INDUSTRIAL FAN HEATER 2400W
MODEL NO: FH2400
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
9 Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and all electrical
connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical products.
Electrical safety information. It is important that the following information is read and understood:
9 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9 Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the correct fuse.
8 DO NOT pull or carry the appliance by the power cable.
8 DO NOT pull the plug from the socket by the cable.
8 DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or is replaced immediately by a
qualied electrician.
If the cable or plug is damaged during use, switch o the electricity supply and remove from use.
Ensurethatrepairsarecarriedoutbyaqualiedelectrician.
If an extension reel is used it should be as short as possible and fully unwound before connection. A reel with an RCD fitted is preferred
since any appliance plugged into it will be protected. The cable core section is important and should be at least 1.5mm², but to be
absolutely sure that the capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we
recommend the use of 2.5mm² section cable.
1.2. GENERAL SAFETY
WARNING! Disconnect the heater from the mains power supply, before servicing or performing any maintenance. Servicing or
maintenance must only be carried out by an authorised service agent.
9 Check that the heater is in sound condition and good working order. Take immediate action to repair or replace damaged parts.
9 Use recommended parts only. Unapproved parts may be dangerous and will invalidate the warranty.
9 Position the heater at least a minimum of 0.5m at the rear and sides, and 2m at the front, from any walls or objects.
WARNING! DO NOT use the heater near ammable material, liquids, solids, gases or compressed gas cylinders etc.
8 DO NOT obstruct the air inlet and outlet sections of the heater.
8 DO NOT cover the heater.
8 DO NOT operate the heater when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8 DO NOT touch the heater casing or grill when rst switched o, as these will be very hot and will take time to cool.
8 DO NOT use the heater for anything other than its intended purpose. It is designed to provide heat in enclosed areas larger than 4m
³
,
such as workshops and other industrial areas. It is not suitable for drying clothes or laundry.
8 DO NOT use this heater in the immediate surroundings of a bath, a shower or a swimming pool.
8 DO NOT get the heater wet or use in areas of high condensation.
8 DO NOT place the heater up against any surface such as a wall, door or furniture etc.
8 DO NOT place the heater immediately below any electrical outlet.
8 DO NOT allow the power lead to touch the radiator surface.
8 DO NOT attempt to repair a damaged heater, contact an authorised service agent.
8 DO NOT stand on the heater.
WARNING! DO NOT use this heater in small rooms when they are occupied by persons not capable of leaving the room on their own,
unless constant supervision is provided.
WARNING! To reduce the risk of re, keep textiles, curtains, or any other ammable material to a minimum distance of 1m from the air outlet.
8 DO NOT use this heater if it has been dropped.
8 DO NOT use if there are visible signs of damage to the heater.
9 Use this heater on a horizontal and stable surface, or x it to a wall as applicable.
8 DO NOT connect the heater to a timer device or other equipment than can automatically switch the heater on or off.
9 Only use the heater in an upright position.
9 Ensure that the heater is correctly turned off when not in use and store in a safe, dry, childproof location.
CAUTION: Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and
vulnerable people are present.
NOTE: Children of less than 3 years should be kept away unless supervised continuously.
Refer To
Instructions
Indoor Use
Only
This product is only suitable for well insulated areas or occasional use.
Do Not Cover
Warning:
Hot Surface
Original Language Version
© Jack Sealey Limited
FH2400 Issue 3 (1,F) 08/11/23
Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed
in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the
appliance or perform user maintenance.
2. INTRODUCTION
Portable industrial heater with two heat settings and one setting for air movement only. Tough composite case with integral carry handle.
Full range ambient room thermostat maintains temperature. Fan doubles as cool air blower for use in the summer.
3. SPECIFICATION
Model No: ............................................................FH2400
Electrical Class: .....................................................Type 2
Fuse Rating: ............................................................... 13A
Power Supply Cable Length: ....................................1.3m
Power: ................................................................0-2400W
Size (W x D x H): ..............................300 x 267 x 332mm
Supply: .........................................................230V ~ 50Hz
4. OPERATION
4.1. Position heater in an upright position on a firm surface and at a safe distance from any obstructions, flammable substances etc. Keep to a
minimum of 0.5m clearance at the rear and sides, and 2m clearance at the front.
4.2. Connect the heater to a suitable mains supply.
4.3. Set thermostat to the required temperature (max. = ~ 85
o
C).
4.4. Set the required temperature using the Fan Control dial set to either the ‘ I ‘ (lower value) or ‘ II ‘ (higher value) (Fig.2).
4.5. Once the room reaches the required temperature, turn the thermostat dial slowly counter-clockwise until the thermostat clicks, leave the
dial in this position to maintain the room temperature at this setting. The heater will continue to operate until the Fan Control is turned to
the OFF ‘ 0 ‘ position.
4.6. For fan only operation, turn the Fan Control clockwise to the fan only settings (low) or (high), and set the thermostat to its
minimum setting (Fig.2).
4.7. When not in use, disconnect the heater from the mains supply. Store it in a safe, dry, childproof location.
4.8. To adjust fan direction, loosen the thumb wheels on the side of the support frame (fig.1) and fully tighten when the required angle is set.
Thumb
Wheel
Adjuster
FIG.1
Thermostat
Fan Control
FIG.2
5. MAINTENANCE
WARNING! Before attempting any maintenance, ensure that the unit is unplugged from the mains power supply and that it has cooled down.
5.1. Clean the heater with a soft dry cloth only. DO NOT use abrasives or solvents.
5.2. Periodically check the heater grille to ensure that it is not blocked.
No other maintenance is necessary. If a problem with the heater is experienced, or if the power lead or plug is damaged, contact your local
authorised service agent for repair. DO NOT dismantle or tamper with the heater, as this may be dangerous and will invalidate the warranty.
Original Language Version
© Jack Sealey Limited
FH2400 Issue 3 (1,F) 08/11/23
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
REGISTER YOUR
PURCHASE HERE
Information requirements for electric local space heaters
* Enter gure or NA
Model identier(s):
Item Symbol Value Unit Item Unit
Heat output
Type of heat input, for electric storage local space heaters
only (select one)
Nominal heat output
P
nom
kW
Manual heat charge control, with
Yes No
integrated thermostat
Minimum heat output (indicative)* P
min
kW
Manual heat charge control with room
Yes No
and/or outdoor temperature feedback
Maximum continuous heat output
P
max,c
kW
Electronic heat charge control with room
Yes No
and/or outdoor temperature feedback
Fan assisted heat output Yes No
Type of heat output/room temperature control (select one)
Single stage heat output and no room
Yes No
temperature control
Two or more manual stages, no room
Yes No
temperature control
With mechanic thermostat room
Yes No
temperature control
With electronic room temperature control Yes No
Electronic room temperature control plus
Yes No
day timer
Electronic room temperature control plus
Yes No
week timer
Other control options (multiple selections possible)
Room temperature control, with presence
Yes No
detection
Room temperature control, with open
Yes No
window detection
With distance control option Yes No
With adaptive start control Yes No
With working time limitation Yes No
With black bulb sensor Yes No
Contact details: Sealey Group, Kempson Way, Suolk Business Park, Bury St Edmunds, Suolk, IP32 7AR. www.sealey.co.uk
ERP Table 2
Auxiliary electricity consumption
At nominal heat output el
max
kW
At minimum heat output el
min
kW
In standby mode el
SB
kW
FH2400.V1
N/a
N/a
N/a
2.40
1.20
2.40
v1
