C
A E
D
Aligh the pin (C) with the hole of the shaft connector hole (E),
inset the shaft (A) to the shaft connector until the pin get into the hole(E)
and screw the knob (D) tightly.
Fig.1 Fig.2
2.Assemble the edger attachment tube to the engine tool (Fig.2)
Fig.3 Fig.4
(Fig.3)
ATTENTION: when working on flat ground, adjust the alignment guide board(E3) to be short,
and when working on road side with gap, adjust the alignment guide board (E3) to be longer
and fitable for tbe road gap
(Fig.4).
ATTENTION: when replacing parts or doing maintenance, make sure switching off the
engine until the cutting parts stop rotary.
