Microwave Oven

MZ3000PG/MZ3000PGSA

Please read through this booklet for safe and efﬁcient use of the appliance.

We urge you to read the "Hint's" section and also follow all detailed

instructions even if you are familiar with using this appliance.

Keep this guide handy for future reference.

First Use Safety Recommendation

English Page 02

Farsi Page 25

Arabic Page 37

230 -240V

220V

English

-2-

Fig A

OST

BLE

GRI

English

-3-

Intended use

Your Black & Decker microwave oven is

designed to heat appropriate foods &

beverages using electromagnetic radiation.

Always check the suitability of ingredients

before cooking.

Do not use this appliance for any other

purpose. This product is intended for

indoor household use only.

Safety instructions

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR

FUTURE REFERENCE

• While using electrical appliances, in

order to reduce the risk of ﬁre, electric

shock, and / or injury to persons, basic

safety precautions should be followed,

including the following:

Warning: If the door or door seals are

damaged, the oven must not be operated

until it has been repaired by a competent

person

Warning: It is hazardous for anyone other

than a competent person to carry out any

service or repair operation that involves the

removal of a cover which gives protection

against exposure to microwave energy

Warning: Liquids and other foods must not

be heated in sealed containers since they

are liable to explode

Warning: Only allow children to use the

oven without supervision when adequate

instructions have been given so that the

child is able to use the oven in a safe way

and understands the hazards of improper

use

Fig B Fig C

WEIGHT

DEFROST

PASTA

FISH

POTATO

PORRIDGE

SOUPPIZZA

MEAT

VEGETABLE

SPEED

DEFROST

GRILL/

COMBI.

MICROWAVE

STOP

CLEAR

START

AUTO

REHEAT

EXPRESS COOK

Mica plate, Do not remove

English

-4-

• This microwave oven is a free-standing

unit & must not be built-in or placed in a

cabinet.

• The oven must have sufﬁcient air ﬂow.

To ensure good ventilation, a gap of 10

centimetres is required at the back, 15

centimetres at one side, 30 centimetres

at the other side and 30 centimetres

above.

• Only use utensils that are suitable for

use in microwave ovens

• When heating food in plastic or paper

containers, keep an eye on the oven due

to the possibility of ignition

• If smoke is observed, switch off or

unplug the appliance and keep the door

closed in order to stiﬂe any ﬂames

• Microwave heating of beverages can

result in delayed eruptive boiling

therefore care must be taken when

handling the container

• The contents of feeding bottles and

baby food jars shall be stirred or shaken

and the temperature checked before

consumption, in order to avoid burns

• Eggs in their shell and whole hard-boiled

eggs should not be heated in microwave

ovens since they may explode, even

after microwave heating has ended

• The oven should be cleaned regularly

and any food deposits removed

• Failure to maintain the oven in a clean

condition could lead to deterioration of

the surface that could adversely affect

the life of the appliance and possibly

result in a hazardous situation

• To protect against the risk of electric

shock, DO NOT IMMERSE the

appliance, cord set or plug in water or

other liquids.

• Do not remove the feet from this

product.

• Do not cook food directly on the glass

tray. Always use a bowl or other

container that is suitable for use in a

microwave oven

Using your appliance

• Do not operate any appliance with a

damaged cord or plug, or after the

appliance malfunctions, or is dropped or

damaged in any manner. Return the

complete appliance to your nearest

authorised service facility for

examination, electrical repair, mechanical

repair or adjustment to avoid any hazard.

• Do not attempt to repair the appliance

yourself; instead, take it to your Black &

Decker-owned or Authorised Service

Centre for repair.

• The use of attachments or accessories

not recommended or sold by this

appliance manufacturer may result in ﬁre,

electric shock or personal injury.

• Do not let the cord hang over the edge of

a table, counter, or touch hot surfaces.

• Avoid touching hot surfaces, use handles

and knobs.

• Do not operate or place any part of this

appliance on or near any hot surfaces

(such as gas or electric burner or in a

heated oven) or any appliance that

generates steam.

• Do not abuse the cord. Never carry the

appliance by the cord or yank it to

disconnect it from the outlet; instead,

grasp the plug and pull to disconnect.

• When using an extension cord with your

appliance, make sure the extension cord

is correctly wired, and rated for its use.

• The microwave oven should be placed on

a ﬂat stable surface which can hold the

weight of the appliance and the heaviest

of food likely to be cooked inside.

• Do not place any item on top of the oven.

• Do not operate the microwave oven

without the glass tray or roller support in

their proper positions.

• Make sure that the power supply cord is

undamaged and does not run under the

microwave oven or over any hot or sharp

surfaces.

English

-5-

• Do not operate the appliance when

empty. This could damage the oven.

• Do not use the oven to store any items.

• Food surrounded by a membrane, such

as egg yolks, potatoes, chicken livers,

etc. must be pierced several times with a

fork before cooking.

• Do not use metal pans or dishes with

metal handles.

• Never place any item with a metal trim

inside a microwave.

• Always remove twist-ties from any foods

before operating the microwave.

• Some plastics are not suitable for use in

a microwave. Always check the

suitability of any item before use.

• Do not cook in a container with a

restricted opening as they may explode

if heated in a microwave oven.

• Conventional meat or candy

thermometers must not be used in the

oven. Only thermometers that are

speciﬁcally made for microwaves should

be used.

• Microwave utensils should be used only

in accordance with the manufacturer's

instructions.

• Do not attempt to deep-fry foods in this

oven.

• Microwave ovens heat the food in a

container and not the container itself. It

is always necessary to check the

temperature of the food to ensure it is

correctly cooked.

• Do not place the oven where heat,

moisture or high humidity are generated,

or near combustible materials.

Warning: Check the oven for any damage,

such as a misaligned or bent door,

damaged door seals and sealing surface,

broken or loose door hinges & latches and

dents inside the cavity or on the door. If

there is any damage, do not operate the

oven.

• Do not cover or block any openings on

the appliance.

• Do not use solvents or other corrosive

chemicals or vapours for cleaning this

appliance.

• Never leave metal utensils in the

Microwave.

• During use the appliance becomes hot.

Care should be taken to avoid touching

heating elements inside the oven.

Warning: Accessible parts may become hot

during use. Young children should be kept

away.

• Do not use harsh abrasive cleaners or

sharp metal scrapers to clean the oven

door glass since they can scratch the

surface, which may result in shattering of

the glass.

• The temperature of accessible surfaces

may be high when the appliance is

operating.

• This appliance is not intended to be

operated by means of external timer or

separate remote-control system.

• The door or the outer surface may get hot

when the appliance is operating.

• If smoke is observed, switch off or unplug

the appliance and keep the door closed

in order to stiﬂe any ﬂames.

• Always stir food to distribute the heat

evenly and allow it to stand for a few

minutes before consumption.

• Containers used for cooking can become

hot because of heat transferred from the

heated food. Always use oven gloves

when removing items from the oven.

• If steam accumulates inside or around

the outside of the oven door, wipe with a

soft cloth. This may occur when the

microwave oven is operated under high

humidity conditions and in no way

indicates malfunction of the unit.

English

-6-

Safety of others

• This appliance is not intended for use by

persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning

use of the appliance by a person

responsible for their safety.

• Children should be supervised to ensure

that they do not play with the appliance.

• Close supervision is necessary when

any appliance is used by or near

children.

• Never leave an appliance unattended

when in use.

After use

• Switch off and remove the plug from the

power outlet when not in use, before

assembling or disassembling parts,

cleaning or carrying out any

maintenance of the appliance. Never

pull the cord while removing it from the

power outlet.

• Keep children and animals away from

the unit and cord set.

Inspection and repairs

If the supply cord is damaged, it must be

replaced by the manufacturer, its service

agent or similarly qualiﬁed persons in order

to avoid a hazard.

Electrical safety

This product must be earthed.

Always check that the power supply

corresponds to the voltage on the rating

plate

Power plugs must match the outlet. Never

modify the plug in any way. Do not use any

adaptor plugs with earthed (Class l)

appliances. Unmodiﬁed plugs and

matching outlets will reduce the risk of

electric shock.

Never operate an appliance directly below

the socket-outlet it is connected to.

Do not insert any object into the openings

on the outer case.

Extension cables & Class l product

• A 3-core cable must be used as your

appliance is earthed and of Class l

construction.

• Up to 30m (100 ft) can be used without

loss of power.

• If the supply cord is damaged, it must

be replaced by the manufacturer or an

authorised Black & Decker Service

Centre in order to avoid a hazard.

Features (Fig. A)

1 Control panel

2 Turntable shaft

3 Roller support

4 Glass tray

5 Observation window

6 Door

7 Safety interlock system

8 Door release

9 Grill rack

10 Heating element

• Remove all packaging from the

appliance.

• Inspect the oven after unpacking for any

damage such as a misaligned or

damaged door, dents or holes in the

door window and screen, and any dents

in the cavity. If any of these are seen,

DO NOT use the oven.

• Clean the appliance before ﬁrst use.

Assembly (Fig. B)

Warning! Before assembly, make sure that

the appliance is switched off and

unplugged.

• Place the appliance on a ﬂat, even

surface.

• Open the door (6) & place the stem into

the hole in the cavity base. The door is

opened by pressing the door release.

• Place the roller support (3) into the hole

in the cavity.

English

-7-

• Align the glass tray (4) on top of the

roller support.

• Connect the appliance to a suitable

electrical supply.

Setting the Clock

When the microwave oven is connected to

a suitable electrical supply, the oven will

display "0:00".

To set the correct time, for example: To set

8:00 .

1 Press the "CLOCK/PRE-SET"

button. The hour ﬁgures will ﬂash.

2 Press the number buttons "8","0","0" in

order.

3 Press the "CLOCK/PRE-SET"

button to ﬁnish setting the clock. The

time will be shown in the LED display.

Note: If "STOP/CLEAR" button is

pressed or if there is no operation within 1

minute, the oven will revert to its previous

state automatically.

Use (Fig. C)

Press the door release (8) to open the oven

door then place the container onto the

glass tray (4).

Close the door & press the Microwave

button repeatedly until the required power

setting is shown in the LED display.

The Microwave power level can be

adjusted to suit the required cooking

method. There are ﬁve power settings

available. These are:

Enter the required cooking time using the

numbered buttons on the control panel (1).

Note: The maximum microwave cooking

time is 99 minutes and 99 seconds.

Press the "Start / Express Cook"

button to start cooking.

Example: To cook an item at 50% power

for 10 minutes

1 Press the Microwave button three

times so that P50 shows in the LED

2 Press the numeric buttons 1, 0, 0, 0 in

sequence

3 Press the Start / Express Cook

button to start cooking

Note: During Microwave cooking, the

Microwave button can be pressed to

display the current microwave power in the

LED for 3 seconds. After three seconds,

the display will revert to normal.

Note: During cooking, the "CLOCK/PRE-

SET" button can be pressed to show

the current time in the LED for 2-3

seconds. The display will then revert to

normal.

Once cooking has completed, an audible

signal will be heard. Open the door &

remove the cooked food.

Always use oven gloves when removing

items from the oven.

If the door of the oven is opened during

cooking, the microwave oven will automati-

cally stop working. Cooking will continue

after re-closing the door.

If the remaining cooking time is not

required, press the "Stop / Clear"

button to cancel further cooking.

Operating the oven when empty could

damage the oven.

To stop the oven during operation, press

the Stop / Clear button.

STOP

CLEAR

STOP

CLEAR

STOP

CLEAR

START

EXPRESS COOK

START

EXPRESS COOK

Press Microwave once 100%

The LED display will show "P100"

Press Microwave twice 80%

The LED display will show "P 80"

Press Microwave three times 50%

The LED display will show "P 50"

Press Microwave four times 30%

The LED display will show "P 30"

Press Microwave ﬁve times 10%

The LED display will show "P 10"

MICROWAVE

English

-8-

Delayed Cooking:

This appliance can be programmed to start

cooking at a pre-set time.

To do this, ﬁrst select the required program.

Press "CLOCK/PRE-SET" button to

display the current clock. The hour ﬁgures

will ﬂash.

Enter the required start time using the

numeric buttons.

Press the "START/EXPRESS COOK"

button to conﬁrm the setting. The LED will

show the current time.

When the set time coincides with the actual

time shown on the LED, cooking will

commence.

Note: The time set must be between 0:00

and 23:59.

Note: Do not operate the appliance when

empty. This could damage the oven.

Note: If the "STOP/CLEAR" button is

pressed while setting the start time, or if

there is no operation within 1 minute, the

appliance will revert to the previous state

automatically.

Note: The clock must be set before using

Delayed Cooking.

Note: Do not use this feature to defrost

frozen items.

Note: After setting the Microwave to cook at

a later time, pressing the "CLOCK/PRE-

SET" button will cause the pre-set

time to ﬂash in the LED for 2-3 seconds. The

Microwave will then revert to the clock

display.

Express Cooking:

Press the "START/EXPRESS COOK"

button to start cooking for 30 seconds at

100% power. Each additional press will

increase the cooking time by 30 seconds

up to 1 minute 30 seconds. After this, the

cooking time will increase by 1 minute, until

the maximum cooking time of 12 minutes

is reached.

Weight Defrost:

Press the "DEFROST BY W.T."

button. The LED will display "dEF1".

Use the numeric control pad to enter the

weight (in grams) of the item to be

defrosted.

Press the "START/EXPRESS COOK"

button to start defrosting. The defrost time

will count down in the LED.

Example: Defrost 500g of beef:

1 Press the "WEIGHT DEFROST BY W.T."

button. The LED will display

"dEF1".

2 Press 5, 0, 0 in sequence

3 Press the "START/EXPRESS COOK"

button to start defrosting, and the

cooking time will count down.

Note: Weights must be entered in grams

Note: The defrosting weight range is

100g-2000g.

Rapid Defrost:

To defrost food faster, press the "Speed

Defrost button the oven will display

"dEF2".

Use the numeric control pad to enter the

weight (in grams) of the item to be

defrosted.

Press the "START/EXPRESS COOK"

button to start defrosting. The defrost time

will count down in the LED.

Note: The defrosting weight range is

100g-1200g.

STOP

CLEAR

START

EXPRESS COOK

START

EXPRESS COOK

START

EXPRESS COOK

START

EXPRESS COOK

START

EXPRESS COOK

WEIGHT

DEFROST

WEIGHT

DEFROST

English

-9-

To use a programme, ﬁrst press the button

for the required cooking mode. The same

button must then be pressed a number of

times until the weight of the ingredients is

shown. Consult the table above for the

actual number of times to press each

button.

Press the "START/EXPRESS COOK"

button to start cooking.

This Microwave has 9 programmed cooking modes:

Cooking Mode Weight (g) Button LED Display

Press

150 Once 150

A-1 250 Twice 250

Auto Reheat 350 Thrice 350

400 4 times 400

A-2 150 Once 150

Vegetable 350 Twice 350

500 Thrice 500

150 Once 150

A-3 250 Twice 250

Fish 350 Thrice 350

400 4 times 400

450 5 times 450

150 Once 150

A-4 300 Twice 300

Meat 450 Thrice 450

600 4 times 600

A-5 50 (with water 450) Once 50

Pasta 100 (with water 800) Twice 100

150 (with water 1200) Thrice 150

A-6 (about 200) Once 1

Potato (about 400) Twice 2

(about 600) Thrice 3

A-7 1 (about 80) Once 1

Pizza 2 (about 160) Twice 2

3 (about 250) Thrice 3

A-8 500 Once 500

Soup 750 Twice 750

1000 Thrice 1000

A-9 550 Once 550

Porridge 1100 Twice 1100

AUTO

REHEAT

VEGET ABLE

FISH

MEA T

PASTA

POT A T O

PIZZA

SOUP

PORRIDGE

START

EXPRESS COOK

English

-10-

Multi-Cook Mode

A maximum of 2 cooking modes can be

programmed into the Microwave.

Press the button for the required cooking

mode.

Enter the required cooking time using the

numeric keypad.

Press the button for the second cooking

mode.

Enter the required cooking time using the

numeric keypad.

Press the "START/EXPRESS COOK "

button to start cooking.

Example: Cook at 100% power for 10

minutes, then at 80% power for 15

minutes.

1 Press the "MICROWAVE" button

once to choose 100% microwave power

2 Press the numeric keys 1, 0, 0, 0 in

sequence to set the cooking time

3 Press the "MICROWAVE" button

twice to choose 80% microwave power;

4 Press the numeric keys 1, 5, 0, 0 in

sequence to set the cooking time.

5 Press the START/EXPRESS COOK

button to start cooking.

Note: Defrosting must always be carried

out before cooking. If the Microwave is to

be used to defrost ingredients before

cooking, it must be checked to ensure it is

fully defrosted before cooking.

Note: Auto cooking can not work in the

multi-section cooking.

Child Lock

To prevent children operating the Micro-

wave, press & hold the "Stop / Clear"

button for 3 seconds. An audible signal will

be heard and the LED will display.

To turn the child lock off, press the

"STOP/CLEAR" button for 3

seconds. An audible signal will be heard

denoting that the lock is released, and the

LED will turn back to the usual display.

Cooking with the Grill

Press the "GRILL/COMBI." button

once to select the grill function, the LED

will display " " and the “ ” icon will

be displayed in the LED

Use the numeric control pad to enter the

weight (in grams) of the item to be cooked.

Press the "START/EXPRESS COOK"

button to start cooking. The time will count

down in the LED, and the ":" and " "

icons will ﬂash in the LED.

Note: Half-way through the set cooking

time, the oven will pause and an audible

signal will sound twice. Turn the ingredients

over, then press the "START/EXPRESS

COOK" button again to continue

cooking.

• If no buttons are pressed for 1 minute

after the audible signal, the oven will

re-start automatically.

• The maximum cooking time is 100

minutes and 39 seconds

Grill / Combi Cooking:

Two Grill / Combi programmes are

available:

Combination 1 (55% Microwave and 45%

Grill)

• Press the "Grill/Combi" button

twice: The LED display will show " "

and " " icon.

START

EXPRESS COOK

START

EXPRESS COOK

START

EXPRESS COOK

START

EXPRESS COOK

GRILL/

COMBI.

GRILL/

COMBI.

STOP

CLEAR

STOP

CLEAR

MICROWAVE

English

-11-

Combination 2 (36% Microwave and 64%

Grill)

• Press the "Grill/Combi" button

three times: The LED display will show

" " and " " icon.

Enter the required cooking time using the

numeric keypad.

• Press " START/EXPRESS COOK "

button to start cooking. The cooking

time counts down, " : " and " " will

ﬂash.

• The maximum cooking time is 100

minutes and 39 seconds.

Note: During Combination Cooking, the

"Grill / Combi" button can be

pressed to display the Grilling mode in the

LED for 3 seconds. After three seconds,

the display will revert to normal.

Operating times and preparations

Follow directions on food packaging.

Switching on and off

The microwave will start to cook once the

Start / Express Cook button is

pressed.

To stop the oven during operation, press

the Stop / Clear button .

Cleaning and maintenance

The oven should be cleaned regularly and

any food deposits removed

Failure to maintain the oven in a clean

condition could lead to deterioration of the

surface that could adversely affect the life

of the appliance and possibly result in a

hazardous situation

Turn the oven off and disconnect from the

power supply before cleaning.

The outside oven surface & control panel

should be cleaned with a damp cloth.

When cleaning surfaces of door, door seal,

cavity of the oven, use only mild,

non-abrasive soaps, or detergents applied

with a sponge or soft cloth.

The glass tray can be washed in warm

sudsy water or in a dishwasher & dried with

a clean cloth.

The roller support and oven cavity should

be cleaned regularly. The cavity should be

cleaned with a damp cloth & a mild

detergent & dried thoroughly. The roller ring

should be washed in warm sudsy water or

in a dish washer.

Note: To prevent damage to the operating

parts inside the oven, water should not be

allowed to enter the ventilation slots.

Do not use detergents, abrasives or

spray-on cleaners on the control Panel.

Do not allow the Control Panel to become

wet.

START

EXPRESS COOK

START

EXPRESS COOK

GRILL/

COMBI.

GRILL/

COMBI.

STOP

CLEAR

-12-

English

Technical data

MZ3000PG

Rating : 230 - 240V ~50Hz 1450W

Microwave Power Output : 900W

Operation Frequency : 2,450MHz

External Dimensions : 326mm high x 520mm wide x 394mm deep

Cavity Dimensions : 226mm high x 332mm wide x 371mm deep

Oven Capacity : 30 litres

Unit weight : 16.3kg

MZ3000PGSA

Rating : 220V ~ 60Hz 1450W

Microwave Power Output : 900W

Operation Frequency : 2,450MHz

External Dimensions : 326mm high x 520mm wide x 394mm deep

Cavity Dimensions : 226mm high x 332mm wide x 371mm deep

Oven Capacity : 30 litres

Unit weight : 16.3kg

Detergents or abrasives must never be

used.

Odours can be removed from the oven by

combining a cup of water with the juice

and skin of one lemon in a deep microwave

able bowl. Microwave for 5 minutes, and

dry the cavity thoroughly with a soft cloth.

Radio Interference

A microwave oven may interfere with the

normal operation of radio, TV, or similar

equipment. Should such interference

occur, the following steps should be

followed:

• Clean the door and sealing surface of

the oven.

• Place the radio, TV, etc. as far away

from the microwave oven as possible.

• Ensure the antenna ﬁtted to the radio,

TV, etc is correctly ﬁtted & receiving a

strong signal.

• Plug the microwave oven into a different

socket outlet

Hot surface

Caution: Hot surface

Microwave Oven

MZ3000PG - 120V

Please read through this booklet for safe and efﬁcient use of the appliance.

We urge you to read the "Hint's" section and also follow all detailed

instructions even if you are familiar with using this appliance.

Keep this guide handy for future reference.

First Use Safety Recommendation

English Page 02

Arabic Page 27

English

-2-

Fig A

CLE

VEG

PIE

PIZ

POT

POWER

E-

SET

English

-3-

Intended use

Your Black & Decker microwave oven is

designed to heat appropriate foods &

beverages using electromagnetic radiation.

Always check the suitability of ingredients

before cooking.

Do not use this appliance for any other

purpose. This product is intended for

indoor household use only.

Safety instructions

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR

FUTURE REFERENCE

• While using electrical appliances, in

order to reduce the risk of ﬁre, electric

shock, and / or injury to persons, basic

safety precautions should be followed,

including the following:

Warning: If the door or door seals are

damaged, the oven must not be operated

until it has been repaired by a competent

person

Warning: It is hazardous for anyone other

than a competent person to carry out any

service or repair operation that involves the

removal of a cover which gives protection

against exposure to microwave energy

Warning: Liquids and other foods must not

be heated in sealed containers since they

are liable to explode

Warning: Only allow children to use the

oven without supervision when adequate

instructions have been given so that the

child is able to use the oven in a safe way

and understands the hazards of improper

use

Fig B Fig C

Mica plate, Do not remove

STOP

CLEAR

START

+30SEC

FRESH

VEGETABLE

FROZEN

VEGETABLE

DINNER

PLATE

CHICKEN

PIECES

STEAKPIZZAPOPCORN POTATO

WEIGHT

DEFROST

POWER

GRILL/

COMB.

TIME

DEFROST

KITCHEN

TIMER

MEMORY AM/PM

CLOCK

PRE-SET

EXPRESS COOK

English

-4-

• This microwave oven is a free-standing

unit & must not be built-in or placed in a

cabinet.

• The oven must have sufﬁcient air ﬂow.

To ensure good ventilation, a gap of 10

centimetres is required at the back, 15

centimetres at one side, 30 centimetres

at the other side and 30 centimetres

above.

• Only use utensils that are suitable for

use in microwave ovens

• When heating food in plastic or paper

containers, keep an eye on the oven due

to the possibility of ignition

• If smoke is observed, switch off or

unplug the appliance and keep the door

closed in order to stiﬂe any ﬂames

• Microwave heating of beverages can

result in delayed eruptive boiling

therefore care must be taken when

handling the container

• The contents of feeding bottles and

baby food jars shall be stirred or shaken

and the temperature checked before

consumption, in order to avoid burns

• Eggs in their shell and whole hard-boiled

eggs should not be heated in microwave

ovens since they may explode, even

after microwave heating has ended

• The oven should be cleaned regularly

and any food deposits removed

• Failure to maintain the oven in a clean

condition could lead to deterioration of

the surface that could adversely affect

the life of the appliance and possibly

result in a hazardous situation

• To protect against the risk of electric

shock, DO NOT IMMERSE the

appliance, cord set or plug in water or

other liquids.

• Do not remove the feet from this

product.

• Do not cook food directly on the glass

tray. Always use a bowl or other

container that is suitable for use in a

microwave oven

Using your appliance

• Do not operate any appliance with a

damaged cord or plug, or after the

appliance malfunctions, or is dropped or

damaged in any manner. Return the

complete appliance to your nearest

authorised service facility for

examination, electrical repair, mechanical

repair or adjustment to avoid any hazard.

• Do not attempt to repair the appliance

yourself; instead, take it to your Black &

Decker-owned or Authorised Service

Centre for repair.

• The use of attachments or accessories

not recommended or sold by this

appliance manufacturer may result in ﬁre,

electric shock or personal injury.

• Do not let the cord hang over the edge of

a table, counter, or touch hot surfaces.

• Avoid touching hot surfaces, use handles

and knobs.

• Do not operate or place any part of this

appliance on or near any hot surfaces

(such as gas or electric burner or in a

heated oven) or any appliance that

generates steam.

• Do not abuse the cord. Never carry the

appliance by the cord or yank it to

disconnect it from the outlet; instead,

grasp the plug and pull to disconnect.

• When using an extension cord with your

appliance, make sure the extension cord

is correctly wired, and rated for its use.

• The microwave oven should be placed on

a ﬂat stable surface which can hold the

weight of the appliance and the heaviest

of food likely to be cooked inside.

• Do not place any item on top of the oven.

• Do not operate the microwave oven

without the glass tray or roller support in

their proper positions.

• Make sure that the power supply cord is

undamaged and does not run under the

microwave oven or over any hot or sharp

surfaces.

English

-5-

• Do not operate the appliance when

empty. This could damage the oven.

• Do not use the oven to store any items.

• Food surrounded by a membrane, such

as egg yolks, potatoes, chicken livers,

etc. must be pierced several times with a

fork before cooking.

• Do not use metal pans or dishes with

metal handles.

• Never place any item with a metal trim

inside a microwave.

• Always remove twist-ties from any foods

before operating the microwave.

• Some plastics are not suitable for use in

a microwave. Always check the

suitability of any item before use.

• Do not cook in a container with a

restricted opening as they may explode

if heated in a microwave oven.

• Conventional meat or candy

thermometers must not be used in the

oven. Only thermometers that are

speciﬁcally made for microwaves should

be used.

• Microwave utensils should be used only

in accordance with the manufacturer's

instructions.

• Do not attempt to deep-fry foods in this

oven.

• Microwave ovens heat the food in a

container and not the container itself. It

is always necessary to check the

temperature of the food to ensure it is

correctly cooked.

• Do not place the oven where heat,

moisture or high humidity are generated,

or near combustible materials.

Warning: Check the oven for any damage,

such as a misaligned or bent door,

damaged door seals and sealing surface,

broken or loose door hinges & latches and

dents inside the cavity or on the door. If

there is any damage, do not operate the

oven.

• Do not cover or block any openings on

the appliance.

• Do not use solvents or other corrosive

chemicals or vapours for cleaning this

appliance.

• Never leave metal utensils in the

Microwave.

• During use the appliance becomes hot.

Care should be taken to avoid touching

heating elements inside the oven.

Warning: Accessible parts may become hot

during use. Young children should be kept

away.

• Do not use harsh abrasive cleaners or

sharp metal scrapers to clean the oven

door glass since they can scratch the

surface, which may result in shattering of

the glass.

• The temperature of accessible surfaces

may be high when the appliance is

operating.

• This appliance is not intended to be

operated by means of external timer or

separate remote-control system.

• The door or the outer surface may get hot

when the appliance is operating.

• If smoke is observed, switch off or unplug

the appliance and keep the door closed

in order to stiﬂe any ﬂames.

• Always stir food to distribute the heat

evenly and allow it to stand for a few

minutes before consumption.

• Containers used for cooking can become

hot because of heat transferred from the

heated food. Always use oven gloves

when removing items from the oven.

• If steam accumulates inside or around

the outside of the oven door, wipe with a

soft cloth. This may occur when the

microwave oven is operated under high

humidity conditions and in no way

indicates malfunction of the unit.

English

-6-

Safety of others

• This appliance is not intended for use by

persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning

use of the appliance by a person

responsible for their safety.

• Children should be supervised to ensure

that they do not play with the appliance.

• Close supervision is necessary when

any appliance is used by or near

children.

• Never leave an appliance unattended

when in use.

After use

• Switch off and remove the plug from the

power outlet when not in use, before

assembling or disassembling parts,

cleaning or carrying out any

maintenance of the appliance. Never

pull the cord while removing it from the

power outlet.

• Keep children and animals away from

the unit and cord set.

Inspection and repairs

If the supply cord is damaged, it must be

replaced by the manufacturer, its service

agent or similarly qualiﬁed persons in order

to avoid a hazard.

Electrical safety

This product must be earthed.

Always check that the power supply

corresponds to the voltage on the rating

plate

Power plugs must match the outlet. Never

modify the plug in any way. Do not use any

adaptor plugs with earthed (Class l)

appliances. Unmodiﬁed plugs and

matching outlets will reduce the risk of

electric shock.

Never operate an appliance directly below

the socket-outlet it is connected to.

Do not insert any object into the openings

on the outer case.

Extension cables & Class l product

• A 3-core cable must be used as your

appliance is earthed and of Class l

construction.

• Up to 30m (100 ft) can be used without

loss of power.

• If the supply cord is damaged, it must

be replaced by the manufacturer or an

authorised Black & Decker Service

Centre in order to avoid a hazard.

Features (Fig. A)

1 Control panel

2 Turntable shaft

3 Roller support

4 Glass tray

5 Observation window

6 Door

7 Safety interlock system

8 Door release

9 Grill rack

10 Heating element

• Remove all packaging from the

appliance.

• Inspect the oven after unpacking for any

damage such as a misaligned or

damaged door, dents or holes in the

door window and screen, and any dents

in the cavity. If any of these are seen,

DO NOT use the oven.

• Clean the appliance before ﬁrst use.

Assembly (Fig. B)

Warning! Before assembly, make sure that

the appliance is switched off and

unplugged.

• Place the appliance on a ﬂat, even

surface.

• Open the door (6) & place the stem into

the hole in the cavity base. The door is

opened by pressing the door release.

• Place the roller support (3) into the hole

in the cavity.

English

-7-

• Align the glass tray (4) on top of the

roller support.

• Connect the appliance to a suitable

electrical supply.

Setting the Clock

When the microwave oven is connected to

a suitable electrical supply, the oven will

display "0:00".

To set the correct time, for example: To set

8:00 .

1 Press the "Clock/Pre-set" button.

The hour ﬁgures will ﬂash.

2 Press the number buttons "8","0","0" in

order.

3 Press AM/PM as required

4 Press the "Clock/Pre-set" button

to ﬁnish setting the clock. The time will

be shown in the LED display.

Note: If "Stop/Clear" button is

pressed or if there is no operation within 1

minute, the oven will revert to its previous

state automatically.

This appliance also has a handy "Kitchen

Timer" button. This can be operated

as follows:

1 Press " Kitchen Timer" button, the

LED display will show 00:00, and the clock

indicator will be lit.

The ﬁrst "0" will ﬂash, the ":" and the other

"0" will light up.

2 Use the numeric buttons to enter the

required alarm time.

3 Press "Start/+30Sec." button to

conﬁrm the setting. The clock indicator will

light up.

4 When the set time arrives, the clock

indicator will go out and an audible alarm

will be heard.

If the clock has been set previously, the

LED will display the current time.

Use (Fig. C)

Press the door release (8) to open the oven

door then place the container onto the

glass tray (4).

Close the door & press the Microwave

button repeatedly until the required power

setting is shown in the LED display.

Remarks: When a power between level

10-8 is chosen, the high level indicator

will light up and it will ﬂash when in

operation.

When a power between level 7-1 is

chosen, the low level indicator will light

up and it will ﬂash when in operation.

Press the " Power" button until the

LED shows the required power level. " "

and " " or “ " will light up.

Enter the required cooking time using the

numeric buttons.

Note: The maximum cooking time is 99

minutes and 99 seconds.

Press the "Start/+30Sec" button to

start cooking. The cooking time will be

displayed and will count down during

cooking. ":", " ”, and " ", or " "

will ﬂash in the LED display.

Note: In the process of cooking, if the

"Stop/Clear" button is pressed or if

there is no operation within 1 minute, the

oven will go back to the former setting

automatically.

Note: During Microwave cooking or grilling,

the "Power" or "Grill / Combi"

button can be pressed to display the

current microwave power in the LED for 3

seconds. After three seconds, the display

will revert to normal.

AM/PM

CLOCK

PRE-SET

CLOCK

PRE-SET

STOP

CLEAR

STOP

CLEAR

KITCHEN

TIMER

KITCHEN

TIMER

START

+30SEC

START

+30SEC

Level Power Display

1 10% PL1

2 20% PL2

3 30% PL3

4 40% PL4

5 50% PL5

6 60% PL6

7 70% PL7

8 80% PL8

9 90% PL9

10 100% PL10

POWER

GRILL/

COMB.

English

-8-

Note: During cooking, the "Clock/Pre-Set"

button can be pressed to show the

current time in the LED for 2-3 seconds. The

display will then revert to normal.

Once cooking has completed, an audible

signal will be heard. Open the door &

remove the cooked food.

Always use oven gloves when removing

items from the oven.

If the door of the oven is opened during

cooking, the microwave oven will automat-

cally stop working. Cooking will continue

after re-closing the door.

If the remaining cooking time is not required,

press the "Stop / Clear" button to

cancel further cooking.

Operating the oven when empty could

damage the oven.

To stop the oven during operation, press the

Stop / Clear button.

Microwave Cook

1 Keep on pressing “Power” button to

choose microwave power. “ ” and

“ ” or “ ” will be lighted.

2 Press number keys to input the cooking

time; the maximum cooking time is 99

minutes and 99 seconds.

3 Press "Start/+30Sec" to start

cooking, and the remained cooking time

will be displayed. “:” , “ ” , “ ” or “

” indicators will be ﬂashing.

Note: In the process of cooking, if the

"Stop/Clear" button is pressed or if

there is no operation within 1 minute, the

oven will go back to the former setting

automatically.

QuickStart

Use the numeric buttons to enter a cooking

time from 1 to 6 minutes.

Cooking will start automatically at 100%

power.

Pressing the "Start/+30Sec" button

will increase the cooking time, up to a

maximum of 99 minutes and 99 seconds.

If the "Start/+30Sec" button is

pressed without entering a cooking time,

the the Microwave will start cooking at

100% power level for 30 seconds. The

cooking time can be increased by pressing

the "Start/+30Sec" button. Each time

the button is pressed the cooking time will

increase by 30 seconds.

The maximum cooking time is 99 minutes

and 99 seconds.

Note: Each time the "Start/+30Sec"

button is pressed, the cooking time will

increase by 30 seconds for the microwave

and Auto menu cooking. This function will

not work in the "defrost by weight" mode.

Weight Defrost:

Press the "Weight Defrost" button.

"The LED will display "dEF1, " " and

Use the numeric control pad to enter the

weight (in ounces) of the item to be

defrosted.

Press the "Start/+30 Sec" button to

start defrosting. The defrost time will count

down in the LED.

Note: Weights must be entered in ounces

Note: The defrosting weight range is 4 -

100 ounces.

Time Defrost:

Press "Time Defrost" button. The LED

will display "dEF2", " " and " ".

Use the numeric buttons to enter the

required defrost time. The time range is 0

minutes and 1 seconds to 99 minutes 99

seconds.

The default microwave power is power

level 3. To change the power level, press

the "Power" button once. The LED

display will show "PL 3". The required

power level can be selected by pressing

the relevant numeric button.

CLOCK

PRE-SET

STOP

CLEAR

STOP

CLEAR

STOP

CLEAR

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

POWER

WEIGHT

DEFROST

TIME

DEFROST

English

-9-

Press " Start/+30Sec. buttonto start

defrosting. The cooking time count down in

the LED display. ":", " “, " ”, indicators

will ﬂash.

Popcorn - standard mode

Press the "Popcorn" button to select

popcorn mode, " ", " " and "Oz" will

light up.

There are three weights programmed into

the Oven. These can be accessed by

repeatedly pressing the "Popcorn"

button. The weights available are:

"1.75 ounces","3.0 ounces" and "3.5

ounces."

Press the " Start/+30Sec." button to

start cooking. An audible signal will be

heard. The "Oz" symbol will go out, and

and " " will ﬂash.

When the cooking is completed, another

audible signal will be heard and the LED will

display "0:00".

If the clock is set, the LED will display the

current time.

Popcorn - Time Set mode

The pre-set cooking times for "Popcorn"

button can be changed.

Press the "Popcorn" button to select

popcorn mode, " ", " " and "Oz" will

light up. Depending on the number of times

the "Popcorn" button is pressed, "1.75"

,"3.0", or "3.5" will appear in the LED.

Press the " Memory " button. The LED

will display the cooking time for the selected

weight. The selected cooking time will ﬂash.

Use the numeric buttons to enter the

required cooking time.

Press " Memory " button to save the

setting.

Note: If the " Start/+30Sec" button is

pressed, the oven will to cook with the

amended cooking time. " ", " " will

ﬂash in the display.

To restore the factory set ﬁgures, press &

hold the "Popcorn" button until an

audible signal is heard.

Potato

Press the "Potato" button repeatedly

until the number of potatoes to be cooked

appears in the display. The " " and " "

symbols will show in the display.

1 potato (approximate 230 gram)

2 potatoes (approximate 460 gram)

3 potatoes (approximate 690 gram)

Press the " Start/+30Sec." button to

start cooking, The " " and " "

symbols will ﬂash in the display and the

timer will count down.

Pizza

Press the "Pizza" button repeatedly

until the required number of slices appears

in the display. The " " and " "

symbols will show in the display.

You can reheat 1 - 3 slices of Pizza each

time.

Press " Start/+30Sec." button to cook,

" " and " " will ﬂash in the display &

the timer will count down.

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

POPCORN

PIZZA

POPCORN

POTATO

MEMORY

Times (press “Pizza”) Weight Display

1 3.0 Oz

2 6.0 Oz

3 9.0 Oz

Times (press “Potato”) Weight Display

1 1set

2 2set

3 3set

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

English

-10-

Steak

Press the "Steak" button repeatedly

until the required weight appears in the

display. The " ", " ", “ ” and "Oz"

symbols will show in the display.

Press the "Start/+30 Sec." button to

cook. The " ", " ", " " will ﬂash in

the display & the cooking time will count

down.

Chicken Pieces

Press the "Chicken Pieces" button

repeatedly until the required weight appears

in the display. The " ", " ", " " and

"Oz" will be shown in the display.

Press the "Start/+30 Sec." button to

start cooking. The " ", " ", " " will

ﬂash in the display & the cooking time will

count down.

Dinner Plate

Press the "Dinner Plate" button

repeatedly until the required weight appears

in the display. The " ", " ", and "Oz"

will show in the display.

Press the "Start/+30 Sec." button to

start cooking. The " ", " " will ﬂash in

the display & the cooking time will count

down.

Fresh Vegetable

Press the "Fresh Vegetable" button

repeatedly until the required weight

appears in the display. The " ", " "

and "Oz" will show in the display.

Press the "Start/+30 Sec." button to

start cooking. The " ", " " will ﬂash in

the display & the cooking time will count

down.

Frozen Vegetables

Press the "Frozen Vegetables" button

repeatedly until the required weight

appears in the display. The " ", " "

and "Oz" will show in the display.

Press the "Start/+30 Sec." button to

start cooking. The " ", " " will ﬂash

in the display & the cooking time will count

down.

Grill

Press the "Grill/Combi." button once

to choose the grill function. The LED will

display "G-1" and " ".

Enter the required cooking time using the

numeric keypad.

The maximum cooking time is 99 minutes

and 99 seconds.

Press the "Start/+30 Sec." button to

start cooking. The cooking time will count

down. ":" and " " will ﬂash in the display.

Note: After half the grilling time has

elapsed, the oven will pause and an

audible signal will be heard. The ingredi-

ents should now be turned over for even

cooking.

FROZEN

VEGETABLE

FRESH

VEGETABLE

FRESH

VEGETABLE

FROZEN

VEGETABLE

DINNER

PLATE

DINNER

PLATE

CHICKEN

PIECES

CHICKEN

PIECES

STEAKSTEAK

GRILL/

COMB.

Times (press “Steak”) Weight Display

1 4.0 Oz

2 8.0 Oz

3 16.0 Oz

Times Weight Display

(press “Chicken Pieces”)

1 4.0 Oz

2 8.0 Oz

3 12.0 Oz

4 16.0 Oz

Times Weight Display

(press “Dinner Plate”)

1 9.0 Oz

2 12.0 Oz

3 18.0 Oz

Times Weight Display

(press “Fresh Vegetable”)

1 4.0 Oz

2 8.0 Oz

3 16.0 Oz

Times Weight Display

(press “Frozen Vegetable”)

1 4.0 Oz

2 8.0 Oz

3 16.0 Oz

English

-11-

Pressing the "Start/+30 Sec." button

will continue cooking. If no button is

pressed within 1 minute of the signal, the

oven will continue working and the audible

signal will be heard again.

Combination Cooking (Microwave &

Grill)

Press the "Grill/Combi." button twice

or three times to select:

Combination 1 (55%microwave+45%grill)

Combination 2 (36%microwave+64%grill)

The LED will display "C-1" or "C-2", " "

and " ".

Enter the required cooking time using the

numeric keypad.

The maximum cooking time is 99 minutes

and 99 seconds.

Press the "Start/+30 Sec." button to

start cooking. The cooking time will count

down and the display will show ":", " "

and " ".

Multi-stage cooking

A maximum of 2 stages can be set for

cooking.

In multi-stage cooking, if one stage is

weight defrosting, this must be carried out

ﬁrst.

Note: Auto cooking cannot work in the

multi-stage cooking.

Example: if you want to cook with 80%

microwave power for 5 minutes + 60%

microwave power for 10 minutes. The

cooking steps are as follows:

Press the "Power" button repeatedly

until "PL8" (80% microwave power) is

displayed;

Press the number keys "5","0","0" to set

the cooking time;

Press the "Power" button repeatedly

until "PL6" (60% microwave power) is

displayed;

Press the number keys "1","0","0","0" to

set the cooking time;

Press "Start/ +30 Sec." button to

start cooking.

Pre-set Function

This Microwave can be programmed to

begin cooking at a pre-set time.

Select the required cooking mode & enter

the details for the ingredients to be

cooked.

Note: Defrosting is beyond pre-set

cooking.

Press the "Clock/Pre-Set" button to

display the current time. The hour ﬁgure

will ﬂash.

The display will show ":" and "0".

Enter the required start time using the

numeric keypad.

Select "AM or PM" by pressing the

AM / PM button repeatedly.

Press the "Start/+30 Sec." button to

conﬁrm the preset procedure. The display

will show the current time.

When the set time arrives, the Microwave

will operate as programmed.

Note: The clock must be set correctly

before using this function.

Memory Function

This Microwave has 5 programmable

memories.

Press the "Memory" button repeat-

edly to select the required programme. The

oven will display "1", to "5" as required.

Enter the one or two stages program

required.

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

MEMORY

POWER

GRILL/

COMB.

AM/PM

CLOCK

PRE-SET

English

-12-

For example : Press "Power" button

six times, to adjust the initial cooking power.

The oven will display "PL5".

Press the numeric buttons "5","0","0" to

enter a cooking time of 5 minutes.

Press the "Power" button once to

select full power. The oven will display

"PL10".

Press the numeric buttons "1","0","0","0" to

enter the remaining cooking time.

Press the "Memory" button key to

save the memory program, or press

"Start/+30 Sec." button to start

cooking and save the program automati-

cally.

The cooking method is now stored & can be

accessed by pressing the "Memory"

button, the number of the required program

then "Start/+30Sec." button to start

cooking.

Child Lock

To prevent children operating the Micro-

wave, press & hold the "Stop / Clear"

button for 3 seconds. An audible signal will

be heard and the LED will display.

To turn the child lock off, press the

"Stop/Clear" button for 3 seconds. An

audible signal will be heard denoting that

the lock is released, and the LED will turn

back to the usual display.

Operating times and preparations

Follow directions on food packaging.

Switching on and off

The microwave will start to cook once the

Start/+30 Sec button is pressed.

To stop the oven during operation, press

the Stop / Clear button .

Cleaning and maintenance

The oven should be cleaned regularly and

any food deposits removed

Failure to maintain the oven in a clean

condition could lead to deterioration of the

surface that could adversely affect the life

of the appliance and possibly result in a

hazardous situation

Turn the oven off and disconnect from the

power supply before cleaning.

The outside oven surface & control panel

should be cleaned with a damp cloth.

When cleaning surfaces of door, door seal,

cavity of the oven, use only mild,

non-abrasive soaps, or detergents applied

with a sponge or soft cloth.

The glass tray can be washed in warm

sudsy water or in a dishwasher & dried

with a clean cloth.

The roller support and oven cavity should

be cleaned regularly. The cavity should be

cleaned with a damp cloth & a mild

detergent & dried thoroughly. The roller

ring should be washed in warm sudsy

water or in a dish washer.

Note: To prevent damage to the operating

parts inside the oven, water should not be

allowed to enter the ventilation slots.

Do not use detergents, abrasives or

spray-on cleaners on the control Panel.

Do not allow the Control Panel to become

wet.

START

+30SEC

START

+30SEC

START

+30SEC

MEMORY

POWER

STOP

CLEAR

STOP

CLEAR

STOP

CLEAR

-13-

English

Technical data

MZ3000PG-B4

Rating : 120V ~60Hz 1500W

Microwave Power Output : 1000W

Operation Frequency : 2,450Hz

External Dimensions : 520mm high x 430mm wide x 335mm deep

Cavity Dimensions : 226mm high x 332mm wide x 371mm deep

Oven Capacity : 28 litres

Unit weight : 15.3kg

Detergents or abrasives must never be

used.

Odours can be removed from the oven by

combining a cup of water with the juice

and skin of one lemon in a deep microwave

able bowl. Microwave for 5 minutes, and

dry the cavity thoroughly with a soft cloth.

Radio Interference

A microwave oven may interfere with the

normal operation of radio, TV, or similar

equipment. Should such interference

occur, the following steps should be

followed:

• Clean the door and sealing surface of

the oven.

• Place the radio, TV, etc. as far away

from the microwave oven as possible.

• Ensure the antenna ﬁtted to the radio,

TV, etc is correctly ﬁtted & receiving a

strong signal.

• Plug the microwave oven into a different

socket outlet

Hot surface

Caution: Hot surface

-14-

English

Black & Decker provides a 2 Year Warranty for this product from the date of purchase against

defects due to defective materials or workmanship. Motor/element burn-outs due to voltage

ﬂuctuations are not covered under warranty. If the product should become defective within the

warranty period, Black & Decker will repair or (at Black & Decker's discretion) replace it free of

charge.

The warranty provisions do not cover failure due to accident, misuse, abuse, negligence or non

observation of local regulations on the part of the user. Equally, the warranty provisions do not

apply where the appliance has been serviced by a person not authorized by Black & Decker or

serviced with non-approved parts and this has contributed to the fault of the product.

Superseded models without a replacement equivalent will either be repaired or (at Black &

Decker's discretion) replaced with another product of similar retail value.

UPON PURCHASE

Fill in the Warranty Registration Card with the original Authorized Dealer's stamp (indicating

date of purchase) and attach your purchase receipt to it. Retain in case of claims in the future.

MAKING A CLAIM

Take your defective product together with the Warranty Registration Card & purchase receipt to

your local service Centre. You can either do this in person or send it freight prepaid. If mailing

or shipping your appliance, ensure that it is packed carefully in a sturdy carton with enough

packing material to prevent damage. Include a note describing the problem to the service

Centre and be sure to give your return address.

DESIGNED FOR DOMESTIC PURPOSES ONLY.

BLACK & DECKER HOME APPLIANCE 2 YEAR WARRANTY

Protecting the environment

Separate collection. This product must not be disposed of with normal household waste.

Should you ﬁnd one day that your Black & Decker product needs replacement, or if it is of no

further use to you, do not dispose it off with other household waste. Make this product

available for separate collection.

Separate collection of used products and packaging allows materials to be recycled and

used again. Use of recycled materials helps prevent environmental pollution and reduces

the demand for raw materials.

Local regulations may provide for separate collection of electrical products from the household,

at municipal waste sites or by the retailer when you purchase a new product.

Black & Decker provides a facility for the collection and recycling of Black & Decker products

once they have reached the end of their working life. To take advantage of this service please

return your product to any authorised repair agent who will collect them on our behalf. You can

check the location of your nearest authorised repair agent by contacting your local Black &

Decker ofﬁce at the address indicated in this manual. A list of authorised Black & Decker repair

agents and full details of our after-sales service and contact are available on the Internet at:

www.2helpU.com

Arabic

-51-

¢LM` {LU≤UÎ ®U±öÎ ±b¢t ßM∑Os ∞Nc« «∞LM∑Z «´∑∂U¸«Î ±s ¢U¸¥a «∞Ad«¡.

¥GDw «∞CLUÊ ´Ou» «∞∑BMOl √Ë «∞Lu«œ «∞b«îKW ≠w «∞∑BMOl. Ë≠w •U∞W ≈ÅU°W «∞LM∑Z °QÍ ´Dq √£MU¡ ≠∑d… «∞CLUÊ, ß∑IuÂ ®dØW

°SÅö•t √Ë (Ë≠IUÎ ∞∑Ib¥d ) «ß∑∂b«∞t ±πU≤UÎ.

ô ¥GDw «∞CLUÊ «_´DU‰ «∞MU¢πW ´s «∞∫u«œÀ, ßu¡ «ôß∑FLU‰, «ù≥LU‰, «ôß∑FLU‰ «∞ªU©T, √Ë ´bÂ «¢∂UŸ «∞MEr «∞LFLu‰ °NU ±∫KOUÎ.

Øc∞p, ô ¢MD∂o ®dË

◊ «∞CLUÊ ≈–« ¢LX ÅOU≤W √Ë ¢BKO` «∞LM∑Z ∞bÈ ©d· ¨Od ±F∑Lb ±s Æ∂q ®dØW , √ Ë ≠w •U∞W «ß

∑ªb«Â ÆDl ¨OU¸ °bËÊ «∞d§uŸ ≈∞v «∞AdØW √Ë «∞∫Bu‰ ´Kv ±u«≠I∑NU, Ë¢º∂∂X ≥cÁ «∞IDl ≠w «∞FDq. Ë≈–« ¢uÆn ≈≤∑UÃ √Í ©d«“ ±l ´bÂ

Ë§uœ «∞∂b¥q «∞LMUßV, ≠SÊ ∞AdØW •o «î∑OU¸ ≈ÅöÕ «∞LM∑Z √Ë «ß∑∂b«∞t °Dd«“ ¬îd °MHf «∞IOLW «∞Ad«zOW.

´Mb «∞Ad«¡

«±ú °DUÆW ¢ºπOq «∞CLUÊ ±l «∞∑QØb ±s Ë§uœ «∞ª∑r «_ÅKw ∞K

∑U§d «∞LF∑Lb (Ë¢u{O` ¢U¸¥a «∞Ad«¡) £r «¸≠o ≈¥BU‰ «∞Ad«¡ °U∞∂DUÆW.

«∞d§U¡ «ô•∑HUÿ °NLU ù°d«“≥LU ≠w •U∞W Ë§uœ ±DU∞∂U‹ ≠w «∞Lº∑I∂q.

´LKOW «∞LDU∞∂W

îc «∞LM∑Z «∞LFDq ±l °DUÆW «∞CLUÊ Ë≈¥BU‰ «∞Ad«¡ °MHºp ≈∞v ±dØe «∞BOU≤W «∞L∫Kw √Ë ¥LJMp ≈¸ßU∞t °U∞∂d¥b «∞Lb≠u´W √§d¢t ßKHUÎ.

Ë≠w •U∞W ≈¸ßU‰ «∞πNU“ °U∞∂d¥b √Ë «∞A∫s, ¢QØb ±s ¢Hd¥m «∞LM∑Z ±s «

∞LU¡ ØKOUÎ ËÆr °∑GKOHt §Ob«Î ≠w ÅMbË‚ Ød¢uÊ ±IuÈ ±l ≈{U≠W

±u«œ ¢GKOn ∞LKv¡ «∞Hd«¨U‹ ∞∑HUœÍ ≈ÅU°∑t °QÍ {d¸. «¸≠o ±ö•EW ¢Bn ≠ONU «∞LAJKW ∞LdØe «∞BOU≤W Ë¢QØb ±s Ø∑U°W ´Mu«≤p.

ÅÔLr ∞öß∑FLUô‹ «∞LMe∞OW ≠Ij.

Black & Decker

{LUÊ ®U±q ∞Lb… ßM∑Os _§Ne… «∞LMe∞OW

BLACK & DECKER

•LU¥W «∞∂OµW

¥πV ´bÂ «∞∑ªKh ±s ≥c« «∞LM∑Z ±l °IOW «∞MHU¥U‹ «∞LMe∞OW.

≈–« Ë§b‹ ≠w ¥uÂ ±s «_¥UÂ √≤p °∫U§W ∞Ad«¡ §NU“ °ö„ √≤b œ¥Jd §b¥b, √Ë ∞r ¢Fb °∫U§W ∞KπNU“ «∞Ib¥r, ô ¢∑ªKh ±Mt ±l «∞

MHU¥U‹ «∞LMe∞OW «_îdÈ. §Ne ≥c« «∞LM∑Z ∞ûß∑öÂ «∞LMHBq.

«ùß∑öÂ «∞LMHBq ∞KLM∑πU‹ «∞Lº∑FLKW Ë±u«œ «∞∑GKOn ¥ºL` °S´Uœ… ¢BMOl «∞Lu«œ Ë«ß∑FLU∞NU ±s §b¥b. ≈ß∑FLU‰ «∞

Lu«œ «∞LFUœ ¢BMOFNU ¥ºU´b ´Kv ±Ml «∞∑KuÀ «∞∂Oµw Ë¥IKq «∞DKV ´Kv «∞Lu«œ «_Ë

∞OW.

«_≤ELW «∞L∫KOW Æb ¢Mh ´Kv {dË¸… «ùß∑öÂ «∞LMHBq ∞KLM∑πU‹ «∞JNd°UzOW ±s «∞LMU“‰, ≠w ±u«Æl «∞∂Kb¥W ∞KMHU¥U‹ √Ë °u«ßDW

°Uzl «∞∑πezW ´Mb±U ¢A∑dÍ ±M∑πUÎ §b¥b«Î.

¢u≠d °ö„ √≤b œ¥Jd «∞∑ºNOö‹ ôß∑öÂ Ë≈´Uœ… ¢BMOl ±M∑πU‹ °ö„ √≤b œ¥Jd ´Mb±U ¢Bq ≈∞v ≤NU¥W •OU¢NU «∞FLKOW. ∞ûß∑HUœ…

±s ≥cÁ «∞ªb±W, ¥d§v ≈´Uœ… §NU“„ ≈∞v √Í ËØOq ¢BKO` ±F∑Lb Ë«∞cÍ ßOIuÂ °Uß∑ö±t °U∞MOU°W ´MU. ¥LJMp ±Fd≠W ±uÆl √Æd»

ËØOq ¢BKO` ±F∑Lb °U∞Mº∂W ∞p °Ld«§FW ±J∑V °ö„ √≤b œ¥Jd «∞L∫Kw ´Kv «∞FMu«Ê «∞L∂Os ≠w ≥c« «∞J∑OV. ¢∑u≠d ÆUzLW °QßLU¡

ËØö¡ «∞∑BKO` «∞LF∑Lb¥s ±s °ö„ Ë œ¥Jd, ØLU ¢∑u≠d ¢HUÅOq ØU±KW ´s îb±U‹ ±U °Fb «∞∂Ol Ë´MUË¥s «ô¢BU‰ ´Kv ®∂JW «ù≤∑d

≤X : moc.Upleh2.www

Arabic

-61-

.É

≤∏£e á£°TÉµdG OGƒªdG hCG äÉØ¶æªdG ΩGóîà°SG ΩóY ø«©àj

™°Vh ∫É∏N øe ¿ôØdG πNGO IOƒLƒªdG íFGhôdG øe ¢ü∏îàdG øµªj

¬«dEG É

aÉ°†e AÉe Üƒc É¡H ∞jhhôµ«ª∏d áÑ°SÉæe á≤«ªY á«fÉ£∏°S

π«¨°ûJ ºK ,∞jhhôµ«ªdG ¿ôa πNGO É¡Jô°ûbh IóMGh áfƒª«d ô«°üY

ΩGóîà°SÉH πeÉµdÉH ∞jƒéàdG ∞«ØéJ ºK ,≥FÉbO 5 Ióªd ¿ôØdG

.á∏∏Ñe ¢TÉªb á©£b

ƒjOGôdG äÉLƒe ™e πNGóàdG

hCG ƒjOGô∏d …OÉ©dG π«¨°ûàdG ™e ∞jhhôµ«ªdG ¿ôa πªY πNGóàj ób

,πNGóàdG Gòg ´ƒbh ádÉM »ah .á¡HÉ°ûªdG Iõ¡LCÉdG hCG ¿ƒjõØ∏àdG

:á«dÉàdG äGƒ£îdG ´ÉÑJG »¨Ñæj

.∞jhhôµ«ªdG ¿ôa ≥∏¨j …òdG í£°ùdGh ÜÉÑdG ∞«¶æJ •

ó©HCG »a á¡HÉ°ûªdG Iõ¡LCÉdGh ¿ƒjõØ∏àdG hCG ƒjOGôdG ™°Vh •

.∞jhhôµ«ªdG ¿ôa øY øµªe ¿Éµe

¿ƒjõØ∏àdG hCG ƒjOGôdG »a âÑãªdG »FGƒ¡dG ¿CG øe ócCÉàdG •

.ájƒb IQÉ°TE

G πÑ≤à°ùjh í«ë°U ƒëf ≈∏Y âÑãe

.∞∏àîe QÉ«J Qó°üe »a ∞jhhôµ«ªdG ¿ôa ¢ùHÉb â«ÑãJ •

øNÉ°S í£°S

Caution: Hot surface

á«æØdG äÉfÉ«ÑdG

MZ3000PG-B4

äGh 1500 ,õJôg 60 ,âdƒa 120 : ∞«æ°üàdG

äGh 1000 : ∞jhhôµ«ªdG ábÉW êôN

õJôg 2450 : π«¨°ûàdG OOôJ

(≥ª©dG × ¢Vô©dG × ´ÉØJQÉdG) º∏e 335 × º∏e 430 × º∏e 520 : á«LQÉîdG OÉ©HCÉdG

(≥ª©dG × ¢Vô©dG × ´ÉØJQÉdG) º∏e 371 × º∏e 332 × º∏e 226 : ¿ôØdG ∞jƒéJ OÉ©HCG

ôàd 28 : ¿ôØdG á©°S

ºéc 15^3 : IóMƒdG ¿Rh

Arabic

-71-

"IôcGòdG" QõdG ≈∏Y §¨°VG :∫ÉãªdG π«Ñ°S ≈∏Y ,äGôe â°S

."PL5" ¿ôØdG ¢Vô©j ±ƒ°S .á«dhCÉdG »¡£dG ábÉW §Ñ°†d

»¡W âbh ∫ÉNOEÉd "0" ,"0" ,"5" á«ªbôdG QGQRCÉdG ≈∏Y §¨°VG

.≥FÉbO 5 √Qób

"IôcGòdG" QõdG ≈∏Y §¨°VG ábÉ£dG ójóëàd IóMGh Iôe

."PL10" ¿ôØdG ¢Vô©j ±ƒ°S .á∏eÉµdG

âbh ∫ÉNOEÉd "0" ,"0" ,"0" ,"1" á«ªbôdG QGQRCÉdG ≈∏Y §¨°VG

.»≤ÑàªdG »¡£dG

"IôcGòdG" QõdG ≈∏Y §¨°VG hCG ,IôcGòdG èeÉfôH ßØëd

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG ßØMh »¡£dG AóÑd

.É

«FÉ≤∏J èeÉfôÑdG

§¨°†dG

∫É∏N øe É¡«dEG ∫ƒ°UƒdG øµªjh ¿BÉdG áfõîe »¡£dG á≤jôW

"IôcGòdG" QõdG ≈∏Y §¨°†dG ºK ,Üƒ∏£ªdG èeÉfôÑdG ºbQh

"á«fÉK 30+/CGóHG" QõdG ≈∏Y.»¡£dG AóÑd

∫ÉØWCÉdG øe ájÉªëdG πØb

QGôªà°SÉdG ™e §¨°VG ,∞jhhôµ«ªdG ¿ôa π«¨°ûJ øe ∫ÉØWCÉdG ™æªd

"í°ùe/±É≤jEG" QõdG ≈∏Y ´Éª°S ºàj ±ƒ°S .¿GƒK 3 Ióªd

:LED á°TÉ°T ¢Vô©J ±ƒ°Sh áYƒª°ùe á«Jƒ°U IQÉ°TEG

QõdG ≈∏Y §¨°VG ,∫ÉØWCÉdG øe ájÉªëdG πØb Iõ«e π«¨°ûJ ±É≤jEÉd

" í°ùe/±É≤jEG" IQÉ°TEG ´Éª°S ºàj ±ƒ°S .¿GƒK 3 Ióªd

.OÉà©ªdG ¢Vô©dG ≈dEG LED á°TÉ°T Oƒ©J ±ƒ°Sh áYƒª°ùe á«Jƒ°U

π«¨°ûàdG äÉbhCGh äGOGóYEG

.áª©WCÉdG äGƒÑY ≈∏Y áë°VƒªdG äÉª«∏©àdG ™ÑJG

π«¨°ûàdG ±É≤jEGh π«¨°ûàdG

QõdG ≈∏Y §¨°†dG OôéªH »¡£dG »a

∞jhhôµ«ªdG CGóÑj ±ƒ°S

"á«fÉK 30+/CGóHG".

"í°ùe/±É≤jEG" QõdG ≈∏Y §¨°VG ,π«¨°ûàdG AÉæKCG ¿ôØdG ±É≤jEÉd

áfÉ«°üdGh ∞«¶æàdG

hCG ΩÉ©W äÉØ∏îe ájCG ádGREGh …QhO πµ°ûH ¿ôØdG ∞«¶æJ »¨Ñæj

.Ö°SGhQ

ádÉM QƒgóJ ≈dEG áØ«¶f ádÉM »a ¿ôØdG ≈∏Y ®ÉØëdG ΩóY …ODƒj ób

πµ°ûj ¿CG πªàëjh RÉ¡édG ôªY ≈∏Y

ÉÑ∏°S ôKDƒj ób Éªe ;í£°ùdG

πÑb »FÉHô¡µdG QÉ«àdG øY ¬∏°üah ¿ôØdG π«¨°ûJ ±É≤jEG Ωõ∏jh .G

ô£N

.¬Ø«¶æJ

ΩGóîà°SÉH ºµëàdG áMƒdh »LQÉîdG ¿ôØdG í£°S ∞«¶æJ »¨Ñæj Éªc

hCG ÜÉÑdG πØb hCG ÜÉÑdG í£°SCG ∞«¶æJ óæY Ωõ∏jh .á∏∏Ñe ¢TÉªb á©£b

äÉØ¶æªdG hCG ¿ƒHÉ°üdG ΩGóîà°SG

≈∏Y QÉ°üàbÉdG ¿ôØdG ∞jƒéJ

á©£b hCG áéæØ°SEG ΩGóîà°SÉH ∂dPh §≤a á£°TÉµdG ô«Z áØ«ØîdG

±É°†e ÅaGO AÉªH á«LÉLõdG á«æ«°üdG π°ùZ øµªjh .áªYÉf ¢TÉªb

.áØ«¶f ¢TÉªb á©£≤H É¡Ø«ØéJh ¥ÉÑWCÉdG ádÉ°ùZ »a hCG ¿ƒHÉ°U ¬«dEG

å«M ;É

jQhO ∞jhhôµ«ªdG ∞jƒéJh IQGhódG áeÉYódG ∞«¶æJ »¨Ñæjh

¬Ø«ØéJh ∞«ØN ∞¶æeh á∏∏Ñe ¢TÉªb á©£≤H ∞jƒéàdG ∞«¶æJ »¨Ñæj

¬«dEG ±É°†ªdG AÉªdÉH IQGhódG IôµÑdG á≤∏M π°ùZ »¨Ñæjh .πeÉµdÉH

.¥ÉÑWCÉdG ádÉ°ùZ »a hCG ¿ƒHÉ°üdG

»¨Ñæj ,¿ôØdG πNGO π«¨°ûàdG AGõLCG ∞∏J ¿hO ádƒ∏«ë∏d :á¶MÉ∏e

.ájƒ¡àdG äÉëàa ≈dEG √É«ªdG ∫ƒNóH ìÉª°ùdG ΩóY

¢TôJ »àdG äÉØ¶æªdG hCG á£°TÉµdG OGƒªdG hCG äÉØ¶æªdG Ωóîà°ùJ Éd

.ºµëàdG áMƒd ∞«¶æàd

.ºµëàdG áMƒd ∫ƒ£j π∏ÑdG ´óJ Éd

START

+30SEC

START

+30SEC

START

+30SEC

MEMORY

POWER

STOP

CLEAR

STOP

CLEAR

STOP

CLEAR

Arabic

-81-

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°†dG …ODƒj ±ÉæÄà°SG ≈dEG

øe IóMGh á≤«bO ∫É∏N QR …CG ≈∏Y §¨°†dG ΩóY ádÉM »a .»¡£dG

.iôNCG Iôe áYƒª°ùe

:(IGƒ°ûªdGh ∞jhhôµ«ªdG) ÖcôªdG ƒ¡£dG

"Öcôe ƒ¡W/IGƒ°ûªdG" QõdG ≈∏Y §¨°VG çÉ∏K hCG ø«Jôe

:ójóëàd äGôe

(IGƒ°ûe %45 + ∞jhhôµ«e %55) 1 ƒ¡£dG Öcôe

hCG

(IGƒ°ûe %64 + ∞jhhôµ«e %36) 2 ƒ¡£dG Öcôe

"h."

.á«ªbôdG ºµëàdG áMƒd ΩGóîà°SÉH Üƒ∏£ªdG »¡£dG âbh πNOCG

.á«fÉK 99h á≤«bO 99 ƒg »¡£∏d âbh ≈°übCG

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG ±ƒ°S .»¡£dG AóÑd

h ":" "h "."

.»¡£∏d ≈°übCG óëc »¡W »à∏Môe áéeôH øµªj

á∏MôªdG √òg AGôLEG Öéj ¬fEÉa ,"¿RƒdG Ö°ùM ó«ªéàdG áHGPEG"

ÉdhCG

.πMGôªdG

%80 ÉgQób ∞jhhôµ«e ábÉ£H »¡£dG »a áÑZôdG ádÉM »a :∫Éãe

¿EÉa ,≥FÉbO 10 Ióªd %60 ÉgQób ∞jhhôµ«e ábÉW + ≥FÉbO 5 Ióªd

:»dÉàdG ƒëædG ≈∏Y ¿ƒµJ »¡£dG πMGôe

"ábÉ£dG" QR ≈∏Y §¨°VG ¢VôY ≈àM Qôµàe πµ°ûH

.(%80 ÉgQób ∞jhhôµ«e ábÉW) "PL8"

âbh §Ñ°†d "0" ,"0" ,"5" á«ªbôdG í«JÉØªdG ≈∏

Y §¨°VG

.»¡£dG

"ábÉ£dG" QR ≈∏Y §¨°VG "PL6" ¢VôY ≈àM Qôµàe πµ°ûH

.(%60 ÉgQób ∞jhhôµ«e ábÉW)

âbh §Ñ°†d "0" ,"0" ,"0" ,"1" á«ªbôdG í«JÉØªdG ≈∏Y §¨°VG

.»¡£dG

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°V.»¡£dG AóÑd

≥Ñ°ùªdG §Ñ°†dG áØ«Xh

•ƒÑ°†e âbƒd É

≤ah »¡£dG AóÑd Gòg ∞jhhôµ«ªdG ¿ôa áéeôH øµªj

.É

≤Ñ°ùe

Üƒ∏£ªdG äÉfƒµªdG π«°UÉØJ πNOCGh Üƒ∏£ªdG »¡£dG ™°Vh OóM

.É¡«¡W

.É

.áYÉ°ùdG ΩÉbQCG ¢†eƒJ ±ƒ°S .»dÉëdG

.á«ªbôdG í«JÉØªdG áMƒd ΩGóîà°SÉH Üƒ∏

£ªdG AóÑdG âbh πNOCG

QõdG ≈∏Y §¨°†dG ∫É∏N øe "PM" hCG "AM" OóM

AÉ°ùe/É

MÉÑ°U".Qôµàe πµ°ûH

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG §Ñ°†dG AGôLEG ó«cCÉàd

™°Vƒ∏d É

.èeôÑªdG

√òg ΩGóîà°SG πÑb í«ë°U πµ°ûH áYÉ°ùdG §Ñ°V Öéj :á¶MÉ∏e

.áØ«XƒdG

IôcGòdG áØ«Xh

.áéeôÑ∏d á∏HÉb IôcGP ´GƒfCG á°ùªN ≈∏Y Gòg ∞jhhôµ«ªdG ¿ôa πªà°ûj

" IôcGòdG" QõdG ≈∏Y §¨°VG èeÉfôÑdG ójóëàd Qôµàe πµ°ûH

.Üƒ∏£ªdG Ö°ùM "5" ≈dEG "1"

.Üƒ∏£ªdG ø«à∏MôªdG èeÉfôH hCG á∏MôªdG èeÉfôH πNOCG

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

MEMORY

POWER

GRILL/

COMB.

AM/PM

CLOCK

PRE-SET

Arabic

-91-

Ωƒë∏dG

"Ωƒë∏dG" QR ≈∏Y §¨°VG Qƒ¡X ≈àM Qôµàe πµ°ûH

" RƒeôdG ¢VôY ºàj ±ƒ°S .á°TÉ°ûdG ≈∏Y Üƒ∏£ªdG ¿RƒdG h "

" " h".á°TÉ°ûdG ≈∏Y "OZ"h "

" á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG ,»¡£dG AóÑd

" RƒeôdG ¢†eƒJ ±ƒ°Sh "h " "h " á°TÉ°ûdG »a "

êÉLódG ™£b

¿RƒdG Qƒ¡X ≈àM Qôµàe πµ°ûH "êÉLódG ™£b" QR ≈∏Y §¨°VG

±ƒ°S .á°TÉ°ûdG ≈∏Y Üƒ∏£ªdG RƒeôdG ¢VôY ºàj

h " "

" "h".á°TÉ°ûdG ≈∏Y "OZ"h "

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG ,»¡£dG AóÑd

" RƒeôdG ¢†eƒJ ±ƒ°Sh "h " "h " ±ƒ°Sh á°TÉ°ûdG »a "

AGó¨dG ≥ÑW

"AGó¨dG ≥ÑW" QR ≈∏Y §¨°VG Qƒ¡X ≈àM Qôµàe πµ°ûH

" RƒeôdG ¢VôY ºàj ±ƒ°S .á°TÉ°ûdG ≈∏Y Üƒ∏£ªdG ¿RƒdG h "

".á°TÉ°ûdG ≈∏Y "OZ"h"

" á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG ,»¡£dG AóÑd

" ¿GõeôdG ¢†eƒj ±ƒ°Sh "h " CGóÑj ±ƒ°Sh á°TÉ°ûdG »a "

áLRÉ£dG äGhô°†îdG

"áLRÉ£dG äGhô°†îdG" QR ≈∏Y §¨°VG Qôµàe πµ°ûH

RƒeôdG ¢VôY ºàj ±ƒ°S .á°TÉ°ûdG ≈∏Y Üƒ∏£ªdG ¿RƒdG Qƒ¡X ≈àM

" "h".á°TÉ°ûdG ≈∏Y "OZ"h "

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG ±ƒ°Sh ,»¡£dG AóÑd

" ¿GõeôdG ¢†eƒj "h " âbh CGóÑj ±ƒ°Sh á°TÉ°ûdG »a "

IóªéªdG äGhô°†îdG

"IóªéªdG äGhô°†îdG"

QR ≈∏Y §¨°VG ≈àM Qôµàe πµ°ûH

" RƒeôdG ¢VôY ºàj ±ƒ°S .á°TÉ°ûdG ≈∏Y Üƒ∏£ªdG ¿RƒdG Qƒ¡X

"h".á°TÉ°ûdG ≈∏Y "OZ"h "

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG ±ƒ°Sh ,»¡£dG AóÑd

" ¿GõeôdG ¢†eƒj "h " âbh CGóÑj ±ƒ°Sh á°TÉ°ûdG »a "

IGƒ°ûªdG

"Öcôe ƒ¡W/IGƒ°ûªdG" QR ≈∏Y §¨°VG QÉ«àNÉd IóMGh Iôe

"h "G-1" ¢VôY ºàj ±ƒ°S .IGƒ°ûªdG áØ«Xh á°TÉ°T ≈∏Y "

.LED

.á«ªbôdG í«JÉØªdG áMƒd ΩGóîà°SÉH Üƒ∏£ªdG »¡£dG âbh πNOCG

.á«fÉK 99 á≤«bO 99 ƒg »¡W âbh ≈°übCG

" á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG ±ƒ°S .»¡£dG AóÑd

.á°TÉ°ûdG »a

Ö«∏≤J ∞bƒàdG Gòg ∫É∏N »¨Ñæjh .áYƒª°ùe IQÉ°TEG ´Éª°S ºàj ±ƒ°Sh

.ó«L »¡W ≈∏Y ∫ƒ°üë∏d äÉfƒµªdG

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

FRESH

VEGETABLE

FRESH

VEGETABLE

FROZEN

VEGETABLE

FROZEN

VEGETABLE

DINNER

PLATE

DINNER

PLATE

CHICKEN

PIECES

CHICKEN

PIECES

STEAK

GRILL/

COMB.

äÉ«bhCG 0^4 1

äÉ«bhCG 0^8 2

á«bhCG 0^16 3

äÉ«bhCG 4^0 1

äÉ«bhCG 8^0 2

á«bhCG 0^12 3

á«bhCG 16^0 4

äÉ«bhCG 0^9 1

á«bhCG 0^12 2

á«bhCG 0^18 3

äÉ«bhCG 0^4 1

äÉ«bhCG 0^8 2

á«bhCG 0^16 3

("IóªéªdG äGhô°†îdG" QR §¨°V)

äÉ«bhCG 4^0 1

äÉ«bhCG 8^0 2

á«bhCG 16^0 3

Arabic

-02-

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG áHGPEG á«∏ªY AóÑd

" ¿Gô°TDƒªdG ¢†eƒj ±ƒ°S .LED "h "."

:»°SÉ«≤dG ™°VƒdG – QÉ°ûØdG

"QÉ°ûØdG" QõdG ≈∏Y §¨°VG ±ƒ°Sh ,QÉ°ûØdG ™°Vh ójóëàd

" A»°†j "h "."OZ"h "

√òg ≈dEG ∫ƒ°UƒdG øµªjh .¿ôØdG »a áéeôÑe ¿GRhCG áKÉ∏K óLƒJ

QõdG ≈∏Y QôµàªdG §¨°†dG ∫É∏N øe áéeôÑªdG ¿GRhCÉdG

"QÉ°ûØdG":»g áMÉàªdG ¿GRhCÉdG

."äÉ«bhCG 3^5"h "äÉ«bhCG 3"h "á«bhCG 1^75"

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG ±ƒ°S .»¡£dG AóÑd

±ƒ°Sh "OZ" õeôdG »Øàîj ±ƒ°S .áYƒª°ùe IQÉ°TEG ´Éª°S ºàj

" ¿GõeôdG ¢†eƒj "h

"."

±ƒ°Sh iôNCG áYƒª°ùe IQÉ°TEG ´Éª°S ºàj ±ƒ°S ,»¡£dG ∫ÉªàcG óæY

.LED á°TÉ°T ≈∏Y "0:00" ¢VôY ºàj

.»dÉëdG

:âbƒdG §Ñ°V ™°Vh – QÉ°ûØdG

Qõ∏d áÑ°ùædÉH É

≤Ñ°ùe áWƒÑ°†ªdG »¡£dG äÉbhCG ô««¨J øµªj

"QÉ°ûØdG".

"QÉ°ûØdG" QõdG ≈∏Y §¨°VG ,QÉ°ûØdG ™°Vh ójóëàd

≤ahh ."OZ" h "

"QÉ°ûØdG" QõdG §¨°V hCG "1^75" ¢VôY ºàj ±ƒ°S ,

.LED á°TÉ°T ≈∏Y "3^5" hCG "3^0"

»¡£dG âbh ¢†eƒj ±ƒ°S .OóëªdG ¿Rƒ∏d »¡£dG âbh LED

.OóëªdG

.Üƒ∏£ªdG »¡£dG âbh ∫ÉNOEÉd á«ªbôdG QGQRCÉdG Ωóîà°SG

" IôcGòdG"

QõdG ≈∏Y §¨°VG.OGóYEÉdG ßØëd

, "á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°†dG ádÉM »a :á¶MÉ∏e

" " h".á°TÉ°ûdG »a "

" QÉ°ûØdG".áYƒª°ùe IQÉ°TEG ´Éª°S ≈àM

¢ùWÉ£ÑdG

"¢ùWÉ£ÑdG" QR ≈∏Y §¨°VG OóY Qƒ¡X ≈àM Qôµàe πµ°ûH

¢VôY ºàj ±ƒ°S .á°TÉ°ûdG ≈∏Y É¡«¡W Üƒ∏£ªdG ¢ùWÉ£ÑdG äÉÑM

" øjõeôdG "h ".á°TÉ°ûdG ≈∏Y "

(É

Ñjô≤J É

eGôL 230) IóMGh ¢ùWÉ£H áÑM

(É

Ñjô≤J É

eGôL 460) ¢ùWÉ£H ÉàÑM

(É

Ñjô≤J É

eGôL 690) ¢ùWÉ£H äÉÑM çÉ∏K

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG ±ƒ°Sh ,»¡£dG AóÑd

" ¿GõeôdG ¢†eƒj "h "

»a âbDƒªdG CGóÑj ±ƒ°Sh á°TÉ°ûdG »a "

.»dRÉæàdG ó©dG

:Gõà«ÑdG

"Gõà«ÑdG" QR ≈∏Y §¨°VG OóY Qƒ¡X ≈àM Qôµàe πµ°ûH

øjõeôdG ¢VôY ºàj ±ƒ°S .á°TÉ°ûdG ≈∏Y É¡«¡W Üƒ∏£ªdG íFGô°ûdG

" " h".á°TÉ°ûdG ≈∏Y"

.Gõà«H íFGô°T çÉ∏K ≈dEG áëjô°T ø«î°ùJ IOÉYEG Iôe πc »a ∂æµªj

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG ±ƒ°Sh ,»¡£dG AóÑd

" ¿GõeôdG ¢†eƒj "h " »a âbDƒªdG CGóÑj ±ƒ°Sh á°TÉ°ûdG »a "

.»dRÉæàdG ó©dG

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

POPCORN

PIZZA

POPCORN

POTATO

MEMORY

IóMGh áÑM 1

¿ÉàÑM 2

äÉÑM çÉ∏K 3

äÉ«bhCG 3^0 1

äÉ«bhCG 6^0 2

äÉ«bhCG 9^0 3

Arabic

-12-

§Ñ°V/áYÉ°ùdG" QõdG ≈∏Y §¨°†dG øµªj ,»¡£dG AÉæKCG :á¶MÉ∏e

íàaG .áYƒª°ùe IQÉ°TEG äƒ°U ´Éª°S ºàj ±ƒ°S ,»¡£dG ∫ÉªàcG OôéªH

ªFGO ¢UôMG

.¿ôØdG

¿ôa ∞bƒàj ±ƒ°S ,»¡£dG AÉæKCG É

MƒàØe ¿ôØdG ÜÉH ¿Éc GPEG

«FÉ≤∏J ∞jhhôµ«ªdG

.ÜÉÑdG

QõdG ≈∏Y §¨°VG ,Üƒ∏£e ô«Z »≤ÑàªdG »¡£dG âbh ¿Éc GPEG

"í°ùe/±É≤jEG".»≤ÑàªdG »¡£dG âbh AÉ¨dEÉd

.¬Ø∏J ≈dEG ¬ZGôa AÉæKCG ¿ôØdG π«¨°ûJ …ODƒj ¿CG øµªj

"í°ùe/±É≤jEG"

QõdG ≈∏Y §¨°VG ,π«¨°ûàdG AÉæKCG ¿ôØdG ±É≤jEÉd

∞jhhôµ«ªdG ƒ¡W

ábÉW QÉ«àNÉd "ábÉ£dG" QR ≈∏Y QGôªà°SÉdG ™e §¨°VG 1

" A»°†j ±ƒ°S .∞jhhôµ«ªdG "h " " hCG "."

âbh ≈°übCG ,»¡£dG âbh ∫ÉNOEÉd ΩÉbQCÉdG í«JÉØe ≈∏Y §¨°VG 2

.á«fÉK 99h á≤«bO 99 ƒg »¡W

±ƒ°Sh ,»¡£dG AóÑd "á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG 3

" " äGô°TDƒªdG ¢†eƒJ ±ƒ°S .»≤ÑàªdG »¡£dG âbh ¢VôY ºàj

"h " hCG "."

QõdG ≈∏Y §¨°†dG ádÉM »a ,»¡£dG AÉæKCG :á¶MÉ∏e

" í°ùe/±É≤jEG" ∫É∏N á«∏ªY ájCG AGôLEG ΩóY ádÉM »a hCG

.É

«FÉ≤∏J ≥HÉ°ùdG OGóYEÉdG ≈

dEG ¿ôØdG ™Lôj ±ƒ°S ,á≤«bO

:™jô°ùdG ƒ¡£dG

á≤«bO øe ìhGôàj »¡W âbh ∫ÉNOEÉd á«ªbôdG QGQRCÉdG Ωóîà°SG

.≥FÉbO 6 ≈dEG IóMGh

.%100 ÉgQób ábÉ£H É

«FÉ≤∏J »¡£dG CGóÑj ±ƒ°S

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°†dG …ODƒj ±ƒ°S IOÉjR ≈dEG

.≈°übCG óëc á«fÉK 39h á≤«bO 100 ≈dEG π°üj ≈àM »¡£dG âbh

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°†dG ádÉM »a ∫ÉNOEG ¿hO

ábÉW iƒà°ùªH »¡£dG CGóÑj ±ƒ°S ∞jhhôµ«ªdG ¿ôa ¿EÉa ,»¡W âbh

∫É∏N øe »¡£dG âbh IOÉjR øµªj .á«fÉK 30 Ióªd %100 √Qób

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°†dG á£¨°V πc …ODƒJh .

.á«fÉK 30 QGó≤ªH »¡£dG âbh IOÉjR ≈dEG QõdG ≈∏Y

.á«fÉK 39h á≤«bO 100 ƒg »¡W âbh ≈°übCG

QõdG ≈∏

Y §¨°†dG É¡«a ºàj Iôe πc »a :á¶MÉ∏e

"á«fÉK 30+/CGóHG" 30 QGó≤ªH »¡£dG âbh OGOõj ±ƒ°S ,

á«FÉ≤∏àdG áªFÉ≤dG »¡Wh ∞jhhôµ«ªdG »¡£d áÑ°ùædÉH á«fÉK

.¿RƒdG

:¿RƒdG Ö°ùM ó«ªéàdG áHGPEG

"¿RƒdG Ö°ùM ó«ªéàdG áHGPEG" QõdG ≈∏Y §¨°VG ±ƒ°S .

"h "dEF1" ¢VôY ºàj "h ".LED á°TÉ°T ≈∏Y "

IóMƒdG (á«bhCÉdÉH) ¿Rh ∫ÉNOEÉd á«ªbôdG ºµëàdG áMƒd Ωóîà°SG

.É¡àHGPEG Üƒ∏£ªdG

" á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG áHGPEG á«∏ªY AóÑd

.LED

.á«bhCÉdÉH ¿GRhCÉdG ∫ÉNOEG Öéj :á¶MÉ∏e

.á«bhCG 100 ≈dEG äÉ«bhCG 4 øe ó«ªéàdG áHGPEG ¿Rh ìhGôàj :á¶MÉ∏e

:âbƒdG Ö°ùM ó«ªéàdG áHGPEG

âbƒdG Ö°ùM ó«ªéàdG áHGPEG" QõdG ≈∏Y §¨°VG ±ƒ°S .

"h "dEF2" ¢VôY ºàj "h ".LED á°TÉ°T ≈∏Y "

ó«ªéàdG áHGPEG âbh ∫ÉNOEÉd á«ªbôdG ºµëàdG áMƒd Ωóîà°SG

.á«fÉK 39h á≤«bO 100 ≈dEG IóMGh á«fÉK øe âbƒdG ìhGôàj .Üƒ∏£ªdG

iƒà°ùe ô««¨àd .3 ábÉ£dG iƒà°ùe »g á«°VGôàaÉdG ∞jhhôµ«ªdG ábÉW

"ábÉ£dG" QR ≈∏Y §¨°VG ,ábÉ£dG øµªj .IóMGh Iôe

»ªbôdG QõdG ≈∏Y §¨°†dG ≥jôW øY ábÉ£dG iƒà°ùe QÉ«àNG

.Ö°SÉæªdG

CLOCK

PRE-SET

STOP

CLEAR

STOP

CLEAR

STOP

CLEAR

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

START

+30SEC

POWER

WEIGHT

DEFROST

TIME

DEFROST

Arabic

-22-

áeÉYódG ≈∏YCG ™e (4) á«LÉLõdG á«æ«°üdG IGPÉëªH ºb •

.IQGhódG

.Ö°SÉæe »FÉHô¡c QÉ«J Qó°üªH RÉ¡édG π°Uh •

áYÉ°ùdG §Ñ°V

±ƒ°S ,Ö°SÉæe »FÉHô¡c QÉ«J Qó°üªH ∞jhhôµ«ªdG ¿ôa π«°UƒJ óæY

.8:00 §Ñ°†d

É∏ãe ,í«ë°üdG âbƒdG §Ñ°†d

"≥Ñ°ùe §Ñ°V/áYÉ°ùdG" QõdG ≈∏Y §¨°VG 1±ƒ°S .

.áYÉ°ùdG ΩÉbQCG ¢†eƒJ

.Ö«JôàdG ≈∏Y "0" ,"0" ,"8" ΩÉbQCÉdG ≈∏Y §¨°VG 2

.Üƒ∏£ªdG Ö°ùM "

AÉ°ùe/É

MÉÑ°U" QõdG ≈∏Y §¨°VG 3

AÉ¡fEÉd "≥Ñ°ùe §Ñ°V/áYÉ°ùdG" QõdG ≈∏Y §¨°VG 4

.LED á°TÉ°T ≈∏Y âbƒdG ¢VôY ºàj ±ƒ°S .áYÉ°ùdG §Ñ°V

"í°ùe/±É≤jEG" QõdG ≈∏Y §¨°†dG ádÉM »a :á¶MÉ∏e hCG

«FÉ

.á≤HÉ°ùdG ádÉëdG ≈dEG

"ïÑ£ªdG âbDƒe" QR ≈∏Y É

°†jCG RÉ¡édG Gòg πªà°ûj π¡°S

:»dÉàdG ƒëædG ≈∏Y QõdG Gòg π«¨°ûJ øµªj .ΩGóîà°SÉdG

.áYÉ°ùdG ô°TDƒe A»°†j ±ƒ°Sh 00:00 ΩÉbQCÉdG LED á°TÉ°T

"0" ΩÉbQCGh ":" õeôdG A»°†j ±ƒ°Sh ,∫hCÉdG "0" ¢†eƒj ±ƒ°S

.iôNCÉdG

.Üƒ∏£ªdG ¬«ÑæàdG âbh ∫ÉNOEÉd á«ªbôdG QGQRCÉdG Ωóîà°SG 2

.OGóYEÉdG ó«cCÉàd "á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG 3

.áYÉ°ùdG ô°TDƒe A»°†j ±ƒ°S

áYÉ°ùdG ô°TDƒe »Øàîj ±ƒ°S ,•ƒÑ°†ªdG âbƒdG ∫ƒ

∏M óæY 4

.¬«ÑæJ äƒ°U ´Éª°S ºàj ±ƒ°Sh

±ƒ°S LED á°TÉ°T ¿EÉa ,É¡£Ñ°V ≥Ñ°S ób áYÉ°ùdG âfÉc GPEG

("ê" πµ°ûdG) ΩGóîà°SÉdG

™°V ºK ,(8) ÜÉÑdG ôjôëJ IóMh ΩGóîà°SÉH ¿ôØdG ÜÉH íàaG

.(4) á«LÉLõdG á«æ«°üdG ≈∏Y AÉYƒdG

(Microwave) ∞jhhôµ«ªdG QR ≈∏Y §¨°VGh ÜÉÑdG ≥∏ZCG

.LED á°TÉ°T ≈∏Y Üƒ∏£ªdG ábÉ£dG OGóYEG ô¡¶j ≈àM Qôµàe πµ°ûH

,8h 10 ø«jƒà°ùªdG ø«H Ée ábÉW iƒà°ùe QÉ«àNG óæY :äÉ¶MÉ∏e

,1h 7 Újƒà°ùŸG ÚH Ée ábÉW iƒà°ùe QÉ«àNG óæY A»°†j ±ƒ°S

.π«¨°ûàdG AÉæKCG ¢†eƒj ±ƒ°Sh ¢†ØîæŸG iƒà°ùŸG ô°TDƒe

" A»°†j ±ƒ°S .Üƒ∏£ŸG ábÉ£dG "h " " hCG "."

.á«ªbôdG QGQRC’G ΩGóîà°SÉH Üƒ∏£ŸG »¡£dG âbh πNOCG

99h á≤«bO 99 ƒg ∞

jhhôµ«ŸG ¿ôa ‘ »¡W âbh ≈°übCG :á¶MÓe

.á«fÉK

"á«fÉK 30+/CGóHG" QõdG ≈∏Y §¨°VG ºàj ±ƒ°S .»¡£dG AóÑd

"h ":" ¢†eƒj "h " " hCG ".LED á°TÉ°T »a "

"í°ùe/±É≤jEG" QõdG ≈∏Y §¨°†dG ádÉM »a ,»¡£dG AÉæKCG :á¶MÉ∏e

™Lôj ±ƒ°S ,á≤«bO ∫É∏N á«∏ªY ájCG AGôLEG ΩóY ádÉM »a hCG

.É

«FÉ≤∏J ≥HÉ°ùdG OGóYEÉdG ≈dEG ¿ôØdG

≈∏Y §¨°†dG øµªj ,IGƒ°ûªdG hCG ∞jhhôµ«ªdÉH »¡£dG AÉæKCG :á¶MÉ∏e

AM/PM

CLOCK

PRE-SET

CLOCK

PRE-SET

STOP

CLEAR

STOP

CLEAR

KITCHEN

TIMER

KITCHEN

TIMER

START

+30SEC

START

+30SEC

PL1 %10 1

PL2 %20 2

PL3 %30 3

PL4 %40 4

PL5 %50 5

PL6 %60 6

PL7 %70 7

PL8 %80 8

PL9 %90 9

PL10 %100 10

POWER

GRILL/

COMB.

Arabic

-32-

øjôNBÉdG áeÉ∏°S

äGQó≤dG hhP ¢UÉî°TCÉdG ¬eóîà°ù«d ºª°üe ô«Z RÉ¡édG Gòg •

.º¡àeÉ∏°S øY ∫hDƒ°ùªdG ¢üî°ûdG πÑb øe RÉ¡édG

.RÉ¡édÉH º¡ãÑY ΩóY ¿Éª°†d ∫ÉØWCÉdG ≈∏Y ±Gô°TEÉdG Ωõ∏j •

…CÉd ∫ÉØWCÉdG ΩGóîà°SG ádÉM »a QòëdGh ≥«bódG ±Gô°TEÉdG Ωõ∏j •

.º¡æe Üô≤dÉH RÉ¡édG π«¨°ûJ hCG RÉ¡L

≤∏£e RÉ¡édG ∑ôàJ Éd •

ΩGóîà°SÉdG ó©H

AÉHô¡µdG òNCÉe øe ¢ùHÉ≤dG ´õfGh RÉ¡édG π«¨°ûJ ±É≤jE

ÉH ºb •

hCG ¬FGõLCG øe …CG ™«ªéJ πÑb hCG RÉ¡édG ΩGóîà°SG ΩóY óæY

∂∏°ùdG ó°T É

≤∏£e ∫hÉëJ Édh .É¡àfÉ«°U hCG É¡Ø«¶æJ hCG É¡µa

.AÉHô¡µdG òNCÉe øY ¢ùHÉ≤dG π°üa AÉæKCG

.∂∏°ùdGh IóMƒdG øY G

ìÉ∏°UEÉdGh ¢üëØdG

ácô°ûdG πÑb øe ¬dGóÑà°SG Öéj ,AÉHô¡µdG ∂∏°S ∞∏J ádÉM »a

.ôWÉîªdG Öæéàd π«gCÉàdG

á«FÉHô¡µdG áeÉ∏°ùdG

Gòg ΩGóîà°SG óæY ¢†jQCÉJ ∂∏°S ΩGóîà°SG Ωõ∏j

QÉ«àdG Qó°üe ≥aGƒJ øe ócCÉàdG É

ªFGO »¨Ñæjh ,èàæªdG

.∞«æ°üàdG áMƒd »a ø«ÑªdG ó¡édG ™e »FÉHô¡µdG

πjó©J É

bÉ∏WEG ∫

hÉëJ Édh QÉ«àdG òNCÉe ™e ¢ùHGƒ≤dG ≥aGƒàJ ¿CG Ωõ∏j

»àdG äÉéàæªdG ™e ÅjÉ¡e ¢ùHGƒb ájCG ΩGóîà°SG ΩóY Ωõ∏jh .¢ùHÉ≤dG

QÉ«àdG òNCÉe πØ°SCG ¿ƒµj ÉeóæY RÉ¡L …CG π«¨°ûàH É

≤∏£e º≤J Éd

.¬H π°UƒªdG

.RÉ¡é∏d »LQÉîdG AÉ£¨dG äÉëàa »a º°ùL …CG πNóJ Éd

"1" áÄØdG äÉéàæeh »aÉ°VEÉdG π«°UƒàdG ∑É∏°SCG

."1" áÄØdG äÉéàæe øeh ¢†jQCÉJ É¡H »àdG Iõ¡LCÉdG

Gôàe 30 ≈dEG ¬dƒW π°üj »aÉ°VEG π«°UƒJ ∂∏°S

ΩGóîà°SG øµªj •

.ábÉ£∏d ¿Gó≤a …CG çhóM ¿hO (Ωób 100)

πÑb øe ¬dGóÑà°SG Ωõ∏j ¬fEÉa ,É

ØdÉJ AÉHô¡µdG ∂∏°S ¿Éc GPEG •

.ôWÉîe ájCG Öæéàd ;ôµjO ófBG ∑É∏H

(CG πµ°ûdG) AGõLCÉdG

ºµëàdG áMƒd 1

IQGhódG á«æ«°üdG OƒªY 2

IQGhódG áeÉYódG 3

á«LÉLõdG á«æ«°üdG 4

áÑbGôªdG IòaÉf 5

ÜÉÑdG 6

ÜÉÑdG ôjôëJ IóMh 8

IGƒ°ûªdG πeÉM 9

ø«î°ùàdG IóMh 10

.RÉ¡édG øe ∞«∏¨àdG OGƒe ádGREÉH ºb •

OƒLh hCG ¬Ø∏J hCG í«ë°üdG ¬fÉµe »a ÜÉÑdG ¿ƒc ΩóY πãe

,á≤HÉ°ùdG äÉ«Ø∏àdG øe …CG OƒLh â¶MÉd GPE

G .¿ôØdG ∞jƒéJ »a

.¿ôØdG Ωóîà°ùJ Éd

.Iôe ∫hCÉd ¬eGóîà°SG πÑb RÉ¡édG ∞¶f •

(Ü πµ°ûdG) Ö«côàdG

∫ƒ°üØeh CÉØ£e RÉ¡édG ¿CG øe ócCÉàdG Öéj ,Ö«côàdG πÑb !ôjòëJ

.»FÉHô¡µdG QÉ«àdG Qó°üe øY

.ƒà°ùe í£°S ≈∏Y RÉ¡édG ™°V •

»a IOƒLƒªdG áëàØdG »a áÑ°ü≤dG ™°V ºK ,(6) ÜÉÑdG íàaG •

IóMh ≈∏Y §¨°†dG ∫É∏N øe ÜÉÑdG íàa ºàj .∞jƒéàdG IóYÉb

.ÜÉÑdG ôjôëJ

»a IOƒLƒªdG áëàØdG »a (3) IQGhódG áeÉYódG Ö«côàH ºb •

.∞jƒéàdG

Arabic

-42-

»a ∂dP ÖÑ°ùàj ó≤a ;É

ZQÉa ¿ƒµj ÉeóæY RÉ¡édG π«¨°ûàH º≤J Éd •

.¬Ø∏J

AÉ°û¨dG Ö≤K Öéj ,∂dP ≈dEG Ée hCG êÉLódG óÑc hCG ¢ùWÉ£ÑdG

.»¡£dG πÑb ácƒ°T ΩGóîà°SÉH äGôe IóY

ªFGO ócCÉJ •

IOÉªdG áÑ°SÉæe øe ≥≤ëàdG É

ªFGO »¨Ñæj ºK øeh ,∞jhhôµ«ªdG

.É¡eGóîà°SG πÑb

ádÉM »a ôéØæj ób ¬fCÉd ;Iô«¨°U áëàa ¬d AÉYh »a »¡£J Éd •

.∞jhhôµ«ªdG ¿ôa »a ¬æ«î°ùJ

»a áeóîà°ùªdG ájó«∏≤

πNGO ôµ°ùdG ∫ƒ∏ëe hCG Ωƒë∏dG IQGôM áLQO ¢SÉ«b

.§≤a ∞jhhôµ«ªdG ¿ôØd É

°ü«°üN

äGOÉ°TQEÉd É

≤ah ÉdEG ∞jhhôµ«ªdG »fGhCG ΩGóîà°SG ΩóY »¨Ñæj •

.øª°ùdG hCG âjõdG

áLQO øe ≥≤ëàdG É

ªFGO Ωõ∏j ºK øe ,¬°ùØf AÉYƒdG Éd AÉYƒdG

hCG á«dÉY áHƒWQ hCG IQGôM ¬H ódƒàJ ¿Éµe »a ¿ôØdG ™°†J Éd •

.¥GôàMÉ∏d á∏HÉ≤dG OGƒªdG øe Üô≤dÉH

¿ƒc ΩóY πãe ,äÉ«Ø∏

í£°Sh ÜÉÑdG ∫ÉØbCG ∞∏J hCG ¬FÉæëfG hCG í«ë°üdG ¬fÉµe »a ÜÉÑdG

äÉ«Ø∏àdG øe …CG OƒLh â¶MÉd GPEG .¿ôØdG ∞jƒéJ hCG ÜÉÑdG »a

.¿ôØdG π«¨°ûàH º≤J Éd ,á≤HÉ°ùdG

.RÉ¡édG »a äÉëàa ájCG ó°S hCG á«£¨àH º≤J Éd •

.RÉ¡édG Gòg ∞«¶æàd QÉîH É¡æe

«FÉ¡f ÖæéJ •

»NƒJ »¨Ñæj ºK øeh ,É

æNÉ°S RÉ¡édG íÑ°üj ΩGóîà°SÉdG AÉæKCG •

.¿ôØdG πNGO áæNÉ°ùdG AGõLCÉdG ¢ùªd Öæéàd QòëdG

áæNÉ°S íÑ°üJ ¿CG øµªj ,É¡«dEG ∫ƒ°UƒdG øµªj »àdG AGõLCÉdG :ôjòëJ

.RÉ¡édG øY G

§°TÉµªdG h

CG ¢ùª∏ªdG áæ°ûN hCG á£°TÉµdG äÉØ¶æªdG Ωóîà°ùJ Éd •

»a ÖÑ°ùàj ¿CG øµªj √QhóH …òdGh í£°ùdG ¢TóN ≈dEG ∂dP …ODƒj

.êÉLõdG ô°ùc

.RÉ¡édG π«¨°ûJ AÉæKCG

âbDƒªdG πFÉ°Sh á£°SGƒH π«¨°ûà∏d ºª°üe ô«Z RÉ¡édG Gòg •

.π°üØæªdG ó©

H øY ºµëàdG ΩÉ¶f hCG »LQÉîdG

π«¨°ûJ AÉæKCG É

æNÉ°S »LQÉîdG í£°ùdG hCG ÜÉÑdG íÑ°üj ¿CG øµªj •

.RÉ¡édG

¬∏°üa hCG RÉ¡édG π«¨°ûJ ±É≤jEG Öéj ,¿ÉNO óYÉ°üJ ßMƒd GPEG •

ájCG OÉªNEÉd É

≤∏¨e ÜÉÑdG AÉ≤HEG ™e »FÉHô¡µdG QÉ«àdG Qó°üe øY

.Ö¡d áæ°ùdCG

ªFGO ¢UôMG •

áé«àf áæNÉ°S »¡£dG »a áeóîà°ùªdG »fGhCÉdG íÑ°üJ ¿CG øµªj •

.¿ôØdG øe »fGhCÉdG êGôNEG AÉæKCG äGRÉØb AGóJQG ≈∏Y

ÜÉH ∫ƒM hCG ∞jhhôµ«ªdG πNGO QÉîÑdG ™ªéJ ádÉM »a •

Édh á«dÉY áHƒWQ ±hôX »a ∞jhhôµ«ªdG π«¨°ûJ óæY Gòg çóëj

Arabic

-52-

ájƒ¡J ¿Éª°†d ,Gòd .

≈∏Y º°S 15h RÉ¡édG ∞∏N º°S 10 √Qób ÆGôa ôaƒJ Ωõ∏j ,Ió«L

≈∏YCG º°S 30h ôNBÉdG ÖfÉédG ≈∏Y º°S 30h ø«ÑfÉédG óMCG

.¿ôØdG

áÑ°SÉæªdG »fGhCÉdG ≈∏Y §≤a ΩGóîà°SÉdG ô°üb »¨Ñæj •

.∞jhhôµ«ªdG ¿GôaCG »a ΩGóîà°SÉ∏d

¬∏°üa hCG ¿ôØdG π«¨°ûJ ±É≤jEG Öéj ,¿ÉNO óYÉ°üJ ßMƒd GPEG •

OÉªNEÉd É

≤∏¨e ¿ôØdG ÜÉH AÉ≤HEG ™e »FÉHô¡µdG QÉ«àdG Qó°üe øY

.Ö¡d áæ°ùdCG ájCG

ôNCÉJ ≈d

EG ∞jhhôµ«ªdG »a äÉHhô°ûªdG ø«î°ùJ …ODƒj ¿CG πªàëj •

AGòZ äÉjhÉM hCG äÉYÉ°VôdG äÉjƒàëe êQ hCG ≥ØN Ωõ∏j •

∫ÉØWCÉ∏d É¡FÉ£YEG πÑb É¡JQGôM áLQO øe ≥≤ëàdGh ∫ÉØWCÉdG

¬«∏Z ºJ …òdG hCG ¬Jô°û≤H ßØàëªdG ¢†«ÑdG ø«î°ùJ ΩóY »¨Ñæj •

ób ¢†«ÑdG Gòg ¿CÉd ∞jhhôµ«ªdG ¿ôa »a ¬Jô°ûb êƒ°†f ≈àM

.Ö°SGhQ

QƒgóJ ≈dEG áØ«¶f ádÉM »a ¿ôØdG ≈∏Y ®ÉØëdG ΩóY …ODƒj ób •

¿CG πªàëjh RÉ¡édG ôªY ≈∏Y

ÉÑ∏°S ôK

Dƒj ób Éªe ;í£°ùdG ádÉM

.IQƒ£N »a ÖÑ°ùàj

.iôNCG πFGƒ°S ájCG hCG AÉªdG »a ¢ùHÉ≤dG hCG ∂∏°ùdG

.èàæªdG Gò¡H á≤ë∏ªdG ºFGƒ≤dG ádGREG ô¶ëj •

øe Égô«Z hCG á«fÉ£∏°S ΩGóîà°SG É

ªFGO Öéjh ,Iô°TÉÑe

.∞jhhôµ«e ¿ôa »a ΩGóîà°SÉ∏d áÑ°SÉæªdG äÉjhÉëdG

RÉ¡édG ΩGóîà°SG

πµ°T …CÉH ¬Ø∏J hCG ¬Wƒ≤°S hCG RÉ¡édG ∞FÉXh »a π∏N …CG Qƒ¡X

õcôe ÜôbCG ≈dEG πeÉµdÉH RÉ¡édG IOÉYEG Öéj Éªc ,∫Éµ°TCÉdG øe

.ôWÉîe ájCG Öæéàd á«µ«fÉµ«ªdG

õcôe ÜôbCG ≈

dEG ¬ª∏°S πH ,∂°ùØæH RÉ¡édG ìÉ∏°UEG ∫hÉëJ Éd •

Éd hCG É¡H ≈°Uƒe ô«Z äÉeõ∏à°ùe hCG äÉ≤ë∏e ΩGóîà°SG …ODƒj ób •

.áæNÉ°ùdG í£°SCÉdG á°ùeÉ∏e

ΩGóîà°SG ≈∏Y ¢UôMGh áæNÉ°ùdG í£°SCÉdG á°ùeÉ∏e ÖæéJ •

.¢†HÉ≤ªdG

…CG Üôb RÉ¡édG Gòg AGõLCG øe …CG ,™°Vh hCG ,π«¨°ûàH º≤J Éd •

RÉ¡édG πªM É

∂°ùeG πH ,¢ùÑ≤ªdG øe ¬∏°üØd Iƒ≤H √ó°T hCG ∂∏°ùdG ΩGóîà°SÉH

.»FÉHô¡µdG QÉ«àdG π°üØd ¬Ñë°SGh ¢ùHÉ≤dÉH

π«°UƒJ øe ócCÉJ ,RÉ¡édG ™e »aÉ°VEG π«°UƒJ ∂∏°S ΩGóîà°SG óæY •

.ΩGóîà°SÉdG πªëJ ≈∏Y ¬JQóbh G

ó«L ∂∏°ùdG

πªëJ ≈∏Y Qó≤j ƒà°ùe í£°S ≈∏Y ∞jhhôµ«ªdG ¿ôa ™°Vh »¨Ñæj •

.¿ôØdG ¥ƒa A»°T …CG ™°†J Éd •

á«LÉLõdG á«æ«°üdG øµJ ºd GPEG ∞jhhôµ«ªdG ¿ôa π«¨°ûàH º≤J Éd •

.í«ë°üdG ™°VƒdG »a IQGhódG áeÉYódG hCG

¿ôa πØ°SC

G ôªj Éd ¬fCGh »FÉHô¡µdG QÉ«àdG ∂∏°S ∞∏J ΩóY øe ócCÉJ •

.IOÉM hCG áæNÉ°S í£°SCG ájCG ¥ƒa hCG ∞jhhôµ«ªdG

ΩGóîà°SÉdG ¢VôZ

äÉdƒcCÉªdG ø«î°ùàd ºª°üe ôµjO ófBG ∑É∏H ∞jhhôµ«ªdG ¿ôa

ªFGO

ºª°üe RÉ¡édG .iôNCG ¢VGôZCG ájCG »a RÉ¡édG Gòg Ωóîà°ùJ Éd

.§≤a »dõæªdG ΩGóîà°SÉ∏d

óYGƒb IÉYGôe É

Ée ∂dP »a ÉªH ,á«°üî°T áHÉ°UEG hCG á«FÉHô¡c áeó°üd ¢UÉî°TCÉdG

:»∏j

.πgDƒe ¢üî°T á£°SGƒH ¬MÉ∏°U

πgDƒªdG »æØdG ô«Z ¢üî°T …CG ΩÉ«b ¿ƒeCÉªdG ô«Z øe :ôjòëJ

.ô°ü≤dG á«gÉæàe äÉLƒªdG ábÉ£d

.QÉéØfÉ∏d á∏HÉb É¡fCÉd

j Éd :ôjòëJ

ΩGóîà°SG ≈∏Y º¡JQób øª°†J »àdG á«aÉµdG äGOÉ°TQEÉdÉH ºgójhõJ

.í«ë°üdG

Ü πµ°ûdG

ê πµ°ûdG

Arabic

-62-

áµ«ªdG IOÉe øe áë«Ø°U

STOP

CLEAR

START

+30SEC

FRESH

VEGETABLE

FROZEN

VEGETABLE

DINNER

PLATE

CHICKEN

PIECES

STEAKPIZZAPOPCORN POTATO

WEIGHT

DEFROST

POWER

GRILL/

COMB.

TIME

DEFROST

KITCHEN

TIMER

MEMORY AM/PM

CLOCK

PRE-SET

EXPRESS COOK

Arabic

CLE

VEG

PIEC

POP

OWER

E-

SET

(CG πµ°T) ∫Éµ°TCÉdG

Afghanistan: Ishan National Co., Opp. Ministry of Justice, Kabul. Tel.: +93-2-2101727. Algeria: SARL Outillage Corporation, 04

Route De Dely Brahim Cheraga, Alger. Tel.: +213-21-364363/508, Fax: +213-21-369667. Bahrain: Fawaz Al Zayani, P.O.Box 26563,

Adliya, Manama. Tel.: +973-17-715252/712756, Fax: +973-17-713789. Bangladesh: Ultra Corporation, 8, Kushol Centre, Uttara,

Dhaka 1230. Tel.: +880-2-8919272/9756 Ext.28, Fax: +880-2-9887167. Egypt: Anasia Egypt for Trading S. A. E., P.O.Box 2443, 110

Mostafa Refaat Street, Sheraton Heliopolis 11361, Cairo. Tel.: +20-2-2684159, Fax: +20-2-2684169. Ethiopia: Tewﬁk Sherif & Co.

Ltd., P.O.Box 5583, Debre Zeit Road, Addis Ababa. Tel.: +251-1-651700/601, Fax: +251-1-650570. India: Gryphon Impex Pvt. Ltd.,

D-6/4, Okhla Industrial Area, Phase-I, New Delhi-110020. Tel.: +91-11-26372602-4, Fax: +91-11-26372601. Iran: Tehran - Service

Centre of Iran, No 510, South Karger Ave, Below Pasteur Sq. Tehran. Tel.: +98-21-6490608/0656/6407672. Kish Island: Cayhan

Electric Co., No. 69, Paradise Shopping Centre, Kish Island. Tel.: +98-76444-22894. Jordan: Bashiti Hardware, P.O.Box 1564, TLA

Ali, Amman. Tel.: +962-6-5350009/4770741, Fax: +962-6-5350012/4789783. Kenya: Zylog Enterprises, IPS Building, Kuanda Street,

P.O.Box 40877, Nairobi. Tel.: +254-2-338188/199, Fax: +254-2-330642. Kuwait: Al Omar Technical Co., P.O.Box 4062, 13041 Safat,

Kuwait. Tel.: +965-4848595/0039, Fax: +965-4845652. Lebanon: Est. F.A. Kettaneh SA, P.O.Box 110242, Dora Highway, Kettaneh

Building, Beirut. Tel.: +961-1-255860/6, Fax: +961-1-255891. Libya: El Ghoul Brothers, P.O.Box 348, Islamic Call Bldg., Ofﬁce

201-202, Benghazi. Tel.: +218-61-9097681/4183, Fax: +218-61-9094123. Madagascar: Group Tana Confort S. A. R. L., B. P. 1770,

Antananarivo. Tel.: +261-20-2264505, Fax: +261-20-2264244. Malta: John G. Cassar Ltd., 36 Victory Str, Qormi QRM 06, Malta.

Tel.: +356-21-493251, Fax: +356-21-483231. Mauritius: Happy World Marketing Ltd., Block 2, Industrial Estate, Coromandel,

P.O.Box 429, Port Louis. Tel.: +230-2076700, Fax: +230-2337330/7400. Nepal: Universal Trading Centre, P.O.Box 1947,

Tripureswor, Kathmandu. Tel.: +977-1-262192/260587/785, Fax: 261154. Nigeria: Amin Bros. Eng. Co. Ltd., 30A (Plot 1291), Akin

Adesola Street, Victoria Island, Lagos. Tel.: +234-1-3201778, Fax: +234-1-2613667. Oman: Oman Mktg. & Service Co., P.O.Box

2734, Ruwi, Muscat. Tel.: +968-560232, Fax: +968-560255. Pakistan: Karachi - Ammar Service & Spares, 60, Bank Arcade, Serai

Road, Karachi. Tel.: +92-21-2426905, Fax: 2427214/5243. Pakistan: Lahore - Electronics Inn, 212-G Raja Centre, Main Market,

Gulberg, Lahore. Tel.: +92-42-5756750. Philippines: Modern House International Enterprises, 213 Rizal Ave. Extension, between 2nd

and 3rd Ave. Kalookan City. Tel.: +632 366-4487, Fax: +632 366-4489. Qatar: Al Muftah Trading & Cont., P.O.Box 875, Doha. Tel.:

+974-4650880/4446868, Fax: +974-4441415. Saudi Arabia: Dammam - Ebrahim Fawaz Al Zayani, P.O.Box 76026, Al Raka,

Dammam. Tel.: +966-3-8140914, Fax: +966-3-8140824. Jeddah: Anasia Trading Co. Ltd. Caravan Shopping Centre, Hail Street. P.

O. Box 50959, Jeddah-21477, Tel. 02 650 0948/02 636 3825, Fax 02 638 0720. Madina: Garziz Trdg. for Bldg. Mat.&Decor.,

P.O.Box 3364, Madina. Tel.: +966-4-8261490/8227636, Fax: +966-4-8265741. Riyadh: Anasia Trading Co Ltd. New Akaria Building,

60th St., 3rd Floor, Building # 4, Ofﬁce # 3402, Malaz. P. O. Box. 18689, Riyadh-11425, Tel.: 01 478 2549, Fax: 01 478 2761. Yanbu:

Bin Aﬁf, P.O.Box 530 Yanbu, Al Bahr. Tel.: +966-4-3222626/8867, Fax: +966-4-3222210. Sri Lanka: Delmege Gen. Equip. Pvt. Ltd.,

No. 428/1AT. B., Jaya Mawatha (Darley Road), Colombo-10. Tel.: +94-11-2665914, Fax: +94-11-2665915. Sudan: United

Distribution Company, P.O.Box 325, Sayed Abdul Rehman Street, Khartoum. Tel.: +249-11-772612/777296, Fax: +249-11-770919.

Tanzania: General Motors Investment, P. O Box 16541, 14 Vingunguti Nyerere Road, Dar Es Salaam. Tel.: +255-22-2862661/5022,

Fax: +255-22-2862667/5412/3. Tunisia: STE Tunisienne De Quincaillerie Stq., Nvelle Z.I 2013, Ben Arous, Tunis, Tunisia, Tel: +216

71386102, Fax: +216 71380412. UAE: Abu Dhabi - Light House Electric., P.O.Box 120, Abu Dhabi. Tel.: +971-2-6726131, Fax:

+971-2-6720667. Dubai - Black & Decker (O) A.G., P.O.Box 5420, Dubai. Tel.: +971-4-7028234/233, Fax: +971-4-2822765. Ideal

Mach. & Equipt. R. W/shop P.O.Box 37116, Al Quoz, Dubai. Tel.: +971-4-3474160, Fax: +971-4-3474157. Sharjah - McCoy Middle

East LLC, P.O.Box 20228, Sharjah. Tel.: +971-6-5336321, Fax: +971-6-5336320. Uganda:

The Building Centre, Kitgum House, 52

Station Road, P.O.Box 7436, Kampala. Tel.: +256-41-234567, Fax: +256-41-236413. Yemen: Aden - Middle East Trad. Co. Ltd.,

Mulla Dakka, Aden. Tel.: +967-2-240950, Fax: +967-2-240952. Sana'a: Middle East Trad. Co. Ltd., P.O.Box 12363, Hayel Street,

Sana'a. Tel.: +967-1-204201, Fax: +967-1-204204. Taiz: Middle East Trad. Co. Ltd., Campa area near Al-Kair mosque, Taiz. Tel.:

+967-4-231610/232033, Fax: +967-4-219869. Zimbabwe: J.D.Distributors, P.O.Box 226, 17 Bessemer Road, Graniteside, Harare.

Tel.: +263-4-753913-7, Fax: 753918. Cyprus: G. Kyprianou Trading Co Ltd., 51 Prodromou AVE. Strovolos, 1681, P.O. Box 23318

Nicosia Cyprus. Tel.: 00357 22 468170/1, Fax: 00357 22 468186, Email [email protected]

Names & Addresses for Black & Decker Service Concessionaries

WARRANTY REGISTRATION CARD

YOUR NAME/

YOUR ADDRESS

POSTCODE

DATE OF PURCHASE

DEALER'S NAME & ADDRESS/

PRODUCT MODEL NO. MZ3000PG - 120V

«ùßr

«∞FMu«Ê

«∞d±e «∞∂d¥bÍ

¢U¸¥a «∞Ad«¡

≈ßr Ë ´Mu«Ê «∞∂Uzl

Black+Decker Black+Decker MZ3000PG Black+decker

Product's Documents

User Manual

Specifications

Black+Decker MZ3000PG Questions and Answers
