INSTRUCTION MANUAL
POWER BANK
Thank you for selecting and buying V-TAC Product. V-TAC will serve you the best.
Please read these instructions carefully & keep this user manual handy for future
reference. If you have any another query, please contact our dealer or local vendor
from whom you have purchased the product. They are trained and ready to serve you
at the best.
INTRODUCTION
TECHNICAL DATA
Multi-Language Manual QR CODE
Please scan the QR code to access the manual
in multiple languages.
WEEE Number: 80133970
MODEL VT-33333
CAPACITY 30000mAh (111Wh)
INPUT 1 DC 5V/2A 9V/2A(Type-C)
INPUT 2 DC 5V/2A 9V/2A(Micro-B)
INPUT 3 DC 5V/2A(Lightning)
INPUT 4 2W(Solar board)
OUTPUT 1 DC 5V/3A 9V/2.22A 12V/1.67A(Type-C)
OUTPUT 2 DC 5V/3A 9V/2.22A 12V/1.67A(USB)
OUTPUT 3 5W/7.5W/10W(Wireless)
This product is lightweight, environmentally friendly, high-capacity stylish mobile power
for portable devices anywhere, anytime. This product contains a high-performance
lithium-ion battery. Using the USB-TYPE C cable, not only can you power portable
devices directly, but also can charge the built-in battery. It provides adequate back-up
energy for the wild expedition, traveling, Adventure, and travel home.
1. Suitable for iPhone, iPod, Tablet, most mobile phone and digital products.
2. Suitable for handheld video games PSP, NDSI, NDSL.
3. Suitable for MP3, MP4, MP5, e-books, GPS, walkie-talkie.
4. Standard USB interface output, compatible with all USB charging devices.
INTRODUCTION
APPLICABLE FOR
POWER BANK FUNCTION
Wireless Charging
Power Button
LED Lights
Lighting Input
USB Output
USB Output
Micro Input
Type C Input/Output
1. Easy to use simply select the appropriate connector to charge.
2. Plug & play, auto-sleep mode function, when no current output the device goes into
sleep mode automatically.
3. Short-circuit protection, over Charge protection, over discharge protection, intelligent
protection of lithium, high conversion efficiency, leakage protection.
1. Display capacity (Note: Applicable for models with LED indicator):
Press control button, capacity LED will be on, 10 seconds later they will be off
automatically.
4 LEDs on: 75%~100% remained.
3 LEDs on: 50%~75%remained.
2 LEDs on: 25%—50% remained.
1 LEDs on: less than 25%
2. LED lighting (Note: Applicable for models with LED flashlight)
Press control button over 2 seconds, the flashlight will switch on.
Press control button more than 2 seconds to switch off the flashlight.
3. Charge portable power bank
The applicable standard cable plug in the computer USB or USB charger, connect to the
USB-TYPE C of mobile power, automatic wake-up charge. During charging, the battery
indicator light cycling starts; full power indicator light indicates charging completed.
4. Use portable power bank to provide power to any digital device. Using the cable and
adapter for the digital products, the electronic switch will be open automatically, output
5V voltage for use. (See Figure 3)
PERFORMANCE
HOW TO USE IT
NOTICE:
Ensure the product's safe operation please read the manual carefully before using that:
A. Attention:
1. Mobile power bas built-in lithium-ion battery, do not use metal objects to short-circuit
products, in order to avoid equipment failure and security risks.
2. Shall not be placed in hot and humid environment.
3. Shall not be demolish or mobile power transformation.
4. The equipment shall meet the specifications required to use DC power, the use of
other power supply may cause fire or malfunction.
5. Heavy impact on the product may cause fire or explosion.
B. Terms of Use
1. If using the product for the first time or if it has not been used for a long time, the
power bank needs 8-10 hours to charge fully.
2. Temperature range from -10°C to +45°C, for best charging results, please use the
device in suitable temperature conditions.
3. When charging and using, this product may get slightly heated, which is normal and
not malfunction.
4. If the products not in use for a long time, you need to charge at least once every three
months to maintain its charge properties.
5. Mobile power bank le unused for a long time will suffer loss of power, which s
normal self- discharge phenomenon, if ready to use, please charge again.
6. Keep the mobile power bank clean, please clean it with dry cloth before using if the
port is dirty.
