2KW INDUSTRIAL FAN HEATER
MODEL NO: EH2001.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and any
other connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of appropriate safety
devices. A Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. We also recommend that a
Residual Current Device (RCD) is used. It is particularly important to use an RCD with portable products that are plugged into a supply
which is not protected by an RCCB. If in any doubt consult a qualified electrician.
You must also read and understand the following instructions concerning electrical safety.
9 The Electricity at Work Act 1989 requires that all portable electrical appliances, if used on business premises, are tested by a qualified
electrician, using a Portable Appliance Tester (PAT), at least once a year.
9 The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of those appliances and
the safety of the appliance operators. If in any doubt about electrical safety, contact a qualified electrician.
9 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9 Use a Portable Appliance Tester.
9 Ensure that cables are always protected against short circuit and overload.
9 Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that
none are loose.
9 Important: Ensure that the voltage marked on the appliance matches the power supply to be used and that the
plug is fitted with the correct fuse - see fuse rating at right.
8 DO NOT pull or carry the appliance by the power cable.
8 DO NOT pull the plug from the socket by the cable.
DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty item repaired or
replaced by a qualified electrician. When a BS 1363/A UK 3 pin plug is damaged, cut the cable just above the
plug and dispose of the plug safely. Fit a new plug according to the following instructions (UK only).
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to the live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d) After wiring, check that there are no bare wires, that all wires have been connected correctly, that the cable outer insulation extends
beyond the cable restraint and that the restraint is tight.
Double insulated products, which are always marked with this symbol , are fitted with live (brown) and neutral (blue) wires only. To
rewire, connect the wires as indicated above.
8 DO NOT connect either wire to the earth terminal.
9 If an extension reel is used it should be as short as possible and fully unwound before connection. A reel with an RCD fitted is preferred
since any appliance plugged into it will be protected. The cable core section is important and should be at least 1.5mm², but to be
absolutely sure that the capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we
recommend the use of 2.5mm² section cable.
1.2. GENERAL SAFETY
WARNING! The appliance shall be disconnected from its power source during service and when replacing parts and, if the removal of the
plug is foreseen, it shall be clearly indicated that the removal of the plug has to be such that an operator can check from any of the points
to which they have access that the plug remains removed.
WARNING: DO NOT use this heater in small rooms when they are occupied by persons not capable of leaving the room on their own,
unless constant supervision is provided.
9 Servicing or maintenance must only be carried out by an authorised service agent.
9 Check that the heater is in sound condition and good working order. Take immediate action to repair or replace damaged parts.
9 Use recommended parts only. Unapproved parts may be dangerous and will invalidate the warranty.
8 DO NOT attempt to repair a damaged heater, contact an authorised service agent.
WARNING! In order to avoid overheating, DO NOT cover the heater.
1.3. POSITIONING OF HEATER
WARNING! To reduce the risk of fire, keep textiles, curtains, or other flammable materials a minimum distance of 1m from the
air outlet.
Refer To
Instructions
Indoor Use
Only
This product is only suitable for well insulated areas or occasional use.
Do Not
Cover
Original Language Version
© Jack Sealey Limited
EH2001.V2 Issue 2 (4,F) 13/07/23
RECOMMENDED
FUSE RATING - 13AMP
WARNING! DO NOT use the heater near ammable material, liquids, solids, gases or compressed gas cylinders etc.
9 Use this heater on a horizontal and stable surface.
8 DO NOT place the heater close to a bath, wash basin, shower, swimming pool or any other water-filled area or wet surface.
8 DO NOT place the heater up against any surface such as a wall, door or furniture etc.
8 The heater must not be located immediately below a socket outlet.
8 DO NOT place the heater on a raised surface or anywhere where it could topple over.
8 DO NOT get the heater wet or use in areas of high condensation.
8 DO NOT allow the power lead to touch hot surfaces.
8 DO NOT connect the heater to a timer device or other equipment than can automatically switch the heater on or off.
8 DO NOT operate the heater when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8 DO NOT stand on the heater.
9 If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a
hazard.
8 DO NOT use the heater with wet hands or when there is water on the power cord.
8 DO NOT use the heater for anything other than its intended purpose. It is designed to provide heat in enclosed areas such as workshops
and other industrial areas. It is not suitable for drying clothes or laundry.
9 Position the heater at least a minimum of 1m at the front, rear and sides from any walls or objects.
9 If an extension cable is required it must be of the same cross section as the heater cable. It must be as short as possible and fully
unwound.
9 Ensure that the heater is correctly turned off when not in use and store in a safe, dry, childproof location.
1.4. OPERATIONAL PRECAUTIONS
9 The heater must only be used by people who have read these instructions and have been trained in its use.
8 DO NOT obstruct the air inlet and outlet sections of the heater.
WARNING! In order to avoid overheating, DO NOT cover the heater.
8 DO NOT use the heater without the grille fitted.
8 DO NOT use if the heater has been dropped.
8 DO NOT use if there are visible signs of damage to the heater.
8 DO NOT touch the heater casing or grille when rst switched off, as these will be very hot and will take time to cool.
NOTE: Children of less than 3 years should be kept away unless supervised continuously.
Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in
its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the
appliance or perform user maintenance.
CAUTION: Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and
vulnerable people are present.
NOTE: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
2. INTRODUCTION
Electric fan heater for industrial applications. One heat setting with thermostat control, plus fan only. A totally dry heat with no
condensation, no gas, no fumes and no smell. Ideal for workshops and garages. Supplied with power cable and 3-pin plug.
3. SPECIFICATION
Model No: .......................................................EH2001.V2
Fuse Rating: ................................................................ 13A
Heated Area: ............................................................. 40m³
Output: ............................................................6,800Btu/hr
Power Supply Cable Length: ......................................1.5m
Supply: .............................................................230V - 13A
IMPORTANT! This unit is designed to raise the ambient temperature of an entire room, the temperature of the air coming out of the
front of the heater will be warmer than the general temperature of the room, but there may not be a signicant increase due to the large
volume of air passing over the element. For the same reason, the element is hot during operation, but does not visibly glow. The room
temperature depends on room size, insulation and the ambient temperature, which will increase as the room gets warmer.
4. OPERATION
4.1. Position heater in an upright position on a firm surface and at a safe distance from any obstructions, flammable substances etc. Keep to a
minimum of 0.5m clearance at the rear and sides, and 2m clearance at the front.
4.2. Connect the heater to a suitable mains supply.
4.3. Set the thermostat dial to its maximum setting (fully clockwise).
4.4. The heater will switch on when the power setting dial is set to the heater setting.
NOTE: It will take up to three minutes for the heater to reach optimum temperature.
4.5. Once the room reaches the required temperature, turn the thermostat dial slowly counter-clockwise until the thermostat clicks, leave the
dial in this position to maintain the room temperature at this setting. The heater will continue to operate until the power switch is turned to
the OFF position.
4.6. For fan only operation, turn the power/fan selector to the fan only setting, and set the thermostat to its minimum setting.
4.7. When not in use, disconnect the heater from the mains supply. Store it in a safe, dry, childproof location.
Original Language Version
© Jack Sealey Limited
EH2001.V2 Issue 2 (4,F) 13/07/23
Original Language Version
© Jack Sealey Limited
5. MAINTENANCE
WARNING! Before attempting any maintenance, ensure the unit is unplugged from the mains power supply and it has cooled down.
5.1. Clean the heater with a soft dry cloth only. DO NOT use abrasives or solvents.
5.2. Periodically check the heater grille to ensure that it is not blocked.
5.3. No other maintenance is necessary. If a problem with the heater is experienced, or if the power lead or plug is damaged, contact your
local authorised service agent for repair. DO NOT dismantle or tamper with the heater, as this may be dangerous and will invalidate the
warranty.
EH2001.V2 Issue 2 (4,F) 13/07/23
Fan only setting
OFF
Power / Fan
Selector
Thermostat
Power setting (2000W)
g.1
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Information requirements for electric local space heaters
* Enter gure or NA
Model identier(s):
Item Symbol Value Unit Item Unit
Heat output
Type of heat input, for electric storage local space heaters
only (select one)
Nominal heat output
P
nom
kW
Manual heat charge control, with
Yes No
integrated thermostat
Minimum heat output (indicative)* P
min
kW
Manual heat charge control with room
Yes No
and/or outdoor temperature feedback
Maximum continuous heat output
P
max,c
kW
Electronic heat charge control with room
Yes No
and/or outdoor temperature feedback
Fan assisted heat output Yes No
Type of heat output/room temperature control (select one)
Single stage heat output and no room
Yes No
temperature control
Two or more manual stages, no room
Yes No
temperature control
With mechanic thermostat room
Yes No
temperature control
With electronic room temperature control Yes No
Electronic room temperature control plus
Yes No
day timer
Electronic room temperature control plus
Yes No
week timer
Other control options (multiple selections possible)
Room temperature control, with presence
Yes No
detection
Room temperature control, with open
Yes No
window detection
With distance control option Yes No
With adaptive start control Yes No
With working time limitation Yes No
With black bulb sensor Yes No
Contact details: Sealey Group, Kempson Way, Suolk Business Park, Bury St Edmunds, Suolk, IP32 7AR. www.sealey.co.uk
ERP Table 2
Auxiliary electricity consumption
At nominal heat output el
max
kW
At minimum heat output el
min
kW
In standby mode el
SB
kW
EH2001 v2
NA
NA
NA
2
2
2
