. Pull the throttle stick or use auto-landing to land the aircraft.

7. After landing, push the throttle stick down and hold. The motors stop after three seconds.

8. Turn o the aircraft and remote controller.

Video Suggestions and Tips

1. The pre-ight checklist is designed to help you y safely and to ensure that you can shoot video

during ight. Go through the full pre-ight checklist before each ight.

2. Select the desired gimbal operation mode in DJI Fly.

3. Shoot video when ying in P-mode or C-mode.

4. DO NOT y in bad weather conditions such as when it is raining or windy.

5. Choose the camera settings that best suit your needs.

6. Perform ight tests to establish ight routes and to preview scenes.

7. Push the control sticks gently to keep the aircraft movement smooth and stable.

Method 1 Method 2

Stopping the Motors Mid-Flight

The motors should only be stopped mid-flight in an emergency situation such as if a collision has

occurred or if the aircraft is out of control and is ascending or descending very quickly, rolling in

the air, or if a motor has stalled. To stop the motors mid-flight, use the same CSC that was used

to start the motors. The default setting can be changed in DJI Fly.

Stopping motors mid-ight will cause the aircraft to crash.

It is important to understand the basic ight guidelines for the safety of both you and

those around you.

DO NOT forget to read the disclaimer and safety guidelines.

2. Method 2: When aircraft has landed, push the left stick down, then conduct the same CSC that was

used to start the motors, as described above. The motors will stop immediately. Release

both sticks once the motors have stopped.

Appendix

Aircraft

Maximum Take-O Mass

(MTOM)

242 g (including the battery, propellers, and a microSD card)

Dimensions (L×W×H)

Folded: 138×81×58 mm

Unfolded: 159×203×56 mm

Unfolded (with propellers): 245×289×56 mm

Diagonal Distance

213 mm

Max Ascent Speed 4 m/s (S Mode)

2 m/s (P Mode)

1.5 m/s (C Mode)

Max Descent Speed 3 m/s (S Mode)

1.8 m/s (P Mode)

1 m/s (C Mode)

Max Speed (near sea level,

no wind)

13 m/s (S Mode)

8 m/s (P Mode)

4 m/s (C Mode)

Max Service Ceiling Above

Sea Level

3000 m

Max Flight Time

30 mins (measured while ying at 17 kph in windless conditions)

Max Wind Speed Resistance

10 m/s (Scale 5)

Max Tilt Angle 30° (S Mode)

20° (P Mode)

20° (C Mode)

Max Angular Velocity 150°/s (S Mode)

130°/s (P Mode)

30°/s (C Mode)

Operating Temperature

Range

0° to 40° C (32° to 104° F)

GNSS

GPS+GLONASS

Operating Frequency Wi-Fi

Model MT2SS5: 5.725-5.850 GHz

Model MT2SD25: 2.400-2.4835 GHz, 5.725-5.850 GHz

GPS

1.57302-1.57782 GHz

GLONASS

1.597-1.607 GHz

Transmission Power (EIRP) Model MT2SS5

5.8 GHz: <30 dBm (FCC); <28 dBm (SRRC)

Model MT2SD25

2.4 GHz: <19 dBm (MIC/CE)

5.8 GHz: <14 dBm (CE)

Appendix

Specifications

DJI Mini SE User Manual

Hovering Accuracy Range Vertical: ±0.1 m (with Vision Positioning), ±0.5 m (with GPS

Positioning)

Horizontal: ±0.3 m (with Vision Positioning), ±1.5 m (with GPS

Positioning)

Gimbal

Mechanical Range Tilt: -110° to +35°

Roll: -35° to +35°

Pan: -20° to +20°

Controllable Range Tilt: -90° to 0° (default setting), -90° to +20° (extended)

Stabilization 3-axis (tilt, roll, pan)

Max Control Speed (tilt) 120°/s

Angular Vibration Range ±0.01°

Sensing System

Downward

Operating Range: 0.5-10 m

Operating Environment Non-reective, discernable surfaces with diuse reectivity of >20%

Adequate lighting of lux>15

Camera

Sensor 1/2.3” CMOS

Eective Pixels: 12 MP

Lens FOV: 83°

35 mm Format Equivalent: 24 mm

Aperture: f/2.8

Focus Range: 1 m to ∞

ISO 100-3200

Shutter Speed Electronic Shutter: 4-1/8000 s

Still Image Size 4:3: 4000×3000 16:9: 4000×2250

Still Photography Modes Single shot

Interval: 2/3/5/7/10/15/20/30/60 s

Video Resolution 2.7K: 2720×1530 24/25/30 p

FHD: 1920×1080 24/25/30/48/50/60 p

Max Video Bitrate 40 Mbps

Supported File System FAT32 (≤ 32 GB)

exFAT (> 32 GB)

Photo Format JPEG

Video Format MP4 (H.264/MPEG-4 AVC)

Remote Controller

Operating Frequency Model MR1SS5: 5.725 - 5.850 GHz

Model MR1SD25: 2.400 - 2.4835 GHz, 5.725 - 5.850 GHz

DJI Mini SE User Manual

Max Transmission Distance

(unobstructed, free of

interference)

Model MR1SS5: 5.8 GHz: 4000 m (FCC); 2500 m (SRRC)

ModelMR1SD25:

2.4 GHz: 2000 m (MIC/CE); 5.8 GHz: 500 m (CE)

Operating Temperature

Range

0° to 40° C (32° to 104° F)

Transmitter Power (EIRP) Model MR1SS5: 5.8 GHz: <30 dBm (FCC); <28 dBm (SRRC)

Model MR1SD25: 2.4 GHz: <19 dBm (MIC/CE)

5.8 GHz: <14 dBm (CE)

Battery Capacity 2600 mAh

Operating Current/Voltage 1200 mA 3.6 V (Android)

450 mA 3.6 V (iOS)

Supported Mobile Device

Size

Max length: 160 mm

Max thickness: 6.5 - 8.5 mm

Supported USB Port Types

Lightning, Micro USB (Type-B), USB-C

Video Transmission System

Enhanced Wi-Fi

Live View Quality

Remote Controller: 720p@30fps

Max. Bitrate

4 Mbps

Latency (depending on

environmental conditions and

mobile device)

170 - 240 ms

Charger

Input 100 - 240V, 50/60 Hz, 0.5A

Output 12V 1.5A / 9V 2A / 5V 3A

Rated Power 18 W

Intelligent Flight Battery

Battery Capacity 2250 mAh

Voltage 7.7 V

Charging Voltage Limit 8.8 V

Battery Type LiPo 2S

Energy 17.32 Wh

Weight 82.5 g

Charging Environment

Temperature

5° to 40° C (41° to 104° F)

Max Charging Power 29 W

App

App DJI Fly

Required Operating System iOS v

10.0.2

or later; Android v6.0 or later

SD Cards

Supported SD Cards Requires UHS-I Speed Grade 3 rating microSD card

DJI Mini SE User Manual

Calibrating the Compass

It is recommended that the compass is calibrated in any of the following situations when ying outdoors:

1. Flying at a location further than 31 miles (50 km) away from the location the drone was last own.

2. The aircraft has not been own for more than 30 days.

3. A compass interference warning appears in DJI Fly and/or the aircraft status indicator blinks red and

yellow alternatively.

DO NOT calibrate the compass in locations where magnetic interference may occur, such as close to

magnetite deposits or large metallic structures such as parking structures, steel reinforced basements,

bridges, cars, or scaolding.

DO NOT carry objects (such as mobile phones) that contain ferromagnetic materials near the aircraft

during calibration.

It is not necessary to calibrate the compass when ying indoors.

Calibration Procedure

Choose an open area to carry out the following procedure.

1. Tap the System Settings in DJI Fly, select “Control” and then select “Calibrate”, and follow the on-

screen instructions. The aircraft status indicator grows yellow, indicating calibration has start.

2. Hold the aircraft horizontally and rotate it 360 degrees. The aircraft status indicator will turn solid

green.

3. Hold the aircraft vertically and rotate it 360 degrees around a vertical axis.

4. If the aircraft status indicator blinks red, the calibration has failed. Change your location and try the

calibration procedure again.

Recommended microSD Cards 16 GB: SanDisk Extreme

32 GB: Samsung Pro Endurance, Samsung Evo Plus, SanDisk Industrial,

SanDisk Extreme V30 A2, SanDisk Extreme Pro V30 A1, SanDisk Extreme

Pro V30 A2, Lexar 633x, Lexar 667x

64 GB: Samsung Pro Endurance, Samsung Evo Plus, SanDisk Extreme

V30 A1, SanDisk Extreme V30 A2, Lexar 633x, Lexar 667x, Lexar 1000x,

Lexar High Endurance, Toshiba EXCERIA M303 V30 A1, Netac Pro V30 A1

128 GB: Samsung Evo Plus, SanDisk Extreme V30 A2, SanDisk Extreme

Plus V30 A1, SanDisk Extreme Plus V30 A2, Lexar 633x, Lexar 667x,

Lexar 1000x, Lexar High Endurance, Toshiba EXCERIA M303 V30 A1,

Netac Pro V30 A1

256 GB: SanDisk Extreme V30 A2

Aircraft takeo weight includes battery, propellers, and a microSD card.

Registration not required in some countries and regions. Check local rules and regulations before use.

These specications have been determined through tests conducted with the latest rmware.

Firmware updates can enhance performance. It is highly recommended to update to the latest

rmware.

DJI Mini SE User Manual

If the aircraft status indicator blinks red and yellow alternatively after calibration is completed, this

indicates that the current location is not suitable for ying the aircraft, due to the level of magnetic

interference. Change your location.

A prompt will appear in DJI Fly if compass calibration is required before takeo.

The aircraft can take o immediately once calibration is complete. If you wait more than three minutes

to take o after calibration, you may need to repeat the calibration process.

After-Sales Information

Visit https://www.dji.com/support for more information about after-sales service policies and value-

added services such as DJI Care.

Updating Firmware

When you connect the aircraft or remote controller to DJI Fly, you will be notified if a new firmware

update is available. To update, connect the mobile device to the internet and follow the on-screen

instructions. Note that the firmware cannot be updated if the remote controller is not linked to the

aircraft.

Make sure to follow all the steps to update rmware. Otherwise, the update may fail. The aircraft will

power o automatically after the rmware update is complete.

The rmware update will take approx. 10 minutes. It is normal for the gimbal to go limp, aircraft

status indicators to blink, and the aircraft to reboot. Wait patiently until the update is complete.

Before performing an update, make sure the Intelligent Flight Battery is at least 15% charged and the

remote controller is at least 20% charged.

The remote controller may become unlinked from the aircraft after updating. Relink the remote

controller and aircraft. Note that the update may reset various main controller settings, such as the

RTH altitude and the maximum ight distance, to default settings. Before updating, take note of your

preferred DJI Fly settings and readjust them after the update.

This content is subject to change.

Download the latest version from

http://www.dji.com/mini-se

If you have any questions about this document, please contact

DJI by sending a message to [email protected].

DJI is a trademark of DJI.

Contact DJI SUPPORT

via Facebook Messenger

WE ARE HERE FOR YOU

Dji MINI SE

Product's Documents

User Manual

Specifications

Dji MINI SE Questions and Answers
