6,000 Lumen Telescope
LED Work Light
370-5386
OPERATOR’S MANUAL
To Reduce The Risk Of Injury, User Must Read And
Understand Operator’s Manual. Save These Instructions For Future Reference.
CAUTION:
Page 2
Safety Symbols ............................................................................... Page 3
Safety Instructions .......................................................................... Page 4,5
Unpacking and Contents .................................................................Page 5
Overview / Specifications ............................................................... Page 6
Assembly Instructions ..................................................................... Page 7
Operation .......................................................................................... Page 7,8
Maintenance ..................................................................................... Page 8
Warranty ............................................................................................ Page 11
TABLE OF CONTENTS
Page 3
SAFETY SYMBOLS
Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the tool better and safer.
This Symbol Designates That This Product Is Listed By The Intertek Testing Services,
To United States And The Canadian Standards Association
WARNING:
CAUTION:
WARNING:
DANGER:
Page 4
The purpose of safety symbols is to attract our attention to possible dangers. The safety symbols, and the explanations
with them, deserve your careful attention and understanding. The symbol warnings do not by themselves eliminate
any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.
Be sure to read and understand all safety insructions in this manual,
including all safety alert symbols such as “DANGER”, “WARNING” and “CAUTION”, before
using this power tool. Failure to follow all instructions listed below may result in electric
shock, fire and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION.
May be used in conjunction with other symbols or pictographs.
Failure to obey this warning WILL result in death or serious injury
to yourself or to others. Always follow the safety precautions to reduce the risk of fire,
electric shock and personal injury.
Failure to obey this safety warning CAN result in death or serious
injur y to yourself or to others. Always follow the safety precautions to reduce the risk of
fire, electric shock and personal injury.
Failure to obey this safety warning MAY result in personal injury to
yourself or others or property damage. Always follow the safety precautions to reduce
the risk of fire, electric shock and personal injury.
SAFETY INSTRUCTIONS
UNPACKING AND CONTENTS
Page 5
WARNING:
READ AND UNDERSTAND
ALL WARNINGS, CAUTIONS AND OPERATING
INSTRUCTIONS BEFORE USING THIS PRODUCT.
Failure to follow all instructions listed below
may result in electric shock, fire and/or serious
personal injury.
CAUTION:
RISK OF ELECTRIC SHOCK,
Do not use with extension cord near water or
where water may accumulate. Keep work light
at least 16 feet from pools and spas. Keep plugs
and receptacles dry. Use only three wire outdoor
extension cords with grounded plugs and grounded
receptacles.
WARNING:
TO REDUCE THE RISK OF
FIRE, ELECTRIC SHOCK OR PERSONAL INJURY
• Ground Fault Circuit Interrupter (GFCI)
protection should be provided on the circuit(s)
or outlet(s) to be used for this work light in wet
locations. Receptacles are available having the built-
in GFCI protection and are able to be used for this
measure of safety.
• Use only with an extension cord for outdoor use,
such as an extension cord of cord type: SW, SW-
A, SOW, SOW-A, STW, STW-A, STOW, STOW-A,
SJW, SJW-A, SJOW, SJOW-A, SJTW, SJTW-A, or
SJTOW, SJTOW-A.
• Do not look directly at the lighted lamps to avoid
eye injuries.
• Always keep the work light away from any
flammable surface or materials.
• Always check damaged or worn-out parts
before using the work light. Broken parts will
affect the work light operation. Replace or repair
damaged or worn parts immediately. If repairs are
needed, consult a professional electrician.
• Do not use a pressure washer to clean this
product.
• Do not modify the work light in any way.
Unauthorized modification may impair the function
and/or safety and could affect the life of the product.
There are specific applications for which the work
light was designed.
• Store work light in a secure place out of the
reach of children. Inspect it for good working
condition prior to storage and before re-use.
SAVE THESE INSTRUCTIONS
SAFETY INSTRUCTIONS
IMPORTANT: Due to modern mass production techniques, it is unlikely the product is faulty or that a part is
missing. If you find anything wrong, do not operate the tool until the parts have been replaced or the fault has been
rectified. Failure to do so could result in serious personal injury.
DESCRIPTION QUANTITY
LED Work Light 1
Shoulder Strap 1
Foot Spikes 3
Operator’s Manual 1
FIG. 1
Shoulder Strap
Tripod Legs
Light Panels
Leg Locking Lever
Locking Button
for Light Panels
Switch
Tripod
Tripod Locking Levers
Power Cable
Page 6
OVERVIEW
SPECIFICATIONS
Rated Power 120V~, 60Hz, 60W
Brightness 3,000 / 6,000 Lumens
Color Temperature 5000K
Color Rendering Index > 80
Cable 6’ 18/3 SJTOW
Height 30.5” - 68”
Net Weight 7.4 lb
FIG. 3
A B
C D
FIG. 2
Switch
Page 7
WARNING:
Check and make sure there
is no sign of physical damage to the product when
unpacking. Do not use damaged product.
SETTING UP AND BREAKING DOWN THE
WORK LIGHT
Your work light is fully assembled and ready to use out
of box.
To Set Up the Light: From folded position A to working
position D:
1. Unwrap the power cord.
2. Release the leg locking lever. See position A.
3. Expand the tripod legs and then lock the leg locking
lever. See position B.
4. Place the light panel locking button at the Unlock
position, then flip the light panels up. See position C.
5. Release the tripod locking levers, raise the tripod to
desired height, then lock it. See position D.
6. Adjust the light panels to be desired position.
To Break Down the Light: From postion D back to
position A.
1. Release the tripod locking levers, lower tripod all the
way down and lock both levers
2. Fold the light panels down in a tube shape.
3. Release the leg locking lever.
4. Raise the leg connector until the end of light panels
nest inside.
5. Lock the leg locking lever.
6. Wrap the power cord.
ASSEMBLY INSTRUCTIONS
OPERATION
SWITCH ACTION
Your light has a white color on-board switch. This switch
turns the light On and Off and control the brightness
settings. The light modes rotates in the following
sequence by each press on the switch:
ON (6,000 Lumens) - ON (3,000 Lumens) - OFF
The switch has a delayed “OFF” function. If a light mode
stays on for more than 15 seconds, the next press on the
swich will turn off the light.
FIG. 4
FIG. 6
FIG. 7
FIG. 5
Locking Button
180°
330°
Page 8
MAINTENANCE
Your work light requires very little care and maintenance.
Simply clean the lens regularly with a non-abrasive
cleaner.
WARNING:
Always make sure the
work light is unplugged and completely cool before
attempting to clean it.
OPERATION
ADJUSTING THE LIGHT PANELS
Your light has four adjustable light panels. They can be
configured in dozens of ways to get light where it is
needed.
Flipping the Light panels: Place the locking button in
Unlock
position. Flip the light panels on each side
up or down to the desired position. Lock the light heads
by placing the locking button at Lock
position. See
figures 4 & 5.
Rotating the Light Heads: The light panels are able to
rotate 330° around their center axis. See figure 6.
CAUTION:
Do not force the light
panels. If it stops rotating in one direction, try the
other direction to reach the desired position.
ACCESSORIES
Foot Spike
Three foot spikes are included for extra hold in tough
conditions. Hammer the foot spike into soft ground
though two holes on the foot to give the light extra
stability. The foot spike can be stored on the leg as
shown in figure 7.
Shoulder Strap
An adjustable shoulder strap is included for easy
transport.
Page 9
NOTES
Page 10
NOTES
Page 11
6,000 Lumen Telescope LED Work Light
WARRANTY
90-DAY MONEY BACK GUARANTEE
This MASTERFORCE® brand power tool carries our 90-Day Money Back Guarantee. If you are not
completely satisfied with your MASTERFORCE® brand power tool for any reason within ninety (90) days
from the date of purchase, return the tool with your original receipt to any MENARDS® retail store, and
we will provide you a refund - no questions asked.
5-YEAR LIMITED WARRANTY
This MASTERFORCE® brand power tool carries our famous No Hassle 5-Year Limited Warranty to the
original purchaser. If, during normal use, this MASTERFORCE® power tool breaks or fails due to a
defect in material or workmanship within five (5) years from the date of original purchase, simply bring
the tool with the original sales receipt back to your nearest MENARDS® retail store. At its discretion,
MASTERFORCE® agrees to have the tool or any defective part(s) repaired or replaced with the same
or similar MASTERFORCE® product or part free of charge, within the stated warranty period, when
returned by the original purchaser with original sales receipt. Not withstanding the foregoing, this limited
warranty does not cover any damage that has resulted from abuse or misuse of the Merchandise. This
warranty: (1) excludes expendable parts including but not limited to blades, brushes, belts, bits, light
bulbs, and/or batteries; (2) shall be void if this tool is used for commercial and/or rental purposes;
and (3) does not cover any losses, injuries to persons property or costs. This warranty does give you
specific legal rights and you may have other rights, which vary from state to state. Be careful, tools are
dangerous if improperly used or maintained. Seller’s employees are not qualified to advise you on the
use of this merchandise. Any oral representation(s) made will not be binding on seller or its employees.
The rights under this limited warranty are to the original purchaser of the merchandise and may not
be transferred to any subsequent owner. This limited warranty is in lieu of all warranties, expressed or
implied including warranties or merchantability and fitness for a particular purpose. Seller shall not be
liable for any special, incidental, or consequential damages. The sole exclusive remedy against the seller
will be for the replacement of any defects as provided herein, as long as the seller is willing or able to
replace this product or is willing to refund the purchase price as provided above. For insurance purposes
seller is not allowed to demonstrate any of these power tools for you.
For questions / comments, technical assistance or repair parts -
Please call toll free at: 1-800-868-7421 (M-F 8am - 5pm EST)
SAVE YOUR RECEIPTS
THIS WARRANTY IS VOID WITHOUT THEM
© 2011 Menard, Inc., Eau Claire, WI 54703 10/2020
