BAUMR-AG PLTCLSBMPC3A Cordless Pole Saw Kit Telescopic User Manual

PC3 Pole Saw Kit

User Manual

[Revision 2.0]

READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND

MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in

appearance, assembly, inclusions, specifications, description, and packaging.

THE BATTERY MAY HAVE SO

ME CHARGE ON ARRIVAL, IT IS IMPORTANT

HOWEVER THAT THE BATTERY IS CHARGED PRIOR TO USE.

PC3 Pole Saw Kit

Safety

Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or

equipment or property damage if not understood or followed. Safety messages have the following symbols:

You WILL be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be INJURED if you do

not follow instructions or equipment

damage may occur.

It is vital that you read and understand this

user manual before using the product,

including safety warnings, and any assembly

and operating instructions. Keep the manual

for future reference.

Safety precautions and recommendations

detailed here must be fully understood and

followed to reduce the risk of injury, fire,

explosion, electrical hazard, and/or property

damage.

Safety information presented here is generic

in nature – some advice may not be

applicable to every product. The term

"equipment" refers to the product, be it

electrical mains powered, battery powered or

combustion engine powered.

• Before Use - If you are not familiar with the

safe operation/handling of the equipment or

are in any way unsure of any aspect of

suitability or correct use for your

application, you should complete training

conducted by a person or organization

qualified in safe use and operation of this

equipment, including fuel/electrical handling

and safety.

• Do NOT operate the equipment in

flammable or explosive environments, such

as in the presence of flammable liquids,

gases, or dust. The equipment may create

sparks or heat that may ignite flammable

substances.

• Keep clear of moving parts.

• Equipment may be a potential source of

electric shock or injury if misused.

• Do NOT operate the equipment if it is

damaged, malfunctioning or is in an

excessively worn state.

• Do NOT allow others to use the equipment

unless they have read this manual and are

adequately trained.

• Keep packaging away from children - risk

of suffocation! Operators must use the

equipment correctly. When using the

equipment, consider conditions and pay

due care to persons and property.

General Work Area Safety

• Wor

k areas should be clean and well it.

• Do not operate the equipment if

bystanders, animals etc are within

operating range of the equipment or the

general work area.

• If devices are provided for connecting dust

extraction / collection facilities, ensure

these are connected and used properly.

Dust collection can reduce dust-related

hazards.

General Personal Safety

• Wear

appropriate protective equipment

when operating, servicing, or when in the

operating area of the equipment to help

protect from eye and ear injury, poisoning,

burns, cutting and crush injuries. Protective

equipment such as safety goggles,

respirators, non-slip safety footwear, hard

hat, hearing protection etc should be used

for appropriate equipment / conditions.

Other people nearby should also wear

appropriate personal protective equipment.

Do not wear loose clothing or jewellery,

which can be caught in moving parts. Keep

hair and clothing away from the equipment.

• Stay alert and use common sense when

operating the equipment. Do not over-

reach. Always maintain secure footing and

balance.

• Do not use the equipment if tired or under

the influence of drugs, alcohol, or

medication.

• This equipment is not intended for use by

persons with reduced physical, sensory, or

mental capabilities.

General Fuel Safety

• P

etrol/fuel/gasoline is extremely flammable

– keep clear of naked flames or other

ignition sources.

• Do not spill fuel. If you spill fuel, wipe it off

the equipment immediately – if fuel gets on

your clothing, change clothing.

• Do NOT smoke near fuel or when

refuelling.

• Always shut off the engine before

refuelling.

• Do NOT refuel a hot engine.

• Open the fuel cap carefully to allow any

pressure build-up in the tank to release

slowly.

• Always refuel in well-ventilated areas.

• Always check for fuel leakage. If fuel

leakage is found, do not start, or run the

engine until all leaks are fixed.

General Carbon-Monoxide Safety

• U

sing a combustion engine indoors CAN

KILL IN MINUTES. Engine exhaust

contains carbon-monoxide – a poison you

cannot smell or see.

• Use combustion engines OUTSIDE only,

and far away from windows, doors, and

vents.

General Equipment Use and Care

• K

eep packaging away from children and

pets, potential risk of suffocation or

choking.

• The equipment is designed for domestic

use only.

• Handle the equipment safely and carefully.

• Before use, inspect the equipment for

misalignment or binding of moving parts,

loose components, damage, or any other

condition that may affect its operation. If

damaged, have the equipment repaired by

an authorised service centre or technician

before use.

• Prevent unintentional starting of the

equipment - ensure equipment and power

switches are in the OFF position before

connecting or moving equipment. Do not

carry equipment with hands or fingers

touching any controls. Remove any tools or

other items that are not a part of the

equipment from it before starting or

switching on.

• Do not force the equipment. Use the

correct equipment for your application.

Equipment will perform better and be safer

when used within its design and usage

parameters.

• Use the equipment and accessories etc. in

accordance with these instructions,

considering working conditions and the

work to be performed. Using the equipment

for operations different from those intended

could result in hazardous situations.

• Always keep equipment components

(engines, hoses, handles, controls, frames,

housings, guards etc) and accessories

(cutting tools, nozzles, bits etc) properly

maintained. Keep the equipment clean and,

where applicable, properly lubricated.

• Store the equipment out of reach of

children or untrained persons. To avoid

burns or fire hazards, let the equipment

cool completely before transporting or

storing. Never place or store the equipment

near flammable materials, combustible

gases, or liquids etc.

• The equipment is not weather-proof, and

should not be stored in direct sunlight, at

high ambient temperatures or locations that

are damp or humid.

• Do not clean equipment with solvents,

flammable liquids, or harsh abrasives.

• For specific equipment safety use and care,

see Equipment Safety.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

General Electrical Safety

• I

nspect electrical equipment, extension

cords, power bars, and electrical fittings for

damage or wear before each use. Repair or

replace damaged equipment immediately.

• Ensure all power sources conform to

equipment voltage requirements and are

disconnected before connecting or

disconnecting equipment.

• When wiring electrically powered

equipment, follow all electrical and safety

codes.

• Always use a Residual Current Device

(RCD) (GFCI) / Earth Leakage Circuit

Breaker / Safety Switch when operating this

item (electrical items only).

• High voltage / high current power lines may

be present. Use extreme caution to avoid

contact or interference with power lines.

Electrical shock can be fatal.

General Electrical Safety

• E

lectrically grounded equipment must have

an approved cord and plug and be

connected to a grounded electrical outlet.

• Do NOT bypass the ON/OFF switch and

operate equipment by connecting and

disconnecting the electrical cord.

• Do NOT use equipment that has exposed

wiring, damaged switches, covers or

guards.

• Do NOT use electrical equipment in wet

conditions or in damp locations.

• Do NOT use electrical cords to lift, move or

carry equipment.

• Do NOT coil or knot electrical cords, and

ensure electrical cords are not trip hazards.

General Service Information

• T

he equipment must be serviced or

repaired at authorised service centres by

qualified personnel only.

• Replacement parts must be original

equipment manufacturer (OEM) to ensure

equipment safety is maintained.

• Do NOT attempt any maintenance or repair

work not described in this manual.

• After use, the equipment and components

may still be hot – allow the equipment to

cool and disconnect spark plugs and/or

electrical power sources and/or batteries

from it before adjusting, changing

accessories, or performing repair or

maintenance.

• Do NOT adjust while the equipment is

running.

• Perform service-related activities in suitable

conditions, such as a workshop.

• Replace worn, damaged or missing

warning/safety labels immediately.

Child Choking Hazard!

• W

ARNING: CHOKING HAZARD - CHILDREN UNDER 8 YRS. CAN CHOKE OR SUFFOCATE ON SMALL PARTS. ADULT

SUPERVISION REQUIRED.

• Carefully inspect anything a baby or child could gain access to, including this product & packaging.

• Dangers include anything of a size that could become stuck or lodged in a baby or child's airway.

• Dangers include things like raw, hard fruit and vegetable pieces, large pieces of meat, bones or sausage skins, popcorn, nuts,

hard lollies and corn chips, small magnets and batteries, coins, beads, marbles and small uninflated balloons, broken toys and smaller toys,

buttons, keys, and coins. But there are also many more.

• Pay particular attention to accessories, nuts, bolts, screws, washers, caps, covers, loose parts, parts that could be removed or break off, pieces

of packaging, staples, tape etc.

• In the case of any doubt, secure the item of concern in an appropriate manner, or completely remove the possibility of access by a baby or child.

Important Safety Reminders

• BE

AWARE THAT THE EQUIPMENT MAY INCLUDE HAZARDOUS COMPONENTS, SUCH AS BLADES, HOT SURFACES AND MOVING

PARTS.

• MOVING BLADES CAN CAUSE SERIOUS INJURY AND EVEN DEATH IF USED IMPROPERLY OR WITHOUT SUFFICIENT PPE.

• DO NOT USE THIS EQUIPMENT ON UNEVEN SURFACES AND ALWAYS MAINTAIN GOOD BALANCE WHEN USING THIS EQUIPMENT.

FAILURE TO DO SO MAY CAUSE SERIOUS INJURY.

• MAINTAIN A SECURE GRIP OF THE TRIGGER ASSEMBLY AT ALL TIMES.

General Power tool Safety Warnings

• WA

RNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or

serious injury.

• Save all warnings and instructions for future reference.

• The term "power tool" in the warnings refers to your mains operated (corded) power tool or battery-operated (cordless) power tool.

Work area safety

• K

eep work area clean and well lit. Cluttered or dark areas invite accidents.

• Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks

which may ignite the dust or fumes.

• Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical safety

• P

ower tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools.

Unmodified plugs and matching outlets will reduce risk of electric shock.

• Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges, and refrigerators. There is an increased risk of electric

shock if your body is earthed or grounded.

• Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.

• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or

moving parts. Damaged or entangled cords increase the risk of electric shock.

• When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of

electric shock.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

• If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the

risk of electric shock.

Personal safety

• S

tay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under

the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.

• Use personal protective equipment. Always wear eye protection.

• Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce

personal injuries.

• Prevent unintentional starting. Ensure the switch is in the off position before connecting to power source and/or battery pack, picking up or

carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.

• Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may

result in personal injury.

• Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.

• Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewellery or

long hair can be caught in moving parts.

• If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust

collection can reduce dust-related hazards.

Power tool use and care

• D

o not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for

which it was designed.

• Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must

be repaired.

• Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or

storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.

• Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the

power tool. Power tools are dangerous in the hands of untrained users.

• Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power

tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.

• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

• Use the power tool, accessories, and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work

to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.

Service

• H

ave your power tools serviced by a qualified repair person using only identical replacement parts. This will ensure that safety of the power tool is

maintained.

Battery tool use and care

• R

echarge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire

when used with another battery pack.

• Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.

• When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects,

that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.

• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts

eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.

Special Safety Instructions for Battery packet and Charger

• If under

extreme conditions any electrolyte should escape from the battery, it's essential to avoid contact with skin. If electrolyte does come into

contact with your skin, rinse it off with water. In the event of electrolyte contact with your eyes, it's essential to consult a doctor.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

• Before the use of the charger and the battery packet, read the instruction manual for it carefully.

• During the charge process, the current used should correspond to the current of the battery charger.

• Never let moisture, rain or splashed water reaches the charging location.

• The ambient temperature must not exceed 40oC. Never expose the device to direct insulation.

• Storage-battery packet, which are defective or damaged or can no longer be recharged, must be disposed of as hazardous waste. Hand them

over at a special collection point. Never harm our environment. Do not throw unusable storage- battery packet away into the domestic waste, into

fire or into water.

• If the electrical cable is damaged, the wire may only be replaced by the supplier or by his repair workshop. Have repairs carried out only by an

authorized specialist only.

• Use only storage-battery packet, which have been produced by the original manufacturer.

• Always keep the surface of the charger free from dust and dirt.

• Insert the battery packet into the charger. Follow the guidelines provided concerning polarity.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

• Always remove battery packet before working on the machine

• When the battery packet is outside the drill, cover the contacts to avoid short circuits (e.g. from tools)

• Do not throw batteries into water or fire, risk of explosion!

• Protect the battery packet from impacts, and don't open it.

• Never discharge the battery packet completely and recharge occasionally if not used for a prolonged period.

Pole Saw Safety Warnings

• O

bserve your surroundings, always remove the fallen branches before cutting, always keep the working area clean before operation.

• Always keep the bystanders at least 15 m away from the working area, especially for children.

• Always wear a helmet, ear protection and safety gloves when working with the Pole saw. Also wear eye protection to keep oil spray and sawdust

out of your eyes.

• Wear dust mask to protect against dust.

• Do not wear loose clothing, jewellery, or short pants while operating.

• Never use the Pole saw while standing on a ladder.

• Do not overreach. Always keep a firm footing and balance during operation, always use the provided harness to distribute the load evenly on your

body.

• Wear sturdy boots to protect yourself from slipping.

• Do not use the electric Pole saw in rain or wet conditions.

• Avoid using the Pole saw close to power lines. Keep a safe distance of at least 10m to over ground power lines.

• Do not stand under the branch you are cutting. Branches may fall without warning. Also beware of the risk of being struck by those that rebound

after hitting the ground. Work at an angle of no more than 60°.

• Keep in mind that, when using the upper point of the saw, the Pole saw may kick back quite violently.

• Keep your eyes not only on the branches you are cutting, also keep an eye on the ground to prevent tripping over from branches that already

have fallen.

• Keep a period of rest for at least 30 minutes after one hour’s operation, otherwise you are getting too tired to control the Pole saw.

• Always wear gloves when handling the saw chain.

• Always cover the guide bar and chain with the protective cover during transportation and storage.

• Do not operate the machine in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. The machine creates sparks

which may ignite the dust or fumes.

• Do not use the machine if the switch does not turn it on and off. Any machine that cannot be controlled with the switch is dangerous and must be

repaired.

• Store idle machine out of the reach of children and do not allow persons unfamiliar with the machine or these instructions to operate the machine.

Machines are dangerous in the hands of untrained users.

• Maintain machine. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the machine’s

operation. If damaged, have the machine repaired before use. Many accidents are caused by poorly maintained machine.

• Keep saw chain sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

• Have your machine serviced by a qualified repair person using only original replacement parts. This will ensure that the safety of the machine is

maintained.

• Children should be supervised to ensure that they do not play with the appliance.

Residual risks

• E

ven when the tool is used as prescribed it is not possible to eliminate all residual risk factors. The following hazards may arise in connection with

the tool’s construction and design:

• Damage to lungs if an effective dust mask is not worn.

• Damage to hearing if effective hearing protection is not worn.

• Health defects resulting from vibration emission if the appliance is being used over longer period of time or not adequately managed and

properly maintained.

• WARNING! THIS MACHINE PRODUCES AN ELECTROMAGNETIC FIELD DURING OPERATION. THIS FIELD MAY UNDER SOME

CIRCUMSTANCES INTERFERE WITH ACTIVE OR PASSIVE MEDICAL IMPLANTS. TO REDUCE THE RISK OF SERIOUS OR FATAL

INJURY, WE RECOMMEND PERSONS WITH MEDICAL IMPLANTS TO CONSULT THEIR PHYSICIAN AND THE MEDICAL IMPLANT

MANUFACTURER BEFORE OPERATING THIS MACHINE.

• Wear hearing protection while operating the power tool.

• The declared vibration total value has been measured in accordance with a standard test method and may be used for comparing one tool with

another.

• The declared vibration total value may also be used in a preliminary assessment of exposure.

• WARNING! THE VIBRATION EMISSION DURING ACTUAL USE OF THE POWER TOOL CAN DIFFER FROM THE DECLARED TOTAL

VALUE DEPENDING ON THE WAYS IN WHICH THE TOOL IS USED. THERE IS THE NEED TO IDENTIFY SAFETY MEASURES TO

PROTECT THE OPERATORS THAT ARE BASED ON AN ESTIMATION OF EXPOSURE IN THE ACTUAL CONDITIONS OF USE (TAKING

ACCOUNT OF ALL PARTS OF THE OPERATING CYCLE SUCH AS THE TIMES WHEN THE TOOL IS SWITCHED OFF AND WHEN IT IS

RUNNING IDLE IN ADDITION TO THE TRIGGER TIME).

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

Safety Symbols

The product may have safety warning labels attached to it, explained below. Understand the symbols on your

product and their meanings. If any stickers become unreadable, unattached etc., replace them.

Flammable Material Hazard

Flammable liquids, gases, or

substances etc may present.

Avoid ignition sources and open

flames. Danger of fire.

Read User Manual

Read and fully understand

product safety warnings,

operation, procedures etc before

using the product.

Use Hand Protection

Wear appropriate hand protection

and take due care as the product

or use of the product may present

hand hazards.

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Electrocution / Electrical Shock

Hazard

High voltage or high current

electricity may be present or

required by the product. Take

due care when handling electrical

products, cables, plugs and

leads. Electrical shock can be

fatal.

Toxic Fumes / Dust Hazard

Using the product or by-products

from use may produce fumes,

smoke or particles that could be

harmful if inhaled. Wear

appropriate breathing protection

and have adequate ventilation.

Explosive Material Hazard

Combustible liquids, gases, or

substances etc may be present.

Avoid ignition sources and open

flames. Danger of explosion.

Cutting / Amputation Hazard

The product may have blades,

edges or mechanical devices that

can cause severe cut injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Crush Hazard

The product may have blades,

edges or mechanical devices that

can cause severe crush injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Single Operator Only

The product must be operated by

a single person only. More than

one person operating the product

may introduce additional hazards.

Use Face Protection

Wear appropriate full-face

protection and take due care as

the product or use of the product

may present face and eye

hazards.

Use Foot Protection

Wear appropriate foot protection

and take due care as the product

or use of the product may present

foot hazards.

Use Eye / Ear / Head Protection

Wear appropriate eye and / or

ear and / or head protection and

take due care as the product or

use of the product may present

eye, hearing, and head hazards.

Running Hazard

Do not run on or near the product

as doing so may present a fall

hazard.

Diving Hazard

Do not dive into the product as

doing so may present a neck /

head injury hazard.

Adult Supervision Required

Always supervise children and

other users of a product to

prevent drowning or injury.

Skin Penetration / Puncture

Hazard

The product may produce

pressure, emit liquids or objects

that can cause severe injury to

fingers, limbs, blood etc. Take

due care when handling and

using the product.

Hot Surface Hazard

Be aware that the product may

produce high temperatures and

hot surfaces that can cause burn

injuries.

Flying Debris Hazard

Be aware that the product or use

of the product may present

hazards produced by flying

debris. Wear appropriate clothing

and protective devices.

Moving Parts Hazard

Be aware that the product

contains or uses mechanical

devices that move or rotate.

Always wait for moving parts to

stop fully before handling the

product, adjusting, maintenance

etc.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Pull Hazard

Be aware that the product

contains or uses mechanical

devices that can pull in objects

and can cause severe injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Slope / Fall Injury Hazard

Be aware that using the product

on sloping surfaces or in slippery

conditions may present additional

dangers from falls and contact

with blades, moving parts, hot

surfaces etc.

"Slam Dunk" Warning

Do NOT attempt "slam dunk"

manoeuvres as this may result in

severe injury due to falling,

product breakage or collapse etc.

Electrocution / Electrical Shock

Hazard - Outdoor

High voltage or high current

electricity may be present or

required by the product. Do NOT

use in rain, damp, or wet

conditions. Electrical shock can

be fatal.

Electrocution / Electrical Shock

Hazard - Disconnect

High voltage or high current

electricity may be present or

required by the product. Always

disconnect the product from the

electrical supply before handling

the product, adjusting,

maintenance etc.

Power Line Electrocution

Hazard

High voltage / high current power

lines may be present. Use

extreme caution to avoid contact

or interference with power lines.

Electrical shock can be fatal.

"Kick-Back" Hazard

High level of "kick-back" hazard

that can cause the machine to

suddenly rotate towards operator.

Kick-back injury can be fatal.

Winch Operator Position

Hazard

Do NOT stand between winch

and load. Do NOT use winch to

move people.

Winch Lift Hazard

Do NOT LIFT load vertically. Use

machine to PULL only.

Cable Hazard

Ensure that load bearing cable is

not kinked or knotted.

Winch Cable Hazard

Ensure that there is a minimum

number of cable coils on

winching mechanism.

Winch Hook Hazard

Carry hook to load – do NOT

throw or run.

Flash / Blinding Hazard

Wear appropriate eye protection

for welding. Direct exposure to

weld arcs may cause permanent

eye injury.

Laser Hazard

Laser may be in use – do NOT

look directly at laser or allow

others to.

Choking Hazard

Children under 8 yrs. Can choke

or suffocate on small parts. Adult

supervision required.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

Table of Contents

Safety ......................................................................................................................................................... 2

Safety Symbols ........................................................................................................................................................... 6

Parts Identification .................................................................................................................................... 9

Assembly ................................................................................................................................................. 12

Install Function Head ................................................................................................................................................ 12

Adjusting the Length of the Telescopic Rod ............................................................................................................. 12

Installing the Battery ................................................................................................................................................. 13

Installing the Shoulder Grip ...................................................................................................................................... 13

Filling with Oil ............................................................................................................................................................ 13

Operation ................................................................................................................................................. 14

Intended Use ............................................................................................................................................................ 14

Proper Usage ............................................................................................................................................................ 14

Special Functions ..................................................................................................................................................... 14

Operating Instructions............................................................................................................................................... 15

Maintenance ............................................................................................................................................. 18

Adjusting the Pole Saw Chain Tension .................................................................................................................... 18

Replacing the Pole Saw Blade ................................................................................................................................. 19

Storage ..................................................................................................................................................................... 19

Lithium Battery Care and Maintenance .................................................................................................. 20

Top 3 Battery Care Requirements ............................................................................................................................ 20

Specifications .......................................................................................................................................... 22

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

Parts Identification

4

5

17

1

16

19

3

20

21

9

2

22

18

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

10

6

13

14

12

15

11

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

No. Name No. Name

1 Pole saw head 12 Hex spanner

2 Chain bar 13 Drive sprocket

3 Plastic blade cover 14 Linkage of Chain Tension

4

Main handle grip

15

Screw of the chain tension

5

Shoulder Grip

16

Lock sleeve

6

Twisting knob

17

Handle Lock sleeve

7

Screw hole

18

On-off switch

8 Front handle 19 Extendable rods

9 Garden chain 20 Battery

10 Oil tank 21 Charger

11

Oiler

22

Circular & spring button

Spare parts available

for purchase, scan QR

code below:

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

Assembly

Install Function Head

Adjusting the height of cutting head

1. Hold one end of the telescopic rod and connect the work head with the telescopic rod.

2. Tighten the lock- sleeve, to ensure the function head is tightened.

Adjusting the Length of the Telescopic Rod

1. Hold one end of the extendable rods and unscrew the lock-sleeve.

2. Extend the rods to the height you need.

3. Tighten the lock- sleeve, to sure the extendable rods are tightened.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

Installing the Battery

1. Take out the battery from the package box.

2. Hold the main handle grip with your hand, and the other hand hold the battery.

3. Press down on the battery lock button.

4. Insert into the battery bracket until it fits snugly.

Installing the Shoulder Grip

The shoulder grip is connected with one plastic hasp. By pressing the spring with one hand, the hasp can be

opened. Pushing the spring part of the hasp to the locked part, will lock the hasp.

The plastic hasp has a safety protection function. When the work environment or the machine had accidental

situations, you can push the spring part of the hasp. This design allows you leave to danger easily and quickly.

Filling with Oil

Open oil cap and pour machine oil into the oil tank. Use machine oil only. Please don’t fully fill!

CAUTION: If you are adding lubrication grease. please use a grease gun to fill the machine oil into tank.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

Operation

Intended Use

The tool is designed for cutting bushes and small hedges in private and hobby gardens. Tools for private and

hobby gardens are not suitable for use in public facilities, parks, and sport centers, along roadways, on farms or

in the forestry sector. The tool is to be used only for its prescribed purpose. Any other use is deemed to be a

case of misuse.

It is prohibited to use the tool to chop material for composting because of the potential danger to

persons and property.

ATTENTION: Always take off the battery pack from the appliance before undertaking any maintenance

work.

Proper Usage

1. Wear the shoulder grip.

2. Hold the main handle grip with one hand and catch the front handle with your other hand.

3. Press the lock switch button with the thumb to the other side.

4. Always toggle the ON/OFF switch button with your index finger.

Your equipment is now ready to be used.

WARNING: Always keep the machine on the other side of your body. It may reduce dangers or risk to

occur.

ATTENTION: Adjust the height of the unit according to the needs of actual operating environments.

Special Functions

Rotate the Pole saw cutting head.

•

The cutting heads can be adjusted and rotate 0°~20°~40° to the planar side according to the required

cutting.

Adjusting or rotating the connection part of the cutting head

1. Hold the connecting part with one hand and press the circular spring button with your thumb.

2. Holding the cutting head and rotate it downward 20° or 40° until the upward and downward small circular

holes of the connection part in a straight line to stop. As time as the button will be restored and emit a “click”

sound. There’s a total of 3 gears for a 40° adjusting angle.

Pole Saw:

0° (level position)

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

20° position

40° position

Operating Instructions

CAUTION: Before first operating the machine, please read these instructions carefully and

be familiar with this machine.

•

Hold the equipment firmly and securely with both hands.

•

Always be aware of your surroundings and don’t put yourself in a dangerous situation. Be calm and

considerate of others when working with the unit.

•

Do not work under bad visibility and lighting conditions.

•

Always be aware of the cutting head.

•

Work only on firm, stable ground.

•

Never use this unit while standing on a ladder.

•

Ensure that no person or animal are within 15m of surrounding the working area. Stop the machine if

someone, especially children, are nearby.

•

Only use the unit during bright, daylight hours.

•

Always wear thick, work-approved gloves or any other gloves made of robust material when operating the

pole chain saw.

•

Cut branches can fall on your face or eyes and can lead to serious injuries, scratches, or cuts. Always wear

a helmet and a protective face cover when you are operating the machine.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

•

Always check the oil level before operating.

Check Oil Level

1. After switching on the tool, let the chain run for a few seconds and check if there is oil splashing out, as

shown.

The oil level can last for a maximum working time of 3 minutes (set to minimal running, or one tankful). Make

sure to refill the oil tank every time before you start any operation.

CAUTION:  Never fill the oil tank or set the oil supply when the machine is running.  Add machine oil

before you turn off the switch and remove the battery pack as well.  The pump has been set in the

factory to guarantee optimal flow; thus, the setting can’t be changed when you’re using it.  Check the

oil tank first before any operation. If the machine oil in the tank is low, add oil. Operating the tool without

engine oil could seriously damage it!

Working with the Tool

•

Do not work with an angle higher than 60°. The chain saw will

work under higher degrees, but there is the danger of being

injured by falling branches without warning. Keep an eye at the

ground while working to avoid tripping over fallen branches.

•

Never use the chain saw without oil, use bio-degradable chainsaw

oil.

•

Please keep in mind that this Pole saw, like all chainsaws, flings

oil from the chain during operation. Protect yourself from falling oil

drops with suitable protective glasses and clothing.

•

To operate the chain saw, press down on the lockout button, and

then pull the switch trigger.

•

The machine is equipped with a low-kickback chain, and it was

also done everything from an engineering point of view to keep

kickback low.

•

Nevertheless, some kickback cannot be avoided when cutting with

the upper tip of the blade. Be prepared for some kickback when using this area of the blade or hitting

another branch with this area. Always hold the unit firmly in both hands.

•

Thin branches can be cut off with one single cut. To prevent the branch from slivering and buckling, the

branch should be cut off in several pieces.

•

When cutting off larger branches, you should first cut into the branch form below. First cut into the branch

from below, outside the place where you intend to cut off the branch. The cut should go from one third to

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

halfway through the branch. This prevents the branch from buckling when you cut into the branch from the

top outside the first cut. Last, cut off the stump with one clean cut. You might want to seal the cut with a

suitable compound.

DANGER! THIS DEVICE IS EQUIPPED WITH EXTREMELY SHARP BLADES, AND WHEN THOSE ARE

USED WRONGLY, IT CAN BE EXTREMELY DANGEROUS AND LEAD TO ACCIDENTS, RESULTING IN

SERIOUS INJURY OR DEATH. ALWAYS FOLLOW THE FOLLOWING INSTRUCTIONS.

•

Do not point the machine at other people.

•

Never let your body touch the blades when the motor of the chain saw is still running.

•

Make sure to switch off the machine and disconnect it from the battery power source before replacing the

angles of the blades, removing branches, the blocks of the blade or at any other time, when you touch the

blade.

•

Always wear thick, work-approved gloves or any other gloves made of robust material when operating the

unit.

•

Place the provided cutting protection over the blades when the device is not in use.

•

Cut branches can fall on your face or eyes and can lead to serious injuries, scratches, or cuts. Always wear

a helmet and a protective face cover when you are operating the machine.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

Maintenance

Adjusting the Pole Saw Chain Tension

How to take down the cutting head?

1. Hold the connection part with one hand, and with the other hand, hold the cutting head.

2. Hold the lock button of the holding connection part, then pull out the cutting head.

WARNING!  The Pole saw chain has sharp edges. Wear protective gloves for your safety.  Always mind

the chain tension. The risk of a setback increases with an un-tensioned chain. If it is un-tensioned, it can

jump out of the guide easily, and hurt the operator, or be damaged. An un-tensioned chain can burn out

easily as well as the sprocket and guide rail.

Often-used tools can lead to the chain becoming loose.

When the chain is in a loosened state, you must adjust the chain tension in a timely manner.

How to adjust and tension the chain?

1. Find the screw of the chain tensioner. It’s located at the Pole saw head - motor side.

2. Hold and insert a hex spanner into the screw of the chain tensioner, then tension the hex screw and

reference the diagram above - right side until you cannot draw out the chain to stop.

3. When the blade of the chain isn’t sharp, you must replace with a new one in a timely manner.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

Replacing the Pole Saw Blade

1. Loosen the twisting knob, then take off the upper cover of the working head.

2. Take down the chain bar cover, then take out the garden chain with your hand.

3. Install the drive sprocket in a way that the chain tension nippers stick up to the chain bar. Make sure the

chain is running towards the right direction!

4. Install the chain bar cover and replace the cutting head.

5. Re-tension the chain.

CAUTION: The chain should not sag, but it should be possible to pull the chain a few millimetres from

the saw rail.

Storage

•

Store the machine in a dry place, out of reach of children.

•

Store the machine with the supplied protection cover.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

Lithium Battery Care and Maintenance

Top 3 Battery Care Requirements

1. Charge battery before first use. The battery may arrive with some charge, regardless of this the

battery must be charged on the initial charge and for each subsequent charge.

2. Charge battery immediately when it is depleted. Do not store a depleted battery. This will

permanently impact the life of the battery. If the battery is going to be stored for a period of time, fully

charge the battery before storing.

3. Disconnect battery when not in use. To prolong the life of a battery, disconnect it from the unit

when not in use. Disconnect chargers from the battery once charged.

To ensure the battery maintains optimum performance, follow the guidelines outlined below.

•

For best results, charge batteries in temperatures between 10°C and 30°C

•

When battery is charged, disconnect the charger from the power supply and remove the battery from the

charger.

•

If a battery is stored or otherwise unused for an extended period, and the battery has no charge remaining

when you check it, consider it to be damaged. Do not attempt to recharge it or to use it. Replace it with a

new battery.

•

Use only with the battery charger specified by the manufacturer.

•

Ensure that the battery charger electrical cord is not subjected to damage or stress. Do not operate the

battery charger if it has a damaged electrical cord or plug.

•

Do not use the charger in wet areas or expose it to rain or water.

•

The typical estimated life of a Lithium-Ion battery is about two to three years or 300 to 500 charge cycles,

whichever occurs first. One charge cycle is a period of use from fully charged, to fully discharged, and fully

recharged again.

•

Explosion hazard – protect the battery against heat, for example, direct sunlight and fire. Do not store

batteries in vehicles or locations subject to heat.

•

Batteries can explode in the presence of an ignition source, such as a pilot light. To reduce the risk of

serious personal injury, never use any cordless product in the presence of open ﬂame. Exploding batteries

can propel debris and chemicals.

•

Do not open the battery – danger of short-circuiting and/or explosion.

•

Do not attempt to destroy or disassemble the battery pack or remove any of its components.

•

Do not touch the battery terminals with metal objects and/or body parts as short-circuit and/or personal injury

may result.

•

Explosion hazard – do not open and/or short-circuit the battery.

•

Poison hazard – battery leakage (liquid ejection). Under extreme conditions, liquid may be ejected from the

battery – avoid contact. If contact accidentally occurs, immediately seek medical attention, and flush with

water. If liquid contacts eyes, immediately seek medical attention, flush with clean water for at least 10

minutes. Liquid ejected from the battery may cause irritation or burns.

•

Dispose of non-serviceable batteries in an environmentally responsible manner and according to local

regulations.

Failure to adhere to the requirements above may result in the battery becoming inoperative or battery life being

reduced. In extreme cases or abuse, battery overheating, or fire may result.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

PC3 Pole Saw Kit

Specifications

Series SYNC

Battery 20V 2Ah Lithium

Chainsaw Bar 8 Inch

Auto Lubrication Yes

Oil Pot Capacity 60ml

Throttle Control Handle Rubber Over Moulded

Shaft Aluminium

Charger 240V / 2.4Ah

Total Average Reach 2m

Power Plug Australian Standard

Note: Minimal Assembly required

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Some experts believe that the incorrect or prolonged use of almost any

product may cause serious injury or death. To help reduce your risk of

serious injury or death, refer to the information below. For more information,

see www.datastreamserver.com/safety



Consult all documentation, packaging,

and product labelling before use. Note

that some products feature

documentation available online. It is

recommended to print and retain the

documentation.



Before each use, check the product for

loose/broken/damaged/missing parts,

wear, or leaks (if applicable). Never use a

product with

loose/broken/damaged/missing parts,

wear, or leaks.



Products must be inspected and serviced

(if applicable) by a qualified technician

every 6 months. This is based on

average residential use by persons of

average size and strength, and on a

property of average metropolitan size.

Use beyond these recommendations may

require more frequent

inspections/servicing.



Ensure that all users of the product have

completed a suitable industry recognised

training course before being allowed

access to the product.



The product has been supplied by a general merchandise

retailer that may not be familiar with your specific

application or description of application. Be sure to attain

third-party approval from a qualified specialist for your

application before use, regardless of any assurances from

the retailer or its representatives.



This product is not intended for use where fail-safe

operation is required. As with any product (for example,

automobile, computer, toaster), there is the possibility of

technical issues that may require the repair or

replacement of parts, or the product itself. If the possibility

of such failure and the associated time it may take to

rectify could in any way inconvenience the user, business,

or employee, or financially affect the user, business, or

employee, then the product is not suitable for your

requirements. This product is not intended for use where

incorrect operation or a failure of any kind, including but

not limited to, a condition requiring product return,

replacement, parts replacement, or service by a

technician may cause financial loss, loss of employee

time or an inconvenience requiring compensation.



If this product has been purchased in error when

considering the information presented here, contact the

retailer directly for details of their returns policy, if

required.

ideas, diagrams, or images may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying, scanning, or recording, or any information storage and retrieval system,

without express permission or consent from the publisher.

BAUMR-AG PLTCLSBMPC3A Cordless Pole Saw Kit Telescopic Handle, 20V

Product's Documents

Product manual

Specifications

BAUMR-AG PLTCLSBMPC3A Questions and Answers
