Baridi 24 Bottle Dual Zone Wine Cooler,
Touch Screen, LED Light Black Glass Door
Model No. DH97
Thank you for purchasing a Baridi product from the Dellonda range. Manufactured to a high standard,
this product will, if used according to these instructions, and properly maintained, give you years of
trouble free performance.
DH97 Issue 2 15/04/24
2
Important Information
Please read these instructions carefully and note any safe operational requirements, warnings &
cautions. Use the product correctly and with care for the purpose for which it is intended. Failure
to do so may cause damage and/or personal injury and will invalidate the warranty. Keep these
instructions safe for future use.
• ELECTRICAL SAFETY
• WARNING! It is the user’s responsibility to
check the following:
• Check all electrical equipment and appliances
to ensure that they are safe before using.
Inspect power supply leads, plugs and all
electrical connections for wear and damage.
Sealey recommend that an RCD (Residual
Current Device) is used with all electrical
products.
• Electrical safety information. It is important
that the following information is read and
understood:
• Ensure that the insulation on all cables and on
the appliance is safe before connecting it to
the power supply.
• Regularly inspect power supply cables and
plugs for wear or damage and check all
connections to ensure that they are secure.
• IMPORTANT: Ensure that the voltage rating
on the appliance suits the power supply to be
used and that the plug is tted with the correct
fuse.
• DO NOT pull or carry the appliance by the
power cable.
• DO NOT pull the plug from the socket by the
cable.
• DO NOT use worn or damaged cables, plugs
or connectors. Ensure that any faulty item
is repaired or is replaced immediately by a
qualied electrician.
• If the cable or plug is damaged during use,
switch off the electricity supply and remove
from use.
• Ensure that repairs are carried out by a
qualied electrician.
• GENERAL SAFETY
• WARNING! IMPORTANT SAFETY
INSTRUCTIONS
• WARNING! To reduce the risk of re, electrical
shock, or injury when using your appliance,
follow these basic precautions:
• ·Before using the appliance, please read
this user manual to ensure that you gain the
maximum benet from it.
• WARNING:
• 1) This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
• 2) Children should be supervised to ensure
that they do not play with the appliance.
• 3) This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given supervision
or instruction concerning use of the appliance
in a safe way and understand the hazards
involved. Children shall not play with the
appliance. Cleaning and user maintenance
shall not be made by children without
supervision.
• 4) If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualied persons in order to avoid
a hazard.
• 5) To avoid a hazard due to instability of the
appliance, it must be xed in accordance with
the instructions.
• 6) When positioning the appliance, ensure the
supply cord is not trapped or damaged.
Refer to
instructions
Indoor use
only
3
• 7) DO NOT locate multiple portable socket-
outlets or portable power supplies at the rear
of the appliance.
• 8) Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obstruction.
• 9) DO NOT use mechanical devices or other
means to accelerate the defrosting process,
other than those recommended by the
manufacturer.
• 10) DO NOT damage the refrigerant circuit.
• 11) DO NOT use electrical appliances
inside the drink storage compartments of
the appliance, unless they are of the type
recommended by the manufacturer.
• 12) DO NOT store explosive substances such
as aerosol cans with a flammable propellant in
this appliance.
• 13) This appliance is intended to be used in
household and similar applications such as
• - staff kitchen areas in shops, ofces and
other working environments;
• - farm houses and by clients in hotels, motels
and other residential type environments;
• - bed and breakfast type environments;
• - catering and similar non-retail applications.
• 14) Children aged from 3 to 8 years are
allowed to load and unload refrigerating
appliances.
• 15) To avoid contamination of drink, please
respect the following instructions:
• - Opening the door for long periods can cause
a signicant increase of the temperature in the
compartments of the appliance.
• - Clean regularly surfaces that can come in
contact with drink and accessible drainage
systems.
• - Clean water tanks if they have not been used
for 48 h; flush the water system connected to
a water supply if water has not been drawn for
5 days.
• - If the refrigerating appliance is left empty
for long periods, switch off, defrost, clean,
dry, and leave the door open to prevent mould
developing within the appliance.
• ·Note: This appliance contains flammable
refrigerant R600a and foaming agent
cyclopentane.
• Please avoid contact re when you transport
and use it.
• Professional repair and servicing only.
• Please send to your local appointed disposal
station when you discard it.
• -Save these instructions-
• During use, service and disposal pay attention
to the symbol ‘Risk of re’ ( see below)
located in the rear of the appliance. There are
flammable materials in the refrigerant pipes
and the compressor. Keep away from any
sources of re during use and disposal.
• INTRODUCTION
• Sleek design with tempered mirror glass doors
to reflect UV light and help protect your wine.
Dual zone design means you can control the
temperature of each zone individually, with the
right and left zones ranging from 5-18°C. Soft
white LED light. Features ten stylish wooden
shelves made of beech with space for up to
12 bottles in each zone. Compressor cooling
technology with automatic defrost feature
to make this unit as easy as possible to use.
Ventilation Space - a minimum space of 10cm
is required at the rear, top and both sides of
the fridge. This will maximise the efciency,
performance and life of the fridge and ensure
that there is sufcient space for the hinge to
operate effectively.
• SPECIFICATION
Model No: DH97
Capacity: 24 Bottles
Dimensions (W x D x H): 510 x 460 x 800mm
Electrical Class: Class I
Energy Eciency
Class / Rating
G
Frequency: 50Hz
Max Bottle Height: 320mm
Noise Level: 42dB
Power Cable Length: 1.7m
Rated Current: 0.6A
Temperature Range: 5 - 18°C
Voltage: 230V
Volume: 65L
4
• INSTALLATION
• The unit is designed to be free-standing.
• Ventilation Space - a minimum space of
10cm is required for the rear, top and sides of
the fridge and 5cm under the base. This will
maximise the efciency, performance and
life of the fridge and also ensure that there
is sufcient space for the hinge to operate
effectively.
• DO NOT locate the unit in a damp or moist
location.
• DO NOT locate the unit in direct sunlight.
• Ensure that the floor surface is strong and
stable enough to support the unit when it is
fully loaded.
• Level the unit when in location by using the
adjustable levelling feet in each corner.
• Once in position allow the unit to rest for an
hour before turning it on.
• Allow the unit 2 - 3 hours to reach set
temperature after switching on before placing
any items in the compartment.
• PARTS AND FEATURES
• 1: Upper Hinge
• 2: Door Gasket
• 3: Door Handle
• 4: Shelves
• 5: Display Shelves
• 6: Bottom Hinge
1
2
3
4
5
6
• OPERATION
• To unlock settings for each section give one 2
second press on the symbol.
• To turn the light on press the symbol and
again for off.
• The light in the unit will turn off automatically
after 10 minutes if the unit is not used.
• To switch between Celsius and Fahrenheit
press on the symbol for 2 seconds.
• Use the symbol to increase the
temperature setting in each compartment.
• Use the symbol to lower the temperature
setting in each compartment.
• When you have set the desired temperatures
leave the keypad for 20 seconds and it will
lock and retain those settings.
• The light and temperature setting button will
work as normal.
• To unlock the keypad press the symbol
again.
• Temperature in the either section can range
from lowest 5°C/41°F to maximum 18°C/64°F.
• Left and right sections operate independently
of each other.
• Automatic defrost feature operates after 12
hours use and the unit will stop working for 30
minutes.
• Settings are retained after unit is switched off.
• MAINTENANCE
• Remove the power plug from the supply when
performing cleaning or maintenance.
• DO NOT use abrasive or chemical cleaning
materials on any surface of the unit.
• Wipe interior and exterior surfaces with a
damp cloth and dry thoroughly with a clean
dry cloth.
• For more soiled surfaces use a neutral
detergent, wipe down with a clean damp cloth
and dry thoroughly with a clean dry cloth.
5
TROUBLESHOOTING
• Error codes
• EE: “EE” is displayed when the temperature probe is short-circuited or disconnected and cooling is
stopped.
• LL: When the temperature measured by the temperature probe is lower than 0 degrees Celsius, “LL”
is displayed, LL flashes, and the unit is stopped.
• HH: When the temperature measured by the temperature probe is higher than 37 degrees Celsius,
“HH” is displayed, HH flashes, and the unit is stopped.
SYMPTOM SOLUTION
Unit does not operate. Not plugged in.
Fuse/circuit breaker failure.
Turns on and off frequently.
Poor cooling.
Room temperature higher than normal.
Door opened too often.
Door not properly closed.
Temperature control incorrectly set.
Door gasket not sealing.
Not enough space around unit.
Vibrations Check to assure unit is level.
Noisy unit Contraction/expansion of panels.
Unit not level.
Check fan operation.
Check heat pump.
Door will not close properly Unit not level.
Gasket distorted.
Internals out of position.
Dellonda Limited, Sole UK Distributor of Baridi
Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757575 [email protected] www.dellonda.co.uk
Environment Protection, Waste Electrical and Waste
Electronic Equipment Regulations (WEEE)
Recycle unwanted packaging materials. When this product is no longer required, or has
reached the end of its useful life, please dispose of in an environmentally friendly way.
Drain any fluids (if applicable) into approved containers, in accordance with local waste
regulations. It is our policy to continually improve products and we reserve the right to alter
data, specications and parts without prior notice. No liability is accepted for incorrect use
of this product. Guarantee is 12 months from purchase date, proof of which is required for
any claim.
