User Manual
2
Heated Pad
Model No. HEA1838GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this
manual carefully paying particular attention to the
safety instructions. Failure to do so may result in
personal injury or damage to the product.
Carefully save this instruction manual for future reference.
Ensure the user manual is included when passing the
product on to any third parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Heated Pad.
• Before plugging your unit into the mains, visually check
that the unit is intact and has not suffered any transit
damage.
• DO NOT use this pad folded or rucked.
• DO NOT insert pins into this pad.
• This appliance can be used by children aged from 8 years
old and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by
children without supervision.
• The appliance can be used by children older than 3 years
and younger than 8 years under supervision and with the
controller always set to the minimum (1) temperature
3
Heated Pad
Model No. HEA1838GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
setting.
• Not to be used by very young children (0-3 years).
• This appliance is not to be used by young children over the
age of three unless the controls have been pre-set by a
parent or guardian, or unless the child has been
adequately instructed on how to operate the controls
safely.
• Children under the age of three are not to use this
appliance due to their inability to react to overheating.
• If sleeping for long periods of time, use the low heat
setting (1) to avoid overheating and discomfort.
• Avoid using the pad with the higher heat settings (3&4)
whilst sleeping as this may increase the risk of skin burns
and heat stroke.
• Only use the Controller marked on the rating label with
this blanket.
• Whilst storing the pad, allow it to fully cool then fold
neatly but not tightly or roll loosely avoiding sharp bends
in the heating element.
• DO NOT crease the appliance by placing other items on
top of the pad.
• Examine the appliance frequently for signs of wear or
damage. If there are such signs, if the appliance has been
misused or does not work return it to the supplier before
switching it on again.
• This pad is for domestic use only and is not intended for
commercial use or for use in hospitals.
• DO NOT use if damp or wet.
• This appliance must not be used by persons insensitive to
heat and other very vulnerable persons who are unable to
react to overheating.
• The appliance should not be used on an adjustable bed.
• When in use ensure the pad & mains lead do not get
trapped.
• The cable and control unit of the appliance can give rise to
4
Heated Pad
Model No. HEA1838GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
risks of entanglement, strangulation, tripping or treading if
not correctly arranged. The user shall make sure that
excess ties and electric cords shall be arranged in a safe
way.
• Arrange the pad so it is not positioned beneath bolsters or
pillows.
• DO NOT dry clean this heated pad, for cleaning follow the
instructions supplied.
• There are no user serviceable parts, the pad should only
be repaired or serviced by a qualified service engineer.
• It is recommended this heated pad is used in conjunction
with a residual current device (RCD) with a rated residual
operating current not greater than 30mA.
• This pad is only for use by humans and shouldn’t be used
for pets.
• When in use the control unit must not be placed near
open windows or inside the bed covers.
• Be sure the pad is only connected to an electrical supply
as specified in the instructions.
• Switch off the power and remove the plug from the socket
outlet when not in use.
• It is recommended that this appliance should not be used
whilst sleeping.
5
Heated Pad
Model No. HEA1838GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
This symbol indicates that the heater is double insulated and
therefore does not require an Earth connection.
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk enter your postcode to find out your
nearest recycling site.
This symbol provides useful additional information on the use of
this product.
This symbol indicates that the supply uses an alternating current
mains supply.
WARNING!
This designates a hazard with moderate risk, which may
result in severe injury if not adhered to.
6
Heated Pad
Model No. HEA1838GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1. Pad Connector
2. Heated Surface
3. Heat Level Display
4. Heat Select Button
5. ON/OFF Switch
6. Controller Connector
7. Mains Lead
Before the first use of Your Heated Pad
Remove all packing materials and discard responsibly.
Description of Parts
Using Your Heated Pad
2
1
3
4
5
6
1. Make sure Mains Plug is not inserted into the socket.
2. Plug the Pad Connector (6) into the Controller
Connector (1) and insert the mains plug into a socket.
3. Move the On/Off Switch (5) to ‘ON’ position
4. Press Heat Select Button (4) to
select the desired heat level
from 1 to 4 as shown on the
Heat Level Display (3). The
heat levels are shown right:
7
1
6
1 = Low
2 = Moderate
3 = Medium
4 = High
7
Heated Pad
Model No. HEA1838GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
During the first few minutes of initial use, you may notice a slight odour.
This is normal and will quickly disappear, It is the coating applied to the
heating elements to prevent any corrosion during transit.
This Heated Pad should never be used whilst folded or rucked as this will cause
overheating and the operation of the thermal safety device and stop the product
working.
Detaching the Controller
Before removing ensure the On/Off Switch (5) is set to ‘0’ (OFF) position and
remove the mains plug from the wall socket.
Lift the locking tab up and pull the controller connector directly out as shown
below.
Do not pull the controller cable or try and pull the controller connector out
without lifting the locking tab as the socket may be damaged.
Care and Maintenance
• Use only as a heated pad.
• Machine wash at 30˚C.
• Do not iron.
• Do not dry clean.
• Do not bleach.
• Line dry.
• Do not use folded or rucked.
• Do not insert pins into heated pad.
• Do not use the heated pad if wet or moist.
• Do not use with a helpless person, an infant or a person insensitive to heat.
• Not to be used by very young children (0-3 years).
8
Heated Pad
Model No. HEA1838GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Spot cleaning
Sponge the affected area using a lukewarm neutral detergent or a mild soap
solution. Follow this by sponging using clean water. Remove any excess water by
compressing the wet area between absorbent towels.
Washing the Heated Pad
WARNING!
• BEFORE WASHING, DISCONECT THE CONTROLLER FROM THE HEATED PAD AS
DESCRIBED ABOVE.
• DO NOT ALLOW THE CONTROLLER, ITS MAINS CABLE OR PLUG TO COME INTO
CONTACT WITH WATER OR ANY OTHER LIQUIDS.
Hand Washing
Immerse the heated pad only in a lukewarm neutral detergent or soap solution.
Soak for five minutes then remove from the solution and gently squeeze the
solution through the pad, rinse in clean water.
After washing, lay the pad flat or drape the pad over a clothesline to dry,
DO NOT use clothes pegs to secure it to the line.
DO NOT wring the pad.
Machine Washing
Disconnect the controller and place the pad in a net bag and seal it. Use a small
amount of detergent and set the washing machine to a “Delicate Wash” with a
maximum temperature of 30°.
After washing, lay the pad flat or drape the pad over a clothesline to dry,
DO NOT use clothes pegs to secure it to the line.
DO NOT wring the pad.
Technical Specification
Rated Voltage
220V-240V AC ~ 50Hz
Rated Power
85W
Model Number
HEA1838GE
Protection Class
II
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). Never use a plug with the fuse cover
missing, if in doubt, consult a qualified electrician.
If you need to remove the plug – DISCONNECT FROM THE MAINS – and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse the
plug or insert it into a socket outlet as there is a danger of electric shock.
9
Heated Pad
Model No. HEA1838GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken
to a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
10
Heated Pad
Model No. HEA1838GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with
proof of purchase or receipt. If any defect should occur due to faulty workmanship or
material, your faulty product should be returned to the place of purchase, replacement or
refund is at the discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged
through inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of
the original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to
the conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under license by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
