1. Place the
specimen directly
below the
objective lens.
3. Adjust the
Zoom knob
to the desired
level of
magnification
Magnification: 60x to 120x
Exit Pupil DIA: 10 mm to 14 mm
Optical Zoom: to 2X
Power: 1 AAA battery
(not included)
1. To avoid possible permanent eye damage, never look at the sun or
very bright objects through your Pocket Zoom Microscope
2. Remove the battery before storing the Pocket Zoom Microscope for
an extended period of time
3. Use under adult supervision
Illumination: LED (top)
Size: 1.45” x 1.0” x 3.5”
(37mm x 26mm x 88mm)
Weight: 1.0 oz./30 grams
2. Press the LED
on/off switch
4. Rotate the
Focus ring,
while looking
through the
eyepiece, until
the specimen is
in focus
USING YOUR MICROSCOPE
SPECIFICATIONS
WARNINGS
Focusing Ring
Objective Lens
LED
Model #: 44116
LED on/off
Battery Door
1. Loosen the
screw on the
battery door with
a screwdriver.
3. Install one AAA battery with
correct polarity
2. Slide the door open
4. Re-attached battery door
and tighten with the
screwdriver
© 2022 Celestron • All rights reserved. • celestron.com • 2835 Columbia Street • Torrance,
CA 90503 U.S.A. • Telephone: 1(800) 421-9649 • For ages 8 and up • Ver: 1.0 0922
INSTALL THE BATTERY
Eyepiece
Zoom Knob
