10' x 20'
MAX AP SCREEN KIT
Assembly Instructions
1-800-524-9970
1-800-559-6175
Canada:
DESCRIPTION MODEL #
10' x 20' MAX AP Screen Kit
35777
Before you start: 2+ individual recommended for assembly, approximate time 30 min.
Please read instructions COMPLETELY before assembly. This shelter MUST be securely anchored.
THIS IS A TEMPORARY STRUCTURE AND NOT RECOMMENDED AS A PERMANENT STRUCTURE.
RECOMMENDED TOOLS
6/14/10
Model# Qty
Description of Parts:
10286 1
00748
48
Screen Wall
Bungees
05-35777-0BPage 2
Risk of re. DO NOT smoke or use open ame devices (including grills, re pits, deep fryers, smokers or
lanterns) in or around the shelter. DO NOT store ammable liquids (gasoline, kerosene, propane, etc.) in
or around your shelter. Do not expose top or sides of the shelter to open re or other ame source.
WARNING:
CAUTION:
PROPER ANCHORING OF THE FRAME IS THE RESPONSIBILITY OF THE CONSUMER.
ShelterLogic
®
, LLC
is not responsible for damage to the unit or the contents from acts of nature. Any shelter that is not anchored
securely has the potential to y away causing damage, and is not covered under the warranty. Periodically check the anchors to ensure
stability of shelter. ShelterLogic
®
, LLC cannot be responsible for any shelter that blows away. NOTE: Your shelter’s cover can be
quickly removed and stored prior to severe weather conditions. If strong winds or severe weather is forecast in your area, we recom-
mend removal of cover.
PROPER ANCHORING AND INSTALLATION OF FRAME:
A tight cover ensures longer life and performance. Always maintain a tight cover. Loose fabric can acceler-
ate deterioration of cover fabric. Immediately remove any accumulated debris from the roof structure with a
broom, mop or other soft-sided instrument. Use extreme caution when removing debris from cover- always
remove from outside the structure. DO NOT use hard-edged tools or instruments like rakes or shovels to
remove debris. This could result in punctures to the cover. DO NOT use bleach or harsh abrasive products to
clean the fabric cover. Cover is easily cleaned with mild soap and water.
Covered by U.S. Patents and patents pending: 6,871,614; 6,994,099; 7,296,584; D 430,306; D 415,571; D 414,564; D 409,310; D 415,572
CARE AND CLEANING:
Prior to installation, consult with all local municipal codes regarding installation of temporary shelters.
Choose the location of your shelter carefully. DANGER: Keep away from electrical wires. Check for
overhead utility lines, tree branches or other structures. Check for underground pipes or wires before
you dig. DO NOT install near roof lines or other structures that could shed debris onto your shelter.
DO NOT hang objects from the roof or support cables.
ATTENTION:
This shelter product is manufactured with quality materials. It is designed to t the ShelterLogic
®
, LLC custom fabric cover included.
ShelterLogic
®
, LLC Shelters offer storage and protection from damage caused by sun, light rain, tree sap and animal - bird excrement.
Please anchor this ShelterLogic
®
, LLC structure properly. See manual for more anchoring details. Proper anchoring, keeping cover
tight and free of snow and debris is the responsibility of the consumer. This shelter is not recommended for severe weather conditions.
Please read and understand the installation detail, warnings and cautions prior to beginning installation. If you have any questions call
the customer service number listed below. Please refer to the warranty card inside this package.
DANGER:
Use CAUTION when erecting the frame. Use safety goggles during installation. Secure and bolt together
overhead poles during assembly. Beware of pole ends.
REPLACEMENT PARTS, ASSEMBLY, SPECIAL ORDERS:
Genuine ShelterLogic
®
, LLC replacement parts and accessories are available from the factory, including anchoring kits for nearly any
application, replacement covers, wall and enclosure kits, vent and light kits, frame parts, zippered doors and other accessories. All
items are shipped factory direct to your door.
This shelter carries a full limited warranty against defects in workmanship. ShelterLogic
®
, LLC warrants to the Original Purchaser that if
properly used and installed, the product and all associated parts, are free from manufacturer’s defects for a period of:
1 YEAR FOR COvER FABRIC, END PANELS AND FRAMEwORk
Warranty period is determined by date of shipment from ShelterLogic
®
, LLC for factory direct purchases or date of purchase from an authorized
reseller, (please save a copy of your purchase receipt). If this product or any associated parts are found to be defective or missing at the time of receipt,
ShelterLogic
®
, LLC will repair or replace, at it’s option, the defective parts at no charge to the original purchaser. Replacement parts or repaired parts
shall be covered for the remainder of the Original Limited Warranty Period. All shipping costs will be the responsibility of the customer. Parts and replace-
ments will be sent C.O.D. You must save the original packaging materials for shipment back. If you purchased from a local dealer, all claims must have a
copy of original receipt. After purchase, please ll out and return warranty card for product registration. Please see warranty card for more details.
WARRANTY:
QUESTIONS - CLAIMS - SPECIAL ORDERS? CALL OUR CUSTOMER SERVICE HOTLINE:
U.S. CUSTOMER SERVICE: 1-800-524-9970 INTERNATIONAL CUSTOMER SERVICE: 001-860-945-6442 CANADA CUSTOMER SERVICE: 1-800-559-6175
HOURS OF OPERATION: MON-FRI 8:30AM-8:00PM EST, SAT-SUN 8:30AM-5:00PM EST.
05-35777-0BPage 3
NOTES:
• Screen kit should secure to the inside of the corner legs and outside of the middle legs as shown below.
• Make sure zipper door is closed when attaching the screen kit.
2. SECURE SCREEN WALL KIT WITH BUNGEES
A. Attach the top of the screen wall to the canopy crossrails with bungees on the inside of the canopy frame.
B. Tie off the screen to the canopy legs with the strings attached to the screen wall.
Insert Bungee Cord Through Grommet
Tie Off String to Canopy Legs
1. ATTACH SCREEN WALL KIT AT CORNER LEGS
A. Determine which corner of the canopy you would like the door positioned in.
B. Tie the laces closest to the zipper door rst.
C. Tie the remaining laces at the other 3 corner legs.
Screen wall - 10286
Screen outside
of middle legs
Screen inside
of corner legs
Tie Laces Closest to Door Opening First
