7106509783 REV1.1.0 ©2022 TP-Link
Smart Wi-Fi Light Switch
Quick Start Guide
*Images may dier from your actual product.
Appearance Button Explanations
Restart
Reset
Press and hold for about 5s until the LED
blinks amber and green to reset Wi-Fi
while keeping other settings.
Press to restart your switch.
Press and hold for about 10s until the
LED blinks amber to restore to factory
default settings.
LED Status
Starting up.Solid amber
Blinking amber
Blinking green
White
Solid red
Stay green for 30s
Blinking amber & green
Connecting to Wi-Fi.
Device resetting.
Light fixture is off.
Disconnected from Wi-Fi.
Connected to Wi-Fi.
On/O
Button
Restart
LED
Reset
Want to Add Switch to Home?
This is a HomeKit-enabled device. You can also
add it to the Home app for easy control from
your iPhone or iPad.
Failed to Add to Home?
Factory reset the switch, and restart your phone.
Then try again.
Refer to the FAQ for detailed instructions:
https://www.tp-link.com/support/faq/3390/
Before You Start:
1. Your phone should be connected to a stable 2.4
GHz Wi-Fi network with internet access.
2. HomeKit will be disabled 10 minutes after the
switch is powered on. You can press the Restart
button on your switch to restart and try again.
Add to Home
1. Open the Home app.
2. Scan the HomeKit QR code in the package, or
enter the PIN on the switch.
Specications
Safety Notice
Before installing, servicing or removing the switch, read and follow all safety
precautions including the following:
• CAUTION – Risk of Electric Shock – More than one disconnect switch may
be required to de-energize the equipment before servicing. A circuit breaker
which disconnects the Line and Neutral conductor simultaneously is suitable.
Ensure power is o at the circuit breaker before removing or installing any
switch. Use a non-contact voltage tester to ensure the power is o.
• The Smart Switch must be installed and used in accordance with the
National Electric Code (NEC) or your local electrical code. If you are
unfamiliar with these codes and requirements, or are uncomfortable
performing the installation, consult a qualied electrician.
• Do not install the Smart Switch with wet hands or when standing on wet or
damp surfaces.
• Install only in a suitable UL Listed outlet box (suitable dimensions:
H > 2.95 in./75 mm, W > 1.81 in./46 mm, D > 2 in./51 mm).
Rating: 120V~ 60Hz
Load: 600W Incandescent, 1/6 HP Motor
Operation temperature: 0~40℃
Method of mounting included: Independently mounted
(Vertically position only);
Operating control, Type 1.C action
Pollution Degree 2, Rated Impulse Voltage 2500 V
Software Class A, NEMA Type 1
High Voltage-Disconnect power supply before servicing
CAUTION
For technical support, the user guide and other information, visit
https://www.tp-link.com/support.
Support
Ready for setup;
Resetting Wi-Fi.
