NEC P42XP10-BK 42" Professional Plasma Display User Manual

PlasmaSync 42XP10

PlasmaSync 50XP10

PlasmaSync 60XP10

EXIT MUTEINPUT

English

User’s Manual

Package Contents

Plasma Monitor

Remote control and AA Batteries

Power cord

Users Manual (CD-ROM)

Start Up Guide (Paper / CD-ROM)

Main Power Switch cover and screw

Cable clamps

•

Important Safety Instructions ..............................................................................................................English-1

Important Information ...........................................................................................................................English-2

Safety Precautions and Maintenance ...................................................................................................English-3

Recommended Use ....................................................................................................................................English-4

Installation

Using Optional Stands/Mounts ...............................................................................................English-6

Mounting Location ....................................................................................................................English-6

Mounting on Ceiling ..................................................................................................................English-7

Maintenance, Orientation, Cable Management ..................................................................English-7

Using the Remote ......................................................................................................................English-8

Part Names and Functions

Control Panel ..............................................................................................................................English-9

Terminal Panel ............................................................................................................................English-10

Remote Control Functions .......................................................................................................English-11

Power, Display, Digital Zoom, Pointer, Main Power Switch Cover .....................................English-12

Remote Control ID .....................................................................................................................English-13

On-Screen Display (OSD)

Using the OSD .............................................................................................................................English-14

OSD ................................................................................................................................................English-15

Operation

Picture Size Using Video Signals ............................................................................................English-19

Picture Size Using Computer Signals ....................................................................................English-20

Split Screen Mode .....................................................................................................................English-21

Picture in Picture Mode ...........................................................................................................English-22

Creating a Video Wall ................................................................................................................English-23

Using the Timer..........................................................................................................................English-24

Repeat Timer ..............................................................................................................................English-25

RS-232C .......................................................................................................................................................English-26

Troubleshooting.........................................................................................................................................English-30

Speciﬁ cations

P42XP10 .......................................................................................................................................English-31

P50XP10 .......................................................................................................................................English-32

P60XP10 .......................................................................................................................................English-33

Supported Resolutions

P42XP10 .......................................................................................................................................English-34

P50XP10 .......................................................................................................................................English-36

P60XP10 .......................................................................................................................................English-38

Pin Assignment ..........................................................................................................................................English-40

Table of Contents

English-1

Read Before Operating Equipment.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation openings. Install in

accordance with the manufacturer's instructions.

8. Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including

ampli ers) that produce heat.

9. Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug

has two blades and third grounding prong  e wide

blade or third prong are provided for your safety. If the

provided plug does not  t into your outlet, consult an

electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or

pinched particularly at plugs, convenience receptacles,

and the point where they exit from the apparatus.

11. Only use attachments/accessories speci ed by the

manufacturer

12. Use only with the cart, stand, tripod, bracket, or

table speci ed by the manufacturer, or sold with the

apparatus. When a cart is used, use caution when

moving the cart or apparatus combination to avoid

injury from tip-over.

13. Unplug this apparatus during lightning storms or when

unused for long periods of time

14. Refer all servicing to quali ed service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as when the power-supply

cord or plug is damaged, liquid has been spilled or

objects have fallen into the apparatus, the apparatus

has been exposed to rain or moisture, does not operate

normally, or has been dropped

Additional Safety Information

15.  is product may contain lead. Disposal of these

materials may be regulated due to environmental

considerations.

For disposal or recycling information, please contact

your local authorities or the Electronic Industries

Alliance: www.eiae org.

16. Damage Requiring Service - e appliance should be

serviced by quali ed service personnel when:

A.  e power supply cord or the plug has been damaged;

B. Objects have fallen, or liquid has been spilled into

the appliance;

C.  e appliance has been exposed to rain;

D.  e appliance does not appear to operate normally or

exhibits a marked change in performance;

E.  e appliance has been dropped, or the enclosure

damaged.

17. Tilt/Stability - All monitors must comply with

recommended international global safety standards for

tilt and stability properties of its cabinet design.

Do not compromise these design standards by applying

excessive pull force to the front, or top, of the cabinet

which could ultimately overturn the product.

Also, do not endanger yourself, or children, by placing

electronic equipment/toys on the top of the cabinet.

Such items could unsuspectingly fall from the top of the

set and cause product damage and/or personal injury.

18. Wall/Ceiling Mounting -  e appliance should be

mounted to a wall/ceiling only as recommended by the

manufacturer.

19. Power Lines - An outdoor antenna should be located

away from power lines.

20. Outdoor Antenna Grounding - If an outside antenna is

connected to the receiver, be sure the antenna system

is grounded so as to provide some protection against

voltage surges and built up static charges.

Section 810 of the National Electric code. ANSI/NFPA

No.70-1984, provides information with respect to

proper grounding of the mats and supporting structure,

grounding of the lead-in wire to an antenna-discharge

unit, size of grounding connectors, location of antenna

discharge unit, connection to grounding electrodes and

requirements for the grounding electrode.

21. Objects and Liquid Entry - Care should be taken so that

objects do not fall and liquids are not spilled into the

enclosure through openings.

Apparatus shall not be exposed to dripping or splashing

and no objects  lled with liquids, such as vases, shall be

placed on apparatus

WA R N I N G

To reduce the risk of  re or electric shock, do not expose

this apparatus to rain or moisture.

Important Safety Instructions

English

English-2

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. DO NOT USE THIS

UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS

CAN BE FULLY INSERTED.

REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM WALL

SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER CORD

FROM THE AC OUTLET. DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

 is symbol warns user that uninsulated voltage within the unit may have su cient magnitude to cause electric shock.

 erefore, it is dangerous to make any kind of contact with any part inside this unit.

 is symbol alerts the user that important literature concerning the operation and maintenance of this unit has been

included.  erefore, it should be read carefully in order to avoid any problems.

Important Information

Canadian Department of

Communications Compliance Statement

DOC:  is Class B digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety

Regulations according to CAN/CSA C22.2

No. 60950-1.

FCC Information

1. Use the attached speci ed cables with the P426Y0(P42XP10),

P506Y1(P50XP10), or P606Y2(P60XP10) color monitor so as not to

interfere with radio and television reception.

(1) Please use the supplied power cord or equivalent to

ensure FCC compliance.

(2) Please use shielded video signal cable,

15-pin mini D-SUB to 15-pin mini D-SUB

with ferrite cores on both ends (not included).

2.  is equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules.  ese

limits are designed to provide reasonable protection against harmful

interference in a residential installation.  is equipment generates, uses,

and can radiate radio frequency energy, and, if not installed and used

in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged

to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the distance between the equipment and

receiver.

Connect the equipment into an outlet on a circuit

di erent from that to which the receiver is connected.

Consult your dealer or an experienced radio/TV technician for help.

If necessary, the user should contact the dealer or an experienced radio/

television technician for additional suggestions.  e user may  nd the

following booklet, prepared by the Federal Communications Commission,

helpful: “How to Identify and Resolve Radio-TV Interference Problems.”  is

booklet is available from the U.S. Government Printing O ce, Washington,

D.C., 20402, Stock No. 004-000-00345-4.

WARN ING

 is product equipped with a three-wire grounding (earthed) plug - a plug

that has a third (grounding) pin.  is plug only  ts a grounding-type power

outlet. If you are unable to insert the plug into an outlet, contact a licensed

electrician to replace the outlet with a properly grounded one. Do not defeat

the safety purpose of the grounding plug.

•

CAUTION: Please use the power cord provided with this display in accordance with the table below. If a power cord is not

supplied with this equipment, please contact your supplier. For all other cases, please use a power cord that matches the AC

voltage of the power outlet and has been approved by and complies with the safety standard of your particular country.

Plug Type North America

European

Continental

U.K. Chinese Japanese

Plug Shape

Country

Voltage

U.S.A./Canada U.K. China JapanEU (except U.K.)

120* 230 220 100230

*When operating the PlasmaSync monitor with its AC 125-240V power supply, use a power supply cord that matches the power

supply voltage of the AC power outlet being used.

English-3

Safety Precautions and Maintenance

Safety Precautions

and Maintenance

FOR OPTIMUM PERFORMANCE, PLEASE NOTE

THE FOLLOWING WHEN SETTING UP AND

USING THE MONITOR:

 e plasma display's panel is made up of  ne picture

elements (cells), of which more than 99.99 percent are active

cells. Some cells may not produce light or remain constantly

lit. For safe operation and to avoid damaging the unit, read

carefully and observe the following instructions.

DO NOT OPEN THE MONITOR.  ere are no user-

serviceable parts inside and opening or removing covers

may expose you to dangerous shock hazards or other

risks.  e manufacturer is not liable for any bodily harm

or damage caused if unquali ed persons attempt service

or open the back cover. Refer all servicing to quali ed

service personnel.

Do not spill any liquids into the cabinet or use your

monitor near water.

Do not insert objects of any kind into the cabinet slots,

as they may touch dangerous voltage points, which can

be harmful or fatal or may cause electric shock,  re or

equipment failure.

Do not bend, crimp or otherwise damage the power cord.

Do not place any heavy objects on the power cord.

Damage to the cord may cause shock or  re.

Do not place this product on a sloping or unstable cart,

stand or table, as the monitor may fall, causing serious

damage to the monitor.

Do not use in a moving vehicle, as the unit could drop or

topple over and cause injuries.

 e power cable connector is the primary means of

detaching the system from the power supply.  e

monitor should be installed close to a power outlet that

is easily accessible.

 is equipment shall be connected to a MAIN outlet

with a protective earth-ground connection. Do not place

any objects onto the monitor and do not use the monitor

outdoors.

Do not use this unit’s polarized plug with an extension

cord or with outlets unless the prongs can be inserted

fully.

 e power supply cord you use must have been approved

by and comply with the safety standards of your

country. (Type H05VV-F 3G 1mm

should be used in

Europe)

In UK, use a BS-approved power cord with molded plug

having a black (13A) fuse installed for use with this

monitor.

Use only with 100 V to 240 V 50 Hz/60 Hz AC power

supply. Continued operation at line voltages greater than

100 V to 240 V AC will shorten the life of the unit, and

might even cause a  re hazard.

•

Unplug the power cord during electrical storms or when

the unit will not be in use for a long period.

Do not use monitor in high temperature, humid, dusty,

or oily areas.

Do not cover vent on monitor.

Clean plasma ventilation areas using a vacuum cleaner

with a so brush nozzle attachment.

To ensure proper ventilation, cleaning the ventilation

areas must be carried out monthly. More frequent

cleaning may be necessary depending on the

environment in which the plasma monitor is installed.

Allow adequate ventilation around the monitor so that

heat can properly dissipate. Do not block ventilated

openings or place the monitor near a radiator or other

heat sources. Do not put anything on top of monitor.

Handle with care when transporting. Save packaging for

transporting.

As is the case with any phosphor-based display (like a

CRT monitor, for example) light output will gradually

decrease over the life of a Plasma Display Panel.

To avoid sulfurization it is strongly recommended not to

place the unit in a dressing room in a public bath or hot

spring bath.

CAUTION

Immediately unplug your monitor from the wall outlet and

refer servicing to quali ed service personnel under the

following conditions:

When the power supply cord or plug is damaged.

If liquid has been spilled on, or objects have fallen into

the monitor.

If the monitor has been exposed to rain or water.

If the monitor has been dropped or the cabinet

damaged.

If the monitor does not operate normally by following

operating instructions.

•

English

English-4

CAUTION

CORRECT PLACEMENT AND ADJUSTMENT OF

THE MONITOR CAN REDUCE EYE, SHOULDER AND

NECK FATIGUE. CHECK THE FOLLOWING WHEN

POSITIONING THE MONITOR:

For optimum performance, allow 20 minutes for warm-

up.

Rest your eyes periodically by focusing on an object at

least 5 feet away. Blink o en.

Position the monitor at a 90 degree angle to windows

and other light sources to minimize glare and

re ections.

Clean the monitor surface with a lint-free, nonabrasive

cloth. Avoid using any cleaning solution or glass

cleaner.

Adjust the monitor’s brightness and contrast controls to

enhance readability.

Get regular eye checkups.

Ergonomics

To realize the maximum ergonomic bene ts, we recommend

the following:

Use the preset Size and Position controls with standard

signals.

Use the preset Color Setting.

Do not use primary color blue on a dark background, as

it is di cult to see and may produce eye fatigue due to

insu cient contrast.

 is equipment is not for use at video display work

station according to Bildscharb V.

For more detailed information on setting up a healthy work

environment, refer to the following document:

American National Standard for Human Factors

Engineering of Visual Display Terminal Workstations

ANSI-HFS Standard No. 100-1988

Published by:

 e Human Factors and Ergonomics Society

P.O. Box 1369, Santa Monica, California 90406.

•

Cleaning the Panel

When the panel becomes dusty or dirty, wipe gently

with so cloth.

Do not rub the panel with coarse material.

Do not apply pressure to the surface.

Do not use OA cleaner. OA cleaner will cause

deterioration or discolor the surface.

Cleaning the Cabinet

Unplug the power supply.

Gently wipe the cabinet with a so cloth.

To clean the cabinet, dampen the cloth with a neutral

detergent and water, wipe the cabinet and follow with a

dry cloth.

NOTE:  e surface of the cabinet is composed of many

types of plastic.

DO NOT clean with benzene thinner, alkaline

detergent, alcoholic system detergent, glass cleaner,

wax, polish cleaner, soap powder, or insecticide.

Rubber or vinyl should not be in contact with

the cabinet for an extended period of time.  ese

types of  uids and materials can cause the paint to

deteriorate, crack or peel.

CLEANING THE VENT HOLES

Clean plasma ventilation areas using a vacuum cleaner

with a so brush nozzle attachment.

To ensure proper ventilation, cleaning the ventilation

areas must be carried out monthly. More frequent

cleaning may be necessary depending on the

environment in which the plasma monitor is installed.

•

Recommended Use

English-5

To avoid or minimize image

retention:

Like all phosphor-based display devices and all other gas

plasma displays, plasma monitors can be susceptible to image

retention under certain circumstances. Certain operating

conditions, such as the continuous display of a static

image over a prolonged period of time, can result in image

retention if proper precautions are not taken. To protect

your investment in this plasma monitor, please adhere to the

following guidelines and recommendations for minimizing

the occurrence of image retention:

Always enable and use your computer’s screen saver

function during use with a computer input source.

Display a moving image whenever possible.

Change the position of the menu display from time to

time.

Always power down the monitor when you are  nished

using it.

To reduce the likelihood of

image retention from long-term

use:

Lower the Brightness and Contrast levels as much as

possible without impairing image readability.

Display an image with many colors and color gradations

(i.e. photographic or photo-realistic images).

Create image content with minimal contrast between

light and dark areas. Use complementary or pastel colors

whenever possible.

Avoid displaying images with few colors and distinct,

sharply de ned borders between colors.

Plasma monitor driving sound

 e panel of the Plasma monitor is composed of

extremely  ne pixels and these pixels emit light

according to received video signals.  is principle may

cause you to hear a buzz or electrical hum coming from

the Plasma monitor. Also note that the rotation speed

of the cooling fan motor increases when the ambient

temperature of the Plasma monitor becomes high. You

may hear the sound of the motor at that time.

NOTE:  e following items are not covered by the

warranty.

• Image retention

• Panel generated sound. Examples: Fan motor

and electrical noises circuit humming /glass panel

buzzing.

•

OPERATING ENVIRONMENT

Operating environment temperature and humidity: 0 °C to

+40 °C (+32 °F to +104 °F); less than 80%RH (cooling vents

not blocked) Do not install this unit in a poorly ventilated

area, or in locations exposed to high humidity or direct

sunlight (or strong arti cial light)

WARNING

Not for use in a computer room as de ned in the Standard

for the Protection of Electronic Computer/Data Processing

Equipment ANSI/NFPA 75.

NOTE: Please use shielded video signal cable, 15-pin mini

D-SUB to 15-pin mini D-SUB with ferrite cores on

both ends (not included).

Recommended Use - continued

English

English-6

Using Optional Stand/Mounts

An optional stand or mounting apparatus can be installed .

When stand or mounting apparatus is to be installed

while the unit is face-down (Figure 1), be sure to lay the

protective sheet (the foam sheet that the unit was wrapped

in) underneath the unit on order to prevent damage to the

screen.

 is unit must be used with a stand or some type of

mounting apparatus.  is unit is not designed for use

without additional support.

For correct Installation and Mounting it is

recommended to use a trained, authorized dealer.

Failure to follow correct mounting procedures could

result in dame to the unit or to the installer.

Product warranty does not cover damage caused by

improper installation.

CAUTION:

To install, follow those instructions included with the

stand or mounting apparatus. Use only those devices

recommended by the manufacturer.

Make sure to install stand or mounting apparatus to the

unit while on a surface that is strong and stable enough

to support the weight of the unit, such as a  oor or

sturdy table.

Use the speci ed clasps for installation.

Take necessary steps to prevent the unit from tipping or

falling.

Mounting Location

 e ceiling and wall must be strong enough to support the

monitor and mounting accessories.

DO NOT install in locations where a door or gate can hit

the unit.

DO NOT install in areas where the unit will be subjected

to strong vibrations and dust.

DO NOT install near where the main power supply

enters the building.

DO NOT install in where people can easily grab and

hang onto the unit or the mounting apparatus.

When mounting in an enclosure or in a recessed area, as

in a wall, leave at least 2 inches (50mm) of space between

the monitor and the wall for proper ventilation (Figure 2).

Allow adequate ventilation or provide air conditioning

around the monitor, so that heat can properly dissipate

away from the unit and mounting apparatus.

•

50mm (2")

Installation

Figure 2

Figure 1

Tab le

Optional table top stand

Protective Sheet

English-7

Mounting on Ceiling

Ensure that the ceiling is sturdy enough to support the

weight of the unit and the mounting apparatus over

time, against earthquakes, unexpected vibrations, and

other external forces.

Be sure the unit is mounted to a solid structure within

the ceiling, such as a support beam. Secure the monitor

using bolts, spring lock washers, washer and nut.

DO NOT mount to areas that have no supporting

internal structure. DO NOT use wood screws or anchor

screws for mounting. DO NOT mount the unit to trim

or to hanging  xtures.

Maintenance

Periodically check for loose screws, gaps, distortions,

or other problems that may occur with the mounting

apparatus. If a problem is detected, please refer to

quali ed personnel for service.

Regularly check the mounting location for signs of

damage or weakness that may occur over time.

Please note the following when

mounting on wall or ceiling.

When using mounting accessories other than those that

are NEC approved, they must comply with the VESA-

compatible (FDMlv1) mounting method.

NEC strongly recommends

using size M8 screws

(16mm + thickness of

bracket in length). If using

screws longer than 16mm,

check the depth of the

hole.(Recommended Fasten

Force: 1125 - 1375N•cm)

NEC recommends

mounting interfaces that

comply with UL1678

standard in North America.

Orientation

When using the display in the portrait position, the monitor

should be rotated clockwise so that the le side is moved to

the top and the LED indicator light is on the bottom.  is

will allow for proper ventilation and will extend the lifetime

of the monitor. Improper ventilation may shorten the

lifetime of the monitor.

When using the display in the portrait position, please turn

the Cooling Fan "ON" in the OPTION2 OSD menu.

•

EXIT

MUTE

INPUT

EXIT MUTEINPUT

Cable Management

To conveniently manage cables, use the cable clamps

provided to bundle the power cord together with the signal

and audio cables at the back of the display.

To attach cable clamps:

1. Attach the cable clamps to the display. Insert the anchor of

the clamp into the hole on the back of the display.  ere are 4

cable clamps and 4 clamp holes on the unit.

2. A er the cable clamp is positioned on the display, wrap the

end around the cables. Place the end of the clamp into the

slot near the anchor. Pull until cables are snug.

Clamps are designed to stay in place. Once in position, they

will be di cult to remove.

3. Cables can be routed to the right or le of the clamp. Use

the beaded bands to secure the cables together along their

length. Make sure the cables are fully supported.

To detach clamps:

Using pliers, twist the clamp 90 degrees and pull outward.

It is possible that the clamp can weaken over time and

removing it may cause damage to the clamp.

Installation - continued

Holes for Clamp

anchors

16mm

Anchor

Slot

Closed Clamp

Screw length should equal

depth of hole (16mm) + the

thickness of mounting bracket.

Unit

Mounting

Bracket

Screw

Thickness

of Bracket

English

English-8

Using the Remote:

Install the remote control batteries.

 e remote control is powered by AA batteries. To install or

replace batteries:

A. Press and slide to open the cover.

B. Align the batteries according to the (+)

and (–) indications inside the case.

C. Replace the cover.

CAUTION: Incorrect usage of batteries can result in leaks or

bursting. NEC recommends the following battery use:

Place “AA” size batteries matching the (+) and (-) signs

on each battery to the (+) and (-) signs of the battery

compartment.

Do not mix battery brands.

Do not combine new and old batteries, or mix brands.

 is can shorten battery life or cause liquid leakage of

batteries.

Remove dead batteries immediately to prevent battery

acid from leaking into the battery compartment.

Do not touch exposed battery acid, it may injure skin.

Do not drop or mishandle the remote.

Do not get the remote control wet. If the remote does get

wet, wipe dry immediately.

Avoid excessive heat and humidity.

Do not dispose of batteries in  re.

Please follow government regulations or public

environmental rules that apply in your country/area

when disposing of used batteries.

When replacing, use only conventional non-

rechargeable alkaline or manganese batteries.

 ere is a risk of explosion if batteries are replaced

incorrectly.

•

Operating Range for the Remote Control

Point the top of the remote control toward the monitor’s

remote sensor while pressing buttons.  e remote control

can be used from the front of the monitor at a maximum

distance of 7 m/23  . from the front of the Plasma monitor’s

remote control sensor.  e maximum horizontal and vertical

angle for use of the remote is 30 degree within a distance of

3.5 m/11.5  .

CAUTION

 e remote control may not function when direct sunlight

or strong illumination strikes the remote control sensor of

the Plasma monitor, or when there is an object in the path of

the sensor.

Handling the Remote Control

Do not open the remote control other than to install

batteries. Do not allow water or other liquid to splash onto

the remote control. If the remote control gets wet, wipe it dry

immediately.

Avoid exposure to heat and steam.

NOTE: If you do not intend to use the Remote Control for a

long period of time, remove the batteries.

Installation - continued

EXIT MUTEINPUT


MEMORY

POWER ON

RGB DVD/HD VIDEO


MODE

DISPLAY

AUTO

SET UP

VOL

SPLIT SCREEN

REMOTEID

SWAP

SET RESET

REMOTE CONTROLLER RU-M113

SLEEP

SELECT/FREEZE

CAPTURE

PIP

S BY S SINGLE

MUTE

ZOOM

POINTER

EXIT

SIZE

STANDBY

123

456

SET

English-9

Part Names and Functions

Control Panel

1) POWER

Switches the power on/standby.

2) MUTE

Switches the audio mute ON/OFF.

3) INPUT

Switches between input sources.

Acts as SET button within the OSD menu.

4) PLUS (+)

Increases the setting adjustment within OSD menu.

5) MINUS (-)

Decreases the setting adjustment within OSD menu.

6) UP ( )

Increases the volume level when the OSD is o .

Moves area up to select which setting to is to be adjusted

within OSD menu.

7) DOWN ( )

Decreases the volume level when the OSD is o .

Moves down to select which setting is to be adjusted within

OSD menu.

8) EXIT

Activates the OSD menu when the OSD menu is o .

Exits from the current menu being displayed to the

previous menu within the OSD.

9) Remote control sensor and Power indicator

Receives the signal when using the wireless remote control.

Glows green when the monitor is active. Glows red when

the monitor is in Standby mode. Glows Amber when the

monitor is in POWER SAVE mode.

A red blinking Power indicator means that the monitor has

detected a failure. Contact quali ed personnel in case of

failure.

10) Main Power Switch

Seesaw switch to turn the main power on/o .

Mode Status indicator light

Power On Green

Standby Red

Power save Amber

Diagnosis

(Detecting failure)

Red blinking

EXIT MUTEINPUT

OFFON

NOTE:

The POWER button does not completely turn off the

display. Use the Main Power Switch to completely turn off

the display.

English

English-10

EXTERNAL CONTROL

OUT

S-VIDEO IN

DVI AUDIO3

(MONO)

AUDIO2 AUDIO1VGA

HD VD

R/Cr/Pr G/Y B/Cb/pb

RGBHV / DVD/HD2

Y Cr/Pr Cb/Pb

DVD/HD1

IN/OUT

VIDEO AC IN

SPEAKER (S)

3 4 5 6 7 8 9

1110

13 14

Part Names and Functions

1) EXTERNAL CONTROL OUT (D-Sub 9 pin)

Connect RS-232C output to a second monitor.

2) EXTERNAL CONTROL (D-Sub 9 pin)

Connect RS-232C input to external equipment such as a

PC in order to control RS-232C functions.

3) DVI

Input digital RGB signals from a computer or HDTV

device having a digital RGB output.

4) AUDIO3

Input the audio signal from external equipment such as a

computer, VCR or DVD player.

5) VGA (Mini D-Sub 15 pin)

Analog computer input or output.

For proper operation select "D-SUB INPUT" in the

OPTION1 OSD menu.

6) RGBHV/DVD/HD2

RGBHV: Input RGB signals from RGB equipment.

A Sync-on-Green signal can be connected using the

G connector.

DVD/HD2: Connect equipment such as a DVD player,

HDTV device, or set-top box.

 is input can be used with an RGB or component source.

For proper operation select "BNC INPUT" in the

OPTION1 OSD menu.

7) AUDIO2

Input the audio signal from external equipment such as a

computer, VCR or DVD player.

8) DVD/HD1

Connect equipment such as a DVD player, HDTV device,

or set-top box.

9) AUDIO1

Input the audio signal from external equipment such as a

computer, VCR or DVD player.

10) S-VIDEO in

Input S-video.

11) VIDEO1

Composite video input or output.

12) VIDEO2

Composite video input.

13) EXTERNAL SPEAKER (L and R) connector

Connects to optional speakers. Output the audio signal

from AUDIO 1, 2, and 3 to external speakers.

NOTE: Speaker Terminal is for 8W + 8W (8 ohm).

14) AC IN

Connects with the supplied power cord.

Information:

For Y/Cb/Cr connections, use the DVD/HD1 or DVD/HD2

terminals.

For SCART connections there are 3 ways to connect:

SCART1: Connect R/G/B to the DVD/HD2 terminals and

composite sync. to the HD terminal.

SCART2: Connect R/G/B to the DVD/HD2 terminals and

composite sync. to the VIDEO1 terminal.

SCART3: Connect R/G/B + composite sync. to the VGA

terminal.

Terminal Panel

English-11

Part Names and Functions - continued

1) POWER ON/STANDBY

Switches the power on/standby.

*If the Power Indicator on the display is not glowing,

then no controls will work.

2) VIDEO

Switches the input signal to the VIDEO source.

3) RGB

Switches the input signal to the RGB source.

4) DVD/HD

Switches the input signal to the DVD/HD source.

5) PICTURE MODE

Selects Picture Mode: [STANDARD], [BRIGHT],

[CINEMA1], [CINEMA2], [DEFAULT].

STANDARD: for viewing in a bright room

BRIGHT: brighter picture than STANDARD

CINEMA1, 2: for viewing in a dark room, good for

movies

DEFAULT: factory default settings

6) SIZE

Set the aspect ratio of the image.

7) KEYPAD

Set REMOTE ID.

8) DISPLAY

Turn on/o the Information OSD.

Move selection up or down

10) AUTO SETUP

Adjusts the CLOCK PHASE, CLOCK, and POSITION

settings automatically. (Analog RGB signal input only)

11) POINTER

Turn on/o the pointer.

12) VOLUME

Increases/Decreases sound level.

13) SPLIT SCREEN

PIP: Picture-in-Picture mode.

S BY S: Side-by-side mode.

SINGLE: Returns to normal mode.

SWAP: Swaps the Split Screen images.

When the QUICK SWAP function (see OSD OPTION4)

is ON, SWAP can be used to change signal input. (Single

screen mode)

SELECT/FREEZE: Selects which input is active when

in split screen mode.

When the PIC FREEZE function (see OSD Option4) is

operating, SELECT/FREEZE can be used to display still

pictures on the sub screen.

CAPTURE : Captures still picture.

14) REMOTE ID

Activates REMOTE ID function.

15) MENU

Turns ON/OFF menu mode.

16) SET

Makes selection.

17) - , +

Increases or decreases amount of adjustment.

18) EXIT

Goes to the previous menu.

19) ZOOM

Enlarges or reduces the picture.

20) MUTE

Mutes audio output.

21) SLEEP

Sleep timer.

NOTE: Any buttons without a corresponding explanation

will not work with the Plasmasync display.


MEMORY

POWER ON

RGB DVD/HD VIDEO


MODE

DISPLAY

AUTO

SET UP

VOL

SPLIT SCREEN

REMOTE ID

SWAP

SET RESET

REMOTE CONTROLLER RU-M113

SLEEP

SELECT/FREEZE

CAPTURE

PIP

S BY S SINGLE

MUTE

ZOOM

POINTER

EXIT

SIZE

STANDBY

123

456

SET

Remote Control Functions

English

English-12

POWER

To turn the unit ON and OFF:

1. Plug the power cord into an AC outlet.

2. Press the Power button (on the unit).

 e monitor's ON/STANDBY indicator turns red and the

unit will be in STANDBY mode.

3. Press the POWER ON button on the remote control.  e

ON/STANDBY indicator will turn green when the unit is

active.

4. Press the STANDBY button (on the remote) or the Power

button (on the unit) to turn o the monitor.

DISPLAY

To check display settings press the DISPLAY button on the

remote.  e screen changes each time the DISPLAY button is

pressed. Display information will disappear a er 3 seconds.

DIGITAL ZOOM

Digital zoom can change the picture position or enlarge the

image on the screen.

1. Be sure ZOOM NAV function is o . Press the ZOOM

button (+ or -) to display the magnifying glass.

Press the ZOOM + button to enlarge the image.

Press the ZOOM - button to reduce the image.

Press the UP and DOWN or PLUS and MINUS buttons to

reposition the picture.

2. Press the POINTER button to hide the pointer.

POINTER

Use the Pointer to point to a speci c area on the screen.

Press the UP and DOWN or PLUS and MINUS buttons to

reposition the Pointer.

Main Power Switch Cover

Included with the display is a cover for the Main Power

Switch. Use this cover to prevent the unit from being

inadvertently powered o .

Place the tab on the cable cover into the rectangular slot on

the display.

 en using the screw provided, secure the cover to the

display.

Part Names and Functions - continued

TAB

SLOT

OFFON

Main Power

Switch

Cover

English-13

REMOTE CONTROL ID

 e remote control included with the display can be used

to control up to 26 individual monitors using what is

called the REMOTE CONTROL ID mode.  e REMOTE

CONTROL ID mode works in conjunction with the Monitor

ID, allowing control of up to 26 individual monitors. For

example: if there are many monitors being used in the same

area, a remote control in normal mode would send signals to

every monitor at the same time Figure 1. Using the remote

in REMOTE CONTROL ID mode will only operate one

speci c monitor within the group Figure 2.

TO SET REMOTE CONTROL ID:

While holding down the REMOTE ID SET button on the

remote control, use the KEYPAD to input the Monitor ID

(1-26) of the display to be controlled via remote.  e remote

can then be used to operate the monitor having that speci c

Monitor ID number.

When 0 is selected or when the remote control is in normal

mode, all monitors will be operated.

TO USE REMOTE CONTROL ID MODE

ID Mode - To enter ID Mode press the REMOTE ID SET

button and hold down for 2 seconds.

Normal Mode - To return to Normal Mode press the

REMOTE ID RESET button and hold down for 2 seconds.

In order for this feature to work properly, the display must

be assigned a Monitor ID number.  e Monitor ID number

can be assigned under the OPTION3 menu in the OSD (See

page 17).

If monitor ID is set to “ALL” , monitor is controled by remote

control not depend on remote ID.

EXIT MUTEINPUT EXIT MUTEINPUT EXIT MUTEINPUT


MEMORY

POWER ON

RGB DVD/HD VIDEO


MODE

DISPLAY

AUTO

SET UP

VOL

SPLIT SCREEN

REMOTEID

SWAP

SET RESET

REMOTE CONTROLLER RU-M113

SLEEP

SELECT/FREEZE

CAPTURE

PIP

S BY S SINGLE

MUTE

ZOOM

POINTER

EXIT

SIZE

STANDBY

123

456

SET

EXIT MUTEINPUT EXIT MUTEINPUT EXIT MUTEINPUT


MEMORY

POWER ON

RGB DVD/HD VIDEO


MODE

DISPLAY

AUTO

SET UP

VOL

SPLIT SCREEN

REMOTEID

SWAP

SET RESET

REMOTE CONTROLLER RU-M113

SLEEP

SELECT/FREEZE

CAPTURE

PIP

S BY S SINGLE

MUTE

ZOOM

POINTER

EXIT

SIZE

STANDBY

123

456

SET

Monitor ID:1 Monitor ID:2

Remote does

not work

Remote does

not work

Figure 2

Remote set up to

use Remote ID:3

Monitor ID:1 Monitor ID:2

Remote works Remote works

Figure 1

Remote in Normal

mode or the REMOTE

ID is set to 0

Remote Control ID Function

Part Names and Functions - continued

Monitor ID:3

Remote works

Monitor ID:3

Remote works

English

English-14

On-Screen Display (OSD)

Using the OSD

Use the Remote Control or the control panel on the front

of the unit to enter the on-screen display menu to adjust

settings.

1. Press the MENU button on the remote or the EXIT button

on the Control Panel.

2. Use the up and down buttons to select the desired menu.

3. Press the SET button to select a sub-menu or item for

adjustment.

4. Change the setting or adjustment by pressing the + and

- buttons on the Control Panel or the Remote Control.

5. Press the EXIT button on the Remote Control, on the

Control Panel to return to the previous menu.

NOTE: Not all menu functions may be available. To access

all functions the Advanced OSD option must be turned on

in the ADVANCED OSD menu.


AUDIO

SCREEN

OPTION1

ADVANCED OSD OFF

SEL. ENTER

MAIN MENU

1/2

EXIT

Press UP or DOWN

button to select

sub-menu.

Press SET. Press UP, DOWN, PLUS,

or MINUS to select the

function or setting to be

adjusted.

Press MENU or EXIT.

Press UP or DOWN

button to select.

Press INPUT

button to decide.

Press UP, DOWN, PLUS,

or MINUS to select.

Press EXIT.

Remote

Control

Panel

OSD

Screen

EXIT MUTEINPUT


AUDIO

SCREEN

OPTION1

OPTION2

OPTION3

OPTION4

ADVANCED OSD ON

SEL. ENTER

MAIN MENU 1/2

EXIT

ADVANCED OSD is OFF. Not all OSD functions will be

available when the ADVANCED OSD is off.

Advanced OSD is ON. All OSD functions are shown, but

some OSD functions may not be available.

English-15

On-Screen Display (OSD)

Main Menu Sub Menu Sub Menu2 Sub Menu3 Explanation Default Reset

PICTURE CONTRAST Adjusts the image brightness in relationship to the white

level. Press + or - to adjust.

50 YES

BRIGHTNESS Adjusts the image brightness in relationship to the

background. Press + or - to adjust.

50 YES

SHARPNESS Adjusts the crispness of the image. Press + or - to adjust. 50 YES

COLOR Adjusts the color depth of the screen. Press + or - to

adjust.

50 YES

TINT Adjusts the tint of the screen. Press + or - to adjust. 50 YES

PICTURE MODE Selects picture mode, [BRIGHT], [STANDARD],

[CINEMA1], [CINEMA2], [DEFAULT].

STANDARD: For watching in a bright room.

CINEMA1, 2: For watching in a dark room, especially

good for movies.

BRIGHT: Brighter picture than STANDARD.

DEFAULT: Restores factory default settings.

STANDARD YES

NR Adjusts the amount of noise reduction. Press + or - to

adjust.

OFF YES

COLOR TEMP. Adjusts the color temperature of the entire screen. A low

color temperature will make the screen reddish. A high

color temperature will make the screen bluish.

MID YES

WHITE BALANCE

Available only when

the Advanced OSD

function is enabled.

GAIN RED The "WHITE BALANCE" appears when the SET button is

pressed on the "COLOR TEMP." OSD menu.

GAIN RED/GREEN/BLUE: Adjusts the white level of the

white balance.

50 YES

GAIN GREEN 50 YES

GAIN BLUE 50 YES

RESET Resets the factory default settings. Select "ON", then

press the SET button to reset.

OFF YES

GAMMA

Available only when

the Advanced OSD

function is enabled.

Select a display gamma for best picture quality.

2.1, 2.2, 2.3, 2.4: The picture becomes darker as the

number increases.

S: Special gamma for certain types of movies. Raises

the dark parts and lowers the light parts of the image.

(S-Curve)

These values are approximate.

2.2 YES

COLOR CONTROL

Available only when

the Advanced OSD

function is enabled.

RED Adjusts the levels of the Red, Green, Blue, Yellow,

Magenta and Cyan.

VIDEO and DVD/HD input only.

50 YES

GREEN 50 YES

BLUE 50 YES

YELLOW 50 YES

MAGENTA 50 YES

CYAN 50 YES

RESET Resets the factory default settings. Select "ON", then

press the SET button to reset.

OFF YES

AUDIO BASS Adjusts the low frequency sound. Press + or - to adjust. 0 YES

TREBLE Adjusts the high frequency sound. Press + or - to adjust. 0 YES

BALANCE Adjusts the balance of L/R volume. Press + or - to adjust. 0 YES

AUDIO INPUT1 Select which audio input to use with the video source. VIDEO1 YES

AUDIO INPUT2 DVD/HD1 YES

AUDIO INPUT3 VGA YES

English

English-16

On-Screen Display (OSD)

Main Menu Sub Menu Sub Menu2 Sub Menu3 Explanation Default Reset

SCREEN ASPECT MODE Selects aspect ratio of the displayed image. Press + or

- to select.

V-POSITION Controls the vertical position of the image within the

Display area of the PDP.

Press + to move up. Press - to move down.

0YES

H-POSITION Controls the horizontal position of the image within the

Display area of the PDP.

Press + to move right. Press - to move left.

0YES

V-HEIGHT Adjusts the vertical size of the image. 0 YES

H-WIDTH Adjusts the horizontal size of the image. 0 YES

AUTO PICTURE ON: H-Position, V-Position, Clock and Clock Phase are

adjusted automatically.

OFF: H-Position, V-Position, Clock and Clock Phase are

adjusted manually.

VGA and RGBHV input only.

OFF NO

CLOCK PHASE Adjusts the visual “noise” on the image.

VGA and RGBHV input only.

0YES

CLOCK Press + to expand the width of the image on the right of

the screen.

Press - to narrow the width of the image on the left.

VGA and RGBHV input only.

0YES

UNDER SCAN

Available only when

the Advanced OSD

function is enabled.

ON: UNDERSCAN is selectable in the ASPECT MODE

menu.

OFF: UNDERSCAN item is not selectable in the ASPECT

MODE menu.

Video signal input only.

OFF YES

OPTION1 OSD DISPLAY OSD ON: Information about inputs, screen size, etc. is shown.

OFF: No information is shown.

ON YES

OSD

POSITION

Change the position of the menu between 1 and 6. Press

+ or - to adjust.

1YES

OSD ORBITER ON: The menu position intermittently shifts eight dots

while the OSD is being displayed.

OFF: The menu position does not shift.

OFF YES

OSD TRANSP. Adjusts the transparency level of the OSD.

Press + or - to adjust.

70% YES

BNC INPUT Selects the input type when using 5BNC connectors.

RGB: For RGB input.

COMP.: For Component input (3BNC connectors).

SCART1: For SCART input (4BNC connectors).

SCART2: For SCART input (3BNC connectors and VIDEO1

input).

SCART1, SCART2 available for Europe and World-Wide

models only.

RGB YES

D-SUB INPUT Selects the input type when using a mini D-SUB

connector.

RGB: For RGB input.

SCART3: for SCART input.

SCART3 available for Europe and World-Wide models

only.

RGB YES

RGB SELECT If there is a problem with signal detection, this function

forces the monitor to display the signal at the desired

resolution.

If no problem is detected, the only available option will be

“AUTO”.

VGA and RGBHV input only.

AUTO YES

HD SELECT Manually selects signal output when similar 1080I signal

are detected.

1080B: Standard digital broadcasts.

1080A: Special digital broadcasts (ex. DTC100).

1080B NO

INPUT SKIP Skips to next input if present input signal is not detected.

This function is valid only for INPUT key on the display.

OFF YES

ALL RESET Resets settings back to factory default values. OFF

English-17

On-Screen Display (OSD)

Main Menu Sub Menu Sub Menu2 Sub Menu3 Explanation Default Reset

OPTION2

Available only

when the

Advanced OSD

function is

enabled.

POWER SAVE Sets how long the monitor waits before going into power

save mode after a signal is lost.

VGA, RGBHV, and DVI input and Separate HV Sync. only.

OFF YES

FILM MODE Selects Film mode. ON YES

SCREEN SAVER Use SCREEN SAVER functions to reduce the risk of image

retention.

PLE PLE: The brightness is decreased in order of Lock mode.

(the higher number is darker)

AUTO YES

ORBITER ORBITER: The screen image moves and is slightly

squeezed or expanded.

AUTO1 YES

INVERSE

WORKING TIME

/WAITING TIME

INVERSE: The screen image is displayed alternately

between positive image and negative image, or the screen

image is displayed full white.

OFF YES

COOLING FAN Cooling fan reduces the temperature of the display. AUTO NO

SIDE MASK Adjusts the color of the side mask when a 4:3 image is

displayed.

Press + button, the bar will become lighter.

Press - button, the bar will become darker.

3YES

PICTURE SIZE When it is set to "OFF", TRUE of picture size appears only

RGB signals.

ON YES

DVI MODE PLUG/PLAY Choose the DVI mode based on the input device

connected via DVI connector and set the black level.

When a PC or similar equipment is connected, the PLUG/

PLAY setting should be "DVI-PC" and the BLACK LEVEL

setting should be "LOW".

When a DVD player or similar equipment is connected,

PLUG/PLAY setting should be "DVI-HD" and the BLACK

LEVEL setting should be "HIGH".

DVI-PC NO

BLACK LEVEL LOW NO

PROTOCOL SET Sets protocol setting for use with RS-232C connection.

OFF: When NEC protocol is used (normal).

ON: When special protocol is used.

Consult dealer for details of protocol.

OFF YES

CLOSED CAPTION

U.S. models only

Choose the closed caption setting. OFF YES

CAPTION CONT

U.S. models only

Chooses the brightness of the closed captions. NORMAL YES

OPTION3

Available only

when the

Advanced OSD

function is

enabled.

TIMER PRESENT

TIME

DAYLIGHT

SAVING

TIME

Sets the date, time, and daylight saving region.

Day & time must be set in order for the “TIMER” function

to operate.

OFF NO

DAY/HOUR/

MINUTE

TIMER Creates a working schedule for the monitor to use. See

page 24 for instructions.

OFF YES

INPUT DETECT INPUT Sets the input mode and the sound volume when the

power is turned on.

LAST: Uses the input that was last selected when the

power was turned off.

MULTI to DVI: Fixed input mode.

AUTO: Automatically searches for the input signal.

PRIORITY: Sets which input has priority when using the

AUTO setting.

LAST YES

VOLUME LAST YES

CONTROL LOCK This function completely locks out access to all Control

Key functions. When this item is set to "ON", the front

panel is disabled as soon as the on-screen menu goes off.

OFF YES

IR REMOTE When "OFF", prevents the monitor from being controlled

by wireless remote controller. The remote becomes

ineffective disabled as soon as the on-screen menu goes

off. To return to normal operation, press the “DISPLAY”

button on the remote controller for 5 seconds.

ON YES

LOOP OUT Change the loop out setting. OFF YES

MONITOR ID Sets the Monitor ID to a number from 1-26 and or to ALL. ALL YES

RS232C CONTROL Selects the mode of the monitor when using the RS-232C

daisy chain.

NORMAL YES

English

English-18

Main Menu Sub Menu Sub Menu2 Sub Menu3 Explanation Default Reset

OPTION3

(continued)

VIDEO WALL Sets the conﬁ guration of video wall.

DIVIDER Sets the video wall. OFF YES

POSITION Sets the position of each display.

DISP. MODE Sets the mode of seam processing for each display. SPLIT YES

SCREEN ASPECT

MODE

Adjusts detail position.

V-POSITION 0YES

H-POSITION 0YES

V-HEIGHT 0YES

H-WIDTH 0YES

AUTO


OFF YES

CLOCK

PHASE

0YES

CLOCK 0YES

UNDER

SCAN

OFF YES

P.ON DELAY Adjusts the delay time between being in “standby” mode

and entering “power on” mode.

OFF YES

OPTION4

Available only

when the

Advanced OSD

function is

enabled.

SUB PICTURE Automatically detects if there is an input signal for the sub

screen. This feature is available only picture-in-picture

mode.

SUB P.

DETECT

Automatically detects sub screen. AUTO YES

DISPLAY Sets the appearance of the sub screen. NORMAL YES

SUB P. RATE Sets the transparency of the sub screen. 100% YES

ZOOM NAV Sets the position of the zoom navigation image. BTM LFT YES

PIC FREEZE Sets the position of the captured still picture. S BY S1 YES

QUICK SWAP Enables quick swapping of input.

Sets which input terminals are used.

OFF YES

SELECT1 VIDEO1 YES

SELECT2 VGA YES

TEXT INSERT Allows text insertion within main screen. OFF YES

INPUT Sets the input of text image of the VGA, RGBHV, and DVI. VGA YES

SUB P.

DETECT

Automatically detects sub screen. AUTO YES

DISPLAY Sets the appearance of the sub screen. NORMAL YES

SUB P. RATE Sets the transparency of the sub screen. 100% YES

ADVANCED

OSM

ON: All menu items are shown for advanced users.

OFF: Some of the advanced menu items are not shown.

OFF YES

LANGUAGE Select the language used by the OSD. ENGLISH NO

COLOR

SYSTEM

The Color System that is used depends on the video

format of the input signal.

VIDEO input only.

AUTO NO

SOURCE

INFORMATION

Display information about the display: frequencies,

polarities, etc.

On-Screen Display (OSD)

English-19

Operation

Picture Size Using Video Signals

Select one of seven picture sizes manually.

While viewing videos or digital video discs, perform the

following actions:

1. Press the SIZE button on the remote control.

2. To switch the screen sizes, press the SIZE button again

within 3 seconds.  e available sizes are NORMAL, FULL,

DYNAMIC, ZOOM, 2.35:1, 14:9, and UNDERSCAN.

If a 720p, 1080i, or 1080p signal is displayed, the available

sizes are FULL, 2.35:1, DYNAMIC, and UNDERSCAN.

If displaying an enhanced split-screen, the available sizes are

NORMAL and FULL.

NORMAL (4:3)

Images with a 4:3 (Normal) aspect ratio are displayed.

FULL

Horizontally expands anamorphic signals to display the

correct linearity.

Normal (4:3) images are horizontally expanded to  ll the

entire screen.

DYNAMIC

Vertically and horizontally expands the picture but at

di erent aspect ratios.

ZOOM

Vertically and horizontally expands the picture while

maintaining the correct aspect ratio.

2.35:1

Image is expanded at a 2.35:1 ratio to  ll the entire screen.

 e screen is  lled vertically; however, some information

will be lost on the le and right sides of the image.

Available for the following inputs:

Video, Component, or RGB input (480I, 480P, 576I, 576P,

720P, 1080I, 1080P)

To avoid image retention, use the 2.35:1 image size if black

bars are displayed at the top and bottom of the screen

showing the displayed image.

14:9

Image is displayed at a 14:9 aspect ratio.

Available for the following inputs:

Video, Component, or RGB input (480I, 480P, 576I, 576P)

UNDERSCAN

Standard televisions crop (Underscan) images. Utilize the

UNDERSCAN function in the SCREEN menu to display the

entire image.

NOTE: Depending on the type of component used, black

borders or signal noise may appear near the screen

edges while in UNDERSCAN mode.

Over a period of time, image ghosting, shadowing,

or burn-in may result from continuous display of

underscanned images. While in UNDERSCAN

mode, the brightness may change if a Macrovision

signal is input.

NOTE: Do not display 4:3 content in NORMAL mode for

extended periods of time to avoid image ghosting,

shadowing, or burn-in.

English

English-20

Operation - continued

Picture Size Using Computer

Signals

To expand a 4:3 image to  ll the entire screen, switch to the

widescreen mode.

While viewing videos or digital video discs, perform the

following actions:

1. Press the SIZE button on the remote control.

2. To switch the screen sizes, press the SIZE button again

within 3 seconds.  e available sizes are NORMAL, FULL,

and ZOOM.

If an enhanced split-screen is displayed, the available sizes

are NORMAL and FULL.

NORMAL (4:3 or SXGA 5:4)

Images are displayed normally.

FULL

Horizontally expands anamorphic signals to display the

correct linearity.

Normal (4:3) images are horizontally expanded to  ll the

entire screen.

ZOOM

Vertically and horizontally expands the picture, while

maintaining the correct aspect ratio.

TRUE

 e image is displayed at the native resolution.

When using a VGA or SVGA signal, PICTURE SIZE in the

OPTION 2 OSD menu should be set to OFF to select TRUE

mode.

Information:

Supported resolutions: For further information on the

display output of the various VESA signal standards

supported by the unit, see pages 34 - 39.

When 1360 dot x 768 line wide XGA signals with a vertical

frequency of 60 Hz and a horizontal frequency of 47.7 kHz

are input:

1. Select an appropriate setting for the RGB SELECT mode.

2. Refer to the Resolutions Supported section of Model

Information on pages 34 - 39.

NOTE: Do not display 4:3 content in NORMAL and TRUE

mode for extended periods of time to avoid image

shadowing, ghosting, or burn-in.

English-21

Split Screen Mode

To display multiple pictures on the screen, perform the

following actions:

1. Press the desired SPLIT SCREEN function button on the

remote (PIP, S BY S, SINGLE).

Only certain RGB signals are supported.

Split Screen mode works according to the table below.

Side by Side Mode

Press the -, +, p or q buttons to change the picture size.

Press the SWAP button to swap pictures.

Press the SELECT/FREEZE button to change the active

picture.

Operation - continued

Picture displayed on the Left / Sub screen

Picture displayed on the Right / Main screen

VIDEO1 VIDEO2 S-VIDEO DVD/HD1 DVD/HD2 SCART1 SCART2 SCART3 VGA RGBHV DVI

VIDEO1 — YES YES YES YES — — — YES YES YES

VIDEO2

YES — YES YES YES — — — YES YES YES

S-VIDEO

YES YES — YES YES — — — YES YES YES

DVD/HD1 YES YES YES — YES — — — YES YES YES

DVD/HD2 YES YES YES YES — — — — YES — YES

SCART1 — — — — — — — — — — YES

SCART2 — — — — — — — — — — YES

SCART3 — — — — — — — — — — YES

VGA YES YES YES YES YES — — — — — YES

RGBHV YES YES YES YES — — — — — — YES

DVI YES YES YES YES YES YES YES YES YES YES —

VGA

SWAP

VGA

VIDEO1

VGA

SELECT/FREEZE

VIDEO1 is active.

VGA is active.

S BY S

button

VGA

S BY S

button

SINGLE

button

PIP

button

PIP

button

SINGLE

button

VGA

Side by Side4-R Side by Side3 Side by Side4-L

button

Side by Side2-R Side by Side1 Side by Side2-L

button

English

English-22

Picture-in-Picture Mode

Press the + and - buttons to change the position of the sub-

picture.

Press the p and q buttons to change the size of the sub-

picture.

Press the SELECT/FREEZE button to change the active

picture.

Displaying Input Signal

1. To make the desired picture active, press the SELECT/

FREEZE button.

2. To change the active signal, press the VIDEO, DVD/HD,

or RGB button.

 e input selection may also be changed by pressing the

INPUT button on the front of the unit.

Adjusting the OSD controls

1. To make the desired picture active, press the SELECT/

FREEZE button.

2. To display the main menu, press the MENU button.

3. Adjust the settings as desired.

NOTE: Some OSD functions may not be available in Split-

Screen mode.

Operation - continued

VGA

button

VGA

button

VGA

VIDEO1

VGA

English-23

Operation - continued

Creating a Video Wall

You can create a video wall consisting of up to 25 individual

monitors with the built-in matrix display capability. Your

Video Wall can have any of the following con gurations:

2x2, 3x3, 4x4, 5x5, 5x1, 4x1, 3x1, 2x1, 1x2, 1x3, 1x4, or 1x5.

Connect the signal cables as shown:

1. Select VIDEO WALL in the OPTION 3 OSD menu, then

press the SET button.

2. Select the desired video wall con guration in the

DIVIDER  eld.

3. Select POSITION in the VIDEO WALL menu, then press

the SET button. Appearing on the OSD is the current video

wall con guration. Select the position of the monitor for the

video wall.

NOTE: Each individual monitor within the video wall must

have its own set position.

EXTERNAL CONTROL

OUT

S-VIDEO IN

DVI AUDIO3

(MONO)

AUDIO2 AUDIO1VGA

HD VD

R/Cr/Pr G/Y B/Cb/pb

RGBHV / DVD/HD2

Y Cr/Pr Cb/Pb

DVD/HD1

IN/OUT

VIDEO

AC IN

SPEAKER (S)

Video Signal

RCA Phono Plug

(IN)

BNC connector

(OUT) to another

display

EXTERNAL CONTROL

OUT

S-VIDEO IN

DVI AUDIO3

(MONO)

AUDIO2 AUDIO1VGA

HD VD

R/Cr/Pr G/Y B/Cb/pb

RGBHV / DVD/HD2

Y Cr/Pr Cb/Pb

DVD/HD1

IN/OUT

VIDEO AC IN

SPEAKER (S)

RGB/DVD/HD Signal

BNC connector

(IN)

VGA connector

(OUT) to

another

display

NO. 16 NO. 17 NO. 18 NO. 19

NO. 20 NO. 21 NO. 22 NO. 23

NO. 24 NO. 25 NO. 26 NO. 27

NO. 28 NO. 29 NO. 30 NO. 31

NO. 5NO. 4NO. 3NO. 1 NO. 2

NO. 32 NO. 33 NO. 34 NO. 35 NO. 36

NO. 37 NO. 38 NO. 39 NO. 40 NO. 41

NO. 42 NO. 43 NO. 44 NO. 45 NO. 46

NO. 47 NO. 48 NO. 49 NO. 50 NO. 51

NO. 52 NO. 53 NO. 54 NO. 55 NO. 56

NO. 7 NO. 8 NO. 9

NO. 10 NO. 11 NO. 12

NO. 13 NO. 14 NO. 15

NO. 1 NO. 2

NO. 4 NO. 3

2 x 2 3 x 3

4 x 4 5 x 5

5 x 1

NO. 4NO. 3

NO. 3

NO. 1 NO. 2

4 x 1

NO. 1

NO. 2

NO. 3

NO. 4

NO. 5

1 x 5

NO. 1

NO. 2

3 x 1

NO. 1 NO. 2

2 x 1

NO. 1

NO. 2

NO. 3

NO. 4

1 x 4

NO. 1

NO. 2

NO. 3

1 x 3

NO. 1

NO. 2

1 x 2

Video Wall Conﬁ gurations

NOTE: 1.  e VIDEO 1 and VGA terminals may be used

either for INPUT or OUTPUT.

Do not connect an OUTPUT signal from another

unit when LOOP OUT in the OPTION 3 OSD is set

to ON, as it may damage the other unit due to an

extraordinary load.

2. While signals are input to the VGA terminal,

LOOP OUT should not be turned ON.

Information:

Set the LOOP OUT in OPTION3 to ON to loop signals out

to another plasma display.

Set the VIDEO WALL options properly when creating a

video wall.

Use the appropriate (length and e ciency) BNC cable to

connect monitors.

If the image quality is poor, do not use the monitor out

terminal to link to another monitor. Use a commercially

available distribution ampli er to connect the split signal

to the appropriate monitor INPUT terminals.

For a resolution of 1024x768 at 60 Hz (or lower), the

maximum recommended size for a viewing wall is 4

displays.

A distribution ampli er is highly recommended when

setting up a 3 x 3 (or greater) video wall.

When looping from plasma to plasma, an appropriate

(length and e ciency) 15-pin male mini D-Sub - 5BNC

conversion cable is required.

•

English

English-24

USING THE TIMER

Turn the “ADVANCED OSD” to “ON” in the MAIN MENU

to access the TIMER feature in OPTION3.

To user the TIMER feature the  rst set the internal clock and

the day of the week.  e display can also be programmed to

turn on or o at preset times, and which input the display

will use at those times.  e Program Timer which turns on

or o the power at the day of the week, time and the input

mode you want, or Repeat Timer which displays two input

modes alternately can each be set also. In the “OPTION3”

OSD menu, select “TIMER”, then press the SET button.  e

“TIMER” screen appears.

PRESENT TIME

 is sets the day of the week and present time. Example:

Setting “WEDNESDAY”, “22:05” In the “TIMER” menu,

select “PRESENT TIME”, then press the SET button.

 e “PRESENT TIME” screen appears. Set the items.

Turn DAYLIGHT SAVING TIME on if daylight

savings is observed.

Select the day of the week.

Set the clock using the 24-hour (HH/MM) format.

To accept PRESENT TIME settings, highlight “SET”* in the

PRESENT TIME OSD menu, then press the SET button to

store the settings.

* If you press the EXIT button instead of the SET button,

Timer settings will not be accepted.

PROGRAM TIMER

 e PROGRAM TIMER feature allows a series of scheduled

operation times to be set.  e display can be programmed to

run on a particular day and time while using a desired input

source. Under the Function setting (FUNC.) either a Screen

Saver setting (ORBITER, INVERSE, WHITE) or a REPEAT

TIMER program can be set for the monitor to use during the

scheduled power-on time.

NOTE: When a REPEAT TIMER program is selected as

the Function setting, the Program Timer's Input option

is not available.  e input used will use the input that is

programmed for the Repeat Timer program.

Up to 10 individual PROGRAM TIMER schedules can be

set. When schedules are set to perform functions at the same

time, the schedule with the lower number has priority. For

example schedule #1 has priority over schedule #10. When

schedules overlap, each action is sequentially executed.

Using special characters in the PROGRAM TIMER

setting.

Using an asterisk (*) alone in the DAY  eld means that the

programmed schedule will run every day.

Using the asterisk (*) and the name of the day means the

programmed schedule will run only on that day. For example

"*FRI" means that the schedule will run every Friday.

A hyphen (-) in either the ON or OFF  elds means that a

time is not set. In order to use the Program Timer, at least

either an ON or OFF time has to be set.

A hyphen (-) in the INPUT or that the monitor will use the

previously used display mode for that particular schedule.

If a Repeat Timer sequence is selected in the FUNC.  eld,

the Input  eld will show a hyphen (-).

Setting the PROGRAM TIMER using multiple inputs

Set the INPUT  eld to “MULTI”, then press the SET button.

 e “MULTI SCREEN SETTING” will appear on the screen.

Use the p and q buttons to select “MULTI MODE”, then

use the + and - buttons to choose from “S BY S1, 2R, or

2L” and “PICTURE IN PICTURE MODE (BOTTOM

LEFT~TOP LEFT)”.

Use the p and q buttons to select “MAIN”/“SUB” and

“LEFT”/“RIGHT”, then use the + and - buttons to choose

from “VIDEO1 to "DVI”.

To set “REP.1~3” as the FUNC.

Set the FUNC.  eld to “REP.1”, “REP.2” or “REP.3”, then press

the SET button.  e “REPEAT TIMER” menu will appear on

the screen.

Use the - and + buttons to choose from “SINGLE”, “S BY S 1,

2R or 2L” and “PICTURE IN PICTURE MODE (BTM LFT

to TOP LFT)”, then adjust the items.

Operation - continued

English-25

Operation - continued

REPEAT TIMER

 e Repeat Timer allows the display to alternate between

inputs at user-determined intervals.

For example the display can be programmed to show the

signal from "VIDEO1" for 10 minutes and then switch to

showing the signal from the DVI input for 10 minutes.

To set the Repeat Timer select "REPEAT" in the Timer

menu, then press the SET button. To enter the REPEAT

TIMER OSD screen.  en make the desired settings.

STATE Settings

 ere are 4 possible state settings to use. When all four

STATES are set to "ON, the repeat timer schedules will

operate consecutively (State1, State2, State3, State4, State1,

State2, State3...).

When a STATE setting is set to OFF, i.e. STATE1-ON,

STATE2-ON, STATE3-OFF, STATE4-ON, the repeat timer

schedules use all but STATE3 (State1, State2, State4, State1,

State2...).

Repeat Timer activates when the OSD menu is exited.

For SINGLE display con gurations

WORK TIME: Set the time duration of the schedule. Time

range is from 1 minute to 24 hours.

INPUT MODE: Choose the signal that will be used.

MULTI settings

MODE: Select the input mode to be displayed as “SINGLE”,

“S BY S 1, 2R or 2L” or “PICTURE IN PICTURE MODE

(BTM LFT~TOP LFT)”.

WORK TIME: Set the time duration of the schedule. Time

range is from 1 minute to 24 hours.

INPUT MODE: Choose the signal that will be used.

Select “MAIN” or “SUB” for “PICTURE IN PICTURE

MODE (BTM LFT~TOP LFT)” and “LEFT” or “RIGHT” for

“S BY S1, 2R or 2L”.

Only one signal is selected for “SINGLE”.

English

English-26

 is monitor uses RXD, TXD and GND

lines for RS-232C control.

 e reverse type cable (null modem cable)

should be used for RS-232C control.

 is Plasma monitor can be controlled via personal

computer using an RS-232C connection.

MONITOR ID and RS-232C CONTROL

Up to 26 individual monitors can be controlled through a

daisy chain via RS-232C connection.

1. Connect PC to the monitor.

Connect a PC’s RS-232C control output to the monitor's

RS-232C input. You can then connect the

RS-232C output from this monitor to another monitor’s

RS-232C input. Up to 26 monitors can be connected

using RS-232C.

2. Set Monitor ID and RS-232C Control mode.

For proper operation, the Monitor ID should be set

in the OSD menu of each monitor that is in the chain.

 e Monitor ID can be set under the “OPTION3”

menu in the OSD.  e Monitor ID number can be set

within a range from 1 to 26 or set to "ALL". No two

monitors should share the same Monitor ID number.

It is recommended to number each monitor in a daisy

chain sequentially from 1.  e  rst monitor in the daisy

chain is designated as the primary monitor. Subsequent

monitors with the chain are secondary monitors.

In the “OPTION3” menu on the  rst monitor in the

RS-232C daisy chain set the "RS232C CONTROL" to

"NORMAL". Set the "RS232C CONTROL" to “2ND”

on all other monitors.

Functions that can be controlled via RS-232C:

Powering ON or OFF

Switching input signals

NOTE: If your PC (IBM or IBM compatible) is equipped

only with a 25-pin serial port connector, a 25-pin

serial port adapter is required. Contact your dealer

for details.

NOTE: In order to function, the RS-232C OUT terminal

can only be connected to another monitor of the

same model. Do not connect to other types of

equipment.

•

RS-232C

EXIT MUTEINPUT EXIT MUTEINPUT

(Out)

RS-232C Cable RS-232C Cable

RS-232C (IN)

RS-232C (OUT)

OUT

RS-232C (IN)

RS-232C (OUT)

English-27

RS-232C - continued

 e following control sequence is used for a single monitor

When using the following control commands, all of the daisy-chained monitors

can be controlled at the same time from the primary monitor. However, reply and

status commands will only pertain to the primary monitor, and not to the secondary

monitors.

1) Interface

PROTOCOL RS-232C

BAUD RATE 9600 [bps]

DATA LENGTH 8 [bits]

PARITY BIT NONE

STOP BIT 1 [bit]

FLOW CONTROL NONE

2) Control command diagram

 e command is structured by the address code, function code, data code and end

code.  e length of the command is di erent for each function.

Address Code Function Code Data Code End Code

HEX 30h 30h Function Data 0Dh

ASCII '0' '0' Function Data

[Address code] 30h 30h (In ASCII code, '0' '0')  xed.

[Function code] A code of each  xed control move.

[Data code] A code of each  xed control data (number) and

not always indicated.

[End code] 0Dh (In ASCII code,

'' )  xed.

To control multiple monitors that are daisy-

chained together please use the extended control

command.

English

English-28

RS-232C - continued

3) Control sequence

1)  e command from a computer to the Plasma monitor will take 400ms.

2)  e Plasma monitor will send a return command 400ms* a er it has received

an encode. If the command is not received correctly,

the Plasma monitor will not send the return command.

3)  e personal computer checks the command and con rms if the

command which has been sent has been executed or not.

4)  is Plasma monitor sends various codes other than the return code. When

sending a control sequence via RS-232C, other codes from personal

computers will be ignored.

* e sending time of the return command may be delayed depending on the

monitor’s current activity (changing of the input signal, etc.).

[Example] Turn the power ON. (' ' is for ASCII code)

Sending commands

from the PC etc.

Status code from

Plasma monitor

Meaning

30 30 21 0D

'0' '0' '!' ' '

Command for

POWER ON

30 30 21 0D

'0' '0' '!' ' '

Command received

(Command echo back)

4) Operation commands

Operation commands execute the basic operation setting of this Plasma

monitor. It may not operate when changing the signal:

Operation ASCII HEX

POWER ON ! 21h

POWER OFF " 22h

INPUT VIDEO1 _v1 5Fh 76h 31h

INPUT VIDEO2 _v4 5Fh 76h 34h

INPUT S-VIDEO _v3 5Fh 76h 33h

INPUT DVD/HD1 _v2 5Fh 76h 32h

INPUT DVD/HD2 _v5 5Fh 76h 35h

INPUT SCART3 _v6 5Fh 76h 36h

INPUT VGA _r2 5Fh 72h 32h

INPUT RGBHV _r3 5Fh 72h 33h

INPUT DVI _r1 5Fh 72h 31h

POWER OFF command should not be used less than 1 minute a er the power is

turned on.

POWER ON command should not be used less than 1 minute a er the power is

turned o .

•

English-29

Structure of the Read-command

ASCII HEX

Function Data Function Data

POWER ON vP 1 76h 50h 31h

POWER OFF vP 0 76h 50h 30h

INPUT VIDEO1 vI v1 76h 49h 76h 31h

INPUT VIDEO2 vI v4 76h 49h 76h 34h

INPUT S-VIDEO vI v3 76h 49h 76h 33h

INPUT DVD/HD1 vI v2 76h 49h 76h 32h

INPUT DVD/HD2 vI v5 76h 49h 76h 35h

INPUT SCART3 vI v6 76h 49h 76h 36h

INPUT VGA vI r2 76h 49h 72h 32h

INPUT RGBHV vI r3 76h 49h 72h 33h

INPUT DVI vI r1 76h 49h 72h 31h

Picture Mode BRIGHT vM p1 76h 4Dh 70h 31h

Picture Mode STANDARD vM p2 76h 4Dh 70h 32h

Picture Mode CINEMA1 vM p3 76h 4Dh 70h 33h

Picture Mode CINEMA2 vM p4 76h 4Dh 70h 34h

Picture Mode DEFAULT vM p5 76h 4Dh 70h 35h

5) Read command

Host computer sends the command without Data-code to monitor.

A er receiving this command, the monitor returns the command with Data-code

of current status to host computer.

<ex> When the Host computer checks the Power status of monitor, the status of

monitor is powered-on.

Command from

computer

Command from

Monitor

Detail of command

30 30 76 50 0D

‘0’’0’’v’’P’[enter]

Ask about the power

status of monitor.

30 30 76 50 31 0D

‘0’’0’’v’'P'’1’[enter]

Monitor is powered-on.

RS-232C - continued

English

English-30

Troubleshooting

No picture

 e signal cable should be properly connected to the display

card/computer.

 e display card should be properly seated in its slot.

Front Power Switch and computer power switch should be in

the ON position.

Check to make sure that a supported mode has been selected

on the display card or system being used. (Please consult

display card or system manual to change graphics mode.)

Check the monitor and your display card with respect to

compatibility and recommended settings.

Check the signal cable connector for bent or pushed-in pins.

Power Button does not respond

Unplug the power cord of the monitor from the AC outlet to

turn o and reset the monitor.

Image persistence

Please be aware that Plasma Technology may experience a

phenomena known as Image Persistence. Image Persistence

occurs when a residual or “ghost” image of a previous image

remains visible on the screen. Unlike CRT monitors, Plasma

monitors’ image persistence is not permanent, but constant

images being displayed for a long period of time should be

avoided. To alleviate image persistence, turn o the monitor

for as long as the previous image was displayed. For example,

if an image was on the monitor for one hour and a residual

image remains, the monitor should be turned o for one hour

to erase the image.

NOTE: As with all personal display devices, NEC DISPLAY

SOLUTIONS recommends displaying moving images and

using a moving screen saver at regular intervals whenever the

screen is idle or turning o the monitor when not in use.

Image is unstable, unfocused or

swimming is apparent

Signal cable should be properly attached to the Plasma

monitor, computer, or other input device.

Use the OSD screen controls to focus and adjust display by

increasing or decreasing the clock phase total. When the

display mode is changed, the OSD Image Adjust settings may

need to be readjusted.

Check the monitor and your display card with respect to

compatibility and recommended signal timings.

Image of component signal is greenish

Check to see if the DVD/HD input connector is selected.

LED on monitor is not lit

(no green or red color can be seen)

Main Power Switch should be in the ON position and power

cord should be connected.

Red LED on monitor is blinking

A certain failure might have occurred, please contact your

nearest authorized NEC DISPLAY SOLUTIONS service

facility.

•

Display image is not sized properly

Use the OSD screen controls to increase or decrease the clock

total.

Check to make sure that a supported mode has been selected

on the display card or system being used. (Please consult

display card or system manual to change graphics mode.)

Selected resolution is not displayed properly

Use OSD information to enter Information menu and con rm

that the appropriate resolution has been selected. If not, select

appropriate resolution.

No Sound

Check to see if speaker cable is properly connected.

Check to see if mute is activated.

Check to see if volume is set at minimum.

NOTE: It is possible to play audio from a source that is di erent

from the video source.

RS-232C does not work

Check the PROTOCOL SET in the OPTION2 menu.

Remote Control does not work

Make sure the batteries are inserted properly.

Test the batteries for strength/life.

Make sure to point the remote directly at the sensor on the

monitor.

Check if the remote is in Remote ID mode.

 e remote control may not function when in direct sunlight

or when there is strong illumination on the remote sensor of

the monitor.

Check the IR REMOTE setting in the OPTION3 menu.

•

English-31

Speciﬁ cations P42XP10

PDP Module Diagonal: 42 "/1058 mm

Pixel Pitch 0.900 mm (W)/0.676 mm (H)

Resolution 1024 x 768

Frequency Horizontal ANALOG: 15.625/15.734kHz, 31.0kHz - 108.5kHz

DIGITAL: 15.625/15.734kHz, 31.0kHz - 91.1kHz

Vertical 24Hz to 120.4Hz

Panel Display Size 922 mm (W) x 519 mm (H)

36.3 in (W) x 20.4 in (H)

Input Signals DVI DVI-D 24pin Digital RGB DVI (HDCP)

VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*, 1920X1080*

VGA 15pin Mini D-sub Analog RGB 0.7V p-p, Input Impedance 75 ohm

VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*

Sync Separate: TTL level (Pos./Neg.)

Composite sync on Green Video: 0.3Vp-p Neg

RGBHV BNC (R,G,B,H,V) Analog RGB 0.7V p-p, Input Impedance 75 ohm

GA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*

Sync Separate: TTL level (Pos./Neg.)

Composite sync on Green Video: 0.3Vp-p Neg.

DVD/HD RCA (Y, Cb/Pb, Cr/Pr) Component Y : 1.0Vp-p/75ohm, Cb/Cr (Pb/Pr) : 0.7Vp-p/75 ohm

HDTV/DVD:1080p*, 1080i*, 720p@50Hz/60Hz,

576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz

VIDEO1 BNC Composite 1.0V p-p Input Impedance 75 ohm

NTSC/PAL(B, G, M, N)/SECAM/4.43NTSC/PAL60

VIDEO2 RCA Composite 1.0V p-p Input Impedance 75 ohm

NTSC/PAL(B, G, M, N)/SECAM/4.43NTSC/PAL60

S-VIDEO DIN 4 pin S-VIDEO Y: 1.0Vp-p/75ohm C: 0.286Vp-p/75 ohm(NTSC),

0.3Vp-p/75ohm(PAL/SECAM)

NTSC/PAL(B, G, M, N)/SECAM/4.43NTSC/PAL60

Output Signal (VIDEO1

and VGA can also be used

as OUTPUT terminals)

VGA 15pin Mini D-sub Analog RGB Analog RGB Video: 0.7V p-p with 75 ohm terminated

Separate HV sync: TTL level (Pos / Neg)

VIDEO1 BNC Composite Composite 1.0V p-p with 75 ohm terminated

Audio AUDIO Input RCA (L/R) X3 Analog Audio Stereo L/R 0.5Vrms

Speaker Output External Speaker Jack 8W + 8W (8 ohm)

External Control RS-232C: IN 9 Pin D-sub

RS-232C: OUT 9 Pin D-sub (daisy chain)

Power Supply 4.4-1.8A@100-240V AC, 50/60Hz

Operational Environment Temperature 0˚ to 40˚C / 32˚ F to 104˚ F

Humidity 20% to 80% (without condensation)

Storage Environment Temperature -10˚C to 50˚C / 14˚ F to 122˚F

Humidity 10 - 90% (without condensation)/ 90% - 2% x (Temp - 40°C) regarding over 40°C

Dimensions Net 1036mm(W) x 644mm(H) x 127mm(D) / 40.8"(W) x 25.4"(H) x 5.0"(D)

Gross 1220mm(W) x 900mm(H) x 360mm(D) / 48.0"(W) x 35.4"(H) x 14.2"(D)

We ig ht

(without speaker and stand )

Net 33.5 kg / 73.9 lbs

Gross 41.5 kg / 91.5 lbs

VESA compatible arm

mounting interface

700mm x 300mm 4 Holes (screw M8 Depth 16mm)

Complied Regulatory

and Guidelines

UL 60950-1/CSA C22.2 No.60950-1/EN60950-1/IEC60950-1

FCC-B/DOC-B/EN55022-B/EN55024/EN61000-3-2/EN61000-3-3/CE/C-Tick

Power Management VESA DPM (Separate HV Sync. only)

Plug & Play VESA DDC2B

Accessories Remote control, AA Batteries, Power cord, Users Manual (CD-ROM),

Start Up Guide (Paper / CD-ROM), Main Power Switch cover and screw, Cable clamps

*Compressed Image

English

English-32

Speciﬁ cations P50XP10

PDP Module Diagonal: 50"/1269 mm

Pixel Pitch 0.81 mm (W)/0.81 mm (H)

Resolution 1365 x 768

Frequency Horizontal ANALOG: 15.625/15.734kHz, 31.0kHz - 108.5kHz

DIGITAL: 15.625/15.734kHz, 31.0kHz - 91.1kHz

Vertical 24Hz to 120.4Hz

Panel Display Size 1106 mm (W) x 622 mm (H)

43.5 in (W) x 24.5 in (H)

Input Signals DVI DVI-D 24pin Digital RGB DVI (HDCP)

VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*, 1920X1080*

VGA 15pin Mini D-sub Analog RGB 0.7V p-p, Input Impedance 75 ohm

VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*

Sync Separate: TTL level (Pos./Neg.)

Composite sync on Green Video: 0.3Vp-p Neg

RGBHV BNC (R,G,B,H,V) Analog RGB 0.7V p-p, Input Impedance 75 ohm

VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*

Sync Separate: TTL level (Pos./Neg.)

Composite sync on Green Video: 0.3Vp-p Neg.

DVD/HD RCA (Y, Cb/Pb, Cr/Pr) Component Y : 1.0Vp-p/75ohm, Cb/Cr (Pb/Pr) : 0.7Vp-p/75 ohm

HDTV/DVD:1080p*, 1080i*, 720p@50Hz/60Hz,

576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz

VIDEO1 BNC Composite 1.0V p-p Input Impedance 75 ohm

NTSC/PAL(B, G, M, N)/SECAM/4.43NTSC/PAL60

VIDEO2 RCA Composite 1.0V p-p Input Impedance 75 ohm

NTSC/PAL(B, G, M, N)/SECAM/4.43NTSC/PAL60

S-VIDEO DIN 4 pin S-VIDEO Y: 1.0Vp-p/75ohm C: 0.286Vp-p/75 ohm(NTSC),

0.3Vp-p/75ohm(PAL/SECAM)

NTSC/PAL(B, G, M, N)/SECAM/4.43NTSC/PAL60

Output Signal (VIDEO1

and VGA can also be used

as OUTPUT terminals)

VGA 15pin Mini D-sub Analog RGB Analog RGB Video: 0.7V p-p with 75 ohm terminated

Separate HV sync: TTL level (Pos / Neg)

VIDEO1 BNC Composite Composite 1.0V p-p with 75 ohm terminated

Audio AUDIO Input RCA (L/R) X3 Analog Audio Stereo L/R 0.5Vrms

Speaker Output External Speaker Jack 8W + 8W (8 ohm)

External Control RS-232C: IN 9 Pin D-sub

RS-232C: OUT 9 Pin D-sub (daisy chain)

Power Supply 6.0-2.6A@100-240V AC, 50/60Hz

Operational Environment Temperature 0˚ to 40˚C / 32˚ F to 104˚ F

Humidity 20% to 80% (without condensation)

Storage Environment Temperature -10˚C to 50˚C / 14˚ F to 122˚F

Humidity 10 - 90% (without condensation)/ 90% - 2% x (Temp - 40°C) regarding over 40°C

Dimensions Net 1221mm(W) x 743mm(H) x 127mm(D) / 48.1"(W) x 29.3"(H) x 5.0"(D)

Gross 1400mm(W) x 980mm(H) x 360mm(D) / 55.1"(W) x 38.6"(H) x 14.2"(D)

We ig ht

(without speaker and stand )

Net 47.5 kg / 104.7 lbs

Gross 57.5 kg / 126.8 lbs

VESA compatible arm

mounting interface

700mm x 300mm 4 Holes (screw M8 Depth 16mm)

Complied Regulatory

and Guidelines

UL 60950-1/CSA C22.2 No.60950-1/EN60950-1/IEC60950-1

FCC-B/DOC-B/EN55022-B/EN55024/EN61000-3-2/EN61000-3-3/CE/C-Tick

Power Management VESA DPM (Separate HV Sync. only)

Plug & Play VESA DDC2B

Accessories Remote control, AA Batteries, Power cord, Users Manual (CD-ROM),

Start Up Guide (Paper / CD-ROM), Main Power Switch cover and screw, Cable clamps

*Compressed Image

English-33

Speciﬁ cations P60XP10

PDP Module Diagonal: 60"/1514 mm

Pixel Pitch 0.966 mm (W)/0.966 mm (H)

Resolution 1366 x 768

Frequency Horizontal ANALOG: 15.625/15.734kHz, 31.0kHz - 108.5kHz

DIGITAL: 15.625/15.734kHz, 31.0kHz - 91.1kHz

Vertical 24Hz to 120.4Hz

Panel Display Size 1320 mm (W) x 742 mm (H)

51.9 in (W) x 29.2 in (H)

Input Signals DVI DVI-D 24pin Digital RGB DVI (HDCP)

VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*, 1920X1080*

VGA 15pin Mini D-sub Analog RGB 0.7V p-p, Input Impedance 75 ohm

VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*

Sync Separate: TTL level (Pos./Neg.)

Composite sync on Green Video: 0.3Vp-p Neg

RGBHV BNC (R,G,B,H,V) Analog RGB 0.7V p-p, Input Impedance 75 ohm

VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*

Sync Separate: TTL level (Pos./Neg.)

Composite sync on Green Video: 0.3Vp-p Neg.

DVD/HD RCA (Y, Cb/Pb, Cr/Pr) Component Y : 1.0Vp-p/75ohm, Cb/Cr (Pb/Pr) : 0.7Vp-p/75 ohm

HDTV/DVD:1080p*, 1080i*, 720p@50Hz/60Hz,

576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz

VIDEO1 BNC Composite 1.0V p-p Input Impedance 75 ohm

NTSC/PAL(B, G, M, N)/SECAM/4.43NTSC/PAL60

VIDEO2 RCA Composite 1.0V p-p Input Impedance 75 ohm

NTSC/PAL(B, G, M, N)/SECAM/4.43NTSC/PAL60

S-VIDEO DIN 4 pin S-VIDEO Y: 1.0Vp-p/75ohm C: 0.286Vp-p/75 ohm(NTSC),

0.3Vp-p/75ohm(PAL/SECAM)

NTSC/PAL(B, G, M, N)/SECAM/4.43NTSC/PAL60

Output Signal (VIDEO1

and VGA can also be used

as OUTPUT terminals)

VGA 15pin Mini D-sub Analog RGB Analog RGB Video: 0.7V p-p with 75 ohm terminated

Separate HV sync: TTL level (Pos / Neg)

VIDEO1 BNC Composite Composite 1.0V p-p with 75 ohm terminated

Audio AUDIO Input RCA (L/R) X3 Analog Audio Stereo L/R 0.5Vrms

Speaker Output External Speaker Jack 8W + 8W (8 ohm)

External Control RS-232C: IN 9 Pin D-sub

RS-232C: OUT 9 Pin D-sub (daisy chain)

Power Supply 7.8-3.2A@100-240V AC, 50/60Hz

Operational Environment Temperature 0˚ to 40˚C / 32˚ F to 104˚ F

Humidity 20% to 80% (without condensation)

Storage Environment Temperature -10˚C to 50˚C / 14˚ F to 122˚F

Humidity 10 - 90% (without condensation)/ 90% - 2% x (Temp - 40°C) regarding over 40°C

Dimensions Net 1447(W)mm x 871mm(H) x 127mm(D) / 57.0"(W) x 34.3"(H) x 5.0"(D)

Gross 1620mm(W) x 1100mm(H) x 360mm(D) / 63.8"(W) x 43.3"(H) x 14.2"(D)

We ig ht

(without speaker and stand )

Net 68.5 kg / 151.0 lbs

Gross 81.0 kg / 178.6 lbs

VESA compatible arm

mounting interface

700mm x 300mm 4 Holes (screw M8 Depth 16mm)

Complied Regulatory

and Guidelines

UL 60950-1/CSA C22.2 No.60950-1/EN60950-1/IEC60950-1

FCC-B/DOC-B/EN55022-B/EN55024/EN61000-3-2/EN61000-3-3/CE/C-Tick

Power Management VESA DPM (Separate HV Sync. only)

Plug & Play VESA DDC2B

Accessories Remote control, AA Batteries, Power cord, Users Manual (CD-ROM),

Start Up Guide (Paper / CD-ROM), Main Power Switch cover and screw, Cable clamps

*Compressed Image

English

English-34

Specification of the signal

Sig.

EURT

OZL

FLA

LUF

fVnoi

no. m

N.r

)

(

)

(

)

(

)

(

animret)z

(

)ZH

(

epyTlan

H X V

IBM PC/AT 1

640 X 400 400line 70.1 31.5

VGA

-- Yes -- - - DVI

-- -- -- - -

Yes Yes

Neg. Neg. 1 640X400

Compatible

2 720 X 400 400line 70.1 31.5

RGBHV -- Yes -- Yes (DVI-PC)

-- Yes -- Yes Yes Yes

Neg. Neg. 1 720X400

Computers s

Y-

-s

Yes Yes

Neg. Pos. - - - -

4 720 X 350 350line s

Y-

-s

eY--

Y--

.07 Yes Yes

Neg. Neg. 1 720X350

5 640 X 480 VGA 59.9 31.5 Yes Yes Yes Yes Yes Yes Yes Yes

Yes Yes

Neg. Neg. 2 640X480

eYs

Y9.738.276

Yes Yes

Neg. Neg. - - - -

Yse

77 Yes Yes

Neg. Neg. - - - -

eYse

seYs

Yse

seY3.34588 Yes Yes Neg. Neg. - - - -

Y1.154.0019 Yes Yes

Neg. Neg. - - - -

eYs

Y3.1

.02101 Yes Yes

Neg. Neg. - - - -

11 848 X 480 Wide-VGA

Y-

-s

Y-

-s

--13

Yes Yes

Pos. Pos. 2 848X480

852 X 480 Wide-VGA s

Y--

Y-

-s

Y-

-s

Y-

-7.1306 Yes Yes

Neg. Neg. 2 852X480

800 X 600 SVGA 56.3 35.2 Yes Yes Yes Yes Yes Yes Yes Yes

Yes Yes

Pos. Pos. - - - -

Y9.

1 Yes Yes

Pos. Pos. - - - -

Yse

eY1.842.2751

Yes Yes

Pos. Pos. - - - -

eYs

seY

.645761

Yes Yes

Pos. Pos. - - - -

7.3

Yes Yes

Pos. Pos. - - - -

Yse

YseY

68.

Yes Yes

Pos. Pos. - - - -

Yse

seYs

219

Yes Yes Pos. Pos. - - - -

20 1024 X 768 XGA 60 48.4 Yes Yes Yes - - Yes Yes Yes - -

Yes Yes

Neg. Neg. 3 1024X768

eYs

eYseY

.651.0712

Yes Yes

Neg. Neg. 5 1024X768

Y--

seY

9.75

9.1722

Yes Yes

Neg. Neg. 6 1024X768

Yse

Y06

5732

Yes Yes

Pos. Pos. - - - -

Yse

eY-

eYs

Y7.865842

Yes Yes

Pos. Pos. - - - -

-se

.086

.001

Yes - -

Neg. Neg. - - - -

--seYs

Yse

5.594

.91

162 Yes - -

Neg. Neg. - - - -

27 1152 X 864 XGA 60 53.7 Yes Yes Yes - - Yes Yes Yes - -

Yes Yes Pos. Neg. - - - -

-s

YseYseY9.462782

Yes Yes

Pos. Neg. - - - -

Yse

eYseY

Y5.765792

Yes Yes

Pos. Pos. - - - -

1280 X 768 Wide-XGA -----

seY

-1

Yes Yes

Pos. Pos. - - - -

seY------seY--8

48.9513

Yes Yes

Pos. Neg. 3 1280X768-1

seY--

---seY

-8

Yes Yes

Neg. Pos. 3 1280X768-2

eY-

58.

Yes Yes

Neg. Pos. 5 1280X768

Y--

---

seY--8.75274

3 Yes Yes

Neg. Pos.

6 1280X768

1280 X 800 Wide-XGA

----

Y--

.94

.95 Yes Yes

Neg. Pos. 4 1280X800

36 1280 X 854 Wide-XGA

-s

Y------seY--1.3506 Yes Yes

Neg. Neg. - - - -

1280 X 960 Wide-XGA --

Yse

Y--

seYseY

606 Yes Yes

Pos. Pos. - - - -

-seYseYseY--2*seY

2*seY2*seY9

.58588

3 Yes - - Pos. Pos. - - - -

1360 X 768 Wide-XGA -

-se

6 Yes Yes

Pos. Pos. 3 1360X768

1376 X 768 Wide-XGA -

-se

--3

5 Yes Yes Neg. Pos. 3 1376X768

1280 X 1024 SXGA

60 64 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes Yes

Pos. Pos. 9 1280X1024

--seY

1*se

Y-

-se

5724

Yes - - Pos. Pos. - - - -

--seYseY1*seY--2

Y2*s

Y2*1*s

Y1.1958

4 Yes - - Pos. Pos. - - - -

2*seY

1*seY

.8011.0014

Yes - - Pos. Pos. - - - -

1400 X 1050 SXGA+

YseYse

Yse

seY460

Yes - -

Neg. Pos. 9 1400X1050

Yse

YseY

eY3.560664

Yes - -

Neg. Pos. 7 1400X1050

--seY

eYseY--2*seY2*

eY2*

.28

774 Yes - - Neg. Pos. - - - -

------

2*seY

Y9.

4 Yes - -

Neg. Pos. - - - -

1680 X 1050 Wide-SXGA

-seY-----

.5606 Yes - - Neg. Pos. 7 1680X1050

1600 X 1200 UXGA

60 75 Yes *2 Yes *2 Yes *2 - - Yes Yes Yes - - Yes - - Pos. Pos. 8 1600X1200

----------2

Y2*s

Y2*se

Y3.1856

15 Yes - -

Pos. Pos. - - - -

---

--2*s

Y2*seY2*se

.780725 Yes - - Pos. Pos. - - - -

------

---2*seY2*seY2*seY8.3957

5 Yes - - Pos. Pos. - - - -

---2

Y2*s

Y2*se

Y3.

5 Yes - - Pos. Pos. - - - -

1920 X 1080

----seY-----

----2.6505 Yes - - Pos. Pos. - - - -

---

seY

-----

-5

65 Yes - - Pos. Pos. - - - -

57 1920 X 1200 Wide-UXGA -

----2*seY--6.

79.

Yes - -

Neg. Pos. 8 1920X1200

58 1920 X 1200RB Wide-UXGA ----seY-

-----2*seY--4706 Yes - - Neg. Pos. - - - -

Apple Macintosh®

640 X 480 Mac13" ---------

eY53

6 Yes Yes Sync on G Sync on G - - - -

82 832 X 624 Mac16" 74.6 49.7 Yes Yes Yes - - - - - - - - - -

Yes Yes

Sync on G Sync on G - - - -

1024 X 768 Mac19"

74.9 60.2 Yes Yes Yes - - - - - - - - - - Yes Yes Sync on G Sync on G - - - -

1152 X 870 Mac21" 75.1 68.7 Yes Yes Yes -- -- -- -- - - Yes Yes Sync on G Sync on G - - - -

85 1440 X 900 Apple17 ----

eY--

-seY--9

.55

.95 Yes Yes Neg. Pos. - - - -

EWS Series

Work Station EWS4800 60 64.6 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes - - Neg. Neg. - - - -

92 1280 X 1024

71.2 75.1 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes - - Neg. Neg. - - - -

1280 X 1024 HP

72 78.1 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes - - - - - - - -

1152 X 900 SUN

66 61.8 Yes Yes Yes - - Yes Yes Yes - -

Yes Yes C Sync C Sync - - - -

1152 X 900

76 71.7 Yes Yes Yes - - Yes Yes Yes - - Yes Yes

C Sync C Sync - - - -

96 1280 X 1024

76.1 81.1 Yes *1 Yes Yes - - Yes *1 Yes Yes - -

Yes - - C Sync C Sync - - - -

1024 X 768 SGI 60 49.7 Yes Yes Yes - - Yes Yes Yes - - Yes - - - - 4 1024X768

1280 X 1024

60 63.9 Yes *1 Yes Yes - - Yes *1 Yes Yes - -

Yes - - - - - - - -

Dgolan

TEXT INSERT

Sync polarity RGB select

ZIS

TOP1-3/MID HIGH/

MID LOW/BOTTOM1-3

Left/Right

P42XP10 Supported Resolutions (PC)

- - NORMAL (4: 3) FULL(16:9) (*1) (*2)

Not Supported 768 pixels x 768 lines 1024 pixels x 768 lines Aspect ratio is 5:4 (720x768) Rough Sampling

English-35

P42XP10 Supported Resolutions (Video)

Specification of the signal

Sig.

MANY

TUP

REDN

41M

ulo

no.

H X V Signal Type (Hz) (kHz) terminal (4:3) (16:9)

(non-linear)

SCAN terminal (4:3) (16:9)

(non-linear)

SCAN Gr. No. Item Item

Video 101 3.58NTSC

59.9 15.8

Video1

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

Composite / S 102

4.43NTSC

59.9 15.8 Video2

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

103 PAL

50 15.6

S-Video

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

104 PAL60 -

3*se

Yse

8.5

105

PAL-N -

---

3*s

eYs

106 PAL-M -

3*s

Yse

seY8.5

9.95

107 SECAM -

3*s

eYse

Y,Pb(Cb),Pr(Cr) SD 111 480I 59.9 15.8

DVD/HD1 Yes Yes Yes Yes Yes Yes Yes *3 - - - - - - - - - - - - - - - - - - - -

112 576I 50 15.6

DVD/HD2

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

113 480P --

---

------

eYse

Yse

.95

114

576P -

---

eYseYseYs

eYs

eY3.1305

115 720P ---

-------

eY-

-s

eYse

116

720P -----

------3

eY--

eYse

-5

117 1080I

------

-s

eYs

118 1080I

---

eY-

-s

eYs

330

119 1080P --

------

eYse

Y-

eYse

--3.65

120 1080P

------

---3*se

seY----

eYse

--5.7606

121 1080P

3*se

Y-

-se

YseY-

303

122 1080P

-se

seY-

-7242

123 1080P

3*s

Y-

--seYs

--8

RGB(Video signal) SD 131

480I *4 59.9 15.8 VGA

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

132 576I *4 50 15.6 RGBHV Yes Yes Yes Yes Yes Yes Yes *3 - - - - - - - - - - - - - - - - - - - -

133 480P 59.9 31.5 (SCART1-3) Yes Yes Yes Yes Yes Yes Yes *3 - - - - - - - - - - - - - - 2 480P - -

134 576P

eYseY

Yse

seY

eY3

HD 135

720P

---

*seYse

Y-

eYs

Y--5.7

136

720P -------

---------

eY-

--se

Y--5

137

1080I -

---

Y-

Y--1

138 1080I B0

---

------

eYse

---seYse

306

139

1080P --

----

-------

-3*seYse

---

-3

140

1080P

3*s

Y--

-seY

.760

141

1080P

---

3*se

Y---

-s

eYs

Y-

8.33

142

1080P

3*se

Y-

eYs

--7242

143 1080P -------

------------

*seYseY----seYseY--8252

144

1080A/540P RCA STB

---

----

3*se

-8

Digital SD

161

640 X 480P 59.9 / 60.0 31.5 / 31.5 - - - - - - - - - - - - - -

DVI

Yes *3 Yes *3 Yes *3 Yes *3 Yes *3 Yes *3 Yes *3 - - - - - -

(EIA/CEA-861)

162

720 (1440) X 480I 59.9 / 60.0 15.7 / 15.8 - - - - - - - - - - - - - -

(DVI-HD) Yes Yes Yes Yes Yes Yes Yes *3 - - - - - -

163

720 X 480P 59.9 / 60.0 31.5 / 31.5 -- -- -- -- -- -- -- Yes Yes Yes Yes Yes Yes Yes *3 -- -- - -

164 720 (1440) X 576I

3*s

---

165 720 X 576P

---

3*se

eY-

-----------3.1305

HD 166

1280 X 720P

59.9 / 60.0 45.0 / 45.0 -- -- -- -- -- -- -- -- Yes Yes -- -- Yes Yes *3 -- -- - -

167 1920 X 1080I 59.9 / 60.0 33.7 / 33.8 - - - - - - - - - - - - - - - - Yes Yes - - - - Yes Yes *3 - - - - - -

168 1920 X 1080P 59.9 / 60.0 67.4 / 67.5 - - - - - - - - - - - - - - - - Yes Yes - - - - Yes Yes *3 - - - - - -

169 1280 X 720P -

5.73

170

1920 X 1080I -----

3*s

-se

------

---

-1

171 1920 X 1080P ---

3*s

eY-

-se

-----

172 1920 X 1080P

-----3*seYseY----s

YseY----

------------8.3303

173 1920 X 1080P

3*se

eY-

-s

eY--

---

--7

174 1920 X 1080P -

---

3*se

-s

-----------

-----8252

Native

191

1366 X 768

---

3*se

Y----------------3

.74

Resolution 192 1024 X 768 -

---

-----------3.7406

193 853 X 480 -

-3

seY

---

-------

---0306

SIZE SIZE

RGB select

nal

Digita

- - NORMAL(4:3) FULL(16:9) (*3) (*4)

Not Supported 768 pixels x 768 lines 1024 pixels x 768 lines Displayed by Underscan mode (100%) SCART input available

English

English-36

Specification of the signal

Sig.

TMOO

UFL

RONT

MOO

LUF

oitul

seR

no.

VH)

(

)

(

)

()

(

yTl

H X V

IBM PC/AT

640 X 400 400line

70.1 31.5

VGA -- Yes -- - - DVI

-- -- -- - -

Yes Yes

Neg. Neg. 1 640X400

Compatible 2 720 X 400 400line 70.1 31.5 RGBHV -- Yes -- Yes

(DVI-PC)

-- Yes -- Yes

Yes Yes

Neg. Neg. 1 720X400

Computers

385

--s

3 Yes Yes

Neg. Pos.

- - - -

720 X 350 350line

31.0

Yes Yes

Neg. Neg. 1 720X350

5 640 X 480 VGA

59.9 31.5 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes

Neg. Neg. 2 640X480

seY

YseY

Yse

Y9.

738.

76 Yes Yes

Neg. Neg. - - - -

.735

7 Yes Yes

Neg. Neg. - - - -

Yse

.345

Yes Yes

Neg. Neg. - - - -

seY

YseY

eYs

eYse

1.154.0019

Yes Yes

Neg. Neg. - - - -

seYse

Yse

.0210

Yes Yes

Neg. Neg. - - - -

11 848 X 480 Wide-VGA

seY

Yes Yes Pos. Pos. 2 848X480

852 X 480 Wide-VGA

Y--

.1306

Yes Yes

Neg. Neg. 2 852X480

13 800 X 600 SVGA 56.3 35.2 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Pos. Pos. - - - -

Yse

YseY9.733

.0641 Yes Yes Pos. Pos. - - - -

842

.2751

Yes Yes Pos. Pos. - - - -

Yse

6457

61 Yes Yes Pos. Pos. - - - -

seYseYs

eYs

.5871

Yes Yes Pos. Pos. - - - -

Yse

YseYs

Y368.9981 Yes Yes Pos. Pos. - - - -

Yse

seYs

57021

Yes Yes Pos. Pos. - - - -

20 1024 X 768 XGA 60 48.4 Yes Yes Yes - - Yes Yes Yes - -

Yes Yes

Neg. Neg. 3 1024X768

seY

-se

seYse

Y5.

651.

Yes Yes

Neg. Neg. 5 1024X768

22 71.9 57.9 Yes Yes Yes - - Yes Yes Yes - -

Yes Yes

Neg. Neg.

6 1024X768

seY

Y--seYseYseY0657

Yes Yes Pos. Pos. - - - -

24 85 68.7 Yes Yes Yes - - Yes Yes Yes - - Yes Yes Pos. Pos. - - - -

25 100.6 80.5 Yes Yes Yes - - Yes Yes Yes - - Yes - -

Neg. Neg. - - - -

26 119.4 95.5 Yes Yes Yes - - Yes Yes Yes - -

Yes - -

Neg. Neg. - - - -

1152 X 864 XGA 60 53.7 Yes Yes Yes - - Yes Yes Yes - - Yes Yes Pos. Neg. - - - -

28 72 64.9 Yes Yes Yes - - Yes Yes Yes - - Yes Yes Pos. Neg. - - - -

29 75 67.5 Yes Yes Yes - - Yes Yes Yes - -

Yes Yes Pos. Pos. - - - -

1280 X 768 Wide-XGA

--seY-

-1

.542.65 Yes Yes Pos. Pos. - - - -

8.9

3 -- Yes -- -- -- Yes -- - -

Yes Yes Pos. Neg.

3 1280X768-1

8.749.9523 -- Yes -- -- -- Yes -- - - Yes Yes

Neg. Pos. 3 1280X768-2

--s

------seY--658.96

Yes Yes

Neg. Pos. 5 1280X768

72 57.8 -- Yes -- -- -- Yes -- - - Yes Yes

Neg. Pos. 6 1280X768

1280 X 800 Wide-XGA -

seY

--seY

--7

.948

Yes Yes

Neg. Pos. 4 1280X800

36 1280 X 854 Wide-XGA

---

-seY-

--1

06 Yes Yes

Neg. Neg. - - - -

37 1280 X 960 Wide-XGA

--s

eYs

Yes Yes Pos. Pos. - - - -

85 85.9 Yes *2 Yes *2 Yes *2 - - Yes Yes Yes - -

Yes - - Pos. Pos. - - - -

39 1360 X 768 Wide-XGA

--se

Y--

seY

7406 Yes Yes Pos. Pos. 3 1360X768

1376 X 768 Wide-XGA

----

seY

--seY

849

95 Yes Yes

Neg. Pos. 3 1376X768

41 1280 X 1024 SXGA 60 64 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes Yes Pos. Pos. 9 1280X1024

42 75 80 Yes * 1 Yes Yes - - Ye s *1 Yes Ye s - -

Yes - - Pos. Pos. - - - -

85 91.1 Yes *1 *2 Yes *2 Yes *2 - - Yes *1 Yes Yes - -

Yes - - Pos. Pos. - - - -

100.1 108.5 Yes *1 *2 Yes *2 Yes *2 - - - - - - - - - - Yes - - Pos. Pos. - - - -

1400 X 1050 SXGA+ 60 64

Yes Ye s Yes - - Yes Yes Yes - -

Yes - -

Neg. Pos. 9 1400X1050

64 Yes Ye s Yes - - Yes Yes Yes - - Yes - -

Neg. Pos.

7 1400X1050

47 74.9 82.3 Yes *2 Yes *2 Yes *2 - - Yes Yes Yes - -

Yes - -

Neg. Pos. - - - -

85 93.9 Yes *2 Yes *2 Yes *2 - - - - - - - - - -

Yes - -

Neg. Pos. - - - -

49 1680 X 1050 Wide-SXGA

----

seY------seY--3.560

Yes - - Neg. Pos. 7 1680X1050

50 1600 X 1200 UXGA

60 75 Yes *2 Yes *2 Yes *2 - - Yes Yes Yes - - Yes - - Pos. Pos. 8 1600X1200

65 81.3 Yes *2 Yes *2 Yes *2 - - - - - - - - - - Yes - -

Pos. Pos. - - - -

52 70 87.5 Yes *2 Yes *2 Yes *2 - - - - - - - - - - Yes - -

Pos. Pos. - - - -

53 75 93.8 Yes *2 Yes *2 Yes *2 - - - - - - - - - -

Yes - - Pos. Pos. - - - -

54 85 106.3 Yes *2 Yes *2 Yes *2 - - - - - - - - - - Yes - - Pos. Pos. - - - -

1920 X 1080

----seY

---

6505

Yes - -

Pos. Pos. - - - -

----

Y-

---

7606

Yes - - Pos. Pos. - - - -

57 1920 X 1200 Wide-UXGA --------

2*se

Y--

79.

Yes - -

Neg. Pos. 8 1920X1200

58 1920 X 1200RB Wide-UXGA ----seY------2*se

Y-

6 Yes - -

Neg. Pos. - - - -

Apple Macintosh®

640 X 480 Mac13"

---

---seYs

YseY5

7.66 Yes Yes Sync on G Sync on G - - - -

82 832 X 624 Mac16" 74.6 49.7 Yes Yes Yes -- -- -- -- - - Yes Yes Sync on G Sync on G - - - -

83 1024 X 768 Mac19"

74.9 60.2 Yes Yes Yes - - - - - - - - - -

Yes Yes Sync on G Sync on G - - - -

84 1152 X 870 Mac21" 75.1 68.7 Yes Yes Yes -- -- -- -- - - Yes Yes Sync on G Sync on G - - - -

1440 X 900 Apple17

-seY------s

--9.5

Yes Yes Neg. Pos. - - - -

EWS Series 91 Work Station EWS4800 60 64.6 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes - - Neg. Neg. - - - -

1280 X 1024

71.2 75.1 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes - - Neg. Neg. - - - -

93 1280 X 1024 HP 72 78.1 Yes *1 Yes Yes - - Yes *1 Yes Yes - -

Yes - -

- - - - - -

94 1152 X 900 SUN

66 61.8 Yes Yes Yes - - Yes Yes Yes - -

Yes Yes C Sync C Sync - - - -

95 1152 X 900 76 71.7 Yes Yes Yes - - Yes Yes Yes - - Yes Yes

C Sync C Sync - - - -

96 1280 X 1024

76.1 81.1 Yes *1 Yes Yes - - Yes *1 Yes Yes - -

Yes - - C Sync C Sync - - - -

1024 X 768 SGI 60 49.7 Yes Yes Yes - - Yes Yes Yes - - Yes - -

- - 4 1024X768

98 1280 X 1024

60 63.9 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes - -

- - - - - -

RGB select

TOP1-3/MID HIGH/

MID LOW/BOTTOM1-3

Left/Right

igi

gol

anA

TEXT INSERT

Sync polarity

P50XP10 Supported Resolutions (PC)

- - NORMAL (4:3) FULL (16:9 ) (*1) (*2)

Not Supported 1024 pixels x 768 lines 1365 pixels x 768 lines Aspect ratio is 5:4 ( 960x768) Rough Sampling

English-37

P50XP10 Supported Resolutions (Video)

Specification of the signal

Sig. t

29:4

DLLU

53.

TUP

fVnoitu

oseR

no.

H X V Signal Type (Hz) (kHz) terminal (4:3) (16:9)

(non-linear)

SCAN terminal (4:3) (16:9)

(non-linear)

SCAN Gr. No. Item Item

Video 101 3.58NTSC 59.9 15.8

Video1

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

Composite / S 102

4.43NTSC 59.9 15.8 Video2 Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

103 PAL

50 15.6

S-Video

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

104 PAL60 -

---

eYseY

Yse

.95

105

PAL-N -

---

----

Y6.5

106 PAL-M -

---

----

---

eYseY

9.95

107 SECAM

---

----

3*s

eYs

Y,Pb(Cb),Pr(Cr) SD

111

480I 59.9 15.8 DVD/HD1

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

112 576I

50 15.6

DVD/HD2

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

113

480P

---

----

---

3*s

eYs

114 576P

31.3

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

HD 11 5

720P -

---

----

seY-

-5.73

116

720P ---

----

---

eY-

-se

eY-

5406

117 1080I

---

Y-

YseY--1.8205

118 1080I

---

seY-

--s

119 1080P -

---

----

eY-

120

1080P

---

Y-

-s

-5

.760

121 1080P

---

eYse

Y-

8.3303

122 1080P 24 27 -- Yes Yes -- -- Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

123

1080P 25 28

-- Yes Yes -- -- Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

RGB(Video signal) SD 131 480I *4 59.9 15.8 VGA Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

132

576I *4

50 15.6 RGBHV Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

133 480P 59.9 31.5

(SCART1-3)

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- 2 480P - -

134 576P 50 31.3 Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

135

720P --

----

---

eYseY----se

seY--5.7305

136 720P

---

----

eY-

eYseY--5406

137

1080I -

---

seY---

-s

eYs

-1.82

138

1080I B080

------

---

eY----seYseY--8.33

139

1080P

---

seY-

-3.65

140 1080P

---

eY-

-seYseY--5.

606

141 1080P -

---

----

Y-

---seYseY--8.

303

142

1080P 24 27

-- Yes Yes -- -- Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

143

1080P 25 28

-- Yes Yes -- -- Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

144 1080A/540P RCA STB

----

---

3*se

Y--

-seYseY--

.3306

Digital SD

161 640 X 480P 59.9 / 60.0 31.5 / 31.5 - - - - - - - - - - - - - - DVI Yes *3 Yes *3 Yes *3 Yes *3 Yes *3 Yes *3 Yes *3 - - - - - -

(EIA/CEA-861)

162

720 (1440) X 480I 59.9 / 60.0 15.7 / 15.8 - - - - - - - - - - - - - -

(DVI-HD)

Yes Yes Yes Yes Yes Yes Yes *3 - - - - - -

163

720 X 480P 59.9 / 60.0 31.5 / 31.5 - - - - - - - - - - - - - - Yes Yes Yes Yes Yes Yes Yes *3 - - - - - -

164

720 (1440) X 576I

eYs

----

-6.5105

165 720 X 576P

3*se

eYs

Yse

----------3.1305

HD 166 1280 X 720P 59.9 / 60.0 45.0 / 45.0 -- -- -- -- -- -- -- -- Yes Yes -- -- Yes Yes *3 -- -- - -

167 1920 X 1080I 59.9 / 60.0 33.7 / 33.8 - - - - - - - - - - - - - - - - Yes Yes - - - - Yes Yes *3 - - - - - -

168 1920 X 1080P 59.9 / 60.0 67.4 / 67.5 -- -- -- -- -- -- -- -- Yes Yes -- -- Yes Yes *3 -- -- - -

169 1280 X 720P -

3*s

eY-

---s

---

-5.

170 1920 X 1080I -

---

3*s

seY-

Yse

---

---1.

171

1920 X 1080P --

-3

Y---

----

.6505

172

1920 X 1080P

---

-3*se

seY--

seYs

Y---

---

----

-8.

173 1920 X 1080P 24 27 -- -- -- -- -- -- -- -- Yes Yes -- -- Yes Yes *3 -- -- - -

174 1920 X 1080P 25 28

-- -- -- -- -- -- -- -- Yes Yes -- -- Yes Yes *3 -- -- - -

Native 191 1366 X 768 -

seY

---

-------

----3.7406

Resolution 192 1024 X 768

-----

---------3*seY----------------3.7406

193

853 X 480

60 30

-- -- -- -- -- -- -- -- Yes *3 -- -- -- -- -- -- -- - -

SIZE SIZE

RGB select

Digi

- - NORMAL (4:3) FULL (16:9 ) (*3 ) (*4)

Not Supported 1024 pixels x 768 lines 1365 pixels x 768 lines Displayed by Underscan mode (100%) SCART input available

English

English-38

P60XP10 Supported Resolutions (PC)

Specification of the signal

Sig.

URT

OZL

PNI

erf

VnoituloseR

no. metI.

H)LA

(

)9:

(

)

(

ret

)

()9:6

()

(

ret)

(

)

ngi

SH X V

IBM PC/AT

640 X 400 400line 70.1 31.5 VGA

-- Yes -- - -

DVI

-- -- -- - -

Yes Yes

Neg. Neg. 1 640X400

Compatible 2 720 X 400 400line 70.1 31.5 RGBHV

-- Yes -- Yes

(DVI-PC)

-- Yes -- Yes

Yes Yes

Neg. Neg. 1 720X400

Computers s

Y--s

eY--

--9

3 Yes Yes

Neg. Pos. - - - -

4 720 X 350 350line 70.1 31.5 - - Yes - - Yes - - Yes - - Yes Yes Yes Neg. Neg. 1 720X350

5 640 X 480 VGA

59.9 31.5 Yes Yes Yes Yes Yes Yes Yes Yes

Yes Yes

Neg. Neg. 2 640X480

eYs

9.738.

6 Yes Yes Neg. Neg. - - - -

eYse

Yse

5.7

577

Yes Yes

Neg. Neg. - - - -

eYse

Y3.3

588

Yes Yes

Neg. Neg. - - - -

eYse

4.0019

Yes Yes

Neg. Neg. - - - -

eYs

3.164.02101

Yes Yes

Neg. Neg. - - - -

11 848 X 480 Wide-VGA s

eY-

-s

eY--13

Yes Yes

Pos. Pos. 2 848X480

852 X 480 Wide-VGA

60 31.7 - - Yes - - Yes - - Yes - - Yes

Yes Yes

Neg. Neg. 2 852X480

13 800 X 600 SVGA 56.3 35.2 Yes Yes Yes Yes Yes Yes Yes Yes

Yes Yes

Pos. Pos. - - - -

eYseY9.733.0641 Yes Yes Pos. Pos. - - - -

eYse

seY

.842.

751

Yes Yes

Pos. Pos. - - - -

Yse

Y9.6

5761 Yes Yes Pos. Pos. - - - -

eYs

eYse

871

Yes Yes

Pos. Pos. - - - -

eYse

1 Yes Yes Pos. Pos. - - - -

Yse

eYs

seYse

7.5702191

Yes Yes Pos. Pos. - - - -

20 1024 X 768 XGA 60 48.4 Yes Yes Yes - - Yes Yes Yes - -

Yes Yes Neg. Neg. 3 1024X768

eYse

--se

eYseY

.651

.07

12 Yes Yes Neg. Neg. 5 1024X768

--s

eYse

eYseY9.759

.17

Yes Yes

Neg. Neg.

6 1024X768

eYs

seYse

seY065

32 Yes Yes Pos. Pos. - - - -

eY--seYse

.86

Yes Yes

Pos. Pos. - - - -

Y--se

Y5.086

.001

52 Yes - -

Neg. Neg. - - - -

eY--seYseYseY5.594.91162 Yes - -

Neg. Neg. - - - -

27 1152 X 864 XGA 60 53.7 Yes Yes Yes - - Yes Yes Yes - -

Yes Yes

Pos. Neg. - - - -

--s

eYse

Y9.46

Yes Yes

Pos. Neg. - - - -

eY--se

seYse

Yes Yes

Pos. Pos. - - - -

1280 X 768 Wide-XGA 56.2 45.1 - - Yes - - - - - - - - - - - -

Yes Yes

Pos. Pos. - - - -

---

-s

seY--84

.9513 Yes Yes

Pos. Neg. 3 1280X768-1

---

-s

-seY--

.74

.952

3 Yes Yes

Neg. Pos. 3 1280X768-2

-s

seY-

.9633 Yes Yes

Neg. Pos. 5 1280X768

-seY-

-----seY--8.752743 Yes Yes Neg. Pos. 6 1280X768

35 1280 X 800 Wide-XGA

59.8 49.7 -- Yes -- -- -- Yes -- - - Yes Yes

Neg. Pos. 4 1280X800

36 1280 X 854 Wide-XGA 60 53.1 - - Yes - - - - - - Yes - - - - Yes Yes

Neg. Neg. - - - -

37 1280 X 960 Wide-XGA 60 60 Yes Yes Yes - - Yes Yes Yes - -

Yes Yes

Pos. Pos. - - - -

--se

seY

eY--2*seY2*

eY2*seY9.58588

Yes - - Pos. Pos. - - - -

39 1360 X 768 Wide-XGA 60 47.7 -- Yes -- -- -- Yes -- - -

Yes Yes

Pos. Pos. 3 1360X768

40 1376 X 768 Wide-XGA 59.9 48.3 - - Yes - - - - - - Yes - - - -

Yes Yes

Neg. Pos. 3 1376X768

41 1280 X 1024 SXGA 60 64 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes Yes Pos. Pos. 9 1280X1024

--seYseY1*

--seYse

1*s

Y085724 Yes - -

Pos. Pos. - - - -

seYseY1*

1*se

Y1.19

34 Yes - - Pos. Pos. - - - -

----

2*seY

2*1*se

.8011.00

Yes - -

Pos. Pos. - - - -

45 1400 X 1050 SXGA+ 60 64 Yes Yes Yes - - Yes Yes Yes - -

Yes - -

Neg. Pos. 9 1400X1050

--se

seYseY--seYseYseY3.56066

Yes - -

Neg. Pos.

7 1400X1050

--seYseYseY-

2*seY

.28

9.4774 Yes - - Neg. Pos. - - - -

----

----2*seY2*seY

2*seY9.395884 Yes - -

Neg. Pos. - - - -

1680 X 1050 Wide-SXGA

60 65.3 - - Yes - - - - - - Yes - - - - Yes - -

Neg. Pos. 7 1680X1050

50 1600 X 1200 UXGA 60 75 Yes *2 Yes *2 Yes *2 - - Yes Yes Yes - - Yes - -

Pos. Pos. 8 1600X1200

-----

2*s

eY3.

615 Yes - - Pos. Pos. - - - -

----

seY5

25 Yes - -

Pos. Pos. - - - -

--2*s

Y2*

eY2*s

Yes - -

Pos. Pos. - - - -

---

-----2*seY2*seY2*seY3.60158

Yes - -

Pos. Pos. - - - -

55 1920 X 1080 50 56.2 - - - - - - - - - - Yes - - - - Yes - - Pos. Pos. - - - -

---

-s

eY-

------5

665

Yes - -

Pos. Pos. - - - -

1920 X 1200 Wide-UXGA

59.9 74.6 -- Yes *2 -- -- -- -- -- - -

Yes - -

Neg. Pos. 8 1920X1200

58 1920 X 1200RB Wide-UXGA ----seY----

-2*seY--

706 Yes - -

Neg. Pos. - - - -

Apple Macintosh® 81

640 X 480 Mac13"

66.7 35 Yes Yes Yes -- -- -- -- - - Yes Yes

Sync on G Sync on G - - - -

82 832 X 624 Mac16"

74.6 49.7 Yes Yes Yes - - - - - - - - - -

Yes Yes

Sync on G Sync on G - - - -

83 1024 X 768 Mac19" 74.9 60.2 Yes Yes Yes - - - - - - - - - -

Yes Yes Sync on G Sync on G - - - -

84 1152 X 870 Mac21" 75.1 68.7 Yes Yes Yes - - - - - - - - - - Yes Yes Sync on G Sync on G - - - -

85 1440 X 900 Apple17 59.9 55.9 - - Yes - - - - - - Yes - - - - Yes Yes Neg. Pos. - - - -

EWS Series 91

Work Station EWS4800

60 64.6 Yes *1 Yes Yes - - Yes *1 Yes Yes - -

Yes - - Neg. Neg. - - - -

1280 X 1024

71.2 75.1 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes - - Neg. Neg. - - - -

1280 X 1024 HP

72 78.1 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes - - - - - - - -

94 1152 X 900 SUN 66 61.8 Yes Yes Yes - - Yes Yes Yes - -

Yes Yes

C Sync C Sync - - - -

95 1152 X 900 76 71.7 Yes Yes Yes - - Yes Yes Yes - - Yes Yes

C Sync C Sync - - - -

1280 X 1024

76.1 81.1 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes - -

C Sync C Sync - - - -

1024 X 768 SGI

60 49.7 Yes Yes Yes - - Yes Yes Yes - - Yes - -

- - 4 1024X768

98 1280 X 1024 60 63.9 Yes *1 Yes Yes - - Yes *1 Yes Yes - - Yes - -

- - - - - -

atig

iDgol

TEXT INSERT

TOP1-3/MID HIGH/

MID LOW/BOTTOM1-3

Left/Right

- - NORMAL (4:3) FULL (16:9 ) (*1) (*2)

Not Supported 1024 pixels x 768 lines 1366 pixels x 768 lines Aspect ratio is 5:4 ( 960x768) Rough Sampling

English-39

P60XP10 Supported Resolutions (Video)

Specification of the signal

Sig. t

9:4

ZCI

ANYDL

PNIREDN

1:5

9:4

no.

H X V Signal Type (Hz) (kHz) terminal (4:3) (16:9)

(non-linear)

SCAN terminal (4:3) (16:9)

(non-linear)

SCAN Gr. No. Item Item

Video

101 3.58NTSC 59.9 15.8

Video1

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

Composite / S 102 4.43NTSC

59.9 15.8

Video2

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

103 PAL

50 15.6 S-Video Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

104 PAL60

---

----

eYse

eYs

519

105

PAL-N

----

3*se

eYs

seY

106 PAL-M -

---

----

--3*s

19.

107 SECAM

---

--3*s

eYs

Y,Pb(Cb),Pr(Cr) SD

111

480I 59.9 15.8

DVD/HD1

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

112 576I 50 15.6 DVD/HD2 Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

113

480P -

---

----

--3*seYse

eYs

139.95

114 576P

3*s

eY3.

HD 115 720P ---

---

------3*se

seY

.73

116 720P --------

-3

-5406

117

1080I

----

--3*s

eY--

--1.

118 1080I

---

seYseY--

.3306

119

1080P

-----

3*se

eY-

-3.

120

1080P

---

-------3*se

--5.7606

121

1080P

-----

---3*se

122 1080P

---

-------

seYseY--

-7242

123

1080P -

-------

-8

RGB(Video signal) SD

131 480I *4 59.9 15.8

VGA

Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

132 576I *4 50 15.6 RGBHV Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- -- -- - -

133 480P

59.9 31.5 (SCART1-3) Yes Yes Yes Yes Yes Yes Yes *3 -- -- -- -- -- -- -- 2 480P - -

134 576P

3*s

seYseYseY3.1305

HD 135 720P ---

---

----3*se

seY

--5

136 720P --------

-3

Y--5406

137

1080I -

-------

eY-

--s

--1

138 1080I B

01------

-----3*se

seY

-s

--8

139

1080P --

-----

---

3*s

seY-

140 1080P ---

-------

----

3*se

----s

Y-

141

1080P

--------

-----3*se

seY--

--8.3

142

1080P

--------

-3

eYs

---s

-7242

143

1080P

--------

eYs

eY-

-8

144 1080A/540P RCA STB

----

3*s

Y-

-s

--8

Digital SD 161

640 X 480P

59.9 / 60.0 31.5 / 31.5 - - - - - - - - - - - - - - DVI Yes *3 Yes *3 Yes *3 Yes *3 Yes *3 Yes *3 Yes *3 - - - - - -

(EIA/CEA-861) 162 720 (1440) X 480I 59.9 / 60.0 15.7 / 15.8 - - - - - - - - - - - - - -

(DVI-HD)

Yes Yes Yes Yes Yes Yes Yes *3 - - - - - -

163

720 X 480P

59.9 / 60.0 31.5 / 31.5 - - - - - - - - - - - - - - Yes Yes Yes Yes Yes Yes Yes *3 - - - - - -

164 720 (1440) X 576I -

-3*s

eYs

-----

-----6.

105

165

720 X 576P

------3*se

Yse

eY-

---3

166

1280 X 720P 59.9 / 60.0 45.0 / 45.0 -- -- -- -- -- -- -- -- Yes Yes -- -- Yes Yes *3 -- -- - -

167

1920 X 1080I

59.9 / 60.0 33.7 / 33.8 - - - - - - - - - - - - - - - - Yes Yes - - - - Yes Yes *3 - - - - - -

168 1920 X 1080P

59.9 / 60.0 67.4 / 67.5 - - - - - - - - - - - - - - - - Yes Yes - - - - Yes Yes *3 - - - - - -

169 1280 X 720P

---

-3*s

Y----se

seY-----------

---5

170 1920 X 1080I

Y-

Y--

----

.82

171 1920 X 1080P

-3*se

eY----se

seY-------------

-3.6505

172

1920 X 1080P

---

Y----s

---

----

173 1920 X 1080P

3*s

Y-

-se

Y-------

-----

--7

174 1920 X 1080P ------

YseY-

Y-

---

------

-----8252

Native 191 1366 X 768 ---

---

--3*seY

-----

----

.74

Resolution 192

1024 X 768

------

3*se

--------

----

.74

193 853 X 480

---

3*se

----

---

-03

SIZE SIZE

RGB select

Digi

- - NORMAL (4:3) FULL (16:9 ) (*3 ) (*4)

Not Supported 1024 pixels x 768 lines 1366 pixels x 768 lines Displayed by Underscan mode (100%) SCART input available

English

English-40

Pin Assignment

1) Analog RGB Input (Mini D-SUB 15P) VGA

Pin No. Name

1 Video Signal Red

2 Video Signal Green

3 Video Signal Blue

4 GND

5 DDC-GND

6 Red-GND

7 Green-GND

8 Blue-GND

9 +5V (DDC)

10 SYNC-GND

11 GND

12 DDC-SDA

13 H-SYNC

14 V-SYNC

15 DDC-SCL

2) Digital RGB Input (DVI-D) DVI

1 TX2- 9 TX1- 17 TX0-

2 TX2+ 10 TX1+ 18 TX0+

3 Shield (TX2/TX4) 11 Shield (TX1/TX3) 19 Shield (TXP/TX5)

4NC 12NC 20NC

5NC 13NC 21NC

6 DDC-Serial Clock 14 +5 power 22 Shield (TXC)

7 DDC-Serial Data 15 Ground (+5V) 23 TXC+

8 NC 16 Hot Plug Detect 24 TXC-

3) RS-232C Input

(D-SUB 9P)

Pin No. Name

1 Connected to 7 & 8

2 RXD

3 TXD

4 Connected to 6

5 GND

6 Connected to 4

7 Connected to 1 & 8

8 Connected to 1 & 7

9NC

D-SUB 9P

DVI-D

Mini D-SUB 15P

DECLARATION OF CONFORMITY

 is device complies with Part 15 of FCC Rules. Operation is subject to the following two

conditions. (1)  is device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

U.S. Responsible Party: NEC Display Solutions of America, Inc.

Address: 500 Park Blvd. Suite 1100

Itasca, IL 60143

Tel. No.: (630)467-3000

Type of Product: Computer Monitor

Equipment Classi cation: Class B Peripheral

Model: PlasmaSync 42XP10 (P426Y0)

PlasmaSync 50XP10 (P506Y1)

PlasmaSync 60XP10 (P606Y2)

We hereby declare that the equipment speci ed above

conforms to the technical standards as speci ed in the FCC Rules.

Windows is a registered trademark of Microso Corporation. NEC is a registered trademark of

NEC Corporation. All other brands and product names are trademarks or registered trademarks

of their respective owners.

Declaration of the Manufacturer

We hereby certify that the color monitor

P426Y0, P506Y1 or P606Y2 is in compliance

with Council Directive 73/23/EEC:

– EN 60950-1

Council Directive 89/336/EEC:

— EN 55022

— EN 61000-3-2

— EN 61000-3-3

— EN 55024

and marked with

NEC Display Solutions Ltd.

4-13-23, Shibaura,

Minato-Ku

Tokyo 108-0023, Japan

WEEE Mark (European Directive 2002/96/EC)

Within the European Union

EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic products

carrying the mark (le ) must be disposed of separately from normal household waste.  is includes monitors and

electrical accessories, such as signal cables or power cords. When you need to dispose of your NEC display products,

please follow the guidance of your local authority, or ask the shop where you purchased the product, or if applicable,

follow any agreements made between yourself and NEC.  e mark on electrical and electronic products only applies

to the current European Union Member States.

 e mark on electrical and electronic products only applies to the current European Union Member States.

Outside the European Union

If you wish to dispose of used electrical and electronic products outside the European Union, please contact your

local authority so as to comply with the correct disposal method.

NEC P42XP10-BK 42" Professional Plasma Display

Product's Documents

User’s Manual

Specifications

NEC P42XP10-BK Questions and Answers
