Congratulations on the purchase of your Lefant ROBOTS!
We hope it brings you satisfaction. We trust your purchase will keep your home clean and provide you a high-quality
life.
Should you encounter situations that have not been properly addressed in this User Manual, please contact our
Customer Service Center, we will solve your specific problem. For more information, please visit the Lefant ROBOTICS
official website: www.lefant.com or send email to the following email address:
The Company reserves the right to make technological or design changes to this product for continuous improvement.
2
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in
electric shock, fire or serious injury.
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.
1. The robot must be used in accordance with the
directions in this User Manual. Our company cannot be
held liable or responsible for any damages or injuries
caused by improper use.
2. Do not allow to be used as a toy. Close attention is
necessary when used by or near children.Do not allow
children to sit on the vacuum.
3. Clear the area to be cleaned. Remove power cords
and small objects from the floor that could entangle the
Robot. Tuck rug fringe under the rug base, and lift items
such as curtains and table cloths off the floor.
4. If there is a drop off in the cleaning area due to a step
or stairs, you should operate the Robot to ensure that it
can detect the step necessary to place a physical
barrier at the edge to keep the unit from falling. Make
sure the physical barrier is not a trip hazard.
5. Only use as described in this manual. Only use
attachments recommended or sold by the manufactur-
er.
6. Please make sure your power supply voltage matches
the power voltage marked on the Docking Station.
7. Do not handle or plug appliance with wet hands.
8. Non-rechargeable batteries are prohibited.
9. Do not use without dust bin and/or filters in place.
10. Do not operate the robot in an area where there are lit
candles or fragile objects on the floor to be cleaned.
11. Do not use and store in extremely hot or cold environ-
ments (below -5°C /23°F or above 40°C/104°F). Please
charge the robot in temperature above 0°C/32°F and
below 40°C/104°F. Follow all charging instructions and do
not charge the battery pack or appliance outside of the
temperature range specified in the instructions. Charging
improperly or at temperatures outside of the specified
range may damage the battery and increase the risk of
fire.
12. Keep hair, loose clothing, fingers, and all parts of body
away from any openings and moving parts.
13. Do not operate the robot in a room where an infant or
child is sleeping.
14. For INDOOR use ONLY. Do not use the robot in outdoor,
commercial or industrial environments. Do not use
Appliance on wet surfaces or surfaces with standing water.
For Household use only
When using an electrical appliance, basic precautions should always be followed, including the following:
3
15. Do not allow the robot to pick up large objects like
stones, large pieces of paper or any item that may clog
the robot.
16. Do not use the robot to pick up flammable or
combustible materials such as gasoline, printer or copier
toner, or use in areas where they may be present.
17. Do not use the robot to pick up anything that is burning
or smoking, such as cigarettes, matches, hot ashes, or
anything that could cause a fire.
18. Do not put any object into openings. Do not use with
any opening blocked; keep free of dust, lint, hair, and
anything that may reduce air flow.
19. Take care not to damage the power cord. Do not pull
on or carry the robot or the Docking Station by the power
cord, use the power cord as a handle, close a door on the
power cord, or pull power cord around sharp edges or
corners. Do not run the robot over the power cord.Keep
power cord away from hot surfaces. Do not unplug by
pulling on cord, To unplug, grasp the plug, not the cord.
20. If the power cord is damaged, it must be replaced by
the manufacturer or its service agent in order to avoid a
hazard.
21. Do not use the Docking Station if it is damaged.
22. Do not use the robot or the Docking Station if it is not
working properly, has been dropped, damaged, left
outdoors, or come in contact with water. It must be
repaired by the manufacturer or its service agent in order
to avoid a hazard.
23. Turn OFF the power switch before cleaning or
maintaining the robot. Turn off all controls
24. The plug must be removed from the receptacle
before cleaning or maintaining the Docking Station.
25. Remove the robot from the Docking Station, and turn
OFF the power switch to the Appliance before removing
the battery for disposal of the robot.
26. The battery must be removed and discarded
according to local laws and regulations before disposal
of the robot.
27. Please dispose of used batteries according to local
laws and regulations.
28. Do not incinerate the robot even if it is severely
damaged. The batteries can explode in a fire.
29. When not using the Docking Station for a long period
of time, please unplug it.
30. Prevent unintentional starting. Ensure the switch is in
the off position before connecting to battery pack,
picking up or carrying the appliance. Carrying the robot
with your finger on the switch or energizing the robot that
have the switch on invites accidents.
31. When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins,keys, nails,
screws,ect, that can make a connection from one
terminal to another. Shorting the battery terminals
together may cause burns or a fire.
32. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
4
flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
33. Do not use a battery pack that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion or risk
of injury.
34. Do not expose a battery pack or appliance to fire or
excessive temperature. Exposure to fire or temperature
above 130°C/265°F may cause explosion.
35. Have servicing performed by a qualified repair person
using only identical replacement parts.
36. Do not modify or attempt to repair the robot or the
battery pack (as applicable) except as indicated in the
instructions.
37. Do not operate the robot in a room that has lit
candles on furniture that the vacuum may accidentally
hit or bump into.
38. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
39. Use the robot only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
40. The robot contains batteries that are only replace-
able by skilled persons. To replace the robot's battery,
please contact Customer Service.
41. If the robot is not going to be used for a long time,
fully charge the robot, power it OFF, and unplug the
Docking Station.
SAVE THESE INSTRUCTIONS
Short-circuit-proof safety isolating transformer
Switch mode power supply
For indoor use only
Direct current
Alternating current
detachable supply unit
S
To satisfy RF exposure requirements, a separation
distance of 20 cm or more should be maintained
between this device and persons during device
operation.
To ensure compliance, operations at closer than this
distance is not recommended. The antenna used for this
transmitter must not be co-located in conjunction with
any other antenna or transmitter.
5
