Cat. No. D215O
At a glance
Features
Quick tip
Your Outdoor Plug-In
Switch works with:
Leviton’s Decora Smart Wi-Fi Outdoor
Plug-In Switch makes it easy to add smart
control to outdoor lighting, such as string
lights, holiday lights, and landscape
lighting. With a 15A rating and support
for motor loads up to 3/4 HP, you can
also control holiday decorations and
inflatables, fountain pumps, outdoor fans,
aquarium pumps, and other electronics
and small appliances.
Use the My Leviton app to create a
schedule, set the run time, select
sunrise/sunset options, or enable the
built in light sensor. You can also pair a
wireless Anywhere Companion Switch for
convenient wall-mount control.
Connect to your smart home platform of
choice. The Outdoor Plug-In Switch works
with Matter, Amazon Alexa, Google Home,
Apple Home/Siri, and more. Use your voice
or your mobile device with the My Leviton
app when you are away from home.
You can pair a wireless Anywhere Switch Companion directly
to your Outdoor Plug-In Switch to control from convenient
wall-mount locations (no Wi-Fi or App needed). See page
12, or learn more about Anywhere Companions and find
connection instructions at Leviton.com/anywhere.
• General purpose loads up to 15 amps, for specific ratings.
S
ee the chart below.
• For indoor or outdoor use in all weather conditions.
• Tested to be certified for an Ingress Protection rating of
I
P65 for dirt, dust, moisture, rain, sprinklers, hoses, snow,
and UV corrosion.
• For outdoor use, plug into a GFCI protected circuit to provide
ON
/OFF control of the connected load/lights.
• Can be used with magnetic low-voltage landscape lighting
tr
ansformers.
• Can be used with extension cords (recommend 14 AWG/15A
ex
terior-rated extension cords).
• Ad
ditional self-service support options can be found in
the My Leviton app or at leviton.com/decorasmart.
RATINGS
General Use 15A, 120VAC, 60Hz
LED / CFL / Electronic Ballast 5A
Incandescent / Halogen 1,500W
Magnetic Ballast, MLV 12A
Motor 3/4 HP
Operating Temp -20 °F to 122 °F (-29 °C - 50 °C)
Operating Humidity 10% - 90% non-condensing
NETWORK
Wi-Fi 802.11 b/g/n networks - 2.4 GHz only
Security WPA, WPA2, or WPA3 security, or open
Bluetooth v5.0
MY LEVITON APP
iOS Version 12.0 or later
Android™ Version 8.0 or later
1. Using a mobile device, confirm a
strong Wi-Fi signal is available in the
area in which you are installing the
Outdoor Plug-In Switch.
2. Insert the Outdoor Plug-In Switch
into a 120V
AC outlet.
3. When the device first powers ON,
the Status LED flashes gr
een to
show it is ready for setup.
4. Press to turn ON and OFF.
A My Leviton account, if connecting using the
My Leviton App.
An iOS (12.0 or later) or Android™ (8.0 or later)
mobile device.
NOTE: Make sure Wi-Fi and Bluetooth are enabled on
your mobile device.
A 2.4GHz Wi-Fi network with high speed internet.
OUTDOOR PLUG-IN
SWITCH
Getting Started Guide
DI-000-D215O-02B
• ON/OFF control of string lights and holiday lights, holiday
decorations and inflatables, landscape and path lighting,
fountain pumps, aquarium pumps, outdoor fans, and other
electronics and small appliances.
• Pairs with up to three DAWSC Anywhere Switch Companions
for wire-free wall-mount control.
• IP65 - weather resistance protects electronics
from dirt, dust, moisture, rain, sprinklers, hoses,
snow, and UV corrosion.
• Wide operating temperature range of -20 °F to 122 °F.
•
Light Sensor can be used outside to automatically turn
lights On during evening hours and O during daylight hours.
• Create a schedule to control connected loads at specific
times, based on sunrise/sunset, or turn o after a specified
duration.
• Wi-Fi operation designed to support outdoor use with signal
strength indication in the My Leviton app.
• Rear mounting holes allow easy placement next to an
outdoor outlet.
• Memory maintains ON/OFF status of load during a power
disruption.
For more information and features visit:
leviton.com/decorasmart
NO
TES:
• Make sure the Outdoor Plug-In Switch’s Outlet is at least 3 in.
abo
ve the ground when plugged in to avoid it being immersed
in water.
• Do not use in a switched outlet.
• The light sensor was designed for outdoor use. For best
perf
ormance, position the device so the light sensor is pointed
away from connected lights and shaded areas, and provide an
unobstructed view towards natural ambient light.
WARNING: ELECTRIC SHOCK HAZARD.
May result in serious injury or death. When used outdoors, this
device must be plugged into a GFCI protected circuit.
What you need to
make it work:
Welcome
NEMA Plug 5-15P
Plugs into power source.
Line and Load Cord
Heavy duty 14 AWG
p
ower cord with
high-durability.
NEMA Outlet 5-15R
Connects lighting and loads
fo
r smart control.
Control Button
Press to toggle
t
he load ON
or OFF.
Light Sensor
Enable via the My Leviton
a
pp to automatically turn
the connected load
ON/OFF when it gets
dark/light.
Status LED
Provides
connec
tivity and
device status
feedback.
Installation
Installation (continued)
A Matter controller or hub, if connecting
using Matter.
See the complete line of My Leviton
TM
app compatible
dimmers, switches, plug-ins, and controllers at:
leviton.com/decorasmart
Easy Wi-Fi lighting
control for the
whole home.
If you need help...
ONLINE
decorasmartsupport.leviton.com
CHAT
www.leviton.com/support
EMAIL
CALL
1-800-824-3005 (USA)
1-800-405-5320 (Canada)
Leviton Manufacturing Co., Inc.
201 North Service Road, Melville, NY 11747
© 2023 Leviton Manufacturing Co., Inc. All rights reserved.
Specifications subject to change at any time without notice.
Status LED
Anywhere Companions are designed to provide a 50ft
wireless range to the primary device. When used with an
Outdoor Plug-In Switch placed outside, the range may be
reduced due to environmental factors.
PLEASE READ THESE INSTRUCTIONS
BEFORE INSTALLING
