Read all of the instructions carefully before using the
appliance. In order to reduce the risk of fire, electric
shocks and personal injuries when using the appliance,
follow the basic safety precautions, including the following
safety instructions.
1.1 Safety definitions
Here you can find explanations of the safety signal words
used in this manual.
WARNING
This indicates that death or serious injuries may occur as
a result of non-observance of this warning.
CAUTION
This indicates that minor or moderate injuries may occur
as a result of non-observance of this warning.
NOTICE:
This indicates that damage to the appliance or property
may occur as a result of non-compliance with this
advisory.
Note:This alerts you to important information and/or tips.
1.2 General information
¡ Read this manual carefully.
¡ Keep the manual and the product information in a safe
place for future reference or for the next owner.
¡ Do not connect the appliance if it has been damaged in
transit.
1.3 Intended use
Only a licensed professional may connect appliances
without plugs. The manufacturer is not responsible for
damage caused by incorrect connections. An incorrect
connection is not covered by the Statement of Limited
Product Warranty.
Only use this appliance:
¡ For drying and freshening up fabrics that are washed
with water and suitable for dryers.
¡ for normal household use and in enclosed spaces in a
residential environment.
¡ up to an altitude of max. 13,100ft (4000m) above sea
level.
1.4 Restrictive Use
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
Do not let children play with the appliance.
Cleaning and user maintenance must not be performed by
children unless they are being supervised.
Keep children under the age of 3 and pets away from the
appliance.
1.5 Safe installation
WARNING
Incorrect installation is dangerous.
▶ Connect and operate the appliance only in accordance
with the specifications on the rating plate.
▶ Connect the appliance to a power supply with
alternating current only via a correctly installed socket
outlet with grounding.
▶ The protective conductor system of the domestic
electrical installation must be properly installed. The
installation must have a sufficiently large cable cross-
section.
▶ When using a residual current circuit breaker, only use
a type with the mark.
▶ Never equip the appliance with an external switching
device, e.g. a timer or remote control.
▶ Never connect the appliance to a circuit that is regularly
switched on and off by the energy supplier.
▶ When the appliance is installed, the power plug of the
power cord must be freely accessible. If free access is
not possible, an all-pole isolating switch must be
integrated in the permanent electrical installation
according to the installation regulations.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
en-us
5
▶ When installing the appliance, check that the power
cord is not trapped or damaged.
If the insulation of the power cord is damaged, that can be
dangerous.
▶ Never let the power cord come into contact with hot
appliance parts or heat sources.
▶ Never let the power cord come into contact with sharp
points or edges.
▶ Never kink, crush or modify the power cord.
WARNING
It is dangerous to use an extended power cord and non-
approved adapters.
▶ Do not use extension cords or multiple socket strips.
▶ Only use adapters and power cords approved by the
manufacturer.
▶ If the power cord is too short and a longer one is not
available, please contact an electrician to have the
domestic installation adapted.
WARNING
The high weight of the appliance may result in injury when
lifted.
▶ Do not lift the appliance on your own.
If this appliance is not correctly installed in a washer-dryer
stack, the installed appliance may fall.
▶ Only stack the dryer on a washing machine using the
connection kit from the dryer manufacturer
→
"Accessories", Page21
. No other installation
method is permitted.
▶ Do not install the appliance in a washer-dryer stack if
the dryer manufacturer does not offer a suitable
connection kit.
▶ Do not install appliances from different manufacturers
and with varying depths and widths in a washer-dryer
stack.
▶ Do not install a washer-dryer stack on a platform; the
appliances may tip over.
WARNING
Children may pull packaging material over their heads, or
wrap themselves up in it and suffocate.
▶ Keep packaging material away from children.
▶ Do not allow children to play with packaging material.
CAUTION
The appliance may vibrate or move when in use.
▶ Place the appliance on a clean, even, solid surface.
▶ Align the appliance using the appliance feet and a spirit
level.
If hoses and power cords have been laid incorrectly, this
causes a tripping hazard.
▶ Lay hoses and power cords in such a way that there is
no risk of tripping.
If the appliance is moved by holding onto protruding
components, such as the appliance door, the parts may
break off.
▶ Do not move the appliance by holding onto protruding
parts.
CAUTION
Touching sharp edges on the appliance may lead to cuts.
▶ Do not touch the sharp edges on the appliance.
▶ Wear protective gloves when installing and transporting
the appliance.
1.6 Safe use
WARNING
If the appliance or the power cord is damaged, this is
dangerous.
▶ Never operate a damaged appliance.
▶ Never pull on the power cord to unplug the appliance.
Always unplug the appliance at the power outlet.
▶ If the appliance or the power cord is damaged,
immediately unplug the power cord or switch off the
breaker in the circuit breaker box.
▶ Call Customer Service. →
Page34
Moisture intrusion may cause an electric shock.
▶ Use the appliance in enclosed spaces only.
▶ Never expose the appliance to intense heat or humidity.
▶ Do not use steam cleaners, high-pressure cleaners,
hoses or sprays to clean the appliance.
WARNING
Children can lock themselves in the appliance, thereby
putting their lives at risk.
▶ Do not install the appliance behind a door as this may
obstruct the appliance door or prevent it from opening.
▶ With redundant appliances, pull out the mains plug of
the power cord, cut through the power cord and remove
the appliance door.
WARNING
Children may breathe in or swallow small parts, causing
them to suffocate.
▶ Keep small parts away from children.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
en-us
6
▶ Do not allow children to play with small parts.
WARNING
If there is coal dust or flour in the air around the appliance,
this may cause an explosion.
▶ Keep the area around the appliance clean during
operation.
WARNING
Condensation water from this appliance is not suitable for
drinking and may be contaminated with lint.
▶ Do not drink or reuse the condensation water from the
appliance.
Detergents and care products may result in poisoning if
consumed.
▶ If accidentally swallowed, seek medical advice.
▶ Keep detergents and care products out of the reach of
children.
WARNING
The refrigerant R290 in this appliance is environmentally
friendly yet combustible and may ignite if it comes into
contact with open flames or ignition sources.
▶ Keep naked flames and ignition sources away from the
appliance.
WARNING
If there is any residual material left in the lint screen, this
may ignite during the drying process.
▶ Clean the lint screen regularly.
Highly flammable objects such as lighters or matches may
ignite during the drying process.
▶ Remove all highly flammable objects from any pockets
in your laundry before the drying process.
Unwashed laundry that has come into contact with
solvents, oil, wax, wax remover, paint, grease or stain
remover may ignite when drying is in progress.
▶ Do not place laundry in this appliance to be dried if the
laundry has not been washed first.
▶ Rinse the laundry thoroughly with warm water and
detergent before drying it in the machine.
▶ Do not use the appliance if industrial chemicals have
been used to clean the laundry beforehand.
WARNING
If drying is interrupted early, the laundry is not cooled
sufficiently and may ignite.
▶ Do not interrupt the drying programme early.
▶ If drying is interrupted early, remove the laundry
immediately and spread it out.
CAUTION
The covering plate may break if you stand on or climb
onto the appliance.
▶ Do not stand on or climb onto the appliance.
The appliance may tip over if you sit on or lean against the
open door.
▶ Do not sit on or lean against the appliance door.
▶ Do not place any objects on the appliance door.
Reaching into the drum while it is still turning may cause
hand injuries.
▶ Wait for the drum to come to a complete stop before
reaching inside.
1.7 Safe cleaning and maintenance
WARNING
Improper repairs are dangerous.
▶ Never make any technical modifications to the
appliance or its features.
▶ Do not tamper with controls.
▶ Repairs to the appliance should only be performed by
authorized service providers.
▶ Only original spare parts may be used to repair the
appliance.
▶ If the power cord of this appliance becomes damaged,
it must be replaced by the manufacturer, the
manufacturer's Customer Service, or an authorized
service provider in order to prevent injury.
Moisture intrusion may cause an electric shock.
▶ Before cleaning, pull out the power plug or switch off
the circuit breaker in the circuit breaker box.
▶ Do not use steam cleaners, high-pressure cleaners,
hoses or sprays to clean the appliance.
WARNING
The use of non-original spare parts and non-original
accessories is dangerous.
▶ Only use the manufacturer's original spare parts and
original accessories.
WARNING
Poisonous fumes may be given off if you use cleaning
agents that contain solvents.
▶ Do not use cleaning agents that contain solvents.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
en-us
7
1.8 State of California Proposition 65
Warnings
This product may contain a chemical known to the State
of California, which can cause cancer or reproductive
harm. Therefore, the packaging of your product may bear
the following label as required by California:
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
en-us Preventing material damage
8
Preventing material damage
2 Preventing material damage
Preventing material damage
NOTICE:
The functionality of the appliance may be impaired if you
use the wrong quantity of fabric softener, detergent, care
product or cleaning agent.
▶ Follow the dosage recommendations from the
manufacturer.
▶ Only use fabric softeners or products to eliminate static
that are specifically recommended for this purpose by
the product manufacturer.
Exceeding the maximum load capacity impairs the
function of the appliance.
▶ Observe the maximum load capacity for each
programme and do not exceed it.
→
"Programs", Page19
The function of the appliance may be impaired if the
appliance overheats.
▶ Keep the ventilation opening on the appliance clear
during operation.
▶ Make sure that the area is adequately ventilated.
Light objects such as hair and lint may be sucked in from
the ventilation opening on the appliance during operation
and impair the function of the appliance.
▶ Keep the area around the appliance clean during
operation.
▶ Keep light objects away from the appliance.
If you operate the appliance without a lint guard (e.g. lint
screen, lint collector, filter mat, etc., depending on
appliance specifications), or if the lint guard is incomplete
or defective, this may result in damage to the appliance.
▶ Do not operate the appliance without a lint guard, or
with a lint guard that is incomplete or defective.
Foam or foam rubber may deform or melt during the
drying process.
▶ Do not dry laundry that contains foam or foam rubber.
Unsuitable cleaning agents may damage the surfaces of
the appliance.
▶ Do not use strong or abrasive cleaning agents.
▶ Do not use cleaning agents with a high alcohol content.
▶ Do not use hard scouring pads or cleaning sponges.
▶ Clean the appliance with nothing but water and a soft,
damp cloth.
▶ Remove all detergent residue, spray residue or other
residues immediately if they come into contact with the
appliance.
Environmental protection and energy-saving
3 Environmental protection and
energy-saving
Environmental protection and energy-saving
3.1 Disposal of packaging
The packaging materials are environmentally compatible
and can be recycled.
▶ Sort the individual components by type and dispose of
them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use
less power.
Operate the appliance in a well-ventilated room and keep
the ventilation opening on the appliance clear.
a
If air exchange is impeded, this extends the program
duration and increases energy consumption.
Spin the laundry in the washing machine before drying.
a
Damper laundry extends the program duration and
increases energy consumption.
Observe the program's maximum load capacity.
→
"Programs", Page19
a
If the maximum load is exceeded, this extends the
program duration and increases energy consumption.
After drying, clean the lint screen →
Page22
.
a
If the lint screen is dirty, this reduces the air flow in the
appliance, extends the program duration, and increases
energy consumption.
Deactivate Wi-Fi on the appliance if it is not being used.
→
"Deactivating Wi-Fi on the appliance", Page26
.
a
If the Wi-Fi is activated, this increases energy
consumption.
3.3 Energy-saving mode
If you do not use the appliance for an extended period, it
automatically switches to energy-saving mode. All displays
go out and flashes.
Energy-saving mode ends when you use the appliance
again.
If you do not continue operating the appliance, it
automatically switches to standby mode.
Installation and connection
4 Installation and connection
Installation and connection
4.1 Unpacking the appliance
NOTICE:
Objects remaining in the drum that are not designed for
operation with the appliance may cause material damage
and damage to the appliance.
▶ Remove these objects, along with all supplied
accessories, from the drum before starting the
appliance.
1. Remove any packaging and protective covers
completely from the appliance.
→
"Disposal of packaging", Page8
2. Check the appliance for visible damage.
3. Open the door.
4. Remove any accessories from the drum.
Installation and connection en-us
9
5. Close the door.
4.2 Included in delivery
After unpacking all the parts, check for any damage in
transit and for completeness of delivery.
NOTICE:
If the appliance is operated with incomplete or defective
accessories, the appliance may not be able to operate
properly, or this may result in material damage and
damage to the appliance.
▶ Do not operate the appliance with incomplete or
defective accessories.
▶ Replace the accessories in question before operating
the appliance.
→
"Accessories", Page21
The delivery consists of the following:
¡ Tumble dryer
¡ Accompanying documents
¡ Water outlet hose with connection adapter, fixing
material, and elbow.
→
"Water drain hose", Page9
¡ Stopper
→
"Connecting the condensation container", Page10
¡ Condensation hose
→
"Connecting the condensation container", Page10
¡ Power adapter with fuses
4.3 Requirements for the installation location
NOTICE:
If the appliance is tilted at an angle greater than 40°,
residual water may leak out of the appliance and cause
material damage.
▶ Tilt the appliance carefully.
▶ Transport the appliance in an upright position.
If residual water in the appliance freezes, this may cause
damage to the appliance.
▶ Do not install or operate this appliance anywhere that is
liable to experience frost and/or outdoors.
If the appliance is operated immediately after
transportation, the refrigerant contained in the appliance
may cause damage to the appliance.
▶ Immediately after transporting the appliance, leave it to
rest for two hours before putting it into operation.
Installation location Requirements
On the floor Place the appliance on a
clean, level, and firm
surface.
Align the appliance
→
Page11
.
Installation location Requirements
In a washer-dryer stack Only use the original
connection set from the
dryer manufacturer when
setting up this appliance in
a washer-dryer stack.
¡ Connection kit
→
Page21
This appliance must only be
stacked on a washing
machine from the same
manufacturer. The depth
and width of this appliance
must correspond with the
dimensions of the washing
machine.
Do not place the washer-
dryer stack on a platform.
Against a wall Do not trap the hoses and
power cord between the
wall and the appliance.
4.4 Water drain hose
Condensation that forms in the appliance as it dries the
laundry is drained by default into the waste water system
using the water outlet hose.
Note
¡ Operate this appliance using the water outlet hose
provided.
→
"Connecting the water outlet hose", Page9
If you connect the water outlet hose, you do not have to
regularly empty the condensation container.
→
"Emptying the condensation container", Page24
Connecting the water outlet hose
NOTICE:
When operating the appliance without the water drain
hose being connected properly, liquid may leak out of the
connecting piece.
▶ Before operating the appliance, connect the water drain
hose properly to the connecting piece.
Requirements
¡ The appliance and the accessory have been unpacked.
→
"Unpacking the appliance", Page8
¡ The appliance is installed at the installation location.
→
"Requirements for the installation location", Page9
¡ The water outlet hose is connected to the appliance.
▶ Connect the appliance to the water outlet.
→
"Water drain connection types", Page10
en-us Installation and connection
10
Water drain connection types
NOTICE:
In the event of a blocked or covered outlet, accumulated
wastewater can flow back into the appliance.
▶ Before operating the appliance, ensure that the
wastewater drains away quickly and eliminate any
blockages.
Drainage into a siphon. Secure the connection point
with a (1/2″-7/8″
(12-22mm)) hose clamp.
Secure the water drain
hose with a hose guide at a
height of at least 311/2″
(80cm) and no more than
393/8″ (100cm).
Note:You can use the Y-
distributor →
Page21
to
connect the water drain
hose of an additional
appliance, such as a
washing machine, to the
same siphon outlet.
Drainage into a washbasin. Push the water drain hose
fully through the elbow and
secure it using fixing
material.
Secure the elbow at a
height of no more than
393/8″ (100cm).
Drainage into a gully. Push the water drain hose
fully through the elbow and
secure it using fixing
material.
Secure the elbow to the
gully.
4.5 Connecting the condensation container
During the drying cycle, condensation forms; you can use
the water outlet hose to drain away this condensation
directly into the waste water system. If this is not possible
at the appliance's installation location, connect the
condensation container.
Note:Operate this appliance using the water outlet hose
provided.
→
"Connecting the water outlet hose", Page9
If you connect the water outlet hose, you do not have to
regularly empty the condensation container.
→
"Emptying the condensation container", Page24
NOTICE:
When operating the appliance without the water drain
hose being connected properly, liquid may leak out of the
connecting piece.
▶ Before operating the appliance, connect the water drain
hose properly to the connecting piece.
Requirements
¡ The appliance and the accessory have been unpacked.
→
"Unpacking the appliance", Page8
¡ The appliance is installed at the installation location.
→
"Requirements for the installation location", Page9
1. Empty the condensation container.
→
"Emptying the condensation container", Page24
2. Remove the stopper from the recess in the top and
insert it in the underside .
When the appliance is delivered, the stopper is included
as an accessory in the scope of delivery.
3. Insert the condensation container.
→
"Inserting the condensation container", Page25
4. Pull the water outlet hose out of the connecting piece.
The water outlet hose is connected to the connecting
piece at the factory.
Note:When removing the water outlet hose, liquid may
leak out of the hose or connecting piece.
Do not dispose of or kink the water outlet hose; instead,
store it in a clean, dry place for later use.
Installation and connection en-us
11
5. Pull the condensation hose out of the holder.
6. Push the condensation hose as far as it will go onto the
connecting piece.
Tip:To go back to using the water outlet hose to drain the
condensation into the waste water system (e.g. if you
change where the appliance is located), carry out these
steps in reverse order.
4.6 Aligning the appliance
In order to reduce noise and vibrations, align the appliance
correctly.
▶ To align the appliance, turn the appliance feet. Check
that the appliance is level using a spirit level.
All appliance feet must stand firmly on the ground.
4.7 Reversing the door
To make it easier to place and remove laundry in the
drum, you can change the side on which the door is
hinged.
CAUTION
Touching sharp edges on the appliance may lead to cuts.
▶ Do not touch the sharp edges on the appliance.
▶ Wear protective gloves when installing and transporting
the appliance.
Notes
¡ Only use a Torx T15 screwdriver and a Torx T20
screwdriver to remove and insert screws.
¡ To prevent material damage, lay the removed door on a
level and soft surface.
Removing the door
Requirement:The appliance is disconnected from the
mains.
1. Open the door.
en-us Installation and connection
12
2. Unscrew the door.
Changing the door hinge and door hook
1. Unscrew the door hinge cover.
2. Unscrew the door hinge and the door hook.
3. Screw the door hinge and the door hook onto the
opposite sides.
When you do this, ensure that the door seal is not
trapped or damaged.
4. Screw on the door hinge cover.
When you do this, ensure that the door seal is not
trapped or damaged.
Installation and connection en-us
13
5. Remove the color door handle indicator and swap it with
the cover on the opposite side.
Select the position of the door handle indicator based
on the appliance's installation location:
– The appliance is installed on the floor.
– The unit is installed in a raised position in a
washer-dryer stack.
Changing the door lock
1. Unscrew the door lock cover.
2. Remove the door lock.
3. Insert the door lock on the opposite side.
4. Screw on the door lock cover.
5. Screw on the door.
4.8 Connecting the appliance to the
electricity supply
1. Insert the power adapter with the line side into a
suitable socket close to the appliance.
Observe the user manual that is enclosed with the
power adapter.
Familiarizing yourself with your appliance en-us
15
Familiarizing yourself with your appliance
5 Familiarizing yourself with your appliance
Familiarizing yourself with your appliance
5.1 Appliance
Here you can find an overview of the parts of your appliance.
1
2
3
4
5
On certain models, specific details such as the color and shape may differ from those pictured.
1
Ventilation opening
2
Lint screen →
Page22
3
Door
4
Condensation container →
Page24
5
Control panel →
Page16
en-us Familiarizing yourself with your appliance
16
5.2 Control panel
You can use the control panel to configure all functions of your appliance and to obtain information about the operating
status.
3
1 1
2
1
Programs →
Page19
2
Program selector →
Page21
3
Buttons →
Page18
and display →
Page17
5.3 Operating logic
Some areas of the display are buttons and respond to
touch. You can activate, deactivate or change settings by
pressing the buttons. The activated settings are
highlighted brightly on the display.
NOTICE:
Pressing on the display with force may cause damage.
▶ Do not apply heavy pressure on the display.
▶ Do not press on the display using pointed or sharp
objects.
Changing a setting value
If you activate certain settings, the display shows selection
buttons and you can change the setting value.
▶
Press the selection buttons →
Page18
.
The display shows the setting value.
Display en-us
17
Display
6 Display
Display
The display shows the current settings, options or relevant information.
Example: Display
Display Description
00:40
1
Expected program duration or program time remaining in hours and minutes.
10h
1
Program end time
→
"Buttons", Page19
You can remove or add laundry, and interrupt the current program.
→
"Adding laundry", Page22
Empty and insert the condensation container.
→
"Emptying the condensation container", Page24
Clean the lint screen.
→
"Cleaning the lint screen", Page22
CArE Run the basic appliance care program.
→
"Appliance care", Page27
Hot The cooling process cools the laundry for a few minutes while the drum is rotating, in
order to avoid damage to the laundry. The cooling process can be cancelled by opening
the door.
Note:Do not change the set program.
¡ Lights up: The appliance is connected to your home network via Wi-Fi.
¡ Flashes: The appliance is trying to connect to your home network via Wi-Fi.
→
"HomeConnect ", Page25
Settings that are not available on the appliance have been set via the HomeConnect app.
You can find more information in the HomeConnectapp.
Anti-crease
Program status
Pause
Program status
End Program end
Program status
1
Example
en-us Buttons
18
Buttons
7 Buttons
Buttons
Below is an overview of the buttons and their setting options.
Button Selection Description
¡ Start
¡ Cancel
¡ Pause
Start, cancel or pause the program.
If is displayed, you can pause the
program.
If is displayed, you can start the
program.
(mains switch) ¡ Switch on
¡ Standby mode
¡ Restart the appliance
Switch on the appliance or put it in
standby mode.
If the control panel does not respond,
press and hold for approximately
5seconds to restart the appliance.
→
"The appliance is not working.",
Page31
3 Sec. ¡ Activate
¡ Deactivate
Activate or deactivate the control panel
lock.
Disable the control panel to prevent
unwanted or accidental operation.
If the control panel lock is activated
and the appliance has been switched
off, the control panel lock remains
activated.
→
"Control panel lock", Page25
Multiple selection To change a setting, press the or
selection button until the display
shows the required setting.
Basic Settings Multiple selection
→
"Basic settings", Page27
Favorite ¡ Save
¡ Set
Press the button for approx. 3 seconds
to save your customized program
settings.
→
"Saving the program settings",
Page22
If you briefly press the button, you can
set customized program settings for
your program.
Extra Dry ¡ Activate
¡ Deactivate
The dryness level defines how damp or
dry the laundry is after the program
ends.
→
"Dryness level", Page25
Dry ¡ Activate
¡ Deactivate
The dryness level defines how damp or
dry the laundry is after the program
ends.
→
"Dryness level", Page25
Iron Dry ¡ Activate
¡ Deactivate
The dryness level defines how damp or
dry the laundry is after the program
ends.
→
"Dryness level", Page25
Wrinkle Block ¡ Activate
¡ Deactivate
Activate or deactivate the crease-
reduction function.
Once the program has ended, the
drum moves the laundry at regular
intervals for 120 minutes to prevent
creasing.
Programs en-us
19
Button Selection Description
Low Heat ¡ Activate
¡ Deactivate
Activate or deactivate gentle drying.
The temperature is reduced for
delicate fabrics, e.g. polyacrylic or
elastane.
The program duration is extended.
Finish in Up to 24 hours Set the program end time.
The program duration is already
included in the set number of hours.
Once the program has started, the
program duration is displayed.
SmartDry Activate After you have washed your laundry in
the washing machine, the dryer
recommends a suitable program for
drying the laundry.
Note:The washing machine must be
compatible with HomeConnect. The
washing machine and dryer must be
connected to your home network and
registered in your HomeConnect app.
Remote Start ¡ Activate
¡ Deactivate
¡ Open the HomeConnect menu
→
"Remote start", Page26
Programs
8 Programs
Programs
You can dry your fabrics using either an automatic
program or a timed program.
1
2
3
1
Large load
2
Medium load
3
Small load
8.1 Automatic programs
Automatic programs are programs in which humidity
sensors measure the residual moisture in the laundry
during the drying cycle. The program only ends once the
set dryness level is reached.
Each automatic program has a dryness level →
Page25
.
The dryness level defines how dry or damp your laundry is
after the program ends.
Tips
¡ Select the dryness level according to the type of fabric
or the desired drying result.
→
"Dryness level", Page25
¡ The laundry's care labels provide you with additional
information on program selection.
Program Description Max. load
Cotton Dry hard-wearing, heat-resistant fabrics made of cotton or linen. large
en-us Programs
20
Program Description Max. load
Mix Dry items made of cotton and synthetics. small
Bedding Dry quilt covers, pillowcases, and sheets made of cotton.
Note:The drum movement is optimized for drying large items of
laundry.
medium
Delicates Dry delicate items made of satin, synthetics, or blended fabrics. small
Sanitize Dry hard-wearing, heat-resistant fabrics made of cotton or linen.
Note:Particularly suitable for strict hygiene requirements.
medium
Jeans Dry jeans and thick, double-layered items made of cotton.
Note:Turn laundry inside out before drying.
medium
Sportswear Dry self-drying sportswear made of performance fibers,
microfibers and synthetics.
small
Quick Dry Auto Dry items made of synthetics or light cotton. small
Towels Dry hard-wearing, heat-resistant towels and robes made of cotton
or linen.
medium
App Programs Select additional programs directly via the HomeConnect app.
A description of the programs can be found in the HomeConnect
app.
Note:Your appliance must be connected to your home network
and registered in your HomeConnect app.
→
"HomeConnect ", Page25
–
8.2 Timed programs
Timed programs are programs with a defined or adjustable program duration. The program ends once this time has
elapsed, even if the laundry is still not dry, for example. Timed programs are suitable for drying individual items of laundry
or thin fabrics.
Tip:The laundry's care labels provide you with additional information on program selection.
Program Description Max. load
Hand Wash/Wool Dry machine-washable items made of wool or containing wool.
Note:The laundry becomes fluffier but not dry.
Remove laundry once the program has ended and allow it to dry.
medium
Air Fluff Fluff/loosen all fabric types except for wool and silk.
This program is suitable for fluffing dry laundry only.
Also suitable for freshening up or airing dry clothing that has
hardly been worn.
Note:This program is suitable for drying using the wool basket.
small
Time Dry Dry all types of fabric except for wool and silk.
Suitable for pre-dried or slightly damp laundry and for drying off
multi-layered, thick laundry.
Note:This program is suitable for drying using the wool basket.
If you are using the wool basket, you can also dry fabrics made
from wool using this program.
small
App Programs Select additional programs directly via the HomeConnect app.
A description of the programs can be found in the HomeConnect
app.
Note:Your appliance must be connected to your home network
and registered in your HomeConnect app.
→
"HomeConnect ", Page25
–
Anti Shrink Pre-dry items made from cotton, linen, or synthetic fabrics.
Suitable for pre-drying slightly damp laundry.
To reduce creasing, hang up the laundry directly after pre-drying.
small
Accessories en-us
21
Accessories
9 Accessories
Accessories
Only use original accessories. These are designed
especially for your appliance.
Note:Some accessories are available in other colors.
Contact
→
"Customer Service", Page34
.
Use Order number
Elbow Secure the water drain hose in place. 00655300
Connection kit To save space, stack the appliance on a suitable washing
machine of the same width and depth, and that is from the same
manufacturer.
WTZ27510UC
Wool basket Dry or air individual woolen items, sports shoes, and soft toys. WMZ20600
Y-distributor Connect the water drain hose of an additional appliance to the
same siphon outlet.
15000490
Appliance care product Spare part for the intensive appliance care function. 00311829
Platform Install the appliance at a raised height so that it can be easily
loaded and unloaded.
WTZPW20D
Power adapter Connect the appliance to a NEMA 14-30 (4-pin) outlet. WTZPA20UC
Power adapter Connect the appliance to a NEMA 10-30 (3-pin) outlet. WTZPA30US
Fuses Spare part for the power adapter to protect the appliance from
damage due to overloads and short circuits.
10013781
Laundry
10 Laundry
Laundry
10.1 Preparing the laundry
NOTICE:
Objects remaining in the laundry may damage the laundry
and the drum.
▶ Remove all items from any pockets in your laundry
before using the appliance.
Note
The appliance and fabrics are protected when you prepare
your laundry.
¡ Brush off sand and soil
¡ Sort the laundry according to color and fabrics and
observe the care labels
¡ Close all zippers, hook and loop fasteners, hooks and
eyes
¡ Remove curtain fittings and lead strips
¡ Load the laundry unfolded into the drum
¡ Spin the laundry before drying
¡ Dry woolen items, sports shoes and soft toys in the
wool basket
Basic Operation
11 Basic Operation
Basic Operation
11.1 Switching on the appliance
Note:If you switch the appliance on the first time after you
have connected it to the electrical system, the switch-on
process takes up to one minute.
Requirement:The appliance has been correctly installed
and connected.
→
"Installation and connection", Page8
▶ Press .
The switch-on process takes a few seconds.
Note:The lighting for the drum goes out automatically.
11.2 Setting a program
1. Press the required program.
→
"Programs", Page19
a The display shows the program settings.
2. If required, adjust the program settings.
→
"Adjusting the program settings", Page22
en-us Basic Operation
22
11.3 Adjusting the program settings
Depending on the program and program progress, you
can adjust or activate/deactivate the settings.
Requirement:A program has been set.
→
"Setting a program", Page21
▶ Adjust the program settings.
→
"Buttons", Page18
Observe the information about operating logic
→
Page16
.
Note:The program settings are not saved permanently for
the program.
11.4 Saving the program settings
You can save your individual program settings as
favorites.
Requirements
¡ A program has been set.
→
"Setting a program", Page21
¡ The program settings have been adjusted.
→
"Adjusting the program settings", Page22
▶ Press and hold Favorite for approximately 3 seconds.
Press Favorite to call up the saved program.
Note:To overwrite the saved program, repeat the steps
above.
11.5 Loading laundry
Note:To prevent creasing, note the maximum load for the
programs.
→
"Programs", Page19
Requirements
¡ The laundry is prepared and sorted.
→
"Laundry", Page21
¡ The drum is empty.
1. Open the door.
2. Place the laundry in the drum.
3. Close the door.
Ensure that there is no laundry trapped in the door.
11.6 Starting the program
Requirement:A program has been set.
→
"Setting a program", Page21
▶ Press .
a The display shows the program duration or the program
end time.
a After the program has ended, the display shows: "End".
Note:If "Hot" appears, the appliance cools the laundry.
When "Hot" goes out, the laundry has cooled down.
11.7 Adding laundry
After the program starts, you can remove or add laundry at
any time.
1. Press .
The cooling process starts automatically after
approximately 30 seconds and cools down the laundry
while the drum is rotating. If you want to avoid or cancel
the cooling process, open the door.
→
"Display", Page17
2. Open the door.
3. Add or remove laundry.
4. Close the door.
5. Press .
11.8 Terminating the program
1. Press .
2. Open the door.
3. Remove the laundry.
→
"Removing the laundry", Page22
11.9 Removing the laundry
1. Open the door.
2. Remove the laundry from the drum.
11.10 Put the appliance into standby mode
▶ Press .
11.11 Lint screen
During drying, lint from the laundry is collected in the lint
screen. The lint screen protects the appliance from lint.
Cleaning the lint screen
If the drying program has finished or the display shows a
notification while the appliance is in operation, clean the
lint screen.
Note:If you do not clean the appliance as described, the
appliance's functionality may be impaired.
Requirements
¡ The display shows the following after drying: "End"
¡ or the display shows the following during operation: .
1. Open the door.
Basic Operation en-us
23
2. Remove the lint from the door.
3. Remove the two-part lint screen.
4. Remove the lint from the recess.
Ensure that no lint falls into the air channel.
5. Disconnect the two-part lint screen.
6. Open the two lint screens.
7. Remove the lint.
en-us Basic Operation
24
8. Clean the two lint screens thoroughly under warm,
running water and then dry them off.
9. Close the two lint screens and put them together.
10.Insert the two-part lint screen.
11.Close the door.
11.12 Condensation container
If you have connected the condensation container, your
appliance uses this to collect any condensation.
Note:Operate this appliance using the water outlet hose
provided.
If you connect the water outlet hose, you do not have to
regularly empty the condensation container.
→
"Emptying the condensation container", Page24
Emptying the condensation container
If the drying program has finished or the display shows a
notification while the appliance is in operation, empty the
condensation container.
Requirements
¡ The display shows the following after drying: "End"
¡ or the display shows the following during operation: .
1. Pull out the condensation container, keeping it level.
2. Empty the condensation container.
Check the condensation container filter →
Page29
regularly, and clean the filter if it is dirty.
Make sure that you insert the condensation container
before operating the appliance.
→
"Inserting the condensation container", Page25
Dryness level en-us
25
Inserting the condensation container
▶ Push the condensation container in as far as it will go.
Dryness level
12 Dryness level
Dryness level
Each automatic program has a specified dryness level.
The dryness level defines how dry or damp your laundry is
after the program ends.
Dryness level Description
Extra Dry For multi-layered, thick laundry
that does not dry readily.
Dry For normal, single-layered
laundry.
Iron Dry For normal, single-layered
laundry.
The laundry is still slightly damp
after the program ends. To
prevent creasing after drying, iron
the laundry or hang it up.
12.1 Changing the dryness level
For some automatic programs, you can change the
dryness level so that your laundry will be drier or more
damp.
1.
Set an automatic program. →
Page19
a The display shows the specified dryness level.
2. Press Dry, Extra Dry or Iron Dry.
12.2 Adjusting the dryness level
If the laundry feels too damp after it has been dried to a
particular dryness level, you can adjust the dryness level.
Note:You can also adjust the dryness level in the basic
settings.
1.
Set an automatic program. →
Page19
a The display shows the specified dryness level.
2. Press and hold Dry, Extra Dry or Iron Dry for
approximately 3seconds.
3. Press or to adjust the dryness level.
4. Press and hold the selected dryness level for
approximately 3seconds to return to the automatic
program.
Control panel lock
13 Control panel lock
Control panel lock
Secure your appliance against being operated
unintentionally using the controls.
13.1 Activating the control panel lock
▶ Press and hold 3 Sec. for around 3seconds.
a The control elements are locked.
a The control panel lock also remains activated when the
appliance is in standby mode and in the event of a
power failure.
13.2 Deactivating the control panel lock
Requirement:To deactivate the control panel lock, the
appliance must be switched on.
▶ Press and hold 3 Sec. for around 3seconds.
HomeConnect
14 HomeConnect
HomeConnect
This appliance is network-capable. Connecting your
appliance to a mobile device lets you control its functions
via the HomeConnect app, adjust its basic settings and
monitor its operating status.
The HomeConnect services are not available in every
country. The availability of the HomeConnect function
depends on the availability of HomeConnect services in
your country. You can find information on this at:
www.home-connect.com.
The HomeConnect app guides you through the entire
registration process. Follow the instructions in the
HomeConnect app to implement the settings.
Tip:Follow the instructions in the HomeConnect app as
well.
Notes
¡ Also note the safety information in this instruction
manual and ensure that it is also observed when
operating the appliance using the HomeConnect app.
→
"Safety", Page4
¡ Operating the appliance on the appliance itself always
takes priority. It is not possible to operate the appliance
using the HomeConnect app during this time.
14.1 Setting up the HomeConnect app
1. Install the HomeConnect app on your mobile device.
2. Start the HomeConnect app and set up access for
HomeConnect.
The HomeConnect app guides you through the entire
registration process.
en-us HomeConnect
26
14.2 Setting upHomeConnect
Requirements
¡ The HomeConnectapp is installed on your mobile
device.
¡ The appliance receives signals from the WLAN home
network (Wi-Fi) at its installation location.
1. Press and hold Remote Start for around 3seconds.
2. Follow the instructions in the HomeConnect app.
14.3 HomeConnect menu
The HomeConnect menu contains all of the
HomeConnect settings.
Calling up the HomeConnect menu
▶ Press and hold Remote Start for at least 3seconds.
a The display shows the first setting of the HomeConnect
menu.
Navigating in the HomeConnect menu
▶ Briefly press Remote Start until the display shows the
required setting.
Exiting the HomeConnect menu
▶ Press and hold Remote Start for at least 3seconds.
14.4 Activating Wi-Fi on the appliance
Requirements
¡ The HomeConnect menu is called up. →
Page26
¡ The display shows "oFF".
▶ Press to change the setting.
a The display shows "on" if the Wi-Fi is activated.
Note:If the Wi-Fi is activated, the display alternately
shows "on" and the signal strength of the Wi-Fi
connection.
14.5 Deactivating Wi-Fi on the appliance
Requirements
¡ The HomeConnect menu is called up. →
Page26
¡ The display shows "on".
▶ Press to change the setting.
a The display shows "oFF" if the Wi-Fi is deactivated.
14.6 Resetting the appliance network
settings
Requirements
¡ The HomeConnect menu is called up. →
Page26
¡ The display shows "rES".
▶ Press and hold for at least 3seconds.
a The network settings are reset.
14.7 Remote start
Enable the appliance for remote start via the
HomeConnect app.
Note
Remote start will be deactivated in the following
circumstances:
¡ The appliance door is opened.
¡ Press .
¡ Press Remote Start.
¡ Following a power failure.
Activating remote start
Requirement:The appliance door is closed.
▶ Press Remote Start.
a Remote Start lights up and the appliance is enabled for
remote start via the HomeConnect app.
Deactivating remote start
▶ Press Remote Start.
a Remote Start goes out.
14.8 Intelligent program recommendation
When you activate the intelligent program
recommendation, your appliance recommends a suitable
program for drying the laundry once you have washed
your laundry in the washing machine.
Activating the intelligent program recommendation
Requirements
¡ Your washing machine has the HomeConnect function.
¡ Your washing machine and your dryer must be
connected to your home network and registered in your
HomeConnect app.
1. Press SmartDry.
a The appliance determines a suitable program. To
cancel the process, set a different program or switch the
appliance to standby mode.
a If the appliance finds a suitable program, the display for
the program lights up and the program information is
displayed.
a If the appliance does not find a suitable program, a
signal tone sounds and the display shows "- --".
2. Press .
14.9 Remote diagnostics
The Customer Service can access your appliance via
Remote Diagnostics if you ask them to do so, if your
appliance is connected to the HomeConnect server and if
Remote Diagnostics is available in the country where you
are using the appliance.
Tip:Further information and details about the availability
of Remote Diagnostics in your country can be found in the
Service/Support section of your local website: www.home-
connect.com.
Basic settings en-us
27
14.10 Data Protection
Please see the information on data protection.
The first time your appliance is registered on a home
network connected to the Internet, your appliance will
transmit the following types of data to the HomeConnect
server (initial registration):
¡ Unique appliance identification (consisting of appliance
codes as well as the MAC address of the installed Wi-Fi
communication module).
¡ Security certificate of the Wi-Fi communication module
(to ensure a secure data connection).
¡ The current software and hardware version of your
appliance.
¡ Status of any previous reset to factory settings.
This initial registration prepares the HomeConnect
functions for use and is only required when you want to
use the HomeConnect functions for the first time.
Note:Please note that the HomeConnect functions can
be utilized only with the HomeConnect app. Information
on data protection can be called up in the HomeConnect
app.
Basic settings
15 Basic settings
Basic settings
You can configure the basic settings for your appliance to
meet your needs.
Note:You can also adjust the the basic settings in the
HomeConnect app.
15.1 Overview of the basic settings
1
2
3
4
5
6
7
Program selector with program positions
1
Set the volume of the signal tone that is emitted
when the program ends:
0 (off) to 4 (very loud)
2
Set the volume of the signal tone that is emitted
when the buttons are selected:
0 (off) to 4 (very loud)
3
Set the display brightness:
1 (low) to 4 (very high)
4
Adjust the dryness level →
Page25
:
0 (dry) to 3 (driest)
5
Start the basic (CP1) or intensive (CP2) appliance
care program.
→
"Appliance care", Page27
6
Display the number of started programs.
7
Restore the appliance to the factory settings (rES).
15.2 Changing the basic settings
1. To call up the basic settings, press Basic Settings.
2. Use the program selector to select the required basic
setting. →
Page27
3. Adjust the basic setting:
‒ To change the value, press or .
‒ To reset the appliance to the factory settings, press
and hold for approx.3seconds.
4. Press Basic Settings to save the settings.
Appliance care
16 Appliance care
Appliance care
The appliance offers cleaning programs for basic and
intensive appliance care.
16.1 Preparing for the appliance care
program
Preparing the appliance for the appliance care
program
Prepare the appliance before running the appliance care
program.
Requirements
¡ The drum is empty.
¡ The appliance is in standby mode.
1.
Clean the lint screen. →
Page22
2. Pull out the condensation container horizontally and
empty it. →
Page24
Preparing the condensation container for the
appliance care program
If you are draining the condensation water from the
appliance using the drain hose, prepare the condensation
container before running the appliance care program.
en-us Appliance care
28
1. Remove the stopper from the recess in the top and
insert it in the underside .
When the appliance is delivered, the stopper is included
as an accessory in the scope of delivery.
2. Clean the filter in the condensation container.
16.2 Calling up the appliance care program
Requirement:The appliance care program is ready.
→
Page27
1. Press .
The switch-on process takes a few seconds.
2. Press Basic Settings.
3. Set the program to position5.
a "CP1"and the program duration alternate on the
display.
16.3 Running the basic appliance care
program
To remove light dirt deposits in the appliance, you can run
the basic appliance care program.
Notes
¡ The basic appliance care program runs for
approximately 1hour.
¡ After a lengthy period of use, the appliance reminds you
to run the basic appliance care program. Before the
program starts or after the program has ended, the
display shows the notification "CArE". This notification
appears repeatedly until you have run the basic
appliance care program through to the end.
Requirements
¡ The appliance care program is ready. →
Page27
¡ The appliance care program is called up. →
Page28
1. Pour approx. 6.3cups (1.5l) of hot mains water into the
condensation container.
Hold the filled condensation container level so that no
liquid spills out.
2. Insert the condensation container so that it locks into
place.
3. Press .
a The appliance care program starts and a signal tone
sounds.
a "End"appears on the display and a signal tone sounds
once the appliance care program has ended.
4. Pull out the condensation container horizontally and
empty it.
5. If you drain the condensation using the drain hose,
remove the stopper from the underside of the
condensation container and insert it into the recess in
the top of the condensation container. →
Page27
6. Insert the condensation container so that it locks into
place.
7.
Put the appliance into standby mode. →
Page22
16.4 Running the intensive appliance care
program
You can run the intensive appliance care program to
remove any stubborn dirt deposits in the appliance and
odors after a downtime of more than one month.
Notes
¡ The intensive appliance care program runs for
approximately 4 hours and must not be canceled.
¡ When you run the intensive appliance care program,
you need the original appliance care product
→
Page21
.
Starting the intensive appliance care program
Requirements
¡ The appliance care program is ready. →
Page27
¡ The appliance care program is called up. →
Page28
1. Press .
a "CP2"and the program duration alternate on the
display.
2. Pour a bottle of the appliance care product and approx.
6.3cups (1.5l) of hot mains water into the condensation
container.
Hold the filled condensation container level so that no
liquid spills out.
3. Insert the condensation container so that it locks into
place.
4. Press .
a The appliance care program starts and a signal tone
sounds.
a After around 3hours, the appliance pauses the
appliance care program and the remaining program
duration flashes on the display.
5. Pull out the condensation container horizontally and
empty it.
6. Pour approx. 6.3cups (1.5l) of hot mains water into the
condensation container.
7. Carefully swivel the condensation container horizontally
and empty it to rinse out any remaining appliance care
product.
Cleaning and maintenance en-us
29
Continuing the intensive appliance care program
1. Pour approx. 6.3cups (1.5l) of hot mains water into the
condensation container.
Hold the filled condensation container level so that no
liquid spills out.
2. Insert the condensation container so that it locks into
place.
3. Press .
a The appliance care program continues.
a "End"appears on the display and a signal tone sounds
once the appliance care program has ended.
4. Pull out the condensation container horizontally and
empty it.
5. If you drain the condensation using the drain hose,
remove the stopper from the underside of the
condensation container and insert it into the recess in
the top of the condensation container. →
Page27
6. Insert the condensation container so that it locks into
place.
7.
Put the appliance into standby mode. →
Page22
Cleaning and maintenance
17 Cleaning and maintenance
Cleaning and maintenance
To keep your appliance working efficiently for a long time,
it is important to clean and maintain it carefully.
17.1 Tips on cleaning and care
Wipe down the housing and
the controls with nothing
but water and a damp cloth.
This ensures the parts of
the appliance will remain
clean and hygienic.
Remove all detergent
residue, spray residue, or
other residues immediately.
Fresh deposits are easier to
remove without leaving any
residue.
Leave the appliance door
open after use.
This allows the residual
water to dry, reducing odors
in the appliance.
17.2 Moisture sensor
The moisture sensor in this appliance measures how
damp the laundry is during the drying cycle. The appliance
changes the duration of the automatic program depending
on the residual moisture in the laundry.
Cleaning the moisture sensor
Over time, residue from limescale, detergents, and care
products can build up on the moisture sensor. Clean the
moisture sensor regularly.
NOTICE:
Hard or rough objects may damage the moisture sensor.
▶ Do not use hard or rough objects, abrasive cleaning
products, or steel wool for cleaning.
Note:If you do not clean the appliance as described, the
appliance's functionality may be impaired.
1. Open the door.
2. Clean the moisture sensor with a sponge.
17.3 Condensation container filter
During drying, lint from the laundry gets into the
condensation. The filter in the condensation container
protects the appliance from lint.
Cleaning the condensation container filter
The filter is cleaned automatically when the condensation
container is emptied. Check the filter regularly and clean
the filter if it is dirty.
1. Empty the condensation container.
→
"Emptying the condensation container", Page24
2. Remove the filter.
3. Clean the filter under warm, running water or in the
dishwasher.
Troubleshooting en-us
31
Troubleshooting
18 Troubleshooting
Troubleshooting
You can eliminate minor issues on your appliance
yourself. Please read the information on eliminating issues
before contacting Customer Service. This may avoid
unnecessary repair costs.
WARNING
Improper repairs are dangerous.
▶ Repairs to the appliance should only be performed by
authorized service providers.
▶ Only original spare parts may be used to repair the
appliance.
▶ If the power cord of this appliance becomes damaged, it
must be replaced by the manufacturer, the
manufacturer's Customer Service, or an authorized
service provider in order to prevent injury.
Issue Cause and troubleshooting
"Hot" and the drum rotates. Cooling process active.
1. Not a fault.
2. Do not change the program during the cooling process.
Note:The cooling process takes up to 10 minutes. You can continue to operate the
appliance.
Humming noise. Compressor active.
▶ Not a fault – normal operating noise.
The display goes out and
flashes.
Energy-saving mode is active.
▶ Press any button.
a The display lights up again.
"CArE" After a period of operation, the appliance automatically recommends that you run
the basic appliance care program.
▶ Run the basic appliance care program on the appliance.
→
"Appliance care", Page27
The lint screen is soiled.
▶
→
"Cleaning the lint screen", Page22
The appliance is not working. The plug for the power cord is not plugged in.
▶ Connect the appliance to the power supply.
The circuit breaker in the circuit breaker panel has tripped.
▶ Check the breaker panel.
There has been a power failure.
▶ Check whether the lighting in your kitchen or other appliances in the room are
working.
There is a software fault.
▶ To restart the appliance, press and hold for approximately 5seconds.
Appliance paused, but the drum is
rotating.
Cooling process active.
▶ Not a fault – no action required.
HomeConnect is not working
properly.
Various causes are possible.
▶ Go to www.home-connect.com.
No connection to the home
network.
Wi-Fi is switched off.
▶ Activating Wi-Fi on the appliance.
→
"Activating Wi-Fi on the appliance", Page26
.
Wi-Fi is activated but a connection to your home network cannot be established.
1. Ensure that the home network is available.
2. Reconnect the appliance to the home network.
→
"Setting upHomeConnect", Page26
Creasing. The load is too large.
▶ Observe the maximum load capacity of the
→
"Programs", Page19
.
en-us Troubleshooting
32
Issue Cause and troubleshooting
Creasing. The laundry lies in the drum for too long after drying.
1. Remove the laundry from the drum as soon as the drying program has finished.
2. Spread out the items of laundry to cool.
Unsuitable program for the type of fabric.
▶ Set a suitable program for the type of fabric.
→
"Programs", Page19
Easy-care fabrics are dried for too long.
▶
→
"Changing the dryness level", Page25
.
▶
→
"Adjusting the dryness level", Page25
.
Crease-reduction function not activated.
▶ Activate the crease-reduction function.
→
"Buttons", Page18
and program terminated. Condensation container filled.
1.
→
"Emptying the condensation container", Page24
.
2.
→
"Inserting the condensation container", Page25
.
3.
→
"Starting the program", Page22
.
Water drain hose is caught or jammed.
1. Ensure that the water drain hose is not kinked or trapped.
2. Route the water drain hose without kinks.
Water drain hose is not connected correctly.
▶ Ensure that the water drain hose is connected correctly.
Water drain hose is blocked.
▶ Rinse the water drain hose with tap water.
The filter for the condensation container is soiled.
▶
→
"Cleaning the condensation container filter", Page29
.
Condensation in the condensation
container even though the water
drain hose is connected.
The remaining volume of condensation may remain in the condensation container.
▶ Not a fault – no action required.
Water drain hose is not connected correctly.
▶ Ensure that the water drain hose is connected correctly.
The program does not start. Control panel lock is activated.
▶ Deactivate the control panel lock.
has not been pressed.
▶ Press .
No program has been set.
1.
→
"Setting a program", Page21
.
2.
→
"Starting the program", Page22
.
The program duration changes
during the drying cycle.
The program operation is optimized electronically. This may change the program
duration.
▶ Not a fault – no action required.
Pumping noise. Condensation pump active.
▶ Not a fault – normal operating noise.
Buzzing noise. Compressor ventilation active.
▶ Not a fault – normal operating noise.
The drying time is too long. The lint screen is soiled.
▶
→
"Cleaning the lint screen", Page22
The ambient temperature is greater than 86°F (30°C).
▶ Ensure that the ambient temperature is below 86°F (30°C).
Troubleshooting en-us
33
Issue Cause and troubleshooting
The drying time is too long. The ambient temperature is lower than 59°F (15°C).
▶ Ensure that the ambient temperature is above 59°F (15°C).
Insufficient air circulation at the appliance's installation location.
▶ Ventilate the appliance's installation location.
Insufficient condensation for automatic self-cleaning when permanently drying small
loads of laundry.
▶ Regularly dry a load weighing more than 6.6lbs (3kg) of damp laundry until the
program ends.
Insufficient condensation for automatic self-cleaning when permanently using the
crease-removal function.
▶ Regularly dry a load weighing more than 6.6lbs (3kg) of damp laundry until the
program ends.
The appliance's ventilation opening is blocked.
▶ Ensure that the ventilation opening of the appliance is kept clear.
The heat exchanger is soiled.
▶ Run the basic appliance care program on the appliance.
→
"Appliance care", Page27
Water is leaking from the
appliance.
Appliance is not correctly aligned.
▶
→
"Aligning the appliance", Page11
Water drain hose is not connected correctly.
▶ Ensure that the water drain hose is connected correctly.
Laundry is too damp. Unsuitable program for the type of fabric.
▶ Set a timed program for subsequent drying.
→
"Programs", Page19
There has been a power failure.
▶ Check whether the lighting in your kitchen or other appliances in the room are
working.
The load is too large.
▶ Observe the maximum load capacity of the
→
"Programs", Page19
.
After the end of the program, warm laundry feels damper than it actually is.
1. Remove the laundry from the drum as soon as the drying program has finished.
2. Spread out the items of laundry to cool.
Unsuitable dryness level set.
▶
→
"Changing the dryness level", Page25
.
Dryness level not adjusted.
▶
→
"Adjusting the dryness level", Page25
.
Load too small.
▶ Set a timed program for subsequent drying.
→
"Programs", Page19
Moisture sensor dirty.
▶
→
"Cleaning the moisture sensor", Page29
.
The drying process is interrupted and the condensation container has been filled.
1.
→
"Emptying the condensation container", Page24
.
2.
→
"Inserting the condensation container", Page25
.
3.
→
"Starting the program", Page22
.
en-us Transportation, storage and disposal
34
Issue Cause and troubleshooting
Odors have formed in the
appliance.
Stubborn dirt in the appliance or an extended appliance downtime of more than one
month.
▶ Run the intensive appliance care program.
→
"Appliance care", Page27
Transportation, storage and disposal
19 Transportation, storage and
disposal
Transportation, storage and disposal
19.1 Preparing the appliance for
transportation
NOTICE:
If the appliance is operated immediately after
transportation, the refrigerant contained in the appliance
may cause damage to the appliance.
▶ Immediately after transporting the appliance, leave it to
rest for two hours before putting it into operation.
Tip:The appliance may contain residual water, which may
drip out of it when transported. The appliance should be
transported upright.
Requirements
¡ The condensation container is emptied. Emptying the
condensation container →
Page24
¡ The appliance is switched on.
→
"Switching on the appliance", Page21
1.
Set any program →
Page21
.
2.
Start the program →
Page22
and wait 5 minutes.
a The condensation is drained.
3. Put the appliance into standby mode.
→
"Put the appliance into standby mode", Page22
4. Remove the water drain hose from the connection point.
→
"Water drain connection types", Page10
5. Secure the water drain hose on the appliance against
unintentional loosening.
Ensure that you do not bend the water drain hose.
6.
Empty the condensation container →
Page24
.
7.
Insert the condensation container →
Page25
.
8. Disconnect the appliance's mains plug from the power
supply.
a The appliance is now ready to be transported.
19.2 Disposal of your old appliance
Environmentally compatible disposal allows valuable raw
materials to be recycled.
WARNING
Children can lock themselves in the appliance, thereby
putting their lives at risk.
▶ Do not install the appliance behind a door as this may
obstruct the appliance door or prevent it from opening.
▶ With redundant appliances, pull out the mains plug of
the power cord, cut through the power cord and remove
the appliance door.
WARNING
Although the refrigerant R290 used in this appliance is
environmentally friendly, it is flammable and may ignite if
appliances are not disposed of in the proper manner.
▶ Dispose of the appliance in the proper manner.
▶ Do not damage the pipes in the refrigerant circuit.
1. Unplug the appliance from the power supply.
2. Cut through the power cord.
3. Remove the appliance door.
4. Dispose of the appliance in an environmentally
responsible manner.
Information about current disposal methods can be
obtained from your specialist dealer or local authority.
Customer Service
20 Customer Service
Customer Service
With any warranty repair, we will make sure your
appliance is repaired by an authorized service provider
using genuine replacement parts. We use only genuine
replacement parts for all repairs.
Detailed information on the warranty period and terms of
warranty can be found in the Statement of Limited Product
Warranty, from your retailer, or on our website.
If you contact Customer Service, you will need the model
number (E-Nr.), the production number (FD) and the
consecutive numbering (Z-Nr.) of your appliance.
USA:
1-800-944-2904
www.bosch-home.com/us/owner-support/get-support
www.bosch-home.com/us/shop
CA:
1-800-944-2904
www.bosch-home.ca/en/service/get-support
www.bosch-home.ca/en/service/cleaners-and-accessories
For assistance with connecting to HomeConnect, you can
also view instructions here:
www.home-connect.com/us/en/help-support/set-up
20.1 Model number (E-Nr.), production
number (FD) and consecutive
numbering (Z-Nr.)
You can find the model number (E-Nr.), the production
number (FD) and the consecutive numbering (Z-Nr.) on
the appliance's rating plate.
Depending on the model, the rating plate can be found:
¡ on the inside of the door.
Technical specifications en-us
35
¡ on the inside of the service flap.
¡ on the backside of the appliance.
Making a note of your appliance's details and the
Customer Service telephone number will enable you to
find them again quickly.
Technical specifications
21 Technical specifications
Technical specifications
Weight 106.7lbs (54.7kg)
Drum volume 4.0ft³
Mains voltage 208-240V, 60Hz
Minimum installation
protection
10A
Power rating 900W
Ambient temperature ¡ Minimum: 41°F (5°C)
¡ Maximum: 95°F (35°C)
Length of the power cord 63 3/8″ (161cm)
Appliance dimensions
A
B
C
D
A
Appliance depth: 24 1/8″ (61.3cm)
Appliance depth with door closed: 26″ (65.1cm)
B
Appliance width: 23 1/2″ (59.8cm)
C
Appliance height
1
: 33 1/4″ (84.2cm)
D
Appliance depth with door open: 43 1/2″
(110.5cm)
1
When aligning the appliance, the appliance height may
increase by up to 5/8″ (1.5cm).
Register your appliance to
enjoy customized benefits.
Thank you for being a Bosch customer!
Simply create a MyBosch account, then register your appliance.
You'll find a variety of customized information in MyBosch such as:
• Discounts for filters, cleaners, accessories & parts
• Easy access to manuals & appliance specifications
• Easy access to part lists
• Customized offer for the Bosch Appliance Service Plan (sent by mail after appliance registration)
Register here:
www.bosch-home.com/us/owner-support/mybosch
Looking for help?
You'll find it here.
No matter what, no matter when: Bosch is here to support you.
We’re here to assist with usage instructions, cleaning tips,
accessories & parts, troubleshooting, and repairs.
Find online resources such as FAQs, how-to-videos, manuals,
warranties and authorized Bosch servicers at:
www.bosch-home.com/us/owner-support/get-support
Contact us:
Please have your Model Number (E-Nr) ready when contacting us.
1-800-944-2904
www.bosch-home.com/us/owner-support/contact-us
BSH Home Appliances Corporation
1901 Main Street, Suite 600
Irvine, CA 92614
USA
www.bosch-home.com
1-800-944-2904
© 2023 BSH Home Appliances Corporation
*9001914001*
9001914001 (031222)
en-us
