WHEEL CLAMP WITH LOCK & KEY
MODEL NO: PB397.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Due to the variety in design of vehicles, it is the user’s full responsibility to ensure no damage occurs whilst using this
clamp. Correct attachment of clamp to a vehicle is therefore critical and is beyond control of the supplier.
WARNING! The user must secure the clamp properly.
8 DO NOT use the wheel clamp if any parts are missing or damaged as this may cause failure and/or personal injury.
WARNING! Avoid any protrusions beyond the side of the car as these may present a risk of injury to passers-by.
8 DO NOT use the clamp for any purpose other than for which it is designed.
9 Ensure that the clamp is removed before using the vehicle or trailer.
9 Ensure all nuts bolts and the locking bar are secure and tight before
leaving the vehicle or trailer unattended.
2. INTRODUCTION
Manufactured from quality steel with zinc plating for corrosion resistance. Simple and
quick ratchet action makes protection easy. Fully lockable and supplied with two keys.
Ideal for forecourt use. Finished in yellow for high visibility.
3. SPECIFICATION
Model No: ..........................PB397.V3
Maximum Clamp Diameter: ............. Ø640mm
Maximum Tyre Width:....................225mm
Minimum Clamp Diameter: ............. Ø450mm
4. ASSEMBLY
4.1. Insertclampsection‘A’(g.1)intothemainplateandsecurewithsuppliednutsandbolts.
4.2. Insertclampsection‘B’(g.2)intothemainplateandsecurewithsuppliednutsandbolts.
4.3. Turnthekeyinthelock‘C’fullyanti-clockwise,toenabletheinsertionofthelockingbar‘D’(g.3).
PB397.V3|Issue101/08/2019
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear protective
gloves
g.1 g.2 g.3
5. OPERATION
5.1. Takethewheelclampandplaceitoverthewheel,withthelockingplatefacingoutwards(g.4).
NOTE! Take care not to damage vehicle bodywork or wheels
5.2. Attachthelockingbar‘D’(g.5)tothelockingplate,holdthekeyfullyanti-clockwiseandpushitinuntilcontactismadewiththe
tyre,thiswillensureatightt.
5.3. Toremove,reverseprocedure4.1to4.3.
PB397.V3|Issue101/08/2019
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
ourtechnicalteamontechnical@sealey.co.ukor01284757505. Important: No Liability is accepted for incorrect use of this product.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
Partssupportisavailableforthisproduct.Pleaselogontowww.sealey.co.uk,emailsales@sealey.co.ukortelephone01284757500
g.4 g.5
