WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK
TURN OFF OR DISCONNECT FROM POWER
WHILE INSTALLING OR SERVICING UNIT
Assembly & Installation: 370-1972 | Masterforce PowerPack Work Light
HARDWARE:
Question/Comment/Missing Part?
Customer Service 1-800-865-6799
- When using product, basic precautions should always be followed.
- Read and follow these instructions and observe all warnings.
- Carefully read and understand the information given in this manual
before beginning installation. Failure to do so could lead to electric
shock, fire, or other injuries which could be hazardous or even fatal.
- Save these instructions and warnings.
- This item is damp rated. NEVER submerge this product in water!
- Do not use in on hot surfaces.
- Do not remove the lens protecting the LED.
- Do not use in areas near a gas source.
- It is NOT possible to change the LED light source.
- This light is not intended for use in potentially explosive
environments. This is NOT a vapor proof light.
- Do not dismantle this light. The LED chips are not replaceable.
- This work light is NOT A TOY and is not suitable for use by children.
WARNING
CAUTION
Part Description Quantity
A Hook 1
B Handle 1
C "U"Stand 1
D Star Knobs 2
E Screws 2
F Star Knobs 1
G "H"Stand 1
H AC Adapter 1
A
B
C
D
E
F
G
H
*PowerPack
Sold Separately
E
AC Socket
This product is guaranteed against failure due to factory defects in materials or workmanship for three (3) years from the
date of purchase. This warranty is non-transferable and applies only to the original owner. Proof of purchase required for
repair or replacement. This warranty does not cover normal wear of parts or damage resulting from any misuse of the
product. Misuse of the product includes but is not limited to: using in extreme weather conditions, opening the housing
of the product, or attempted remodel/alterations made to product.
- Do not look directly at the LED lights for any length of time.
- Do not remove protective lens covering LED lights.
Assembly & Installation: 370-1972 | Masterforce PowerPack Work Light
EYES
TO USE:
This light utilizes PowerPack (not included) that can rupture if
damaged. Before use of this product, inspect battery for damage.
1. Install battery securely and charge battery before use.
2. Press the On/Off switch to turn on the light.
3. Press the button again to change between 2000LM High,
1000LM Medium, and 500LM, Low, and OFF.
4. Tilt and adjust to any angle for best light.
5. Tighten knobs to secure work light to desired angle.
Connect the “U” shaped stand (C)
and the “H” shaped base (G)
together with the Star Knob (F)
as shown in figure 2
Connect the Lamp Body (H)
with “U” shaped stand (C)
with side Star Knobs (D)
as shown in figure 3.
*Note: This is completed at the
factory. Instructions included in
the case that this product is
disassembled after purchase.
STEP
#1:
STEP
#2*:
F
G
C
Figure 2
Figure 3
D
H
C
WARNING:
TO AVOID RISK OF ELECTRICAL SHOCK
TURN OFF OR DISCONNECT FROM POWER
WHILE INSTALLING OR SERVICING UNIT
Question/Comment/Missing Part?
Customer Service 1-800-865-6799
