PACKAGE CONTENTS
• Wireless adapter
• USB to USB-C cable
• 3.5 mm audio cable
• Soft pouch
• Quick Setup Guide
FEATURES
• Receives or transmits Bluetooth signals to add connectivity to many devices,
including listening through two headphones simultaneously
• LEVEL mode optimizes audio performance
• Two ports let you charge the device using a USB-C or Lightning cable (not
included)
• Up to 16 hours (transmitter mode) or up to 13 hours (receiver mode) of battery
life keeps your device working longer.
OVERVIEW
Front Back
CHARGING YOUR ADAPTER
• Plug the included USB to USB-C cable or a Lightning cable (not included) into
your wall charger. Plug the other end of the cable into the USB-C or Lightning
port on your adapter.
Notes:
• Do not use the USB-C and Lightning ports
on your adapter at the same time.
• You can use a USB-C to USB-C cable (not
included) to charge your adapter if the
power draw is less than 100W.
• When the battery is charging, the red LED
lights solid.
• When the battery is fully charged, the red
LED turns o.
TRANSMITTER MODE
In transmitter mode, you can connect your adapter to a media source, and play the audio on your earbuds or headset via Bluetooth.
Setting up your wireless adapter (TX mode)
1 Switch to TX (transmit) mode by moving the mode switch to TX.
2 Connect one end of the included audio cable to the 3.5 mm jack on your adapter.
3 Connect the other end to an audio output on your media source.
Connect to the rst headset or music receiver
1 Put your Bluetooth headphone or Bluetooth music receiver in pairing mode. Consult the documentation for those devices for more information.
2 Press and hold the MFB button for three seconds to turn on the adapter and enter pairing mode.
3 When your adapter and devices are connected, the blue LED blinks once every ve seconds.
Connect to the second headset or music receiver
1 Put your second Bluetooth headphones or music receiver into pairing mode. Consult the documentation for those devices for more information.
2 Press the MFB button twice to pair with a second device. The blue LED blinks quickly for two minutes while pairing.
3 After both devices have connected to your adapter, the blue LED blinks twice every ve seconds. Audio will be played to both devices simultaneously.
USING YOUR WIRELESS ADAPTER (TX MODE)
• Press and hold the MFB button for one and a half seconds to turn the adapter on. The LED blinks red and blue once. The adapter automatically connects to
the last device it was paired with. After connecting, the blue LED blinks once every ve seconds.
Note When you turn the adapter on for the rst time, it will enter pairing mode automatically. The LED will blink red and blue.
Optimizing volume and sound quality (TX mode)
• When you connect your earbuds with your adapter and the audio is too low, too loud, or overdriven (causing clipping distortion),
you can slide the level switch to optimize the volume.
Understanding LED indicators (TX mode)
Before using your new product, read these instructions to prevent any damage.
QUICK SETUP GUIDE
Bluetooth Wireless
Transmitter and
Receiver
NS-HPBTAA23
(Long cable not included)
TX mode
3.5 mm audio cable
(included)
Media source
TV
*For the best performance, do not place behind your TV
Headset
2nd paired
L
R
Earbuds
1st paired
This adapter can be congured as TX (transmitter) or RX (receiver). To change between these modes, slide the mode switch to the correct mode.
RESETTING YOUR WIRELESS ADAPTER
• To reset and clear all saved devices, switch to TX mode by pressing and holding the
MFB button for seven seconds while the adapter is o. The red LED blinks slowly
ve times and the devices are cleared. The adapter will enter pairing mode.
TROUBLESHOOTING
No power.
• Make sure that your adapter power cable is connected to your adapter and a power
outlet.
• Make sure that your adapter is turned on.
No sound or low volume
TX mode:
• Shorten the distance between your devices and adapter.
• Make sure that all connections are secure.
• Turn up the volume on your media source.
• Make sure that your earbuds or headset has a Bluetooth connection with your
adapter.
RX mode:
• Shorten the distance between your devices and adapter.
• Make sure that all connections are secure.
• Turn up the volume on your media source.
• Make sure that your media source has a Bluetooth connection with your adapter.
Cannot establish a Bluetooth connection.
• Shorten the distance between your adapter and your Bluetooth device.
• Make sure that you have selected Insignia NS-HPBTAA23 on your Bluetooth
device.
• Turn your devices o, then on. Re-pair your adapter and your Bluetooth device.
• Make sure that your adapter is not paired to another Bluetooth device.
• Make sure that your adapter and Bluetooth device are both in pairing mode.
• Make sure that your Bluetooth device is not connected to any other device.
My adapter does not appear on my Bluetooth device.
• Shorten the distance between your adapter and your Bluetooth device.
• Put your adapter into pairing mode, then refresh your list of Bluetooth devices. For
more information, see the documentation that came with your Bluetooth device.
SAFETY WARNINGS
• The adapter requires full connection and both hands to install.
• The adapter has Lithium – Polymer batteries. Please do not open the unit to prevent
unwanted short circuit happening.
• Do not use the adapter near water (for example, a bath tub, wash bowl, kitchen sink,
laundry tub, wet basement, swimming pool, or other areas located near water).
• Clean with a dry cloth.
• Power o the adapter before cleaning.
• Install the adapter far away from heat sources.
• Use only the attached accessories.
• Power o the adapter when unused for long time.
Mode switch
Level switch
3.5 mm stereo
MFB button
OR
USB to USB-C cable
(included)
Lightning cable
(not included)
INDICATOR
Red and blue LEDs blink alternatively for 1 second
Blue and red LEDS blink alternatively for 1 second
Red and blue LEDs blinking
Blue LED blinks once every 5 seconds
DESCRIPTION
Adapter is turned on
Adapter is turned o
Searching for Bluetooth device
One Bluetooth device is connected
INDICATOR
Blue LED blinks twice every 5 seconds
Red LED blinks slowly 5 times
Blue LED blinks quickly
Blue LED blinks slowly
DESCRIPTION
Two Bluetooth devices are connected
Saved devices cleared
Searching for second Bluetooth device
Disconnected from Bluetooth device
Note: Due to Bluetooth limitations, expect
delays between video and audio signals.
USB-C
charging port
Lightning
charging port
LED
OR
