Devanti EAC-C-RC-11C-WH 8L Evaporative Air Cooler User Manual

Full Function Portable

Evaporative Cooler

Instruction Manual

Model:EAC-C-RC-11C-WH

Important Safeguards

When using electrical appliances, in

order to reduce the risk of re, electric

shock and/or injury, these basic

safety precautions should always be

followed:

For Your Safety

Read all instructions carefully, even if you are

familiar with the appliance.

• Toprotectagainsttheriskofelectricshock,

DONOTIMMERSEpowercordorpluginwater

oranyotherliquid.

• Thisapplianceisnotintendedforuseby

persons(includingchildren)withreduced

physical,sensoryandmentalcapabilities,

orlackofexperienceandknowledge,

unlesstheyhavebeengivensupervisionor

instructionconcerninguseoftheappliance

byapersonresponsiblefortheirsafety.

• Childrenshouldbesupervisedtoensurethat

theydonotplaywiththeappliance.

• Alwaysunplugtheunitwhennotinuse.

• Donotoperateunitwithadamagedpower

cordorplug,orafteramalfunction,has

beendroppedorisdamagedinanymanner.

Returntheunittoanauthorisedservice

facilityforexamination.

• Thisunitisnotintendedforuseinbathrooms,

laundryareasorsimilarmoistindoorlocations.

Neverlocatetheunitwhereitmayfallintoa

bathtuborotherwatercontainer.

• Donotrunthepowercordundercarpeting

orcoverthepowercordwiththrowrugs,

runnersorthelike.Arrangethepowercord

awayfromtrafcareasandwhereitwillnot

betrippedover.

• Donotplacethepowercordoveranypart

oftheunit.

• Donotplugthisunitintoanextensionlead,

doubleadapterorpowerboard.

• TodisconnecttheunitsetmainswitchtoOFF

thenremovetheplugfromtheoutlet.

• Thisunithashotelectricalpartsinside.DO

NOTuseitinareaswheregasoline,paintor

ammableliquidsareusedorstored.

• Donotinsertorallowforeignobjectstoenter

anyventilationorexhaustopeningasthis

maycauseanelectricshock,reorcould

damagetheunit.

• Usetheunitonlyasdescribedinthisbooklet

Anyotherusenotrecommendedbythe

manufacturermaycausere,electricshock

orinjurytopersons.

• Fullyremovethepowercordfromthepower

cordtidybeforeuse.Alwaysuncoilthepower

cordbeforeapplyingpower.

• ThisproductmustalwaysbeusedAND

STOREDintheuprightposition.

• Donotusethisunitwithaprogrammer,timer

oranyotherdevicethatswitchestheuniton

automatically,sinceareriskexistsiftheunit

iscoveredorpositionedincorrectly.

• Batteriesmustbeinsertedintotheremote

controlwhichmustbepointeddirectatthe

unit,usingthefrontportiontoactivate.

• Useindooronly.

• Ifitisnecessarytomovetheunitafterthe

waterhasbeenadded,rollgentlytothe

requiredposition.

• Donotmovethemachinewhenitisinuse.

• Alwaysensurethatthereiswaterinthetank

wheninuseforcooling.

• Donotblockaircirculation

• Donotusehotwater.

• Placethemachineonalevelsurface.

•Unplugtheapplianceduringllingand

cleaning.

Warning

Ifthesupplypowercordisdamaged,thepower

cordmustbereplacedbythemanufacturer,

itsserviceagentorsimilarlyqualiedpersonsin

ordertoavoidahazard.

Thisproducthasnotbeendesignedforanyuses

otherthanthosespeciedinthisbooklet.

SaveTheseInstructions

FeaturesofYourFullFunctionPortableEvaporative

Cooler

Control

Panel

W a t e r  F i l t e r 

Handle

Louver

WaterLevel

Indicator

CastorWheels

(4Pcs)

IceBracket

IceCrystals

Box

Remote

Control

WaterTank

Storage For

PowerCord

FilterCover

AirFilter

FeaturesofYourFullFunctionPortableEvaporative

Cooler

W a t e r  F i l t e r 

IceBracket

IceCrystals

Box

Remote

Control

Thebuttonsofthesamedescriptionsonthe

mainunit/remotecontrolhavethesame

functions.

Timer

Button

Time

Indicators

CoolAir

Indicator

Anion

Indicator

Vane

Indicator

WindMode

Indicators

Speed

Indicators

Power

Indicator

Remote

Sensor

Cool

Button

Anion

Button

Vane

Button

WindMode

Button

Wind

Speed

Button

On/Off

Button

Control Panel

YourFullFunction

PortableEvaporative

Cooler

Congratulationsonthepurchaseofyournew

FullFunctionPortableEvaporativeCooler.

BeforerstusingyourMistralFullFunction

PortableEvaporativeCooleritismostimportant

thatyoureadandfollowtheinstructionsinthis

use and

carebooklet,evenifyoufeelyouare

quite



familiarwiththistypeofappliance.

Yourattentionisdrawnparticularlytothesection

dealingwithIMPORTANTSAFEGUARDS.Find

aplaceandkeepthisbooklethandyforfuture

reference.

YourFullFunctionPortableEvaporative

Coolerissafeandeasytouse.Ithasbeen

designedtofunctionquietlyandsafelyunder

normalcircumstances.

HintsforBetterCooling

1. Yourcoolerrequiresasupplyoffreshair.

Placethecoolernearanopenwindow

orleavethedoortotheroomopen.Then

openanotheroutsidewindowordooronthe

oppositesideoftheroomsothatyoucreate

“owthrough”ventilation.Thecoolerwillnot

workproperlyinaclosedroom.

2. Asanadditionplacethecoolernearthe

entrancetotheroom.Thecoolerwilldraw

coolairfromotherpartsofthehouseand

furtherbringdowntemperature.

3. Startyourcoolerwhentheroomisstillcool.

Youmayleaveitrunningallday.Youwillnd

thatthissystemworksbestandkeepsthe

roomcooler.

4.Placeicecrystalsboxinyourrefrigerator

andletitfreezefor1to2hours,thenplace

ittothewatertank.Itwillbegoodcooling

efciency.

5.Addcoldwaterandicetothewatertank.

Turnonthecoolswitchandthelterpadwill

becomedamp.Theairisdrawninthrough

backpanelandacrossthelterpadto

releasecoolcleanair.Itmaytakeafew

minutesforthepadtobecomesaturated.

6. Sincehumiditychangesfromhour-to-hour

andday-to-day,whenitistoohumid,you

mayuseyourcoolerasafan.Justturncooler

onbutdonotturnoncoolbutton.

Operation

OPERATION(Do Not connect the

power plug as yet)

1.Removeallpackagingandcheckthe

applianceforanydamagesduring

transportation.Placetheunitonalevel

surfaceinastableuprightposition.

2.Pourcleancoldwaterintothewatertank,

observingthewaterlevelindicatoranddo

notoverllpasttheMAXwaterindicator

mark.

1.Rotatethe

Locker

2.Pulloutthe

watertank

3.Pourclean

coldwater

intowater

tankhere

4.Placeice

intoice

basket

5.Place

ice

crystals

boxinto

watertank

Ifdesired,placeiceintheicebracketofwater

tank.

CAUTION:

Whenmovingtheunit,dosowithextreme

caution,soasnottospillanywaterinthe

reservoir.Theunitshouldbemovedslowlyandin

asidewaysdirection.

CAUTION:

Ensureicecrystalsboxiskeptawayfrom

children,consumingwillbeharmful

Alwayskeeptheunitupright.

3.Connecttheunittoapoweroutletofthe

samevoltageandfrequencyasindicated

ontheratingplate.Theunit’sON/OFFLED

lightforthepowerwillturnontoindicatethat

thereispowertotheunit.

4.TurntheunitONbypressingtheON/OFF

buttononce.Theunitwillstartwiththefanin

normalmodeandonhispeedsetting.Further

operationcanbeperformedviapressing

theSPEED,MODE,VANE,ANION,COOLand

TIMERbuttons.

5.Ifyouwishtoturntheunitoffatapre-

determinedtime,pleasepresstheTIMER

button.Theunitcanbesettoturnoffat

anytimebetween0.5hourand7.5hours

from“TurnOn”bypressingtheTIMER

button.Ifnotimeisselected,theunitwill

operatecontinuously.Thetimesetcanbe

incrementedin0.5hrstepsandtheselected

timeisindicatedbyacombinationof

indicatorlights.e.g.5.5hrsisindicatedbythe

4hrLED,the1hrLEDandthe0.5hrLEDbeing

illuminatedsimultaneously.

6.Toinitiatethecoolingfunction,pressthe

COOLbutton.Itwilltakeapproximately2

minutesfortheairtocool.

Note: If this button is not depressed

the unit will only circulate “room

temperature” air.

7.Movethehorizontallouversfortheairoutlet

toblowupordowntosuit.

8.Theverticallouverscanbesettoadirection

orallowedtorotatebypressingtheVANE

button.

9.Allthefunctionscanbeperformedwiththe

remotecontrolsuppliedwiththisunit.

a)Removebatterycoverandinstalltwo“AAA”

batteriesasindicated.(Pleaseobserve

correctbatterypolarity,batteriesnot

included).

b)Pointtheremotetowardstheunitandpress

theappropriatebutton.Theremotecontrol

willoperateupto4metersfromtheunit.

10.PresstheON/OFFbuttonagaintocancelall

functions.

11.Whennotinusedisconnecttheunitfromthe

poweroutlet.

Note: Initial setting is “normal” mode

and “Mi” speed.

A. ON/OFF:

Pressthebuttononcetostart

aircooler.PressagaintoPowerOFFtheair

cooler.Whencoolerispluggedintothe

mainsocket,theLEDlightwillbeilluminate

indicatingtheaircoolernowhaspowerand

isreadytobeswitchedONorOFF.

B. SPEED:Presstochangefanspeedfrom

“Mid-High-Low”,relativeSPEEDLEDlightsturn

on.SPEEDfunctionHigh-Mid-Lowandalsobe

usedin-conjunctionwiththeNORMAL,SLEEP

andNaturalfunction.

C. MODE:

Thereare3modefunctions,Normal,

NaturalandSleep.

• Normal mode: Constantairowandcan

beadjustedviatheSPEEDfunctionbutton.

Example,NormalLOWorNormalHighor

NormalMedium.

• Natural mode:Programmedtosimulate

Naturalairow(breeze)asthoughitwere

enteringviathewindow.Thismodeis

preferredforusewhenconstantairow

(Normalmode)isnotsuitable.Naturalmode

canbeoperatedinHIGHTorMEDIUMorLOW

speed.

• Sleepmode:Programmedtoprovide

comfortwhiletheuserisasleep.

Note: All above can be operated via the

remote control shown on page 3.

D. VANE:

Pressonce,theindicatingLEDwill

lightup,andthelouveroftheaircooler

beginstoswinghorizontallyandblowcoolair.

Pressthebuttonagain,thelightisnowOFF.

Thelouveroftheaircoolerstopsswinging,

andtheairwillbeblowinginonedirection.

E. ANION:

Togainfreshairinyourroom,just

pressANIONbuttonandthebuild-inionizer

willoperate.theindicatingLEDwilllightup,

F. COOL:

PressoncetooperatetheCOOL

function.Thisfunctionbeginswiththeprocess

ofsoakingtheairlterinwatersothatnormal

airpassingthroughtheairlterwillbecooler

whenblownout.Pressthebuttonagainto

switchthisfunctionOFF,andtheunitwill

operatethefanmodeonly.

Note: The alarm will ring

when you press the Cool button if there

is not enough water in water tank.

Note: Under the cooling mode, the

appliance will delay 5 minutes to stop

working when you shut off the unit or

timer is complete, during the extended

period, the timer pilot lamp will ash.

G. TIMER

Setthelengthoftimebeforethecoolerswitches

itselfOFF.Pressonceforeach0.5hrincrement.

Maximumallowableis7.5hrs.Exampleofuse:

Ifthe0.5hrand1.0hrlightsareonatthesame

time,itmeanstheunitwillcontinuetorunfor

1.5hrsbeforeautomaticallyswitchingOFF.The

TIMMERfunctionisOFFwhennotimeLEDsare

illuminated.

Specications

Model No

RatedVoltage&

Frequency

220-240V~50Hz

RatedPower 65W

CapacityofWater

Tank

8.0L

WaterConsumption 1.0L/h

EAC-C-RC-11C-WH

HowtoClean

Toensureeffectivehumidifyingandltering,itis

recommendedthatthelterbecleanedonce

everytwoweeks.

Disconnecttheunitfromthemainssupplybefore

cleaning.

Tocleantheexteriorsurfacessimplywipeover

withasoftdampcloth.Shoulditbenecessary,

greasymarksmayberemovedfromthesurfaces

byusingmildsoapandaclothdampenedin

hotwater.Avoidallothertypesofdetergents,

cleaners,solventsthatmaycontainchemicals,

whichcoulddamagepartsoftheunit.

Thoroughlydryallpartsbeforestorageorfurther

use.

Water Tank

1.Takeoutthewatertank.RefertoFig.1.

Fig.1

1.Rotatethe

lockerup

2.Takeoutthe

watertank

fromtheunit

Note: Do not put this cooler directly

under a water tap, use a proper

container to ll water to avoid splashing

and damaging to the electric appliance.

2.Flushandrinseoutthewatertank.

AirFilter

Cleantheairlteratleastonceeverytwoweeks

topreventinferiorfanoperationduetodust

accumulation.

TakeouttheAirlter.RefertoFig.2.

Fig.2

Washtheairlterbyimmersingitgentlyinwarm

waterwithaneutraldetergent.Rinsethelter

anddryitinashadyplace.

PuttheAirlterandFiltercoverbackintothe

unit.

TroubleShooting

Alwayscheckfullproductoperationasdetailed

abovebeforecallingforassistance,unlessthere

isdamagetothepowercordorplug-inthis

situation,stopusingtheproductimmediately.

Onhumiddaystheunitmaynotappeartobe

coolingcorrectly.Thisisduetotheairalready

beingsaturatedwithwater.Addingmore

watertotheairwillnotresultinpullingtheair

temperaturedown.Intheseconditions,itis

advisabletooperatetheunitasafanonlyto

circulateroomair.

For Your Safety

• Alwaysoperatetheunitasdetailedbelow.

• Iftheplugandsupplypowercordare

damaged,itmustbereplacedbythe

manufacturer,itsserviceagentorasuitable

qualiedpersoninordertoavoidahazard.

• CAUTION:Toreducetheriskofelectricshock,

DONOTremovethecover(orback)whilst

theunitisinoperationorconnectedtothe

mainssupply.

• Thisproductoperateswithwater-operate

andmovetheproductwithextremecare.

• Donotoperatetheunitwithadamaged

powercordorplug,oraftertheunit

malfunctions,orisdamagedinanymanner.

Returnthecompleteunittotheplaceof

purchaseforin-warrantyreplacement,or

inspectionandrepair.

Devanti EAC-C-RC-11C-WH 8L Evaporative Air Cooler Conditioner

Product's Documents

Instruction Manual

Specifications

Devanti EAC-C-RC-11C-WH Questions and Answers
