OWNER'S MANUAL
English
EN
APCP-1700 Automatic Pool Cover Pump
The Little Giant APCP-1700 Pool Cover Pump helps to protect your pool cover from prolonged accumula-
tion of rain or melting snow. The APCP-1700 is certified for use on pool covers, and can attach to a standard
garden hose for easy water removal.
The pump is controlled by a float switch mechanism. The pump auto-
matically starts when approximately 2½” of water accumulates, and
shuts off when the water level is reduced to approximately 1”.
This product is covered by a Limited Warranty for a period of 36
months from the date of original purchase by the consumer. For com-
plete warranty information, refer to www.LittleGiant.com
.
Specifications
Flow Rates
SAFETY INSTRUCTIONS
Before Getting Started
This equipment should be installed and serviced by technically qualified personnel who are familiar with
the correct selection and use of appropriate tools, equipment, and procedures. Failure to comply with
national and local electrical and plumbing codes and within Little Giant recommendations may result in
electrical shock or fire hazard, unsatisfactory performance, or equipment failure.
Know the product’s application, limitations, and potential hazards. Read and follow instructions carefully to
avoid injury and property damage. Do not disassemble or repair unit unless described in this manual.
Failure to follow installation or operation procedures and all applicable codes may result in the following
hazards:
Model HP Volts HZ Amps Watts
APCP-1700 1/3 115 60 2.2 270
Gallons per Hour/Liters per Hour
1 FT (0.3 m) 5 FT (1.5 m) 10 FT (3 m) 15 FT (4.6 m) 20 FT (6.1 m) Maximum Height
1745 (6605) 1540 (5625) 1230 (4650) 850 (3210) 490 (1855) 26 FT (7.9 m)
Risk of death, personal injury, or property damage due to explosion,
fire, or electric shock.
• Do not use to pump flammable or explosive fluids such as gasoline, fuel oil, kerosene, etc.
• Do not use in explosive atmospheres or hazardous locations as classified by the NEC, ANSI/NFPA70.
• When a pump is in its application, do not touch the motor, pipes, or water until the unit is unplugged or electri-
cally disconnected.
• If the power disconnect is out of sight, lock it in the open position and tag it to prevent unexpected application of
power.
