INDUSTRIAL FAN HEATER WITH DUCTING
MODEL NO’S: DEH2001, DEH3001, DEH5001 & DEH10001
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
I
MP
PO
R
RTA
TA
NT:
PLEA
S
E READ THE
S
E IN
S
TRU
C
TI
O
N
S
C
AREFULLY. N
O
TE THE
S
AFE
O
PERATI
O
NAL RE
Q
UIREMENT
S
, WARNIN
GS
&
C
AUTI
O
N
S
. U
S
E
TH
HE
P
PR
O
ODU
C
T
CO
RRE
C
TLY AND WITH
C
ARE F
O
R THE P
U
RP
OS
E F
O
R WHI
C
H IT I
S
INTENDED. FAIL
U
RE T
O
D
O
SO
MAY
C
A
US
E DAMA
G
E AND
/O
R
PE
ER
S
SON
N
AL IN
JU
RY AND WILL INVALIDATE THE WARRANTY. KEEP TH
ESE
IN
STR
UCT
ION
S S
AFE
FO
R F
U
T
U
RE
USE
.
1. SAFETY
1.1. ELECTRICAL SAFETY (DEH10001)
WARNING! ELECTRICAL INSTALLATION OF THE HEATER TO A 3-PHASE 415VOLT SUPPLY MUST ONLY BE CARRIED OUT
BY A QUALIFIED ELECTRICIAN.
Make sure the power supply cable is correctly connected to the earth. It is the user’s responsibility to read, understand and comply
with the following:
You must check all electrical equipment and appliances to ensure they are safe before using. You must inspect power supply leads,
plugs and all electrical connections for wear and damage. You must ensure the risk of electric shock is minimised by the installation
of appropriate safety devices. An RCCB (Residual Current Circuit Breaker) should be incorporated in the main distribution board. You
must also read and understand the following instructions concerning electrical safety.
The Electricity At Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by a qualifi ed
electrician, using a Portable Appliance Tester (PAT), at least once a year.
The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance and the
safety of the appliance operator. If in any doubt about electrical safety, contact a qualified electrician.
Ensure insulation on all cables and the product itself is safe before connecting to mains power
supply.
Ensure that cables are always protected against short circuit and overload.
Regularly inspect power supply, leads, plugs and all electrical connections for wear and damage,
especially power connections, to ensure that none are loose.
Important: Ensure the voltage marked on the product is the same as the electrical power supply to
be used. A three phase plug must be fitted to this machine.
DO NOT pull the powered appliance by the power cable.
DO NOT pull power plugs from sockets by the power cable.
DO NOT use worn or damage leads, plugs or connections. Immediately replace or have repaired
by a qualified electrician.
This product must be fitted with a 3-phase plug according to the diagram, and will require a
minimum supply of, 16Amps per phase for DEH3001 and DEH5001, and 32Amps for DEH10001.
You must contact a qualified electrician to ensure an appropriately fused supply is available.
Connect GREEN/YELLOW wire to earth (E) terminal .
Connect the live wires to live 1, 2 and 3.
When completed, check that there are no bare wires, that all wires have been connected correctly, that the cable external insulation
extends beyond the cable restraint and that the restraint is tight.
1.2. ELECTRICAL SAFETY (DEH2001, DEH3001 & DEH5001)
WARNING! It is the user’s responsibility to check the following:
Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and
all electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical
products. You may obtain an RCD by contacting your local Sealey Stockist.
If the product is used in the course of business duties, it must be maintained in a safe condition and
routinely PAT (Portable Appliance Test) tested.
Electrical safety information, it is important that the following information is read and understood.
1.2.1. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power
supply.
1.2.2. Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure
that they are secure.
1.2.3. Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the
plug is fi tted with the correct fuse - see fuse rating in these instructions.
DO NOT pull or carry the appliance by the power cable.
DO NOT pull the plug from the socket by the cable.
DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or is
replaced immediately by a qualifi ed electrician.
1.2.4. This product is fi tted with a BS1363/A 13 Amp 3 pin plug.
Recommended fuse rating
DEH2001 13Amp
DEH3001 16Amp
DEH5001 16 Amp
DEH2001 DEH3001 DEH5001 DEH10001 Issue 2 16/08/21
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Electrical
shock
hazard
Hot surfaces
Do not cover
This product is only suitable for well insulated areas or occasional use.
If the cable or plug is damaged during use, switch the electricity supply off and remove from use.
Ensure that repairs are carried out by a qualifi ed electrician.
Replace a damaged plug with a BS1363/A 13 Amp 3 pin plug. If in doubt contact a qualifi ed electrician.
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to the live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
Ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight.
Sealey recommend that repairs are carried out by a qualifi ed electrician.
1.3. GENERAL SAFETY
WARNING! Disconnect the heater from the mains power supply before carrying out any servicing or maintenance.
Maintain the heater in good order and clean condition for best and safest performance. Replace or repair damaged parts.
Locate heater in a suitable work area and keep area clean, tidy and free from unrelated materials. Ensure there is adequate lighting
and keep the immediate area in front of the outlet grille clear.
Allow the unit to cool before storage. When not in use, disconnect from the mains power supply and store in a safe, cool, dry,
childproof area.
Only use the heater standing in the upright position on a level surface.
DO NOT use the heater where there are fl ammable liquids, solids or gases such as petrol, solvents, aerosols etc, or where heat
sensitive materials may be stored.
DO NOT place the heater near items that may be damaged by heat, allow at least 2mtr clearance in front of the heater.
DO NOT allow the heater to get wet as this may cause an electric shock, causing damage to the heater and possible personal
injury.
DO NOT let power lead hang over an edge (i.e. table), or touch a hot surface, lie in the beam of heat, or run under a carpet.
DO NOT use in bathroom, shower room, or in any wet or damp environments or where there is high condensation.
DO NOT operate the heater when you are tired or under the infl uence of alcohol, drugs or intoxicating medication.
DO NOT insert or allow objects to enter any openings of heater as this may cause an electric shock, fi re or damage to heater.
DO NOT use heater if the power cord, plug or the heater is damaged, or if the heater has become wet.
DO NOT use the heater for any purpose other than for which it is designed.
DO NOT use a timer or other remote device to operate the heater.
DO NOT allow children to touch or to operate the heater.
DO NOT site the heater below an electrical socket outlet.
DO NOT use the heater without the grille fi tted.
DO NOT use the heater out of doors. These heaters are designed for indoor use only.
DO NOT cover heater when in use, and DO NOT obstruct the air inlet and outlet grilles.
DO NOT place heater too close to yourself or any object, allow the air to circulate freely.
DO NOT touch the outlet grille of the heater during and immediately after use as it will be hot.
1.4. OPERATIONAL PRECAUTIONS
The heater must only be used by people who have read these instructions and have been trained in its use.
DO NOT obstruct the air inlet and outlet sections of the heater.
DO NOT cover the heater.
DO NOT touch the heater casing or grille when fi rst switched off , as these will be very hot and will take time to cool.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervision.
Children of less than 3 years should be kept away unless continuously supervised.
Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed
in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.
CAUTION some parts of this product can become very hot and cause burns. Particular attention has to be given where children
and vulnerable people are present.
2. INTRODUCTION
Electric fan heaters with ducting for industrial applications. Model No. DEH2001 features one heat setting, Model Nos. DEH3001, DEH5001
and DEH10001 feature two heat settings. All units have thermostat control and fan only options. A totally dry heat with no condensation, no
gas, no fumes and no smell. Ideal for workshops and garages. Model No. DEH2001 is supplied with 6m ducting hose, power cable and 3-pin
plug. Model No DEH3001 is supplied with 6m ducting hose and power cable. DEH5001 is supplied with 6m ducting hose, 3ph power cable
and 16A plug. DEH10001 is supplied with 6m ducting hose, 3ph power cable and 32A plug.
3. SPECIFICATION
Model No:.................................DEH2001 ........................... DEH3001 ........................... DEH5001 .............................. DEH10001
Power: ...........................................2000W ...................... 1500/3000W .......................2500/5000W ......................... 5000/10000W
Supply: ................................... 230V - 13A .........................230V - 16A .................. 415V/3ph - 16A ....................... 415V/3ph - 32A
Airfl ow rating: .............................. 397m³/h ............................. 387m³/h ..............................738m³/h .................................1063m³/h
4. CONNECTION (DEH10001)
4.1. CONNECTING DEH10001 TO MAINS SUPPLY see fi g.1
4.1.1. The DEH10001 heater is supplied with a protected 5 pin connector mounted on the side of the control housing. In order to connect
to the mains it will be necessary to have the extension cable shown in fig.1 made up by a qualified electrician. (This connector is
not supplied with the machine.) The cable should be no shorter than 1.8mtr and no longer than 3.0mtr.
4.1.2. Before connecting the DEH10001 to the mains ensure that the selector switch is set to OFF and the thermostat is set at minimum.
4.1.3. Hold open the protective cover on the socket connector on the extension lead as shown above and present it to the heater
connector in the correct orientation so that the spigot on the heater connector passes into the keyway on the socket connector.
DEH2001 DEH3001 DEH5001 DEH10001 Issue 2 16/08/21
Original Language Version
© Jack Sealey Limited
Push the socket connector fully home.
4.1.4. Connect the other end of the extension cable to the mains supply.
5. OPERATION
5.1. Position the fan heater so that it stands upright on a fi rm surface and at a safe distance from wet environments and fl ammable
objects.
WARNING! Always allow elements to cool before moving the units. Use only on a smooth even surface.
5.2. Connect the fan heater to the mains (see section 4 for DEH10001).
5.3. Set the thermostat knob to the MAX and let the heater operate at full power.
5.4. The fan heater will switch on when the heating selector is set to one of the power settings.
5.5. Once the room reaches the required temperature, the heating element will stop working but the fan will keep working. Once the room
temperature goes below the set temperature, the heating element will start working. The fan heater will start and stop automatically
keeping the room temperature constant.
5.6. Before switching off the heater, please turn the thermostat to MIN position and turn the switch to the fan position, let the appliance
cool down for two minutes then turn off the heater and pull out the plug.
6. MAINTENANCE
WARNING! Before cleaning the appliance, disconnect it from the mains and let it cool down.
6.1. The cover can easily get dirty, wipe it often with a soft cloth. To clean dirt off of the cover, wipe with a clean sponge dipped in <50°C
water and mild detergent, then dry the heater cover with a clean cloth. Be careful not to let water enter the appliance.
DO NOT splash water onto the heater, never use solvent like gasoline etc. to clean the heater, in order to protect the cover.
6.2. When you store the heater, let it cool down fi rst, keep it dry. Then cover it with a plastic bag, put in a packing box and store it in a
dry, ventilated place.
7. TROUBLESHOOTING
Problem Possible cause Treatment
The heater does not operate,even when it
is plugged in and the switch and thermostat
are switched on.
The plug is loose, or there is a bad
connection
Pull out the plug, check the connection of
the plug and socket.
No power in socket outlet Insert the plug in a proper socket
The heating element is glowing The input voltage is too high or too low Use power supply according to the rating on
the label
The air inlet grill is blocked Keep the heater away from articles like
curtains, plastic bags, paper and other
things that can cover the inlet or can easily
cover the air inlet
The appliance didn’t heat up, or only the fan
worked
The switch was not turned to a heat setting Turn the switch to heat setting
The thermostat operated Turn the thermostat down wait for it to cool
and then turn the thermostat up. If there is
no click and the thermostat is not damaged,
the heater will automatically switch on when
the appliance has cooled down
The self-resetting cut-out operated Turn the heater off and inspect the blockage
of inlet or outlet. Disconnect the plug and
wait at least 10 minutes for the protection
system to reset before attempting to restart
the heater.
Abnormal noise The appliance is not stood upright Put the heater on a level surface
Off
Fan
Full Power
Off
Fan
Half Power
Full Power
fi g.2
DEH2001 DEH3001 DEH5001 DEH10001 Issue 2 16/08/21
Original Language Version
© Jack Sealey Limited
fi g.1
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
DEH2001 DEH3001 DEH5001 DEH10001 Issue 2 16/08/21
Original Language Version
© Jack Sealey Limited
Information requirements for electric local space heaters
(QWHU¿JXUHRU1$
0RGHOLGHQWL¿HUV
Item Symbol Value Unit Item Unit
Heat output
Type of heat input, for electric storage local space heaters
only (select one)
Nominal heat output
P
QRP
kW
0DQXDOKHDWFKDUJHFRQWUROZLWK
<HV1R
LQWHJUDWHGWKHUPRVWDW
0LQLPXPKHDWRXWSXWLQGLFDWLYH P
PLQ
kW
0DQXDOKHDWFKDUJHFRQWUROZLWKURRP
<HV1R
DQGRURXWGRRUWHPSHUDWXUHIHHGEDFN
0D[LPXPFRQWLQXRXVKHDWRXWSXW
P
PD[F
kW
(OHFWURQLFKHDWFKDUJHFRQWUROZLWKURRP
<HV1R
DQGRURXWGRRUWHPSHUDWXUHIHHGEDFN
)DQDVVLVWHGKHDWRXWSXW <HV1R
Type of heat output/room temperature control (select one)
6LQJOHVWDJHKHDWRXWSXWDQGQRURRP
<HV1R
WHPSHUDWXUHFRQWURO
7ZRRUPRUHPDQXDOVWDJHVQRURRP
<HV1R
WHPSHUDWXUHFRQWURO
:LWKPHFKDQLFWKHUPRVWDWURRP
<HV1R
WHPSHUDWXUHFRQWURO
:LWKHOHFWURQLFURRPWHPSHUDWXUHFRQWURO <HV1R
(OHFWURQLFURRPWHPSHUDWXUHFRQWUROSOXV
<HV1R
GD\WLPHU
(OHFWURQLFURRPWHPSHUDWXUHFRQWUROSOXV
<HV1R
ZHHNWLPHU
Other control options (multiple selections possible)
5RRPWHPSHUDWXUHFRQWUROZLWKSUHVHQFH
<HV1R
detection
5RRPWHPSHUDWXUHFRQWUROZLWKRSHQ
<HV1R
ZLQGRZGHWHFWLRQ
:LWKGLVWDQFHFRQWURORSWLRQ <HV1R
:LWKDGDSWLYHVWDUWFRQWURO <HV1R
:LWKZRUNLQJWLPHOLPLWDWLRQ <HV1R
:LWKEODFNEXOEVHQVRU <HV1R
&RQWDFWGHWDLOV6HDOH\*URXS.HPSVRQ:D\6XႇRON%XVLQHVV3DUN%XU\6W(GPXQGV6XႇRON,3$5ZZZVHDOH\FRXN
(537DEOH
Auxiliary electricity consumption
$WQRPLQDOKHDWRXWSXW el
PD[
kW
$WPLQLPXPKHDWRXWSXW el
PLQ
kW
,QVWDQGE\PRGH el
SB
kW
DEH2001,V1
N/A
N/A
N/A
2.0
N/A
2.0
v1
DEH2001,V1
N/A
N/A
N/A
2.0
N/A
2.0
v1
Information requirements for electric local space heaters
(QWHU¿JXUHRU1$
0RGHOLGHQWL¿HUV
Item Symbol Value Unit Item Unit
Heat output
Type of heat input, for electric storage local space heaters
only (select one)
Nominal heat output
P
QRP
kW
0DQXDOKHDWFKDUJHFRQWUROZLWK
<HV1R
LQWHJUDWHGWKHUPRVWDW
0LQLPXPKHDWRXWSXWLQGLFDWLYH P
PLQ
kW
0DQXDOKHDWFKDUJHFRQWUROZLWKURRP
<HV1R
DQGRURXWGRRUWHPSHUDWXUHIHHGEDFN
0D[LPXPFRQWLQXRXVKHDWRXWSXW
P
PD[F
kW
(OHFWURQLFKHDWFKDUJHFRQWUROZLWKURRP
<HV1R
DQGRURXWGRRUWHPSHUDWXUHIHHGEDFN
)DQDVVLVWHGKHDWRXWSXW <HV1R
Type of heat output/room temperature control (select one)
6LQJOHVWDJHKHDWRXWSXWDQGQRURRP
<HV1R
WHPSHUDWXUHFRQWURO
7ZRRUPRUHPDQXDOVWDJHVQRURRP
<HV1R
WHPSHUDWXUHFRQWURO
:LWKPHFKDQLFWKHUPRVWDWURRP
<HV1R
WHPSHUDWXUHFRQWURO
:LWKHOHFWURQLFURRPWHPSHUDWXUHFRQWURO <HV1R
(OHFWURQLFURRPWHPSHUDWXUHFRQWUROSOXV
<HV1R
GD\WLPHU
(OHFWURQLFURRPWHPSHUDWXUHFRQWUROSOXV
<HV1R
ZHHNWLPHU
Other control options (multiple selections possible)
5RRPWHPSHUDWXUHFRQWUROZLWKSUHVHQFH
<HV1R
detection
5RRPWHPSHUDWXUHFRQWUROZLWKRSHQ
<HV1R
ZLQGRZGHWHFWLRQ
:LWKGLVWDQFHFRQWURORSWLRQ <HV1R
:LWKDGDSWLYHVWDUWFRQWURO <HV1R
:LWKZRUNLQJWLPHOLPLWDWLRQ <HV1R
:LWKEODFNEXOEVHQVRU <HV1R
&RQWDFWGHWDLOV6HDOH\*URXS.HPSVRQ:D\6XႇRON%XVLQHVV3DUN%XU\6W(GPXQGV6XႇRON,3$5ZZZVHDOH\FRXN
(537DEOH
Auxiliary electricity consumption
$WQRPLQDOKHDWRXWSXW el
PD[
kW
$WPLQLPXPKHDWRXWSXW el
PLQ
kW
,QVWDQGE\PRGH el
SB
kW
DEH3001,V1
N/A
N/A
N/A
3.0
1.5
3.0
v1
DEH3001,V1
N/A
N/A
N/A
3.0
1.5
3.0
v1
Information requirements for electric local space heaters
(QWHU¿JXUHRU1$
0RGHOLGHQWL¿HUV
Item Symbol Value Unit Item Unit
Heat output
Type of heat input, for electric storage local space heaters
only (select one)
Nominal heat output
P
QRP
kW
0DQXDOKHDWFKDUJHFRQWUROZLWK
<HV1R
LQWHJUDWHGWKHUPRVWDW
0LQLPXPKHDWRXWSXWLQGLFDWLYH P
PLQ
kW
0DQXDOKHDWFKDUJHFRQWUROZLWKURRP
<HV1R
DQGRURXWGRRUWHPSHUDWXUHIHHGEDFN
0D[LPXPFRQWLQXRXVKHDWRXWSXW
P
PD[F
kW
(OHFWURQLFKHDWFKDUJHFRQWUROZLWKURRP
<HV1R
DQGRURXWGRRUWHPSHUDWXUHIHHGEDFN
)DQDVVLVWHGKHDWRXWSXW <HV1R
Type of heat output/room temperature control (select one)
6LQJOHVWDJHKHDWRXWSXWDQGQRURRP
<HV1R
WHPSHUDWXUHFRQWURO
7ZRRUPRUHPDQXDOVWDJHVQRURRP
<HV1R
WHPSHUDWXUHFRQWURO
:LWKPHFKDQLFWKHUPRVWDWURRP
<HV1R
WHPSHUDWXUHFRQWURO
:LWKHOHFWURQLFURRPWHPSHUDWXUHFRQWURO <HV1R
(OHFWURQLFURRPWHPSHUDWXUHFRQWUROSOXV
<HV1R
GD\WLPHU
(OHFWURQLFURRPWHPSHUDWXUHFRQWUROSOXV
<HV1R
ZHHNWLPHU
Other control options (multiple selections possible)
5RRPWHPSHUDWXUHFRQWUROZLWKSUHVHQFH
<HV1R
detection
5RRPWHPSHUDWXUHFRQWUROZLWKRSHQ
<HV1R
ZLQGRZGHWHFWLRQ
:LWKGLVWDQFHFRQWURORSWLRQ <HV1R
:LWKDGDSWLYHVWDUWFRQWURO <HV1R
:LWKZRUNLQJWLPHOLPLWDWLRQ <HV1R
:LWKEODFNEXOEVHQVRU <HV1R
&RQWDFWGHWDLOV6HDOH\*URXS.HPSVRQ:D\6XႇRON%XVLQHVV3DUN%XU\6W(GPXQGV6XႇRON,3$5ZZZVHDOH\FRXN
(537DEOH
Auxiliary electricity consumption
$WQRPLQDOKHDWRXWSXW el
PD[
kW
$WPLQLPXPKHDWRXWSXW el
PLQ
kW
,QVWDQGE\PRGH el
SB
kW
DEH5001,V1
N/A
N/A
N/A
5.0
2.5
5.0
v1
DEH5001,V1
N/A
N/A
N/A
5.0
2.5
5.0
v1
Information requirements for electric local space heaters
(QWHU¿JXUHRU1$
0RGHOLGHQWL¿HUV
Item Symbol Value Unit Item Unit
Heat output
Type of heat input, for electric storage local space heaters
only (select one)
Nominal heat output
P
QRP
kW
0DQXDOKHDWFKDUJHFRQWUROZLWK
<HV1R
LQWHJUDWHGWKHUPRVWDW
0LQLPXPKHDWRXWSXWLQGLFDWLYH P
PLQ
kW
0DQXDOKHDWFKDUJHFRQWUROZLWKURRP
<HV1R
DQGRURXWGRRUWHPSHUDWXUHIHHGEDFN
0D[LPXPFRQWLQXRXVKHDWRXWSXW
P
PD[F
kW
(OHFWURQLFKHDWFKDUJHFRQWUROZLWKURRP
<HV1R
DQGRURXWGRRUWHPSHUDWXUHIHHGEDFN
)DQDVVLVWHGKHDWRXWSXW <HV1R
Type of heat output/room temperature control (select one)
6LQJOHVWDJHKHDWRXWSXWDQGQRURRP
<HV1R
WHPSHUDWXUHFRQWURO
7ZRRUPRUHPDQXDOVWDJHVQRURRP
<HV1R
WHPSHUDWXUHFRQWURO
:LWKPHFKDQLFWKHUPRVWDWURRP
<HV1R
WHPSHUDWXUHFRQWURO
:LWKHOHFWURQLFURRPWHPSHUDWXUHFRQWURO <HV1R
(OHFWURQLFURRPWHPSHUDWXUHFRQWUROSOXV
<HV1R
GD\WLPHU
(OHFWURQLFURRPWHPSHUDWXUHFRQWUROSOXV
<HV1R
ZHHNWLPHU
Other control options (multiple selections possible)
5RRPWHPSHUDWXUHFRQWUROZLWKSUHVHQFH
<HV1R
detection
5RRPWHPSHUDWXUHFRQWUROZLWKRSHQ
<HV1R
ZLQGRZGHWHFWLRQ
:LWKGLVWDQFHFRQWURORSWLRQ <HV1R
:LWKDGDSWLYHVWDUWFRQWURO <HV1R
:LWKZRUNLQJWLPHOLPLWDWLRQ <HV1R
:LWKEODFNEXOEVHQVRU <HV1R
&RQWDFWGHWDLOV6HDOH\*URXS.HPSVRQ:D\6XႇRON%XVLQHVV3DUN%XU\6W(GPXQGV6XႇRON,3$5ZZZVHDOH\FRXN
(537DEOH
Auxiliary electricity consumption
$WQRPLQDOKHDWRXWSXW el
PD[
kW
$WPLQLPXPKHDWRXWSXW el
PLQ
kW
,QVWDQGE\PRGH el
SB
kW
DEH10001,V1
N/A
N/A
N/A
10.0
5.0
10.0
v1
DEH10001,V1
N/A
N/A
N/A
10.0
5.0
10.0
v1
