MODEL 5011
22” GIDE HO
ASML ISRCIN
ILLUSTRATED PARTS LIST
1. Handle (1 pc)
Encargarse de
Se charger de
2. Griddle Hood (1 pc)
Capucha de plancha
Couverture de fer otte
3. M5 Screw (4 pcs)
Tornillo M5
Vis M5
4. Nut (4 pcs)
Nuez
Écrou
5. M6x12MM Screw (2 pcs)
Tornillo M6x12MM
Vis M6x12MM
ASSEMBLY INSTRUCTIONS
STEP 1.
Use two M6x12mm screws to attach the handle
to the griddle hood as illustrated.
Use dos tornillos M6x12mm para unir el mango a la
cubierta de la campana como se ilustra.
Utilisez deux vis M6x12mm pour xer la poignée sur
le couvercle du capot comme illustré.
Handle
Nut
Two(2)M6X12MM Screws
Four(4) M5 Screws
Cuatro (4) tornillos M5
Quatre (4) vis M5
Encargarse de
Se charger de
Dos (2) tornillos M6X12MM
Deux (2) vis M6X12MM
Nuez
Écrou
Seguidor
Supporter
STEP 2.
Remove the four(4) pre-installed M5 screws and nuts located on the back of the griddle unit.
Assemble the griddle hood on the griddle unit using the four(4) pre-existing M5 screws and
nuts as illustrated.
Retire los cuatro (4) tornillos M5 preinstalados y
las tuercas ubicadas en la parte posterior de la
unidad de la parrilla. Ensamble la campana de
la plancha en la unidad de la parrilla usando los
cuatro (4) tornillos y tuercas M5 preexistentes
como se ilustra.
Retirez les quatre (4) vis M5 préinstallées et les
écrous situés à l’arrière de l’unité de cuisson.
Assemblez le capot de la plaque de cuisson sur
l’unité de cuisson à l’aide des quatre (4) vis et
écrous M5 préexistants, comme illustré.
For questions regarding your BAKTN POUT, or if in need of replacement parts, you can call 435.252.3030 or send us an
email at [email protected].
