1 2 3 4 5
1 2 3 4 5
ca. 100 cm ca. 100 cm
ca. 145 cm ca. 145 cm
ca. 105 cm ca. 105 cm
min. 60 cm
max. 100 cm
min. 60 cm
max. 100 cm
60 – 100 cm
Hose
Retainer
Tie
strap
max. 100 cm
min. 60 cm
N
Owner‘s Manual
F1403RD(1~9)
Read all instructions and explanations of the installation before use. Follow the instructions carefully. Keep the operating
instructions handy for later use. If the appliance is sold or passed on then ensure that the new owner always receives these
operating instructions. The following warnings must be strictly observed for safety reasons. They must be read before instal-
ling the appliance and putting it into operation.
• Intendeduse:Thisappliancehasbeendesignedexclusivelyforuseindry-interiorhouseholds.Usetheapplianceonlywithcold
drinking water and only for washing textiles with washing detergents designed for washing machines. Every other use is improper
and may lead to injuries, whereby the liability of the manufacturer will cease.
• Thisappliancemayonlybeusedbyadults.Donotallowchildrentotouchthecontrolsortoplaywiththeproduct.
• Nevermodifytheapplianceonyourown,asthisisdangerous.
• Thisapplianceisheavy.Transportingwithcare.
• Removeallpackagingandtransportboltsbeforeusingtheappliance.Otherwiseseriousdamagemayresult.
• Allinstallationworkmustbecarriedoutbyaqualiedtterortechnician.
• Haveelectricalconnectionsdonebyaqualiedelectrician.
• Neverplacetheapplianceonthepowercord.
• Iftheapplianceisplacedonacarpetthenplacethefeetsothataircancirculateunderneaththeappliance.
• Alwaysunplugthemachineandturnoffthewatersupplyafteruse.Disconnectappliancebypullingonlytheplug-neverdisconnect
bypullingthepowercord.Nevertouchtheplugwithwetngersorhands.
• Donotoverloadtheappliance.
• Washonlymachine-washabletextiles.Ifyouhavedoubtsregardingthis,thenobservethemarkingsonthelabel.
•
Neverplaceelectricalheaters,candlesetc.inthevicinityoftheappliance.Theycouldcausetheappliancetoigniteorpartstowarp.
• Protecttheappliancefromwetanddamp.Otherwise,thereisdangerofelectricshockandre.
• Connecttheappliancetoasuitablewallsocketfor220-240V.Neveruseanextensioncordordoubleadapter.
• Emptyallpockets.Hardorsharpobjectssuchascoins,needles,nails,screwsorstonesmaycauseseriousdamage.
Unbalancedmassmaycreateheavyvibrations.Ifheavyvibrationsremainalsowithoutload,callforanauthorizedcustomerservice.
• Donotwashordryarticlesthathavebeencleanedin,washedin,soakedin,ordabbedwithcombustibleorexplosivesubstances
(suchaswax,oil,paint,gasoline,degreasers,dry-cleaningsolvents,kerosene,etc.).Thismayresultinreorexplosion.
• Neverinsertproductscoatedwithmineraloils(e.g.nyloncoating,plasticbelts,etc.)intothemachine.Ifastainremoverhasbeen
usedthenmakesurethatthesolventhasbeencarefullywashedoutbeforeinsertingtheclothesintotheappliance.Oilmayremain
inthetubafterawholecycleresultinginreduringdrying.So,donotloadoilyclothes.
• Donotoperatetheapplianceatlocationswhereammablesubstancesarepresentsuchasoil,benzeneorhighlyinammablegas.
Suchmaterialsmaycausereorexplosion.Neverusecombustibledetergents.
• Onlyaddtheprescribedamountofsoftener.Excessiveamountsmaydamagetheclothes.
• Afterwashing,keepthedrumdooropentoprotectthedoorseal.
• Makesurethatallwaterhasrunoffbeforeopeningthedoor.Neveropenthedoorifwaterstillremains.Dangerofscalding.
• Animalsandchildrenmaygetintothewashingmachine.Soalwayschecktheappliancebeforeusingit.
• Duringwashing,theglassdoorbecomesveryhot.Keepchildrenawayfromtheappliancewheninoperation.
• Nevertrytorepairthemachineyourself.Incorrectrepairsmayresultininjuriesand/orseriousdefectstothemachine.
• Theproductshouldbeservicedandrepairedonlybytheauthorisedcustomerserviceusingoriginalreplacementparts.
•
Whendisposingofyouroldmachine,thepowercablemustbecappedandthedoorlockmustbemadeunusableinordertoprotectchildren.
• Whenplacingonacarpetedoor,makesurethattheopeninginthesocketisnotblocked.
• Iftheappliancehasbeenunderwaterthencontactthecustomerservice.Thereisdangerofelectricshockandre.
• Thecovercupofthelteraswellasthedispenserdrawermaynotbeopenedduringtheoperation.
• Keepallwashingpowderanddetergentsawayfromchildren.Dangerofpoisoning
Disposal
• Whenthiscrossed-outwheeledbinsymbolisattachedtoaproductitmeanstheproductiscovered
byEuropeanDirective2002/96/EC.
• Allelectricalandelectronicproductsshouldbedisposedofseparatelyfrommunicipalwastestream
via designated collection facilities appointed by the government or the local authorities.
• Thecorrectdisposalofyouroldappliancewillhelppreventpotentialadverseconsequencesforthe
environment and human health.
• Formoredetailedinformationaboutdisposalofyouroldappliance,pleasecontactyourcityofce,
waste disposal service or the shop where you purchased the product.
Safety instructions for use
Safety instuctions for the installation
Installorstoretheappliancewhereitwillnotbeexposedtosub-zerotemperaturesorexposedtotheweather.Fitthepowerplug
to a grounded wall socket that complies with all statutory regulations and ordinances. Ensure that the base opening is free from
obstructionbycarpetingifthewashingmachineisinstalledonacarpetedoor.Incountrieswherethereisariskofcockroach
infestation or other vermin, pay particular attention to keep the appliance and its surroundings in a clean condition at all times.
Anydamagewhichmaybecausedbycockroachesorotherverminisnotcoveredbytheapplianceguarantee.
CAUTION about positioning the appliance
Install the washing machine on a flat hard floor. Make sure that air circulation around the washing machine is
not impeded by carpets, rug etc.
•
Nevertrytocorrectanyunevennessintheoorusingpiecesofwood,cardboardorsimilarmaterialsunderthewashingmachine.
•
If it is not possible to position the washing machine away from a gas cooker or coal burning stove, an insulation panel
(85x60cm)coveredwithaluminumfoilonthesidefacingthecookerorstove,mustbeinsertedbetweenthetwoappliances.
•
Thewashingmachinemustnotbeinstalledinroomswherethetemperaturemaydropbelow0°C.
•
Pleaseensurethatwhenthewashingmachineisinstalled,thataServiceTechniciancangaineasyaccessintheeventofa
breakdown.
•
Adjustallfourfeetusingthetransitboltspannerprovidedtoensurethattheapplianceisstable,with20mmclearnacebetween
the top of the washing machine and underside of the worktop.
CAUTION about the power cord
Werecommendconnectingmostappliancestoadedicatedcircuitwhichisprotectedbyamainsfuse.Thatis,asingleoutlet
supplyingpoweronlytotheapplianceconcerned,withoutanyadditionaloutletsorbranchcircuits.Checkthespecications
ofthisowner‘smanual.Donotoverloadwallsockets.Overloadedwallsockets,looseordamagedwallsocketsorextension
cords,frayedpowercords,damagedorcrackedwireinsulationaredangerous.Anyoftheseconditionscouldresultinelectric
shockorre.Periodicallyexaminethecordofyourappliance,andifitsappearanceindicatesdamageordeterioration,unplugit,
discontinueuseoftheappliance,andhavethecordreplacedwithanexactreplacementpartbyanauthorizedservicer.Protect
thepowercordfromphysicalormechanicalabuse,suchasbeingtwisted,kinked,pinched,squashedinajambofadoor,or
walkedupon.Payparticularattentiontoplugs,walloutlets,andthepointwherethecordexitstheappliance.
CAUTION about location and moving
This equipmentis not designed for maritime use or foruse mobile installations suchas caravans, aircraft etc. Turn off the
stopcockifthemachineistobeleftforanylengthoftime(e.g.ifyouaregoingonholiday),especiallyifthereisnooordrain
(gully)intheimmediatevicinity.Ifrelocatingtheapplianceusetheoriginalpackingmaterial.Packagingmaterial(e.g.plasticlm,
Styrofoam)canbedangerousforchildren.Thereisariskofsuffocation!Keepallpackagingwellawayfromchildrenanddonot
allow children to play inside the bowl as they may become trapped.
CAUTION about the floor surface
• Theinstallationsurfacemustbeclean,dryandlevel.
• Installwashingmachineonaathardoor.Poorlyconstructedtimberbaseoorscancontributetoexcessivenoiseand
vibration.
• Properplacementandlevellingofthewashingmachineensurelong,regularandreliableoperation.
• Thewashingmachinemustbeperfectlylevelandrmlyinposition.
• Itmustnot“see-saw”acrosscornersunderload.
• Theinstallationsurfacemustbeclean,freefromoorwaxandotherlubricantcoatings.
• Donotallowthefeetofthewashingmachinetogetwet.Iffeetofthewashingmachinegetwet,slippingmayoccur.
@
Name of product
Front loading washing machine
Power supply
220-240V~,50Hz
Size WxDxH mm:
600x640x850
Weight
72kg
Max. Watt
2100W(Wash)/1500W(Dry)
Capacity
9 kg
(Wash)/
6kg
(Dry)
Water consumption
95
Permissible water pressure
1.0-10bar(100-1000kPa)
Technical Specification
1 3
5
2 4
Turn off the
water tap
Unscrew the
water inlet hose
Pull out the water
inlet filter
Clean the filter using
a hard bristle brush
Pull out the
dispenser drawer
Clean the dispenser
drawer under
flowing water
Clean inside the
recess with an
old toothbrush
Insert the
dispenser drawer
Cleaning the water inlet filter
Cleaning the dispenser drawer
Open the lower
filter cover and pull
out the drain hose.
Unplug the drain
hose plug
Then
open the filter by
turning to the left
Remove any
extraneous
matter from the
pump filter
After cleaning, refit the
drain filter cap and tighten it
by turning it clockwise. and
insert the drain plug
Tighten up the
inlet hose
Close the lower
cover
Once you
have finished
cleaning, replace
the drawer and
run a rinse cycle
without laundry or
soap.
Warning: Before cleaning the washing machine interior, unplug the electrical power cord to avoid the risk of electric
shock.
Exterior
Proper care of your washing machine can extend its service life.
The outside of the machine can be cleaned with warm water and
a neutral non-abrasive household detergent. Immediately wipe off
any spillage. Wipe with damp cloth. Avoid striking the surface with
sharp objects. Never hose down the machine!
Interior
Dry around the washing machine door
opening, flexible gasket and door
glass. Run washing machine through a
complete cycle using hot water. Repeat
process if necessary.
Cleaning in general
Important: Do not use methylated spirits, solvents or similar products.
Cleaning and Maintenance
Cleaning the drain pump filter
Installation of drain hose
•Thedrainhoseshouldnotbeplacedhigherthan100cmabovetheoor.
•Propersecuringofthedrainhosewillprotecttheoorfromdamageduetoanywaterleakage.
•Ifthedrainhoseistoolongdonotforcebackintothewashingmachine.Thiswillcauseabnormal
noise and cause the machine to malfunction and leak.
Electrical connection
1. Do not use an extension cord or double adapter.
2.Havedamagedsupplycordsreplacedbythemanufactureroritsserviceagentsorasimilarlyqualiedpersonto
prevent danger.
3.Alwaysunplugthemachineandturnoffthewatersupplyafteruse.
4.Connectthemachinetoanearthedsocketinaccordancewithcurrentwiringregulations.
5. The appliance must be positioned so that the plug is easily accessible.
•Repairstothewashingmachinemustonlybecarriedoutbyqualiedpersonnel.Repairscarriedoutbyinexpe-
riencedpersonsmaycauseinjuryorseriousmalfunctioning.Contactyourlocalservicecentre.
•Donotinstallyourwashingmachineinroomswheretemperaturebelowfreezingmayoccur.Frozenhosesmay
burstunderpressure.Theelectroniccontrolunitmaybecomeunreliableattemperaturesbelowfreezingpoint.
•Iftheapplianceisdeliveredinthewintermonthsandtemperaturesarebelowfreezing:Leavethewashingmachine
standing at room temperature for a few hours before putting it into operation.
Rattling and clanking noise Extraneous objects such as coins or safety pins maybe in drum or pump.
Thumping sound Heavywashloadsmayproduceathumpingsound.Thisisusuallynormal.
Vibrating noise Havealltransitboltsandpackingbeenremoved?
Water leaks. Checkandtightenhoseconnections.Unclogdrainpipe.Contactplumberifnecessary.
Excessive suds Too much detergent or unsuitable detergent.
Washing machine does not start Powercordmaynotbepluggedinorconnectionmaybeloose.
Washing machine won’t spin Checkthatthedoorisshut.
Checkthatforeignobjectsmaybeblockingthedraincausingthewaternottodrainout.
Door does not open Oncestarted,thedoorcannotbeopenedforsafetyreasons.
AttheendofthecycleorwhenStartPauseispressed,waitoneortwominutesbeforeopeningthedoorto
allow the electric locking mechanism time to release.
Troubleshooting
• Water supply is not adequate in area
• Water supply taps are not completely
open.
• Water inlet hose(s) are kinked.
• The lter of the inlet hose(s) are
clogged.
Check another tap in the house.
Fully open tap.
Straighten hose(s).
Check the filter of the inlet hose(s).
• Drain hose is kinked or clogged.
• The drain lter is clogged.
Clean and straighten the drain hose.
Clean the drain filter.
For more detailed information, please
refer to “Cleaning the drain pump filter”
• Load is too small.
• Load is out of balance.
• The appliance has an unbalance detection
and correction system. If individual heavy
articles are loaded (ex. bath mat, both
robe, etc.), this system may stop spinning
or even interrupt the spin cycle altogether.
• If the laundry is still too wet at the end of
the cycle, add smaller articles of laundry
to balance the load and repeat the spin
cycle. Floor is unstable.
Feet are not adjusted
Add 1 or 2 similar items to help balance
the load.
Rearrange load to allow proper spinning
• Is the door opened or not
completely closed?
Close the door completely.
If the " " does not clear, call for
service.
Unplug the power plug and call for
service.
• Water overlls due to the faulty water
valve.
Close the water tap.
Unplug the power plug.
Call for service.
Restart the cycle.
• Water level sensor has malfunctioned.
• Over load in motor.
• The washer experienced a power
failure.
• Check water supply.
CAUTION
•Theapplianceisnotintendedforusebyyoungchildrenorinrmpersonswithoutsupervision.
•YoungChildrenshouldbesupervisedtoensurethattheydonotplaywithappliance.
CAUTION
The hose supplied with the machine must be used.
Oldhosesmaynotbereused.
The oor should be a solid surface.
Adjust the feet so that the machine
does not rock from side to side or front
to back.
Before use please read carefully the safety instructions!
ThankyouforbuyinganLGfullyautomaticwashingmachine.
Pleasereadthisowner‘smanualcarefully,itprovidesinstructionsonsafeinstallation,useandmaintenance.
Keepithandyforfuturereferenceofthismachine.Makeanoteofthemodelandserialnumbersofyour
washing machine.
P/No.:MFL59755568
For the U.K. customer
CUSTOMERSERVICESTel.:+44-(0)844847LGLG(5454)Fax.:+44-(0)8448471413
LGEUKSERVICEWEB-SITE:http://www.lge.co.uk
Turn the tap on.
If “ ” is not released, unplug
power plug and call for service.
Safety instructions for use
To minimize the risk of fire within the inner bowl, the following should be observed:
•Itemsthathavebeenspottedorsoakedwithvegetableorcookingoilconstitutearehazardandshouldnotbe
placed in a tumble dryer.
Oil-affecteditemscanignitespontaneously,especiallywhenexposedtoheatsourcesSuchasinatumbledryer.
Theitemsbecomewarm,causinganoxidationreactionintheoil.Oxidationcreatesheat.Iftheheatcannot
escape,theitemscanbecomehotenoughtocatchre.Piling,stackingorstoringoil-affecteditemscanprevent
heatfromescapingandsocreatearehazard.
If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated by hair care prod-
uctsbeplacedinatumbledryertheyshouldrstbewashedinhotwaterwithextradetergent-thiswillreduce,
butnoteliminate,thehazard.The‘cooldown’cycleoftumbledryersshouldbeusedtoreducethetemperature
of the items. They should not be removed from the tumble dryer or piled or stacked while hot.
•Itemsthathavebeenpreviouslycleanedin,washedin,soakedinorspottedwithpetrol/gasoline,dry-cleaning
solventsorotherammableorexplosivesubstancesshouldnotbeplacedinatumbledryer.
Highlyammablesubstancescommonlyusedindomesticenvironmentsincludeacetone,denaturedalcohol,
petrol/gasoline,kerosene,spotremovers(somebrands),turpentine,waxesandwaxremovers.
•Itemscontainingfoamrubber(alsoknownaslatexfoam)orsimilarlytesturedrubberlikematerialsshouldnotbe
dried in a tumble dryer on a heat setting.
Foamrubbermaterialscan,whenheated,producerebyspontaneouscombustion.
•Fabricsoftenersorsimilarproductsshouldnotbeusedduringadryingcycle,toeliminatetheeffectsofstatic
electricityunlessthispracticeisspecicallyrecommendedbythemanufacturerofthefabricsoftenerorproduct.
•Undergarmentsthatcontainmetalreinforcementsshouldnotbeplacedinatumbledryer.
Damage to the tumble dryer can result if metal reinforcements come loose during drying.
Whenavailableadryingrackcouldbeusedforsuchitems.
•Plasticarticlessuchasshowercapsorbabieswaterproofnapkincoversshouldnotbeplacedinatumbledryer.
•Rubber-backedarticles,clothesttedwithfoamrubberpads,pillows,rubberbootsandrubber-coatedtennis
shoes should not be placed in a tumble dryer.
BS Plug Safety Details (For U.K. User)
Green
Yellow )
Brown(Live)
Blue(Neutral)
Fuse
Cord
grip
E
L
N
and
(Earth)
ThisappliancemustbeearthedAsthecoloursofthewiresinthemains
lead of this apparatus may not correspond with the coloured markings
identifyingtheterminalsinyourplug,proceedasfollows:Thegreenand
yellow wire must be connected to the terminal in the plug marked E or by
the earth symbol or coloured green or green and yellow.
The wire coloured blue must be connected to the terminal marked with the letter N or coloured black.
ThewirecolouredbrownmustbeconnectedtotheterminalmarkedwiththeletterLorcolouredred.Ifa13
amp(BS1363)plugisused,ta13ampBS1362fuse.
Loading ...
