© 2021 by Snow Joe
®
, LLC
All rights reserved. Original instructions.
SAVE THESE INSTRUCTIONS
1
EN
A Division of Snow Joe
®
, LLC
Model SJPPFP-CVR
Form No. SJ-SJPPFP-CVR-880E-M
R
OPERATOR’S MANUAL
PROPANE FIRE PIT
23-INCH | 20 LBS LP CYLINDER | 50,000 BTU
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Read all the instructions contained in this manual. Keep this
manual in a safe place, so that the information is available at
all times. If you give this equipment to another person, make
sure to provide these operating instructions. Basic safety
precautions should always be followed to reduce the risk of
fire or explosion, which could cause property damage,
personal injury, or death.
Notice the personal safety alert symbol m used in this
manual to draw your attention to a WARNING given along
with the particular operating instruction. This means that
the operation requires special ATTENTION, CAUTION, and
AWARENESS.
m
WARNING!
FOR OUTDOOR USE ONLY (outside any enclosure)
Maintenance or service on this fire pit must be performed
by a qualified installer or licensed service professional.
m
WARNING!
1. Improper installation, adjustment, alteration, service, or
maintenance may result in property damage, injury, or
death.
2. Thoroughly read all WARNINGS, cautions and instructions
for installation, operation, and maintenance before
installing, servicing or using this equipment.
3. Failure to follow these instructions could result in a fire or
explosion, which could cause property damage, personal
injury, or death.
m
DANGER! FIRE or EXPLOSION HAZARD
If you smell gas:
1. DO NOT try to light the fire pit
2. DO NOT touch any electrical switch
3. Shut off the gas
4. Extinguish any open flames
5. If odor continues, leave area immediately
6. Call your local fire department
m
WARNING!
1. This item is for outdoor use only, and should NEVER be
used in a building, garage, or any other enclosed area.
2. DO NOT use this fire pit for indoor heating. TOXIC carbon
monoxide fumes can accumulate and cause asphyxiation
or death.
3. This fire pit is NOT for commercial use.
4. This fire pit is NOT to be operated by children.
5. This fire pit is NOT to be used in or on boats or
recreational vehicles.
6. This fire pit is NOT intended for cooking or food
preparation.
7. Always use this equipment in accordance with all
applicable local, state, and national regulations including
the Natural Gas and Propane Installation Code, CSA
B149.1, or the Propane Storage and Handling Code, CSA
B 149.2. Contact your local fire department for details on
outdoor burning.
8. When using this fire pit, exercise the same precautions as
you would with any open fire.
9. The use of alcohol, prescription, or non-prescription drugs
may impair the consumer’s ability to properly assemble or
safely operate this fire pit.
10. This appliance requires a 20 lbs LP gas cylinder.
11. DO NOT burn anything EXCEPT for propane.
12. DO NOT alter this fire pit in any manner.
13. DO NOT use this fire pit until it is COMPLETELY
assembled and all parts are securely fastened and
tightened.
14. DO NOT use or store gasoline or other flammable vapors
or liquids in the vicinity of this or any other appliance.
15. DO NOT store LP gas cylinders within 10 feet (3.05 m) of
this fire pit while it is in operation.
16. An LP-cylinder not connected for use shall not be stored
in the vicinity of this or any other appliance.
17. DO NOT use this fire pit near automobiles, trucks, vans, or
recreational vehicles.
2
18. DO NOT use in an explosive atmosphere. Keep outdoor
area clean and free from combustible materials, gasoline,
and other flammable liquids.
19. DO NOT use this fire pit under an overhead or near any
unprotected combustible constructions. Avoid using near
or under overhanging trees and shrubs.
20. Always use this fire pit on a hard level non-combustible
surface such as concrete, rock, or stone. An asphalt or
blacktop surface may not be acceptable for this purpose.
DO NOT use on wooden or composite decks.
21. DO NOT wear flammable or loose clothing when operating
this fire pit.
22. DO NOT use in windy conditions.
23. DO NOT use gasoline, kerosene, diesel fuel, lighter fluid,
or use these items to relight fires.
24. Keep all electrical cords away from a hot fire pit.
25. All surfaces of this fire pit are hot when in operation.
To avoid burns, do NOT touch the fire pit until it has
completely cooled, unless you are wearing protective
gear (i.e. pot holders, gloves, BBQ mittens, hot pads, etc.)
26. DO NOT leave a lit fire pit unattended, especially around
children and pets.
27. DO NOT attempt to move or store this fire pit until the
flame is completely extinguished.
28. Use heat-resistant gloves or hot pads when contacting
handles.
29. DO NOT lean over this fire pit when lighting or when in
use.
30. Avoid breathing propane gas.
31. This fire pit should be thoroughly inspected and cleaned
on a regular basis.
32. After a period of storage and/or non-use, check for signs
of damage. DO NOT operate until all necessary repairs
and/or proper cleaning procedures have been successfully
executed.
33. Do not use the appliance if any part has been under water.
Immediately call a qualified service technician to inspect
the appliance and to replace any part of the control
system and any gas control which has been submerged.
34. Death, serious injury, or damage to property may occur if
any of the above precautions are not followed exactly.
m
WARNING! The LP cylinder must be:
1. Constructed and marked in accordance with the
specifications for LP-gas cylinders by the U.S.
Department of Transportation (DOT); or the Standard
for Cylinders, Spheres and Tubes for Transportation of
Dangerous Goods and Commission, CAN/CSA-B339, as
applicable.
2. Provided with a listed overfilling prevention device, and
with a cylinder connection compatible with the appliance.
3. Designed and equipt for vapor withdrawal.
4. Equipt with a collar to protect the gas valve.
m
DANGER! Alert children and adults to the hazards of
high surface temperatures and keep them away
to avoid burns or clothing ignition.
m
CAUTION! Perform a leak test with soapy solution
(refer to page 5 for leak test instructions):
1. To check your gas connection.
2. After connecting a new propane cylinder.
3. Upon reassembly.
m
DANGER! Carbon Monoxide Hazard
This appliance can produce carbon monoxide which has no
odor. Using it in an enclosed space can be potentially fatal.
Never use this appliance in an enclosed space such as a
camper, tent, car or home.
m
WARNING! This product can expose you to
chemicals including lead, which is known to the State of
California to cause cancer; and carbon monoxide, which is
known to the State of California to cause birth defects or other
reproductive harm. For more information, go to:
www.P65Warnings.ca.gov.
3
Know Your Propane Fire Pit
Read the owner’s manual and safety rules carefully before using your fire pit. Compare the illustration below to the actual unit in
order to familiarize yourself with the location of the various parts and hardware. Save this manual for future reference.
1
2
3
4
1. Fabric cover
2. Gas burner
3. Battery compartment
4. Control knob
5. Housing
6. Adjustable feet (4)
7. Handle/Vent
8. Cylinder clamp screw
9. Door panel
10. Gas regulator
11. Gas regulator handle
12. Lava rocks
Technical Data
Diameter .............................................................. 23 in. (58 cm)
Fuel .............................................................................. Propane
Fuel Tank ........................................... 20 lbs (9 kg) LP Cylinder
Input ................................................. 50,000 BTU/h (14.65 kW)
Max. Burn Time .................................................. Up to 8 hours
Min. Gas Supply ............................................. 25 PSI (175 kPa)
Max. Gas Supply ........................................ 250 PSI (1750 kPa)
Regulator Gas Pressure ........................... 11 in. WC (2.74 kPa)
Burner Hole Diameter .................................. 1/16 in. (2.25 mm)
Housing Material .............................................................. Steel
Net Weight ..................................................... 41.4 lbs (18.8 kg)
5
6 7 8
9
10
11
12
4
Unpacking
NOTE: Before beginning assembly, make sure that all of
the parts listed below are present. If any part is missing or
damaged, do not attempt to assemble the product. Contact
the Snow Joe
®
+ Sun Joe
®
customer service department at
1-866-SNOWJOE (1-866-766-9563).
Carton Contents
1. Fire Pit
2. Lava Rocks
3. Fabric Cover
4. Manual and Registration Card
Assembly
No Tools Required
Choose a soft and level location for assembly. Remove all
parts from the packaging, and check for missing parts.
1. Place the fire pit on the ground and adjust the feet as
needed (Fig. 1).
2. Unscrew the battery compartment cap on the control
panel, install one AAA battery (NOT included) with the
positive end facing out. (Fig. 2).
3. Place the lava rocks (Max 24.25 lbs) onto the burner of the
gas fire pit (Fig. 3).
Installation
Location
NOTE: Your fire pit must be installed on a flat, stable surface.
m
WARNING! Make sure surrounding areas are free of
combustible materials, gasoline, and other flammable vapors
or liquids.
Fig. 1
Adjustable feet
Fig. 2
Battery
compartment cap
AAA battery
(not included)
Fig. 3
Lava rocks
5
m
WARNING! Your fire pit was designed and approved
for OUTDOOR use only. DO NOT use it inside a building or any
other enclosed area.
• Ensure that the area is well ventilated and free of
obstructions.
• Follow the spacing tolerances shown in (Fig. 4)
m
CAUTION! When certain materials or items are left,
above, beside or under this fire pit while in use, they will be
subject to radiant heat and could be seriously damaged.
Connecting Your Gas Cylinder
1. Open the door panel, attach regulator to the gas cylinder
and turn clockwise to tighten (Fig. 5).
NOTE: Only use the regulator supplied with this fire
pit. Only replace them with those specified by the
manufacturer.
2. Place the gas cylinder into the clamp in the base of the
fire pit with the regulator facing OUTWARDS. Turn the
tightening screw clockwise to secure it in place (Fig. 6).
Leakage Check
1. Mix a solution of 1 part liquid soap and 3 parts water.
2. Turn the propane cylinder valve until fully open.
3. Spoon (or squirt) several drops of the solution on to the
gas hose, regulator and cylinder valve (Fig. 7).
4. Inspect the connections and look for bubbles. If no
bubbles appear, the connection is safe.
5. If bubbles appear there is a leak. Turn off the cylinder
valve, then loosen and retighten the regulator.
6. Check for leakage again.
Fig. 4
35"
35"
60"
Fig. 5
Gas cylinder
Regulator
Fig. 6
Regulator
facing out
Clamp tightening
screw
Fig. 7
Gas hose
Cylinder valve
Regulator
6
7. If bubbles still appear, turn of the cylinder valve and call
the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563). Do not attempt to
use this fire pit.
m
DANGER! Make sure the control knob is turned to the
"OFF" position before performing the leakage check.
m
WARNING! DO NOT use an open flame to check for
leakage.
m
WARNING! DO NOT smoke during testing.
m
WARNING! DO NOT test indoors.
m
CAUTION! A leak check must be performed whenever
the gas cylinder is replaced.
Operation
m
WARNING! Do not attempt to operate the fire pit until
you have read and understood all precautions. Failure to do so
can result in property damage, serious injury, or death.
m
WARNING! The gas fire pit should be thoroughly
inspected before each use.
• Be sure all gas connections are tight and there are no leaks.
• Be sure the access panel is clear of debris.
• Be sure any component removed during assembly or
servicing is replaced and fastened prior to starting.
• Inspect the hose before each use of the appliance. The
hose assembly must be replaced if there is evidence of
damage, excessive abrasion or wear. The replacement hose
assembly shall only be that specified by the manufacturer.
m
DANGER! Always wait at least 5 minutes to relight a
hot gas fire pit.
m
WARNING! In the event of a gas leakage:
1. Press down and turn the control knob to the "OFF"
position.
2. Turn the propane cylinder valve until fully closed.
3. Wait 5 minutes to allow gas to dissipate.
4. If odor continues, leave area immediately.
5. Call your local fire department.
Lighting
1. Make sure the control knob is in the "OFF" position.
2. Turn propane cylinder valve until fully open.
3. Press down on the control knob and turn it
counter-clockwise to the "IGNITE/LOW" position
to light the burner (Fig. 8).
Fig. 8
4. If the burner is lit, keep pressing down on the control knob
for 10 seconds before releasing it.
m
DANGER! If at any time you are unable to light the
burner after 1 minute, press down on the control knob and turn
clockwise to the "OFF" position. Then wait 5 minutes to allow
flammable vapors to dissipate before attempting to light the
fire pit.
5. Once the burner is lit, turn the control knob to the desired
heat between "IGNITE/LOW" and "HIGH".
NOTE: The burner flame is normally yellow. If the flame is
blue and very small, please check the gas cylinder as it
may be low on pressure or empty. If this is not the case,
please call the Snow Joe
®
+ Sun Joe
®
customer service
center at 1-866-SNOWJOE (1-866-766-9563) to replace
the burner.
If the flames lift away from the burner, backfires, or
produces thick black smoke, the fire pit should be turned
off immediately and should not be operated again until the
unit is serviced by a qualified service technician.
m
CAUTION! Avoid inhaling fumes emitted from the gas
appliance's first use. Smoke and odor from the burning of oils
used in the manufacturing will appear. Both smoke and odor
will dissipate after approximately 30 minutes. The appliance
should not produce thick black smoke.
6. Press down and turn the control knob clockwise to the
"OFF" position to turn off the fire pit.
m
WARNING! The gas supply must be turned off at the
propane cylinder valve when not in use.
7
m
WARNING! Gas appliance will be hot after use.
Handle with extreme care.
• DO NOT touch or move the fire pit for at least 45 minutes
after use.
• DO NOT put on fabric cover until the fire pit is completely
cooled.
Care and Maintenance
Inspecting
This fire pit should be inspected on a regular basis to ensure
product safety and longer product life.
m
WARNING! DO NOT attempt to inspect this fire
pit until the fire is COMPLETELY out and the fire pit has
COMPLETELY cooled.
1. Check if there are cracks or worn sections on the hose. If
there are, Please call the Snow Joe
®
+ Sun Joe
®
customer
service center at 1-866-SNOWJOE (1-866-766-9563) to
replace the hose.
2. At least once a year, the unit should be inspected for the
presence of spiders, spider webs or other insects.
m
CAUTION! Air flow must be unobstructed.
Signs of a possible blockage includes:
• Fire pit does NOT reach the desired temperature.
• Fire pit glow is excessively uneven.
• Fire pit makes popping noises.
Cleaning
1. Keep exterior surfaces clean.
2. Use warm soapy water for cleaning. Never use flammable
or corrosive cleaning agents.
3. Spiders and insects can nest in the burner. This may
damage your gas fire pit and render it unsafe for use.
Clean burner holes by using a heavy-duty pipe cleaner
and compressed air.
m
CAUTION! While washing your unit, be sure to keep
the area around the burner dry at all times. If the gas control is
exposed to water in any way, do NOT try to use it. It must be
replaced.
Storage
NOTE: Store the fire pit indoors during the winter if it will be
subjected to freezing temperatures.
NOTE: In a high salt environment (such as by the sea),
corrosion occurs more rapidly than normal. Frequently check
for corroded areas and repair them promptly.
1. Turn the control knob to "OFF" position.
2. Turn to close the propane cylinder valve.
3. Allow at least 45 minutes for the fire pit to
cool down after use.
4. Take out the battery from the battery compartment during
extended periods of inactivity or transportation.
5. Turn the regulator counter-clockwise to disconnect it
from the gas cylinder, then turn the cylinder clamp screw
counter-clockwise to loosen the cylinder from the fire pit.
6. Remove the cylinder and seal it tightly using threaded
valve plugs. Store the gas cylinder outdoors in a well-
ventilated area out of the reach of children.
7. Hang the regulator on the gas regulator handle to prevent
it from being damaged.
8. Cover the fire pit with the provided fabric cover to protect
exterior surfaces and to help prevent build up of debris in
air passages.
9. Store gas fire pit in an area sheltered from the elements
(rain, sleet, hail, snow, dust and debris).
m
CAUTION! You may store the fire pit indoors ONLY if
the cylinder is disconnected and removed.
Support
If your Sun Joe
®
SJPPFP-CVR propane fire pit requires service
or maintenance, please call 1-866-SNOWJOE
(1-866-766-9563) for assistance.
Model and Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide
the model and serial numbers, which can be found on the
decal located on the unit. Copy these numbers into the space
provided below.
Record the following numbers from your new product:
Model #:
Serial #:
S J P P F P - C V R
8
Troubleshooting
Only a company specialist may be able to correct faults that cannot be rectified with the aid of this table. Please call the
Snow Joe
®
+ Sun Joe
®
customer service center at 1-866-SNOWJOE (1-866-766-9563).
Gas odor
Delayed ignition
Incorrect burner flame
• Check all gas connections
• Check gas supply pressure
• Clean burner parts--see manual "CARE AND MAINTENANCE" section
• Change battery
• Check gas supply pressure
• Clean burner parts
Problem Remedy
R4_01282020
SNOW JOE
®
+ SUN JOE
®
CUSTOMER PROMISE
OUR WARRANTY:
Snow Joe
warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when used
for ordinary household use for a period of two years from the date of purchase by the original, end-user purchaser when purchased
from Snow Joe or from one of Snow Joe’s authorized sellers with proof of purchase. Because Snow Joe is unable to control the quality
of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not cover Products purchased from
unauthorized sellers. If your Product does not work or there’s an issue with a specific part that is covered by the terms of this Warranty,
Snow Joe will elect to either (1) send you a free replacement part, (2) replace the Product with a new or comparable product at no
charge, or (3) repair the Product. How cool is that!
This Warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
PRODUCT REGISTRATION:
Snow Joe strongly encourages you to register your Product. You can register online at snowjoe.com/register, or by printing and
mailing in a registration card available online from our website, or calling our Customer Service Department at 1-866-SNOWJOE
(1-866-766-9563), or by e-mailing us at [email protected]. Failure to register your Product will not diminish your warranty
rights. However, registering your Product will allow Snow Joe to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by Snow Joe to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not affect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased
at snowjoe.com or by calling 1-866-SNOWJOE (1-866-766-9563).
ABOVE ALL ELSE, Snow Joe, LLC (“Snow Joe”) is dedicated to you, our customer. We strive to make your experience as pleasant as
possible. Unfortunately, there are times when a Snow Joe
®
, Sun Joe
®
, or Aqua Joe
®
product (“Product”) does not work or breaks under
normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have a Limited Warranty
(“Warranty”) for our Products.
9
EN
10
11
sunjoe.com
