2
ENGLISH
CONTENTS
PREPARATION
INSTALLATION
10 Projection Distance per Screen Size
12 Adjusting the Position of the Projection Screen
13 Adjusting the Angle and Focus of the Projection Screen
14 Kensington Security System
USING MAGIC LIGHTING REMOTE
15 Inserting Batteries in the Remote Control
16 Viewing the Remote Control Features
19 Pairing the Magic Lighting Remote
19 Re-registering the Magic Lighting Remote
19 Unregistering Magic Lighting Remote
20 Using the Magic Lighting Remote
CONNECTING DEVICES
21 Connecting with a HDMI Cable
22 Connecting with a USB-C Cable
23 Connecting a smart device (smartphone, tablet, etc.)
SAFETY PRECAUTIONS
CHECKING BEFORE REPORTING MALFUNCTION
35 Projector Safety Check
36 Troubleshooting
CHECKING INFORMATION
38 Specifications
39 HDMI/USB-C Supported mode
43 Licenses
44 Open Source Software Notice Information
45 Other specifications
46 Symbols
This manual is produced for public use and may contain images or contents
different from the product you purchased.
This manual is subject to change depending on the company’s circumstances.
3
ENGLISH
PREPARATION
The pictures may differ slightly from the actual product.
Accessories
Accessories included with the projector are show below.
Accessories are subject to change without prior notice.
New accessories may be added or old ones removed.
Magic Lighting Remote
Two AA Batteries
Owner's Manual
AC-DC Adaptor Power cord
AA: Due to the environment government regulations about import and batteries
destruction in Colombia, projectors will not bring the batteries of remote control
included.
• When connecting an HDMI or USB cable, or
connecting a USB flash drive to the HDMI or
USB port, use a product that has a width of
18mm (0.7inches) or less and a height of
10mm (0.3inches) or less. If the USB cable
or USB flash drive does not fit the USB ports
of the projector, use an extension cable that
supports USB 2.0.
A ≤ 10mm (0.3inches)
B ≤ 18mm (0.7inches)
• Use a certified cable with the HDMI logo attached.
• If you do not use a certified HDMI cable, the screen may not display or a
connection error may occur. (Recommended HDMI cable types)
— Ultra High Speed HDMI
®
/™ Cable (3m (9.8feet) or less)
4
ENGLISH
Optional Extras
To purchase optional accessories, visit an electronics store or online shopping site or
contact the retail store where you purchased the product. Optional accessories are
subject to change without prior notice.
Projection Screen LG Audio Device HDMI Cable
USB-C Cable
5
ENGLISH
Parts and Components
Speaker
Joystick Button
Outlet Vent
2)
Lighting
Lighting
IR Receiver
Display Fit Sensor
Lens
1)
Inlet Vent
1) Do not touch the lens when using the projector. The lens may be damaged. (Keep
lens away from sharp objects.)
2) Due to the high temperature of vent area, do not get close to the vent area.
6
ENGLISH
4
1
2 3
1
Port
2
Port
3
Port
4
(DC IN Port)
NOTE
• Open the projector terminal cover before connecting the cable.
7
ENGLISH
Using the Joystick Button
You can operate the projector by pressing the button or moving the joystick left, right,
up, or down.
Basic functions
Power On
When the projector is turned off, place your
nger on the joystick button, press it once, and
release it.
Power Off
(Press and
Hold)
Press and hold the joystick button for more than
3 seconds while the projector is on.
Volume
Control
Place your nger over the joystick button and
move it up or down, you can adjust the volume
level.
Up/Down/
Left/Right
If you move the joystick up, down, left, or right,
you can move the cursor to select the menu
items.
NOTE
• When moving the joystick button up, down, left or right, be careful not to move
the button while it is being pressed. The volume may not be adjusted and the
cursor may not move when the joystick button is pressed and moved.
8
ENGLISH
Adjusting the menu
When the projector is turned on, press the joystick button one time.
You can adjust the menu items moving the joystick button left, right, up, or down. Move
to the desired menu item, and then press the joystick button once to select it.
Turns the power off.
Changes the input source.
Clears on-screen displays and returns to projector viewing.
Displays the Settings menu.
9
ENGLISH
Projector Status Indicators
LED Power
Indicator
LED Power Indicator
Red
Power standby state
Off
The projector is operating with the power on.
10
ENGLISH
INSTALLATION
Projection Distance per Screen Size
1 Place the projector on a sturdy, level surface, together with the PC or audio/
video source.
2 Place the projector an appropriate distance away from the screen. The distance
between the projector and the screen determines the actual size of the image.
3 Connect the power cord of the projector and the connected device to the wall
outlet.
Ratio of upward projection: 100 %
X/2 X/2
Projection Distance (D)
Screen Height (X)
Screen
Y/2 Y/2
Projection Distance (D)
Screen
Screen Width (Y)
11
ENGLISH
16:9 Aspect Ratio
Screen Size Screen Width (Y) Screen Height (X)
Projection
Distance (D)
inches mm inches mm inches mm inches mm
60 1524 52.2 1328 29.4 747 63.5 1615
70 1778 61.0 1550 34.3 872 74.4 1890
80 2032 69.7 1771 39.2 996 85.0 2160
90 2286 78.4 1992 44.1 1121 96.0 2440
100 2540 87.1 2214 49.0 1245 106.6 2710
110 2794 95.8 2435 53.9 1370 117.3 2980
120 3048 104.6 2657 58.8 1494 128.1 3255
The projection distance may vary depending on the installation conditions.
NOTE
• If the projected image looks distorted or bent, check to see if the screen is
installed properly.
12
ENGLISH
Adjusting the Position of the Projection Screen
Adjust the angle of the projector to adjust the screen position.
• When adjusting the angle of the projector, be careful not to tilt the projector
backward.
• When adjusting the angle of the projector, be careful not to an excessive force
the projector. It may damage the projector.
13
ENGLISH
Adjusting the Angle and Focus of the Projection
Screen
Be careful not to shake the product.
Automatically adjusts the angle and focus of the projection screen of the projector.
(Q. Settings) → ([Installation Wizard]) → [Auto Screen Adjustment]
When an image appears on the screen, check if it is in focus and ts the screen
properly. If the angle and focus of the projection screen are not adjusted automatically,
you can make detailed adjustments manually.
Adjusting the Angle Details of the Projection Screen
(Q. Settings) → ([Installation Wizard]) → [Edge Adjustment]
Adjusting the Focus Details of the Projection Screen
(Q. Settings) → ([Installation Wizard]) → [Focus Adjustment]
NOTE
• After using the product at room temperature, turning on the power may blur the
focus if the inside temperature is low, but it will recover over time.
• This defocusing is a temporary phenomenon that occurs in low-temperature
environments, and this will not affect the product’s performance or lifespan.
14
ENGLISH
Kensington Security System
• This projector has a Kensington Security Standard connector as an anti-theft
mechanism. Connect a Kensington Security System cable as shown below.
• For more information on installation and use of the Kensington Security System,
refer to the user’s guide provided with the Kensington Security System.
• The Kensington Security System is an optional accessory.
• What is Kensington?
Kensington is a company that provides safety systems for laptops and other
electronic devices. Website: http://www.kensington.com
15
ENGLISH
USING MAGIC LIGHTING REMOTE
• Depending on country
Inserting Batteries in the Remote Control
If the battery low message appears while using the Projector, replace the batteries.
Use 1.5V, AA-type alkaline batteries. Replace the two batteries with new ones and
insert them according to the direction indicator inside the remote control.
1 Remove the battery cover on the back of the
remote control by sliding it downwards.
2 Insert the batteries to match the +, - polarity
symbols.
3 Close the battery cover.
2
1
CAUTION
• Do not mix new batteries with old ones.
16
ENGLISH
Viewing the Remote Control Features
* : To use the button, press and hold for more than 3 seconds.
(Power)
Turns the Projector on or off.
(Input)
Changes the input source.
(Input) *
Accesses the [Home Dashboard].
Number buttons
Enters numbers.
*
Accesses the [Quick Help].
(Ready)
This button is currently unavailable and can be used as a button
for other functions through an update.
*
Edits QUICK ACCESS.
(QUICK ACCESS is a feature that allows you to enter a specied
app directly by pressing and holding the number buttons.)
(More Actions)
Displays more remote control functions.
17
ENGLISH
(Volume button)
Adjusts the volume level.
(Page Up/Down)
Moves to the previous/next page.
(Mute)
Mutes all sounds.
(Mute) *
Accesses the [Accessibility] menu.
(Voice recognition)
Network connection is required to use the voice recognition
function. Check for recommended content. (Some recommended
services may not be available in some countries.)
(Voice recognition) *
Speak while pressing and holding the button to use the voice
recognition feature.
(Home menu)
Accesses the Home menu.
(Home menu) *
Launches the last used apps.
(Back)
Returns to the previous screen.
(Back) *
Clears on-screen displays and returns to last input viewing.
(Up/Down/Left/Right)
Press the up, down, left or right button to scroll the menu. If you
press
buttons while the pointer is in use, the
pointer will disappear from the screen and the Magic Lighting
Remote will operate like a general remote control. To display the
pointer on the screen again, shake the Magic Lighting Remote to
the left and right.
Wheel (OK)
Press the centre of the Wheel button to select a menu. You can
move cursor or menu by using the Wheel button.
18
ENGLISH
Streaming Service buttons
Connects to the Video Streaming Service.
(Picture Mode)
Changes the [Picture Mode].
(Sound Mode)
Changes the [Sound Mode].
(Q. Settings)
Accesses the Quick Settings.
(Q. Settings) *
Displays the [All Settings] menu.
(HDMI Input)
Change the input source to [HDMI].
(Adjust Details button)
These access special functions in some menus.
The remote control buttons light up so that you can use the
remote control in the dark.
If the remote control does not move, the pointer disappears and
the remote control light turns off in about 5 seconds.
The lighting function is applied when the product is shipped, and
if you press and hold the button for more than 5 seconds, the
(POWER) button ashes twice and you can turn the lighting
function on or off.
(Focus Adjustment)
Accesses the [Focus Adjustment].
(Focus Adjustment) *
Initializes the focus that has already been set and adjusts the
focus anew.
(Installation Wizard)
Accesses the [Installation Wizard].
(Mood Lighting)
Turns the Lighting on or off.
19
ENGLISH
Pairing the Magic Lighting Remote
You must pair the Magic Lighting Remote with the projector to use it.
Pair the Magic Lighting Remote prior to use as follows.
1 Put batteries into the Magic Lighting Remote and turn the projector on.
2 Point the Magic Lighting Remote at your projector and press the Wheel
(OK) on the remote control.
• If the projector fails to register the Magic Lighting Remote, try again after
turning the projector off and back on.
Re-registering the Magic Lighting Remote
If the Magic Lighting Remote’s pointer does not appear on the projector, you must
re-register it.
1 Hold the remote control towards the projector and press the and
buttons at the same time for more than 5 seconds until instructions appear.
2 The previously registered remote control is deregistered and then registered
again.
Unregistering Magic Lighting Remote
If you have multiple LG Smart Projectors and want to register the Magic Lighting
Remote currently in use to another Projector, you must unregister the previous one.
1 If you press the button and the button at the same time for more
than 5 seconds, the lamp on Magic Lighting Remote will blink and the
registration will be canceled.
2 If you want to unregister and register for another LG Smart projector, please
follow the registration method above.
20
ENGLISH
Using the Magic Lighting Remote
1 If you shake the Magic Lighting Remote left and right or turn its wheel while
pointing it at the projector, a pointer will appear on the projector screen. If you
move the remote control in the direction you want, the pointer follows the
movement.
2 Move the pointer to the location you want and press the Wheel (OK)
button to execute the function.
3 If the pointer has not been used for a certain period of time, it will disappear.
When the pointer disappears from the screen, shake the Magic Lighting
Remote right and left. It will then re-appear. The pointer will disappear if you
press Up/Down/Left/Right buttons, and the remote will work as a standard
remote control.
4 You can control the projector by scrolling or pressing Wheel (OK) button
in the middle of Up/Down/Left/Right buttons. When viewing a screen that
requires scrolling, you can easily move up and down by scrolling the Wheel
(OK) button. When watching a video, you can press the Wheel (OK)
button to pause/play.
• If the pointer is not responding smoothly, you can reset the pointer by moving it
to the edge of the screen.
• You can set the pointer speed and size you want while it is on the screen.
(Q. Settings) → → [General] → [System] → [Additional Settings] →
[Pointer Options]
— [Tracking Speed]: Sets the pointer speed.
— [Pointer Size]: Selects the pointer size.
• Use the remote control within the working distance (within 10m (32.8feet)).
If there is an obstacle between the projector and the remote control, it may not
operate properly.
• Depending on the peripherals (wireless router, microwave oven, etc.),
communication failures may occur.
• Impacts can cause the Magic Lighting Remote to malfunction.
• Take care not to bump into nearby furniture, electronic equipment, or other
people when using the Magic Lighting Remote.
• The Magic Lighting Remote may not work properly if a wireless router (AP) is
within 0.2m (0.6feet) of the Projector. Your wireless router should be more
than 0.2m (0.6feet) away from the Projector.
21
ENGLISH
CONNECTING DEVICES
You can connect various external devices to the projector.
Connecting with a HDMI Cable
Connect an HD receiver, DVD, PC, Notebook, or external devices to the projector and
select an appropriate input mode.
With an HDMI cable, you can enjoy high quality picture and sound.
Using a HDMI cable, connect the port of the projector to the HDMI output port
of the device to connect. Both video and audio are output at the same time.
• (Input) → [Home Dashboard] → [Inputs] → [HDMI]
Optional Extras
NOTE
ARC (Audio Return Channel)
• External audio devices that support SIMPLINK and ARC must be connected
using port. ( )
• When connected with a Ultra High Speed HDMI
®
/™ Cable, external audio
devices that support ARC output or SPDIF work with the SIMPLINK function
without the need for an additional optical audio cable.
When connecting PC/laptop
• The projector supports Plug and Play. Your PC will automatically detect the
projector and requires no driver installation.
22
ENGLISH
Connecting with a USB-C Cable
Connect the USB-C terminal of the projector to the USB-C output terminal of a PC/
laptop or smartphone using a USB-C cable.
Contact the manufacturer of your device to see if this feature is supported. Only the
smartphones that support USB-C will work.
• (Input) → [Home Dashboard] → [Inputs] → [USB-C]
USB-C
Optional Extras
NOTE
• PD (Power Delivery) and DP Alternate Mode are supported.
— A USB-C gender changer may be necessary depending on the cable used if
using PD (Power Delivery).
• The function may not operate properly depending on the connected device’s
specifications, USB-C cable status, or surroundings.
• The USB PD (for power supply) function may not operate according to the
specifications of the connected equipment.
• Check the resolution of the connected devices before using the DP Alternate
Mode function.
23
ENGLISH
Connecting a smart device (smartphone, tablet,
etc.)
• (Input) → [Home Dashboard] → [Inputs] → [HDMI]
• The picture may look different from the actual product.
Connect a smart device to the projector using a cable
1)
and set the external input of
the projector to HDMI. The smart device screen will then be displayed through the
projector. You can connect with any HDMI input port.
For model-specic instructions regarding use of the wired connection, please check
with the smart device manufacturer.
Supported smart devices may change depending on the circumstances of each
manufacturer.
1) Examples of how to connect a cable to different smart devices (cable purchased
separately).
Slimport supported devices
HDMI cable
Projector HDMI port
Projector USB port
Charging
cable of
a smart
device
Slimport adapter
Charger
Charging port of a
smart device
Apple Lightning Digital AV adapter supported devices
HDMI cable
Projector HDMI port
Lightning Digital AV
adapter
Charging port of a smart device
Apple 30-pin Digital AV adapter supported devices
HDMI cable
Projector HDMI port
Apple 30-pin Digital
AV adapter
Charging port of a smart device
24
ENGLISH
SAFETY PRECAUTIONS
Please take note of the safety instructions to prevent any potential accident or misuse
of the projector.
Child injuries can be prevented by following these simple safety precautions.
The precautions should be followed in the same manner when you store or move your
existing projector.
• Safety precautions are given in two forms, i.e., WARNING and CAUTION as
detailed below.
WARNING: Failure to follow the instructions may cause serious injury and
even death.
CAUTION: Failure to follow the instructions may cause personal injury or
product damage.
• Read the owner’s manual carefully and keep it on hand.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead symbol, within an equilateral triangle,
is intended to alert the user to the presence of uninsulated dangerous
voltage within the product’s enclosure that may be of sufcient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the device.
WARNING/CAUTION
— TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR MOISTURE.
25
ENGLISH
Read these instructions. Keep these instructions.
Heed all warnings. Follow all instructions.
Indoor Installation
WARNING
Do not install products including projectors and remote controls in the
following places:
— Any place exposed to direct sunlight;
— Any humid place such as bathroom;
— Any place near hot objects such as ammables and stoves;
— Any place where oil, oil mist, and steam can reach such as a worktop or places
near a humidier;
— Any place where water can splash like a vase or the aquarium;
— Any place that is dusty or exposed to wind and rain;
— Any place that is under the air conditioner or is directly exposed to the wind
from the air conditioner;
— Any place near ammable materials such as ammable sprays, etc.; or
— Any cupboard, bookcase shelf or cabinet without a xture installed and any
place where a pet can access.
• It may cause an electric shock, fire, malfunction, deformation or falling.
Be careful not to drop the projector when connecting an external device.
• It may cause injury or damage to the product.
26
ENGLISH
Keep the following precautions in mind to prevent the temperature rise inside
the projector:
— Install the air vents at least 30cm (11.8inches) away from the wall.
— Do not install the product in a place where it cannot be ventilated, such as on a
bookcase or in a closet.
— Do not install the product on carpet or cushion.
— Make sure that the air vents are not blocked with tablecloths, curtains, etc.
• It may cause a fire.
For places where oil or oil mist can reach, do not install the product on a wall
or ceiling.
• The product may be damaged and fall.
Do not allow a child to hang or climb on the installed projector.
• The projector may fall and cause injury or death.
27
ENGLISH
CAUTION
When moving the projector, be sure to turn off the power switch and
disconnect the power plug, antenna cable and the connection cord between
the devices.
• A failure to do so may cause damage to the projector or the cord, resulting in a
fire or electric shock.
Do not install the projector on a shaky shelf, a slanted place, a place subject
to vibrations, a place where the projector is not fully supported or on a fabric
such as tablecloths.
• It may cause injury as the projector falls or tips over, or it may cause a
malfunction of the projector.
To prevent damage to the power cord or plug, do not install the projector
where the cord can be walked on.
• It may cause a fire or electric shock.
When installing the projector, do not install it too close to the wall.
• The cable connection may be deteriorated or the projector and its cables may be
damaged.
When installing the projector on a cabinet or a shelf, make sure that the front
end of the bottom of the projector does not come out.
• The projector may fall due to the unbalance of the center of gravity and cause
injury to people or a malfunction.
28
ENGLISH
When in Use
WARNING
When thunder or lightning strikes, unplug the power cord and do not touch
the antenna wire.
• It may cause an electric shock.
If there is a gas leak from the gas lines, do not touch the outlet and be sure to
vent by opening the window.
• Sparks may be caused and lead to a fire or burns.
When using the product with an external device connected such as a games
console, make sure the connection cable is long enough.
• The product may fall over and cause injury or product damage.
Do not scratch or give an impact on the projector with metallic materials or
objects.
• It may cause injury to people or damage to the product.
Do not insert metallic objects including coins, hairpins or a piece of iron or
ammableobjectssuchaspaperormatchesintotheprojector.
• It may cause a fire or electric shock.
When replacing the batteries used for the remote control, be careful not to let
children eat them and keep the batteries out of reach of children.
• If a child swallows the battery, consult a doctor immediately.
29
ENGLISH
Keep the plastic wrapping of the product out of the reach of children.
• If a child misuses it, it may suffocate the child.
Do not touch near the vents during the operation or immediately after the
power is turned off as they generate intense heat.
• The heat does not indicate a defect or a problem of the projector when it is
operating so use it with confidence.
Do not look into the front of the lens when the projector is operating. Strong
light is projected from the product which can cause injury to your eyes.
Never try to disassemble or modify the projector yourself. Always seek a
qualiedservicetechnicianorconsultyourdealerorlocalServiceCenterfor
inspection, adjustment or repairs.
• It may cause a fire or electric shock.
30
ENGLISH
CAUTION
Do not use any product that uses high voltage electricity near the projector.
(e.g.Anelectricyswatter)
• It may cause a malfunction.
Do not place any liquid containers such as a vase, pot, cup, cosmetics or
medicine, decorations such as candles or any heavy objects on top of the
projector.
• Doing so may cause a fire, electric shock and injury due to failing.
The surface of the AC adapter is hot, so be careful not to put the surface
against your skin or let the children touch the surface during use. (Except for
the models that do not use an adapter)
Do not hold or move the projector upside down by grabbing only the power
cord, signal cable, or projection mirror.
• Doing so may damage the product or cause an electric shock or fire.
Even if the projector is turned off with the remote control or the button, the
power is not completely cut off if the power cord is plugged in.
If you use headphones or earphones, do not use them at high volume or for a
long period of time. (It applies only to the models that support headphones
(earphones).)
• Doing so may damage your hearing.
Do not start the projector when the volume is high.
• A loud volume can cause hearing loss.
Do not use or store the projector outdoors for an extended period of time.
Do not touch the projector’s lens or give an impact on it.
• It may cause damage to the product.
31
ENGLISH
Do not block the light from the projector lens with a person, book or other
objects.
• If the light from the projector shines on an object for a long time, it can cause
fire due to the heat of such light. Also, the reflected light can heat the lens and
cause damage to the projector.
Do not mix old and new batteries together.
• It may cause battery rupture or fire due to liquid leakage or may cause electrical
shock.
When replacing the batteries, make sure that they are properly installed
according to the polarities (+, -).
• Battery rupture or leakage may lead to fire, explosion, injury or contamination
(damage) of the surrounding area.
Donotexposethebatteriestodirectsunlight,replace,electricheater,high
temperatureabove60°C(140°F),excessivelyhumidplacesorexcessiveheat.
• It can cause an explosion or fire.
Do not throw or disassemble the battery.
• It can cause a fire and explosion due to battery damage.
Do not carelessly throw away old batteries.
• It can cause an explosion or fire. The disposal method may vary by country and
region. Dispose of it in an appropriate manner.
Riskofreorexplosionifthebatteryisreplacedbyanincorrecttype.
Supervise children and to never allow them to stare into the projector beam at
any distance from the projector.
Use caution when using the remote control for staring the projector while in
front of the projection lens.
The user to avoid the use of optical aids such as binoculars or telescopes inside
the beam.
Iftheambienttemperaturerisesabove30°C(86°F),thefanmayrunfaster
to protect the internal parts of the projector.
Iftheambienttemperatureexceeds35°C(95°F),thelightoutputmaybe
reduced to protect the projector.
32
ENGLISH
Power
WARNING
Make sure the power plug is securely plugged in to prevent it from shaking.
• If the connection is unstable, it may cause a fire.
Do not plug too many devices into one multi-power outlet.
• This may result in fire due to the power outlet overheating.
Do not insert a metal object such as chopsticks into the other end of the
power plug while it is plugged into a wall outlet. Also, do not touch the power
plug immediately after unplugging it from the outlet.
• It can cause an electric shock.
Connect the power plug to a grounded outlet or multi-tap. (Except for any
device without ground connection)
• A failure to do so may cause an electric shock due to a malfunction or electrical
short.
Never touch the power plug with wet hands.
• It may cause an electric shock.
Disconnect the power plug from the outlet when you are not using the
projector for a long time or absent.
• Dust collects and may cause an electric shock and fire caused by a short circuit
due to heat, ignition and insulation/degradation.
The Power Plug is the disconnecting device. In case of an emergency, the
Power Plug must remain readily accessible.
33
ENGLISH
If any of the following occurs, it could be a malfunction of the product, so
you must immediately turn the projector off, unplug the power cord from the
outlet, and contact the service center:
— When the product is damaged;
— When the product fails;
— When there is a foreign substance inside the product; or
— When the product smokes or smells.
• It may cause a fire or electric shock.
CAUTION
Do not unplug or plug the power plug from/in the outlet while the power
switch is on. (Do not use the power plug as a switch.)
• It may cause a fire or malfunction.
When removing the AC adapter or power cord, be sure to hold the plug part.
• A failure to do so may cause a fire or damage to the product.
Do not damage the AC adapter, power cord or power plug, place heavy objects
on them or give an impact on them.
• It may cause a fire, electric shock or damage to the product.
Attach the power cord and AC adapter connected to the projector in a way
that they are fully seated.
• Poor contact can cause a malfunction of the product and fire.
If there is dust on the pin part of the power plug or the outlet, clean it
thoroughly.
• It may cause a fire.
Keep the power cord away from heat sources.
• The coating of the cord may melt and cause a fire or electric shock.
Use only the authorized power cord or AC adapter supplied by LG Electronics.
Do not use any other products.
• It may cause a malfunction of the product, fire or electric shock.
34
ENGLISH
Cleaning
WARNING
Do not spray water directly onto the projector when cleaning it.
• It may cause a fire or electric shock.
CAUTION
How to clean the projector
— Disconnect the plug from the outlet before cleaning.
— Do not wipe the optical system (the lens and mirror) immediately after the
power is turned off.
— Do not spray the water with a sprayer on the product or wipe the product with
a damp cloth.
— Wipe the product gently with a soft cloth.
— Do not use any detergents, automotive or industrial polishes, abrasives, waxes,
benzenes or alcohols.
• It may cause a fire, electric shock or damage to the projector (deformation,
corrosion, and breakage).
How to clean the lens
— Clean the lens if any dust or smudge appears on the surface of the lens.
— Clean the surface of the lens with an air sprayer or a soft, dry cloth.
— To remove dust or stains on the lens, use a compressed air duster, cotton swab,
or soft cloth to gently wipe the lens.
— Never clean the lens when the projector is operating or immediately after the
projector is turned off.
— Do not use any detergents, automotive or industrial polishes, abrasives, waxes,
benzenes, alcohols, water, etc. on the lens, as they will damage the projector.
Consult your dealer or the service center for cleaning the interior of the
product once a year.
• If you do not clean the interior of the projector for a long time while dust
collects, it may cause a fire or malfunction.
35
ENGLISH
CHECKING BEFORE REPORTING
MALFUNCTION
Please check the list below when you experience the following symptoms during use of
the product. It may not be a failure.
Projector Safety Check
Symptoms
• The projector does not display anything on the screen or output sound when
it is turned on.
• The product emits smoke or a burning smell.
• Water or foreign substances are present inside the product.
• Part of the projected image is cut out.
• A strange noise (crackling or sparking sound) regularly occurs from inside the
projector.
• The projector still displays the screen or outputs sound when it is turned off.
• There are other errors or failures.
Causes and Solutions
• For safety, turn off the power switch and remove the plug from the socket.
• Contact the place of purchase or authorized service center for product
inspection.
• Do not attempt to repair the product yourself.
36
ENGLISH
Troubleshooting
Symptoms Causes and Solutions
I cannot turn on
the Projector.
• Please make sure your projector power plug is correctly
connected to the outlet.
• There may be a problem with the outlet, so try plugging
the power cord of another product into the outlet
where the projector was plugged in.
Cannot control
the Projector
with the remote
control.
• The remote control may not work properly where a
lamp with electronic stabilizer or a three-wavelength
lamp is installed.
— In this case, replace the lamp with electronic
stabilizer or the three-wavelength lamp with
international standard products to ensure the
remote control works properly.
• Check if there is any obstacle between the product and
the remote control.
• When replacing the batteries, make sure that they are
properly installed according to the polarities (+, -).
• Replace both used batteries with new ones.
The power turns
off suddenly.
• Check whether the [Sleep Timer], [Auto Off], or [Auto
Power Off] is set.
• See if the external devices are operating together.
• The auto-off function may have been activated. This
product is equipped with an auto-off function that
automatically turns the product off when no signal is
present and when the remote control has not been
pressed, depending on the settings for the auto-off
function.
37
ENGLISH
Symptoms Causes and Solutions
I see dots on the
screen.
• There is a colored dot (bright dots, dark dots, stationary
dots, and/or flickering dots) on the screen.
— This projector was produced with high precision
technology. However, a tiny dark or bright dot may
appear on the screen. This is a common occurrence
due to the production process, and it does not
indicate a functional failure.
※ Bright spot: brightly lit dots, Dark spot: invisible or blurred
point of text or objects, Blinking: ashing dots, Bright dot:
glowing dots that are brighter than regular images
I hear a noise. • Electrical noise: this is a small sound generated from
the operation of the high-speed switching circuit that
supplies current to the projector, and the noise may
vary depending on the product. This noise is normal and
does not affect the projector’s functions. LG Electronics
manages the manufacturing of projectors according to
strict standards. A fixed level of noise does not indicate
a problem. Please understand that this does not allow
you to get an exchange or refund.
• Fan sound: to maintain the temperature inside the
projector at an appropriate level, the fan sound may
increase or decrease depending on the ambient
temperature.
38
ENGLISH
CHECKING INFORMATION
Specications
MODEL
PU700R (PU700R-GL)
Resolution (Pixel)
3840 (Horizontal) × 2160 (Vertical)
1)
Aspect ratio
16:9 (Horizontal:Vertical)
Projection distance
— Screen size
1615 mm to 3255 mm (63.5 inches to 128.1 inches)
— 1524 mm to 3048 mm (60 inches to 120 inches)
Ratio of upward
projection
100 %
Power
consumption
140 W
AC-DC Adaptor
Manufacturer: Honor
Model: ADS-150KL-19N-3 190140E
Input: 100-240 V~ 50/60 Hz 2.0 A
Output: 19.0 V 7.37 A
Audio Output
5 W (Mono)
Height
306.1mm (12.0inches) (without foot), 307.1mm
(12.0inches) (with foot)
Width
164 mm (6.4 inches)
Depth
144 mm (5.6 inches)
Weight
3.1 kg (6.8 lbs)
USB Device
USB 2.0 Standard-A
Output: 5 V, 0.5 A (Max.)
USB Type-C
Output: 5 V, 1 A (Max.)
Environment
Condition
Temperature
Operation
0 °C to 40 °C (32 °F to 104 °F)
Storage
-20 °C to 60 °C (-4 °F to 140 °F)
Relative Humidity
Operation
0 % to 80 %
Storage
0 % to 85 %
• Use only power supplies listed in the user instructions.
• Contents in this manual may be changed without prior notice due to upgrade of
product functions.
1) 4K UHD resolution with 8.3 million discrete pixels projected by XPR (Extended Pixel
Resolution) video processing.
39
ENGLISH
HDMI/USB-C Supported mode
DTV
Resolution
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
640 x 480p 31.46 59.94
640 x 480p 31.5 60
720 x 480p 31.46 59.94
720 x 480p 31.5 60
720 x 576p 31.25 50
1280 x 720p 37.5 50
1280 x 720p 44.95 59.94
1280 x 720p 45 60
1920 x 1080i 28.12 50
1920 x 1080i 33.71 59.94
1920 x 1080i 33.75 60
1920 x 1080p 26.97 23.97
1920 x 1080p 27 24
1920 x 1080p 28.12 25
1920 x 1080p 33.71 29.97
1920 x 1080p 33.75 30
1920 x 1080p 56.25 50
1920 x 1080p 67.43 59.94
1920 x 1080p 67.5 60
3840 x 2160p 53.94 23.97
3840 x 2160p 54 24
40
ENGLISH
Resolution
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
3840 x 2160p 56.25 25
3840 x 2160p 67.43 29.97
3840 x 2160p 67.5 30
3840 x 2160p 112.5 50
3840 x 2160p 134.86 59.94
3840 x 2160p 135 60
4096 x 2160p 53.94 23.97
4096 x 2160p 54 24
4096 x 2160p 56.25 25
4096 x 2160p 67.43 29.97
4096 x 2160p 67.5 30
4096 x 2160p 112.5 50
4096 x 2160p 134.86 59.94
4096 x 2160p 135 60
41
ENGLISH
PC
Resolution
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
640 x 350 31.46 70.09
720 x 400 31.46 70.08
640 x 480 31.46 59.94
800 x 600 37.87 60.31
1024 x 768 48.36 60
1152 x 864 54.34 60.05
1360 x 768 47.71 60.01
1280 x 1024 63.98 60.02
1920 x 1080 67.5 60
3840 x 2160 53.94 23.97
3840 x 2160 54 24
3840 x 2160 56.25 25
3840 x 2160 67.43 29.97
3840 x 2160 67.5 30
3840 x 2160 112.5 50
3840 x 2160 134.86 59.94
3840 x 2160
135 60
4096 x 2160 53.94 23.97
4096 x 2160 54 24
42
ENGLISH
Resolution
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
4096 x 2160 56.25 25
4096 x 2160 67.43 29.97
4096 x 2160 67.5 30
4096 x 2160 112.5 50
4096 x 2160 134.86 59.94
4096 x 2160 135 60
• If an invalid signal is input into the projector, it will not be displayed properly on
the screen or a message such as [No Signal] or [Invalid Format] will be displayed.
• The projector supports the DDC1/2B type as the Plug and Play function (Auto-
recognition of PC monitor).
• 3840 x 2160 is recommended as the best picture quality in the PC mode.
43
ENGLISH
Licenses
Supported licenses may differ by model. For more information about licenses, visit
www.lg.com.
The terms HDMI, HDMI High-Denition
Multimedia Interface, HDMI trade dress
and the HDMI Logos are trademarks or
registered trademarks of HDMI Licensing
Administrator, Inc.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Vision, Dolby Vision
IQ, Dolby Audio, Dolby Atmos, and the double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum.
44
ENGLISH
Open Source Software Notice Information
To obtain the source code that is contained in this product, under GPL, LGPL, MPL,
and other open source licenses that have the obligation to disclose source code, and
to access all referred license terms, copyright notices and other relevant documents,
please visit https://opensource.lge.com.
LG Electronics will also provide open source code to you on CD-ROM for a charge
covering the cost of performing such distribution (such as the cost of media, shipping,
and handling) upon email request to[email protected].
This offer is valid to anyone in receipt of this information for a period of three
yearsafter our last shipment of this product.
45
ENGLISH
Otherspecications
As with any bright light source, do not stare into the beam, RG2 IEC 62471-
5:2015.
Risk Group 2
CAUTION Possibly hazardous optical radiation
emitted from this product. Do not stare at
operating lamp. May be harmful to the eye.
This label is attached to the bottom of the product and language may differ.
46
ENGLISH
Symbols
Refers to alternating current (AC).
Refers to direct current (DC).
Refers to class II equipment.
Refers to stand-by.
Refers to “ON” (power).
Refers to dangerous voltage.
ABOUT LG PROJECTOR
The images in this user manual are for illustration purposes only and may look different from the
real product.
The contents of this user manual may be changed or added without prior notice to improve the
quality of the product.
Your projector’s OSD (On Screen Display) may differ slightly from that shown in this manual.
[ ]: the buttons and the text to be displayed on the projector screen.
ABOUT LG PROJECTOR
Copyright © 2022 LG Electronics Inc. All Rights Reserved.
3
ENGLISH
ABOUT LG PROJECTOR
Home Tutorial
Using the Home feature of the LG Projector
You can open the Home screen by pressing the button on your remote control.
You can use more features by scrolling the Wheel (OK) button on the Magic
Lighting Remote. You can open apps and content or use various features of the smart
projector.
• When using a standard remote control, press the up/down button on the remote
control.
4
5
6
1
2 3
1
You can check weather information and useful projector features.
2
You can log in to your [LG Account] or view basic information about the
account to which you are currently logged in.
For details, please refer to "Managing your LG Account".
3
Launch [Search].
For details, please refer to "Search Content".
4
ENGLISH
4
Returns to the most recently used external input.
5
You can get recommendations from various contents.
• You must log in to your LG account to get personalized content
recommendations.
• You must connect to the network to use the recommendation
feature.
6
You can run, move, and delete the apps installed on your projector.
• [App List] and [Top Picks For You] are automatically shown on the screen each
time the projector is turned on. To change the Home screen display, change the
setting of [Home Auto Launch] in (Q. Settings) → → [General] →
[System] → [Additional Settings] → [Home Settings].
• The availability of and access to contents and services in LGE device are subject
to change at any time without prior notice.
• Available features vary depending on the region or service.
5
ENGLISH
Manage LG Projector Home
You can change the order of displayed apps or content lists by pressing the button
on the remote control.
You can use more features by scrolling the Wheel (OK) button on the Magic
Lighting Remote. You can enter edit mode by selecting located at the bottom of
the screen.
6
ENGLISH
1
3
4
2
1
Enter the [Edit App List] mode.
Depending on your usage pattern, you can set the app order automatically
or edit it yourself.
• After selecting the app you wish to edit from [App List] on the Home
screen, press and hold the OK button on the remote control, or select
the [Edit App List] button located in the last area of [App List] to
enter [Edit App List] mode.
2
Enters the [Edit Contents List] mode.
You can directly edit the order of the content list displayed in Home.
3
[Reset App Order]: Resets the order of items in the app list.
[Delete Usage Data]: It resets the content view history and the app usage
history. If you reset them, it takes some time to receive recommendations
for contents again.
[Home Settings]: When turning the power on, go to the screen that sets
the Home behavior.
• Items that can be set may vary depending on the edit mode.
4
Exits edit mode.
7
ENGLISH
Connecting to the Network
Connecting to the Network
If you congure settings for the network, you can use various services such as online
contents and applications.
Setting a Wireless Network
1 Turn on the power of the router connected to the Internet.
2 Press the (Q. Settings) button on the remote control.
3 Select → [General] → [Network] → [Wi-Fi Connection].
4 When the network search is complete, the list of networks available for
connection is shown.
5 Select a network to connect.
If your Wireless Router is password protected, enter the password congured
for the router.
8
ENGLISH
Cautions for Network Setup
• Resetting the router may fix some network connection problems. Turn the
power OFF, disconnect and reconnect it, and then turn the power on to solve the
problem.
• LG Electronics is not responsible for network connectivity or operation failure
due to problems such as equipment failure or disconnected lines.
• The network connection may not work properly because of network settings or
the Internet service provider.
• DSL service must use a DSL modem; and cable service must use a cable modem.
Since only a limited number of network connections may be available, projector
network setting may not be used depending on the contract with Internet
service provider. (If the contract does not allow more than one device per line,
only the already-connected PC may be used.)
• A wireless network can experience interference from other devices that use
the 2.4 GHz frequency (wireless phone, Bluetooth device, or microwave oven).
Although interference can also happen when using the 5 GHz frequency, it is less
likely to occur.
• The wireless environment can make wireless network service run slowly.
• Using several wireless devices at the same time can slow your network.
• The access point device must support wireless connections and wireless
connection feature must be enabled on the device to have AP (access point)
connection. Contact the service provider for availability of wireless connections
on the access point.
• Check SSID and security settings of the AP. Refer to the appropriate
documentation for SSID and security settings of the AP.
• If the network is changed by moving the projector or changing the router, you
must set up the wireless network again. Existing wireless network connections
will not be saved.
• Invalid settings of network devices (wired/wireless line sharer, hub) can cause the
projector to operate slowly or not operate properly. Install the devices correctly
according to the appropriate manual and network.
• The connection method may differ depending on the AP manufacturer.
• To troubleshoot problems with this feature, refer to "TROUBLESHOOTING".
9
ENGLISH
Managing your LG Account
LG Membership
Logging in with [LG Account] enables you to use customized recommended content
and various app service.
You can sign up for LG membership and log in with your email address in [LG Account].
Alternatively, you can sign up for LG membership using the ID and password of an
external service account.
1 Select (Q. Settings) → → [General] → [System] → [LG Account].
2 Choose one from the three options, Sign in with the [Sign in with the Mobile
Web]/[Sign in with the Projector remote], and sign up for LG membership.
3 Agree to the User Agreements and enter the information required to sign up.
• Required information may vary depending upon the country.
4 A verication link will be sent to the email address you entered when you
signed up. Please complete email verication within the validity period.
5 Once your email address is veried, you can log in with your credentials.
• This feature may not be available in some countries.
• Age restrictions may apply for signing up.
• To troubleshoot problems with this feature, refer to "TROUBLESHOOTING".
Managing your LG Account
• (Q. Settings) → → [General] → [System] → [LG Account]
When you enter [LG Account], the previously logged-in account is displayed, and you
can select an account to log in or edit the account list.
Basic information about the account can be viewed by selecting [Account
Management] under the logged-in account. Also, you can change your password or edit
your account information.
10
ENGLISH
HOW TO OPERATE THE PROJECTOR
Using Projector Functions through Speech
You can easily and quickly access the projector’s various functions through speech
recognition.
1 Press and hold the (Voice recognition) button on the remote control and
speak out the function you want to launch or the keyword you want to use for
your search.
2 Once you release the (Voice recognition) button after your speech input,
the corresponding function is launched.
11
ENGLISH
• Some models may not be supported.
• Your [Location] must correspond to the language for exact search results. Some
function may not be available if your location settings and language settings are
different.
• You can change the language in (Q. Settings) → → [General] →
[System] → [Language] → [Menu Language].
• The languages available for voice recognition features may be changed in
accordance with service operation policy.
• Details of service may vary by model.
• Please note that AI service may be changed, removed or terminated, without
notice, by LGE or its third party providers.
• You can change the voice-related settings or see which features are available to
be used with the voice in (Q. Settings) → → [General] → [AI Service]
→ [Voice Recognition Settings]/[Voice Recognition Help].
12
ENGLISH
Cautions for Speech Recognition
• Voice recognition requires a Magic Lighting Remote, which may not be supported
by certain models.
• To use all speech recognition features, you need to set your regions, etc.
Otherwise, you cannot use some features.
• You must have a network connection to use the speech recognition feature.
• If you have a network connection, you need to accept the terms and conditions
to use speech recognition.
• To control the set-top box connected to the projector with the voice recognition,
you need to set the universal remote control in (Q. Settings) → →
[General] → [Devices] → [External Devices] → [Universal Control Settings].
• It is recommended to point the Magic Lighting Remote toward the set top box
after the voice input.
• The rate of speech recognition may vary depending on the characteristics
of the user (voice volume, pronunciation, accent, and talking speed) and the
surroundings (noise and projector volume).
• To achieve accurate recognition of your speech, you must pronounce words in a
slow and accurate manner at an appropriate voice volume at a distance of about
10 cm away from the Magic Lighting Remote’s microphone.
• If you speech is not recognized properly, speech recognition may operate
differently than you originally intended.
13
ENGLISH
To View More Features of the Remote Control
You can control more features or external devices connected to your projector by using
the buttons displayed on your projector screen.
1 Press the button on the remote control.
2 Using the remote control, select your desired button on [More Actions]
displayed on your projector screen.
2
3
1
1
You can set up the universal remote control.
• You need Magic Lighting Remote to use universal remote control
function. (The provided remote control differ depending upon model.)
2
External input information is displayed on the screen.
3
When the projector malfunctions, you can get help to solve the problem.
• The types of buttons appearing on the [More Actions] vary, depending on the
region and the type of connected device.
• The configurable items differ depending upon model.
14
ENGLISH
Universal Remote Control
Automatically Setting the Universal Remote Control
When you set up the universal remote control, you can control the peripherals (Blu-ray
/ DVD player, home theater, set-top box, etc.) with the Magic Lighting Remote rather
than using their dedicated remote controls.
Connect the devices to be set to the projector’s HDMI input, and turn the power of the
device on.
The projector will scan the connected device to automatically set the universal remote
control without manual setting.
• After setting the universal remote control, you may need to do some additional
user settings.
• It may take several seconds to complete the settings for the universal remote
control.
• In some models, you can set the universal remote control only after converting
to an input of a connected device.
• Depending on the connected device, the automatic setting feature for universal
remote control (automatic device connection) may not be supported.
15
ENGLISH
Manually Setting the Universal Remote Control
If the universal remote control is not set up automatically, you can set it up manually.
1 Select (Q. Settings) → → [General] → [Devices] → [External
Devices] → [Universal Control Settings].
2 Select the type of the device you want to set.
3 Complete the settings for the universal remote control according to the
guidance on the screen.
You can change or cancel the universal remote control settings.
• This feature can only be used with the Magic Lighting Remote. (The provided
remote control differ depending upon model.)
• Some models may not be supported.
• When changing the settings, check that the device to be changed is turned on.
• To set up the universal remote control with the latest information, connect to a
network and agree to the User Agreements.
• The manual setting feature for universal remote control is not supported for a
game console.
• Some buttons may not work depending upon the model of the external device.
• Point the Magic Lighting Remote at the device you want to control. Make sure
that there are no objects in front of the device to ensure that the remote control
signal is well received.
16
ENGLISH
Launching Apps through [Quick Access]
Using apps quickly and easily with [Quick Access]
Press and hold a number button on the remote control to open an app or to activate an
external input registered to the button.
Setting the [Quick Access]
1 Launch the app or input you wish to assign.
2 Press and hold the number button (1~8) you want to register.
No. 9 is xed to [Quick Help].
3 When the registration pop-up window appears, select [Yes].
• If you press and hold a number button that has already been registered, the
registered function will be performed.
• To see the items that can be registered, select a number that has not been
registered in the [Edit Quick Access] mode.
• If you are in a mode where [Quick Access] cannot run, no action will be
performed.
• If you delete a registered app, [Quick Access] will be deregistered as well.
17
ENGLISH
Checking and editing [Quick Access]
Press and hold the number 0 button on the remote control.
The [Quick Access] edit screen appears.
1
2
3
1
Selecting a number that has already been registered allows deregistering
it.
2
When you select a number that has not been registered, items that can
be registered will be shown.
• An item that has been registered to a different number is indicated
with a check mark.
3
You can view a brief instruction for this function.
18
ENGLISH
Using [Installation Wizard]
[PJT Mode]
(Q. Settings) → ([Installation Wizard]) → [PJT Mode]
This function turns the projected image ips horizontal.
[Edge Adjustment]
(Q. Settings) → ([Installation Wizard]) →[Edge Adjustment]
[Edge Adjustment] adjusts the horizontal and vertical sides of the projected image if
the projector is at an angle and not perpendicular to the screen. This feature ensures
the shape of the projected image is not distorted.
Use this feature only when the projector cannot be set up at the optimal angle. [Edge
Adjustment] may result in a loss of image quality.
• Some models may not be supported.
• The configurable items differ depending upon model.
• You can adjust the screen by selecting one out of [4 points]/[9 points]/[15
points].
• [4 points]
Screen fit is adjustable using 4 points.
• [9 points]
Screen fit is adjustable using 9 points.
• [15 points]
Screen fit is adjustable using 15 points.
[High Altitude]
(Q. Settings) → ([Installation Wizard]) → [High Altitude]
If the projector is used at an altitude higher than 1200 meters (3937.0 feet), turn this
on.
Otherwise, the projector may overheat or its protection function may be activated. If
this happens, turn the projector off and then on again after waiting for several minutes.
• Some models may not be supported.
19
ENGLISH
[Remote Setting]
(Q. Settings) → ([Installation Wizard]) → [Remote Setting]
The power button on the LG TV remote control can be used separately or together with
the projector.
• [Projector + TV]
The power on the projector and TV can be used together.
You can turn the projector on and off with the LG TV remote control.
• [Projector Only]
The power on the projector and TV can be used separately.
You cannot turn the projector on and off with the LG TV remote control.
• Some projector models may not support this feature.
• Other company's products are not compatible.
[Interior Image]
(Q. Settings) → ([Installation Wizard]) → [Interior Image]
Decorate space by projecting interior image.
[Focus Adjustment]
(Q. Settings) → ([Installation Wizard]) → [Focus Adjustment]
Adjust the focus of the projection screen with the left/right buttons on the screen or
on the remote control.
[Mood Lighting]
(Q. Settings) → ([Installation Wizard]) → [Mood Lighting]
Set the operation time, color and mode of LED lighting.
[Auto Screen Adjustment]
(Q. Settings) → ([Installation Wizard]) → [Auto Screen Adjustment]
This function automatically adjusts the focus and screen when installing the projector.
When the user passes in front of the screen, [Auto Screen Adjustment] may work.
20
ENGLISH
Connecting to SIMPLINK (HDMI-CEC)
Using SIMPLINK
With a single remote control, you can easily manage various devices such as a soundbar
or set-top box connected to a projector with HDMI.
• Up to three devices can be connected and used simultaneously.
1 Connect the SIMPLINK HDMI Output port to the projector’s HDMI IN port with
an HDMI
®
cable.
2 Select (Q. Settings) → → [General] → [Devices] → [HDMI Settings].
3 Set [SIMPLINK (HDMI-CEC)] to [On].
4 Turn on the connected device. When the projector automatically connects to
the device, the input will switch. If the device is not automatically connected to
the projector, click the button.
• This feature works only with devices with the logo. Check for the
SIMPLINK logo on the external device. There may be a problem using the device
if the device does not meet the required specifications.
• A high-speed HDMI
®
cable with CEC (Consumer Electronics Control) function is
required to use SIMPLINK. Pin 13 of the high-speed HDMI
®
cable is used for data
transfer between devices.
• To output sound from an external audio device, connect the audio device to the
projector's HDMI (ARC) port with an HDMI cable. Set Sound Out to [HDMI(ARC)
Device] and set [SIMPLINK (HDMI-CEC)] to [On].
21
ENGLISH
Supported SIMPLINK Functions
• Instant Play
When you start a multimedia device, you can immediately watch content from
the device on the projector without having to control anything.
• Controlling devices with the projector remote control
Enables the user to control multimedia devices with the projector remote control
to watch content.
– The menu of the multimedia device can be operated with the arrow keys on
the remote control.
• Main Power Off
Turning off the projector will also turn off the devices connected through
SIMPLINK.
– This feature is only available in certain devices.
• Main Power On
Turning on a SIMPLINK device will also turn on the projector.
– Some models may not be supported.
22
ENGLISH
Connecting an Input Device to USB
Using a USB Wired/Wireless Mouse
Connect your mouse to the USB port. Use the mouse to move the pointer on the
projector screen and select the menu you want.
• The right button and the special buttons on the mouse do not work.
• When using a wireless USB mouse, the connection can be lost or slowed,
depending on the distance between the projector and mouse and the wireless
environment.
Using a USB Wired/Wireless Keyboard
Connect your keyboard to the USB port. You can enter text with the connected
keyboard device.
• It is not possible to enter text on some screens.
• It is recommended that you use a product that has been tested for compatibility
with LG projectors.
Logitech K360, Logitech K400, Logitech K750
• You can change the input language by pressing the language switch key or the
right Alt key. It can also be changed by pressing the Ctrl key and the Space key
at same time.
• When using a wireless USB keyboard, the connection can be lost or slowed,
depending on the distance between the projector and keyboard and the wireless
environment.
• To enter text in the text field, use the on-screen keyboard on your projector
screen or a USB keyboard.
23
ENGLISH
Using a Gamepad
Connect your gamepad to the USB port on the projector if the game requires a
gamepad.
• It is recommended that you use a gamepad that has been tested for
compatibility with LG projectors.
Sony DualShock 4, Sony DualShock 3, Microsoft Xbox 360 Controller, NVIDIA
SHIELD Controller, Logitech F310, Logitech F710
Connecting Bluetooth Input Devices
You can connect and use devices such as a Bluetooth-enabled keyboard, mouse, or a
gamepad with your projector.
For details, please refer to "[Connect Bluetooth Controller]" in "Managing External
Device Connections".
24
ENGLISH
APPS AND CONTENT
Installing Apps
You can install apps in a variety of categories such as games, education, and news and
conveniently use them on your projectors.
1 Press the button on the remote control.
2 Launch [Apps].
3 Select a category or press the Search button to search for an app.
4 Select an app to install.
5 Read the details of the app and then press [Install].
6 When the installation is complete, you can run the app immediately.
25
ENGLISH
2
3
1
4
1
Searches for content.
For details, please refer to "Search Content".
2
You can log in with your LG account and manage apps.
3
You can manage apps, such as updating or deleting installed apps.
4
Closes the app.
To turn off the app from running in the background, press the button
on the remote control and select [Quit App].
• In order to install apps, you must be logged in.
• Available categories may vary depending on the country or service status.
• If the storage on your projector is insufficient, you can install the apps by
connecting an external memory device.
• Some USB storage devices may not be supported or may not work properly.
• USB drivers containing apps from other LG TVs or LG Projectors may not be
used.
• Exercise caution when in use by children. Children may have access to
inappropriate online content through this product. You can block inappropriate
online content by restricting access to some apps.
– Congure the settings in (Q. Settings) → → [General] → [System]
→ [Safety] → [Application Locks].
26
ENGLISH
Content Recommendation
If you are watching the projector using a set-top box, you must complete the setup of
the universal remote control to use the recommendation feature normally.
For details, please refer to "Universal Remote Control".
1 Press the (Voice recognition) button on the Magic Lighting Remote. The
Content Recommendation screen appears.
• When using a standard remote control, press the button on it.
2 You can view more content by pressing the icon on the screen.
• Some models may not be supported.
• You must connect to the network to use the recommendation feature.
• The supported services vary depending on countries, so the recommendations
may be provided differently.
• The list of the recommendations may be less relevant or irrelevant, depending on
the information of the program you are watching.
27
ENGLISH
Search Content
Searches for content by title, actor/actress, and genre.
1 Press the button on the remote control.
2 Launch .
3 Search for a variety of content and information by typing in your desired
search terms.
1
3
4
2
1
Enter your desired search term.
2
Shows recent searches.
3
You can select one from the suggested keywords and proceed to search.
4
Provides a list of content for the selected genre.
• You must connect to the network to use the search feature.
• Search results may vary depending on the region, network settings, and whether
you have agreed to the terms and conditions.
28
ENGLISH
CONNECT OTHER DEVICES
Using [Home Dashboard]
You can select or control a device (mobile, external device, etc.) connected to the
projector.
• Run [Home Dashboard] by pressing the button on the remote control.
• You can also press and hold the button on the Magic Lighting Remote.
1
2
3
4
5
6
7 8
1
You can check and select the external device connected through the
external input port or network.
2
Connect your mobile device to projector to share the mobile screen and
enjoy the stored contents.
29
ENGLISH
3
Use AirPlay/HomeKit to control your projector and watch content from
your iPad or Mac on the projector screen.
• The availability of and access to Contents and Services in LGE Device
are subject to change at any time without prior notice.
4
It can only be selected if you have connected a USB storage device or a
media server.
5
The currently selected output speaker is displayed, and you can navigate to
the output speaker settings screen.
6
You can view the list of connected Bluetooth devices and select one.
7
[Edit Inputs]: You can edit the name of the connected device or apply the
related settings.
[Universal Control Settings]: Move to the [Universal Control Settings] app.
[Quit App]: Turns off the app from running in the background.
8
Closes the app.
• Available settings vary depending on the model or region.
30
ENGLISH
To see the Smart Device's screen on the projector
To see the Mobile Device's screen on the projector
1 Enable Screen Share mode on the mobile device.
2 Your projector will be displayed in the list of available devices.
3 Select your projector and request connection.
4 Select accept in the connection request popup window.
5 After the connection is established, the projector will display the screen of the
connected device.
• When you connect [Screen Share] for the first time, a popup will appear which
allows you to select [Accept], [Decline] or [Block].
– [Accept]: You can connect the device. No connection popup will appear from
the second time.
– [Decline]: Do not connect the device. If you try to connect again, the popup
will appear.
– [Block]: Do not connect the device. Even if you try to connect again, the
popup will not appear and the connection will not work.
– To turn off [Block], go to (Q. Settings) → → [General] → [Devices]
→ [External Devices] and select [Delete Connection History].
• For a reliable connection always keep the connected device to your projector
updated to the latest OS version.
• Depending on the model or manufacturer of the smart device, the Screen Share
feature may not be supported.
• Connect the device to a 5 GHz router because the performance may be affected
by your wireless environment.
• The response rate may vary, depending upon the user’s environment.
• It differs among devices. For more information on the device you want to
connect to, refer to its user guide.
• If connection fails repeatedly, turn off the projector and the device you want to
connect to, then turn them back on and try again.
31
ENGLISH
Playing Sound from a Smart Device through the
projector’s Speakers
Connect a smart device to the projector via Bluetooth to play sound from the smart
device through the projector’s speakers.
1 Turn the smart device’s Bluetooth on, then select the projector from the list
of devices.
2 The projector will be connected to the smart device.
• The projector may not be found in the list of smart devices while setting up a
Bluetooth speaker.
• If you connect a smart device to the projector via Bluetooth and listen to the
sound of the smart device through the projector speaker, the projector may not
be connected to any other smart device.
32
ENGLISH
Connecting USB
Connect a USB storage device (USB HDD, USB stick) to the USB port on the projector
to easily enjoy the content les stored on the USB storage device on your projector.
33
ENGLISH
Tips for Using a USB storage device
• A USB storage device that has a built-in automatic recognition program or uses
its own driver might not be recognizable.
• Some USB storage devices may not be supported or may not work properly.
• If you use a USB extension cable, the USB storage device may not be recognized
or may not work properly.
• Please use only USB storage devices formatted with the FAT32, exFAT or NTFS
file system provided by Windows OS.
• It is recommended that you use an external USB HDD with a rated voltage of
5 V or less and a rated current of 500 mA or less. If you use a device requiring
a higher voltage/current than the rated voltage/current, it may not operate
properly due to lack of current.
• For USB hubs and USB storage devices, it is recommended to use a type that
supplies power by connecting the AC adapter to a power outlet.
• It is recommended that you use a USB stick of 32 GB or less or a USB HDD of 2
TB or less.
• If a USB HDD with power-saving function does not work, turn the hard drive off
and on again to make it work properly. See the owner’s manual for the USB HDD
for more information.
• Data on a USB storage device may be damaged, so it is recommended that you
back up any important files. Users are responsible for data management. The
manufacturer bears no responsibility.
• Press the button on the remote control. To remove the USB storage device,
press the [Eject] button, which appears at the top when you focus on the USB
storage device you want to remove.
If you disconnect the USB storage device without selecting [Eject], an error may
occur in your projector or storage device.
• When you connect a USB storage device of a file system not supported by
the projector to the USB input port, the format message appears. To use the
connected USB storage device, you should format the device first. Formatting
deletes all data stored on the USB storage device, and the device is formatted
with the FAT32, exFAT or NTFS file system.
• Run [Home Dashboard] by pressing the button on the remote control.
Select the connected USB from [Home Dashboard] and select the [Format]
button to format the USB storage device.
• When connecting a USB storage device, a random file/folder can be created to
provide Smart projector services such as the saving and retrieving of thumbnail
images.
34
ENGLISH
Using the [Media Player]
You can search and view photos or play videos and songs with the [Media Player] app.
1 Press the button on the remote control.
2 Run the [Media Player] app.
3 Select a device to use from the device list.
4 Select the content to play.
1
2
3
4
5
35
ENGLISH
1
You can select a device connected to your projector.
2
Displayed only when music is playing.Press the to access the Play
Music screen.
3
Launch [Search].
4
[View Type]: Selects a content display mode.
[Sort]: Select the option to sort content.
[Group]: If you lter by [Music], you can group content into categories
such as [Artist] and [Album].
[Selection Play]: You can select and play multiple pieces of content.
[Delete]: You can select and delete multiple pieces of content.
[Quit App]: Turns off the app from running in the background.
5
Closes the app.
• You cannot delete files that are shared from other devices.
• Different settings items are available depending on the filtering or model you
selected.
• Certain content may not be displayed on the list if the number of all content
exceeds 40,000.
36
ENGLISH
Viewing Photos
You can select a photo from the [Media Player] app and view the photo.
You can use more features by pressing the down ( ) button on the remote control
while viewing a photo.
1 2 3
5
6 7 8
4
1
Shows the previous content.
2
Starts the slide show.
3
Shows the next content.
4
Rotates photos.
5
You can zoom the photos in/out.
6
360-degree photos can be viewed in 360 degrees.
• Using the 360° VR Play on a normal photo may distort the image.
• Some models may not be supported.
7
Plays a music le selected from the storage device as background music.
8
You can set the size of a photo or change the speed and effect of a slide
show.
• Some models may not be supported.
37
ENGLISH
Playing Videos
You can select a video from the [Media Player] app and play the video.
Pressing the left/right ( ) buttons on the remote control allows you to skip
backward/forward 10 seconds.
You can access more features by pressing the down ( ) button on the remote control
while playing a video.
1 2 3
4 5 6 7 8 9
10
38
ENGLISH
1
Shows the previous video.
2
Plays or pauses the video.
3
Shows the next video.
4
You can change subtitle settings.
5
Rotates videos.
6
Fast-rewinds the video at higher speeds.
7
You can do the settings related to play on repeat of the video.
8
Fast-forwards the video at higher speeds.
9
360-degree videos can be viewed in 360 degrees.
• Using the 360° VR Play on a normal video may distort the videos.
• Some models may not be supported.
10
[Resume Play]: You can set continue watching to resume playing from the
last viewed scene.
[Play Speed]: Sets the playback speed.
[Audio Track]: You can set audio tracks.
[Quit App]: Turns off the app from running in the background.
39
ENGLISH
Listening to Music
You can select a song from the [Media Player] app and play the song.
You can use more features by pressing the down ( ) button on the remote control
while playing a song.
1 2 3 4 5
1
You can set the random play mode.
2
You can set the repeat play mode.
3
Lyrics are available for music les that provide them.
In some music les, you can choose a lyric section and move the playback
position.
• The lyrics feature is only supported on some devices.
• The lyrics may not be displayed in sync depending on the lyrics data
in the music file.
4
You can listen to music with the screen turned off.
5
[Lyrics Sync]: You can set the lyric speed.
• This feature may not be supported depending on the music.
[Quit App]: Turns off the app from running in the background.
40
ENGLISH
View Computer Files
Watch content saved in your PC on the Projector
You can enjoy videos/music/photos stored on your PC on the Projector when these
devices are connected to the same network.
Browse the content on your PC to watch on Projector (Windows 10)
1 Connect you projector and PC to the same network.
2 Right-click the le you want to play and select “Cast to Device”.
3 Select the name of the Projector you want to watch from the displayed list,
and playback will start on that Projector.
• Even when multiple projectors or devices are connected, the selected file is
played through only one device. The playback rate may vary depending on the
network connection.
• To play on other operating systems or devices, refer to the manual of the
operating system/device.
41
ENGLISH
Browse and watch the content stored on the PC using the Projector (Windows 10)
1 Connect you projector and PC to the same network.
2 Open the “Start” menu on your PC screen, search for “media streaming
options” and then select the result that appears.
3 Select the “Turn on media streaming” button in the window that opens.
4 Allow all of the “media streaming options”.
5 Select “OK” to save the settings.
6 Select the connected PC in the [Home Dashboard] app on the Projector, and
then select and play the le you want.
• To play on other operating systems or devices, refer to the manual of the
operating system/device.
42
ENGLISH
Matters that require special attention during Content Share
• Check your network settings if the Content Share option does not work properly.
• May not work properly on a wireless network.
• May not work properly depending on the network environment.
• If multiple display devices are connected to one device, the content may not be
played properly depending on server performance.
• To watch the 1080p video through Content Share function, a router that uses
5 GHz frequency is required. If a 2.4 GHz router is used, the video may not play
properly.
• The Content Share function may not be supported for a router that does not
support multi-cast. For more information, refer to the user guide that came with
your router or contact the manufacturer.
• Captions are only supported on some connected devices.
• If you have added a caption file afterward, disable the shared folder on the PC
and then enable it again.
• The DRM files in the connected device will not play.
• Even for the file format supported by the projector, the supported file format
may differ depending on the connected device environment.
• If there are too many folders or files in a folder, it may not work properly
• The information on the file imported from the connected device may not be
displayed correctly.
• Depending upon the encoding, some streams may not play in Content Sharing
mode.
43
ENGLISH
To See the PC Screen on the Projector
To see the PC screen on the projector
Connect wireless
1 Enable Screen Share mode on the PC. Your projector will be displayed in the
list of available devices.
2 Select your projector and request connection.
3 After the connection is established, the projector will display the screen of the
connected device.
• For a reliable connection always keep the connected device to your projector
updated to the latest OS version.
• It is recommended that you use this function at close range.
• Start Screen Share faster by having your mobile device or PC connected to the
same network as the projector.
• Though it can be connected without a wireless router, connecting your device to
a 5 GHz router is recommended because the performance can be affected by
the surrounding wireless environment.
• The response rate may vary, depending upon the user’s environment.
• It’s different from Windows version. For more information on the device you
want to connect to, refer to its user guide.
• If connection fails repeatedly, turn off the projector and the device you want to
connect to, then turn them back on and try again.
44
ENGLISH
Connect wired
1 Connect the PC with projector by HDMI
®
cable.
2 In → [Home Dashboard], change the input to the terminal to which the
HDMI cable is connected.
3 After the connection is established, the projector will display the screen of the
connected PC.
• If there is a problem with your connection, refer to "Troubleshooting PC
Connection Issues".
45
ENGLISH
MAKING THE MOST OF SMART
PROJECTOR
Using the [Web Browser]
Using the [Web Browser]
You can enter the website when you input the web address on the URL bar.
If you input the search word, it will nd the information about search word base on the
search engine.
1 Press the button on the remote control.
2 Launch the [Web Browser] application.
1
2
3
4 5
6
1
You can refresh the web page you are viewing.
2
You can type in a web address to navigate to a specic website or enter a
search term directly.
3
You can view the tabs that are currently open.
46
ENGLISH
4
You can zoom in or out on the screen while browsing the website.
[Block Ads]: You can block ads within the web page you are viewing.
However, this button is displayed only when → [Settings] → [Use
Block Ads] is set to [On].
[Projector View]: Split the screen to display the projector screen. You can
browse web pages while watching projector.
[History]: You can view and delete the website visit history.
[Add to bookmarks]: You can add the website you are currently viewing to
your Favorites.
[Bookmarks]: You can view and delete the list of websites you have added
to your Favorites.
[Settings]: You can change the web browser settings.
[Quit App]: Turns off the app from running in the background.
5
Exit the [Web Browser].
6
The new tab screen shows a list of [Recommended Sites] and [Most Visited
Sites].
If you do not want to display [Recommended Sites], set the →
[Settings] → [Show Recommended Sites] function to [Off].
[Recommended Sites] may vary by country and is only available in certain
countries.
47
ENGLISH
• The [Web Browser] app on your projector is a browser for projector, so it may
work differently than the browser for your PC.
– Some of the content may not play properly.
– Flash Plug-in is not supported, and only HTML5 media is supported.
– Plug-in installation is not supported.
– Media in formats other than JPEG / PNG / GIF may not be played.
– Apps may be forced to shut down if the projector runs out of memory.
– The fonts provided on the projector are used. Depending on the content,
characters may look different from PC or mobile browsers.
– File and font downloads are not supported.
– Caution is required because malicious or phishing sites are not automatically
blocked.
– Some features may not be supported temporarily due to external factors of
the web browser.
• The website can be accessed through the projector's [Web Browser] app, so care
needs to be taken about children's access to harmful online contents.
You can lock the [Web Browser] app to prevent access to harmful online
contents.
Configure the settings in (Q. Settings) → → [General] → [System] →
[Safety] → [Application Locks].
• If you experience problems while using Web Browser, refer to Troubleshooting.
48
ENGLISH
Changing Web Browser Settings
Select → [Settings] at the top of the [Web Browser] app.
• [On Startup]
You can choose the page that appears when you start the [Web Browser] app.
• [Search Engines]
You can select a search engine to search for when entering a keyword in the
address bar.
– Search engine settings may be subject to change without notice based on the
supplier’s circumstances.
• [Show Recommended Sites]
You can set whether or not to display a list of [Recommended Sites] on the new
tab screen.
• [Always Show Address Bar]
When set to [On], the address bar and menu bar area at the top will always be
displayed.
• [Private Browsing]
If set to [On], a history of website visits will not be stored.
• [Site Filtering]
You can register websites to block or allow.
[Approved Sites]: You can configure the settings to open the previously
registered web pages only.
[Blocked Sites]: You can configure the settings to block specific websites.
– To use the [Site Filtering] function, you should enter the projector password.
• [Pop-up Blocker]
Blocks pop-ups that are automatically displayed by web pages.
• [Do Not Track]
You can request to not leave a history of your visit on the website. The operation
may vary depending on the policy of the website.
• [Adaptive Streaming using JavaScript]
The media streaming technology using JavaScript allows you to view video with
optimized resolution.
If this is set to [Off], the resolution of the videos played in [Web Browser] is
limited to 720p.
49
ENGLISH
• [Cookies Settings]
Enables the website to store and use cookie data.
• [Use Block Ads]
When set to [On], a button to turn [Use Block Ads] on or off appears when
clicking the icon at the top of [Web Browser]. Turning on the [Use Block Ads]
feature speeds up page loading by blocking ads included in the website.
• [Automatic Web Browser Issue Report]
When it is set to [On], if a failure (malfunction, media playback failure, page
loading failure, abnormal shutdown, delay in response due to insufficient
memory, etc.) occurs while using the web browser, the relevant information
will be automatically sent to the web browser development team at the LG
Electronics headquarters (Korea). The submitted information will only be used to
improve the Web Browser performance.
• [Clear Browsing Data]
[Clear Cookies]: Deletes cookie data. When deleted, you are logged out of most
sites.
[Clear All Browsing Data]: Deletes all browsing history, including cookies.
50
ENGLISH
Connecting a Camera to the Projector
By connecting a camera to the projector, you can use it for video conferencing, etc.
1 Connect the camera to the USB IN port.
2 Run [Home Dashboard] by pressing the button on the remote control.
3 Select [Camera].
• For detailed description of the camera's functions, refer to the device's manual.
• The camera must be purchased separately.
It is recommended that you use a product that has been tested for compatibility
with LG Projectors.
Logitech C920/C920s/C922 Pro/C922x/C925e/C930c/C930e
• Depending on the installation status of the projector, the camera may not be
mounted on the projector.
• USB storage device may not work or function properly when a USB hub or
extension cable is used.
• This function may not be available in some countries or models.
Video Conferencing
You can have a video conference using an internet website or an app that enables video
conferences.
• This function may not be available in some countries or models.
• Internet connection is required to use this feature.
• Depending on camera performance or the network environment, the image
quality may not be clear.
51
ENGLISH
SETTINGS
The congurable items differ depending upon model.
Quick Settings
Quick Settings
Displays a set of light-weight controls quickly and simply such as [Picture Mode],
[Sound Out], [Game Optimizer] and so on.
Press the (Q. Settings) button on the remote control.
1
2
3
4
5
6
7
8
52
ENGLISH
1
You can set the [Picture Mode].
2
You can choose the [Sound Out].
3
Move to the [Game Optimizer] screen.
4
You can set the [Sleep Timer].
5
Move to the [Network] screen.
6
Move to the [Installation Wizard] screen.
7
You can set more options.
• You can also long-press (Q. Settings) button of the remote
control to run the All settings directly.
8
You can add/delete the quick setting items or change their order.
• Move to an item that can be set up, press the remote control's Wheel (OK)
button once, and then press and hold the Wheel (OK) button to move to the
menu.
• The configurable items differ depending upon model.
53
ENGLISH
[Picture]
Selecting Picture Mode
(Q. Settings) → → [Picture] → [Select Mode]
Select the picture mode that is best suited to your viewing environment, preferences
or video type.
Select a picture mode. By adjusting and setting each item in more detail based on the
mode, your video is better optimized for its characteristics.
• The configurable items differ depending upon model.
• Depending upon the input signal, the available picture modes may be different.
• When watching online service content, the Picture Mode may be changed to
match the content being shown.
54
ENGLISH
When You Use Normal Signals
• [Vivid]
Sharpens the image by increasing the contrast, brightness and sharpness.
• [Standard]
Displays the picture with normal contrast, brightness, and sharpness levels.
• [Cinema]
Optimizes the screen for movies.
• [Sports]
Optimizes the screen for sports games. Sharpens the image of rapid movements
such as kicking or throwing a ball.
• [Game Optimizer]
Optimizes the screen for gameplay.
• [FILMMAKER MODE]
Provides optimized Cinema Picture quality certified by UHD Alliance, the
standard setting body for UHD-related technologies.
– To auto-switch to [FILMMAKER MODE] when a signal that can be operated
with this mode is entered, set [FILMMAKER MODE Auto Start] to [On].
• [Brightest]
It displays the maximum screen brightness under appropriate image conditions.
• [Expert (Bright space, daytime)]/[Expert (Dark space, night)]
This mode is suitable for movies, etc. viewed in a dark environment.
[Expert (Dark space, night)] has lower color temperature than [Expert (Bright
space, daytime)]. Select a mode that is suitable for the movie you are watching.
55
ENGLISH
When You Use the HDR
• [Vivid]
Sharpens the image by increasing the contrast, brightness and sharpness.
• [Standard]
In a normal viewing environment, it opens a screen that can properly show the
expressiveness and brightness of HDR.
• [Cinema Home]
The screen appears brighter and clearer than that of the [Cinema] screen.
• [Cinema]
Suitable picture for HDR video signal.
• [Game Optimizer]
Optimizes the screen for gameplay.
• [FILMMAKER MODE]
Provides optimized Cinema Picture quality certified by UHD Alliance, the
standard setting body for UHD-related technologies.
– To auto-switch to [FILMMAKER MODE] when a signal that can be operated
with this mode is entered, set [FILMMAKER MODE Auto Start] to [On].
• [Brightest]
It displays the maximum screen brightness under appropriate image conditions.
• If an HDR video signal is input to the models that do not support the HDR
technology, normal signal picture mode options will be made available.
• Depending upon the input signal, the available picture modes may be different.
• When watching online service content, the Picture Mode may be changed to
match the content being shown.
• [Select Mode] changes may modify [Energy Saving] settings and it can affect
energy consumption. You can change the settings in [General] → [Energy
Saving].
56
ENGLISH
Setting the Screen Size
(Q. Settings) → → [Picture] → [Aspect Ratio] → [User Selection]
You can change the screen size according to the type of content you are watching.
• [16:9]
Displays an aspect ratio of 16:9.
• [Original]
The optimal screen ratio changes depending on the input image signal.
• [4:3]
Displays an aspect ratio of 4:3.
• [Vertical Zoom]
You can adjust the vertical dimension of the screen and align the screen
vertically by using [Adjust Zoom Ratio] and [Adjust Screen Position].
• [4-Way Zoom]
You can adjust the horizontal/vertical/diagonal dimensions of the screen and
align the screen horizontally/vertically by using [Adjust Zoom Ratio] and [Adjust
Screen Position].
• The configurable items differ depending upon model.
• The picture may get distorted while zooming in or out.
• Selecting a different screen size from the original size may cause the image to
look different.
• Depending on the combination of picture format and screen size, the edges may
be hidden or shown in black, or both sides of the picture may flicker.
• Depending upon the input signal, the available screen sizes may be different.
View Screen with [Just Scan]
(Q. Settings) → → [Picture] → [Aspect Ratio] → [Just Scan]
If you turn this feature [On], you can view the content in the aspect ratio that is in
content source. If the edge of the screen is not clean, please turn it [Off].
If set to [Auto], the feature switches between [On] or [Off] status depending on the
information contained in the video signal.
• The items that can be selected may vary depending on the current input.
57
ENGLISH
Adjusting the Brightness of a Picture
(Q. Settings) → → [Picture] → [Advanced Settings] → [Brightness]
You can adjust the brightness of the entire screen.
• [Adjust Contrast]
Adjusts the contrast of the bright and dark areas of the picture. The closer to
100, the higher the contrast.
• [Black Level]
Adjusts the brightness of dark areas of the screen. The closer it is to 100, the
lighter the screen becomes.
• [Auto Dynamic Contrast]
Corrects the difference between the bright and dark areas of the screen for
optimal results depending on the brightness of the picture.
• [Gamma(Adjust Brightness)]
Adjusts the medium brightness of the picture.
You can be selected from [1.9]/[2.2]/[2.4]/[BT.1886].
– [BT.1886] expresses the gradation in ITU-R BT.1886, which is an international
standard.
• [Video Range]
Adjusts the darkness of the screen in order to display a perfect black. Select
[Video Range] to match the color range of the external input device.
– This feature can be used while watching content through an external input.
• Depending upon the input signal or the selected picture mode, the available
options may differ.
• The configurable items differ depending upon model.
58
ENGLISH
Adjusting the Color of an Picture
(Q. Settings) → → [Picture] → [Advanced Settings] → [Color]
• [Color Depth]
Tones down or up the Colors displayed on the screen. The closer to 100, the
deeper the Color.
• [Tint]
Adjusts the Color balance between red and green displayed on the screen. The
closer to Red 50, the more red the Color will be. The closer to Green 50, the
more green the Color will be.
• [Color Gamut]
Selects the range of Colors to display. Set color gamut to [Auto Detect]
according to the signal, or to [Native] to display more vivid and richer color.
• [Fine Tune]
This is used when experts control it by using a test pattern. You can control it by
selecting areas of six colors ([Red]/[Green]/[Blue]/[Cyan]/[Magenta]/[Yellow]).
For normal images, adjustments may not result in noticeable Color changes.
– [Color Adjustment]: Adjusts the Color and saturation of the picture to make
the image more Colorful and lively.
– [Select Color]: From [Red]/[Green]/[Blue]/[Cyan]/[Magenta]/[Yellow], select
a tone to adjust.
– [Adjust Saturation]/[Adjust Tint]/[Adjust Luminance]: Adjust the chroma/tint/
luminance of the tone in the range of -30 to +30.
59
ENGLISH
• [White Balance]
The function to adjust each color to be reproduced more accurately based
on white allows you to adjust the overall color tone of the screen to your
preference.
– [Method]: This method is used for ne-tuning the color temperature setting.
You can control the color temperature at two points of the bright part and
dark part of the video if you select [2 Points], at each point of 10 levels if you
select [10 Points Signal Level(%)], and at each point of 22 levels of the video
if you select [22Points Signal Level(%)].
– [Point]: Select screen brightness for color temperature adjustment.
If [Method] is set to [2 Points]; use Low to select shadows and High to select
highlights.
When the [Method] is set to [10 Points Signal Level(%)], you can select the
brightness with the 10 levels of brightness.
When the [Method] is set to [22Points Signal Level(%)], you can select the
brightness with the 22 levels of brightness.
– [Signal Level(%)]: Select screen brightness for color temperature adjustment.
When the [Method] is set to [10 Points Signal Level(%)], you can select the
brightness with the 10 levels of brightness.
When the [Method] is set to [22Points Signal Level(%)], you can select the
brightness with the 22 levels of brightness.
– [Show brightness level at the maximum signal level(%)]: Adjust the luminance
to the highest 100 point signal level (%).
– [Adjust brightness level at the selected signal level(%)]: You can adjust the
selected brightness by points.
You can use these settings only when the [Picture] → [Select Mode] is set
to [Cinema], [Expert (Bright space, daytime)], or [Expert (Dark space, night)]
and when the [Method] is set to [10 Points Signal Level(%)] or [22Points
Signal Level(%)].
– [Red]/[Green]/[Blue]: Adjust the color temperature of the selected point.
Adjust the intensity of [Red]/[Green]/[Blue] in the range of -50 to 50.
You can adjust respective values for the brightness selected in [Point].
• [Color Temperature]
Adjusts the Color temperature cool/medium/warm.
• Depending upon the input signal or the selected picture mode, the available
options may differ.
• The configurable items differ depending upon model.
60
ENGLISH
Adjusting the Contrast of a Picture
(Q. Settings) → → [Picture] → [Advanced Settings] → [Clarity]
You can adjust the contrast of a Picture to show it more clearly.
• [Adjust Sharpness]
Adjusts the sharpness of the image. The closer to 50, the sharper and clearer
the image.
• [Super Resolution]
Adjusts the resolution to make dim and blurred images clearer.
• [Noise Reduction]
Removes small dots that stand out so as to make the image clean.
• [MPEG Noise Reduction]
Reduces the noise produced during the creation of digital video signals.
• [Smooth Gradation]
It reduces the phenomenon that the outline of the image is rugged and in a
staircase pattern and displays a smoother screen.
• [Real Cinema]
Optimize display for movies.
• [TruMotion]
This feature is available on certain models only.
Optimizes the image quality of fast-moving pictures.
– [Off]: Turns off the [TruMotion].
– [Cinematic Movement]: Adjusts the shaking of the motion on the screen to
make it feel like you are in a movie theater.
– [Natural]: Sets images with a lot of motions to look natural and clear.
– [Smooth Movement]: Softens fast-moving pictures.
– [User Selection]: Sets [TruMotion] manually.
• [De-Judder]: Adjusts juddering on the screen.
• The advanced settings can be changed only in [User Selection] mode.
• Depending upon the input signal or the selected picture mode, the available
options may differ.
• The configurable items differ depending upon model.
61
ENGLISH
Applying the Current Picture Settings to All Inputs
(Q. Settings) → → [Picture] → [Advanced Settings] → [Apply to All Inputs]
The settings you specify only applies to the currently selected input mode. To apply
your current picture settings to all input modes, select [Apply to All Inputs].
Resetting Picture Mode
(Q. Settings) → → [Picture] → [Advanced Settings] → [Reset]
If you want to reset the image settings to the factory defaults after conguring the
image settings, select reset for each image mode.
[FILMMAKER MODE Auto Start]
(Q. Settings) → → [Picture] → [Advanced Settings] → [FILMMAKER MODE
Auto Start]
If set to [On], [Picture Mode] will automatically be changed to [FILMMAKER MODE]
when a signal that can be operated with [FILMMAKER MODE] is entered.
• While this mode effectively conveys the creator's intention, it may appear darker
than other [Picture Mode].
62
ENGLISH
[Sound]
Selecting Sound Mode
(Q. Settings) → → [Sound] → [Select Mode]
You can select the most suitable sound mode for each genre.
• [AI Sound]/[AI Sound Pro]
Automatically optimize sound based on content type.
• [Standard]
Optimizes the sound for all types of content.
• [Cinema]
Optimizes the sound for cinemas.
• [Clear Voice]/[Clear Voice Pro]
Boosts voice clarity.
• [Sports]
Optimizes the sound for sports.
• [Music]
Optimizes the sound for music.
• [Game Optimizer]
Optimizes the sound for gameplay.
• This setting only applies to the internal speakers of the Projector or HDMI (ARC)
connected devices that support [Sound Mode Share].
• The configurable items differ depending upon model.
[Use Projector Speaker]
(Q. Settings) → → [Sound] → [Sound Out] → [Use Projector Speaker]
Audio is played through the projector’s internal speakers.
63
ENGLISH
[Use Wired Speaker]
(Q. Settings) → → [Sound] → [Sound Out] → [Use Wired Speaker]
[HDMI(ARC) Device]
Sound from the projector can be output through an external audio device connected via
a HDMI (ARC) port.
• Select [HDMI(ARC) Device] to automatically turn on SIMPLINK. Once SIMPLINK
is turned off, the output speaker settings automatically revert to the default
settings for uninterrupted audio output.
• The configurable items differ depending upon model.
64
ENGLISH
[Use Wireless Speaker]
(Q. Settings) → → [Sound] → [Sound Out] → [Use Wireless Speaker]
[Bluetooth Device]
You can connect wirelessly a Bluetooth audio device or a Bluetooth headset to enjoy
your projector’s sound in richer quality and greater convenience.
Refer to the user manual of the Bluetooth audio device for details on how to connect
and use the device.
• Press to view the connected devices or any devices that can be connected
and connect to any one of them.
• For some Bluetooth devices, the device volume can be controlled by selecting
from the connection list.
• LG Sound Sync devices will automatically try to connect to the recently used
devices when you turn the projector on.
• We recommend that you connect an LG audio device that supports LG Sound
Sync, using LG TV mode or LG Sound Sync mode on device.
• Some models may not be supported.
• The audio codec that can be output via Bluetooth is SBC/aptX™.
• If the device fails to connect, check the power of the device to connect to and
check if the audio device is working properly.
• Using a Bluetooth headset is recommended when you connect two Bluetooth
devices.
• Depending on the type of the Bluetooth device, the device may not connect
correctly or an abnormal behavior may occur such as unsynchronized video and
audio.
– The mobile-only headsets may not work.
– If two different Bluetooth devices are connected and used at the same time,
the voice may not match.
• Sound may stutter or sound quality may be reduced if:
– the Bluetooth device is too far from the projector;
– there are obstacles between the Bluetooth device and the projector; or
– used together with radio equipment such as a microwave oven or wireless
LAN.
• If [Picture] → [Select Mode] is [Game Optimizer] and [Sound Out] is set to
[Bluetooth Device], [Picture] → [Select Mode] is changed to [Standard].
• If you continue to experience problems, we recommend using a wired connection.
(HDMI (ARC) port)
65
ENGLISH
[Use External Speakers with Projector Speaker]
(Q. Settings) → → [Sound] → [Sound Out] → [Use External Speakers with
Projector Speaker]
Audio can be played through multiple devices simultaneously.
[Bluetooth Device + Projector Speaker]
Both the internal speaker of the projector and the Bluetooth speaker can be used to
output the sound at the same time or a surround sound can be used.
Up to two Bluetooth devices of the same model can be connected.
1 Select to connect a Bluetooth speaker.
2 Run [Audio Delay] to synchronize the projector's internal speaker with the
Bluetooth speaker. You can adjust the sync automatically or manually.
• When you set [Sound Out] as [Bluetooth Device + Projector Speaker], if
[Picture] → [Select Mode] is [Game Optimizer], it will be changed to [Standard].
• The image and voice may be out of sync while using the Screen Share mode. We
recommend using [Use Projector Speaker] in [Sound Out].
• To adjust the volume with the volume button on your Bluetooth device, set
(Q. Settings) → → [General] → [Accessibility] → [Enjoy Projector Sound
Together] to [On]. For Bluetooth devices that do not have volume buttons, you
can adjust the volume of the device in the detailed settings screen of [Bluetooth
Device + Projector Speaker].
• If (Q. Settings) → → [General] → [Accessibility] → [Enjoy Projector
Sound Together] is set to [On], only one Bluetooth device can be connected.
• Depending on the type of your Bluetooth device, two devices may not be
connected at the same time.
• Depending on the type of the Bluetooth device, the device may not connect
correctly or an abnormal behavior may occur such as unsynchronized video and
audio.
• Some models may not be supported.
66
ENGLISH
[Equalizer]
(Q. Settings) → → [Sound] → [Advanced Settings] → [Equalizer]
You can adjust the sound by increasing or decreasing the output of the specic
frequency range of the voice signal.
• The option can be enabled if [Sound] → [Select Mode] is set to [Standard].
• This setting only applies to the internal speakers of the Projector or HDMI (ARC)
connected devices that support [Sound Mode Share].
Applying the Current Sound Settings to All Inputs
(Q. Settings) → → [Sound] → [Advanced Settings] → [Apply to All Inputs]
The settings you specify only applies to the currently selected input mode. To apply
your current sound settings to all input modes, select [Apply to All Inputs].
Initializing Sound Settings
(Q. Settings) → → [Sound] → [Advanced Settings] → [Reset]
Changes the detailed sound settings of the [Standard] mode to default.
This setting only applies to the internal speakers of the Projector or HDMI (ARC)
connected devices that support [Sound Mode Share].
67
ENGLISH
[Automatic Volume Adjustment]
(Q. Settings) → → [Sound] → [Advanced Settings] → [Automatic Volume
Adjustment]
If it is set to [On], the volume will be automatically adjusted to a suitable level for each
content you watch to help you enjoy watching more comfortably.
• This setting only applies to the internal speakers of the Projector or HDMI (ARC)
connected devices that support [Sound Mode Share].
Adjusting AV Synchronization
(Q. Settings) → → [Sound] → [Advanced Settings] → [Match Screen and
Sound]
Adjusts the synchronization of the sound from the speaker that is working.
The closer the value is set to 60, the slower the voice output speed will be than the
default speed.
If you select the [Bypass], Outputs the sound from external devices without any audio
delay. The audio may be output before the video because of the time the projector
takes to process the video input.
• The adjustable items vary depending on [Sound Out].
[Select HDMI Input Audio Format]
(Q. Settings) → → [Sound] → [Advanced Settings] → [Select HDMI Input
Audio Format]
You can set the audio format for each HDMI input. When the voice delivered through
the HDMI port is not synchronized, set it to [PCM].
68
ENGLISH
[Sound Mode Share]
(Q. Settings) → → [Sound] → [Advanced Settings] → [Sound Mode Share]
Plays the sound mode applied to the projector speakers on the soundbar, or selects the
sound mode of the soundbar on the projector to play.
• [Off]
Turns off the [Sound Mode Share].
• [Enjoy Projector Sound Mode]
The [Sound] → [Select Mode] set on the projector is applied to the soundbar to
deliver a variety of sounds.
• [Enjoy Soundbar Sound Mode]
You can set the sound mode of the soundbar in [Sound] → [Select Mode] on
the projector.
– The name of the sound mode displayed on the soundbar may differ from that
of the [Sound] → [Select Mode] on the projector, depending on the model. In
this case, it will be matched with the sound mode with similar effects.
69
ENGLISH
[Digital Sound Output]
(Q. Settings) → → [Sound] → [Advanced Settings] → [Digital Sound Output]
You can congure the [Digital Sound Output] settings.
• You can set when (Q. Settings) → → [Sound] → [Sound Out] → [Use
Wired Speaker] is set to [HDMI(ARC) Device].
• When [Pass Through] is enabled, sound effects may not be output.
• The codec output with a device may differ from input signals.
Sound Input Digital Sound Output
[PCM]
All PCM
[Auto]
/ [Pass
Through]
MPEG PCM
Dolby Digital Dolby Digital
Dolby Digital Plus /
Atmos
(HDMI ARC) Dolby Digital Plus / Atmos
Dolby TrueHD (HDMI
only)
(HDMI ARC) Dolby Digital Plus / Atmos
HE-AAC / AAC
(HDMI ARC) Dolby Digital / Dolby Digital
Plus
• Dolby TrueHD, Dolby Atmos: Some models may not be supported.
• Depending on the connected device and the type of input audio, it may output as
Dolby MAT PCM (Dolby Metadata-Enhanced Audio Transmission PCM).
• When [Digital Sound Output] is set to [Pass Through] and the HDMI input is
Dolby TrueHD, Multi-Channel PCM, audio can be output as bypass.
70
ENGLISH
[General]
[AI Service]
(Q. Settings) → → [General] → [AI Service]
• [AI Sound]
When set to [On], the image quality is automatically optimized for content
characteristics based on the algorithms learned with deep learning techniques.
– This setting only applies to the internal speakers of the Projector or HDMI
(ARC) connected devices that support [Sound Mode Share].
• [Voice Recognition Help]
It shows a list of voice commands the projector can perform.
• [Voice Recognition Settings]
You can apply settings for voice recognition features.
• [AI Recommendation]
You can get content recommendation messages according to your content
viewing history and app usage history.
– [Alarm]
[Smart Tips]: You can get an introduction to smart features you can use
when watching projector or using an app.
[Next Picks]: You can get recommendations based on your projector viewing
patterns.
• This feature may not be available in some countries.
– [Usage Data Management]
[Reset Usage Data]: It resets the content view history and the app usage
history. If you reset them, it takes some time to receive recommendations for
contents again.
• The configurable items differ depending upon model.
71
ENGLISH
[Game Optimizer]
(Q. Settings) → → [General] → [Game Optimizer]
Sets up the features for an immersive experience when you play with a video game
console.
1 Press the (Q. Settings) button on the remote control.
2 Select on the screen.
3 Selecting [On] turns on all related settings.
• It only works with HDMI inputs.
• If you set (Q. Settings) → → [Picture] → [Select Mode] to a mode
other than [Game Optimizer], some items in [Game Optimizer] cannot be set.
• If you turn this feature [On], you cannot change some video settings items.
• When [Game Optimizer] is set to [On], audio delay may occur if [Sound Out] is
set to [Bluetooth Device]/[HDMI(ARC) Device].
• Switch to [Use Projector Speaker] or change (Q. Settings) → →
[Sound] → [Advanced Settings] → [Select HDMI Input Audio Format] to [PCM].
• The configurable items differ depending upon model.
72
ENGLISH
[Usage Limits Setting]
(Q. Settings) → → [General] → [Family Settings] → [Usage Limits Setting]
You can use the projector in the set time period only. Outside of the set time period,
you must enter your password to use the projector.
1 Set [Enable the function] to [On].
2 Set [Start Time] and [End Time].
Selecting [Repeat] will activate this feature every day.
3 Select [Set]
[Volume Limit Mode]
(Q. Settings) → → [General] → [Family Settings] → [Volume Limit Mode]
Set [Enable the function] to [On]. The volume cannot be raised above a certain level for
the protection of your hearing.
• [Volume Limit Mode] may not work for audio devices connected to the HDMI
(ARC)/headphone port.
[Screen Time Reports]
(Q. Settings) → → [General] → [Family Settings] → [Screen Time Reports]
You can check your projector usage time.
73
ENGLISH
Setting Projector
(Q. Settings) → → [General] → [Devices] → [Projector Management]
• [Home/Store Mode]
You can choose between [Home Mode] and [Store Mode].
To use the projector at home, select [Home Mode].
Select [Store Mode] only when the projector will be displayed in store. The [Store
Mode] provide settings optimized for store display.
• [Projector Information]
You can check information such as [Model], [Serial Number] and [Device Name].
74
ENGLISH
Managing External Device Connections
(Q. Settings) → → [General] → [Devices] → [Settings]
You can set to use a smart device connected to the projector to control the projector
or manage the connection history.
The congurable items differ depending upon model.
• [Connect Bluetooth Controller]
You can connect and use devices such as a Bluetooth-enabled keyboard, mouse,
or a gamepad with your projector.
Turn on the device, set it to pairing mode, and then click [Connect] on your
projector screen. When a device you've connected before is turned on, it
automatically connects to your projector. To disconnect the existing connection,
click [Disconnect].
– It is recommended that you use a product that has been tested for
compatibility with LG projectors.
Bluetooth Mouse: Logitech M535, Logitech MX Master 2S, Apple Magic
Mouse2
Bluetooth Keyboard: Logitech K480, Arteck HB030B, Arteck HB192, Apple
Magic Keyboard
Bluetooth Gamepad: Sony Dualshock4, Microsoft Xbox One S Controller,
Microsoft Xbox Series X Controller, NVIDIA SHIELD Controller
– This feature is available for Bluetooth-enabled models only.
– Connecting multiple Bluetooth devices may result in poor connection or
operation.
– If the Bluetooth device is too far from the projector, or there are obstacles
between them, they may not operate normally.
– Depending on the peripherals (wireless router, microwave oven, etc.),
communication failures may occur.
– If the device you selected from [Registered Devices] does not reconnect,
[Disconnect] and then reconnect the device.
– It differs among devices. When trying to connect to a device, refer to the
device's User's Guide for more information.
75
ENGLISH
• [Camera]
You can set access permissions to the camera for each app.
• [Universal Control Settings]
If you set up the universal remote control, you can control peripheral devices
connected to the projector with the Magic Remote instead of their own remote
controls.
For details, please refer to "Universal Remote Control".
• [Projector On With Mobile]
If [Turn on via Wi-Fi] or [Turn on via Bluetooth] is set to [On], you can turn on
your projector using an application that supports [Projector On With Mobile] or
see the screen of the application on your projector.
– The projector should be connected to a network.
– The projector and the device to be used should be connected to the same
network.
– The [Turn on via Wi-Fi] feature must be used in an app on a smart device that
supports the feature.
– The [Turn on via Bluetooth] feature can only be used with certain LG
Electronics smartphones.
– The projector must be plugged in.
– To connect for the rst time, make sure the device to be used is ready to
connect.
– Some models may not be supported.
• [Delete Connection History]
You can delete the connection history of the devices connected to the projector
on the wireless network.
76
ENGLISH
Setting HDMI External Input
(Q. Settings) → → [General] → [Devices] → [HDMI Settings]
You can apply settings to ensure a clear picture and easy control for the HDMI
connected devices.
[HDMI Deep Color]
If you connect a device that supports the [HDMI Deep Color] feature, you can view a
clearer image. Connect a playback device and set [HDMI Deep Color] to [4K].
If the device doesn’t support it, it may not work properly.
In that case, change the [HDMI Deep Color] setting to [Off].
• Supported Display Resolution
– 4K: Supports 4K@120Hz (4:4:4, 4:2:2, 4:2:0) (120Hz models only),
4K@60Hz (4:4:4, 4:2:2, and 4:2:0)
– Off: Supports 4K@60 Hz (4:2:0)
• 4K@50/60Hz Supported Format (60Hz models only)
Resolution
Frame rate
(Hz)
Color Depth/Chroma Sampling
8 bit 10 bit 12 bit
3840 × 2160p
4096 × 2160p
50
59.94
60
YCbCr 4:2:0
YCbCr 4:2:0
1)
YCbCr 4:2:2
1)
YCbCr 4:4:4
1)
- -
RGB 4:4:4
1)
- -
1) Supported when [HDMI Deep Color] is set to [4K].
77
ENGLISH
• 4K@100/120Hz Supported Format (120Hz models only)
Resolution
Frame rate
(Hz)
Color Depth/Chroma Sampling
8 bit 10 bit 12 bit
3840 × 2160p
4096 × 2160p
50
59.94
60
YCbCr 4:2:0
YCbCr 4:2:0
1)
YCbCr 4:2:2
1)
YCbCr 4:4:4
1)
YCbCr 4:4:4
1)2)
RGB 4:4:4
1)
RGB 4:4:4
1)2)
100
1)2)
120
YCbCr 4:2:0
YCbCr 4:2:2
RGB 4:4:4
1) Supported when [HDMI Deep Color] is set to [4K].
2) This feature is available for HDMI (4K@120 H) Input terminals only.
• Settings are changeable only for the HDMI input currently being used.
• You can specify a different setting for each HDMI port.
• Some models may not be supported.
[SIMPLINK (HDMI-CEC)]
You can conveniently control and use various multimedia devices connected through
HDMI with the projector’s remote control.
For details, please refer to "Using SIMPLINK".
78
ENGLISH
Setting a Wireless Network
(Q. Settings) → → [General] → [Network] → [Wi-Fi Connection]
If you have set up the projector for a wireless network, you can check and connect to
the available wireless Internet networks. Select the wireless router to connect.
For more detailed settings, select [Other Network].
• [Add a Hidden Wireless Network]
If you input the name of network directly, you can add a wireless network.
• [Connect via WPS PBC]
If the wireless router you want to connect to has a Wi-Fi Protected Setup-Push
Button Configuration (WPS-PBC, a button to set up a secure Wi-Fi connection)
feature, you can easily connect to the wireless router by pressing the WPS-PBC
button on the router. Press the wireless router’s WPS-PBC button and then
press the projector’s [Connect] button.
• [Connect via WPS PIN]
This is a method to connect to an access point using a Wi-Fi Protected Setup-
Personal Identification Number (WPS-PIN). Select the access point (AP) to
which you would like to connect. Enter the PIN displayed on the access point’s
Wi-Fi device.
• [Advanced Wi-Fi Settings]
Once you connect to a wireless network you can view connection information
such as detailed IP address information. In addition, you can change the IP
address and DNS server address you want to connect to by pressing the [Edit]
button.
– The IPv6 setup does not support [Edit].
79
ENGLISH
Configuring Language Settings
(Q. Settings) → → [General] → [System] → [Language]
You can choose the menu language displayed on the screen.
• [Menu Language]
You can select one of the menu languages to be displayed on the screen.
The language for the speech recognition will be automatically set to selected
language for the menu.
– The speech recognition is only applied to some models.
• [Keyboard Languages]
Select the language to use the on-screen keyboard.
Setting the Location
(Q. Settings) → → [General] → [System] → [Location]
You can change the location setting of your projector.
The congurable items differ depending upon model.
• [Broadcast Country]
Select the broadcasting country.
• [Address Setting]/[Zip Code]
You can set the detailed location.
– It is subject to change depending on the broadcast country settings.
• [LG Services Country]
Select the country where you want to access LG’s services. Services may vary
depending on location.
– You must set the country manually when you are not connected to the
network.
80
ENGLISH
Setting the Time
(Q. Settings) → → [General] → [System] → [Time & Timer]
You can check the time or congure related settings.
The congurable items differ depending upon model.
• [Set Automatically]
It automatically sets the projector time.
• [Time]/[Date]/[Time Zone]
You can manually set the date and time, etc.
• [Custom Time Zone]
When [Time Zone] is set to [Custom], [Custom Time Zone] is enabled.
• [Timers]
– [Sleep Timer]
Sets the projector to turn off at a specied time.
If you want to disable [Sleep Timer], select [Off].
– [Power On Timer]
Set [Power On Timer] to [On].
The projector turns on at the set time.
• [Time]: Set the power-on time.
• [Timer Repeat]: Set the day of the week. Set the option to [None] to
operate the feature only once.
• [Input]: Set an external input to display when the power is turned on.
• [Volume]: Set audio volume to use when the power is turned on.
– [Power Off Timer]
Set [Power Off Timer] to [On].
The projector is turned off at the set time.
• [Time]: Set the time at which to turn the projector off.
• [Timer Repeat]: Set the day of the week. Set the option to [None] to
operate the feature only once.
– [Auto Off]
If there is no input signal or button press, the projector automatically turns
off after the preset time has elapsed.
• To use [Power On Timer]/[Power Off Timer], set the time correctly.
81
ENGLISH
Setting [Safety]
(Q. Settings) → → [General] → [System] → [Safety]
To set [Safety], set it to [On].
• [Application Locks]
You can lock or unlock the application.
– The lock function is not immediately available for the currently running
application.
• [Input Locks]
You can lock or unlock the Input Locks.
• [Reset Password]
Set or change the password for the projector.
– The initial password is set as “0000”.
When France or Norway is selected for Country, the password is not “0000”
but “1234”.
Resetting a Lost Password
If you lose the password you set, you can reset it as follows:
1 Select (Q. Settings) → → [General] → [System] → [Safety].
2 Press → → → on the remote control. The
master password input window will appear.
3 Enter the numbers “0313” in the master password input window, then press
[Enter]. The password will be reset.
82
ENGLISH
Managing your LG Account
(Q. Settings) → → [General] → [System] → [LG Account]
In [LG Account], you can use your email address to create a new LG account.
Using [Notifications]
(Q. Settings) → → [General] → [System] → [Additional Settings] →
[Notications]
You can view all notications from projector apps and LG service at the same time. You
can view and delete each notication message, and directly move to the app or website
using notications that support shortcuts.
[Home Auto Launch]
(Q. Settings) → → [General] → [System] → [Additional Settings] → [Home
Settings] → [Home Auto Launch]
You can set Home to launch automatically when turning on the projector.
• The configurable items differ depending upon model.
[Pointer Options]
(Q. Settings) → → [General] → [System] → [Additional Settings] → [Pointer
Options]
You can set the pointer speed and size you want while it is on the screen.
• [Tracking Speed]
Sets the pointer speed.
• [Pointer Size]
Selects the pointer size.
[Settings Help]
(Q. Settings) → → [General] → [System] → [Additional Settings] →
[Settings Help]
When set to [On], you can get help for the selected items when navigating through the
Settings menu.
83
ENGLISH
Restoring the Default Settings
(Q. Settings) → → [General] → [System] → [Reset to Initial Settings]
Return projector to its initial settings.
After reset, the projector will automatically turn off and on.
• [Reset All]
All items on the projector are changed to their default settings.
• [Reset all except network settings]
All items except the network settings are changed to their default settings.
• If [Safety] is set to [On], you should type the password to [Reset to Initial
Settings].
• Do not turn off the power during initialization.
• We recommended that you reset the projector to [Reset to Initial Settings]
before you sell it or transfer it to a third party.
84
ENGLISH
To Use Energy Saving Feature
(Q. Settings) → → [General] → [Energy Saving]
Reduces power consumption by adjusting peak screen brightness.
If you use [Energy Saving Step] function, brightness of your projector will be affected.
• [Energy Saving Step]
– [Minimum]/[Medium]/[Maximum]: Applies the pre-set Energy Saving mode.
• [Auto Power Off]
When the projector is on, it turns off automatically if you do not press any
button within the set period of time.
– Some models may not be supported.
85
ENGLISH
To Use Audio Guidance
(Q. Settings) → → [General] → [Accessibility] → [Audio Guidance]
If [Audio Guidance] is set to [On], audio guides will be provided in various situations,
such as when you adjust the volume or change settings and input signals.
• [Speed]
Adjust the speed of spoken guide.
• [Volume]
Adjust the volume of spoken guide.
• [Pitch]
Adjust the tone of spoken guide.
• This feature is available on certain languages only.
• Some models may not be supported.
• The configurable items differ depending upon model.
• For visually impaired users.
86
ENGLISH
[Projector Power Sound]
(Q. Settings) → → [General] → [Accessibility] → [Projector Power Sound]
This feature lets you turn on/off the sound effects that you hear when your projector is
switched on or off.
• Some models may not be supported.
• Settings the [Audio Guidance] to [On] automatically switches the [Projector
Power Sound] to [On] as well.
[Enjoy Projector Sound Together]
(Q. Settings) → → [General] → [Accessibility] → [Enjoy Projector Sound
Together]
The sound simultaneously outputs to the projector's built-in speaker and Bluetooth
device, so that users with different hearing abilities can watch projector together.
Set to [On]. [Sound Out] changes to [Bluetooth Device + Projector Speaker]. The
existing Bluetooth connection history will then be deleted.
• For Bluetooth devices, earphone or headset type is recommended.
• For instructions on how to connect and set up a Bluetooth device, refer to "[Use
External Speakers with Projector Speaker]".
Changing the Menu to High-Contrast Screen
(Q. Settings) → → [General] → [Accessibility] → [High Contrast]
When this feature is set to [On], it adjusts the background of some of the menus on
the screen and font colors to highlight the contrast between the light and dark areas.
[Grayscale]
(Q. Settings) → → [General] → [Accessibility] → [Grayscale]
Change the color of the menu on the screen to black and white tone to make its
ambiguity very clear. Set to [On].
[Invert Colors]
(Q. Settings) → → [General] → [Accessibility] → [Invert Colors]
To enhance the visibility of the menus on the screen, you can invert and calibrate
certain colors in some menus. Set to [On].
87
ENGLISH
[Support]
[Software Update]
(Q. Settings) → → [Support] → [Software Update]
If the software needs to be updated, run Software Update to apply the latest software
version for use.
• [Auto Update]
If set to [On], updates will be proceeded automatically without asking when
there is a new update after a version check.
• [Check for Updates]
When checking for the latest update version, you can perform updates only if an
update file of a later version is available. The projector automatically checks your
software version but, if necessary, you can perform a manual check.
• The configurable items differ depending upon model.
• The latest version can be obtained via internet connections.
• If software is not updated, certain functions may not work properly.
• In some countries, [Auto Update] is not displayed if you are not connected to the
internet.
88
ENGLISH
[Screen Self-diagnosis]
(Q. Settings) → → [Support] → [Screen Self-diagnosis]
Start the Picture Test to check that the video signal output is normal, and then select
whether there is an error.
If there are no problems in the test, check the connected external device.
[Sound Self-diagnosis]
(Q. Settings) → → [Support] → [Sound Self-diagnosis]
Start the Sound Test to check that the sound signal output is normal, and then select
whether there is an error.
If you have found no problems in the test, then check the connected external device.
[Privacy & Terms]
(Q. Settings) → → [Support] → [Privacy & Terms]
• [User Agreements]
These are the terms and conditions for privacy for the use of Smart projector-
related services.
• [Legal Notice]
It's a legal notice for services provided via projector.
• [Open Source Software Notice]
You can view the instructions for each item.
89
ENGLISH
TROUBLESHOOTING
Please check the list below when you experience the following symptoms during use of
the product. It may not be a failure.
Information on customer service for product problems is available in (Q. Settings)
→ → [Support] on the projector.
Perform Check-up with the [Quick Help].
When the projector malfunctions, you can get help to solve the problem.
Push the (Q. Settings) button of the remote control to select → [Support] →
[Quick Help].
You can also long-press the number button of the remote control to run the [Quick
Help].
• [Optimization Settings]
You can automatically check the overall status of your projector and view and
change the recommended setting values.
• [Check Items]
Select the problematic item, and you can get help to solve the problem.
– [Self-Diagnosis of Projector Settings]: Select the item that matches the
symptom to nd instructions that can help you solve the problem.
– [Check the status of Projector]: You can check your projector’s current status
for the selected item.
• [LG Remote Service]
You can get help in solving the problem via Remote Service. For [LG Remote
Service], make sure to contact the LG Electronics Customer Service Center.
– Some models may not be supported.
– This feature may not be available in some countries.
• When there is no related content in the [Quick Help], please refer to the
"TROUBLESHOOTING".
• If you still fail to solve the problem, please contact our customer service center.
90
ENGLISH
Troubleshooting Power/Remote Issues
Please check the list below when you experience the following symptoms during use of
the product. It may not be a failure.
I cannot turn on the Projector.
• Please make sure your projector power plug is correctly connected to the outlet.
• If you are using a multi-outlet, check if it is working properly. To check whether a
power strip is working properly, plug the projector’s power plug directly to a wall
outlet and observe its operation.
• Try to power on using the button on your projector set.
• If you are using a standby power cut-off switch, turn off the standby power cut-
off and turn the power on again.
The power is on, but the screen does not turn on for some time.
• It is not a sign of defect because the screen may turn on later to prevent
possible noise from the screen when the power is turned on.
The pointer of Magic Lighting Remote does not appear on the screen.
• Hold the remote control towards the projector and press the and (Q.
Settings) buttons at the same time more than 5 seconds until instructions
appear. The previously registered remote control is deregistered and then
registered again.
• Replace the batteries when you are prompted to do so on your projector screen.
(Use alkaline batteries.)
• If (Q. Settings) → → [General] → [Accessibility] → [Audio Guidance] is
set to [On], the pointer of the Magic Lighting Remote does not appear.
Set [Audio Guidance] to [Off]. (Some models may not be supported.)
91
ENGLISH
I cannot turn the projector on with the remote control.
• Please make sure your projector power plug is correctly connected to the outlet.
• Replace the batteries in the remote control. (Use alkaline batteries.)
• Check whether there are any obstacles in front of the projector’s remote control
sensor. Sound bars or other obstacles placed in front of the projector’s lower
receiver may obstruct IR signal reception.
• When using a set-top box remote control, if the projector integrated control
function of the set-top box remote control is turned off, you cannot power on
or off the projector with the settop box remote control. Please contact your
set-top box provider.
The power turns off suddenly.
• Make sure [Power Off Timer] is set.
• The projector will be turned off automatically if you do not press any buttons
for 4 hours even after the projector is turned on at the time set by [Power On
Timer].
• There is also a chance that the internal protection circuitry has activated because
the internal temperature of the product has risen unusually or excessively.
• If you are using a set-top box, the projector may be set to turn off when the set-
top box is turned off. To prevent the projector from turning off when you turn off
the set-top box, switch the projector power sync function off on the set-top box.
I cannot turn on or operate the device with the projector remote control even
after setting the universal remote control.
• Make sure that the device's power plug is plugged into the outlet.
• Replace the batteries in the remote control. (Use alkaline batteries.)
• Check if there are any obstacles blocking the signal in front of the connected
device’s remote control receiver.
92
ENGLISH
Troubleshooting Screen Issues
Please check the list below when you experience the following symptoms during use of
the product. It may not be a failure.
First of all, perform (Q. Settings) → → [Support] → [Screen Self-diagnosis]
to check for any abnormalities in the projector.
If you are using a set-top box, turn it off, and then turn it back on.
Make sure that the set-top box is correctly connected to your projector.
It says there is no signal on the screen.
• Check if the cable connected to the external device is properly connected to the
projector.
• Go to to choose the connected input.
• Check if your external device, such as a set-top box or Blu-ray player, is turned
on.
Part of the projected image is cut out.
• Try changing (Q. Settings) → → [Picture] → [Aspect Ratio].
• When using an external device (set-top box, game console, etc.), check the
screen size settings in the Settings menu of the device.
The screen shakes after the momentary appearance of vertical/horizontal lines
and net pattern.
• Use a different wall outlet than where you plug wireless telephones, hairdryers,
electrical drills etc. The problem is caused by high-frequency electronic devices
such as another projector or strong electromagnetic sources.
93
ENGLISH
I see vertical lines in the left, right, top, and bottom corners of the screen, or
colors are blurred when I try to connect to HDMI.
• (Q. Settings) → → [Picture] → [Aspect Ratio] → [Just Scan]
Set [Just Scan] to [Off].
[Just Scan] shows you the original image as it is. If the signal contains noise,
noise may be seen in the left, right, top, and bottom corners of the screen.
Idon’tseeanything,ortheimagekeepsickeringwhenItrytoconnectthe
HDMI cable.
• Check whether your HDMI
®
cable is compliant with the specifications. You may
experience flickering or a blank screen if the HDMI
®
cable is faulty (bent, broken).
• Make sure that the cable is correctly connected to the port. Bad or loose contact
may cause display problems on the screen.
• When using a UHD set-top box, adjust (Q. Settings) → → [General] →
[Devices] → [HDMI Settings] → [HDMI Deep Color].
The screen looks too dim or dark.
• (Q. Settings) → → [Picture] → [Select Mode]
Switch [Select Mode] to your desired picture mode. ([Standard], [Vivid], etc.)
This applies only to the current input mode.
• (Q. Settings) → → [General] → [Energy Saving] → [Energy Saving
Step]
Switch [Energy Saving Step] to [Minimum].
The screen is in black and white or displaying strange colors.
• Check the input mode or cable connection.
• Go to to choose the connected input.
• Check the [High Contrast], [Grayscale] and [Invert Colors] settings.
94
ENGLISH
Troubleshooting Sound Issues
Please check the list below when you experience the following symptoms during use of
the product. It may not be a failure.
First of all, perform (Q. Settings) → → [Support] → [Sound Self-diagnosis] to
check for any abnormalities in the projector.
If you are using a set-top box, turn it off, and then turn it back on.
Make sure that the set-top box is correctly connected to your projector.
Thescreenisne,butitdoesnotplayanysound.
• If you use a set-top box, there will be no sound if you have set the volume of
the set-top box or your projector to 0 or enabled Mute. Set the volume to an
appropriate level.
• (Q. Settings) → → [Sound] → [Sound Out]
Set [Sound Out] to [Use Projector Speaker] and check again. If you can hear the
sound normally, check the connection of the external speaker such as the sound
bar and the settings of the external speaker.
95
ENGLISH
Troubleshooting PC Connection Issues
Press and hold the button on your remote control. Select → [Edit] → [Edit
Inputs] in the upper right corner of [Home Dashboard]. In the edit mode, set the icon
of the HDMI terminal connected to the PC to [PC] to apply the video and aspect ratio
settings that are aligned with the PC.
Please check the list below when you experience the following symptoms during use of
the product. It may not be a failure.
To connect a different device to the same input terminal, you need to set the icon again
because the settings of the edit icon will not be automatically restored.
The screen remains blank after it is connected to a PC.
• Check that the PC is properly connected to the projector.
• Turn the projector off and back on using the remote control.
• Restart the PC with the projector on.
• Make sure that the output resolution set on the PC is set to the HDMI-PC
supported resolution of the projector.
• To use dual monitors, check that the PC or notebook supports dual-monitor
mode.
• Reconnect the high speed HDMI
®
cable.
• If you have connected the RGB output port of your PC to the HDMI input port or
your projector. You need an RGB to HDMI gender.
You will not see anything on the screen if you use an HDMI to RGB gender.
The screen is cut off or moved to one side after it is connected to a PC.
• Set the PC’s resolution to one supported by the projector.
• Set the connected HDMI device’s name to PC.
Press and hold the button on your remote control. Select → [Edit] →
[Edit Inputs] in the upper right corner of [Home Dashboard]. Change the icon of
the HDMI port connected to [Input] to PC and select [Save].
The sound does not play when the PC is connected with an HDMI
®
cable.
• In PC settings, set Control Panel → Sound → Play → LG projector as the default
device.
• Consult your manufacturer on whether your graphics card supports HDMI audio
output.
96
ENGLISH
Troubleshooting Movie Playback Issues
Please check the list below when you experience the following symptoms during use of
the product. It may not be a failure.
For more information about supported les, see "Using the [Media Player]".
Icannotndaleinthe[MediaPlayer].
• Check that the files on the USB storage device can be read by a PC.
• Check that the file extension is supported.
• Change the filter to [All].
Igetamessagesaying“Thisleisnotsupported”orthesoundisplaying
normally but the video is not.
• Check that the file plays without any problems on a PC’s video player. Also check
for file damage.
• Check that the file extension is supported.
• Check that the resolution is supported.
• Check that the video codec is supported.
• Check that the frame rate is supported.
Igetamessagesaying“Thisaudioisnotsupported”orthevideoisplaying
normally but the audio is not.
• Check that the file plays without any problems on a PC’s video player. Also check
for file damage.
• Check that the file extension is supported.
• Check that the audio codec is supported.
• Check that the bit rate is supported.
• Check that the sample rate is supported.
• Check that the audio channel separation is supported.
97
ENGLISH
I cannot see the subtitles.
• Check that the file plays without any problems on a PC’s video player. Also check
for file damage.
• Check that the video and subtitle files have the same name.
• Also check that both the video file and the subtitle file are in the same folder.
• Check that the subtitle file format is supported.
• Check that the language is supported. (You can check the language of the
subtitle file by opening the file in the Notepad.)
If subtitles encoding is incorrectly set, subtitles may not be displayed properly.
Press the down ( ) button on the remote control during video playback actions.
Change the [Code Page] value by selecting .
• If you play a video file stored on another device by using the content sharing
feature, subtitles may not be available depending on the program you use.
• Subtitles are not supported if you are playing video through an NAS unit. Consult
your NAS manufacturer.
My USB storage device is not recognized when connected.
• Check whether it is a USB storage device supported by the projector.
For details, please refer to "Connecting USB".
98
ENGLISH
Troubleshooting Network Connection Issues
Please check the list below when you experience the following symptoms during use of
the product. It may not be a failure.
Before connecting to a wireless network, check the name and password of the Wi-Fi
device to connect.
You can check the network connection status as shown below.
• (Q. Settings) → → [General] → [Network] → [Wi-Fi Connection] →
[Other Network] → [Advanced Wi-Fi Settings]
• Some models may support the [Wi-Fi Connection] function only.
When X appears next to projector
• Check the projector or the AP (Router).
• Check the connection status of the projector, AP (Router) and Cable Modem.
• Power off and power on in the following order;
1. The Cable Modem, wait for the Cable Modem to reset.
2. Turn your cable modem off and back on, and wait for the device to reset.
3. The projector.
• If you want to establish a wireless connection check the following points as well.
1. Set your router’s SSID (network name) or wireless channel.
2. Set your router’s security key.
If you do not know this setting, check the router's instruction manual and the
manual provided by the Internet provider. If you are still not sure, contact the
router company or the Internet company.
• If you are using a static IP, enter the IP directly.
99
ENGLISH
When X appears next to Gateway
• Check the AP (Router) or consult your Internet service provider.
• Unplug the power cord of the AP (Router), Cable Modem, wait 10 seconds.
Reapply power.
• Initialize (Reset) on the AP (Router) or Cable Modem.
• Check the AP (Router) manufacturer’s website to make sure your router has the
latest firmware version installed.
• If you do not know this setting, check the router's instruction manual and the
manual provided by the Internet provider. If you are still not sure, contact the
router company or the Internet company.
When X appears next to DNS
• Check the AP (Router) or consult your Internet service provider.
• Unplug the power cord of the AP (Router), Cable Modem, wait 10 seconds.
Reapply power.
• Initialize (Reset) on the AP (Router) or Cable Modem.
• Check that the MAC address of the projector/AP (Router) is registered with
your Internet service provider. (The MAC address displayed on the pane of the
network status window should be registered with your Internet service provider.)
• If you do not know this setting, check the router's instruction manual and the
manual provided by the Internet provider. If you are still not sure, contact the
router company or the Internet company.
100
ENGLISH
Troubleshooting LG Account Issues
In some countries, access to the website (www.lgappstv.com) may be restricted.
I have already signed up on the projector. Do I still have to sign up again at the
website (www.lgappstv.com)?
• You can use the website with the membership information that you used when
signing up on projector.
I forgot my Password. What should I do?
• On the projector's login screen, select the [Forgot Password?] Select the button
to go to the find password page. Enter your email address on the find password
page, and we'll send you a link to reset your password.
• You can also reset your password in LG Account → Reset Password on the
website (www.lgappstv.com).
I wish to delete the account saved on the projector.
• When you log in to your LG account on the projector, the account will be saved
to the projector.
You can delete accounts stored on the projector at any time, as follows.
1 Select (Q. Settings) → → [General] → [System] → [LG Account].
2 Select → [Edit Account List] at the top of the screen.
3 Pressing [DELETE] will delete the account.
It will not delete the login history or close the account.
101
ENGLISH
I wish to delete the usage history on the projector.
• When you use the projector after logging in to your LG account, the usage
history will be saved and you can delete it at any time.
1 Select (Q. Settings) → → [General] → [System] → [LG Account].
2 Select [Account Management] for the account you wish to set up.
3 Select [Usage Data Management].
4 Pressing [DELETE] will delete the usage history.
I wish to close my account on the projector.
• You can also close your LG account on the projector as follows.
1 Select (Q. Settings) → → [General] → [System] → [LG Account].
2 Select [Account Management] for the account you wish to set up.
3 Select [Terminate My Account].
4 Enter your password and press [OK] to close your account.
102
ENGLISH
Troubleshooting Contents Issues
Please check the list below when you experience the following symptoms during use of
the product. It may not be a failure.
I cannot see any content in HOME.
• You may not be able to see the content if the service country setting has been
changed.
Change the country you want to use in (Q. Settings) → → [General]
→ [System] → [Location] → [LG Services Country]. (Some models may not be
supported.)
• If you cannot see some apps, it may be because you deleted them. Please
reinstall the appropriate app.
• If the app is deleted, you can download the app at [Apps] and reinstall it. Search
for the desired app in → [Apps] and install it.
• The type of supported content differs by country.
• The content offerings are subject to change or interruption by the service
provider.
103
ENGLISH
Troubleshooting Internet Browser Issues
Please check the list below when you experience the following symptoms during use of
the product. It may not be a failure.
Some parts of a particular website are not visible when I am using the Internet.
• The Web Browser supports only HTML5 media and not Flash Plug-in.
• The Web Browser does not support plug-in installation.
• On the Web Browser, it may not be possible to play media files in formats other
than:
JPEG/PNG/GIF
• You cannot save attachments or images.
• If the [Use Block Ads] feature is turned on, the area on the website that appears
to show an ad will appear blank. If some of the content of the website is blocked
and is not displayed, try setting → [Settings] → [Use Block Ads] to [Off] in
[Web Browser]. Even if [Use Block Ads] is set to [Off], [Sponsored AD] on the
new tab page will be displayed.
The Internet browser automatically shuts down when I visit a website.
• The Internet browser may be forced to shut down if the available memory size is
not sufficient to accommodate the image information for a website. Check if you
can access the site with the issue on your PC.
When watching a video in Web Browser, the video is forced off.
• You may be able to fix this by setting → [Settings] → [Adaptive Streaming
using JavaScript] to [Off] in [Web Browser]. The setting is not applied to tabs
that were open before the change, and is only applied to tabs opened after the
change.
104
ENGLISH
BEING AWARE OF THE
INFORMATION
Supported Photo Files
File type Format Resolution
jpeg, jpg, jpe JPEG
Minimum: 64 x 64
Maximum
Normal Type: 15360 (W) x 8640 (H)
Progressive Type: 1920 (W) x 1440 (H)
png PNG
Minimum: 64 x 64
Maximum: 5760 (W) x 5760 (H)
bmp BMP
Minimum: 64 x 64
Maximum: 1920 (W) x 1080 (H)
105
ENGLISH
Supported Video Files
Maximum data transfer rate
• Full HD video
H.264 1920 x 1080@60P BP/MP/[email protected] Maximum 40 Mbps
HEVC 1920 x 1080@60P Main/[email protected] Maximum 40 Mbps
• ULTRA HD video (ULTRA HD model only)
H.264 3840 × 2160@30P BP/MP/[email protected] Maximum 50 Mbps
HEVC 3840 × 2160@60P Main/[email protected] Maximum 60 Mbps
Supported external subtitles
smi, srt, sub (MicroDVD, SubViewer 1.0/2.0), ass, ssa, txt (TMPlayer), psb (PowerDivX),
dcs (DLP Cinema)
Supported embedded subtitles format
• Matroska (mkv): Sub Station Alpha (SSA), Advanced Sub Station Alpha (ASS),
SRT
• MP4 (mp4): Timed Text
106
ENGLISH
Supported video codecs
Extension Codec
asf
wmv
Video
VC-1 Advanced Prole (except for WMVA), VC-1
Simple and Main Proles
Audio
WMA Standard (except for WMA v1/ WMA
Speech)
avi
Video
Xvid (except for GMC), H.264/AVC, Motion Jpeg,
MPEG-4
Audio
MPEG-1 Layer I, II, MPEG-1 Layer III (MP3), Dolby
Digital, LPCM, ADPCM
mp4
m4v
mov
Video H.264/AVC, MPEG-4, HEVC, AV1
Audio
Dolby Digital, Dolby Digital Plus, AAC, MPEG-1
Layer III (MP3), Dolby AC-4, MPEG-H 3D Audio
3gp
3g2
Video H.264/AVC, MPEG-4
Audio AAC, AMR-NB, AMR-WB
mkv
Video
MPEG-2, MPEG-4, H.264/AVC, VP8, VP9, HEVC,
AV1
Audio
Dolby Digital, Dolby Digital Plus, AAC, PCM, MPEG-1
Layer I, II, MPEG-1 Layer III (MP3)
ts
trp
tp
mts
Video H.264/AVC, MPEG-2, HEVC
Audio
MPEG-1 Layer I, II, MPEG-1 Layer III (MP3), Dolby
Digital, Dolby Digital Plus, AAC, PCM, Dolby AC-4
mpg
mpeg
dat
Video MPEG-1, MPEG-2
Audio MPEG-1 Layer I, II, MPEG-1 Layer III (MP3)
vob
Video MPEG-1, MPEG-2
Audio Dolby Digital, MPEG-1 Layer I, II, DVD-LPCM
• Dolby AC-4, MPEG-H 3D Audio: Some models may not be supported.
107
ENGLISH
Cautions for Video Playback
• Some user-created subtitles may not work properly.
• A video file and its subtitle file must be located in the same folder. For subtitles
to be displayed properly, make sure that the video file and the subtitle file have
the same name.
• Subtitles on a Network Attached Storage (NAS) device may not be supported
depending on the manufacturer and model.
• Streams that include Global Motion Compensation (GMC) and Quarterpel
Motion Estimation (Qpel) are not supported.
• ULTRA HD video (ULTRA HD model only): 3840 x 2160, 4096 x 2160
Some HEVC-encoded ULTRA HD videos other than the content officially
provided by LG Electronics may not be played.
Some codecs can be supported after a software upgrade.
Extension Codec
mkv
mp4
ts
Video
H.264/AVC, HEVC
Audio
Dolby Digital, Dolby Digital Plus, AAC
• Only Window Media Audio V7 and later are supported.
• The AAC main profile is not supported.
• Video files created by some encoders may not be played.
• Video files in a different format than specified may not be played properly.
• Video files stored on a USB storage device that does not support High Speed
may not be played properly.
108
ENGLISH
Supportedmusicleformats
File type Item Info
mp3
Bit rate 32 kbps ~ 320 kbps
Sample freq. 16 kHz ~ 48 kHz
Support MPEG-1, MPEG-2
Channels mono, stereo
wav
Bit rate -
Sample freq. 8 kHz ~ 96 kHz
Support PCM
Channels mono, stereo
ogg
Bit rate 64 kbps ~ 320 kbps
Sample freq. 8 kHz ~ 48 kHz
Support Vorbis
Channels mono, stereo
wma
Bit rate 128 kbps ~ 320 kbps
Sample freq. 8 kHz ~ 48 kHz
Support WMA
Channels up to 6 ch
flac
Bit rate -
Sample freq. 8 kHz ~ 96 kHz
Support FLAC
Channels mono, stereo
• The number of supported channels may vary depending upon the sample
frequency.
