AP-230A Air purifier
User Manual
airchoice@afterservice.vip +1 (855) 620 5858
C-1
IMPORTANT SAFEGUARDS:
Please read the entire instruction manual before using the product and then save it for future reference.
1. Recommend to use individual electric supply socket and not to use an extension socket, in order to avoid the
danger of overheating in the outlet. Using inappropriate voltage and power outlet will damage and harm others.
2. Do not immerse the appliance or the electrical cord or plug in liquids.
3. Place the product on a flat, firm and safety place. Do not put it on the table edge or on tilted area, in order to
avoid dropping or damaging the product accidentally.
4. Do not operate the product without filters or with damaged filters.
5. Not to place it where the product is exposed to condensation, due to big temperature changes.Operate it under
room temperature between 0
0
-35
0
.
6. Always switch off the product before attempting to open the cover and take the filter.
7. Do not block the air inlet and outlet to avoid damage due to overheating. Place away from soft objects such as
curtains. Please make sure there’s 30cm distance between the object and the product which including top side,
front and back side as well.
8. To avoid shortening life span or damaging your product, do not use the machine with parts or accessories that
are not original. Otherwise, warranty of the product will be invalid.
9. Never operate the product without supervision. Children should be supervised by a responsible adult to ensure
that they do not play with the product.
10. Do not put your fingers or other objects into the air outlet, to avoid injury and damage the product.
11. Periodically check the electric cable of the product. If the electric cable is damaged, it must be replaced by
after-sales service in order to avoid danger.
12. Do not operate the product in area where gasoline, painting or flammable liquids are around. Keep the product
away from heat or hot units, as it may cause explosion.
13. This product is not intended to use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
14. This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
15. Before cleaning, repairing or moving the product, you must unplug it. Do not use volatile liquids or hard
cloth to clean the product, as to prevent the product from scratching.
16. Do not use this appliance when you have used indoor smoke-type insect repellents or in places with oily
residues, burning incense or chemical fumes.
17. Always unplug the appliance after use. When unplugging the power cord, hold the plug top, not the power
cord.
airchoice@afterservice.vip +1 (855) 620 5858
C-2
Parts Description:
A、front cover; B、display screen; C、touch panel; D、air outlet window; E、filter; F、back cover; G、
handle; H、dust sensor
Installation of Filters:
Please be reminded to take away the plastic bag before putting the filters in the air purifier.
1.Take away the back cover by holding the machine and pull the handle. (Fig 1)
（ Fig 1 ）
airchoice@afterservice.vip +1 (855) 620 5858
C-3
2. Take away the filter. (Fig 2, Fig 3)
3. Take the composite filter out of the plastic bag. (Fig 2, Fig 3)
4. Then put the composite filter into the machine. Please note wrong installation of filters will be resulted in
abnormal operation. (Fig 4)
5. Next, put the back cover to the machine. (Fig 5)
（ Fig 2 ）
（ Fig 5 ）
（ Fig 4 ）
（ Fig 3 ）
airchoice@afterservice.vip +1 (855) 620 5858
C-4
6. Last, undo the power cord strap and connect the power supply to use. (Fig 6.7)
（Fig 6 ）
（ Fig 7）
airchoice@afterservice.vip +1 (855) 620 5858
C-5
Control panel and functions:
Instruction of the control panel:
Button
Function
ON/OFF
1) in standby mode, press once to start the machine, and the default starting wind speed mode is
automatic mode: the wind speed indicator is displayed in automatic gear A.
The air quality indicator changes according to the actual PM2.5 value measured.
2）Press the button again, shut down the machine, turn off the negative ion, and turn off
the other indicators except the standby indicator (with the power supply indicator).
Speed
After ON, press the wind speed button to circulate as follows. Assuming that the current
work is in "low-grade", press "low- middle- high-automatic- low" cycle.
At the same time, the air quality lamp changes according to "1 (a bar)2_3_1 to 3
cycles_1" cycle.
Air Quality Display
Screen
green
blue
red
Wind Speed Indicator
Lamp
auto
auto
auto
Motor operation
low
middle
high
PM2.5
0-50
51-100
>101
Timer
In the case of ON, press the timing key, the timing indicator lights up, and the timing
time is switched by an unscheduled - 01-02-04-08 cycle every time, and the
corresponding timing time is executed; when the timing time arrives, the machine
automatically shuts down.
airchoice@afterservice.vip +1 (855) 620 5858
C-6
Child lock
Hold (Child Lock button) for 3 seconds to activate the lock function and
corresponding light is on. The control panel is locked meaning that other buttons
are invalid. Hold for another 3 seconds to deactivate it. The appliance returns to
normal operation.
Sleep
mode
Press hold on 3 seconds ,sleep button’s light on , there are no use press other button ,
press hold on 3 seconds sleep button’s OFF
Filter
replaceme
nt
indicator
1） Set the cumulative working time of the machine as T:T>=2160 hours. "The screen
reminder icon indicator light is always on, the screen time is over 90%. The frequency of
the screen indicator light 1HZ flickers, otherwise the icon will be extinguished."
2) When the filter reminder icon is on, hold the reset button for 3 seconds and the filter
reminder icon is off.
3) When the indicator lights up, without reset operation, the switch machine or the
power is switched off, and the indicator lights will remain on until the reset
operation is carried out.
Trouble shooting:
This section summarizes the most common problems you could encounter with the appliance. If you are unable to
solve the problem, contact the Consumer Care Center in your country.
Problem
Possible Cause
Solution
Air flow from air
outlet is at low
level.
1. The plastic bag of the filter is not
removed.
2. There are objects blocking the
air outlet.
1. Take away the plastic bag.
Please refer to “Installation of filters” section.
2. Clear the objects from air outlet
Please refer to “Cleaning and Maintenance” section.
Air purifying
performance is
not obvious and
no improvement
in air quality.
1. Filters are not installed yet.
2. Doors or windows are always
kept opened. Pollutants outside
flowed into the room continuously.
Therefore, it takes longer time to
purify the air.
3. Product is placed in a too tight
area or with objects blocking nearby.
4. Filters are dirty resulting in
1. Install the filters.
2. Do not place the product too near the window
unless the window is closed. Please keep the door
closed.
3. Place the product in an area with good airflow
environment.
3. Clean or replace filter.
Please refer to “Cleaning and Maintenance” section.
airchoice@afterservice.vip +1 (855) 620 5858
C-7
filtration efficiency.
Air quality
indicator light
keeps at red color
for very long time.
1. Dust sensor is dirty.
2. Doors or windows are always
kept opened. Pollutants outside
flowed into the room continuously.
Therefore, it takes longer time to
purify the air.
1. Please clean the dust sensor to restore its
sensitivity.
Please refer to “Cleaning and Maintenance” section.
2. Close the windows and door first. Turn to high
fan speed so that the product can purify the air in
short time.
PRODUCT SPECIFICATION:
Model No
AP-230A
Voltage
120V~ 60Hz
Power
60W
Recommend Coverage
16~26 ㎡
CADR(GB)
230m³/h
Noise
<60dB
Product Size
305*175*395mm
。
CONTACT US:
airchoice@afterservice.vip +1 (855) 620 5858
C-8
Thank you for choosing AIR CHOICE product.
If there is a defect arises during one year, please feel free to contact us to get
your valid claim. To obtain warranty service, please your model and order of the
product via:
� airchoice@afterservice.vip
☎ +1 (855) 620 5858
Our usual response time is within 12 hours!
