Mechanical
Scissor Jack
Operating Instructions & Parts Manual
Model Number Capacity
T-9456 3,000 lbs
Printed in China
T-9456-MO_012016
SFA Companies, Inc.
10939 N. Pomona Ave.
Kansas City, MO 64153
Phone 1-816-891-6390
90 DAYS LIMITED WARRANTY
For a period of ninety (90) days from date of purchase, SFA Companies will
repair or replace, at its option, without charge, any of its products which fails due to a
defect in material or workmanship, or which fails to conform to any implied warranty
not excluded hereby.
Performance of any obligation under this warranty may be obtained by
returning the warranted product, freight prepaid, to SFA Companies Warranty Service
Department, 10939 N. Pomona Ave., Kansas City, MO 64153.
Except where such limitations and exclusions are specically prohibited
by applicable law, (1) the CONSUMER’S SOLE AND EXCLUSIVE REMEDY
SHALL BE THE REPAIR OR REPLACEMENT OF DEFECTIVE PRODUCTS AS
DESCRIBED ABOVE, and (2) SFA Companies SHALL NOT BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGE OR LOSS WHATSOEVER, and (3)
THE DURATION OF ANY AND ALL EXPRESSED AND IMPLIED WARRANTIES,
INCLUDING WITHOUT LIMITATION, ANY WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED TO A PERIOD OF
NINETY (90) DAYS FROM DATE OF PURCHASE.
Some states do not allow limitations on how long an implied warranty lasts, so
the above limitation may not apply to you. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation or exclusion
may not apply to you. This warranty gives you specic legal rights, and you may also
have other rights which vary from state to state.
• Leer, comprender, y seguir las
instrucciónes antes de utilizar el
aparato.
• El manual de instrucciónes y la
información de seguridad deben estar
comunicado en lengua del operador
antes del uso.
• No seguir estas indicaciónes
puede causar daños personales o
materiales.
To avoid crushing and related injuries:
• NEVER work under a load supported
only by a jack.
• ALWAYS use a pair of adequately
rated jack stands.
ATENCIÓN
!
WARNING
!
Read, understand and follow all printed materials provided with/on this device
before using.
4
MAINTENANCE
Lubrication
Lubricate the thread and bearing with
wheel bearing grease. A periodic coating
of light lubricating oil to pivot points, axles
and hinges will help to prevent rust and
assure parts move freely.
Note: Never apply lubricant directly on
top of saddle.
Cleaning
Periodically check the jack for signs of
rust and corrosion.
Storage
When not in use, store the jack with
saddle fully lowered.
OPERATION
Lifting (refer to Fig 1,)
1. Place vehicle in park, with emergency
brake on and the wheel diagonally
opposite from the wheel being lifted
chocked in both directions.
2. Insert the handle into the hole of the
handle socket. Center the saddle
under lift point. Jack shall be positioned
perpendicular to the vehicle’s rolling
axis.
3. Hold the straight portion of the hooked
shaft with one hand while turning the
L-shaped handle clockwise.
4. Continue to crank it until you reach
the desired height, but never beyond
a point just high enough to remove and
install the tire.
Lowering
Turn the L-shaped handle
counter-clockwise to lower the vehicle.
