all-in-one
SONIC
water flossing system
Questions or Comments? 1-800-334-4031
www.interplak.com
Instruction Manual • Model SWJ2
For your safety and continued enjoyment of this product,
always read the instruction book carefully before using.
by
Subgingival Tip
Designed for close-in comfort, the rubber tip delivers a
concentrated jet stream of water or antibacterial solution
that reaches deep into periodontal pockets.
Note: This tip is NOT intended for general use, and
MUST be used on low pressure setting only. Place the
soft tip against a tooth and gently place the tip slightly
under the gum line into the pocket. Clean by gently
following the gum line, inserting the tip between teeth.
Do all areas of the mouth.
Orthodontic Cleaning
Using the water jet tip, follow the recommended
technique described on page 7 to clean around
orthodontic brackets one tooth at a time.
Using Mouthwash and Other Solutions
Your Interplak System can be used with mouthwash
or other antibacterial solutions. Ask your dentist to
recommend an appropriate product for you.
Important Note: Use of some solutions can shorten the
life of your unit if it is not cleaned properly. You must
thoroughly rinse out the unit after using any solution.
Fill the tank with warm water to the lowest fill line, then
aim the tip into the sink and run until the tank is empty.
Insert brush tip into handle. Apply toothpaste.
Insert brush tip into mouth, press Sonic button
and brush your teeth as you normally do.
When finished, turn off the unit by pressing the Power button on the base
and empty the water tank. Be sure to also turn off the Sonic function
by pressing the Sonic button on the handle.
Rinsing Using Water Stream
Press and hold the Pause button and place brush
in mouth, slightly closing lips to avoid splashing.
Press the Power button, release the Pause button,
and rinse along the gum line as shown.
Slightly close lips as shown to avoid splashing.
Release the Pause button and rinse
as shown along the gum line.
Instructions for Using Battery
• Always purchase the correct size and grade of battery most suitable
for the intended use.
• Clean the battery contacts and also those of the device prior to
battery installation.
• Ensure the battery is installed correctly with regard to polarity (+ and -).
• Remove battery from equipment that is not to be used for an extended
period of time.
• Remove used battery promptly.
Battery Disposal
When replacing the battery, make sure you dispose of the old battery in
accordance with applicable regulations. It should be disposed of in a location
specifically designated for that purpose so it can be recycled safely and
without posing any risk to the environment. Do not burn or bury it.
Cleaning and Care of Your
Interplak
®
All-in-One Sonic Water Jet System
If the valve on the water tank begins to leak after repeated use, it is simply time
to clean the valve and valve seat. Using a jet tip, push out the valve body –
located inside the bottom of the water tank. Use the tip to clean both valve and
valve seat, then replace the valve.
> Replace every 3 months
> Replace every 6 months
To order replacements parts, call 1-800-334-4031
Replacement tips available for $8.99, including shipping and handling.
Replacement tip pack includes:
2 full size brush tips
1 gum massage tip
1 subgingival tip
1 jet tip
Recommended Tip Replacement Intervals
Full Size
Brush Tip
Jet Tip
Gum
Massage Tip
Tongue
Cleaner Tip
Subgingival
Tip
Troubleshooting Guide
Problem Cause(s) Solution(s)
Sonic vibration
not working
Tank leaks
Inadequate
pressure
Main unit
doesn’t start
Tip doesn't
pull off
1. Dead battery
2. Dirty contact
3. Battery cap is loose
4. Sonic ON/OFF
button on handle
is in OFF position
The valve and valve
seat in water tank
need to be cleaned
1. Tank is not
positioned properly
2. Tip is clogged with
debris
3. Pressure control
is on low setting
No power to the unit
Release button
located on top
of handle
1. Replace battery
2. Clean contact with
cotton swab
3. Turn the battery cap
to Closed position
4. Press Sonic OF/OFF
button to ON
Follow cleaning and care
instructions on page 9
1. Reposition the tank and
push down firmly
2. Try a different tip; clean or
replace tip that is clogged
3. Adjust pressure control
to higher setting
Check the outlet and make
sure it is functioning; check
electrical reset buttons and
wall switches
Press release button
and pull tip off
Still have questions? Call 1-800-334-4031
Limited 2-Year Warranty
Conair will repair or replace (at our option) your unit free of charge for 24 months
from the date of purchase if the appliance is defective in workmanship or materials.
To obtain service under this warranty, return the defective product to the service
center listed below, together with your purchase receipt and $3.00 for postage and
handling.
California residents need only provide proof of purchase and should call
1-800-334-4031 for shipping instructions. In the absence of a purchase receipt,
the warranty period shall be 24 months from the date of manufacture.
ANY IMPLIED WARRANTIES, OBLIGATIONS, OR LIABILITIES, INCLUDING
BUT NOT LIMITED TO THE IMPLIED WARRANTY OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED IN DURATION TO
THE 24-MONTH DURATION OF THIS WRITTEN, LIMITED WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts,
so the above limitation may not apply to you.
IN NO EVENT SHALL CONAIR BE LIABLE FOR ANY SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES FOR BREACH OF THIS OR ANY OTHER
WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. Some states do not allow the
exclusion or limitation of special, incidental, or consequential damages, so the above
limitation may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights,
which vary from state to state.
Service Center:
Conair Corporation
Service Department
7475 N. Glen Harbor Blvd.
Glendale, AZ 85307
Please register this product at: www.conair.com/registration
For more information regarding this and other Interplak
®
by Conair products,
visit www.interplak.com or call 1-800-334-4031
©2016 Conair Corporation, 150 Milford Road, East Windsor, NJ 08520
16IN025410
IB-14762
Recommended Technique – Sonic Brushing
