MDP18B10AWWC
USER MANUAL
Warning notices: Before using this product, please read this manual carefully and keep it for future reference.
The design and specifications are subject to change without prior notice for product improvement.
Consult with your dealer or manufacturer for details.
The diagram above is just for reference. Please take the appearance of the actual product as the standard.
Dish Washer
THANK YOU LETTER
01
02
15
12
11
26
29
32
33
08
10
34
SAFETY INSTRUCTIONS
SPECIFICATIONS
PRODUCT OVERVIEW
QUICK START GUIDE
PRODUCT INSTALLATION
OPERATION INSTRUCTIONS
CLEANING AND MAINTENANCE
TROUBLESHOOTING
TRADEMARKS, COPYRIGHTS AND LEGAL STATEMENT
DISPOSAL AND RECYCLING
DATA PROTECTION NOTICE
THANK YOU LETTER
Thank you for choosing Midea! Before using your new Midea product, please read
this manual thoroughly to ensure that you know how to operate the features and
CONTENTS
Intended Use
Explanation of Symbols
SAFETY INSTRUCTIONS
02
The following safety guidelines are intended to
prevent unforeseen risks or damage from unsafe
or incorrect operation of the appliance. Please
check the packaging and appliance on arrival to
make sure everything is intact to ensure safe
operation. If you find any damage, please contact
the retailer or dealer.
Please note modifications or alterations to the
appliance are not allowed for your safety concern.
Unintended use may cause hazards and loss of
warranty claims.
●
●
Danger
This symbol indicates that there are dangers
to the life and health of persons due to
extremely flammable gas.
Warning of electrical voltage
This symbol indicates that there is a danger
to life and health of persons due to voltage.
Warning
The signal word indicates a hazard with a
medium level of risk which, if not avoided,
may result in death or serious injury.
Read these operating instructions carefully and
attentively before using/commissioning the unit and
keep them in the immediate vicinity of the installation
site or unit for later use!
03
Caution
The signal word indicates a hazard with a
low degree of risk which, if not avoided,
may result in minor or moderate injury.
Attention
The signal word indicates important
information (e.g. damage to property),
but not danger.
Observe instructions
This symbol indicates that a service
technician should only operate and maintain
this appliance in accordance with the
operating instructions.
04
DANGER: Risk of Fire/Flammable materials
●●
●
●
●
●
●
●
●
●
When using your dishwasher, follow the precautions
listed below:
Installation and repair can only be carried out by a
qualified technician.
This appliance is intended to be used in household
and similar applications such as:
-staff kitchen areas in shops, offices and other
working environments;
-farm houses;
-by clients in hotels, motels and other residential
type environments;
-bed and breakfast type environments.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be done by children
without supervision.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Packaging material could be dangerous for children!
This appliance is for indoor household use only.
To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.
Earthing Instructions
05
●
●
●
●
●
●
●
●
●
●
●
●
Please unplug before cleaning and performing main-
tenance on the appliance.
Use a soft cloth moistened with mild soap, and then
use a dry cloth to wipe it again.
This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce the
risk of an electric shock by providing a path of least
resistance of electric current. This appliance is
equipped with an earthing conductor plug.
The plug must be plugged into an appropriate outlet
that is installed and earthed in accordance with all
local codes and ordinances.
Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded.
Do not modify the plug provided with the appliance
if it does not fit the outlet.
Have a proper outlet installed by a qualified
electrician.
Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
Do not operate your dishwasher unless all enclosure
panels are properly in place.
Open the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
Do not place any heavy objects on or stand on the
door when it is open. The appliance could tip
forward.
06
●
●
●
●
●
●
●
●
●
●
●
●
When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal;
2) Warning: Knives and other utensils with sharp
points must be loaded in the basket with their points
facing down or placed in a horizontal position.
Some dishwasher detergents are strongly alkaline.
They can be extremely dangerous if swallowed.
Avoid contact with the skin and eyes and keep
children away from the dishwasher when the door is
open.
Check that there are no detergent residues after
completion of the wash cycle.
Do not wash plastic items unless they are marked
“dishwasher safe” or the equivalent.
For unmarked plastic items not so marked, check the
manufacturer's recommendations.
Use only detergent and rinse agents recommended
for use in an automatic dishwasher.
Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
The door should not be left open, since this could
increase the risk of tripping.
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.
During installation, the power supply must not be
excessively or dangerously bent or flattened.
Do not tamper with controls.
The appliance needs to be connected to the main
water valve using new hose sets. Old sets should not
be reused.
Disposal
07
●
●
●
●
●
●
●
●
●
To save energy, in stand by mode , the appliance will
switch off automatically while there is no any
operation in 30 minutes.
The maximum number of place settings to be
washed is 8.
The maximum permissible inlet water pressure is
1MPa.
The minimum permissible inlet water pressure is
0.04MPa.
For disposing of package and the appliance please
go to a recycling center.
Therefore cut off the power supply cable and make
the door closing device unusable.
Cardboard packaging is manufactured from recycled
paper and should be disposed in the waste paper
collection for recycling.
By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences for
the environment and human health, which could
otherwise be caused by inappropriate waste handling
of this product.
For more detailed information about recycling of this
product, please contact your local city office and
your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste separately
for special treatment is necessary.
08
SPECIFICATIONS
Height (H)
Width (W)
Depth (D1)
Depth (D2)
W
D1
H
D2
35.63 inches
17.64 inches
23.63 inches (with the door closed)
46.26 inches (with the door opened 90°
09
Product information sheet
09
Sheet of household dishwasher according to EU Directive 1016/2010 & 1059/2010:
Standard place setting
Standard cleaning cycle
Energy consumption of the standard cleaning cycle
Water consumption of the standard cleaning cycle
Annual energy consumption
Noise level
Mounting
Could be built-in
Rated power uasge (Heater)
Rated voltage / frequency
Used water pressure
8
Normal
0.56-0.64 kWh
9.7-19 L
237 kWh
52 dB(A) re 1 pW
Portable
No
1000W
AC 120V/60Hz
20-120 psi (140-830 kPa)
10
Product
PRODUCT OVERVIEW
IMPORTRANT
To get the best performance from your dishwasher, read all operating
instructions before using it for the first time.
NOTE
Pictures are only for reference, different models may be different.
Upper spray arm
Upper basket
Cup rack
Lower basket
Cutlery basket
Dispenser
Lower spray arm
Filter assembly
Inner pipe
QUICK START GUIDE
Please read the corresponding content in the instruction manual
for detailed operating method.
11
1.Install the dishwasher
3. Load the baskets.
Inside Outside
5. Select a suitable program
and start the dishwasher.
4. Fill the dispenser with
detergent and rinse aid.
2. Remove larger residue
from dishes.
Avoid pre-rinsing.
B
A
About Power Connection
Electrical Shock Hazard
Disconnect electrical power before installing dishwasher.
Failure to do so could result in death or electrical shock.
For personal safety:
Do not use an extension cord or an adapter plug with this appliance.
Do not, under any circumstances, cut or remove the earthing
connection from the power cord.
The installation of the pipes and electrical equipments should
be done by professionals.
Electrical requirements
Please look at the rating label to know the rating voltage and connect the dishwasher
to the appropriate power supply. Use the required fuse 10A/13A/16A, time delay fuse or
circuit breaker recommended and provide separate circuit serving only this appliance.
Electrical connection
Ensure the voltage and frequency of the power being corresponds to those on the
rating plate. Only insert the plug into an electrical socket which is earthed properly.
If the electrical socket to which the appliance must be connected is not appropriate
for the plug, replace the socket, rather than using a adaptors or the like as they could
cause overheating and burns.
Ensure that proper earthing exists before use
WARNING
WARNING
Attention
12
PRODUCT INSTALLATION
Positioning The Appliance
Position the appliance in the desired location. The back should rest against the wall
behind it, and the sides, along the adjacent cabinets or walls. The dishwasher is
equipped with water supply and drain hoses that can be positioned either to the
right or the left sides to facilitate proper installation.
Water Supply And Drain
Connect the unicouple to the faucet
Attach the unicouple to the faucet adapter following
the three steps below:
1. Depress the locking collar at the top of the
unicouple.
2. Place the unicouple completely over the faucet
adapter.
3. Release the locking collar. The unicouple should
now be locked onto the faucet adapter.
13
Remove unicouple from faucet
1. Turn off cold water.
2. Relieve water pressure from the unicouple
assembly before disconnecting it from the
faucet by depressing the red pressure relief
button on the unicouple.
3. Depress the locking collar and remove the
unicouple from the faucet.
Depress collar to
release unicouple
from faucet
Depress red button to
release water pressure
Collar
14
Extension hose
If you need a drain hose extension, make sure to use a similar drain hose.
It must not be longer than 4 meters, otherwise the cleaning effect of the dishwasher
could be reduced.ance.
Syphon connection
The waste connection must be at a height less than 1000 mm (maximum) from the
bottom of the dishwasher.
How to drain excess water from hoses
If the connection to the drain pipe is positioned higher than 1000 mm, excess water
may remain in the drain hose. It will be necessary to drain excess water from the hose
into a bowl or suitable container that is held outside and lower than the sink.
Water outlet
Connect the water drain hose. The drain hose must be correctly fitted to avoid water
leaks. Ensure that the water drain hose is not kinked or squashed.
Insert the drain hose into a drain pipe with a minimum diameter of 1.47 inches, or let it
run into the sink, making sure to avoid bending or crimping it. The height of drain pipe
must be less than 39.37 Inches. The free end of the hose must not be immersed in water
to avoid the back flow of it.
Connection Of Drain Hoses
Please securely fix the drain hose in either position A or position B
B
A
MAX 39.37 inches
Drain hose
Counter
1.47 inches
Back of dishwasher
Water inlet
Drainage outlet
Control Panel
OPERATION INSTRUCTIONS
Description
●
No.1
Press this button to turn on your dishwasher,the
screen lights up.
15
●
Press the Delay button to increase the delay start
time. Delay a cycle for up to 24 hours in one-hour
increments. After setting the delay time, press the
Start/Pause button to start.
Power
No.2
Delay start
●
For heavily soiled items include pots and pans.
With dried on food.
No.5
Heavy
●
This is the standard program suitable for normally
soiled loads, such as pots, plates, glasses and lightly
soiled pans.
Normal
●
For normally soiled loads, such as pots, plates,
glasses and lightly soiled pans.
ECO
●
For lightly soiled crockery and glass.Glass
●
For normally soiled loads that need quick wash.
●
A shorter wash for lightly soiled loads that do not
need drying.
90 min
Rapid
●
Select the appropriate washing program, the selected
program indicator will be lit.
Program
No.3
●
To start the selected washing program.
Press the button for 3 seconds to cancel the program
when the dishwasher is working.
No.4
Start/Cancel
1 2 3 45 6 7
8
16
Description
No.8
Progress
indicator
●
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is
low on dishwasher rinse aid and needs to be refilled.
●
To show the reminding time, delay time, error code
etc.
●
The progress light that corresponds to the current
operation turns on to show the progress of the cycle.
No.6
indicator
No.7
Pre-wash
Main-wash
Rinse
Drying
Program end
Program
Description
Of Cycle
Running
Time(min)
Energy
(kWh)
Water
(L)
Detergent
Pre/Main Wash
Heavy
Normal
(*Test cycle)
Glass
90 min
Rapid
Pre-wash 1
Pre-wash 2
Main wash(65
°C
)
Rinse 1
Rinse 2
Last Rinse(68
°C
)
Drying
Pre-wash 1
Pre-wash 2
Main wash
(45-60
°C
)
Rinse 1
Rinse 2
Last Rinse(65
Drying
Pre-wash
Main-wash(50
Rinse 1
Rinse 2
Last Rinse(62
Drying
Pre-wash
Main wash(50
Rinse 1
Rinse 2
Last Rinse(62
Drying
Pre-wash(55
°C
)
Main wash(60
°C
)
Rinse(55
°C
)
Rinse(58
°C
)
Drying
16
0/17.8g
AHAM/NSF:
0/17.8g
DOE: 0/8.9g
0/17.8g
0/17.8g
190.76
9.7-190.56-0.64
130.56
0/17.8g
160.53
0.60
0/17.8g
130.83
165
121-150
60
155
125
90
Pre-wash(50
Main wash(60
Rinse(55
Last Rinse(68
Drying
The table below shows which programs are best for the levels of food residue
on them and how much detergent is needed. It also show various information about
the programs. Consumption values and program duration are only indicative except
for the ECO program.
Programmes
17
18
Preparing And Loading Dishes
Consider buying utensils which are identified as dishwasher-proof.
For particular items, select a program with the lowest possible temperature.
To prevent damage, do not take glass and cutlery out of the dishwasher immediately
after the program has ended.
For washing the following cutlery/dishes
Are not suitable
Cutlery with wooden, horn china or mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not temperature resistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Very small items should not be washed in the dishwasher as they could easily fall
out of the basket.
NOTE
Are of limited suitability
Some types of glasses can become dull after a large number of washes
Silver and aluminum parts have a tendency to discolor during washing
Glazed patterns may fade if machine washed frequently
Recommendations for loading the dishwasher
Scrape off any large amounts of leftover food. Soften remnants of burnt food in
pans. It is not necessary to rinse the dishes under running water.
For best performance of the dishwasher, follow these loading guidelines.
(Features and appearance of baskets and cutlery baskets may vary from your model.)
Place objects in the dishwasher in the following way:
tems such as cups, glasses, pots, pans, etc. must face downwards.
Curved items, or ones with recesses, should be loaded aslant so that water can run off.
All utensils are stacked securely and can not tip over.
All utensils are placed in the way that the spray arms can rotate freely during washing.
Load hollow items such as cups, glasses, pans etc. With the opening facing downwards
so that water cannot collect in the container or a deep base.
Dishes and items of cutlery must not lie inside one another, or cover each other.
To avoid damage, glasses should not touch one another.
The upper basket is designed to hold more delicate and lighter dishware such as glasses,
coffee and tea cups.
Long bladed knives stored in an upright position are a potential hazard!
Long and sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
LOADING THE BASKETS
19
Loading the upper basket (8 place setting)
The upper basket has been designed for small plates, mugs, glasses, and plastic items
marked “dishwasher safe”. Load your plates into the dishwasher in two half rows, so
that the front of each plate faces the back of the plate in front of it, and the open sides
of the plates at the center of the dishwasher face each other.
When loading dishes, pull the upper basket out sufficiently so you can load it without
striking the counter.
Loading the lower basket (8 place setting)
The lower basket has been especially designed for dinner dishes, soup bowls, plates,
pots, lids, casserole dishes, and plates.
Load large items such as pans and pots into the dishwasher so their open sides face
downwards.
Number Item
1
2
3
4
5
6
Soup spoons
Knives
Salad forks
Forks
Large spoons
Large forks
20
Loading the cutlery basket
The silverware basket can be divided into three separate modules that can be used in
both upper and lower racks
Removing the dishes
To prevent water dripping from the upper basket into the lower basket, we recommend
that you empty the lower basket first, followed by the upper basket.
321 5444 6
46
45
4
4
5
4
4
4
4
1 1 1 1 1 1
1 1 1 1 1 1
1
1
1
1
2 2 2 2
2 2 2 2
33
33
33
33
Do not let any item extend through the bottom.
Always load sharp utensils with the sharp point down!
Be sure nothing protrudes though bottom of the basket
or rack to block the lower spray.
WARNING
WARNING
Items will be hot! To prevent damage, do not take glass and
cutlery out of the dishwasher for around 15 minutes after the
program has ended.
upper position
3. Re-attach the upper basket to upper
or lower rollers.
4. Push in the upper basket.
Folding back the cup shelves
To make room for taller items in the upper basket, raise the cup rack upwards.
You can then lean the tall glasses against it. You can also remove it when it is not
required for use.
Basket Loading Tips
Adjusting the upper basket
lower position
1. Pull out the upper basket. 2. Remove the upper basket.
The height of the upper basket can be easily adjusted to accommodate taller dishes in
either the upper or lower basket.
To adjust the height of the upper rack, follow these steps:
21
22
Function of detergent
The chemical ingredients that compose the detergent are necessary to remove,
crush and dispense all dirt out of the dishwasher. Most of the commercial quality
detergents are suitable for this purpose.
When to refill the rinse aid dispenser
TAdd rinse aid into the dispenser, when the rinse aid symbol( ) is illuminated on
the LED Display.
Function Of The Rinse Aid And Detergent
The rinse aid is released during the final rinse to prevent water from forming droplets on
your dishes, which can leave spots and streaks. It also improves drying by allowing water
to roll off the dishes. Your dishwasher is designed to use liquid rinse aids.
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any
other substances (e.g. Dishwasher cleaning agent, liquid detergent). This would damage
the appliance.
Proper Use of Detergent
Use only detergent specifically made for dishwashers use. Keep your detergent
fresh and dry.
Do not fill detergent into the dispenser until you are ready to start the dishwasher.
Dishwasher detergent is corrosive! Keep dishwasher detergent out of the
reach of children.
WARNING
WARNING
23
Filling The Rinse Aid Reservoir
Adjusting the rinse aid reservoir
Turn the rinse aid indicator dial to a number between 1 and 4. The higher the number,
the more rinse aid the dishwasher uses.
If the dishes are not drying properly or are spotted, adjust the dial to the next higher
number until your dishes are spot-free. Reduce it if there are sticky whitish stains on
your dishes or a bluish film on glassware or knife blades.
The rinse aid is released during the final rinse to prevent water from forming droplets on
your dishes, which can leave spots and streaks. It also improves drying by allowing water
to roll off the dishes. Your dishwasher is designed to use liquid rinse aids.
3. Close the rinse aid reservoir cap by
rotating it clockwise.
1. Remove the rinse aid reservoir cap 2
by rotating it counterclockwise.
2. Carefully pour in the rinse-aid into
its dispenser, whilst avoiding it to
overflow.
Adjust lever(Rinse)
24
Saving Energy
1. Pre-rinsing of tableware items leads to increased water and energy consumption
and is not recommended.
2. Washing tableware in a household dishwasher usually consumes less energy and
water in the use phase than hand dishwashing when the household dishwasher is
used according to the instructions.
Filling The Detergent Dispenser
Be aware that depending on the soiling of water, setting may be different.
Please observe the manufacturer's recommendations on the detergent packaging.
NOTE
1. Press the release latch on the
detergent dispenser to open
the cover.
2. Fill detergent to the lower fill line A.
(15 grams) for lightly soiled dishes
such as glassware.For a normal soil
level fill to the MAX fill line B (25
grams).
3. Close the cover and press on it until
it locks into place.
Push latch to open
B
A
A program can only be changed if it has been running only for a short period of time,
otherwise the detergent may have already been released or the the wash water with
detergent has already been drained. If this is the case, the dishwasher needs to be reset
and the detergent dispenser must be refilled. To reset the dishwasher, follow the
instructions below:
1. Open the door a little to stop the dishwasher, after the spray arm stop working,
you can open the door completely.
2. Press Start/Cancel button for more than 3 seconds to cancel the program.
3. Press the Program button to select the desired program.
4. Press the Start/Cancel button, then close the door within four seconds, the
dishwasher will start after 10 seconds.
Forget To Add A Dish?
A forgotten dish can be added any time before the detergent dispenser opens. If
this is the case, follow the instructions below:
1. Open the door a little to stop the dishwasher, after the spray arm stop working,
you can open the door completely.
2. Add the forgotten dishes.
3. Press the Start/Cancel button, then close the door within four seconds, the
dishwasher will start after 10 seconds.
It is dangerous to open the door mid-cycle,
as hot steam may scald you.
WARNING
After 5 sec
Starting A Program
1. Draw out the lower and upper basket, load the dishes and push them back.
It is commended to load the lower basket first, then the upper one.
2. Pour in the detergent.
3. Insert the plug into the socket. The power supply refer to last page ”Product fiche”.
Make sure that the water supply is turned on to full pressure.
4. Open the door, press the Power button.
5. Choose a program, the response light will turn on. Then press the Start/Pause
button, the dishwasher will start its cycle after a few seconds.
25
Changing The Program Mid-cycle
3 sec
26
External Care
CLEANING AND MAINTENANCE
The door and the door seal
Clean the door seals regularly with a soft damp cloth to remove food deposits.When
the dishwasher is being loaded, food and drink residues may drip onto the sides of
the dishwasher door. These surfaces are outside the wash cabinet and are not
accessed by water from the spray arms. Any deposits should be wiped off before the
door is closed.
Internal Care
Filtering system
The filtering system in the base of the wash cabinet retains coarse debris from the
washing cycle, including foreign objects such as tooth picks or shards. The collected
coarse debris may cause the filters to clog. Check the condition of the filters regularly,
carefully remove foreign objects and clean the parts of the filtering system if necessary
with water. Follow the steps below to clean the filter.
The control panel
If cleaning is required, the control panel should be wiped with a soft damp cloth only.
To avoid penetration of water into the door lock and electrical components, do not
use a spray cleaner of any kind.
Never use abrasive cleaners or scouring pads on the outer surfaces because they
may scratch the finish. Some paper towels may also scratch or leave marks on the
surface.
Pictures are only for reference, different models of the filtering system and spray
arms may be different.
1. Hold the coarse filter and rotate
it anticlockwise to unlock the
filter. Lift the filter upwards and
out of the dishwasher.
2. The fine filter can be pulled off the
bottom of the filter assembly. The
coarse filter can be detached from
the main filter by gently squeezing
the tabs at the top and pulling it away.
WARNING
WARNING
Main filter
Coarse filter
Fine filter
27
3. Larger food remnants can be
cleaned by rinsing the filter under
running water. For a more thorough
clean, use a soft cleaning brush.
4. Reassemble the filters in the reverse
order of the disassembly, replace the
filter insert, and rotate clockwise to
the close arrow.
It is necessary to clean the spray arms regularly for hard water chemicals will clog the
spray arm jets and bearings.
To clean the spray arms, follow the instructions below:
Spray arms
EN
Do not over tighten the filters. Put the filters back in sequence securely, otherwise
coarse debris could get into the system and cause a blockage.
Never use the dishwasher without filters in place. Improper replacement of the filter
may reduce the performance level of the appliance and damage dishes and utensils.
1. To remove the upper spray
arm, hold the nut in the center
still and rotate the spray arm
counterclockwise to remove it.
2. To remove the lower spray
arm, pull out the spray arm
upward.
3. Wash the arms in soapy and
warm water and use a soft
brush to clean the jets.
WARNING
Frost precaution
Please take frost protection measures on the dishwasher in winter. Every time after
washing cycles, please operate as follows:
1. Cut off the electrical power to the dishwasher at the supply source.
2. Turn off the water supply and disconnect the water inlet pipe from the water valve.
3. Drain the water from the inlet pipe and water valve. (Use a pan to gather the water)
4. Reconnect the water inlet pipe to the water valve.
5. Remove the filter at the bottom of the tub and use a sponge to soak up water in
the sump.
After every wash, turn off the water supply to the appliance and leave the door
slightly open for a while so that moisture and odors are not trapped inside.
Before cleaning or performing maintenance, always remove the plug from the socket.
To clean the exterior and rubber parts of the dishwasher, do not use solvents or
abrasive cleaning products. Only use a cloth with warm soapy water.
To remove spots or stains from the surface of the interior, use a cloth dampened
with water an a little vinegar, or a cleaning product made specifically for dishwashers.
It is recommend that you run a wash cycle with the dishwasher empty and then
remove the plug from the socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door seals to last longer and prevent
odors from forming within the appliance.
If the appliance must be moved, try to keep it in the vertical position. If absolutely
necessary, it can be positioned on its back.
One of the factors that cause odours to form in the dishwasher is food that remains
trapped in the seals. Periodic cleaning with a damp sponge will prevent this from
occurring.
28
Caring For The Dishwasher
After every wash
Remove the plug
No solvents or abrasive cleaning
When not in use for a long time
Moving the appliance
Seals
29
EN
TROUBLESHOOTING
Possible reason SolutionProblem
Dishwasher doesn't
start
Before Calling For Service
Reviewing the charts on the following pages may save you from calling for service.
Replace fuse or reset circuit breaker.
Remove any other appliances sharing
the same circuit with the dishwasher.
Make sure the dishwasher is turned
on and the door is closed securely.
Make sure the power cord is
properly plugged into the wall socket.
Stained tub interior
Spilled rinse aid. Always wipe up rinse aid spills
immediately.
Detergent with
colourant
may have been used.
Make sure that the detergent has no
colourant.
Water not pumped
form dishwasher
Check that the water supply is
connected properly and the water
is turned on.
Door of dishwasher
not properly closed.
Make sure to close the door
properly and latch it.
Twisted or trapped
drain hose.
Check the drain hose.
Filter clogged. Check the filter system.
Foam in the tub
Check the kitchen sink to make sure
it is draining well. If the problem is
the kitchen sink that is not draining ,
you may need a plumber rather than
a serviceman for dishwashers.
Fuse blown, or the
circuit break tripped.
●
Power supply is not
turned on.
●
Water pressure is low
●
●
●
●
Kitchen sink clogged.
●
Wrong detergent.
●
●
●
Use only the special dishwasher
detergent to avoid suds. If this occurs,
open the dishwasher and let suds
evaporate. Add 1 liter of cold water
to the bottom of the dishwasher.
Close the dishwasher door, then select
any cycle. Initially, the dishwasher will
drain out the water. Open the door
after draining stage is complete and
check if the suds have disappeared.
Repeat if necessary.
30
Possible reason SolutionProblem
There are rust
stains on cutlery
The affected items
are not corrosion resistant.
Avoid washing items that are not
corrosion resistant in the dishwasher.
Items are blocking
the movement of
the spray arms.
Rearrange the items so that the spray
can rotate freely.
The filter combination
is not clean or is not
correctly fitted in the
base of wash cabinet.
This may cause the spray
arm jets to get blocked.
Clean and/or fit the filter correctly.
Clean the spray arm jets.
Knocking noise in
the dishwasher
Rattling noise in
the dishwasher
Interrupt the program and
rearrange the items which are
obstructing the spray arm.
Items of crockery
are loose in the
dishwasher.
Interrupt the program and
rearrange the items of crockery.
Knocking noise in
the water pipes
The dishes
are not clean
This may be caused
by on-site installation
or the cross-section
of the piping.
This has no influence on the
dishwasher function. If in doubt,
contact a qualified plumber.
See the “Preparing And Loading
Dishes”.
Select a more intensive program.
Not enough detergent
was dispensed.
Use more detergent, or change
your detergent.
●
A spray arm is knocking
against an item in a
basket
●
●
●
Cloudiness on
glassware.
Combination of soft
water and too much
detergent.
Use less detergent if you have soft
water and select a shorter cycle to
wash the glassware and to get
them clean.
●
The dishes were not
loaded correctly.
The program was
not powerful enough.
●
●
●
●
●
White film on
inside surface
Hard water minerals.
To clean the interior, use a damp
sponge with dishwasher detergent
and wear rubber gloves. Never use
any other cleaner than dishwasher
detergent otherwise, it may cause
foaming or suds.
●
Black or grey
marks on dishes
Detergent left in
dispenser
Aluminium utensils
have rubbed against
dishes
Use a mild abrasive cleaner to
eliminate those marks.
Dishes block
detergent dispenser
Re-loading the dishes properly.
●
●
31
Possible reason SolutionProblem
The dishes aren't
drying
Use gloves if detergent residue can
be found on dishes to avoid skin
irritations.
With a short program, the
washing temperature is lower,
decreasing cleaning performance.
Choose a program with a long
washing time.
Improper loading
●
Increase the amount of rinse-aid/refill
the rinse-aid dispenser.
Too little rinse-aid
●
●
Dishes are removed
too soon
Wrong program has
been selected.
●
Use of cutlery with a
low-quality coating.
●
Self-repair or non-professional repair may cause serious risks to the safety of the user
of the appliance and impact warranty.
Water drainage is more difficult with
these items. Cutlery or dishes of this
type are not suitable for washing in
the dishwasher.
Do not empty your dishwasher
immediately after washing. Open
the door slightly so that the steam
can come out. Take out the dishes
until the inside temperature is safe
to touch. Unload the lower basket
first to prevent the dropping water
from the upper basket.
Possible reason
Solution
Problem
E1
E3
E4
Faucets is not opened, or water
intake is restricted, or water
pressure is too low.
Not reaching required
temperature.
Malfunction of heating element.
Overflow.
Some element of dishwasher leaks.
Longer inlet time.
●
●
●
●
●
●
If overflow occurs, turn off the main water supply before calling a service.
If there is water in the base pan because of an overfill or small leak, the water should
be removed before restarting the dishwasher.
If there is an error code that cannot be solved, please request professional assistance.
ERROR CODES
If there is a malfunction the dishwasher will display an error code. The following table
shows possible error codes and their causes.
WARNING
WARNING
32
logo, word marks, trade name, trade dress and all versions thereof are
trademarks, copyrights and other intellectual property rights, and all goodwill derived
from using any part of an Midea trademark. Use of Midea trademark for commercial
purposes without the prior written consent of Midea may constitute trademark
infringement or unfair competition in violation of relevant laws.
This manual is created by Midea and Midea reserves all copyrights thereof. No entity or
individual may use, duplicate, modify, distribute in whole or in part this manual, or
bundle or sell with other products without the prior written consent of Midea.
All the described functions and instructions were up to date at the time of printing this
manual. However, the actual product may vary due to improved functions and designs.
TRADEMARKS, COPYRIGHTS
AND LEGAL STATEMENT
Important instructions for environment
Compliance with RoHS Directive
Package information
33
DISPOSAL AND RECYCLING
Compliance with the WEEE Directive and Disposing of the Waster Product:
This product complies with EU WEEE Directive (2012/19/EU). This product bears a
classification symbol for waster electrical and electronic equipment (WEEE).
This symbol indicates that this product shall not be disposed
with other household wastes at the end of its service life. Used
recycling of electrical electronic devices. To find these
collection systems please contact to your local authorities or
retailer where the product was purchased. Each household
performs important role in recovering and recycling of old
appliance. Appropriate disposal of used appliance helps
prevent potential negative consequences for the environment
and human health.
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does
not contain harmful and prohibited materials specified in the Directive.
Packaging materials of the product are manufactured from
recyclable materials in accordance with our National Environ-
ment Regulations. Do not dispose of the packaging materials
together with the domestic or other wastes. Take them to the
packaging material collection points designated by the local
authorities.
34
DATA PROTECTION NOTICE
For the provision of the services agreed with the customer,
we agree to comply without restriction with all stipulations of applicable data protection
law, in line with agreed countries within which services to the customer will be delivered,
as well as, where applicable, the EU General Data Protection Regulation (GDPR).
Generally, our data processing is to fulfil our obligation under contract with you and for
product safety reasons, to safeguard your rights in connection with warranty and
product registration questions. In some cases, but only if appropriate data protection is
ensured, personal data might be transferred to recipients located outside of the
European Economic Area.
Further information are provided on request. You can contact our Data Protection
[email protected]. To exercise your rights such as right to object your
personal date being processed for direct marketing purposes, please contact us via
[email protected]. To find further information, please follow the QR Code.
35
MIDEA
DISHWASHER
LIMITED
WARRANTY
ATTACH YOUR RECEIPT HERE. PROOF OF PURCHASE
IS REQUIRED TO OBTAIN WARRANTY SERVICE.
Please have the following information available when
you call the Customer Service Center:
Name, address and telephone number
Model number and serial number
A clear, detailed description of the problem
Proof of purchase including dealer or retailer
name and address
IF YOU NEED SERVICE:
1. Before contacting us to arrange service, please determine whether your product requires
repair. Some questions can be addressed without service. Please take a few minutes to
review the Troubleshooting section of the User Manual, or visit http://us.Midea.com/support
2. All warranty service is provided exclusively by our authorized Midea Service Providers, in the
U.S. and Canada.
Midea Customer Service
In the U.S.A. or Canada, call 1-866-646-4332.
If outside the 50 States of the United States or Canada, contact your authorized Midea dealer to
determine whether another warranty applies.
LIFETIME LIMITED WARRANTY
WHAT IS COVERED
FIRST YEAR LIMITED WARRANTY (PARTS AND LABOR)
For one year from the date of purchase, if this major appliance is installed, operated and
maintained according to instructions attached to or furnished with the product, Midea America
Corporation (hereafter “Midea”) will pay for factory specified replacement parts and repair
labor to correct defects in materials or workmanship that existed when this major appliance was
purchased, or at its sole discretion replace the product. In the event of product replacement, your
appliance will be warranted for the remaining term of the original unit’s warranty period.
LIFETIME LIMITED WARRANTY (STAINLESS STEEL TUB AND INNER DOOR LINER ONLY)
For the lifetime of the product from the date of original purchase, when this major appliance is
installed, operated and maintained acco
rding to instructions attached to or furnished with the
product, Midea will pay for factory specified parts and repair labor for the following components
to correct non-cosmetic defects in materials or workmanship that existed when this major
appliance was purchased:
Stainless steel tub
Inner door liner
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR OR REPLACEMENT AS PROVIDED HEREIN. Service must be provided by a Midea
designated service company. This limited warranty is valid only in the 50 States of the United
States or Canada and applies only when the major appliance is used in the country in which it
was purchased. This limited warranty is eective from the date of original consumer purchase.
Proof of original purchase date is required to obtain service under this limited warranty.
36
LIFETIME LIMITED WARRANTY
WHAT IS NOT COVERED
1. Commercial, non-residential or multiple-family use, or use inconsistent with published user,
operator or installation instructions.
2. In-home Instruction on how to use your product.
3. Service to correct improper product maintenance or installation, installation not in accordance
with electrical or plumbing codes or correction of household electrical or plumbing (i.e. house
wiring, fuses, plumbing or water inlet hoses).
4. Consumable parts (i.e. light bulbs, batteries, air or water filters, etc.).
5. Defects or damage caused by the use of non-genuine Midea parts or accessories.
6. Damage from accident, misuse, abuse, fire, floods, electrical issues, acts of God or use with
products not approved by Midea.
7. Repairs to parts or systems to
correct product damage or defects caused by unauthorized
service, alteration or modification of the appliance.
8. Cosmetic damage including scratches, dents, chips, and other damage to appliance finishes
unless such damage results from defects in materials and workmanship and is reported to
Midea within 30 days.
9. Routine maintenance of the product.
10. Discoloration, rust or oxidation of surfaces resulting from caustic or corrosive environments
including but not limited to high salt concentrations, high moisture or humidity or exposure to
chemicals.
11. Pick-up or delivery. This product is intended for in-home repair.
12. Travel or transportation expenses for service in remote locations where an authorized Midea
servicer is not availabl
e.
13. Removal or reinstallation of inaccessible appliances or built-in fixtures (i.e. trim, decorative
panels, flooring, cabinetry, islands, countertops, drywall, etc.) that interfere with servicing,
removal or replacement of the product.
14. Service or parts for appliances with original model/serial numbers removed, altered or not
easily identified.
The cost of repair or replacement under these excluded circumstances shall be borne by the
customer.
DISCLAIMER OF IMPLIED WARRANTIES
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE
YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states and provinces do not allow
limitations on the duration of implied warranties of merchantability or fitness, so this limitation
may not apply to you. This warr
anty gives you specific legal rights, and you also may have other
rights that vary from state to state or province to province.
DISCLAIMER OF REPRESENTATIONS OUTSIDE OF WARRANTY
Midea makes no representations about the quality, durability, or need for service or repair of this
major appliance other than the representations contained in this warranty. If you want a longer
or more comprehensive warranty than the limited warranty that comes with this major appliance,
you should ask Midea or your retailer about buying an extended warranty.
LIMITATION OF REMEDIES; EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE
PRODUCT REPAIR AS PROVIDED HEREIN. MIDEA SHALL NOT BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES. Some states and provinces do not allow the exclusion or limitation
of incidental or
consequential damages, so these limitations and exclusions may not apply to you.
This warranty gives you specific legal rights, and you also may have other rights that vary from
state to state or province to province.
00000000000000
此红框内丝印此用户手册对应的14位物料编码 红色框不需印刷
字体为Gotham-Book 8pt 位置大小严格按图纸操作
