CERAMIC FAN HEATER 1400W/230V
2 HEAT SETTINGS
MODEL NO: CH2013.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
NOTE: THIS PRODUCT IS ONLY SUITABLE FOR USE IN WELL INSULATED AREAS OR OCCASIONAL USE.
1. SAFETYi
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
9 Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and all electrical
connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical products.
Electrical safety information. It is important that the following information is read and understood:
9 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9 Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the correct fuse.
8 DO NOT pull or carry the appliance by the power cable.
8 DO NOT pull the plug from the socket by the cable.
8 DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or is replaced immediately by a
qualied electrician.
If the cable or plug is damaged during use, switch o the electricity supply and remove from use.
Ensure that repairs are carried out by a qualied electrician.
If an extension reel is used it should be as short as possible and fully unwound before connection. A reel with an RCD fitted is preferred
since any appliance plugged into it will be protected. The cable core section is important and should be at least 1.5mm², but to be
absolutely sure that the capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we
recommend the use of 2.5mm² section cable.
1.2. GENERAL SAFETY
9 Familiarise yourself with the applications and limitations of the heater.
9 Ensure that heater housing is positioned with feet and tilt switch on a rm, horizontal dry surface.
WARNING! To reduce the risk of re, keep textiles, curtains, or any other ammable material to a minimum distance of 1m from the air outlet.
9 Keep away from ammable objects/materials/surfaces. This product gets very hot during use. Use in a location where accidental
contact (particularly by children) is unlikely.
9 Ensure the 4 position switch is set to ‘o ‘ before connecting power cord to power supply.
9 Ensure the heater is in good order and condition before use. If in any doubt DO NOT use the unit and contact an electrician.
9 Keep tools and other items away from the heater when it is in use.
9 Keep the area clean and clear of unnecessary items.
9 Keep children and unauthorised persons away from the heater, as it gets very hot.
9 Disconnect from mains and allow to cool before moving or attempting any cleaning.
8 DO NOT use this heater in the immediate surroundings of a bath, a shower or a swimming pool.
8 DO NOT get the heater wet or use in damp or wet locations or areas where there is condensation.
8 DO NOT remove plug from mains supply by pulling on power cord.
8 DO NOT move the heater whilst in operation or even when still warm.
8 DO NOT disassemble the heater for any reason. The heater must be checked by qualified personnel only.
8 DO NOT use this product to perform a task for which it has not been designed.
WARNING! If a fuse blows, ensure it is replaced with an identical fuse type and rating. If it blows again DO NOT use the unit and contact
an electrician
8 DO NOT place any object on the heater at any time.
8 DO NOT use this heater if it has been dropped.
8 DO NOT use if there are visible signs of damage to the heater.
9 Use this heater on a horizontal and stable surface, or x it to a wall as applicable.
WARNING! DO NOT use this heater in small rooms when they are occupied by persons not capable of leaving the room on their own,
unless constant supervision is provided.
WARNING! Ensure any object is at least 200cm from the heater front face.
NOTE: Children aged from 3 years and less than 8 years shall only switch on/o the appliance provided that it has been placed or
installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and
clean the appliance or perform user maintenance. Children of less than 3 years should be kept away unless continuously supervised.
Refer to
instruction
manual
DO NOT
cover
Warning:
Electric shock
hazard
Warning:
Hot surface
Indoor use
only
Original Language Version
© Jack Sealey Limited
CH2013.V3 Issue 4 (1,F) 08/11/23
2. INTRODUCTION
Stylish modern design heater with two heat settings of 700/1400W. Features PTC heat conducting ceramic elements to achieve an
instant, odour-free heat. Thermostat control to maintain ambient temperature at preset level. Includes overheating protection and tilt
safety switch, protecting the user, product and environment.
3. SPECIFICATION
MODEL NO: CH2013.V3
Min. Power 700W
Max. Power 1400W
Size (W x D x H): 210mm x 115mm x 250mm
Supply 230V
4. OPERATION
fig.
1
fig.
2
fig.
3
WARNING! Ensure you read, understand and apply the safety instructions in Section 1 before using the heater.
NOTE! The ceramic element is fragile and therefore it is important that it is not subjected to any unnecessary shocks or vibration and is
not moved when it is hot.
4.1. Unwrap the mains lead and place where required.
4.2. For fan only select switch position labelled (fig.3) (fig.3)
4.3. Choose the required heat output by selecting the appropriate switch.
4.4. LOW SETTING: Select switch position marked with “I” (fig.3).(fig.3).
4.5. HIGH SETTING: Select switch position marked with “II” (fig.3).(fig.3).
4.6. THERMOSTAT: Rotate the control knob to set the required room temperature cut off point.
4.7. To switch the unit off, turn the heat selecting switch to the off position “O” (fig.3)(fig.3) and unplug from the mains supply.
4.8. Allow the unit to cool before handling or storage.
4.9. SAFETY CUT-OUTS The heater is fitted with a thermostatic cut-out which will automatically turn the heater off should it exceed the set
value. Should this happen, switch the heater off and disconnect it from the mains. Allow the heater to cool before handling. In the event of In the event of
the heater being knocked over or raised from the ground, the safety tilt switch (fig.1), will disable the heater. the heater being knocked over or raised from the ground, the safety tilt switch (fig.1), will disable the heater.
4.10. When used for the first time, it is suggested that you set the heater to maximum power for a few minutes in a well ventilated room to
eliminate the newness smell typical of this type of heater.
MPORTANT: During relocation, the heater should remain switched off and disconnected from the mains supply.
4.11. In the event the heater has been accidentally knocked over, follow these steps to re-start the heater.
aa) Switch ‘off’ the heater at the “O” position (fig.3).) Switch ‘off’ the heater at the “O” position (fig.3).
bb) Disconnect the power cord from the mains supply.) Disconnect the power cord from the mains supply.
cc) Return the heater to a standing position on its four feet.) Return the heater to a standing position on its four feet.
dd) If no damage has occurred to elements, re-connect power cord to the power supply and switch the heater back on. Should the ) If no damage has occurred to elements, re-connect power cord to the power supply and switch the heater back on. Should the
power cord require replacement, a complete wiring loom should be purchased and fitted by a suitably qualified person.power cord require replacement, a complete wiring loom should be purchased and fitted by a suitably qualified person.
5. TROUBLESHOOTING
FAULT DESCRIPTION SUGGESTED SOLUTION
Heater does not operate Check power supply/fuse if fails again, Check for cracked casing or snagged
wiring/connections.
Check for tilt safety switch engagement, if switch works (clicks) but heater does
not.
For the above consult a qualied electrician for all suspected electrical faults or
contact a Sealey authorised stockist.
6. MAINTENANCE
WARNING! Disconnect from the mains and allow to cool before moving or attempting any cleaning or maintenance.
6.1. Clean the heater with a moist cloth and some mild detergent.
6.2. Use a vacuum cleaner on the outside grille to clean dust from internal parts.
6.3. When not in use, store the heater carefully in a safe, dry, childproof location.
6.4. To replace any of the elements, contact your authorised Sealey stockist.
8 DO NOT perform a ash test, as this will reduce the life of the elements.
8 DO NOT use abrasive cleaners or polishes on casing or grille.
Original Language Version
© Jack Sealey Limited
CH2013.V3 Issue 4 (1,F) 08/11/23
Original Language Version
© Jack Sealey Limited
CH2013.V3 Issue 4 (1,F) 08/11/23
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please
email or call our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Information requirements for electric local space heaters
* Enter gure or NA
Model identier(s):
Item Symbol Value Unit Item Unit
Heat output
Type of heat input, for electric storage local space heaters
only (select one)
Nominal heat output
P
nom
kW
Manual heat charge control, with
Yes No
integrated thermostat
Minimum heat output (indicative)* P
min
kW
Manual heat charge control with room
Yes No
and/or outdoor temperature feedback
Maximum continuous heat output
P
max,c
kW
Electronic heat charge control with room
Yes No
and/or outdoor temperature feedback
Fan assisted heat output Yes No
Type of heat output/room temperature control (select one)
Single stage heat output and no room
Yes No
temperature control
Two or more manual stages, no room
Yes No
temperature control
With mechanic thermostat room
Yes No
temperature control
With electronic room temperature control Yes No
Electronic room temperature control plus
Yes No
day timer
Electronic room temperature control plus
Yes No
week timer
Other control options (multiple selections possible)
Room temperature control, with presence
Yes No
detection
Room temperature control, with open
Yes No
window detection
With distance control option Yes No
With adaptive start control Yes No
With working time limitation Yes No
With black bulb sensor Yes No
Contact details: Sealey Group, Kempson Way, Suolk Business Park, Bury St Edmunds, Suolk, IP32 7AR. www.sealey.co.uk
ERP Table 2
Auxiliary electricity consumption
At nominal heat output el
max
kW
At minimum heat output el
min
kW
In standby mode el
SB
kW
CH2013.V3
N/A
N/A
N/A
1.4
0.0053
1.4
