Before using the appliance, always read the safety warnings.
This appliance shall not be used by children.
Keep the appliance and its cord out of reach
of children.
1. DESCRIPTION
1.1 Description of the appliance
(page 3 - A )
A1. Beans container lid
A2. Beans container
A3. Cup tray
A4. Steam dial
A5. Hot water spout
A6. Steam spout
A7. Cappuccino maker selection ring
A8. Cappuccino maker
A9. Cappuccino maker connection nozzle
A10. Cup grille for espresso
A11. Cup grille for glasses or mugs
A12. Drip tray grille
A13. Drip tray
A14. Drip tray water level indicator
A15. Water tank lid
A16. Water tank extraction handle
A17. Water tank
A18. Water softener lter housing
A19. Power cord connector socket
A20. Main switch (ON/OFF)
A21. Boiler outlet
A22. Coee mill outlet (tamping station)
A23. Presser lever
1.2 Description of control panel
(page 3 - B )
B1. ON/Standby button
B2. Ground coee quantity dial
B3. "X2" button: to use the 2 coees Easy Clean lter
B4. Rinse button
B5. "OK" button: to deliver the beverage/conrm
B6. Hot water button
B7. "My" button: to customise beverage quantity
B8. Mode selector dial:
• Espresso
• Americano
• Coee
• Descaling
B9. Descale light
B10. Steam ready light
B11. Overtemperature light
B12. Energy saving light
B13. General alarm light
B14. Beans container empty/No beans container light
B15. No water light
B16. Pressing light
B17. Pressure gauge
1.3 Description of the accessories
(page 2 - C )
C1. Filter holder
C2. Easy Clean lter 1 coee
C3. Easy Clean lter 2 coee
C4. "Total Hardness Test" indicator paper
C5. Descaler
C6. Water softener lter (*if present)
C7. Power cord
C8. Tube brush
C9. Milk jug
2. PREPARING THE APPLIANCE
Wash all accessories with warm water and washing-up liquid,
then proceed as follows:
1. Insert the beans container (A2) in the coee mill (g. 1).
The container is correctly inserted when the arrow is lined
up with the symbol and you hear a “click”;
2. Insert the drip tray (A13) complete with cup grill (A11) and
drip tray grille (A12) (g. 2);
3. Extract the water tank (A17) (g. 3) and ll with fresh clean
water, taking care not to exceed the MAX level (g. 4).
4. Put the tank back in the appliance.
Important: Never operate the appliance without water in the tank or without the
tank.
Please note: You should customise water hardness as soon as possible following the
instructions in section "12.2 Water hardness".
3. SETTING UP THE APPLIANCE
1. Plug the power cord connector (C7) into the socket (A19) at
the back of the appliance (g. 5), then plug the plug into
the mains socket. Make sure the main switch (A20) at the
back of the appliance is pressed and in the I position (g.
6);
2. The light corresponding to the button (B6) comes on to
indicate that you need to deliver water to ll the circuit (g. 7);
3. Place a container with a minimum capacity of 100 ml under
the hot water spout (A5) and cappuccino maker (A8) (g.
8);
4. Press the button (B6) corresponding to the light (g.
9). Delivery begins and stops automatically. Empty the
container.
Before using the machine, you must rinse the internal circuits.
Proceed as follows:
23
5. Attach the lter holder (C1) complete with lter to the appli-
ance. To attach correctly, align the lter holder handle with
"INSERT" (g. 10), then turn the handle to the right until it is
aligned in the "CLOSE" position;
6. Place a recipient under the lter holder and cappuccino
maker (A8) (g. 11);
7. Press the button (B4) corresponding to the light. De-
livery begins (g. 12);
8. When delivery is complete, turn the steam dial (A4) (g.
13) and deliver steam for 10 seconds to rinse the steam
circuit;
9. Repeat points 7 and 8 until you have delivered at least 1
litre of water (about half the tank);
10. Extract the water tank (A17) (g. 3), rinse and ll with fresh
clean water, taking care not to exceed the MAX level (g. 4).
The appliance is ready for use.
Please note: We also recommend rinsing the internal circuits if the appliance is
not used for a long period.
The rst time you use the appliance, you need to make 4-5 cups
of coee before the appliance starts to give satisfactory results.
Pay particular attention to the quantity of pre-ground coee in
the lter ((C2) or (C3)) (see instructions in section "4.5 Adjusting
the quantity of ground coee in the lter").
Proceed as described in section "4. Prepare the perfect dose".
4. PREPARE THE PERFECT DOSE
4.1 Preparing the coee mill
1. Make sure the beans container is correctly inserted and
lined up to position "3" (g. 14) (default setting) ;
2. Remove the beans container lid (A1);
3. Place the required quantity of coee beans in the container
(g. 15);
4. Close the lid, pressing rmly.
5. The rst time you use the appliance, make sure the dial (B2)
is in the position (default setting).
4.2 Select the grinding level
The grinding level aects delivery speed and therefore the qual-
ity of the extract.
The rst time you use the appliance, we recommend using the
factory setting (medium grinding) (g. 14), then if you are not
satised with the result, adjust the level according to your per-
sonal taste and the type of coee by setting a ner or coarser
grinding level, referring to the tips in section "4.5 Adjusting the
quantity of ground coee in the lter".
Important:
• Always adjust the coee mill while in operation.
• Adjust one grinding level at a time and make at least 5 coees
before adjusting again.
• Do not remove the beans container while it contains beans.
4.3 The coee lters
The appliance is provided with two coee lters.
The 1 coee lter (C2) has the symbol marked on the
bottom.
The 2 coee lter (C3) has the symbol marked on the
bottom.
For the correct quantity of coee, the ideal level of pressed coee
is marked inside the lters (g. 16). If the quantity is above or
below the level indicated, the result may not be satisfactory. The
next times you use the coee mill, you can adjust the grinding
level using the dial (B2) (see section "4.5 Adjusting the quantity
of ground coee in the lter").
4.4 Grind the coee directly into the lter
1. Place the ground coee lter (C2) or (C3) in the lter holder
(C1) (g. 17);
2. Press the "X2" button if you are using the 2 coee lter;
3. Attach the lter holder to the outlet of the coee mill
(A22), aligning it with "INSERT", then turning it to the right
(g. 18). Grinding begins when the lter holder reaches the
CLOSE position and stops automatically;
Important: while the appliance is grinding coee, you can per-
form a rinse, or produce hot water or steam at the same time.
4. Once grinding is complete, the light (B16) ashes. Pull
the presser lever (A23) as far as it will go. The force exerted
on the coee is indicated on the lever itself ( )
(g. 19).
5. Remove the lter holder by turning it towards the left.
Important: to adjust the correct quantity ground automatically into the lter hold-
er, see section "4.5 Adjusting the quantity of ground coee in the lter".
If you remove the lter holder from the outlet of the coee mill
without pressing the coee, the light (B16) ashes. To
press, turn the dial (B2) to the position to disable the coee
mill, re-attach the lter holder and pull the lever (A23).
4.5 Adjusting the quantity of ground coee in
the lter
Important: The rst time you use the coee mill, leave the dial
in the position (min). It is normal for you to have to grind the
coee a number of times before nding the correct adjustment for
the right amount of coee.
24
Perfect dose Too much coee Too little coee
After grinding coee for the rst time, turn the dial (B2) gradu-
ally, starting from the “min” position (see following gure)
until you reach the correct quantity, depending on the type of
coee. The ideal position is within the sector shown in grey in
the following gure.
By adjusting this dial, you can adapt the mill to any type of coee
and to wear of the burrs over time.
5. COFFEE DELIVERY
5.1 Beverage selection
1. Turn the mode selector dial (B8) to select the desired coee
(see section "5.4 Coee beverages").
2. If you use the 2 cup lter (C3), press the "2X" button (B3).
5.2 Delivering the coee
1. Attach the lter holder (C1) to the appliance. To attach cor-
rectly, align the lter holder handle with "INSERT" (g. 10),
then turn the handle to the right until it is aligned in the
"CLOSE" position;
2. Place the cup or cups under the lter holder spouts;
3. If you are using small cups, lower the cup grille (A10) to
bring the lter holder spouts nearer the cup. This makes a
better froth (g. 20);
4. Using the dial (B8), select the desired beverage.
5. Press the button. The appliance makes the coee then
stops automatically.
Please note: While the machine is making coee, delivery can
be interrupted at any moment by pressing the button. To re-
move the lter holder, turn the handle from right to left.
Danger of burns
• To avoid splashes, never remove the lter holder while the
appliance is delivering coee. Wait for a few seconds after
delivery.
• If no coee is delivered, wait for about 1 minute before remov-
ing the lter holder. There could be a pu of steam caused by
the residual pressure inside the appliance.
5.3 Pressure gauge
The pressure gauge enables you to check that pressure is correct
while the coee is being delivered (g. 21).
While making Espresso coee, the indicator of the pressure
gauge will rotate within the optimal zone sector showing the
pressure used during brewing.
For more information, see section "16. How to make perfect
coee".
Important: the pressure gauge only operates while coee bev-
erages are being made. If you are preparing hot water " " or
using the steam function, the pressure gauge indicator does not
move.
5.4 Coee beverages
• ESPRESSO
Beverage of Italian origin, a short coee with an intense
aroma.
Coee Pre-
infusion
Quantity Filter
✓
1 cup
35 ml
C3
C2
✗
2 cups
70 ml
C3
C2
✓
Always check that there is the right amount of coee in the lter
(see section "4.5 Adjusting the quantity of ground coee in the
lter").
• COFFEE
Beverage of European origin, a long coee with a delicate
aroma.
25
Coee Pre-
infusion
Quantity Filter
✗
1 cup
70 ml
C3
C2
✗
2 cups
140 ml
C3
C2
✓
Always check that there is the right amount of coee in the lter
(see section "4.5 Adjusting the quantity of ground coee in the
lter").
• AMERICANO
Beverage of American origin, a long coee. Made by deliv-
ering an espresso, followed by hot water added directly to
the cup. Only one cup can be made at a time.
Coee Pre-
infusion
Quantity Filter
✓
1 cup
120 ml
C3
C2
✗
RECOMMENDED:
1 cup
240 ml
C3
C2
✓
Always check that there is the right amount of coee in the lter
(see section "4.5 Adjusting the quantity of ground coee in the
lter").
6. CUSTOMISING THE QUANTITY OF COFFEE
BEVERAGES WITH THE BUTTON (B7)
1. Prepare the appliance to deliver 1 or 2 cups of the coee
beverage you want to make, as far as attaching the lter
holder (C1) complete with the (C2) or (C3) lter and ground
coee.
2. Turn the dial (B8) to select the coee to be programmed.
3. Press the button: the light corresponding to the
button (B5) comes on steadily and the light corresponding
to the button ashes.
4. Press the button to start delivering the beverage. The
lights corresponding to the and buttons ash.
5. When you have reached the desired quantity of the bever-
age, press the button again.
6. Press the button to save the new setting. The appliance
is ready for use again and the button remains on.
If you do not want to save the new setting, press any other
button.
Programming Americano coee: follow the procedure described
above for the quantities of both coee and hot water.
Please note:
• You can programme coee beverages, but not steam and hot water.
• Programming changes the quantity of the beverages, but not the amount of
coee ground.
• "X2” beverages can be programmed separately.
6.1 Beverage reset
To reset the default beverage quantities, press and hold the
button (B7) until it goes o.
The selected beverage is reset to the default values.
7. USING PRE-GROUND COFFEE
1. Place the ground coee lter (C2) or (C3) in the lter holder
(C1) (g. 17);
2. Place the quantity of ground coee in the lter;
3. Turn the dial (B2) to the position to disable the coee
mill;
4. Attach the lter holder to the outlet of the coee mill
(A22), aligning it with "INSERT", then turning it to the right
(g. 10).
5. Pull the presser lever (A23) as far as it will go. The print-
ing on the lever indicates the pressing force exerted
( ) (g. 19).
6. Remove the lter holder by turning it towards the left.
8. DELIVERING HOT WATER
1. Choose the cup and place it on the correct cup grille ((A10)
or (A11)).
2. Press the button (B6): the appliance delivers hot
water from the spout (A5) then goes o automatically.
3. To interrupt delivery, press the button again.
9. HOW TO MAKE MILK-BASED BEVERAGES
1. Pour the quantity of milk you want to heat/froth into the
milk jug (C9), remembering that the volume of milk dou-
bles or triples in volume. For a denser more even froth,
you should ideally use skimmed or partially skimmed cow's
milk at refrigerator temperature (about 5°C).
2. Choose the position of the ring (A7) (g. 22) according to
the beverage to be prepared (see following table):
26
Recommended
position
Milk beverage to be
prepared
Hot milk (not frothed) /
Caelatte / Macchiato / Flat
White
Cappuccino, Espresso Mac-
chiato, Hot Milk (frothed)
3. Place the jug (C9) containing the milk under the cappuccino
maker (A8) (g. 23).
4. Immerse the cappuccino maker in the milk jug. Never im-
merse the black ring (g. 24).
5. Turn the dial to the position (g. 25). Steam to heat the
milk is delivered from the cappuccino maker. If the ring is
in the FOAM position, the steam gives the milk a creamy
frothy appearance (g. 26). To obtain a creamier froth,
immerse the cappuccino maker in the milk and rotate the
container with slow upward movements.
6. When the required temperature (the ideal is 60°C) and
froth density is reached, interrupt steam delivery by turn-
ing the dial to the ◯ position.
7. For beverages requiring it, prepare the coee (see section
"4. Prepare the perfect dose"). Choose suciently large
cups and place them on the espresso cup grille (A10). To
use tall glasses, close the espresso cup grille (A10) and rest
the glass on the cup grille for glasses or mugs (A11).
8. Pour the frothed milk into the cups. Sweeten to taste and if
desired, sprinkle the froth with a little cocoa powder.
Please note: Preparing cappuccino: consider about 100 g of milk for each
cup.
10. CLEANING THE CAPPUCCINO MAKER
AFTER
USE
For hygiene reasons, the cappuccino maker should always be
cleaned after use.
Proceed as follows:
1. Turn the steam dial to the position to deliver a little
steam for a few seconds (points 2, 5 and 6 of the previous
section). This causes the cappuccino maker to discharge
any milk left inside.
2. Press the (B1) ON/Standby button to turn the appliance o.
3. Wait a few minutes for the cappuccino maker to cool down.
With one hand, hold the cappuccino maker tube rmly,
with the other, release the cappuccino maker by turning it
anticlockwise, then pull o downwards (g. 27).
4. Remove the rubber steam connection nozzle from the
spout by pulling it downwards (g. 28).
5. Push the ring upwards and make sure the two holes shown
by the arrows in g. 29 are not blocked. If necessary, clean
with a pin;
6. Replace the connection nozzle, move the ring downwards
and put the cappuccino maker back on the nozzle, turning
it and pushing it upwards until it is attached.
For more thorough cleaning, use De’Longhi detergent.
11. ACTIVATING THE WATER SOFTENER FILTER
Certain models are tted with a water softener lter (C6). If this
is not the case with your model, you are recommended to pur-
chase one from De’Longhi Customer Services.
To use the lter correctly, follow the instructions below.
1. Remove the lter from the packaging;
2. Turn the date indicator disk (g. 30) until the next 2 months
of use are displayed;
Please note: The lter lasts about two months if the appliance is used normal-
ly. If the coee machine is left unused with the lter installed, it will last a maximum
of 3 weeks.
3. To activate the lter, run tap water through the hole in the
lter (g. 31) until water comes out of the openings at the
side for more than a minute;
4. Extract the tank (A17) (if necessary ll with water);
5. Insert the lter in the water tank and immerse it complete-
ly for about ten seconds, sloping it and pressing it lightly to
enable the air bubbles to escape (g. 32);
6. Place the lter in the lter housing (A18) and press as far
as it will go. Close the tank, then put the tank back in the
machine;
The lter is now active and you can use the coee machine.
12. MENU SETTINGS
Please note: Once in the menu, you can modify all the menu functions as de-
scribed in the previous sections.
12.1 Coee temperature
To change the temperature of the water used to make the coee,
proceed as follows:
1. Press and hold the
(B3) and
(B7) buttons togeth-
er for at least 3 seconds to access the menu. The (B15)
and (B16) lights alternate;
2. Turn the mode selection dial (B8) to the ESPRESSO
position. The light (B11) remains on steadily;
3. Press the button corresponding to the desired selection as
shown in the following table:
Button Temperature
Standard
High
4. Press the button (B1) to exit the menu. (If the appliance
is left idle for
about 1 minute, it exits automatically from
the settings menu and is ready for use again).
27
12.2 Water hardness
The descale light (B9) comes on after a period of time es-
tablished according to water hardness. The machine can also
be programmed according to the actual hardness of the water
supply in the various regions, in which case descaling may be
required less frequently.
Proceed as follows:
1. Remove the "TOTAL HARDNESS TEST" indicator paper (C4)
from its pack.
2. Immerse the paper completely in a glass of water for one
second.
3. Remove the paper from the water and shake lightly. After
about a minute, 1, 2, 3, or 4 red squares form, depending
on the hardness of the water. Each square corresponds to
one level.
4. Press and hold the
(B3) and (B7) buttons for at
least 3 seconds to access the menu. The (B15) and
(B16) lights alternate;
5. Turn the mode selection dial (B8) to the AMERICANO
position. The light (B9) remains on steadily;
6. Press the button corresponding to the desired selection as
shown in the following table:
Total Hardness Test result Button Level
1
soft water
2
medium
water
3
hard or
very hard
water
7. Press the button (B1) to exit the menu. (If the appliance
is left idle for
about 1 minute, it exits automatically from
the settings menu and is ready for use again).
12.3 Auto-o
Auto-o can be set so that the appliance goes o after 9 min-
utes, one and a half hours, or three hours. Proceed as follows:
1. Press and hold the
(B3) and
(B7) buttons for at
least 3 seconds to access the menu. The (B15) and
(B16) lights alternate;
2. Turn the mode selector dial (B8) to the COFFEE posi-
tion: The light (B13) remains on steadily;
3. Press the button corresponding to the desired selection as
shown in the following table:
Button Time
9 minutes
1.5 hours
3 hours
4. Press the button (B1) to exit the menu. (If the appliance
is left idle for
about 1 minute, it exits automatically from
the settings menu and is ready for use again).
12.4 Default values
The appliance can be reset to the default values. Proceed as
follows:
1. Press and hold the
(B3) and
(B7) buttons for at
least 3 seconds to access the menu;
2. Press and hold the button for a few seconds until the
corresponding light starts ashing;
3. Press the button (B1) to exit the menu. (If the appliance
is left idle for
about 1 minute, it exits automatically from
the settings menu and is ready for use again).
12.5 Energy saving
Use this function to enable or disable energy saving. When en-
abled, the function reduces energy consumption in compliance
with European regulations.
Proceed as follows:
1. Press and hold the
(B3) and
(B7) buttons for at
least 3 seconds to access the menu;
2. Press the
button (B6). The light (B12) comes on ;
3. Press the button (B1) to exit the menu. (If the appliance
is left idle for
about 1 minute, it exits automatically from
the settings menu and is ready for use again).
Please note:
• If energy saving is active, you may have to wait a few seconds before delivery.
• When energy saving is disabled, steam is delivered immediately.
12.6 Extra grinding adjustment
Over time, the burrs will wear down and the quantity of ground
coee will diminish. When adjusting the burrs as described in
section "4.5 Adjusting the quantity of ground coee in the l-
ter" is no longer enough, you can select a new grinding range.
Proceed as follows:
1. Press and hold the (B3) and (B7) buttons for at
least 3 seconds to access the menu. The (B15) and
(B16) lights alternate;
2. Turn the mode selection dial (B8) to the position. The
light (B14) remains on steadily;
3. Select the new grinding range by pressing the button
(B4);
28
4. Press the button (B1) to exit the menu. (If the appli-
ance is left idle for about 1 minute, it exits automatically
from the settings menu and is ready for use again);
5. Turn the ground coee quantity dial (B2) to the "min”
position, then proceed to adjust as if it were the rst time
("4.5 Adjusting the quantity of ground coee in the lter").
13. CLEANING
13.1 Cleaning the machine
The following parts of the machine must be cleaned regularly:
- drip tray (A13) complete with cup grille (A11) and drip tray
grille (A12);
- espresso cup grille (A10);
- coee lters (C2) and (C3);
- the beans container (A2);
- the coee mill burrs;
- the coee mill outlet (A22) (smart tamping station);
- boiler outlet (A21);
- water tank (A17);
- cappuccino maker (A8) as described in section "10. Clean-
ing the cappuccino maker after use".
Important!
• Do not use solvents, abrasive detergents or alcohol to clean
the coee machine.
• Do not use metal objects to remove encrustations or coee
deposits as they could scratch metal or plastic surfaces.
• None of the components of the appliance can be washed in
a dishwasher with the exception of the drip tray (A13) and
cup grilles (A10) and (A11).
• If the appliance is not used for more than a week, before
using it again, we recommend you perform a rinse cycle as
described in section "3. Setting up the appliance".
Danger!
• While cleaning, never immerse the coee maker in water. It
is an electrical appliance.
• Before cleaning the outside of the appliance, turn it o,
unplug from the mains socket and allow to cool.
13.2 Cleaning the drip
tray
The drip tray is tted with a
level indicator (A14) showing
the amount of water it contains.
Before the indicator protrudes
from the cup tray, the drip tray
must be emptied and cleaned,
otherwise the water may over-
33
ow the edge and damage the appliance, the surface it rests on or
the surrounding area.
1. Remove the drip tray (g. 33).
2. Remove the cup grille (A11), drip tray grille (A12) and level
indicator (A14), empty the water and clean all the compo-
nents with a cloth, then reassemble the drip tray.
3. Put the drip tray back in place.
13.3 Cleaning the espresso cup grille
1. Extract the grille (A10) by pulling it from the left, then re-
moving it from the support (g. 34).
2. Clean the support with a cloth and wash the grille (dish-
washer safe).
3. Put the grille back on the support from the right side, then
push until it is correctly attached (g. 35).
35
34
1
2
1
22
2
1
13.4 Coee lter cleaning and maintenance
The coee lters are designed to obtain the best possible coee
froth. For best results, the lters must always be clean and free
from all coee residues.
After using the appliance, always rinse the lters under abun-
dant running water (g. 36), pushing the perforated lter to
make sure it is always correctly inserted in its housing (g. 37);
make sure the hole underneath (shown in g. 40) is free from
all residues.
36 37
29
If still dirty, and in any case always at least once a month, clean
the coee lters thoroughly:
1. Extract the perforated lter by pulling the tab (g. 38).
38 39
2. Rinse the lters under
running water (g. 39).
3. Make sure the holes are
not blocked. If necessary,
clean with a pin (g.
39-40).
4. Dry all the components
with a cloth.
5. Put the perforated lter
back in the housing and
press as far as it will go
(g. 37).
13.5 Cleaning the boiler outlet
After every 200 coees, rinse the boiler outlet. Press the
rinse button (B4) and deliver about 200 ml of water.
13.6 Cleaning the water tank
1. Remove the lter (*if present) and rinse with running
water.
2.
Clean the water tank regularly (about once a month) and when-
ever you replace the water softener lter (C6) (*if present) with
a damp cloth and a little mild washing up liquid, then rinse
thoroughly.
3.
Replace the lter (*if present), ll the tank with fresh water
and replace the tank.
4. (Models with water softener lter only) Deliver about 100
ml of water.
Danger!
While cleaning, never immerse the coee maker in water. It is an
electrical appliance.
13.7 Cleaning the beans container
Without extracting it, clean the beans container regularly with
a cloth.
For more thorough cleaning, proceed as follows:
1. Make sure the beans container (A2) is empty. If necessary,
operate the coee mill without beans to empty it:
2. Release the beans container by turning it anticlockwise and
extract from the appliance.
3. Wash the container and
lid (A1) with warm water.
Do not wash the compo-
nents in a dishwater or
use washing up liquid! Dry
all accessories thoroughly
before using again.
4. Remove coee residues
(g. 41);
5. Clean the beans contain-
er housing with a damp
cloth and dry;
6. Put the container back as described in section "3. Setting
up the appliance".
13.8 Cleaning the burrs
When cleaning the beans container, clean the container housing
and upper burr with a damp cloth. The burr can be removed and re-
placed when worn. Contact an authorised customer services centre.
You may also need to remove the burr if it becomes blocked with
foreign matter. If this occurs, clean as follows:
1. Empty the beans container (if necessary, using a vacuum
cleaner to remove any remaining beans).
2. Attach the lter holder and operate the mill without beans
to free the coee guide, then attach the lter holder to the
outlet of the coee mill (A22), lining it up with "INSERT",
then turning it to the right (g. 18). Grinding begins when
the lter holder reaches the CLOSE position and stops
automatically;
3. Turn the appliance o;
4. Remove the beans container as described in the previous
section "13.7 Cleaning the beans container".
5. Turn the neness selector anticlockwise as far as it will go
to the "REMOVE" position (g. 42).
40
41
30
19
1942 43
6. Extract the upper burr,
gripping it by the handle
(g. 43).
7. Clean the burr with a
brush (g. 44) and remove
the coee residues using a
vacuum cleaner (g. 41).
8. Put the upper burr back in place:
45
46
• Insert the burr in its housing (g. 45);
• Turn the selector to select the desired grinding level (g.
46);
• Make sure the burr is inserted correctly by pulling it by the
handle. If it is correctly inserted, it will not move;
9. Use a brush to remove any coee residues from the outlet
of the coee mill (A22).
13.9 Replacing the burrs
When the quantity of coee becomes even less, contact a cus-
tomer services centre to have the burrs replaced, then adjust the
mill again as follows:
1. Press and hold the (B3) and (B7) buttons for at
least 3 seconds to access the menu. The (B15) and
(B16) lights alternate;
2. Turn the mode selection dial (B8) to the position. The
light (B14) remains on steadily;
3. Select the original grinding range by pressing the
button;
4. Press the button (B1) to exit the menu. (If the appli-
ance is left idle for about 1 minute, it exits automatically
from the settings menu and is ready for use again);
5. Turn the ground coee quantity dial (B2) to the "min”
position, then proceed to adjust as though it were the rst
time ("4.5 Adjusting the quantity of ground coee in the
lter").
13.10
Cleaning the "Smart tamping station"
To guarantee top quality grinding, clean the “Smart tamping
station” regularly as follows:
47 48
1. Clean the attachment area
with a brush (g. 7).
2. Pull the
lever
(A23) as
far as it will go and clean
the presser cylinder with
a brush (g. 48). Then re-
lease the lever.
3. Use the tube brush (C8)
to clean the coee guide
(g. 49).
44
49
31
13.11 Other cleaning operations
1. Do not use solvents or abrasive detergents to clean the cof-
fee maker. Use a soft damp cloth only.
2. Clean the lter holder cup.
3. You are recommended to use De’Longhi detergent.
14. DESCALING
Descale the appliance when the light (B9) comes on.
• Before use, read the instructions and the labelling on the
descaler pack.
• It is important to use De’Longhi descaler only. Using unsuitable
descaler and/or performing descaling incorrectly may result in
faults not covered by the manufacturer's guarantee.
Proceed as follows:
1. (IF PRESENT, REMOVE THE WATER SOFTENER FILTER).
Pour
the descaler into the tank up to the level A marked in-
side the tank (equal to one 100ml packet), then add water
(litre) up to the level B .
2. If the appliance is o, press the ON/Standby button (B1).
3. Make sure the lter holder is not attached and position a
recipient under the spouts (A5), (A6) and the boiler outlet
(A21)
(g. 8).
4. Turn the mode selector dial (B8) to the position. The
light ashes and the light comes on.
5. Press (B5) to start descaling.
6. The descale programme starts and the descaler liquid comes
out of the spouts and boiler outlet. The descale programme
removes limescale deposits from inside the appliance by au-
tomatically performing a series of rinses and pausesuntil the
tank is empty.
7. Delivery stops and the (B15) and lights corre-
sponding to the rinse button (B4) come on.
8. Empty the recipient used to collect the descaler solution
and replace it empty under the spouts.
9. Remove the water tank, empty any residues of descaler
solution, rinse with running water and ll with fresh water
up to the MAX level. Put the tank back in its housing.
10. Press the button. The appliance rinses the internal
circuits and delivers water from all three spouts.
11. When rinsing is complete, delivery stops. All the LEDs ash
briey and the appliance prepares to be used again.
12. Empty the recipient used to collect the rinse water.
13. Extract and empty the drip tray, then put back in the
appliance.
14. Extract the tank, ll with fresh water, then put back in the
appliance.
15. Turn the mode selector dial to one of the coee positions.
15. TECHNICAL DATA
Mains voltage: 220-240V
˜
50-60Hz
Absorbed power: 1450W
Size LxDxH: 375x368x445 mm
MAX. pressure: 19 bars
Water tank capacity: 2 L
Power cable length: 1200 mm
Weight: 12 kg
32
16. HOW TO MAKE PERFECT COFFEE
PERFECT ESPRESSO UNDER-EXTRACTED COFFEE OVER-EXTRACTED COFFEE
FROTH: nut-brown coloured with
dark lights and light-coloured
streaks, 3-4 mm thick
FROTH: clear and thin with large
bubbles
FROTH: dark and thin, only at the edges
BODY: dense, full-avoured and
smooth
BODY: thin, watery BODY: excessive
TASTE: well-balanced and lingering TASTE: weak and short-lived TASTE: strong, astringent, lingering and bit-
ter on the palate
AROMA: intense AROMA: not pronounced AROMA: weak, with a hint of burnt coee
GRINDING LEVEL: Correct GRINDING LEVEL: too coarse. Adjust the
mill to a lower position, follow-
ing the instructions in section
"4.5 Adjusting the quantity of
ground coee in the lter"
GRINDING LEVEL: too ne. Adjust the mill
to a higher position, following the
instructions in section "4.5 Adjusting
the quantity of ground coee in the
lter"
COFFEE QUANTITY: Correct QUANTITY OF COFFEE IN FILTER:
Not enough. Increase the quan-
tity by turning the dial "B2.
Ground coee quantity dial" as
described in section "4.5 Ad-
justing the quantity of ground
coee in the lter"
QUANTITY OF COFFEE IN FILTER:
Too much: reduce the quantity by
turning the dial "B2. Ground coee
quantity dial" as described in section
"4.5 Adjusting the quantity of ground
coee in the lter"
33
17. EXPLANATION OF LIGHTS
LIGHTS EXPLANATION OF LIGHTS OPERATION
All the lights ash briey Turning the machine on Self-diagnosis
on
Insucient water in tank or water tank
not inserted correctly
Fill the tank or extract the tank and put it
back correctly
Energy saving is enabled See section "12.5 Energy saving" if you want
to disable the function
on
The appliance is on and ready for use The appliance is at the right temperature
to deliver steam. To deliver steam, turn the
steam dial (A4)
ashing
The appliance is on and energy saving
is enabled. The steam dial (A4) is in the
steam delivery position
The light ashes to indicate that the ap-
pliance is preparing to deliver steam. De-
livery begins as soon as the appliance is at
temperature
The appliance is heating up to be ready
for use
The appliance is at temperature when the
light remains on steadily
on
Presser lever (A23) is not in the correct
position
Turn the lever back in place.
ashing
Pressing is needed The coee has just been ground and the lter
holder is attached to the coee mill
The lter holder has been detached
from the coee mill without pressing
Detach the lter holder and press the coee
as described in section "7. Using pre-ground
coee"
The lter holder has been detached be-
fore grinding has ended or pressing has
been performed too quickly
Repeat grinding
The slide of coee grinder is clogged Clean as described in section "13.10 Clean-
ing the "Smart tamping station"" and sec-
tion "18. Troubleshooting" in correspond-
ence to g. 50.
The burrs are blocked by foreign matter Remove the foreign matter and clean the
burrs as described in section "13.8 Cleaning
the burrs".
on
The beans container is empty Fill the beans container
ashing
The beans container is not inserted or
is not correctly screwed in place, or the
selector on the bottom of the container
is not in a position from 1 to 6.
Put the beans container in the appliance
correctly
…
→
34
LIGHTS EXPLANATION OF LIGHTS OPERATION
+ ash briey at regular
intervals
The dial (B2) has been turned to the
maximum adjustment possible
When not enough coee is ground to reach
the correct quantity, select the new grinding
range as described in section "12.6 Extra
grinding adjustment".
ashing
The appliance is too hot to make coee Wait for it to cool
on
Descaling must be performed Descale the appliance as described in section
"14. Descaling"
ashing
Descaling is underway Complete the operation as described in sec-
tion "14. Descaling"
Descaling has ended and the dial (B8) is
in the "descaling" position
Turn the mode selector dial to one of the
"coee positions"
ashing quickly
The dial (B8) is in the descaling position Turn the dial to one of the beverage positions
on
The appliance is being turned on for the
rst time and the water circuit must be
lled
Proceed as described in section "3. Setting up
the appliance".
+ ashing
If the water softener lter (C6) is
present, an air bubble may have been
released inside the circuit, obstructing
delivery
Press the button (B6) corresponding to the
light (g. 9). Delivery begins and stops
automatically.
The grinding is too ne and the coee is
delivered too slowly or not at all
Extract the lter holder and repeat the op-
erations to make the coee, bearing in mind
the indications in section "4.5 Adjusting the
quantity of ground coee in the lter" and
table "16. How to make perfect coee".
ashing
The drip tray (A13) is missing or has not
been inserted correctly
Extract the drip tray then put back correctly
in the appliance
on
General alarm Contact Customer Services
…
→
35
LIGHTS EXPLANATION OF LIGHTS OPERATION
+ ashing
If the water softener lter (C6) is
present, an air bubble may have been
released inside the circuit, obstructing
delivery
Press the button (B6) corresponding to the
light (g. 9). Delivery begins and stops
automatically.
The grinding is too ne and the coee is
delivered too slowly or not at all
Extract the lter holder and repeat the op-
erations to make the coee, bearing in mind
the indications in section "4.5 Adjusting the
quantity of ground coee in the lter" and
table "16. How to make perfect coee".
The lter is blocked, or the perforated
lter is missing
Clean as described in section "13.4 Coee
lter cleaning and maintenance" and make
sure the perforated lter is put back correctly
The tank has been inserted incorrectly
and the valves on the bottom are not
open
Press the tank down lightly to open the
valves on the bottom
Scale in the water circuit Descale as described in section "14.
Descaling"
18. TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
No espresso coee is delivered No water in the tank (A17) Fill the tank
The light is on to indicate that the
coee or steam circuit is empty.
Press the button corresponding to the
light to ll the circuit.
The lter is blocked, or the perforated
lter is missing
Clean as described in section "13.4 Coee
lter cleaning and maintenance" and make
sure the perforated lter is put back correctly
The tank has been inserted incorrectly
and the valves on the bottom are not
open
Press the tank down lightly to open the
valves on the bottom
Scale in the water circuit Descale as described in section "14.
Descaling"
The lter holder cannot be attached to
the appliance
The ground coee has not been pressed
or is too much
Clean as described in section "4.4 Grind the
coee directly into the lter"
The espresso coee drips from the
edges of the lter holder rather than
the holes
The lter holder is inserted incorrectly Attach the lter holder correctly and rotate
rmly as far as it will go
The espresso boiler gasket has lost elas-
ticity or is dirty
Have the espresso boiler gasket replaced by
Customer Services
The lter is clogged, or the perforated
lter is missing or dirty
Clean as described in section "13.4 Coee
lter cleaning and maintenance"
…
→
36
PROBLEM CAUSE SOLUTION
The coee froth is too light (delivered
from the spout too fast)
The appliance settings need reviewing See section "16. How to make perfect coee"
The coee froth is too dark (delivered
from the spout too slowly)
The appliance settings need reviewing See section "16. How to make perfect coee"
No milk froth is formed when making
cappuccino
The ring (A7) is in the "FLAT" (NO
FROTH) position
Push the ring into the "FOAM" position
Milk not cold enough Always use semi-skimmed milk at refrigera-
tor temperature.
The cappuccino maker (A8) is dirty Clean the cappuccino maker as described in
section "10. Cleaning the cappuccino maker
after use"
Scale in the water circuit Descale as described in section "14.
Descaling"
At the end of descaling, the appliance
requests a further rinse
During the rinse cycle, the water tank
has not been lled to the MAX level
Repeat the rinse cycle from point (8) of section
"14. Descaling"
The appliance does not grind the coee There is foreign matter that cannot be
ground in the coee mill
Clean the burrs as described in section "13.8
Cleaning the burrs", making sure you remove
all the beans from the beans container (A2)
before extracting it.
Before putting the burr back, vacuum all resi-
dues from the housing (g. 44).
If you want to change the type of coee You must remove all the beans present
in the machine
• Empty the beans container (if neces-
sary, operate the coee mill without
beans or use a vacuum cleaner to re-
move any remaining beans).
• Attach the lter holder and operate the
coee mill a number of times without
beans to free the coee guide. Attach
the lter holder to the outlet of the mill
(A22), lining it up with "INSERT", then
turning it to the right (g. 22). Grinding
begins when the lter holder reaches
the CLOSE position and stops automat-
ically. Repeat until the lter is empty.
• Place the new coee in the beans
container.
• If the amount of coee ground is not
enough to reach the “perfect quantity”,
proceed as described in section "4.5 Ad-
justing the quantity of ground coee in
the lter".
…
→
37
PROBLEM CAUSE SOLUTION
After grinding, the coee lter is empty The coee mill coee guide is clogged
Clean as described in section "13.10 Cleaning
the "Smart tamping station"". If the problem
persists, access the guide by opening the hatch
and free it using the brush (g. 50).
After grinding, there is too much coee
in the lter
After grinding, the ground coee in
the lter does not reach the “perfect
amount of coee”
The "Smart Tamping Station" needs
cleaning
Clean as described in section “13.11 Cleaning
the "tamping station", then grind again.
The quantity of ground coee needs
adjusting
Adjust the quantity of coee with the dial
(B2), following the instructions in section
"4.5 Adjusting the quantity of ground coee
in the lter". If the dial is already in the max.
position, proceed as described in section "12.6
Extra grinding adjustment".
Over time the burrs wear down
Replace the burrs as described in section
"13.9 Replacing the burrs".
