Revision History:
Rev. 1.0: Initial release. Rev. 1.1: Added mounting holes for IB8367A, IB8369A, IB8377, and IB8379
Rev. 1.2: Added IB9387, MS8391-EV, MS9390-HV, and IB9389 as the supported models.
VIVOTEK Mounting Accessories
AM-412 Corner mount
Installation Guide
Mechanical Drawings
II
Installation
III
Compatible VIVOTEK Cameras
I
AM-412
Corner mount bracket
170
315,25
45
4- 6
4- 7
86
102
86
102
56,29
48,75
3- 4,5
175
215,71
144,17
M8X20mm
SUS 302
Below is a general, sample procedure using a Corner mount bracket:
1. Combine the two metal pieces together using the M8 hex nuts and washers.
2. Align the assembled brackets with the desired position. Align screw holes on the brackets against the wall. Drill
holes on the wall for securing the bracket and for routing the cables. Hammer the anchors into the wall. Note
that these screws and wall anchors are user-supplied.
Corresponding ordering part numbers:
AM-412: 900034902G AM-719: 100184500G
AM-218: 100146100G
Compatible
accessories
Supported Cameras
AM-719 IB836BA-EHF3/EHT/HF3/HT, IB8382-EF3/ET/F3/T, IB9371-EHT/HT, IB9381-EHT/HT,
IB9365-EHT/HT, IB9367-EHT/HT/EH/H, IB8377-EHT/HT, IB9391-EHT, IB9387-EHT/
HT/EH/H, MS8391-EV.
AM-218 (via AM-719) Please refer to AM-218, AM-520, and AM-525 documents.
Directly attached Supported Cameras
* IB836BA-EHF3/EHT/HF3/HT, IB8382-EF3/ET/F3/T, IB9371-EHT/HT, IB9381-EHT/HT,
IB9365-EHT/HT, IB9367-EHT/HT/EH/H, IB8377-EHT/HT, IB9391-EHT, IB9387-EHT/
HT/EH/H, MS8391-EV, MS9390-HV
IB8367A, IB8369A, IB8377-H, IB8379-H, IB9389 series
* The directly-attached conīæguration is less recommended for the lack of waterproof and cabling
protection. If directly attached, you should properly wrap the rear-end cables and connectors with
waterproof protection such as putties.
Package Contents
Items 1. Corner mount bracket, 2. M6X20mm screws x4. 3. M5X20mm screws x4, 4. Hex L
wrench 5mm x1, 5. Hex L wrench 4mm x1, 6. M8 nut x2. 7. M4x15 screws x4
M6X20
X4
M4X15
X4
5mm X1
M5X20
X4
4mm X1
M8
X2
Bullet camera
AM-719
AM-412
AM-218
Dome camera
AM-520 / AM-525, etc.
AM-412
AM-719
AM-412
Applications
x8
3. The 4 screw holes in the center are used for directly mounting the IB series bullet cameras.
The 4 screw holes at the edges are used for mounting the AM-719 conduit box.
For M6 socket screws
- for IB series bullet cameras
directly attached
Also applies to MS9390 using
the M4 screws
For M5 socket screws
- for AM-719 conduit box
4. Secure the AM-719 conduit box to bracket using the M5 screws, washers, and hex heads. A hex crescent
wrench is required.
M5
5. For the rest of the installation procedure, refer to the documentation that came with the AM-719, AM-218, and
the other accessories.
Rev. 1.2
The 3 screw holes in the center are used for mounting
the IB8367A, IB8369A, IB8377-H, IB8379-H, and IB9389
bullet cameras.
For M4 screws
- for IB8367A, IB8369A
IB8377-H, IB8379-H,
and IB9389 series.
The 3/4" cable glands and conduts for protecting cables are user-supplied.
