WDH804N8WA
user manual
Tumble Dryer
Electrolux. Thinking of you.
Westinghouse. We are part of the Electrolux family.
Share more of our thinking at www.electrolux.com
CONTENTS
Safety information 2
Conditions of Use 5
Safety instructions 5
Product Description 7
Control Panel 8
Program table 9
Options 11
Settings 12
Before first use 14
Daily use 15
Hints and tips 16
Care and cleaning 17
Troubleshooting 19
Technical Data 21
Warranty 22
Environmental concerns 24
Subject to change without notice.
SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible if an incorrect installation and use causes
injuries and damage. Always keep the instructions with the
appliance for future reference.
- Read the supplied instructions.
Warning: Risk of fire / Flammable materials.
The appliance contains flammable gas, propane (R290), a
gas with a high level of environmental compatibility. Keep fire
and ignition sources away from the appliance. Be careful not
to cause damage to the refrigerant circuit containing
propane.
Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
2 westinghouse
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
• Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
from the appliance unless continuously supervised.
• Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of it
appropriately.
• Keep detergents away from children.
• Keep children and pets away from the appliance when the
door is open.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
General Safety
• Do not change the specification of this appliance.
• The appliance can be installed as freestanding or below a
kitchen counter with correct space (refer to the Installation
leaflet).
• Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite side,
that would prevent the appliance door from being fully
open.
• The ventilation opening in the base must not be covered
by a carpet, mat, or any floor covering.
• WARNING: The appliance must not be supplied through
an external switching device, such as a timer, or
connected to a circuit that is regularly switched on and off
by a utility.
• Connect the mains plug to the mains socket only at the
end of the installation process. Make sure that the mains
plug is accessible after installation.
westinghouse 3
• Ensure good air ventilation in the room where the
appliance is installed to avoid the backflow of unwanted
gases into the room from appliances burning gas or other
fuels, including open fires.
• WARNING: Do not install the appliance in an environment
with no air exchange.
The appliance contains flammable gas, propane (R290), a
gas with a high level of environmental compatibility. Keep
fire and ignition sources away from the appliance. Be
careful not to cause damage to the refrigerant circuit
containing propane.
• WARNING: In the appliance enclosure or in the built -in
structure, keep ventilation opening clear of obstruction.
• WARNING: Do not damage the refrigerant circuit.
• If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service
Centre or similarly qualified persons to avoid an electrical
hazard.
• Do not exceed the maximum load of 8 kg (refer to the
"Programme chart" chapter).
• Do not use the appliance if items have been soiled with
industrial chemicals.
• Wipe away lint or packaging debris that has accumulated
around the appliance.
• Do not run the appliance without a filter. Clean the lint filter
before or after each use.
• Do not dry unwashed items in the tumble dryer.
• Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent
before being dried in the tumble dryer.
• Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in
the tumble dryer.
4 westinghouse
• Fabric softeners, or similar products, should only be used
as specified by the product manufacturer’s instructions.
• Oil-affected items can ignite spontaneously, especially
when exposed to heat sources such as in a tumble dryer.
The items become warm, causing an oxidation reaction in
the oil. Oxidation creates heat. If the heat cannot escape,
the items can become hot enough to catch fire. Piling,
stacking or storing oil-affected items can prevent heat from
escaping and create a fire hazard.
• If it is unavoidable that fabrics that contain vegetable or
cooking oil or have been contaminated by hair care
products be placed in a tumble dryer they should first be
washed in hot water with extra detergent -this will reduce,
but not eliminate, the hazard.
• Remove all objects from items that could be a source of
fire ignition such as lighters or matches.
• WARNING: Never stop a tumble dryer before the end of
the drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the socket.
CONDITIONS OF USE
This appliance is intended to be used in
household and similar applications such
as:
• farm houses;
• by clients in hotels, motels, bed &
breakfast and other residential type
environments;
• areas for communal use in blocks of
flats or in launderettes.
SAFETY INSTRUCTIONS
Installation
Warning: Risk of fire / Flammable
materials.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Do not install the appliance in an
environment with no air exchange
The appliance contains flammable gas,
propane (R290), a gas with a high level
of environmental compatibility. Keep
fire and ignition sources away from the
appliance. Be careful not to cause
westinghouse 5
damage to the refrigerant circuit
containing propane.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use the appliance
where the temperature can be lower
than 5°C or higher than 35°C.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Always keep the appliance vertical
when it is being moved.
• The rear surface of the appliance must
be put against a wall.
• When the appliance is in its permanent
position, check if it is levelled correctly
with the aid of a spirit level. If it is not,
adjust the feet accordingly.
Electrical connection
WARNING! Risk of fire and
electric shock.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
Use
WARNING! Risk of injury,
electric shock, fire, burns or
damage to the appliance.
Warning: Risk of fire / Flammable
materials. The appliance contains
flammable gas, propane (R290), a gas
with a high level of environmental
compatibility. Keep fire and ignition
sources away from the appliance. Be
careful not to cause damage to the
refrigerant circuit containing propane.
• This appliance is for household
(indoors) use only.
• Do not dry damaged (torn, frayed)
items that contain padding or fillings.
• If laundry has been washed with a stain
remover, carry out an additional rinse
cycle before starting a drying cycle.
• Dry only fabrics that are suitable to dry
in the appliance. Follow the cleaning
instruction on the item label.
• Do not drink or prepare food with the
condensed water/distilled water. It can
cause health problems to people and
pets.
• Do not sit or stand on the open door of
the appliance.
• Do not dry dripping wet clothes in the
appliance.
Internal lighting
WARNING! Risk of injury.
• Visible LED radiation, do not look
directly into the beam.
• To replace the internal lighting, contact
the Authorised Service Centre.
Care and cleaning
WARNING! Risk of injury or
damage to the appliance.
Warning: Risk of fire / Flammable
materials. The appliance contains
flammable gas, propane (R290), a gas
with a high level of environmental
compatibility. Keep fire and ignition
sources away from the appliance. Be
careful not to cause damage to the
refrigerant circuit containing propane.
6 westinghouse
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
• Be careful when you clean the
appliance to prevent damage to the
cooling system.
Compressor
WARNING! Risk of damage to
the appliance.
• The compressor and its system in the
tumble dryer is filled with a special
agent which is free from fluoro-chloro-
hydrocarbons. This system must stay
tight. The damage of the system can
cause a leakage.
Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
Disposal
WARNING! Risk of injury or
suffocation.
Warning: Risk of fire / Risk of
material damage and damage to the
appliance.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable close
to the appliance and dispose of it.
• The appliance contains flammable gas
(R290). Contact your municipal
authority for information on how to
discard the appliance correctly.
• Remove the door catch to prevent
children or pets from becoming trapped
in the drum.
• Dispose of the appliance in accordance
with local requirements for the disposal
of Waste Electrical and Electronic
Equipment (WEEE).
PRODUCT DESCRIPTION
1 2
6
3
4
5
7
8
9
10
1
Water container
2
Control panel
3
Internal light
4
Appliance door
5
Filter
6
Rating plate
7
Airflow slots
8
Heat Exchanger lid
9
Heat Exchanger cover
10
Adjustable feet
For ease of loading laundry or
ease of installation the door is
reversible. (see separate
leaflet).
westinghouse 7
CONTROL PANEL
1
89 7 6
3
5
4
2
1
Programme knob
2
Display
3
Time Dry touch button
4
Start/Pause touch button
5
Delay Start touch button
6
Extra Anticrease touch button
7
Reverse Plus touch button
8
Dryness Level touch button
9
On/Off button
Press the touch buttons with
your finger in the area with the
symbol or name of the option.
Do not wear gloves when you
operate the control panel.
Make sure that the control
panel is always clean and dry.
Display
Symbol on the display Symbol description
time drying option on
delay start option on
indicator:
check Heat Exchanger
8 westinghouse
Symbol on the display Symbol description
indicator:
clean filter
indicator:
drain the water container
indicator:
drying phase
indicator:
cooling phase
indicator:
anti-crease phase
child lock on
wrong selection
program duration
-
time Drying duration
-
delay start duration
PROGRAM TABLE
Program
Load
1)
Properties / Fabric type
2)
Favourite
Depends
on a
memo‐
rised pro‐
gram
You can do your configuration of program and op‐
tions and memorise in the appliance memory
(See chapter "
Settings - Favourite
").
Cotton 8 kg Cotton fabrics.
/
Mixed 3kg
Cotton and synthetic fabrics. Low
temperature program. Delicate pro‐
gram with warm air.
/
Bedding 3kg
Bed linen such as single and dou‐
ble sheets, pillowcases, duvet cov‐
er.
/
Synthetic 3,5 kg Synthetic and mixed fabrics.
/
Eco Cotton
3)
8 kg
Cycle to be used to dry cotton with
"cotton cupboard" dryness level,
with maximum energy saving.
/
westinghouse 9
Program
Load
1)
Properties / Fabric type
2)
Drying Rack
4)
1kg (or 1
pair of
sport
shoes)
For drying sport shoes only with Drying Rack (see
separate user manual provided with Drying Rack).
Denim 4 kg
Leisure clothing such as jeans,
sweat-shirts of different material
thicknesses (e.g. at the neck, cuffs
and seams).
/
Gym Wear 2 kg
Sportswear, thin and light fabrics,
microfiber, polyester.
/
Easy Iron
1 kg (or 5
shirts)
Easy care fabrics for which a mini‐
mum of ironing is necessary. The
drying results can be different from
one type of fabric to another.
Shake the items before putting
them in the appliance. When the
program has ended, immediately
remove the items and put them on
a hanger.
/
Shirts
1,5kg (or
7 shirts)/
Easy care fabrics for which a mini‐
mum of ironing is necessary. The
drying results can be different from
one type of fabric to the other.
Shake the items before you put
them in the appliance. When the
program is completed, Immediately
remove the items and put them on
a hanger.
/
Wool 1 kg
Woollen fabrics. Gentle drying for hand-washable
woollens. Remove items immediately when the
program is completed.
Delicates 4 kg
Delicate fabrics such as viscose,
rayon, acrylic, and their blends.
/
1)
The maximum weight refers to dry items.
2)
For fabric mark meaning see chapter HINTS AND TIPS: Preparing the laundry.
3)
Eco Cotton program is the reference program for Energy Label, tested according to AS/NZS2442.2.
4)
Only with the Drying Rack (standard accessory or optional, depending on model).
10 westinghouse
OPTIONS
Dryness Level
This function helps to increase dryness of
the laundry. There are 3 options:
• Extra Dry
• Cupboard Dry
• Iron Dry
Reverse Plus
Increase drum reversing frequency to
reduce items twisting and entanglement.
To increase uniformity of drying result and
help reduce creases. Recommended for
large or long items (e.g. sheets, trousers,
long dresses)"
Extra Anticrease
Extends the anti-crease phase by 60
minutes at the end of the drying cycle.
This function reduces creases. The
laundry can be removed during the anti-
crease phase.
Time Dry
You can set the program duration, from a
minimum of 10 minutes to a maximum of 2
hours. The required duration is related to
the quantity of laundry in the appliance.
We recommend that you set a
short duration for small
quantities of laundry or for only
one item.
TIME DRYING RECOMMENDATION
10 - 20 min
action of cool
air only (no
heater).
20 - 40 min
additional dry‐
ing to improve
dryness after
previous dry‐
ing cycle.
>40 min
full drying of
the small laun‐
dry loads up to
4 kg, well
spun (>1200
rpm).
Time Dry on Drying Rack
program
Option suitable for Drying Rack program .
You can set the program duration, from a
minimum of 10 minutes to a maximum of 2
hours. The setting of the duration is
related to the quantity of laundry in the
appliance.
We recommend that you set a short
duration for small quantities of laundry or
for only one item.
Options table
Program
1)
Dryness Level
Reverse
Plus
Extra Anti‐
crease
Time Dry
Favourite
Depends on a memorised program
Cotton ■ ■ ■ ■ ■ ■
Mixed ■ ■ ■
Bedding ■ ■
westinghouse 11
Program
1)
Dryness Level
Reverse
Plus
Extra Anti‐
crease
Time Dry
Synthetic ■ ■ ■ ■ ■ ■
Eco Cotton
■ ■
Drying Rack ■
Denim ■ ■ ■ ■
Gym Wear ■ ■
Easy Iron ■ ■
Shirts ■ ■
Wool ■
Delicates ■ ■
1)
Together with the program you can set 1 or more options. To activate or deactivate them, press the related
touch button.
SETTINGS
A B C
E
DF
A. Time Dry touch button
B. Start/Pause touch button
C. Delay Start touch button
D. Extra Anticrease touch button
E. Reverse Plus touch button
F. Dryness Level touch button
Child lock function
This option prevents children playing with
the appliance while a program is
operating. The touch buttons are locked.
Only the on/off button is unlocked.
Activating the child lock option:
1. Press the on/off button to activate the
appliance.
2. Press and hold touch button (D) for a
few seconds.
The child lock indicator comes on.
It is possible to deactivate the
child lock option while a
program operates. Press and
hold the same touch buttons
until the child lock indicator
goes off. The Child Lock
function isn't available for 8 s
after switching on the
appliance.
Favourite
You can do your configuration of program
and options and memorise in the
appliance memory.
To memorise your
configuration:
1. Press the on/off button to activate the
appliance
2. Set the program and available options.
3. Press the (E) button for some
seconds.
12 westinghouse
The sound and the message on the
display confirm that the configuration is
memorised.
To activate your memorised
configuration:
1. Press the on/off button to activate the
appliance.
2. Use the program knob to set Favourite
position.
Previously memorised configuration of
program and options will be restore.
Adjustment of remaining
laundry moisture
The appliance allows you to chose
between 3 levels corresponding to
different ranges of water hardness.
Dryness
level
ppm
the results from
the included
water hardness
kit.
< 150 C01-C03
150 -
300
C04-C05
> 300 C06-C07
Depending on the country, the water
hardness is expressed in equivalent
scales: e.g. French degrees (°f), German
degrees (°d), English degrees (°e), mmol/l
and ppm
If necessary, please contact your local
water authority to check the water
hardness in your area.
Every time you enter in the
"Adjustment of remaining
laundry moisture" mode,
previously set degree of
remaining moisture will change
into next value ( e.g previously
set will change into
).
To change the default degree of remaining
moisture:
1. Press the on/off button to activate the
appliance.
2. Use the program knob to set any
program.
3. Wait approximately 8 seconds.
4. Press and hold buttons (E) and (D) at
the same time.
One of these indicators comes on:
• the maximum dryness
• the more dry laundry
• the standard dry laundry
5. Press and hold buttons (E) and (D)
again until the indicator of the correct
level comes on.
If the display returns to the
normal mode (the time of
the selected program from
step 2. will be displayed),
while setting the degree of
remaining moisture, press
and hold buttons (E) and
(D) once again to enter to
the "Adjustment of
remaining laundry moisture"
mode (previously set
degree of remaining
moisture will change into
next value).
6. After 5 s the display returns to normal
mode.
Water container indicator
By default, the water container indicator is
on. It comes on when the program is
completed or when it is necessary to
empty the water container.
If a draining kit is installed
(additional accessory), the
appliance automatically drains
the water from the water
container. In this case we
recommend that you deactivate
the indicator of the water
container.
westinghouse 13
Deactivating the water container
indicator:
1. Press the on/off button to activate the
appliance.
2. Wait approximately 8 seconds.
3. Press and hold touch buttons (A) and
(C) at the same time.
The display shows one of these 2
configurations:
• The display shows "Off". After 5 s
the display returns to normal mode.
• The display shows "On". After 5 s
the display returns to normal mode.
Buzzer on/off
To deactivate or activate the acoustic
signals, press and hold for approximately
2 seconds touch buttons (E) and (F) at the
same time.
BEFORE FIRST USE
Rear drum locks are removed
automatically when dryer is
activated for the first time.
Possible to hear some noise.
It is highly recommended to
start any program for the
first time without the load for
a few seconds to ensure that
the rear drum locks are
removed properly.
To unlock the rear drum locks:
1. Switch on the appliance.
2. Set any program.
3. Press the Start/Pause button.
Drum starts to rotate. Rear drum locks are
automatically deactivated.
If the drum still does not rotate,
please release the rear drum
locks manually (to do that,
please use provided key).
A
B
A
B
Before you use the appliance to dry
items:
• Clean the tumble dryer drum with a
moist cloth.
• Start a 1 hour program with moist
laundry.
At the beginning of the drying
cycle (first 3-5 min) there could
be a slightly higher sound level.
This is due to the compressor
starting up. This is normal for
compressor powered
appliances such as
refrigerators and freezers.
14 westinghouse
DAILY USE
Start a program without delay
start
1. Prepare the laundry and load the
appliance.
CAUTION! Make sure that
when you close the door,
the laundry does not get
caught between the
appliance door and the
rubber seal.
2. Press the on/off button to activate the
appliance.
3. Set the correct program and options
for the type of load.
The display shows the program duration.
Real drying time will depend on
type of the load (quantity and
composition), the room
temperature and the humidity
of your laundry after spin drying
phase.
4. Press the Start/Pause touch button.
The program starts.
Starting the program with delay
start
1. Set the correct program and options
for the type of load.
2. Press the delay start button again and
again until the display shows the delay
time you want to set.
You can delay the start of a
program from a minimum of
30 minutes to a maximum
of 20 hours.
3. Press the Start/Pause touch button.
The display shows the countdown of the
delay start.
When the countdown is completed, the
program starts.
Change a program
1. Press the on/off button to deactivate
appliance
2. Press the on/off button to activate the
appliance.
3. Set the program.
At the end of the program
When the program is completed:
• An intermittent acoustic signal
operates.
• The display shows
• The indicator is on.
• The indicators
Filter and Tank
may come on.
• The Start/Pause indicator is on.
The appliance continues to operate with
the anti-crease phase for approximately
30 minutes or more if Extra Anticrease
option was set (see chapter
Option - Extra
Anticrease
).
The anti-crease phase reduces creasing.
You can remove the laundry before the
anti-crease phase is completed. We
recommend, for better results, that you
remove the laundry when the phase is
almost completed.
When the anti-crease phase is completed:
• The display still shows
• The indicator is off.
• The indicators Filter and Tank
remain on.
• Start/Pause indicator goes off.
1. Press the on/off button to deactivate
the appliance.
2. Open the appliance door.
3. Remove the laundry.
4. Close the appliance door.
westinghouse 15
Possible causes of unsatisfactory drying
results:
• Inadequate default dryness level
settings. See chapter
Adjustment of
default dryness level
• Room temperature is too low or too
high. Optimal room temperature is
between 18°-25°C.
Always clean the filter and
empty the water container
when a program is
completed.
Stand-by function
To reduce energy consumption, this
function automatically deactivates the
appliance:
• After 5 minutes if you do not start the
program.
• After 5 minutes from the end of the
program.
HINTS AND TIPS
Preparing the laundry
Very often the clothes after
washing cycle are kneaded and
tangled altogether.
Drying kneaded and tangled
clothes is inefficient.
To assure proper air flow and
even drying it is recommended
to shake and load one by one
the clothes to the tumble dryer.
To assure proper drying process:
• Close the zips.
• Close the fasteners of duvet covers.
• Do not dry ties or ribbons loose (e.g.
apron ribbons). Tie them before you
start a program.
• Remove all items from pockets.
• Turn items with the internal layer made
of cotton inside out. Cotton layer must
be faced outwards.
• Always set the program suitable for the
type of laundry.
• Do not put light and dark colours
together.
• Use suitable program for cottons,
jersey and knitwear to reduce
shrinkage.
• Do not exceed the maximum load
stated in the programs chapter or
shown on the display.
• Dry only the laundry that is suitable for
tumble drying. Refer to the fabric label
on the items.
• Do not dry large and small items
together. Small items can be trapped
inside the large items and remain wet.
• Shake the large clothes, fabrics before
placing in the tumble dryer. It is to
avoid moist places inside the fabric
after the drying cycle.
Fabric label Description
Laundry is suitable for tumble drying.
Laundry is suitable for tumble drying at higher temperatures.
Laundry is suitable for tumble drying at low temperatures only.
Laundry is not suitable for tumble drying.
16 westinghouse
CARE AND CLEANING
Cleaning the filter
CAUTION! Avoid the use of
water to clean the filter. Instead
throw away lint in the dustbin
( avoid dispersion of plastic
fiber in water ambient).
To achieve the best drying
performances clean the filter
regularly , clogged filter lead to
longer cycles and energy
consumption increase.
Use your hand to clean the
filter , and if necessary , a
vacuum cleaner .
1. 2.
1
2
3.
1
2
4.
5.
1)
6.
2
1
1)
If necessary remove fluff from the filter socket and gasket. You can use a vacuum cleaner.
Emptying the water container
1. 2.
westinghouse 17
3. 4.
You can use the water from the
water container as an
alternative to distilled water
(e.g. for steam ironing). Before
you use the water, remove dirt
residues with a filter.
Cleaning the Heat Exchanger
1. 2.
1
2
3. 4.
11
22
5. 6.
18 westinghouse
7. 8.
9.
2
1
CAUTION! Do not touch the
metal surface with bare hands.
Risk of injury. Wear protective
gloves. Clean carefully to avoid
damaging the metal surface.
Cleaning the drum
WARNING! Disconnect the
appliance before you clean it.
Use a standard neutral soap detergent to
clean the inner surface of the drum and
drum lifters. Dry the cleaned surfaces with
a soft cloth.
CAUTION! Do not use
abrasive materials or steel wool
to clean the drum.
Cleaning the control panel and
housing
Use a standard neutral soap detergent to
clean the control panel and housing.
Use a moist cloth to clean. Dry the
cleaned surfaces with a soft cloth.
CAUTION! Do not use furniture
cleaning agents or cleaning
agents which can cause
corrosion.
Cleaning the airflow slots
Use a vacuum cleaner to remove fluff from
the airflow slots.
TROUBLESHOOTING
WARNING! Refer to Safety
chapters.
Error Codes
The appliance does not start or it stops during operation.
First try to find a solution to the problem (refer to the table). If the problem persists,
contact the Authorised Service Centre.
westinghouse 19
WARNING! Deactivate the appliance before carrying out any check.
In case of major problems, the acoustic signals operate, the display shows an
error code and the Start/Pause button may flash continuously:
Error code Possible cause Remedy
E5A
Appliance motor overloaded.
Too much laundry or entrap in the
drum.
The program was not completed.
Remove the laundry from the
drum, set the program and restart
the cycle.
E97
Internal fail. No communication be‐
tween electronic elements of the
appliance.
The program was not finished
properly or the appliance stoped
too early. Switch the appliance off
and on again.
If the error code appears again,
contact the Authorised Service
Centre.
EH0
The mains supply is unstable. When the appliance is showing
EH0, please wait until main supply
is stable than press start. If the ap‐
pliance pause the cycle without
any indication then press the cycle
start. If the warning will occur
check the power cord / socket in‐
tegrity or main supply.
If the display shows other error codes, deactivate and activate the appliance. If the
problem continues, contact the Authorised Service Centre.
In case of different problem with the tumble dryer check the table below for possible
solutions.
Troubleshooting
Problem Possible solution
You cannot activate the appliance. Make sure that the mains plug is connected
to the mains socket.
Check fuse in fuse box (domestic installa‐
tion).
The drum does not rotate. Release the rear drum locks manually (see
chapter
Before First Use
).
The program does not start. Press Start/Pause.
Make sure that the appliance door is closed.
20 westinghouse
Problem Possible solution
The appliance door does not close. Make sure that the installation of the filter is
correct.
Make sure that the laundry is not caught be‐
tween the appliance door and the rubber
seal.
The appliance stops during operation. Make sure that the water container is empty.
Press Start/Pause to start the program again.
Load is too small, increase the load or use
the Time Drying program.
The cycle time is too long or unsatisfactory
drying result.
1)
Make sure that the weight of the laundry is
suitable for the duration of the program.
Make sure that the filter is clean.
The laundry is too wet. Spin the laundry in
the washing machine again.
Ensure that the room temperature is higher
than +5°C and lower than +35°C. Optimal
room temperature is 18°C to 25°C.
Set the Time Drying or the Extra Dry pro‐
gram.
2)
The display shows .
If you want to set a new program, deactivate
and activate the appliance.
Make sure that the options are suitable for
the program.
1)
After maximum 5 hours, the program ends automatically.
2)
It can happen that some area remains humid when drying big items (e.g. bed sheets ).
If the drying results are not
satisfactory
• The set program was incorrect.
• The filter is clogged.
• The Heat Exchanger is clogged.
• There was too much laundry in the
appliance.
• The drum is dirty.
• Incorrect setting of the conductivity
sensor ( See chapter "
Settings -
Adjustment of the remaining laundry
moisture degree
" for better setting).
• The airflow slots are clogged.
• Room temperature is too low or too
high ( optimal room temperature 18°C
to 25°C )
TECHNICAL DATA
Height x Width x Depth 850 x 596 x 638 mm (maximum 662 mm)
westinghouse 21
Max. depth with the appliance door open 1107 mm
Max. width with the appliance door open 958 mm
Adjustable height 850 mm (+ 15 mm - feet adjustment)
Drum volume 118 l
Maximum load 8 kg
Voltage 230-240 V
Frequency 50 Hz
Total power 800 W
Type of use Household
Permitted ambient temperature + 5°C to + 35°C
Level of protection against ingress of solid
particles and moisture ensured by the protec‐
tive cover, except where the low voltage
equipment has no protection against mois‐
ture
IPX4
Gas designation R290
Weight 0,140 kg
WARRANTY
FOR SALES IN AUSTRALIA AND NEW
ZEALAND
APPLIANCE: WESTINGHOUSE DRYER
This document sets out the terms and
conditions of the product warranties
for Westinghouse Appliances. It is an
important document. Please keep it
with your proof of purchase documents
in a safe place for future reference
should there be a manufacturing defect
in your Appliance. This warranty is in
addition to other rights you may have
under the Australian Consumer Law.
1. In this warranty:
a) ‘ACL’ or ‘Australian Consumer
Law’ means Schedule 2 to the
Competition and Consumer Act
2010;
b) ‘Appliance’ means any Electrolux
product purchased by you and
accompanied by this document;
c) ‘ASC’ means Electrolux authorised
service centres;
d) 'Westinghouse' is the brand
controlled Electrolux Home
Products Pty Ltd of 163 O'Riordan
Street, Mascot NSW 2020, ABN 51
004 762 341 in respect of
Appliances purchased in Australia
and Electrolux (NZ) Limited
(collectively "Electrolux") of 3-5
Niall Burgess Road, Mount
Wellington, in respect of
Appliances purchased in New
Zealand;
e) ‘Warranty Period’ means the
period specified in clause 3 of this
warranty;
f) ‘you’ means the purchaser of the
Appliance not having purchased
the Appliance for re-sale, and
‘your’ has a corresponding
meaning.
22 westinghouse
2. Application: This warranty only
applies to new Appliances, purchased
and used in Australia or New Zealand
and is in addition to (and does not
exclude, restrict, or modify in any way)
other rights and remedies under a law
to which the Appliances or services
relate, including any nonexcludable
statutory guarantees in Australia and
New Zealand.
3. Warranty Period: Subject to these
terms and conditions, this warranty
continues for in Australia for a period
of 24 months and in New Zealand for a
period of 24 months, following the date
of original purchase of the Appliance.
4. Repair or replace warranty: During
the Warranty Period, Electrolux or its
ASC will, at no extra charge if your
Appliance is readily accessible for
service, without special equipment and
subject to these terms and conditions,
repair or replace any parts which it
considers to be defective. Electrolux
may, in its absolute discretion, choose
whether the remedy offered for a valid
warranty claim is repair or
replacement. Electrolux or its ASC
may use refurbished parts to repair
your Appliance. You agree that any
replaced Appliances or parts become
the property of Electrolux.
5. Travel and transportation costs:
Subject to clause 7, Electrolux will
bear the reasonable cost of
transportation, travel and delivery of
the Appliance to and from Electrolux or
its ASC. Travel and transportation will
be arranged by Electrolux as part of
any valid warranty claim.
6. Proof of purchase is required before
you can make a claim under this
warranty.
7. Exclusions: You may not make a
claim under this warranty unless the
defect claimed is due to faulty or
defective parts or workmanship. This
warranty does not cover:
a) light globes, batteries, filters or
similar perishable parts;
b) parts and Appliances not supplied
by Electrolux;
c) cosmetic damage which does not
affect the operation of the
Appliance;
d) damage to the Appliance caused
by:
1. negligence or accident;
2. misuse or abuse, including
failure to properly maintain or
service;
3. improper, negligent or faulty
servicing or repair works done
by anyone other than an
Electrolux authorised repairer
or ASC;
4. normal wear and tear;
5. power surges, electrical storm
damage or incorrect power
supply;
6. incomplete or improper
installation;
7. incorrect, improper or
inappropriate operation;
8. insect or vermin infestation;
9. failure to comply with any
additional instructions supplied
with the Appliance;
In addition, Electrolux is not liable
under this warranty if:
a. the Appliance has been, or
Electrolux reasonably believes that
the Appliance has been, used for
purposes other than those for
which the Appliance was intended,
including where the Appliance has
been used for any non-domestic
purpose;
b. the Appliance is modified without
authority from Electrolux in writing;
c. the Appliance’s serial number or
warranty seal has been removed
or defaced
8. How to claim under this warranty:
To enquire about claiming under this
warranty, please follow these steps:
a. carefully check the operating
instructions, user manual and the
terms of this warranty;
b. have the model and serial number
of the Appliance available;
westinghouse 23
c. have the proof of purchase (e.g. an
invoice) available;
d. telephone the numbers shown
below.
9. Australia: For Appliances and
services provided by Electrolux in
Australia: Electrolux goods come with
guarantees that cannot be excluded
under the Australian Consumer Law.
You are entitled to a replacement or
refund for a major failure and for
compensation for any other reasonably
foreseeable loss or damage. You are
also entitled to have the Appliance
repaired or replaced if the Appliance
fails to be of acceptable quality and the
failure does not amount to a major
failure. ‘Acceptable quality’ and ‘major
failure’ have the same meaning as
referred to in the ACL.
10. New Zealand: For Appliances and
services provided by Electrolux in New
Zealand, the Appliances come with a
guarantee by Electrolux pursuant to
the provisions of the Consumer
Guarantees Act, the Sale of Goods Act
and the Fair Trading Act. Where the
Appliance was purchased in New
Zealand for commercial purposes the
Consumer Guarantee Act does not
apply.
11. Confidentiality: You accept that if you
make a warranty claim, Electrolux and
its agents including ASC may
exchange information in relation to you
to enable Electrolux to meet its
obligations under this warranty.
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been fol‐
lowed.
AUSTRALIA
FOR SERVICE
or to find the address of your nearest author‐
ised service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call
FOR SPARE PARTS
or to find the address of your nearest spare
parts centre in Australia
PLEASE CALL13 13 50
For the cost of a local call
NEW ZEALAND
FOR SERVICE
or to find the address of your nearest author‐
ised service centre in New Zealand
PLEASE CALL 0800 10 66 10
FOR SPARE PARTS
or to find the address of your nearest state
spare parts centre in New Zealand
PLEASE CALL 0800 10 66 20
WDryer_Warr_Apr20
ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put
the packaging in relevant containers to
recycle it. Help protect the environment
and human health by recycling waste of
electrical and electronic appliances. Do
not dispose of appliances marked with the
symbol with the household waste.
Return the product to your local recycling
facility or contact your municipal office.
24 westinghouse
*
www.westinghouse.com.au
136987350-A-072022
